MAXSTAR VITA User manual

COLD PRESS JUICER
VITA PRESS
MAXSTAR APPLIANCE LIMITED
1/7, West Patel Nagar, Opposite Pillar No. - 205, New Delhi - 110008
Tel: [phone]; e-mail: [e-mail]; Website: www.maxstar.in
USER MANUAL
Please read this book carefully before using this appliance.

FOR HOUSEHOLD USE ONLY
IMPORTANT SAFE INSTRUCTION
When use electrical appliances, basic safety precaution should always be followed including below:
1. read all instruction carefully before using
2. to protect against risk of electrical shock, do not put main body(motor) in water or any liquid
3. children should be supervised to ensure they do not play with the appliance
4. do not operate any appliance with damaged cord or plug or after the appliance malfunctions, or it is dropped or
damaged in any manner. return the appliance to nearest authorized service agent for examination, repair or
electrical or mechanical adjustment.
5. if the supply cord is damaged, it must be replaced by manufacturer or its service agent or similar qualified person
in order to avoid hazard
6. always unplug when it is not in use or before assembling or taking off parts or cleaning.
7. forbid to touch moving parts
8. do not use any attachments which is not supplied by manufacturer ,otherwise it may lead to fire, electrical shock
or other injury
9. always ensure to switch off appliance and motor has been stopped completely before disassembling
10. do not put your fingers or any foreign into the juicer when it is working. If food is stuck in the inlet ,use pusher to
push it down or use reverse switch to unstick .if this manner can not solve the problem, then to stop juicer
immediately and after ensure the motor is stopped completely to disassemble appliance to move food.
11. do not use appliance outdoor
12. do not use appliance for other intended purpose
13. do not put any parts into dishwasher for cleaning
14. do not use the appliance more than 20min constantly to avoid motor is damaged. Use it again until appliance is
cool(around 20min)
15. do not use appliance to extract had material, like large seeds, ice ,frozen fruit and so on.
16. This appliance is not intended for use by persons (including children)with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance.
17,switch off the appliance and unplug from socket before changing accessories or approaching parts that move in
using.
installation & operation instruction
parts instruction
1-hopper
2-auger head
3-filter
4-spinning brush
5- bowl
6-base
7-clean brush
8-pusher
9-pulp cup
10-juice cup
Friendly hint: do not operate appliance with empty bowl, otherwise it will speed up abrasion of parts
assembling instruction
importance: prior to assemble the juicer, please check this point: at the base of bowl, there is a r
ubber
stopper ,correctly fix the stopper to ensure all of the juice only exits via the juicer outlet, before extracting
always ensure the rubber stopper is firmly in place. See below fig.
1,assemble bowl onto the base. Put bowl on the base and clockwise rotate to lock the blow. Make sure the bowl is
always locked on the base tightly. See below fig.
2,put the spinning brush into the bowl and make sure the spinning brush could be rotated freely.
3,put the filter into the spinning brush, pls note there is a sign on the filter edge ,this sign must align with
the
same sign on the edge of bowl. The correct assembling makes the filter can not be rotated in the bowl. See
below
fig.
4,insert the auger head into the filter, make sure the auger head’s axes must be tightly fixed on the base’s axes. S
ee
below fig.

5,assemble hopper onto the bowl: Align the convex point of hopper edge with the sign on the bowl and
then
clockwise rotate the hopper to fix tightly .see below fig.
operation instruction
important:
do not switch on appliance prior to imputing materials
do not operate appliance more than 20min at one times
1,plug in appliance
2,place cups under outlet of juice and outlet of pulp
3,know of switch: ON/ OFF /REV ---see switch button on product
ON-starts the motor and juicing process
OFF-switch off appliance
REV-reverse rotation, only use the function when something is stuck in the bowl and need to be unclogged
4,put materials into the hopper to extract juice
.ensure pieces are not large to enter into hopper
.remove hard seeds or pips or other hard part of material
.do not overstuff the hopper or force material in. put material slowly one by one. the pusher only be used
if
materials are stuck
5,switch on juicer to extract juice ,at the same time put materials into hopper one by one as step4.
6,if materials are stuck or clogged ,stop juicer and then shift switch to REV to unclog materials. If such action is
not
working ,stop juicer and disassemble hopper to clean material ,then assemble hopper again to go on work.(
very
important: before disassemble hopper ,must unplug from power socket)
7,when finished or leave juicer for a while ,switch off the juicer and unplug from power socket.
how to clean juicer
1,switch off juicer and unplug from power socket before cleaning
2,as per step of assembling to be reverse method to disassemble all parts of juicer one by one
3,use brush to clean all parts under water tap
4,use damp cloth to wipe base ,make sure do not let any liquid go into the base
technical data
input voltage: AC220-240V
Frequency :50/60Hz
Power:150watts
Speed:AC motor 45RPM / DC motor 75RPM
Max operation time: less than 20min
trouble shooting
before you call for service ,review the trouble shooting firstly
problem
Possible cause
What to do
No power to work
.Juicer is not plugged in
correctly
.Check the juicer to plug in tightly
.incorrect to assemble
hopper
.re-assemble hopper correctly
Motor is stopped
during working
.Bowl is overfill with
material
.hard material inside or
much fiber inside that
cause juicer be stuck
Press reverse button to unclog material .if not working ,then
disassemble hopper to clean material and then assemble
hopper
again to try .if juicer still is not working ,stop juicer to call
service
agent
Leakage from
beneath the bowl
Rubber plug on base of
bowl is not inserted
correctly.
Disassemble all parts to check rubber plug and re-plug in correctly
Stain on the bowl,
filter, spinning
brush
Natural color from juicing
material
This is perfectly normal
Damage filter
Frozen material, seeds,
pips, and other hard
material in bowl
Ensure you have read the manual carefully and operate correctly
Squeaking noise
during working
.Juicing noise from
squeezing screw
.This is perfectly normal. Ensure you did not overstuff material
.some hard material in the
bowl
.stop juicer to disassemble hopper to clean material
'

