Maxair 2260-05 DLC Shroud User manual

01023577 Rev B Page 1
Bio-Medical Devices Intl 17171 Daimler Street Irvine, CA 92614 800-443-3842 www.maxair-systems.com
Intended Use
The MAXAIR®CAPR® Shroud Systems are intended to lter
aerosolized and droplet particulates.
Shrouds are designed for single use applications.
For Use With
The MAXAIR 2260-05 DLC-Shroud is a component of the
MAXAIR CAPR Shroud Systems and is intended to be donned with a
MAXAIR CAPR Powered Air Purifying Respirator (PAPR)
Helmet and a Filter Cartridge.
O.N. 2260-05SM
(Small-Medium)
O.N. 2260-05ML
(Medium-Large)
WARNING
Use only if package is received unopened and contents are
undamaged. If damage is noted, contact the shipper for replacement
or repair.
Prior to using any MAXAIR® System or component, be sure to be
familiar with the system’s NIOSH approved conguration.
DO NOT use if any component is damaged. If any components are
damaged or contaminated and therefore unt for safe and effective
use, they should be replaced immediately.
Only trained and experienced personnel who have read and under-
stand the User’s Instructions should use this product.
Failure to follow the User’s Instructions Manual may be hazardous to
the user’s health.
The institution using this product in any application is responsible for
determining the appropriateness of this equipment relative to regula-
tory requirements. Bio-Medical Devices Intl, Inc. does not recommend
the appropriate systems for a particular institution or facility.
Use only MAXAIR Systems/ NIOSH approved compatible
components.
NOT for use in atmospheres immediately dangerous to life or health
(IDLH), and atmospheres containing less than 19.5% oxygen, or
more than 25% oxygen.
Flammability Level II: fabric may burn if exposed to open ame.
Follow current local regulations governing biohazard waste to safely
dispose of used shrouds.
If you need more information, contact your BMDI Sales
Representative, or call BMDI customer service at 1-800-443-3842.
CAUTION: Before use, refer to the CAPR System User’s Instructions Manual received with each MAXAIR Helmet for
details. Always start with a 2260-05ML unless the wearer has a very small head (Bottom, page 3.).
!
2260-05 DLC Shroud
Instruction For Use
Symbol Denitions
Warning, Caution, or Note
Order Number Part Number
!
O.N. PN
!
Standard CAPR System with 2260-05 DLC Shroud
1. 2081-03 Helmet
(2081-03 Helmet, 2051-07
SnapOn Cage removed, 2071-
06 Liner, 2590-05 Power Cord)
2. 2164-10 Filter Cartridge*
3. 2061-08 Filter Cover Cap
4. 2500-36TSC Battery** 5. 2000-76 Battery Belt
6. 2600-01 Battery Charger 7. 2260-05 DLC Shroud
*Alternate Filter Cartridges include the 2166-10 and 2167-10.
**Alternate Baeries include the 2500-37TSC.
Materials
DLC Lens is PETG
DLC Cuff is Polyurethane
Shroud body is Polypropylene
Specicaons
Temperature Limits: 490C
Eciency Rang: HE
Regulatory
NIOSH
1
5 6
32
7
4

Bio-Medical Devices Intl 17171 Daimler Street Irvine, CA 92614 800-443-3842 www.maxair-systems.com
Page 2 01023577 Rev B
2260-05 DLC Shroud
Instruction For Use
Assembly to Helmet
1.Remove Shroud from packaging;
note Shroud is turned inside-out to
mount to Helmet.
3. Turn FCC front TurnClip horizontal and
aach Shroud front Mounng Hole
over TurnClip. Turn TurnClip vercally to
secure the aachment.
5. Snap one side of DLC onto one
side FFC Aachment Post; then
snap other side.
7. Pull Shroud over and down
the back of the Helmet.
8. Use Pull Tap to posion Shroud Rear Snap
over FCC Rear Snap; snap and secure.
Disassembly
Reverse Asssembly steps to remove Shroud from Helmet.
WARNING
Dispose of contaminated Shrouds according to instuonal protocol for contaminated waist.
2. Grasp top of DLC Cu and pull
gently away from Lens so that
Cu and Flappers are away
from Lens.
6. Hold helmet securely, grasp Shroud’s
rear Pull Tab and pull shroud up and
over helmet.
9. Snap and secure le Rear Side Snaps
between Shroud and FCC. Then
repeat on right Rear Side Snaps.
4. Pull Shroud top fabric up over the
front TurnClip and tuck it in under
and/or close to the FCC boom
edge all around FCC.

