Matrix MIN600SI Reference manual

Cod:0103086447-00.03

Declarations of Conformity:
This appliance has been manufactured to comply with all EU & UK
statutory requirements and complies with all applicable legislation
and the following European Directives:
• The Low Voltage Directive 2014/35/EU
• Electromagnetic Compatibility Directive 2014/30/EU
The product has been marked with the UKCA and CE symbols.

This appliance is marked according to the European directive
2004/104/EC on Waste Electrical and Electronic equipment (WEEE).

4
• This extractor has been designed to be used in a room with a
volume of less than 36 m3.
• Steam cleaners must not be used when cleaning this appliance.
• The performance of your extractor will vary depending on a number
of factors. These include: type of extraction, length of ducting, room
volume, ventilation available and cleanliness of the filters.

6
Care and Maintenance
IMPORTANT : DO NOT PERFORM MAINTENANCE OR CLEANING OF
THE EXTRACTOR WITHOUT FIRST SWITCHING OFF THE ELECTRICITY
SUPPLY.
Cleaning
You should use a nonabrasive cleaner. Any abrasive cleaner
(including Cif) will scratch the surface and could erase the
control panel markings.
You can clean your extractor effectively by simply using a dilute
solution of water and mild detergent and drying to a
shine with a clean cloth, for example a clean microfibre cloth.
Cleaning the (rectangular) grease filter
The grease filter captures grease particles in the air, so is therefore
subject to clogging depending on the frequency of use of the
appliance.
In order to prevent fire hazard it is recommended to clean the
grease filter at a maximum of 2 month intervals by carrying out these
instructions:
Depending on model, you may have either acrylic or aluminium
grease filter(s).
Acrylic grease filter:
1. Remove the cover panel by pushing the fixing clips up and then
lifting the panel forwards.

7
2. Remove the filter retaining wires from the cover panel.
3. Remove the grease filter and wash by hand in a lukewarm
solution of water and mild detergent. Once clean squeeze
the grease filter but DO NOT wring it out. Clean the filter holder
using a dilute solution of water and mild detergent or with a
damp cloth. Allow the grease filter to dry completely before
reassembling the extractor.
4. Replace the grease filter in the cover panel and reattach the
filter retaining wires.
5. Replace the cover panel by inserting the lugs on the upper side
in the extractor, and then refasten the fixing clips on the lower
side.
Aluminium grease filters:
1. Remove the filters from the cooker hood and wash in a solution of
warm water and neutral liquid detergent, leaving to soak.
2. Rinse thoroughly with warm water and leave to dry.
3. The filters may alternatively be washed in the dishwasher. The
aluminium panels may alter in colour after several washes in a
dishwasher. This is not a fault and is not cause for replacing the
panels.
Changing the (circular) charcoal filter (re-circulating only):
To ensure best performance of your extractor, you should replace the
charcoal filters every four to six months,
depending on use. ks into position.
3. Replace the cover panel or grease filter that has been removed.

8
Replaceable (LED only) light Fig.1-I
Fig.1-II
Fig.1-III
source by an end-user
LED LED
E14 LED 4Wx1
DR-4-H-E14-37

9
Only use bulbs recommended for your extractor. Do not fit bulbs of a
higher power rating. Bulbs of a lower power rating may be adequate
for use, generally last longer and use less energy.
Spare bulbs are available from CDA Customer Care.

10
Installation requirements
When the extractor is to be installed above an electric hob, the
minimum distance between the hob and extractor must exceed
600mm (650mm is recommended).
When the extractor is to be installed above a gas hob, the minimum
distance between the hob and extractor must exceed 700mm (750mm
is recommended).
If the instructions provided with your gas hob state that the required
distance between the hob and extractor must be greater than 700mm,
then that is the distance that should be observed; this is a legal
requirement and may lead to your hob being disconnected from the
gas supply and the installation being reported to RIDDOR (The height
should be measured from the top of the burners).
NOTE: IN THE ABSENCE OF ANY
INSTRUCTIONS SUPPLIED WITH
THE GAS HOB, THE MINIMUM
DISTANCE BETWEEN THE HOB
AND EXTRACTOR MUST BE AT
LEAST 760mm.
The width of any hob must not
be greater than the width of the
extractor installed above it.
Fig. 2
Gas: 750mm recommended
Electric: 650mm recommended
Hob

