PM100
This product is marked with:
in accordance with the Class II product
requirements specified in the R+TTE Directive,
1 /5/EC.
"We hereby declare that the above named
product is in conformity to all the essential
requirements of Directive 1 /5/EC".
French Translation
Nous déclarons que le produit référencé
ci-dessus satisfait aux exigences
R&TTE 1 /5/EC qui lui sont applicables.
Spanish Translation
Certificamos que el aparato es conforme con lo
establecido en las disposiciones de la
Directiva 1 /5/CE.
German Translation
"Wir möchten hiermit bekanntgeben, daß das oben
genannte Produkt in Übereinstimmung mit allen
erforderlichen Bedürfnissen der 1 /5/EC Direktive
seht"
ENGLISH
1
0168 !
All manuals and user guides at all-guides.com

INDEX
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
THE MAXON PM100 . . . . . . . . . . . . . . . . . . . . . . . . . . .3
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
DESCRIPTION OF RADIO . . . . . . . . . . . . . . . . . . . . . .4
NOTES TO THE USER . . . . . . . . . . . . . . . . . . . . . . . . .5
PRECAUTIONS IN USE . . . . . . . . . . . . . . . . . . . . . . . .5
PREPARING FOR USE . . . . . . . . . . . . . . . . . . . . . . . . .6
CONTROLS AND INDICATORS . . . . . . . . . . . . . . . . .6
FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
REAR PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
STATUS LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
AUDIBLE MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . .7
USING THE PM100 . . . . . . . . . . . . . . . . . . . . . . . . . . .7
ERROR ALERTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
RADIO OPERATIONS . . . . . . . . . . . . . . . . . . . . . . . . .8
SWITCHING THE RADIO ON . . . . . . . . . . . . . . . . . . . .8
RECEIVING A CALL . . . . . . . . . . . . . . . . . . . . . . . . . . .8
MAKING A CALL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
BUSY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
TRANSMIT TIME OUT TIMER . . . . . . . . . . . . . . . . . . . .
TX LOCK-OUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MONITOR/TONE DEFEAT . . . . . . . . . . . . . . . . . . . . . .
CHANGE CHANNEL . . . . . . . . . . . . . . . . . . . . . . . . . . .
SCANNING & PRIORITY LOOKBACK . . . . . . . . . . . . . .
ADDITIONAL INFORMATION . . . . . . . . . . . . . . . . . .11
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
VOICE PRIVACY . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
ENGLISH
2
All manuals and user guides at all-guides.com

INTRODUCTION
THE MAXON PM100
Key features
 State of the art microprocessor control
 Four fully synthesised channels
 Tri-colour LED instantly shows the status of a channel
 Full scanning features
 Front panel speaker
 Standard vehicle DIN mounting size
 Encryption option
 Selcall optional module
S gnall ng opt ons
 Continuous Tone Coded Squelch Signalling (CTCSS) and
Digitally Coded Squelch (DCS)
CTCSS/DCS helps to screen you from calls intended for
other users or user groups. It is also used in some
systems to access wide-area repeaters.
Robustness bu lt- n
The PM100 is of a sturdy construction and is dust and water
resistant to the level set down in IEC 52 , level IP54 and
also withstands the rigorous tests of the US MIL STD 810C,
D, E.
WARRANTY
This product comes with a standard 12 months (UK)
warranty. An extended warranty can be arranged for this
product. Ask your dealer for details.
ENGLISH
3
All manuals and user guides at all-guides.com

DESCRIPTION OF RADIO
1 Channel Selector
2 Volume Control
3 Microphone Socket
4 Status LED Display
5 Auxilary Button
6 Monitor Button
7 Channel Display
8 Antenna Socket
DC Supply
10 External Speaker Socket
ENGLISH
4
All manuals and user guides at all-guides.com
all-guides.com

