MAXI30 Installation Manual
Phase 7 / Dual Timer / S.A.F.E. System
WARNING:Foryoursafetytheinformation
in this manual must be followed to
minimize the risk of fire or explosion and
to prevent property damage, personal
injuryordeath.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinityof thisor anyother appliance.
— WHATTO DOIFYOU SMELLGAS:
●Donot tryto lightany appliance.
●Donot touchanyelectrical switch;
donot useanyphone inyour
building.
●Cleartheroom, building or areaof
alloccupants.
●Immediatelycallyourgassupplier
froma neighbor’sphone. Follow
thegas supplier’sinstructions.
●Ifyoucannotreachyourgas
supplier, callthe firedepartment.
— Installation and service must be
performedbyaqualifiedinstaller,service
agencyor thegas supplier.
AVERTISSEMENT:Assurez-vousdebien
suivrelesinstructionsdonnéesdanscette
noticepour réduireau minimumle risque
d’incendie ou d’explosion ou pour éviter
toutdommagematériel,touteblessureou
lamort.
—Ne pas entreposer ni utiliser d’essence
nid’autres vapeursou liquides
inflammablesà proximité decet
appareilou de toutautre appareil.
—QUEFAIRESIVOUS SENTEZUNE
ODEURDEGAZ:
●Nepas tenter d’allumerd’appareils.
●Netouchezà aucuninterrupteur. Ne
pasvous servirdestéléphones se
trouvantdansle bâtiment.
●Évacuezla pièce,lebâtiment oula
zone.
●Appelezimmédiatement votre
fournisseurde gazdepuis unvoisin.
Suivezlesinstructions dufournisseur.
●Sivous nepouvez rejoindrele
fournisseurde gaz,appelez leservice
desincendies.
—L’installation et l’entretien doivent être
assurés par un installateur ou un
service d’entretien qualifié ou par le
fournisseurdegaz.
Maxidry
Part No. 113260-4

2113260-4
“IMPORTANT NOTE TO PURCHASER”
Information must be obtained from your local gas supplier on the
instructions to be followed if the user smells gas. These
instructionsmust beposted ina prominentlocation nearthe dryer.
FOR YOUR SAFETY
Do not store or use gasoline
orother flammablevapors
andliquids inthe vicinityof
thisor anyother appliance.
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence
nid’autres vapeursou liquides
inflammablesà proximité decet
appareilou de toutautre appareil.
Wehavetriedtomakethismanualas complete as possibleandhopeyou will find ituseful. Themanufacturer
reserves the right to make changes from time to time, without notice or obligation, in prices, specifications,
colors, and material, and to change or discontinue models. The illustrations included in this manual may
not depict your particular dryer exactly.
IMPORTANT
For your convenience, log the following information:
DATEOFPURCHASE ______________________________________________________MODELNO. _________________
RESELLER’SNAME ___________________________________________________________________________________
SERIALNUMBER(S) ___________________________________________________________________________________
____________________________________________________________________________________________________
____________________________________________________________________________________________________
Retain This Manual in a Safe Place for Future Reference
This product embodies advanced concepts in engineering, design, and safety. If this product is properly
maintained, it will provide many years of safe, efficient, and trouble free operation.
Only qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation
manual included with the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
MAXI30
These instructions are only valid if the following country code is on the appliance… If this code is not
presentonthe appliance, it is necessary to refer to the technical instructions which will providethenecessary
information concerning the modification of the appliance to the condition of use for the country.
In accordance with EN ISO 3166-1, the names of countries shall be represented by the following codes:
GB United Kingdom
IE Ireland

113260-4 3
List of Acronyms _____________________
D.M.S. Drill Measurement Size
HVAC Heating, Ventilating, and Air-Conditioning
inWC Inches of Water Column
L.C.D. Liquid Crystal Display
L.E.D. LightEmitting Diode
L.P. Liquid Propane
OSHA Occupational Safety
and Health Administration
S.A.F.E. Sensor Activated Fire Extinguishing
UL Underwriters Laboratory
Table of Contents ______________
IMPORTANT
You must disconnect and lockout the electric supply and the
gas supply or the steam supply before any covers or guards
are removed from the machine to allow access for cleaning,
adjusting, installation, or testing of any equipment per OSHA
standards.
Please observe all safety precautions displayed on the
equipmentand/or specifiedinthe installation manualincluded
with the dryer.
Beforeinstallation, check thatthelocal distribution conditions,
natureof gas and pressure, and adjustmentoftheappliances
are compatible.
CAUTION
Dryer(s) should never be left unattended while in operation.
When discarding or storing your old clothes dryer,
remove the door.
Lorsque vous entreposez ou mettez votre sécheuse
au rebut, enlevez-en la porte.
“Caution:Label allwirespriorto disconnectionwhenservicing
controls. Wiring errors can cause improper operation.”
«Attention: Au moment de l’entretien des commandes,
étiquetez tous les fils avant de les débrancher. Des erreurs
de câblage peuvent entraîner un fonctionnement inadéquat
etdangereux.»
WARNING
Childrenshould not be allowedtoplayon or near thedryer(s).
Children should be supervised if near dryer(s) in operation.
Under no circumstances should the dryer door switch(es),
lint door/drawer switch(es), or heat safety circuit(s) ever be
disabled.
Do not modify this appliance.
Thedryer mustneverbe operatedwithanyof thebackguards
orservicepanelsremoved. Personal injuryorfire couldresult.
Thedryer must never be operatedwithoutthelintfilter/screen
in place, even if an external lint collection system is used.
If the hi-limit switch trips, a service call is required to
investigate the reason and resolve the issue.
FOR YOUR SAFETY
Donotdrymopheadsinthedryer. Donotusedryerinthe
presence of dry cleaning fumes.
The dryers must not be installed or stored in an area where it
will be exposed to water and/or weather.
Thewiring diagram for the dryeris located behind the control
panel.
Proposition 65
Use of this product could expose you to substances
from fuel combustion that contain chemicals
known to the State of California to cause cancer,
birth defects and other reproductive harm.
!WARNING In the State of Massachusetts, the following
installation instructions apply:
■Installations and repairs must be performed
by a qualified or licensed contractor,
plumber, or gasfitter qualified or licensed
by the State of Massachusetts.
■If using a ball valve, it shall be a T-handle
type.
■A flexible gas connector, when used, must
not exceed 3 feet.
Safety Precautions ....................................................4
Specifications .............................................................5
Installation Procedures............................................7
Unpacking / Setting Up...............................................7
Location Requirements ..............................................7
Dryer Enclosure Requirements .................................7
Fresh Air Supply Requirements ................................8
Exhaust Requirements...............................................8
Electrical Information................................................10
Gas Information........................................................14
Steam Information ....................................................16
Preparation for Operation / Start-Up.......................18
Preoperational Test ..................................................18
Preoperational Instructions .....................................19
Shutdown Instructions ............................................20
Service / Parts Information ...................................20
Service .....................................................................20
Parts..........................................................................20
Routine Maintenance ..............................................20
Cleaning ....................................................................20
Adjustments .............................................................21
Lubrication................................................................21
Data Label Information ...........................................21
Procedure for Functional Check
of Replacement Components ..............................22
Manual Reset
Burner Hi-Limit Instructions.................................23
Phase 7 ....................................................................23
DualTimer.................................................................23
S.A.F.E. System .........................................................24
Non-Coin Programming .........................................27
Coin Programming ..................................................28

