Maxx Cold MCWC28 User manual

INSTRUCTION MANUAL
MODE D’EMPLOI
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USE
English Be sure wine cellar is standing upright 24 hours prior to plug-in.
020315
MCWC28
28-Bottle Wine Cellar
Cellier pour 28 bouteilles

IMPORTA T SAFEGUARDS
Read all instructions before using this appliance. When using this appliance, always ex-
ercise basic safety precautions, including the following:
1. Use this appliance only for its intended purpose as described in this instruction manual.
2. This Wine Cellar must be properly installed in accordance with the installation instruc-
tions before it is used. See grounding instructions in the Installation section.
3. This model can be built in or free-standing. Built-in units vent at the bottom front, and
airflow at the front of this vent must be unimpeded. Allow clearances of at least 1/4”
at sides, 1/2” at rear and 1” at top.
4. If the unit is placed on a stand, the front surface of the door must be 3” or more back
from the edge of the stand in order to avoid accidental tipping of the appliance during
normal usage.
5. Never unplug the unit by pulling on the power cord. Always grip the plug firmly and
pull straight out from the outlet. Repair or replace any cord that is frayed. Do not use a
cord that shows cracks or abrasions along its length.
6. If the unit has a plug in the moisture channel on the floor of the unit, remove this plug
and allow the drain to remain clear at all times when in operation.
SAVE THESE I STRUCTIO S!
DA GER!
Avoid the risk of child entrapment. If product is not in use, remove the door so that small
children cannot get trapped inside.

TECH ICAL SPECIFICATIO S
Model umber: MCWC28
Capacity: 28 standard wine bottles
Electrical Input: 115VAC, 60Hz
Current Rating: 1.8A
Unit Dimensions: 14.6”W x 23”Dx33.5”H /
370.84mm W x 584.2mm D x 850.9 mm H
Unit weight: 77 lb/34.92kg
Please note: You can switch temperature display setting from degrees Fahrenheit to
degrees Celsius by pressing and holding the U button for 10 seconds. The tempera-
ture in degrees Fahrenheit or degrees Celsius will appear in the temperature display
window .
LOCATIO S OF PARTS

Remove the exterior and interior packaging. Use a soft dry cloth to wipe down the
outside of the wine cellar thoroughly. Use a clean cloth dampened with lukewarm
water to wipe down the inside of the cellar.
The cellar should be located in a well-ventilated area. Avoid placing it near any
source of heat or moisture, or in direct sunlight. Direct sunlight may affect the finish,
and nearby heat sources will cause higher electrical consumption.
The wine cellar is designed to be either built-in or free-standing. A motorized fan at
the bottom of the unit directs compressor-generated heat away from the compres-
sor and through the vents at the front of the unit. If the unit is built-in, allow minimum
clearances of ¼ ” at the sides, ½” at the back and 1” at the top. Airflow from the
vents at the front of the unit must be unimpeded.
Once the wine cellar is positioned, the adjustable legs should be turned to level the
appliance. This will reduce vibrations.
Electrical Connection
Important! For your personal safety, this appliance must be properly grounded. In the
event of an electrical short circuit, grounding reduces the risk of shock by providing
an escape wire for the electric current. This appliance is equipped with a cord hav-
ing a grounding wire with a grounding plug. The plug must be inserted into an outlet
that is properly grounded and installed. Consult a qualified electrician if you do not
completely understand these grounding instructions.
DO OT U DER A Y CIRCUMSTA CES CUT OR REMOVE THE THIRD (GROU D) PRO G
FROM THE POWER CORD.
Use of an Extension Cord
Avoid the use of an extension cord because of potential safety hazards under cer-
tain conditions.
I STALLATIO

OPERATI G YOUR WI E CELLAR
IMPORTA T: Do not plug in the wine cellar for 24 hours after unit is set in place. Failure
to do so may result in the unit working improperly.
lug in the wine cellar to turn it on automatically. (After the unit has been on for
about 6 hours, the compressor will shut down for thirty minutes to allow for automatic
defrosting.)
If you want to use the Automatic Temperature (default) setting, do nothing further.
The unit will automatically set the temperature in the compartment at 55° F (13° C). If
you want to set another temperature, see below.
Temperature Setting
Wine Storage Temperatures: While wines store best at temperatures around 56-58° F,
your unit also allows you to store wine at drinking temperatures. Generally, RED WINE
should be kept at 60-62° F and WHITE WINE, which is usually served chilled, should be
kept at 54-55° F. Sparkling wines should be kept at about 46° F.
To adjust the temperature, press the SET button, then use the keys to navigate to the
preferred temperature. The range of set temperatures is from 46 to 64° F. For exam-
ple, if you are storing red wine, you may want to set a temperature of 61° F. When the
correct temperature appears in the display window of the control panel, press SET
again to confirm. The actual temperature inside the unit will now appear in the win-
dow. This temperature will vary depending on the number of bottles stored and how
frequently the door is opened.
If the temperature of the room is over 80° F, set the unit temperature between 50°
and 55° F to avoid overheating the compressor. If room temperature is between 64°
and 80° F, set the unit temperature in the range of 46° to 60° F.
PLEASE OTE: Cold air falls and warmer air rises, and there will be a temperature vari-
ation from the bottom to the top of the unit. The temperature sensor is located near
the center of the wine storage compartment and records the temperature in that
vicinity. The temperature at the bottom of the unit will always be slightly colder. Red
wines do best near the top of the wine cellar, while white and sparkling wines thrive in
the cooler temperatures of the lower racks.
To temporarily stop the cooling cycle, unplug the wine cellar. To shut it down for
longer periods of time, disconnect the plug and leave the door partially open.
OTE: If you unplug the wine cellar, allow 3 minutes before plugging back in. The unit
will not restart in less than 3 minutes.

