MaxJax M6K User manual

1
MaxJax™
5240 Willis Road
Theodore, AL 36582
844-629-5291
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO INSTALLATION AND OPERATION.BY PROCEEDING WITH LIFT
INSTALLATION AND OPERATION YOU AGREE THAT YOU FULLY UNDERSTAND AND COMPREHEND THE FULL CONTENTS OF THIS
MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE
INJURY OR DEATH.
Rev B - February 2021
P/N# 5900228
M6K USER MANUAL
Reference ANSI/ALI ALIOM safety
requirements for installation and service of
automotive lifts before installing lift.
MODEL: M6K
PORTABLE MID-RISE LIFT
6,000 POUND CAPACITY
Patent No. US 8.256.577 B2
Patent No. US 9.150.395.B2

2
IMPORTANT NOTICE
1. Read this manual thoroughly before installing, operating, or maintaining this Lift.
2. This Lift is designed for indoor use only, and should not be installed in a pit or depression.
3. The oor on which the Lift is to be installed must be 4"(101mm) minimum thickness concrete, with a minimum
compressive strength of 3,000 psi (20 MPa) and reinforced with steel bar.
4. The Lifts have specic electrical requirements as described in the Installation Instructions section of this manual.
5. This Lift has a minimum ceiling height requirement as described in the Installation Instructions section of this manual.
6. Failure by the owner to provide the recommended shelter, mounting surface, electrical supply, and ceiling height could result
in unsatisfactory lift performance, property damage, or personal injury.
7. Do not attempt to install this Lift if you have never been trained on basic automotive lift installation procedures. Reference
ANSI/ALI ALIOM requirements for installation and service of Automotive Lifts.
8. Never attempt to lift components without proper lifting tools such as Forklift or Shop Cranes. Stay clear of any moving parts
that can fall and cause injury. These instructions must be followed to insure proper installation and operation of your Lift.
9. Dannmar Equipment will assume no liability for loss or damage of any kind, expressed or implied resulting from improper
installation or use of this product.
10. This lift is rated to 6,000-lbs lifting capacity. NEVER EXCEED rated lifting capacity of Lift.
11. Qualied person must be consulted for seismic loads and other local or state requirements.
DEFINITIONS OF HAZARD LEVELS
Identify the hazard levels used in this manual with the following denitions and signal words.
Hazards or unsafe practices which could result in severe personal injury or death.
Hazards or unsafe practices which may result in minor personal injury, product or property damage.
Hazards or unsafe practices which may result in minor personal injury, product or property damage.
Lubricate all plastic guide blocks, bearings, and shafts with grease prior to operating the lift. Lubricate all on a weekly basis.
Motors and all electrical components are not sealed against the weather and moisture. Install this lift in a protected indoor loca-
tion. Failure by the owner to provide the recommended shelter could result in unsatisfactory lift performance, property damage,
personal injury, and may void the warranty.
BE SAFE: YOUR NEW LIFT WAS DESIGNED AND BUILT WITH SAFETY IN MIND. HOWEVER, YOUR OVER-
ALL SAFETY CAN BE INCREASED WITH PROPER TRAINING AND THOUGHTFUL OPERATION ON THE PART
OF THE OPERATOR. DO NOT OPERATE OR REPAIR THIS EQUIPMENT WITHOUT READING THIS MANUAL
AND THE IMPORTANT SAFETY INSTRUCTIONS SHOWN INSIDE. KEEP THIS OPERATION MANUAL NEAR
THE LIFT AT ALL TIMES. MAKE SURE THAT ALL USERS READ AND UNDERSTAND THIS MANUAL.