4113260-4
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
Do not spray aerosols in the vicinity of this appliance while
it is in operation.
Purchaser and user should consult the local gas supplier
for proper instructions to be followed in the event the user
smells gas. The instructions should be posted in a
prominent location.
What To Do If You Smell Gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Clear the room, building, or area of all occupants.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a qualified
installer, service agency, or gas supplier.
Dryers must be exhausted to the outdoors.
Although the manufacturer produces a very versatile dryer,
there are some articles that, due to fabric composition or
cleaning method, should not be dried in it.
Safety Precautions ___________________
!WARNING
For your safety, the information in this manual must
be followed to minimize the risk of fire or explosion or
to prevent property damage, personal injury, or loss
of life.
The dryer must never be operated with any of the
back guards, outer tops, or service panels removed.
Personal injury or fire could result.
!WARNING
You must disconnect and lock out the electric supply
and the gas supply or the steam supply before any
covers or guards are removed from the machine to
allow access for cleaning, adjusting, installation, or
testing of any equipment per OSHA standards.
!WARNING
Articles left in the dryer after the drying and cooling
cycles have been completed can create a fire hazard.
!WARNING
Personal injury or fire could result should the dryer
door switch, lint door switch, or heat safety circuit
ever be disabled.
!WARNING
Dry only water washed fabrics. Do not dry articles
spotted or washed in dry cleaning solvents, a
combustible detergent, industrial chemicals, or “all
purpose” cleaner. Explosion could result.
Do not dry rags or articles coated or contaminated
with gasoline, kerosene, oil, paint, or wax. Explosion
could result.
Do not dry mop heads. Contamination by wax or
flammable solvents will create a fire hazard.
Do not use heat for drying articles that contain plastic,
foam, sponge rubber, or similarly textured rubber
materials. Drying in a heated tumbler may damage
plastics or rubber and may be a fire hazard.
IMPORTANT: Dryer must be installed in a location/
environment, which the ambient temperature remains
between 40º F (4.44º C) and 130º F (54.44º C).
CE ONLY
IMPORTANT: This appliance must only be installed and
operated in the country of destination indicated on the
dryer’s data plate. If the appliance is to be installed and
operated in a country other than the one indicated on the
data plate, a data plate amendment must be obtained
from Maxidry.
IEC335 applies.
Read and follow all caution and direction labels attached to
the dryer.
For safety, proper operation, and optimum performance, the
dryer must not be operated with a load less than sixty-six
percent, 19 lb (8.61 kg) of its rated capacity.
This dryer is not to be used in the presence of dry cleaning
solvents or fumes.
Remove articles from the dryer as soon as the drying cycle
has been completed.
For personal safety, the dryer must be electrically grounded
in accordance with local codes and/or the National Electrical
Code ANSI/NFPA NO. 70-LATEST EDITION or in Canada,
the Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990
or LATESTEDITION.
NOTE: Failure to electrically ground the dryer properly will
void the warranty.
Under no circumstances should the dryer door switch, lint
door switch, or heat safety circuit ever be disabled.
!WARNING
The collection of lint in the burner area and exhaust
ductwork can create a potential fire hazard.
The possible presence of residual quantities of aggressive
or decomposed chemicals in the load may produce damage
to the machine and harmful fumes.
A program should be established for the inspection and
cleaning of lint in the burner area, exhaust ductwork, and
areaaroundthe backofthe dryer. Thefrequencyof inspection
and cleaning can best be determined from experience at
each location.

113260-4 5
Specifications _____________________________________________________________________
)THGIEWYRD(YTICAPACMUMIXAMbl03 gk6.31
RETEMAIDRELBMUT”4/3-23 mc2.38
HTPEDRELBMUT”8/5-52 mc1.56
EMULOVRELBMUTtfuc5.21 L6069.353
ROTOMEVIRD/RELBMUT
gnisreveR/gnisreveR-noN ph2/1/ph2/1 *Wk373.0/Wk373.0
ROTOMNAF/REWOLB
gnisreveR/gnisreveR-noN ph2/1/ph— *Wk373.0/Wk—
)RETEMAID(GNINEPOROOD”2/1-12 mc16.45
THGIEHLLISROOD”8/1-33 mc51.48
NOITCENNOCRETAW HN5.11-4/3
)aciremAhtroN(
.T.P.S.B”4/3 )aciremAhtroNedistuO(
RENIATNOC’04/’02REPSREYRD 62/21
KCURT’35/’84REPSREYRD 23/03
ELBALIAVAEGATLOV zH06/05w4,3,2ø3,1V084-021
THGIEWTENETAMIXORPPAbl435 gk242
THGIEWGNIPPIHSETAMIXORPPAbl175 gk952
WOLFRIA zH06 mfc064 mmc31
zH05 mfc383 mmc58.01
TUPNITAEHrh/utB000,001 rh/lack002,52
)RETEMAID(NOITCENNOCTSUAHXE”8mc23.02
NOITCENNOCRIADESSERPMOC A/N
EMULOVRIADESSERPMOC A/N
NOITCENNOCEPIPTELNI .T.P.N.M”2/1 .T.P.S.B”2/1
)ylnOailartsuAdnaEC(
ELBALIAVAEGATLOV zH06/05w4,3,2ø3,1V064-802
THGIEWTENETAMIXORPPAbl435 gk242
THGIEWGNIPPIHSETAMIXORPPAbl175 gk952
WOLFRIA zH06 mfc064 mmc31
zH05 mfc383 mmc58.01
)RETEMAID(NOITCENNOCTSUAHXE”8mc23.02
NOITCENNOCRIADESSERPMOC A/N
EMULOVRIADESSERPMOC A/N
EZISNEVO
Wkrh/utB rh/lack
02002,86 002,71
42009,18 006,02
ELBALIAVAEGATLOV zH06/05w4,3,2ø3,1V084-021
THGIEWTENETAMIXORPPAbl395 gk962
THGIEWGNIPPIHSETAMIXORPPAbl136 gk682
WOLFRIA zH06 mfc064 mmc31
zH05 mfc383 mmc58.01
NOITPMUSNOCMAETSrh/bl401 rh/gk2.74
ERUSSERPMAETSGNITAREPOxamisp521 rab6.8
)RETEMAID(NOITCENNOCTSUAHXE”8mc23.02
NOITCENNOCRIADESSERPMOC .T.P.N.F”8/1
EMULOVRIADESSERPMOChfc5.0 hmc410.0
)DAOLLAMRON(REWOPESROHRELIOB phB0.3
NOITCENNOCYLPPUS .T.P.N.F”1
NOITCENNOCNRUTER .T.P.N.F”1
GASELECTRIC
STEAM**
Shaded areas are stated in metric equivalents 1/5/04
* Reversing dryer available with 3-phase (3ø) 1/2 hp (0.373 kW) motor standard.
** Specify air-operated or electromechanical steam damper system. Air-operated steam damper system must be provided with
clean, dry and regulated 80 psi ± 10 psi (5.51 bar ± 0.68 bar) air supply.
NOTE: The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.

