MFS Series is one of the Maxphotonics outstanding products. Its appearance
has revolutionary significance for the integration of high-speed and high-
resolution laser marking system.
Compact, stand-alone, easy-to-use design that can be integrated directly into
the user's device. Low power consumption, practical and durable design for
laboratory and market applications.
Laser light exhibits unique characteristics that may pose safety hazards.
Therefore, the laser light can’t be normally associated with other light sources,
and all operators and people near the laser must be aware of these special
hazards.
In order to ensure the safe operation and optimal performance of the product,
please follow all warnings and safety instructions in this guide during process of
operation, maintenance and service.
For ensuring the safety of operators, operators are urged not to open the
equipment privately at all times. There are no user serviceable parts, equipment
or assemblies associated with this product. Lasers of unauthorized disassembly
shall not be subject to warranty.
Chapter 1
Characteristic Description

6
Chapter 2
General Safety Information
1-Safety Conventions
All safety warning symbols during operating process of the laser include:
SYMBOLS DESCRIPTION
WARNING: Refers to a potential Electrical Hazard to
human body. It requires a procedure that, if not correctly
followed, may result in bodily harm to you and/or others.
Do not proceed beyond the WARNING sign until you
completely understand and meet the required conditions.
CAUTION：Refers to a potential hazard on product. It
requires a procedure that, if not correctly followed, may
result in damage to the product or components. In order
to ensure normal use of equipment, do not violate the
requirement of the CAUTION sign.
WARNING:Refers to a potential Laser Hazard.The symbol
represents laser radiation. The symbol is pasted on laser
output end.
NO SYMBOL
IMPORTANT：Refers to any information regarding the
operation of the product. Please do not overlook this
information.

7
Chapter 2 General Safety Information
NOTE :
◎ This device is classified as a high power Class IV laser instrument. It
may emit up to 20W average power near 1060nm wavelength. This level
of light may cause damage to the eye and skin. Despite the radiation
being invisible, the beam may cause irreversible damage to the retina.
Laser safety eyewear is not provided with this instrument, but must be
worn at all times while the laser is operational. Use appropriate laser safety
eyewear when operating this device. The manufacturer of the laser system
is responsible for the safety compliance according to the applicable
standards and regulations.
2-Laser Protection
1.Laser Protection Requirements
You must wear the safety protective glasses while operating the laser, and
rationally select the safety protective glasses according to the lasing wavelength
of the laser. If the device is a tunable laser or Raman product, it emits light
over a range of wavelengths and the end user should conrm the laser safety
eyewear used protects against light emitted by the device over its entire range
of wavelength.
2.Laser Protective Equipment Suppliers
Maxphotonics recommends material or equipments provided by following laser
protective equipment suppliers for you, including LaserVision USA, Kentek
Corporation, Rochwell Laser Industries, etc. All the supplier information is
provided by Maxphotonics only for the convenience to use, so Maxphotonics
assumes no responsibility for any problem caused by using the products of
abovementioned suppliers.

8Chapter 2 General Safety Information
3-General Safety Instructions
In order to ensure the safe operation and optimal performance of the
product, please follow these warning and cautions in additionto the other
contained elsewhere in this document.
1.Specular Reflection
There are often numerous secondary laser beams produced at various angles
in the output port of the laser. These divergent beams are produced when the
primary beam of laser reects off a smooth surface, and they are called specular
reflections. Although these secondary beams may be less powerful than the
total power emitted from the primary beam, the intensity may be great enough to
cause damage to the eyes and skin as well as surface of materials.
WARNING:
◎You must exercise caution to avoid/minimize specular reflections as these
laser radiations are invisible!
2.Safety Instructions of Accessories
WARNING :
◎This device has an output optical head connected to the laser with a fiber
cable. Please, be careful dealing with the output head.
3.Optical Operating Instructions
We strongly recommend that you read the following procedures before operating
the laser:
1.Never look directly into the laser output port when the power is turned on.
2.Avoid positioning the laser and all optical output components at eye level.
3.Ensure that all personal protective equipment is suitable for the output power

9
Chapter 2 General Safety Information
and wavelength range of the l aser.
4.Do not install collimators when the laser is active.
5.It is forbidden to turn on the laser during the mounting of ber or cutting head.
6.For collimated outputs, maintaining a clean output lens is essential. Always
close (re-cap) the collimator after use. Do not touch the output lens and do not
clean it with any solvents. Cleaning with the special solvent and cleaning buds is
allowed as described later on in th is manual.
WARNING:
◎Make sure that the individual protective equipment meets the output power
and wavelength range of the laser.
◎ Never look directly into the optical ber or the collimator, and Use appropriate
laser safety eyewear when operating this device.
◎Optical damage may result from failure to comply with the above instructions.
Such damage is not covered by the warranty.
CAUTION:
◎Use of controls or adjustments or performance of procedures other than those
set forth in this User’s Guide and related documents may result in hazardous
radiation exposure.
4.Operation Environment Requirements
We strongly recommend that you read the following procedures before operating
the laser:
1.Do not expose the device to a high moisture/high temperature environment .
Install the laser in the cabinet with the function of temperature-humidity control