3
IMPORTANT SAFETY INSTRUCTIONS
READ THESE SAFETY INSTRUCTIONS ENTIRELY
Do not attempt to install this lift if you have never been trained on basic automotive lift installation procedures. Never
attempt to lift components without proper lifting tools such as a forklift or crane. Stay clear of any moving parts that can fall
and cause injury.
1. READ ALL INSTRUCTIONS.
2. READ AND UNDERSTAND all safety warning procedures before operating lift.
3. KEEP AREA WELL LIGHTED.
4. WARNING! RISK OF EXPLOSION. This equipment has internal arcing or sparking parts which should not be exposed
to ammable vapors. This machine should not be located in a recessed area or below oor level.
5. KEEP CONTROL HANDLES AND / OR BUTTONS dry, clean and free from grease and oil.
6. CARE MUST BE TAKEN as burns can occur from touching hot parts on the hydraulic unit’s electric motor.
7. DO NOT operate equipment with a damaged power cord or if the equipment has been dropped or damaged until it has
been examined by a qualied service person.
8. DO NOT let the power cord come in contact with hot manifolds or moving fan blades.
9. IF AN EXTENSION CORD IS NECESSARY, a cord with a current rating equal to or more than that of the equipment
should be used. Cords rated for less current than the equipment may overheat. Care should be taken to arrange the
cord so that it will not be tripped over or pulled.
10. ALWAYS UNPLUG EQUIPMENT FROM ELECTRICAL OUTLET WHEN NOT IN USE. Never use the power cord to
pull the power plug from the outlet. Grasp the plug and pull to disconnect.
11. LET EQUIPMENT COOL COMPLETELY BEFORE PUTTING AWAY. Loop power cord loosely around equipment
when storing.
12. TO REDUCE THE RISK OF FIRE, do not operate equipment in the vicinity of open containers of ammable liquids
(i.e., gasoline).
13. ADEQUATE VENTILATION SHOULD BE PROVIDED when working on operating internal combustion engines.
14. KEEP HAIR, LOOSE CLOTHING, FINGERS, AND ALL PARTS OF THE BODY AWAY FROM MOVING PARTS.
15. TO REDUCE THE RISK OF ELECTRIC SHOCK, do not use on wet surfaces or expose to rain.
16. USE ONLY AS DESCRIBED IN THIS MANUAL. Use only manufacturer’s recommended attachments.
17. DO NOT raise vehicle on the lift until installation is completed as instructed in this manual.
18. KEEP HANDS AND FEET CLEAR. Remove hands and feet from any moving parts. Keep feet clear of lift when
lowering. Avoid pinch points.
19. KEEP WORK AREA CLEAN. Cluttered work areas invite injuries.
20. CONSIDER WORK AREA ENVIRONMENT. Do not expose equipment to rain. DO NOT use in damp or wet locations.
Keep area well lighted.

4
21. ONLY TRAINED OPERATORS should operate this lift. All non trained personnel should be kept away from work
area. Never let untrained personnel come in contact with, or operate lift.
22. USE LIFT CORRECTLY. Use lift in the proper manner. Never use lifting adapters other than what is approved by the
manufacturer.
23. DO NOT override self closing lift controls.
24. REMAIN CLEAR of lift when raising or lowering vehicle.
25. CLEAR AREA if vehicle is in danger of falling.
26. ALWAYS ENSURE that the safety locks are engaged before any attempt is made to work on or near vehicle.
27. DRESS PROPERLY. Non skid steel toe footwear is recommended when operating lift.
28. GUARD AGAINST ELECTRIC SHOCK. This lift must be grounded while in use to protect the operator from electric
shock. Never connect the green power cord wire to a live terminal. This is for ground only.
29. DANGER! The power unit used on this lift contains high voltage. Disconnect power at the receptacle before
performing any electrical repairs. Secure plug so that it cannot be accidentally plugged in during service.
30. ALWAYS WEAR SAFETY GLASSES. Everyday eyeglasses only have impact resistant lenses. They are not safety
glasses.
31. MAINTAIN WITH CARE. Keep lift clean for better and safe performance. Follow manual for proper lubrication and
maintenance instructions. Keep control handles and / or buttons dry, clean and free from grease and oil.
32. STAY ALERT. Watch what you are doing. Use common sense. Be aware!
33. CHECK FOR DAMAGED PARTS. Check for alignment of moving parts, breakage of parts or any condition that may
a󰀨ect its operation. Do not use lift if any component is broken or damaged.
34. NEVER remove safety related components from the lift. Do not use lift if safety related components are damaged or
missing.
NOTE: If attachments, accessories, or conguration modifying components that are located in the load path, a󰀨ect
operation of the lift, a󰀨ect the lift electrical listing or a󰀨ect intended vehicle accommodation are used on this lift
and, if they are not certied for use on this lift, then the certication of this lift shall become null and void. Contact
Dannmar Equipment for information pertaining to certied attachments, accessories, or conguration modifying
components.
SHIPPING DAMAGE CLAIMS:WHEN THIS EQUIPMENT IS SHIPPED,TITLE PASSES TOTHE PURCHASER UPON RECEIPT FROM THE CARRIER.
CONSEQUENTLY, CLAIMS FOR THE MATERIAL DAMAGED IN SHIPMENT MUSTBE MADE BY THE PURCHASERAGAINST THETRANSPORTATION
COMPANY AT THE TIME SHIPMENT IS RECEIVED.
When removing the lift from the shipping angles pay close attention as the posts can slide and can cause injury. Prior to
removing the bolts make sure the posts are held securely by a Forklift, Shop Crane, or some other heavy lifting device.