6113260-4
Specifications _____________________________________________________________________

113260-4 7
Installation Procedures ______________
Installation should be performed by competent technicians
in accordance with local and state codes. In the absence of
these codes, the installation must conform to applicable
American National Standards: ANSI Z223.1-LATEST
EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70-
LATEST EDITION (National Electrical Code) or in Canada,
the installation must conform to applicable Canadian
Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/
CGA-B149.2-M91(L.P.Gas)orLATESTEDITION(forGeneral
Installation and Gas Plumbing) or Canadian Electrical
Codes Parts 1 & 2 CSAC22.1-1990 or LATEST EDITION (for
Electrical Connections).
Unpacking / Setting Up _______________
Remove protective shipping material (i.e., plastic wrap and
optional shipping box) from dryer.
IMPORTANT: Dryer must be transported and handled in
an upright position at all times.
The dryer can be moved to its final location while still
attached to the skid or with the skid removed. To unskid the
dryer, locate and remove the four bolts securing the base of
the dryer to the wooden skid. Two are at the rear base
(remove the back panel for access), and two are located in
the bottom of the lint chamber. To remove the two bolts
located in the lint chamber area, remove the lint door.
With the skid removed, to make it easier to slide the dryer
into its final position, slightly lower all four leveling legs, so
that the dryer will slide on the legs instead of the base frame.
Leveling Dryer
The dryer is equipped with four leveling legs, one at each
corner of the base. Two are located at the rear of the dryer
base, and two are located in the lint chamber (coop). To
increase bearing life and improve efficiency, the dryer should
be tilted slightly to the rear.
Location Requirements ______________
Before installing the dryer, be sure the location conforms to
local codes and ordinances. In the absence of such codes
or ordinances the location must conform with the National
FuelGasCodeANSI.Z223.1LATESTEDITION, or inCanada,
the installation must conform to applicable Canadian
Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/
CGA-B149.2-M91(L.P.Gas)orLATESTEDITION(forGeneral
Installation and Gas Plumbing).
The dryer must be installed on a sound level floor capable
of supporting its weight. Carpeting must be removed from
the floor area that the dryer is to rest on.
IMPORTANT: “The dryer must be installed on
noncombustible floors only.”
The dryer must not be installed or stored in an area where it
will be exposed to water and/or weather.
The dryer is for use in noncombustible locations.
Provisions for adequate air supply must be provided as
noted in this manual (refer to Fresh Air Supply
Requirements).
Clearance provisions must be made from noncombustible
construction as noted in this manual (refer to Dryer
Enclosure Requirements).
Provisions must be made for adequate clearances for
servicing and for operation as noted in this manual (refer to
Dryer Enclosure Requirements).
Dryer must be exhausted to the outdoors as noted in this
manual (refer to Exhaust Requirements).
Dryer must be located in an area where correct exhaust
venting can be achieved as noted in this manual (refer to
Exhaust Requirements).
IMPORTANT: Dryer should be located where a minimum
amount of exhaust duct will be necessary.
The dryer must be installed with a proper exhaust duct
connection to the outside.
The dryer must be installed with provisions for adequate
combustion and make-up air supply.
CAUTION: This dryer produces combustible lint and
must be exhausted to the outdoors. Every 6 months,
inspect the exhaust ducting and remove any lint
buildup.
IMPORTANT: Dryer must be installed in a location/
environment, which the ambient temperature remains
between 40º F (4.44º C) and 130º F (54.44º C).
Dryer Enclosure Requirements ______
Bulkheads and partitions should be made of
noncombustible materials and must be located a minimum
of 12-inches (30.48 cm) above the dryer’s outer top;
18-inches (45.72 cm) for steam dryers, except along the
front of the dryer, which may be closed if desired.
NOTE: Allowances must be made for opening the control
door.
With the exception of the floor, clearances shown are for
combustible construction.
X = 12-inch (30.48 cm) minimum, 24-inches (60.96 cm) is suggested for ease
of maintenance.
* 1-inch (2.54 cm) maximum for electric dryers.
** 18-inch (45.72 cm) minimum for steam dryers.

8113260-4
Exhaust Requirements _______________
Exhaust ductwork should be designed and installed by a
qualified professional. Improperly sized ductwork will create
excessive back pressure, which results in slow drying,
increased use of energy, and shutdown of the burner by the
airflow (sail) switch, burner hi-limits, or lint chamber hi-limit
protector thermostat. The dryer must be installed with a
proper exhaust duct connection to the outside.
When possible, it is suggested to provide a separate (single)
exhaust duct for each dryer.
The design of the flue system shall be such that any
condensate formed when operating the appliance from cold
shall either be retained and subsequently re-evaporated or
discharged.
CAUTION: This dryer produces combustible lint and
must be exhausted to the outdoors.
Improperly sized or installed exhaust ductwork can
create a potential fire hazard.
IMPORTANT: It is recommended that exhaust or booster
fans not be used in the exhaust ductwork system.
The exhaust ductwork should be laid out in such a way that
the ductwork travels as directly as possible to the outdoors
with as few turns as possible. The shape of the ductwork is
not critical as long as the minimum cross section area is
provided. Single or independent dryer venting is
recommended.
It is suggested that the use of 90° turns be avoided; use 30°
or 45° angles instead.
The ductwork should be smooth inside with no projections
from sheet metal screws or other obstructions, which will
collect lint. When adding ducts, the ducts to be added should
overlap the duct to which it is connected. All ductwork joints
must be taped to prevent moisture and lint from escaping
into the building. Additionally, inspection doors should be
installed at strategic points in the exhaust ductwork for
periodic inspection and cleaning.
IMPORTANT: When connecting ductwork to the dryer
exhaust duct, be sure that when screws are used they do
not restrict the operation (both opening and closing) of the
damper.
NOTE: When the exhaust ductwork passes through a wall,
ceiling, or roof made of combustible materials, the
opening must be 2-inches (5.08 cm) larger than the duct
(all the way around). The duct must be centered within
this opening.
To protect the outside end of the horizontal ductwork from
the weather, a 90° elbow bent downward should be installed
where the exhaust exits the building. If the ductwork travels
vertically up through the roof, it should be protected from the
weather by using a 180° turn to point the opening downward.
In either case, allow at least twice the diameter of the duct
between the duct opening and the nearest obstruction (i.e.,
roof or ground level).
NOTE: Air considerations are important for proper and
efficient operation.
Dryers may be positioned sidewall to sidewall. However, a
1/16” (1.59 mm) minimum allowance must be made for
opening and closing of the control door. It is suggested that
the dryer be positioned about 2 feet (0.61 meters) away
from the nearest obstruction for ease of installation,
maintenance, and service (to be measured from the back
guard). Refer to the illustration on previous page for details.
Fresh Air Supply Requirements ______
This appliance may only be installed in a room that meets
the appropriate ventilation requirements specified in the
national installation regulations.
The air supply (make-up air) must be given careful
consideration to ensure proper performance of each dryer.
An unrestricted source of air is necessary for each dryer. As
a general rule, an unrestricted air entrance from the outdoors
(atmosphere) of a minimum of 1-1/2 square feet (0.14
square meters) is required for each dryer. If registers or
louvers are installed over the openings, then the area must
be increased. It is not necessary to have separate
make-up air openings for each dryer. Common make-up
air openings are acceptable. However, they must be set up
in such a manner that the make-up air is distributed equally
to the dryers. The dryer must be installed with provisions
for adequate combustion and make-up air supply.
Example: For a bank of eight dryers, two unrestricted
openings measuring 3 feet by 2 feet (0.914 meters by 0.61
meters) are acceptable.
IMPORTANT: Make-up air openings should not be
located in an area directly near where exhaust vents exit
the building.
Allowances must be made for remote or constricting
passageways or where dryers are located at excessive
altitudes or predominantly low pressure areas.
IMPORTANT: Make-up air must be provided from a
source free of dry cleaning solvent fumes. Make-up air
that is contaminated by dry cleaning solvent fumes will
result in irreparable damage to the motors and other dryer
components.
NOTE: Component failure due to dry cleaning solvent
fumes will void the warranty.