11
55
553
23.5
Adjacent Cabinet
Installation procedure
1. Mark the positions of the fixing holes on the wall using the
dimensions shown in Fig. 3.
2. Drill and plug the wall with appropriate fixings, suitable for the wall
type you are fixing the extractor on.
3. Mount the brackets and securely tighten.
4. Hang the hood on the brackets and adjust the brackets and
height to suit. The adjustment mechanism is shown in Fig. 4.
5. Once the hood is levelled and square against the wall, adjust the
bottom panel as required (Fig. 5).
6. Secure the extractor to the adjacent units through the holes
in the side of the product, to ensure that it cannot be
accidentally knocked off the hanging brackets.
Fig. 3
55

12
Fig4
Fig. 5
Mains Electricity Connection
THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY
A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE
SWITCHED FUSED SPUR OUTLET AND PROTECTED BY A 3A FUSE.
We recommend that the appliance is connected by a qualified
electrician, who is a member of the N.I.C.E.I.C. and who will comply
with the I.E.T. and local regulations.
The wires in the mains lead of this appliance are coloured in
accordance with the following code:
BLUE = NEUTRAL, BROWN = LIVE.

13
As the colours of the wires in the mains lead for the appliance may
not correspond with the coloured markings identifying the terminals
connecting to the fused spur, proceed as follows:
• The wire which is coloured blue must be connected to the terminal
marked N (Neutral), or coloured black.
• The wire which is coloured brown must be connected to the
terminal marked L (Live), or coloured red.
NOTE: USE A 3A FUSE
Assembly and electrical connection should be carried out by
competent personnel.
When installing this product we recommend you seek the help of
another individual.
IMPORTANT: THIS APPLIANCE IS A CLASS II APPLIANCE (DOUBLE
INSULATED) AND IS NOT INTENDED TO BE EARTHED. DO NOT FIT AN
EARTH LEAD TO THIS EXTRACTOR.
Do not mount the isolation switch behind the chimney section. It is a
requirement that you must be able to isolate the
extractor from the mains electrical supply after installation.
This appliance is intended to be connected to the mains electrical
supply by means of an isolation switch and fused spur and is
intended to be protected by a 3A fuse. The use of a 13A fuse can
cause damage to the internal wiring in the event of a fault, and may
also invalidate the warranty.

14
Electrical Information
Mains electrical voltage: 230 – 240Vac.
Total rated power consumption: 49W.
Troubleshooting
If your extractor is not working:
1. Check that the mains supply has not been switched off.
2. Check that the fuse in the spur has not blown.
Contact CDA Customer Care
A : Customer Care Department, The CDA Group Ltd, Harby Road,
Langar, Nottinghamshire, NG13 9HY
T : 01949 862 012 F : 01949 862 003
E : customer.car[email protected] W : www.cda.eu
DOUBLE POLE SWITCHED
FUSED SPUR OUTLET
USE A 3 AMP FUSE

15
Attribute Symbol Units
I/1S06NiMnoitacifitnedI ledoM I 0
Annual Energy Consumption AECHood 26.6 kWh
Time increase factor f 1.7
Fluid Dynamic Eciency FDEHood 8.6
Energy Eciency Index EEIHood 69.1
Measured airflow at Best Eciency
Point
QBEP 99.2 m3/h
Measured Pressure at Best Eciency
Point
PBEP 120.0 Pa
Qwolfria mumixaM MAX 193.2 m3/h
Measured electric power at Best
Eciency Point
WBEP 38.2 W
Nominal lighting power WL 4 W
Average illumination of the lighting
system on the cooking surface
EMiddle 55.0 Lux
Measured power consumption in
standby
PS-- W
Measured power consumption o
mode
PO0.0 W
Sound power level LWA 62.0 dBA
Grease Filter Eciency GFEHood 70 %
ELycneiciffe pmaL Hood
Energy Efficiency Information
Value
14 %