COLD PRESS JUICER
RATING : 220-240V,50 HZ
POWER : 150W
VITA MIX
WARRANTY CARD

Please preserve the Warranty Card and Cash Memo and ensure that they are duly stamped and signed by the Company’s dealer.
The Warranty Card or a Cash Memo which is not stamped and signed by the dealer will be treated as invalid.
Max Star product that you have bought is of excellent quality and construction. However we \will correct, free of charge any defects in
material or workmanship for a period of one year* (the Warranty period) from date of purchase subject to the terms and conditions.
TERMS & CONDITIONS OF WARRANTY
1. Max Star products are warrantied solely against poor workmanship, manufacturing defect and use of faulty material only.
Consequential liabilities will not be entertained. All Max Star products are designed for domestic usage only.
2. In the event of a replacement of spares during the warranty period, this warranty card will be required along with the original tax
invoice/ Cash Memo to process the claim. The Company will not entertain a claim with incomplete warranty details.
3. This warranty is confined to the first purchaser of the product only & is not transferable.
4. Repair or replacement of spares will be carried out through the Company’s Authorized Service Centre or its Authorized Dealers.
5. Repairs during warranty period shall be carried on “Carry In” basis, wherein, for services, the purchaser shall bring the product to the
Company’s Authorized Service Center / Authorized Dealer for warranty service along with Tax Invoice / Cash Memo and Warranty
Card. The warranty does not cover cost of transportation of product from the customer’s place to the Company’s Authorized Service
Centre/ Authorized dealer. However, in case the customer located beyond the municipal limits of the jurisdiction of the Company’s
Authorized Service / Authorized Dealers, wishes the Company / its Authorized Service Center/ Authorized Dealer to collect the
product from his place for the purpose of servicing the product then all expenses incurred in collection and delivery back of the
product, as well as the expenses incurred in connection with deputing of service personnel / technicians towards to and for travel,
conveyance and other incidentals etc. will be borne by the customer.
6. In the event of repairs / replacement of any part/s of the product, this warranty will be thereafter continue and remain in force only for
the unexpired period of the warranty. Moreover, the time taken for repair/ replacement and in transit whether under the warranty or
otherwise shall not be excluded from the warranty period. The customer shall have to pay a visit charge towards inspection, as
applicable.
7. The Company / its Authorized Service Centre/ Authorized Dealer, reserves the right to retain any parts or component/s replaced at
its/their discretion in the event of a defect noticed in the equipment during the warranty period. The company shall have exclusive
right to replace the defective / unserviceable part/s or component/s with the part/s or component/s which may be new or refurbished.
8. The warranty does not cover accessories external to the product.
9. The warranty does not cover demonstration/installation of the product purchased.
10. In the event of any unforeseen circumstance, and spares not being available, the Company’s prevailing depreciation rules will be
binding onthe purchaser to accept as a commercial solution in lieu of repairs.
11. The warranty is issued at Delhi and Courts at Delhi shall have exclusive jurisdiction over matters covered or flowing from this
warranty.
12. The Company’s obligation under this warranty shall be limited to repairing or providing replacement of parts, which are found to be
defective.
13. In the event of repairs/replacement of specific parts on which warranty is more is more than product warranty, the specific parts will
be repaired /replaced free of the cost but customer needs to pay service charges in such cases.
THIS WARRANTY IS NOT APPLICABLE IN ANY OF THE FOLLOWING CASES:
1. The warranty card is not duly filled by the selling dealer.
2. The completed warranty card is not presented to the service personnel at the time of repair.
3. The product is not purchased from an Authorized MAX STAR dealer.
4. The product is not installed, used and maintained according to instruction given in the instruction manual.
5. Defect cause by improper use as determined by the company personnel.
6. Installation/ repair work is carried out by persons/agency other than Authorized by the company.
7. Defects have been caused by reasons beyond control of the Company, like act of God, during transit to Service Centre or
purchaser’s residence, poor maintenance, damage to the product caused by insects/ rodents.
8. The warranty does not apply to :
a. Surface coating, body aesthetics, plastic parts, neon lamps, bake light part, rubber/neon parts, cord wire, push button & bulb and
dursable parts viz. shaft, bush etc.
b. Normal wear and tears of parts.
c. Damages resulting from accidents, mishandling, improper use or negligence on the part of customer and fluctuation in supply
voltage.
d. Damages resulting due to usage of power supply other than specified 230 Volts AC 50 Hz. e.g. inverters, generator etc.
e. For humming noise generated due to usage of electronic fan regulators of any make.
f. Breakage of glass parts.
g. Heating tubes/rods for failure or breakage.
MAXSTAR APPLIANCE LIMITED
1/7, West Patel Nagar, Opposite Pillar No. - 205, New Delhi - 110008
Tel: [phone]; e-mail: [e-mail]; Website: www.maxstar.in
WA R R A NT Y
(As per terms and conditions overleaf)
Name of Purchaser : Address : Phone No. Residence :
Office : Product Sl. No.: Date Of Purchase :
Customer’s Signature Dealer’s Stamp & Signature