113260-4 9
IMPORTANT: Do not use screens, louvers, or caps on the
outside opening of the exhaust ductwork.
Exhaust back pressure measured by a manometer at the
dryer exhaust duct area must be no less than 0 and must
not exceed 0.3 in WC (0.74 mb).
NOTE: As per the National Fuel Gas Code, “Exhaust ducts
for type 2 clothes dryers shall be constructed of sheet
metal or other noncombustible material. Such ducts shall
be equivalent in strength and corrosion resistance to
ducts made of galvanized sheet steel not less than 26
gauges (0.0195-inches [0.50 mm]) thick.”
Single Dryer Venting
Horizontal Venting
When a single 8-inch (20.32 cm) horizontal vent is used,
the ductwork to the outlet cannot exceed 68 feet (20.7
meters), refer to Illus. A below. This calculation of 68 feet
(20.7 meters) compensates or allows for the use of a
maximum of only one elbow, (which is the outside outlet
protection).
Illus. A
Vertical Venting
When vertical single 8-inch (20.32 cm) venting is used (refer
to Illus. B below), the ductwork from the dryer to the outside
outlet cannot exceed 55 feet (16.7 meters). This calculation
compensates for the use of a maximum of three elbows
including the two elbows creating the 180° (turned
downward) outside outlet.
Illus. B
If the length of the duct run or quantity of elbows used
exceeds the above noted specifications, the cross-sectional
area of the ductwork must be increased in proportion to the
number of elbows or duct run added.
IMPORTANT: For extended ductwork runs, the cross
section area of the duct can only be increased to an
extent. For extended ductwork runs, a professional HVAC
firm should be consulted for proper venting information.
Multiple Dryer (Common) Venting
If it is not feasible to provide separate exhaust ducts for
each dryer, ducts for individual dryers may be channeled
into a common main duct. Each dryer is provided with a
back draft damper. The individual ducts should enter the
bottom or side of the main duct at an angle not more than
45° in the direction of the airflow.
The main common duct may be any shape as long as the
minimum cross-sectional area is provided. The main duct
should be tapered with the diameter increasing before each
individual 8-inch (20.32 cm) duct is added (refer to Illus. C
for horizontal venting and Illus. D for vertical venting on the
following page).
IMPORTANT: No more than four dryers maximum should
be connected to one main common duct with a vertical
run.
NOTE: Distance between dryer single ducts being
connected to the main common duct must be a minimum
of 34-1/4” (87 cm) dryer width.
Ductwork should be laid out in such a manner where
allowances are made at rear area of the dryer for removal
of rear service panels or guards.

10 113260-4
The illustrations below show the minimum cross section
area for multiple dryer venting. These figures must be
increased in proportion if the main duct run from the last
dryer to where it exhausts has numerous elbows or is
unusually long.
IMPORTANT: For extended ductwork runs, the cross
section area of the duct can only be increased to an
extent. For extended ductwork runs, a professional HVAC
firm should be consulted for proper venting information.
Refer below for Multiple Dryer Horizontal Venting and Vertical
Venting examples/illustrations.
Horizontal Venting
Illus. C
IMPORTANT: It is recommended that exhaust or booster
fans not be used in the exhaust ductwork system.
Vertical Venting
Illus. D
Electrical Information ________________
Electrical Requirements
All electrical connections must be made by a properly
licensed and competent electrician. This is to ensure that
the electrical installation is adequate and conforms to local
and state regulations or codes. In the absence of such
codes, all electrical connections, materials, and
workmanship must conform to the applicable requirements
of the National Electrical Code ANSI/NFPA NO. 70-LATEST
EDITION or in Canada, the Canadian Electrical Codes Parts
1 & 2 CSAC22.1-1990 or LATEST EDITION.
IMPORTANT: Failure to comply with these codes or
ordinances, and/or the requirements stipulated in this
manual can result in personal injury or component failure.
NOTE: Component failure due to improper installation will
void the warranty.
Each dryer should be connected to an independently
protected branch circuit. The dryer must be connected with
copper wire only. Do not use aluminum wire, it could create
a fire hazard. The copper conductor wire/cable must be of
proper ampacity and insulation in accordance with electric
codes for making all service connections.
NOTE: The use of aluminum wire will void the warranty.
An individual ground circuit must be provided to each
dryer, do not daisy chain.
Component failure due to improper voltage application
will void the warranty.
The manufacturer reserves the right to make changes in
specifications at any time without notice or obligation.
IMPORTANT: A separate protected circuit must be
provided to each dryer.
The dryer must be connected to the electric supply shown
on the data label. In the case of 208 VAC or 240 VAC, the
supply voltage must match the electric service
specifications of the data label exactly.
The wire size must be properly sized to handle the related
current.
!WARNING
Dryer must never be operated without the lint filter/
screen in place, even if an external lint collection
system is used.
!WARNING
208 VAC and 240 VAC are not the same. Any damage
done to dryer components due to improper voltage
connections will automatically void the warranty.

