General information
The equipment must be set up where it can stand securely, i.e. it should be bolted to a workbench, a
universal base frame or similar.
All covers and safety devices have to be properly fitted before the equipment is switched on. ͻIt must be
possible for the blade to run freely.
When working with wood that has been processed before, watch out for foreign bodies such as nails or
screws, etc.
Before you actuate the On/Off switch, make sure that the saw blade is correctly fitted and that the
equipment’s moving parts run smoothly.
5.2 Setting up the saw (Fig. 3)
The workpiece supports must be inserted and tightened using a Phillips screwdriver. Screwdriver not
included in delivery.
5.3 Adjusting the saw (Fig. 1/2)
ͻTo adjust the turntable (8), loosen the knurled screw (10) by approx. 2 turns, which frees the turntable.
ͻThe turntable has locking points at angles of 0°, 5°, 10°, 15°, 22,5°, 30°, 35°, 40°, 45°. Once the turntable
is engaged, the setting must be additionally secured by tightening the knurled screw (10).
ͻIf different angle settings are required, the turntable (8) may be secured in position using only the
knurled screw (10).
ͻLightly press the machine head (4) down while at the same time pulling the retaining pin (16) out from
the motor mounting; this causes the saw to move down to the lower working position.
ͻSwing up the machine head (4).
ͻBy loosening the lock screw (12), the machine head (4) can be angled to the left up to 45°.
ͻCheck that the voltage marked on the rating plate is the same as your mains voltage and connect up the
machine.
5.4 Precision adjustment of the stop rail (Fig. 7/8)
ͻLower the machine head (4) and fasten in place with the safety pin (16).
ͻFasten the turntable (8) in 0° position.
ͻPlace the 90° stop angle (a) between the blade (5) and the stop rail (7).
ͻSlacken the adjustment screws (28), set the stop rail (7) to 90° in relation to the saw blade (5) and
retighten the adjustment screws (28).
5.5 Precision adjustment of the stop for 90°cross-cuts (Fig. 8-10)
ͻLower the machine head (4) and fix with the lock pin (16).
ͻSlacken the tightening screw (12).
ͻPlace the stop angle (a) between the saw blade (5) and the rotary table (8).
ͻSlacken the counter nut (29) and adjust the setting screw (18) until the angle between the saw blade (5)
and the rotary table (8) equals 90°.
ͻRe-tighten the counter nut (29) to fix the machine in this setting.
ͻFinally, check the position of the angle indicator (11). If necessary, release the pointer with a crosstip
screwdriver, move to the 0° position of the angle scale (15) and retighten the holding screw.
ͻNo stop angle included.
5.6 Precision adjustment of the stop for 45°mitre cuts (Fig. 8/12)
ͻLower the machine head (4) and fix with the lock pin (16).
ͻFix the rotary table (8) in 0° position.
ͻUndo the tightening screw (12) and use the handle (2) to tilt the machine head (4) to the left until it
coincides at 45°. ͻPlace the 45° stop angle (b) between the saw blade (5) and the rotary table (8).
ͻSlacken the counter nut (30) and adjust the setting screw (19) until the angle between the saw (5) and
the rotary table (8) equals exactly 45°.
ͻNo stop angle included.
6. Operation
6.1 Crosscut 90° and turntable 0° (Fig. 1)