Memorized Temperature Setting
The unit has been designed to “remember” the last run mode to which it was set. If
there is a power outage or any other power cutoff, the unit will automatically return
to the previous temperature setting after power is returned.
Compressor Run Indicator
The compressor is running when the unit displays a moving icon representing a run-
ning fan. If the compressor stops running, the icon will stop moving as well.
About the Liquid Crystal Display (LCD)
When you press any button on the control panel, a backlight will appear in the dis-
play. If no other button is pressed, the backlight will automatically go out after 2 min-
utes.
ALARM Mode
In the event that there is a fault in the unit, an ALARM indication will appear on the
screen.
In ALARM mode, the unit will make a beeping sound and display an alarm message.
If the LCD on the control panel displays any of the following messages: ROBE
ERROR, LOW TEM or HIGH TEM , consult the Wine Cellar Troubleshooting section of
this manual.
Interior Light
The interior light can be operated manually by pressing the ON/OFF button on the
control panel. The light will automatically turn off after 5 minutes.
NOTE: Avoid overuse of the interior light since the heat generated can raise the tem-
perature of the stored wine.
Shelving
The wine racks in your unit are chrome-plated so they will not rust. These racks pull out
only 1/3 of the way. This is a safety feature so that neither the machine nor the rack
will tip over.
The five upper racks are designed to hold five bottles each, with alternating bottles
on each rack pointing in opposite directions. These racks are removable and re-
versible. To remove a rack, take out the bottles on the rack and pull it out until it
stops. Then lift up the front of the rack and remove it from the unit.
The lowermost shelf is tilted and can hold three bottles. It is designed for storage as
well as for display.
OPERATI G YOUR WI E CELLAR

CLEA I G & MAI TE A CE
Cleaning the Outside
Clean the outside of your unit with mild soapy water. Dry thoroughly with a soft cloth.
To clean the door gasket, use only mild soapy water. Never use harsh cleansers or
scouring pads to clean any part of your wine cellar.
Cleaning the Inside
Unplug your wine cellar and remove all bottles. Wipe the inner surfaces with a soft,
clean cloth dampened with plain water. Dry the chrome trays. Avoid getting excess
water inside the machine since it will flow into the water trap near the compressor
and possibly overflow.
Defrosting the Cellar
The cellar uses an automatic defrost system in which the refrigerated surfaces of the
wine cellar defrost automatically. Defrost water drains into a hole in the floor of the
wine storage compartment and is channeled into a drain pan located at the back
of the cellar near the compressor. Heat transferred from the compressor evaporates
any water that has collected in the pan. Be sure the drain hole in the floor of the
wine cellar is clear and unobstructed.
Changing the Light Bulb
The bulb can be replaced with any standard U-shaped, 2-pin compact fluorescent
bulb of 5, 7 or 9 watts. Follow steps A through D in the diagram to remove the old bulb:
Do not use any unusual force to remove the old bulb. No tools should be necessary.
Follow steps E through H to install the new bulb:

Cellar does not turn on
Not plugged in. Fuse blown or circuit breaker tripped.
oise or vibration
Check that unit is level. If not, adjust leveling legs.
Cellar is too warm
Check that door is properly closed and sealed. Check temperature setting. (To
change the temperature setting, follow the steps in the Operating Your Wine Cellar
section of this manual.) Check if door has been opened frequently.
LCD displays “PROBE ERROR - E”
This message is an ALARM MODE indication. The LCD displays “ ROBE ERROR” on the
left and “E” in the middle when the thermostatic sensor has malfunctioned. When this
happens, the cellar first stops working for 15 minutes, then turns ON for 5 minutes and
OFF for 15 minutes automatically and continuously. Contact your authorized service
facility for sensor replacement.
LCD displays “LOW TEMP”
This message is an ALARM MODE indication. The LCD displays “LOW TEM ” on the left
and the actual temperature reading in the middle. It indicates that the actual tem-
perature is much lower than your set temperature and that the magnet valve may
not be functioning properly and should be replaced.
LCD displays “HIGH TEMP”
This message is an ALARM MODE indication. The LCD displays “HIGH TEM ” on the
left and the actual temperature reading in the middle. It indicates that the actual
temperature is much higher than your set temperature. ossible causes are:
NThe door might not be fully closed.
NRequires service.
NThe control panel may not be functioning properly and should be replaced. If you
are certain that the door is not the cause of the problem, contact your authorized
service facility immediately.
CELLAR TROUBLESHOOTI G