5
SAVE THESE INSTRUCTIONS
OWNER / EMPLOYER RESPONSIBILITIES
• Shall ensure that lift operators are qualied and that they are trained in the safe use and operation of the lift using the
manufacturer’s operating instructions and regional requirements.
• Shall establish procedures to periodically inspect the lift in accordance with the lift manufacturer’s instructions and
regional requirements. The Employer Shall ensure that lift inspectors are qualied and that they are adequately
trained in the inspection of the lift.
• Shall establish procedures to periodically maintain the lift in accordance with the lift manufacturer’s instructions and
regional requirements, Inspection and Maintenance and The Employer Shall ensure that lift maintenance personnel
are qualied and that they are adequately trained in the maintenance of the lift.
• Shall maintain the periodic inspection and maintenance records recommended by the manufacturer and regional
requirements.
• Shall display the lift manufacturer’s operating instructions; ALI/SM 93-1, ALI Lifting it Right safety manual; ALI/ST-10
ALI Safety Tips card; in a conspicuous location in the lift area convenient to the operator.
• Shall not modify the lift in any manner without the prior written consent of the manufacturer or regional requirements.
• Shall provide necessary lockout/ tagout means for energy sources per ANSI Z244.1-1982 (R1993), safety require-
ments for the lockout / tagout of energy sources, before beginning any lift repairs.
INSTALLER /OPERATOR:PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO INSTALLATION
AND OPERATION. BY PROCEEDING WITH LIFT INSTALLATION AND OPERATION YOU AGREE THAT YOU FULLY
UNDERSTAND AND COMPREHEND THE FULL CONTENTS OF THIS MANUAL. FORWARD THIS MANUAL TO ALL
OPERATORS. FAILURE TO OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE INJURY OR DEATH.
• I have visually inspected the site where the lift is to be installed and veried the concrete to be in good condition and
free of cracks or other defects. I understand that installing a lift on cracked or defective concrete could cause lift failure
resulting in personal injury or death.
• I understand that a level oor is required for proper installation and level lifting.
• I understand that I am responsible if my oor is of questionable slope and that I will be responsible for all charges
related to pouring a new level concrete slab if required and any charges.
• I understand that MaxJax Lifts are supplied with concrete fasteners meeting the criteria of the latest version of the
American National Standard “Automotive Lifts Safety Requirements for Construction, Testing, and Validation” ANSI/
ALI ALCTV and that I will be responsible for all charges related to any special regional structural and/or seismic an-
choring requirements specied by any other agencies and / or codes such as the Uniform Building Code (UBC) and /
or International Building Code (IBC).
• I will assume full responsibility for the concrete oor and condition thereof, now or later, where the above equipment
model(s) are to be installed. Failure to follow danger, warning, and caution instructions may lead to serious personal
injury or death to operator or bystander or damage to property.
•
• I understand that MaxJax is designed to be installed in indoor locations only. Failure to follow instructions may lead to
serious personal injury or death to operator or bystander or damage to property or Lift.