113260-4 11
Electrical Service Specifications
Gas and Steam Models Only
Check your national and local code for breaker and wire size 7/18/14
Check your national and local code for breaker and wire size 7/18/14
ELECTRICAL SERVICE SPECIFICATIONS
IMPORTANT:
NOTES:A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
When fuses are used they must be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse
value, byapplying either local and/or National Electrical Codes to
listed appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) motor curve type
ONLY. For others, calculate/verify correct breaker size according to
appliance amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE PHASE WIRE
SERVICE APPROX. AMP DRAW CIRCUIT BREAKER
60 Hz 50 Hz
NON-REVERESING
120 1ø 2 8.7 —15
208 1ø 2 5.5 —15
220 1ø 2 4.5 3.9 15
230 1ø 2 3.2 3.5 15
240 1ø 2 4.8 4.6 15
208 3ø 3 3.1 —15
220 3ø 3 3.1 3.9 15
230 3ø 3 —3.5 15
240 3ø 3 3.3 4.2 15
380-400 3ø 4 or 3 —2.2 15
416 3ø 4 or 3 —2.3 15
460-480 3ø 3 2.1 —15
REVERSING
208 3ø 3 5 —15
220 3ø 3 5.2 6.8 15
230 3ø 3 —6.2 15
240 3ø 3 5.6 7.4 15
380 3ø 3 5.4 —15
460-480 3ø 3 3.2 —15
380-400 3ø 4 or 3 —3.4 15
416 3ø 4 or 3 —3.5 15
Electric Models Only
All electrically heated dryers must be connected to the
electric service shown on the dryer’s data label. The
connecting wires must be properly sized to handle the rated
current.
ELECTRICAL SERVICE SPECIFICATIONS
IMPORTANT:
NOTES: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. Whenordering,
specify exact voltage.
Whenfuses are used theymust be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse
value, by applying either local and/or National Electrical Codes to listed
appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) type ONLY. For
others, calculate/verify correct breaker size according to appliance
amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE PHASE WIRE SERVICE OVEN kW APPROX. AMP DRAW CIRCUIT BREAKER
60 Hz 50 Hz
NON-REVERSING
208 1ø 2 20 102 —150
220 1ø 2 17 82 81 125
230 1ø 2 18.5 84 84 125
240 1ø 2 20 88 88 125
208 1ø 2 24 121 —175
220 1ø 2 20 95 95 125
230 1ø 2 22 99 99 125
240 1ø 2 24 105 105 150
208 3ø 3 20 61 —80
220 3ø 3 17 49 49 70
230 3ø 3 18.5 50 50 70
240 3ø 3 20 53 53 70
208 3ø 3 24 72 —100
220 3ø 3 20 57 56 80
230 3ø 3 22 58 59 80
240 3ø 3 24 63 62 80
220 3ø 3 17 —49 70
380 3ø 4 17 —30 40
400 3ø 4 18.5 —30 40
416 3ø 4 20 —32 50
380 3ø 4 20 —34 50
400 3ø 4 22 —35 50
416 3ø 4 24 —38 50
208 3ø 3 20 59 —80
220 3ø 3 17 48 —60
240 3ø 3 20 51 52 70
380 3ø 3 17 29 —40
460 3ø 3 18.5 25 —40
480 3ø 3 20 26 —40
208 3ø 3 24 70 —90
220 3ø 3 20 56 —70
240 3ø 3 24 61 62 80
380 3ø 3 20 34 —50
460 3ø 3 22 30 —40
480 3ø 3 24 31 —40
208 3ø 3 30 86 —90
220 3ø 3 26 71 —70
240 3ø 3 30 75 76 80
380 3ø 3 26 43 —50
460 3ø 3 28 37 —40
480 3ø 3 30 38 —40
230 3ø 3 18.5 —50 70
380 3ø 4 or 3 17 —28 40
400 3ø 4 or 3 18.5 —29 40
416 3ø 4 or 3 20 —30 40
220 3ø 3 20 —56 80
230 3ø 3 22 —59 80
380 3ø 4 or 3 20 —33 50
400 3ø 4 or 3 22 —34 50
416 3ø 4 or 3 24 —36 50
440 3ø 4 or 3 20 —28 50
220 3ø 3 26 —72 80
230 3ø 3 28 —74 80
380 3ø 4 or 3 26 —42 50
400 3ø 4 or 3 28 —43 50
416 3ø 4 or 3 30 —44 50

12 113260-4
Check your national and local code for breaker and wire size 7/18/14
Grounding
A ground (earth) connection must be provided and installed
in accordance with state and local codes. In the absence of
these codes, grounding must conform to applicable
requirements of the National Electrical CodeANSI/NFPANO.
70-LATEST EDITION, or in Canada, the installation must
conform to applicable Canada Standards: Canadian
Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST
EDITION. The ground connection may be to a proven earth
ground at the location service panel.
For added personal safety, when possible, it is suggested
that a separate ground wire (size per local codes) be
connected from the ground connection of the dryer to a
grounded cold water pipe. Do not ground to a gas pipe or
hot water pipe. The grounded cold water pipe must have
metal-to-metalconnectionallthe way to theelectricalground.
If there are any nonmetallic interruptions, such as, a meter,
pump, plastic, rubber, or other insulating connectors, they
must be jumped out with a wire (size per local codes) and
securely clamped to bare metal at both ends.
IMPORTANT: For personal safety and proper operation,
the dryer must be grounded.
Provisions are made for ground connection in each dryer at
the electrical service connection area.
Electrical Connections
A wiring diagram is located inside the control box for
connection data.
If local codes permit, power to the dryer can be made by the
use of a flexible UL listed power cord/pigtail (wire size must
conform to rating of dryer), or the dryer can be hard wired
directly to the service breaker panel. In both cases, a strain
relief must be installed where the wiring enters the dryer.
Gas and Steam Models Only
IMPORTANT: A separate protected circuit must be
provided to each dryer.
Single-Phase (1ø)
Wiring Connections / Hookup
The electrical input connections on all single-phase (1ø)
gas dryers and steam dryers are made into the rear service
box located at the upper left area of the dryer.
Single-Phase Electrical Lead Connections
Black
+
Positive
White or Red
+
Neutral
or L2
Green
+
Ground
ELECTRICAL SERVICE SPECIFICATIONS
IMPORTANT:
NOTES: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
Whenfuses are used theymust be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse
value, by applying either local and/or National Electrical Codes to listed
appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) type ONLY. For
others, calculate/verify correct breaker size according to appliance
amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE PHASE WIRE SERVICE OVEN kW APPROX. AMP DRAW CIRCUIT
BREAKER
60 Hz 50 Hz
REVERSING
208 3ø 3 20 61 —80
220 3ø 3 17 50 51 70
240 3ø 3 20 54 56 70
380 3ø 3 17 31 —40
460 3ø 3 18.5 26 —40
480 3ø 3 20 27 —40
208 3ø 3 24 72 —90
220 3ø 3 20 58 59 80
240 3ø 3 24 63 —80
380 3ø 3 20 36 —50
460 3ø 3 22 31 —40
480 3ø 3 24 32 —50
575 3ø 3 24 27 —40
208 3ø 3 30 88 —90
220 3ø 3 26 73 75 80
240 3ø 3 30 78 —80
380 3ø 3 26 45 —50
460 3ø 3 28 38 —40
480 3ø 3 30 39 —50
575 3ø 3 30 33 —50
230 3ø 3 18.5 —53 70
380 3ø 4 or 3 17 —29 40
400 3ø 4 or 3 18.5 —30 40
416 3ø 4 or 3 20 —31 40
230 3ø 3 22 —61 80
240 3ø 3 24 —65 90
380 3ø 4 or 3 20 —34 50
400 3ø 4 or 3 22 —35 50
416 3ø 4 or 3 24 —37 50
440 3ø 4 or 3 20 —29 50
230 3ø 3 28 —76 80
240 3ø 3 30 —80 90
380 3ø 4 or 3 26 —43 50
400 3ø 4 or 3 28 —44 50
416 3ø 4 or 3 30 —45 50

113260-4 13
For 208-240V Applications
A ground lug is provided in the rear electrical box to connect
your service ground.
3-Phase (3ø) Wiring Connections / Hookup
The electrical connections on all 3-phase (3ø) gas and
steam dryers are made into the rear service box located at
the upper left area of the dryer. The electrical connections
are made at the power distribution block located in the
service box. The ground connection is made to the copper
lug, also provided in this box. To gain access, the service
box cover must be removed.
The neutral will only be used on 4-wire service. This is
typical for 380-416V, 50 Hz.
Electrically Heated Models Only
The only electrical input connections to the dryer are the
3-phase (3ø) power leads (L1, L2, L3, and sometimes
neutral) and ground. Single-phase (1ø) power for the control
circuit and for any single-phase (1ø) motors (if present) is
doneinternallyto thedryer bythefactory attheoven contactor.
No single-phase (1ø) input connection is required on a
3-phase (3ø) dryer.
CAUTION: The dryer must be grounded. A ground lug
has been provided for this purpose.
Input connection wiring must be sized properly to handle
the dryer’s current draw. This information is printed on the
dryer’s data label.
The electrical input connections are made at the electric
oven contactor located inside the assembly at the rear center
upper section of the dryer. The ground connection is made
to a copper lug also provided in this area. To gain access,
remove oven rear service cover.
IMPORTANT: A strain
relief must be used where
the input wiring enters the
oven assembly.
For 110V Applications