NOTES TO THE USER
Care of equ pment
 Keep the exterior of the radio clean using a soft damp cloth.
 Do not use chemical cleaners, aerosol sprays or petroleum
based products as they may damage the radio housing.
Warn ngs
The use of an attachment not recommended or supplied by
Maxon may cause damage to equipment or injury to
personnel.
Never attempt to disassemble, modify or repair the unit
unless the work is carried out by a qualified technician.
Incorrect assembly, modification or repair may cause
irreparable damage to your unit.
For service or repair always return your radio to an
authorised Maxon dealer.
PRECAUTIONS IN USE
 Maxon Sewon Europe Ltd. draw your attention to the
provisions within the UK Highway Code, Section 43:
You MUST exercise proper control of your vehicle at all
times. Do not use a hand-held telephone or microphone
while you are driving. Find a safe place to stop first. Do
not speak into a hands-free microphone if it will take your
mind off the road. You MUST NOT stop on the hard
shoulder of a motorway to answer or make a call, except
in an emergency.
 Never transmit when people are near the antenna: holding
or being close to the antenna may cause injury.
 Never use the radio transmitter without the correct antenna
securely connected or a suitable load attached.
 Never use the radio in close proximity to sensitive medical
equipment.
 Always switch off the radio if you are near to an explosive
atmosphere or where electrical detonation may occur.
 Always install all equipment in accordance with MAXON
SEWON Europes installation instructions.
ENGLISH
5
All manuals and user guides at all-guides.com

PREPARING FOR USE
Unpack ng and Inspect on
Unpack the radio and check that you have received the
following items:
 PM100 mobile radio
 Microphone
 Power lead
 Mounting kit
 Accessories kit
 Microphone clip
CONTROLS AND INDICATORS
FRONT PANEL
ÀChannel selector: Rotate to select desired channel
ÁVolume control: The volume control is the ON/OFF
switch and controls the speaker volume.
ÂM crophone socket: Plug the fist microphone in here.
ÃStatus LED d splay: Illuminates and flashes in different
colours to tell you the current operating condition and
activities of your radio.
ÄAux l ary button: Switches in the scrambling option if
fitted. If your radio has been upgraded with an encryption
module, further functions become available. Pressing the
Auxiliary button makes the radio transmit and receive in
scrambled mode. Releasing the button switches the radio
back to normal, clear, mode (see SCRAMBLER
FEATURES).
ÅMon tor button: Allows a channel to be monitored. This
button may be used to assist clarity when the radio is
operating at the limit of its range.
ÆChannel d splay: The LED at the current position is
illuminated.
REAR PANEL
ÇAntenna socket: This is the connection point for a 50
ohm antenna.
ÈDC Supply
ÉExternal speaker socket: This is the connection point for
an external loudspeaker for the radio. The front panel
speaker is muted when the external speaker is connected.
ENGLISH
6
All manuals and user guides at all-guides.com

STATUS LED
* Your dealer or system supervisor may have disabled the
flashing green scan indicator.
AUDIBLE MESSAGES
Audible alerts, such as high and low tones, of long and short
duration, may be used. Your radio controller will be able to
give you details of the alerts used in your system.
USING THE PM100
Note: The availability of the functions described in this
section is dependent on the set-up of your radio. Please
consult your Dealer or Supervisor for further information.
ERROR ALERTS
Unprogrammed channel
If your radio has been set-up for less than the maximum
number of channels, turning to a blank channel will cause
your radio to beep and the status LED will flash red,
indicating that the channel is unusable.
Rece ve only channel
Your radio may be set-up to receive on a channel but not to
transmit. If the PTT is pressed on such a channel, the radio
will beep and the LED will flash red.
ENGLISH
7
Status Descr pt on Colour
Normal Power on ready Off
Busy Yellow
Receiving correct Green
CTCSS/DCS
Transmit Red
TX-lock out Yellow, flashing
Scanning Green, flashing*
Error EEPROM Error Red, flashing
PLL Error Red, flashing
Filtering Error Red, flashing
All manuals and user guides at all-guides.com

RADIO OPERATIONS
SWITCHING THE RADIO ON
Switch the radio on by turning the volume control clockwise
until its clicks. An audible alert sounds on completion of the
automatic self-test.
RECEIVING A CALL
On receipt of a call, the TX/RX LED will switch to either
yellow or green depending on your system configuration.
Wait until the incoming message has finished before starting
your own transmission.
Press and hold the fist microphone PTT button (located on
the side of the microphone) while making a transmission 
speak clearly with the microphone approximately 5 to 8 cms
away  release the PTT button to listen.
The status LED illuminates red whenever your radio is
transmitting.
If your radio has been set-up for Transmit Time Limiting, your
radio will return to the Receive state after this transmit
period.
If your radio has been set-up for Transmit Lockout, you will
not be able to transmit if the channel is busy.
MAKING A CALL
Before transmitting, it is recommended that you monitor the
channel to ensure that it is not in use. Using the channel
selector, turn to the required channel and press the Monitor
button.
If the channel is clear, press the microphone PTT button.
The TX/RX LED will turn red. Speak to the party you are
trying to call.
Listen to the acknowledgement from the called party and
then speak into the microphone in a normal manner.
Release the PTT button to listen.
BUSY
When your radio receives a signal above a preset minimum
level, the LED will illuminate yellow to tell you that there is
activity on the channel you are switched to. Your radio may
be set up so that you hear who is talking straight away or it
may be set up to prevent this until the correct CTCSS/DCS
code is received.
ENGLISH
8
All manuals and user guides at all-guides.com