6
Failure to follow danger, warning, and caution instructions may lead to serious personal injury or death to operator or
bystander or damage to property.
Please read entire manual prior to installation. Do not operate this machine until you read and understand all the dangers,
warnings and cautions in this manual. For additional copies or further information, contact:
MaxJax™
5240 Willis Road
Theodore, AL 36582
844-629-5291
INSTALLER / OPERATOR
PROTECTIVE EQUIPMENT
Personal protective equipment helps makes installation and operation safer, however, it does not take the place of safe
operating practices. Always wear durable work clothing during any installation and/or service activity. Shop aprons or shop
coats may also be worn, however loose fitting clothing should be avoided. Tight fitting leather gloves are recommended
to protect technician hands when handling parts. Sturdy leather work shoes with steel toes and oil resistant soles should
be used by all service personnel to help prevent injury during typical installation and operation activities.
Eye protection is essential during installation and operation activities. Safety glasses with side shields, goggles, or face
shields are acceptable. Back belts provide support during lifting activities and are also helpful in providing worker protec-
tion. Consideration should also be given to the use of hearing protection if service activity is performed in an enclosed
area or if noise levels are high.

7
INSTALLATION INSTRUCTIONS
TOOLS REQUIRED
IMPORTANT NOTICE
These instructions must be followed to ensure proper installation and operation of your lift. Failure to comply with these
instructions can result in serious bodily harm and void product warranty. Manufacturer will assume no liability for loss or
damage of any kind, expressed or implied resulting from improper installation or use of this product.
STEP 1
SELECTING SITE
BEFORE INSTALLING YOUR NEW LIFT, CHECK THE FOLLOWING:
1. LIFT LOCATION: Always use architects plans when available. Check layout dimension against oor plan
requirements making sure that adequate space is available.
2. OVERHEAD OBSTRUCTIONS: The area where the lift will be located should be free of overhead obstructions such
as heaters, building supports, electrical lines etc.
3. DEFECTIVE FLOOR: Visually inspect the site where the lift is to be installed and check for cracked or defective
concrete. Do not drill or cut into post tension slab oors. Consult your building architect for more information.
4. OPERATING TEMPERATURE. Operate lift only between temperatures of 41° - 104° F (5º - 40 º C).
5. Lift is designed for INDOOR INSTALLATION ONLY.
STEP 2
FLOOR REQUIREMENTS
This lift must be installed on a solid level concrete oor minimum 4"(101mm) thick, compressive strength 3,000 psi
(20 MPa) with no more than 3° of slope. FAILURE TO DO SO COULD CAUSE PERSONAL INJURY OR DEATH.
DO NOT install this lift on any asphalt surface or any surface other than concrete.
DO NOT install this lift on expansion seams or on cracked or defective concrete.
DO NOT install this lift on a second / elevated oor without rst consulting building architect.
DO NOT install this lift outdoors.
• Rotary Hammer Drill or Similar
• 7/8"(22mm) Masonry Bit
• Hammer
• 4 Foot Level (1.5 M)
• Open End Wrench Set: Metric
• Socket and Ratchet Set: Metric
• Hex Key / Metric Allen Wrench Set
• Large Crescent Wrench
• Large Phillips Screwdriver
• Chalk Line
• Medium Phillips Screwdriver
• Tape Measure: 25 Foot (7.5 M) Minimum