14 113260-4
Shaded areas are stated in metric equivalents
* Measured at outlet side of gas valve pressure tap when gas valve is on.
Gas Connections
Inlet connection ............... 1/2” N.P.T.
Inlet supply size .............. 1/2” Diameter Pipe (minimum)
Heat input (per dryer) ...... 100,000 Btu/hr (25,200 kcal/hr)
European Models............ 95,000 Btu/hr (23,940 kcal/hr)
Natural Gas
Regulation is controlled by the dryer’s gas valve’s internal
regulator. Incoming supply pressure must be consistent
between a minimum of 6.0 in WC (14.92 mb) and a maximum
of 12.0 in WC (29.9 mb) pressure.
L.P. Gas
Dryers made for use with L.P. gas have the gas valve’s
internal pressure regulator blocked open so that the gas
pressure must be regulated upstream of the dryer. The
pressure measured at each gas valve pressure tap must
be a consistent 10.5 in WC (26.1 mb). There is no regulator
or regulation provided in an L.P. dryer. The pressure must
be regulated at the source (L.P. tank) or an external regulator
must be added to each dryer.
TYPE OF GAS
Btu/hr
Rating kcal/hr
Rating Natural Liquid Propane
Qty. D.M.S.*Part No. Qty. D.M.S.*Part No.
100,000 25,200 2 #29 140820 2 #46 140806
Liquid Propane Conversion Kit Part Number 882269
95,000 **
23,940 2 #30 140819 2 #48 140804
Liquid Propane Conversion Kit Part Number 883195**
Gas Supply
The gas dryer installation must meet the American National
Standard...National Fuel Gas Code ANSI Z223.1-LATEST
EDITION, or in Canada, the Canadian Installation Codes
CAN/CGA-B149.1 M91 (Natural Gas) or CAN/CGA-B149.2-
M91 (L.P. Gas) or LATEST EDITION, as well as local codes
and ordinances and must be done by a qualified
professional.
NOTE: Undersized gas piping will result in ignition
problems, slow drying, increased use of energy, and can
create a safety hazard.
Thedryermust be connectedtothe type of heat/gasindicated
on the data label. If this information does not agree with the
type of gas available, do not operate the dryer. Contact the
reseller who sold the dryer or contact the factory.
IMPORTANT: Any burner changes or conversions must
be made by a qualified professional.
saGfoepyT
erusserPdlofinaM *erusserPeniL-nI
larutaN
ni5.3CWCWni0.21-0.6
bm7.8 bm9.92-29.41
diuqiL enaporP
CWni5.01CWni0.11
bm1.62 bm4.72
Gas Information ______________________
It is your responsibility to have all plumbing connections
made by a qualified professional to ensure that the gas
plumbing installation is adequate and conforms to local
and state regulations or codes. In the absence of such
codes, all plumbing connections, materials, and
workmanship must conform to the applicable requirements
of the National Fuel Gas Code ANSI Z223.1-LATEST
EDITION, or in Canada, the Canadian Installation Codes
CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-
M91 (L.P. Gas) or LATEST EDITION.
In Australia, the fuel gas code is AS 5601/AG 601, local
authority, gas, electricity, and any other relevant statutory
regulations.
IMPORTANT: Failure to comply with codes or ordinances,
and/or requirements in this manual, can result in personal
injury and improper operation of the dryer.
The dryer and its individual shutoff valves must be
disconnected from the gas supply piping system during
any pressure testing of that system at test pressures in
excess of 1/2 psig (3.5 kPa). The dryer must be isolated
from the gas supply piping system by closing its individual
manual shutoff valve during any pressure test of the gas
supply piping system at test pressures equal to or less
than 1/2 psig (3.5 kPa).
IMPORTANT: Failure to isolate or disconnect the dryer
from supply as noted can cause irreparable damage to
the gas valve, which will void the warranty.
!WARNING
Fireor explosion could result dueto failureof isolating
or disconnecting the gas supply as noted.
The input ratings shown on the dryer data label are for
elevations up to 2,000 feet (610 meters), unless elevation
requirements of over 2,000 feet (610 meters) were specified
at the time the dryer order was placed with the factory. The
adjustment or conversion of dryers in the field for elevations
over 2,000 feet (610 meters) is made by changing each
burner orifice. If this conversion is necessary, contact the
reseller who sold the dryer or contact the factory.
IMPORTANT: This gas dryer is not provided with an
internal gas supply shutoff and an external gas supply
shutoff must be provided.
Technical Gas Data
Gas Specifications
Shaded areas are stated in metric equivalents
* D.M.S. equivalents are as follows:
Natural Gas ............... #29 = 0.1360” (3.4540 mm).
L.P. Gas ..................... #46 = 0.0810” (2.0574 mm).
Natural Gas** ............ #30 = 0.1285” (3.2639 mm).
L.P. Gas**.................. #48 = 0.0760” (1.9304 mm).
**European Models Only

113260-4 15
Piping Connections
All components/materials must conform to National Fuel
Gas Code SpecificationsANSI Z223.1-LATEST EDITION, or
in Canada, CAN/CGA-B149.1-M91 (Natural Gas) or CAN/
CGA-B149.2-M91(L.P.Gas)orLATESTEDITION(forGeneral
Installation and Gas Plumbing), as well as local codes and
ordinances and must be done by a qualified professional.
It is important that gas pressure regulators meet applicable
pressure requirements, and that gas meters be rated for
the total amount of all the appliance Btu being supplied.
The dryer is provided with a 1/2” N.P.T. inlet pipe connection
extending out the back area of the burner box. The minimum
pipe size (supply line) to the dryer is 1/2” diameter. For
ease in servicing, the gas supply line of each dryer must
have its own shutoff valve.
The size of the main gas supply line (header) will vary
depending on the distance this line travels from the gas
meter or, in the case of L.P. gas, the supply tank, other
gas-operated appliances on the same line, etc. Specific
information regarding supply line size should be determined
by the gas supplier.
NOTE: Undersized gas supply piping can create a low or
inconsistent pressure, which will result in erratic operation
of the burner ignition system.