Bio-Medical Devices Intl 17171 Daimler Street Irvine, CA 92614 800-443-3842 www.maxair-systems.com
Page 3 01023577 Rev B
2260-05 DLC Shroud
Instruction For Use
Donning
2. Connect Helmet Power Cord
to Baery; push Power Cord
Connector into the Baery
Receptacle unl the Secure
Connecon audibly clicks.
3. Loosen headband
Ratchet Knob
(counterclockwise).
4. Pull top of DLC
Cu down to insert
chin while pulling
Helmet over and
down on head.
5. Tighten Ratchet Knob
secure as comfortably
possible, while
ensuring stability.
7. Pull back of shroud up and over the
Helmet. Slide ngers between face and
cu on both sides from chin to temples
to ensure slight Cu-to-Face tension.
6. Posion front headband within ½ inch
of eyebrows for visualizaon of the
Safety LEDs.
WARNING
After donning, if conditions 1 and 2 both are not achieved, switch to the other
size DLC and repeat the Assembly and Donning steps to this point.
Condion 1: Ensure the DLC Flappers
are away from the Lens, posioned
perpendicular to your temples, and in
front of the FCC Side Tabs.v
Condion 2: Ensure slight tension on the cu is
felt connuously while sliding the index or rst
nger between the cu and the face all along the
chin and up to the temples, from the right side of
the face to the le.
1. Assemble the Baery onto the Belt -
Place top edge of Belt under Baery
Clip such that Clip detent touches
Clip not Belt. Don by placing belt
comfortably around waist with baery
near the side-back of the right hip.
DLC Flappers
FCC Side Tabs
≤ 1/2
Inch
(~1.25 cm)

Bio-Medical Devices Intl 17171 Daimler Street Irvine, CA 92614 800-443-3842 www.maxair-systems.com
Page 4 01023577 Rev B
2260-05 DLC Shroud
Instruction For Use
WARNING
Refer to Users Instrucons
(P/N 03521015) for details on
chargers and charging baeries.
10. Pull neck es around to the
front and e securely, leaving
about a ½ inch gap between
neck and Shroud. Pull waist
es around and e in front.
8. Connue pulling Shroud down all around.
Dong
9. Don outer body gown
under the shoud per
gown manufacturer’s
instrucons.
3. Connue rolling while bringing
shroud to front, pulling Lens o the
Helmet. Connue pulling foward
away from the body and discard.
2. While pulling up the shroud
from the boom back, roll the
shroud inside-over-outside, up
and over the Helmet.
1. Une all es.
4. Remove other PPE
per manufacturers’
recommendaons.
7. Li Helmet up,
foreward, and o the
head.
6. Loosen Ratchet Knob
(counterclockwise).
8. Disconnect Power Cord from
the Baery - push Secure
Connecon Buon down,
pull Cord Connector out,
release the Buon.
9. Disconnect the Baery Belt
from around the waist by un-
snapping the buckle.
10. Connect Charger to mains wall power,
connect the Charger Cord to the Baery.
Push the Charger Cord Connector into the
Baery Receptacle unl it is fully seated.
The enre CAPR System may be
decontaminated, cleaned and/
or stored at this me.
5. Discard all
disposables per
instuonal
protocal for
contaminated
waste.