8
Remove the 6mm Allen Bolt and install the Cylinder Fittings.
Assemble all Fittings together, including the Quick Disconnect,
preferably in a vice. Then, install the Fitting Assembly into the
Hydraulic Cylinder. (See Figure 3)
STEP 3
INSTALLING THE HYDRAULIC CYLINDERS
Install the Post Wheels (P/N 5575061) using M8x55 Hex Head Bolts
(P/N 5530377) and M8 Nylon Nuts (P/N 5535001) onto each Post.
(See Figure 1)
Slide the Fitting Assembly through the
access hole located on the backside of
the Posts. (See gure 4)
Slide the Lift Head until it rests rmly on
the Base Plate, then carefully stand up
each post.
1.
2.
4.
3.
Fig. 2
Install the Post Handles (P/N 5505071) with
M10 x 25 Hex Head Bolts (P/N 5530738) with
M10 Washers (P/N 5545200) and install the
Post Straps Assemblies (P/N 5601487) with
M10 x 40mm Hex Bolts and M10 Nylon
Lock Nuts. (See Figure 6)
Slide the Hydraulic Cylinders through the
Lift Head tube. (See gure 5)
P/N 5505071
4
P/N 5530738
4
P/N 5535013
4
P/N 5530302
4
P/N 5550209
1
P/N 5550076
1
P/N 5550077
1
P/N 5550014
1
5.
Fig. 5
Fig. 3Fig. 3
Fitting Assembly
6.
Turn the Posts over and lay them down with the open side up.
Slide the Lift Head to the top of the Post. Remove the Hydraulic
Cylinder from the Post. Rotate Hydraulic Cylinder to access the
Hydraulic Cylinder Port. (See Figure 2)
7.
Fig. 4
Fig. 6
Fig. 1
P/N 5530377
4
P/N 5575061
2
P/N 5535001
4
Lift Head
Hydraulic
Cylinder
Hydraulic
Cylinder
2a.
2b.
Cylinder
Port

9
1. Assemble the Cart as shown. (See Figure 7)
2. Attach the Power Unit and Hydraulic Flow Divider to the
Power Unit Cart using 8 Hex Head Bolts (P/N 5530304) and
Nylon Nuts (P/N 5535001). (See gure 8)
NOTE:
Install the Hydraulic Flow Divider so that when facing it
from the front, the OUT Ports are on the top, and the
lower ports are IN.
3. Remove the Shipping Plug from the Lower Left Port
stamped "IN" on the Flow Divider. Install the Long 90°
Elbow Fitting (P/N 5550170). When tightening the Fitting,
hand tighten rst and then using a wrench turn approx.
3 turns past tight. (See gure 9)
NOTE:
Use the include Liquid Thread Sealant to seal the
connections made to the Hydraulic Flow Divider.
Use Liquid Thread Sealant on NPT threads only.
4. Remove the plastic plug from the Hydraulic Pressure
Port (usually labeled as P1 / P2)on the Power Unit and
attach the Long 90°Elbow Fitting (P/N 5550074).
5 Attach the Short Power Unit Hose (P/N 5570242) as
shown. DO NOT use Teon Tape on the JIC Fittings.
(See Figure 9)
* SEE FOLLOWING PAGE *
STEP 4
MOUNTING THE HYDRAULIC POWER UNIT
P/N 5550170
1
P/N 5550074
1
P/N 5570242
1
P/N 5530378
12
P/N 5601474
1
P/N 5755171
2
P/N 5535357
12
P/N 5737162
1
P/N 5540113
2
P/N 5545141
4
P/N 5215970
2
P/N 5601535
1
P/N 5530304
8
P/N 5535001
8
Fig. 7
Fig. 8 Fig. 9
P/N 5715003
1

10
IMPORTANT FLOW DIVIDER INFORMATION
There is a Hydraulic OUT Port on either side of the Flow Divider, and a Hydraulic IN Port on the lower Ports. Depending
on the Flow Divider that came with your Lift, the Ports may be congured di󰀨erently.
Your Lift will not work right if the Flow Divider is installed incorrectly!
If your Flow Divider looks like the graphic below, connect the two Long Hydraulic Hoses to the top OUT Ports, and the
Short Hydraulic Hose connects to the Bottom Left IN Port.
If your Flow Divider looks like the graphic below, the Left side Ports are mislabeled. Do not connect the Short
Hydraulic Hoses to the Top Left Port. Connect the Short Hydraulic Hose connects to the Bottom Left Port, and two
Long Hydraulic Hoses connect to the Top Ports on either side of the Flow Divider.
If your Flow Divider looks like the graphic below, rotate the Flow Divider 180° so that the side with an IN and
OUT Port is on the right side, and then connect the Short Hydraulic Hose to the Lower IN Port; the other end of the
Short Hose connects to the Pressure Port on the right side of the Power Unit..