16 113260-4
Steam Information ___________________
It is your responsibility to have all plumbing connections
made by a qualified professional to ensure that the steam
plumbing installation is adequate and conforms with local
and state regulations or codes.
Care must be exercised when leveling steam dryers into
final position. After leveling the dryer, check the downward
pitch of the heat exchanger from front to rear with a level.
Likewise, check the downward pitch of the return condensate
manifold toward its outlet part. Absence of these downward
pitches will result in probable water hammer and premature
heat exchanger fracture and leakage.
The presence of condensate in the steam will cause water
hammer and subsequent heat exchanger failure. The steam
supply connection must be taken from the top of a
well-dripped steam main. If the supply run-out to the dryer
exceeds 20 feet (6.1 meters), it should be dripped just before
the control valve with a proper trap and dirt pocket.
IMPORTANT: Failure to comply with the requirements
stipulated in this manual can result in component failure,
which will void the warranty.
NOTE: This dryer is manufactured with a pneumatic
(piston) damper system, which requires an external
supply of air (80 psi +/- 10 psi [5.51 bar +/- 0.68 bar]).
Steam Coil pH Level
The normal pH level for copper type steam coils must be
maintained between a value of 8.5 to 9.5. For steel type
steam coils the pH level must be maintained between a
value of 9.5 to 10.5. These limits are set to limit the acid
attack of the steam coils.
IMPORTANT: Coil failure due to improper pH level will
void the warranty.
Steam Requirements
erusserPmaetSgnitarepO
mumixaMgisp521 *aPk48.168
)daoLlamroN(tupnItaeHphB0.3
)etamixorppA(noitpmusnoCrh/bl401 rh/gk2.74
The pressure of the condensate in the steam supply line
will cause water hammer and subsequent heat exchanger
(steam coil) failure. The steam supply connection into the
main supply line must be made with a minimum 10-inch
(25.4 cm) riser. This will prevent any condensate from
draining towards the dryer.
The steam supply line to the dryer must include a 12-inch
(30.48 cm) riser along with a drip trap and check valve. This
will prevent any condensate from entering the steam coil.
Flexible hoses or couplings must be used. The dryer
vibrates slightly when it runs and this will cause the steam
coil connections to crack if they are hard piped to the supply
and return mains.
Shutoff valves for each dryer should be installed in the
supply line, return line, and drip trap return line. This will
allow the dryer to be isolated from the supply main and the
return main if the dryer needs maintenance work.
Install an inverted bucket steam trap and check valve at
least 12-inches (30.48 cm) below the steam coil as close
to the coil as possible. A trap with a capacity of 350 lb (160
kg) of condensate per hour at 125 psi (8.61 bar) is needed
for each unit.
The supply line and the return line should be insulated.
Thiswillsave energy andprovidefor the safetyofthe operator
and maintenance personnel.
Water pockets in the supply line, caused by low points, will
provide wet steam to the coil possibly causing steam coil
damage. All horizontal runs of steam supply piping should
be pitched 1/4-inch (6.35 mm) for every 1 foot (0.30 meters)
back towards the steam supply header causing the
condensate in the line to drain to the header. Install a bypass
trap in any low point to eliminate wet steam.
IMPORTANT: Flexible hoses/couplings must be used.
Coil failure due to hard plumbing connections will void the
warranty.
Steam Damper Air System Connections
This dryer is manufactured with a pneumatic (piston) damper
system, which requires an external supply of compressed
air. The air connection is made to the steam damper
solenoid valve, which is located at the rear inner top area of
the dryer just in front of the electric service relay box.
Shaded areas are stated in metric equivalents
* The minimum operating pressure for optimum results is 100 psig (689.47
kPa).
Installation Instructions
To ensure an adequate supply of steam is provided, be
sure that the steam supply lines and steam return lines are
sized and laid out as stipulated in this manual. Inadequate
steam supply lines and steam return lines or improper
steam plumbing will result in poor performance and can
cause component failure. Clean, dry steam must be
provided to the dryer.
IMPORTANT: Steam coil failure due to water hammer by
wet steam will void the warranty.

113260-4 17
Air Requirements
There is no air requirement for dryers with the
electromechanical steam damper option.
Shaded areas are stated in metric equivalents
Air Connection
Air connection to system — 1/8” N.P.T.
Air Regulation
Noairregulator or filtrationisprovided withthedryer. External
regulation/filtration of 80 psi (5.51 bar) must be provided. It
is suggested that a regulator/filter gauge arrangement be
added to the compressed air line just before the dryer
connection. This is necessary to ensure that correct and
clean air pressure is achieved.
Steam Damper System Operation
The steam damper, as shown in the following illustration,
allows the coil to stay constantly charged eliminating
repeated expansion and contraction. When the damper is
opened, the air immediately passes through the already
hot coil, providing instant heat to start the drying process.
When the damper is closed, ambient air is drawn directly
into the tumbler, allowing a rapid cool down.
Compressed Air Supply Air Pressure
Normal 80 psi 5.51 bar
Minimum Supply 70 psi 4.82 bar
Maximum Supply 90 psi 6.21 bar
Diagram 1 shows the damper in the heating (open) mode,
allowing heat into the tumbler.
Diagram 2 shows the damper in the cool down (closed)
mode, pulling ambient air directly into the tumbler without
passing through the coils.
NOTE: With the dryer off or with no air supply, the steam
damper is in cool down mode as shown in Diagram 2.

18 113260-4
Steam Damper Air Piston (Flow Control)
Operation Adjustment
Damper operation was tested and adjusted prior to shipping
at 80 psi (5.51 bar). If damper air adjustment is necessary,
locate the flow control valve and make the necessary
adjustments as noted below.
Preparation for Operation / Start-Up__
The following items should be checked before attempting
to operate the dryer:
• Read all “Caution”, “Warning”, and “Direction” labels
attached to the dryer.
• Check incoming supply voltage to be sure that it is the
same as indicated on the dryer data label.
• Gas Models – check to ensure that the dryer is
connected to the type of heat/gas indicated on the dryer
data label.
• Gas and Electric Models – the sail switch damper
assembly was installed and adjusted at the factory prior
to shipping. However, each sail switch adjustment
must be checked to ensure that this important safety
control is functioning.
• Check bolts, nuts, screws, terminals, and fittings for
tightness and security.
• Gas Models – be sure that all gas shutoff valves are in
the open position.
• Check that all back guard panels and service box
covers have been replaced.
• Check the lint drawer to ensure that it is closed and
secured in place.
• Rotate the tumbler (drum) by hand to be sure it moves
freely.
• Steam Models – check to ensure that a clean, dry,
regulated air supply (80 psi [5.51 bar]) is on the dryer
(with air-operated damper system only).
• Steam Models – check to ensure all steam shutoff
valves are open.
• Steam Models – check steam damper operation.
• Check tumbler bearing setscrews to ensure that they
are all tight.
• Check vent is connected to the dryer and is exhausted
to the outdoors.
Preoperational Test___________________
All dryers are thoroughly tested and inspected before leaving
the factory. However, a preoperational test should be
performed before the dryer is publicly used. It is possible
that adjustments have changed in transit or due to marginal
location (installation) conditions. Installer must instruct the
user on how to correctly operate the dryer before leaving.
Turn on electric power to the dryer.
Refer to the Operating Instructions for starting your particular
model dryer.
Gas Models Only
When a gas dryer is first started (during initial start-up), it
has a tendency not to ignite on the first ignition attempt.
This is because the gas supply piping is filled with air, so it
may take a few minutes for the air to be purged from the
lines.
NOTE: During the purging period, check to be sure that
all gas shutoff valves are open.
Gas model dryers are equipped with an ignition system,
which has internal diagnostics. If ignition is not established
after one time, the heat circuit in the ignition module will
attempt two more ignitions (total of three ignition attempts).
If there is no flame after the third ignition attempt the module
will lock out until it is manually reset. To reset the ignition
system, open and close the main door and restart the dryer.
A gas pressure test should be taken at the gas valve
pressure tap of each dryer to ensure that the water column
pressure is correct and consistent.
NOTE: Water column pressure requirements (measured
at the pressure tap of the gas valve body):
Natural Gas.......................... 3.5 in WC (8.7 mb)
L.P. Gas ............................ 10.5 in WC (26.1 mb)
IMPORTANT: There is no regulator provided in an L.P.
dryer. The water column pressure must be regulated at
the source (L.P. tank), or an external regulator must be
added to each dryer.
Make a complete operational check of all safety related
circuits:
• Door Switch(es)
• Hi-Limit Thermostats
• Cycling Thermostat
• Gas and Electric Models Only – Sail Switch
NOTE: The sail switch can be checked for proper operation
by opening the lint drawer. While pushing the lint drawer
switch in, start a drying cycle. The heating unit should not
activate (wait 30-seconds). If heat does activate, make the
necessary adjustments to the sail switch.
Make a complete operational check of all operating controls.

