FIRESTAR VER. 1.0 – 3-May-2011
To view the current fan speed settings:
1. Press and hold the Fan Set button. The light bars will
display the current fan speed settings.
To change the fan speed settings:
1. Press and hold the Fan Set button; then press the or
button for the respective mode to decrease or increase the
fan speed setting. Decreasing the setting (fewer lights on the
light bar) lowers the fan speed. Increasing the setting (more
lights on the light bar) increases the fan speed.
Auto Relight
When the auto relight function is enabled, the controller
continuously monitors the burner temperature. If at any time the
burner temperature is less than the burner temperature setting
(which is set at the factory) and the controller is in NORMAL or HI
mode, the controller will automatically change to Ignition mode in
an attempt to relight and raise the burner temperature.
NOTE: A drop in burner temperature may be caused by wet
or contaminated fuel or by an extended IDLE mode time, for
example.
If after three Ignition mode cycles, the burner temperature does
not rise above the burner temperature setting, all outputs will be
disabled, the Auto Relight Enabled light will ash, and the LED
display will indicate to notify that the burner re has gone out.
NOTE: Before resetting the controller after the auto relight
function has failed, be sure to nd the cause of the burner not
being operational (e.g., wet or contaminated fuel, mechanical
problem, etc.).
WARNING
Do not attempt any service on the burner without rst
disconnecting the main power supply to the furnace. Make
sure there is no hot ash in the burn chamber or furnace.
The controller will maintain the system in a disabled condition and
the Auto Relight Enabled light will continue to ash until one of the
following occurs:
1. Press and hold the Ignition button for 15 seconds.
2. Press the Power button to turn off the controller; then press
again to turn on the controller.