10 Chapter 2 General Safety Information
and dust-free.
2.Before switching on the device make sure that environmental temperature and
humidity are within a specied range.
WARNING:
◎Optical damage may result from failure to comply with the above instructions.
Such damage is not covered by the warranty.
1.Avoid the impaction on the shipper rod of worktable when the laser is working.
2.The laser and optical lens are fragile, please handle with care.
3.Stop running once device failure, and provide professional treatment.
4.Please follow a set sequence of on-off.
5.The limitation on surface of marking machine is within the working area.
6.Keep the device clean and indoor.
6.Safety Labels and Labeling Locations
The following shows the pictures of tags and their positions on the product:
Pictures of label Label name Label location
Light Emission
at top of
galvanometer
Caution at top of
galvanometer
CAUTION

11
Chapter 2 General Safety Information
4-Additional Safety Information
For additional information regarding Laser Safety, please refer to the list
below:
Laser Institute of America(LIA)
13501 Ingenuity Drive, Suite 128
Orlando,Florida 32826
Phone:[phone],Fax: [phone]
Toll Free:1 800 34 LASER
American National Standards Institute
ANSI Z136.1, American National Standard for the Safe Use of Lasers
(Available through LIA)
International Electro-technical Commission
IEC 60825-1,Edition 1.2
Center for Devices and Radiological Health
21 CFR 1040.10 - Performance Standards for Light-Emitting Products
US Department of Labor - OSHA
Publication 8-1.7 - Guidelines for Laser Safety and Hazard Assessment.
Laser Safety Equipment
Laurin Publishing
Laser safety equipment and Buyer’s Guides

12
1-Features
MFS Series is one of the Maxphotonics outstanding products. Its appearance
has revolutionary significance for the integration of high-speed and high-
resolution laser marking system. Compact, stand-alone, easy-to-use design
that can be integrated directly into the user's device. Low power consumption,
practical and durable design for laboratory and market applications.
Main Features:
1.Narrow Pulse width, High peak power, Wide frequency
2.High reliability, Super long life time
3.Shadow and virtual breakage will not occur in special material processing
Applications:
1.Industrial applications
2.Scientic research
2-Laser Model Designation Codes
Model Coding Rules：
Chapter 3
Product Description
Model Model Coding Rules
MFS-10T Maxphotonics Q-switched laser-10W
MFS-20T Maxphotonics Q-switched laser-20W

13
Chapter 3 Product Description
3 - Certification
Maxphotonics certifies that this equipment has been thoroughly tested and
inspected and meets published specications prior to shipping. Upon receiving
your equipment, check whether the packaging and accessories have been
damaged in transit. If damage is apparent, please contact Maxphotonics
immediately.

14
Chapter 4
Specication
1-Characteristic Parameters
No. Type MFS-10T MFS-20T
1Laser power 9±1W 19.5±0.5W
2Central wavelength 1064nm
3Beam quality M2 ＜ 1.4
4Frenquency tunable
range 20-50khz 30-60khz
5Marking Area
(Standard) 110(F=160MM)
6Engraving Line Speed 0-15000mm/s
7Mode for focusing Manual
8Marking Speed 600-1000 characters/min
9Min. Line Width 0.02mm
10 Min. Character 0.15mm
11 Repetition Accuracy ±0.002mm
12 Cooling Air Cooling
13 Working Environment Clean Room or Less dust room
14 Working Temperature 10-35℃
15 Power Consumption ≤ 120W ≤ 160W
16 Operation voltage AC220V±10%，50HZ

15
Chapter 4 Specication
2-Computer Configuration
No. TYPE Conguration
1CPU Intel J1800 Processors
2Memory ADATA 4G DDR3L 1600
3Ethernet 2x LAN Intel I211 (post IO interface)
4Graphic
Control Intel® HD Graphics
5Display Port 1x HDMI：HDMI supported Max. resolution is 1920×1200@6
0Hz
6Hard disk 64G
7USB
Interface 2x USB2.0；2x USB3.0
8Serial Port 1x RS232(contact pin)，and COM1 support mode RS422,
RS485
9Operate
System
Windows 7 32 bit Chinese Professional System (strandard)；
Also support Windows 7/ Windows 8/ Windows 10/ Linux
10
Temperature
Working Temperature：0℃～ 60℃
11 Storage Temperature：-40℃～ 85℃
12 Humidity 5% ～95% relative humidity,no condensation

16 Chapter 4 Specication
3-Structural Layout
Laser Views.（Unit：mm）

17
1-Interface function description
Laser power supply as follows:
Chapter 5
Using Instruction
Please confirm the attachments contained in this product according to the
table below：
NOTE：
◎ If you find any damage to the outer packaging or internal components after
receiving the products, please contact Maxphotonics or local representative
immediately.
ITEM QTY
User Manual and Test 1
Power supply（optional）1
23456
8 9 10 11 12 13
1
7

18 Chapter 5 Using Instruction
Definition of each interface:
1.Power Supply: 220V to 24V power adapter socket;
2.DB 15 Pins Interface:Scan head/Galvometer interface;
3.DB 26 Pins Interface:External Control IO interface of control card (more
denition about IO);
4.USB Interface: For USB upgarde the control card program interface and WiFi
interface;
5.External USB port: used for external computer and laser control system
connection port by USB cable (reserved);
6.DIP switch: used for internal USB interface and external USB interface
selection switching;;
7.Foot Switch Interface: use for foot switch/padel; turn ON, the laser emit, turn
OFF, no laser emit;
8.Microphone, audio interface;
9.Computer USB interface;
10.Computer network port, when the industrial computer is connected to the
network cable;
11.VGA interface, computer monitor interface;
12.HDMI interface, computer monitor interface;
13.Industrial computer power supply interface, the internal power of the laser
machine has been supplied, so this interface does not need to be used under
normal circumstances.
2-DB 26 Pins Interface Definition
1.Functions of each interface