113260-4 19
NOTE: If computer program changes are required, refer to
the computer programming section of the manual supplied
with the dryer.
The dryer should be operated through one complete cycle to
ensure that no further adjustments are necessary and that
all components are functioning properly.
Tumbler Coating
The tumbler is treated with a protective coating. We suggest
dampening old garments or cloth material with a solution of
water and nonflammable mild detergent and tumbling them
in the tumbler to remove this coating.
Check the electric service phase sequence (3-phase [3ø]
models only). While the dryer is operating, check to see if the
blower wheel (impellor/fan) is rotating in the proper direction.
Looking from the front, the blower wheel (impellor/fan) should
spin in the clockwise direction. If it is, the phasing is correct.
If the phasing is incorrect, reverse two of the three leads at
connections L1, L2, and L3 of the power supply to the dryer.
IMPORTANT: If the blower wheel (impellor/fan) is rotating
in the wrong direction, it will drastically reduce drying
efficiency and it can also cause premature component
failure.
Preoperational Instructions _________
Coin Models
Microprocessor Controller (Computer)
• When the microprocessor controller (computer) is in the
ready state, the L.C.D. screen will display “READY,
INSERT$XX.XX(AMOUNT)TOSTART”.
• Insert coin(s). Once the correct “Amount to Start” has
been inserted, the L.C.D. will display “SELECT
TEMPERATURE”.
• Select temperature by pressing “HI”, “MED”, or “LO”. The
cycle will start and the L.C.D. will display the Dry Cycle
selected and the remaining time.
• The dryer will continue through the drying and cooling
cycles, until the vended time has expired.
• Upon completion of the drying and cooling cycles, the
tone (buzzer) will sound and the dryer will go into the
Anti-Wrinkle Mode for 99 minutes, or until the main door
has been opened.
NOTE: To stop dryer, open main door or pressing the
“PAUSE” key. Continuation of the cycle will resume only
after the door has been closed and any of the three
temperature selection is pressed.
IMPORTANT: For more detailed information regarding the
microprocessor controller (computer) on your dryer, refer to
the microprocessor user’s manual included with the dryer.
Mechanical Drop /
Rotary Coin Meter or Slide Coin Meter
• Insert coin and turn knob (rotary type meter), or for slide
meter unit, push in coin chute.
• Select Temperature.
• Push the “Start” button.
• To stop dryer, open the main door.
Non-Coin Models
• The L.E.D. display reads “Ready” (no cycle in progress).
• Press the letter on the keypad corresponding to the cycle
desired (i.e., key “D”).
• The dryer will then start. (I.E., blower, tumbler, and heat.)
• The L.E.D. display will read “MANUAL DRYING CYCLE
D,00:00MIN REMAIN”.
• When the programmed drying time has expired, the
Phase 7 non-coin microprocessor controller (computer)
will proceed into the Cool Down Cycle.
• Once the Cool Down Cycle begins at the end of the heat
cycle, the L.E.D. display will read “COOL DOWN TEMP
___/___ MINUTES REMAINING”. At the end of the heat
cycle, the dryer will shut off the heat and continue the fan
and tumbler until the Cool Down Time or temperature is
reached.
NOTE: “0-40” will require the “START/ENTER” key to be
pressed after the number is selected in order to accept the
selection and start drying.
Press and hold the “UP ARROW” to view the tumbler
temperature at any time.
The dryer can be stopped at any time by pressing the
“STOP/CLEAR” key, at this time the dryer will go into a
cycle pause. If the “STOP/CLEAR” key is pressed again at
this point, the cycle that was in progress will be cancelled
and returned to the “READY” state.
Press and hold the “DOWN ARROW” to view the tumbler
RPM.
IMPORTANT: For more detailed information regarding the
microprocessor controller (computer) on your dryer, refer to
the microprocessor user’s manual included with the dryer.
Dual Timer Dryers
• Turn drying timer knob for a time of 20 minutes.
• Select “High Temp”.
• Push “Push to Start” button.
• To stop dryer, open the main door.
Spin and dwell (stop) times are adjustable at the reversing
timer.

20 113260-4
NOTE: Suggested time intervals shown are for average
usage, which is considered 6 to 8 operational (running)
hours per day.
IMPORTANT: Dryer produces combustible lint and must
be exhausted to the outdoors. Every 6 months, inspect
the exhaust ducting and remove any lint buildup.
Suggested Cleaning Schedule
Every Third or Fourth Load
Clean the lint screen every third or fourth load. Aclogged lint
screen will cause poor dryer performance. The lint door/
drawer is located just below the loading door of the dryer.
Open the lint door/drawer, brush the lint off the lint screen,
and remove the lint. Inspect lint screen and replace if torn.
NOTE: The frequency of cleaning the lint screen can best
be determined from experience at each location.
Service / Parts Information __________
Service
Service must be performed by a qualified trained technician.
If service is required, contact the reseller from whom the
equipment was purchased. If the reseller cannot be
contacted or is unknown, contact the Service Department
for a reseller in your area.
NOTE: When contacting the Service Department, be sure
to give them the correct model number and serial number
so that your inquiry is handled in an expeditious manner.
Parts
Replacement parts should be purchased from the reseller
from whom the equipment was purchased. If the reseller
cannot be contacted or is unknown, contact the Parts
Department for a reseller in your area.
NOTE: When ordering replacement parts from the reseller
or the manufacturer, be sure to give them the correct
model number and serial number so that your parts order
can be processed in an expeditious manner.
Routine Maintenance _________________
Cleaning
A program and/or schedule should be established for
periodic inspection, cleaning, and removal of lint from various
areas of the dryer, as well as throughout the ductwork
system. The frequency of cleaning can best be determined
from experience at each location. Maximum operating
efficiency is dependent upon proper airflow. The
accumulation of lint can restrict this airflow. If the guidelines
in this section are met, the dryer will provide many years of
efficient, trouble free, and most importantly, safe operation.
!WARNING
Lint from most fabrics is highly combustible. The
accumulation of lint can create a potential fire hazard.
Keep dryer area clear and free from combustible
materials, gasoline, and other flammable vapors and
liquids.
Reversing Timer Spin / Dwell Adjustments
Timer models have an electronic reversing timer in the
electrical service box, which is located in the upper left rear
area of the dryer.
Both the Dwell (stop) Time and the tumbler Spin Time are
adjustable by mode selection switches located on the
electronic timer (as noted in the illustration below).
Shutdown Instructions _______________
If the dryer is to be shutdown (taken out of service) for a
period of time, the following must be performed:
Discontinue power to the dryer either at the external
disconnect switch or the circuit breaker.
Discontinue the Heat Supply
Gas Models – discontinue the gas supply:
• Shut off external gas supply shutoff valve.
• Shut off internal gas supply shutoff valve located in the
gas valve burner area.
Steam Models – discontinue the steam supply.
• Shut off external (location furnished) shutoff valve.
• Shut off internal steam valves in the supply lines and
the return lines.
DNEGELGNIMIT
EMITNIPS
rebmuNnoitisoPtnemtsujdA12345
sdnoceSniemiT *030609021051
EMIT)POTS(LLEWD
rebmuNnoitisoPtnemtsujdA12345
sdnoceSniemiT *53.66.79.82.01
.dnoces-1-/+eranwohsseulaV*