Rece v ng CTCSS/DCS
Your PM100 may be set-up so that only calls with the radios
specified code will be heard. In normal operation, the
speaker will remain quiet until the correct CTCSS/DCS code
is received. The status LED will glow green, the loudspeaker
will open and the message will be heard.
TRANSMIT TIME OUT TIMER
If set-up, your radio will stop transmitting after a preset
period of time. An audible alert is heard at the end of the
period.
TX LOCK-OUT
The PM100 may be set-up to disable the transmitter when
the channel is Busy. If the PTT button is pressed, an audible
alert will sound and the status LED will flash yellow.
MONITOR/TONE DEFEAT
Your radio may be set-up to either allow or dis-allow
monitoring of a channel. Short presses of the Monitor button
will toggle the monitor mode on and off.
When on, the radio will continue to receive even if the signal
is very low. This may assist clarity if the radio is operating at
the limit of its range.
CHANGE CHANNEL
The PM100 can access a maximum of 4 channels. Turn the
channel control to the channel number on which you wish to
operate.
SCANNING & PRIORITY LOOKBACK
Note: Your radio may or may not be configured for scanning.
Please ask your Dealer or System Supervisor for specific
details.
What s scann ng?
Your radio is switched into Scan mode by selecting the scan
channel (see Dealer/System Supervisor for details). When
scan commences, it cycles through a set of channels. It is
pre-programmed to stop at any busy channel. When activity
stops on this channel, the radio waits a pre-determined time
to allow you to respond. If you dont transmit, the radio will
then continue with the scan.
ENGLISH
9
All manuals and user guides at all-guides.com
all-guides.com

Remov ng a channel from the scan l st
If your radio is always stopping on an unwanted channel,
press the Monitor button while the scan has stopped on the
channel to remove it from the scan list.
Note: Scan list is reset when the radio is turned off then on,
or when the scan channel is re-selected.
What s pr or ty lookback?
If your radio is programmed for priority lookback, your
Dealer/System Supervisor will have assigned a priority
channel, and between 1 and 3 lookback channels. If your
radio is receiving on a lookback channel, it will periodically
check the priority channel for activity. If the priority channel
becomes busy, the radio will monitor this channel in
preference to the current channel.
ADDITIONAL INFORMATION
ACCESSORIES
A full range of Maxon accessories are available to use with
this product. Please contact your Maxon Reseller for more
information or visit www.maxon.co.uk
VOICE PRIVACY
Your radio may be upgraded with one of two voice privacy
options which provide protection against unauthorised
eavesdroppers. The Single Frequency Inversion Scrambler
provides medium level speech security, and the Rolling Code
Scrambler provides high level speech protection against the
most determined opponents.
Clear mode
Once upgraded, the Auxiliary button is used to toggle the
radio between clear and secure modes. When the button is
out, the PM100 will transmit in clear mode.
Secure Mode
When the Auxiliary button is in, the PM100 will be switched
to the secure mode. All transmissions will now be scrambled.
Rece ve Mode
If your radio has inversion scrambling fitted, to listen to
scrambled messages, the Auxiliary button must be pressed
in. Radios with rolling code scrambling will switch into the
ENGLISH
10
All manuals and user guides at all-guides.com

correct receive mode automatically.
NOTES:
When using inversion scrambling, all radios in a system must
have the special function button switched to the same state
to allow correct operation.
When using the rolling code scrambler, the PM100 will
automatically switch between clear and secure modes when
receiving a transmission. This transmits data at the start of
every transmission and the user should pause for about half-
a-second after depressing the PTT button before speaking
into the radio.
SOP55-01 FIXED SELCALL MODULE
If your radio has been upgraded with the SOP55-01 Selcall
Module, a range of additional signalling options is available.
These features can reduce the time spent receiving
messages meant for other radios and makes better use of
the radio channel.
With the Selcall option fitted, the operation of the radio will
change. An instruction sheet with further details on the
operation of the radio with Selcall is included with the
module.
ENGLISH
11
All manuals and user guides at all-guides.com

All manuals and user guides at all-guides.com

©2002 By Maxon Europe Ltd. All Rights Reserved UM PM100 4L
All manuals and user guides at all-guides.com
