Maxxon Cayman II Kayak User manual

1
OWNER’S MANUAL
Cayman II Kayak
Dear customer,
Congratulations on your purchase of the CAYMAN II kayak. We are proud to bring you a quality product with a bargain price and
excellent performance. Please take the time to read through this manual. It contains details of the kayak, its equipment, and
information on its operation and maintenance. Familiarize yourself with this inflatable before using it on the water in order to ensure
safety and to prevent accidents.
WARNING Indicates an imminently hazardous situation which, if not avoided, could result in death or serious injury or
property damage.
The CAYMAN II Kayak fulfills the requirements of EN ISO 6185-1 standard, TYPE Ⅲ.
The CAYMAN II Kayak is certified by the ISTITUTO GIORDANO S.p.A. in Italy.

2
WARNING
There is a risk of serious injury or death from drowning. Paddle sports can be very dangerous and
physically demanding. The user of this product acknowledges, understands, and assumes the risks involved
in paddle sports. Observe the following safety standards and safe operating practices whenever using this
product.
• Always wear a approved personal flotation device.
• Wear kayak vests, which are not as low in the back as a marine PFD.
• Do not exceed maximum weight capacity. Regardless of the number of persons on board, the total weight
of persons and equipment must not exceed maximum weight capacity.
• Do not operate the kayak under the influence of drugs or alcohol.
• Wear a helmet when appropriate.
• Do not paddle alone.
• Children must be supervised by a responsible adult at all times.
• Dress appropriately for weather and marine conditions; cold water and cold weather can result in
hypothermia.
• Beware of offshore winds and currents as they can take you out to sea.
• Check weather forecasts and obtain local knowledge of the marine environment and weather conditions
prior to your voyage.
• Do not exceed your paddling ability; be aware of your limitations.
• Be aware of safe river water levels, tidal changes, currents, and obstacles in and above the water.
• Check your equipment prior to each use for signs of wear, leaks or failure.
• Tie a leash to your paddle when appropriate.
• Always inform someone of your paddling route, the time and place of your departure and your intended
time and place of arrival.
• Always carry identification.
• Do not paddle in flood conditions.
• Make sure you are able to exit the craft if necessary.
• Scout unfamiliar waters; portage where appropriate.
TECHNICAL SPECIFICATIONS
Model Length (cm) Width (cm) Weight (kg) Persons
Capacity Max. Load Capacity (kg)
CAYMAN II 335 95 15 2 200

3
DRAWING
1. Soft Handle
2. Bow Cover
3. D-Ring
4. Adjustable Seat
5. Paddle Holder
6. Zipper
7. Valve
8. Drain Plug
9. Skeg Base
10. D-Ring for Seat
11. Directional Strake
12. Stern Cover
ASSEMBLY INSTRUCTIONS / INFLATION / DEFLATION
Inflate your CAYMAN II with a pump from EVERGOING PRODUCTS (MAXXON) or any pump designed for inflatable boats, and
other low pressure inflatables. These types of pump will have a hose and adapters to fit the valves on this kayak.
Choose a smooth and clean surface to unfold your kayak.
1. Attach the skeg on the underside by folding the hull. First partially deflate the kayak. The skeg cannot be installed when the
kayak is fully inflated. The curvature of the skeg must be pointed towards the back end of the kayak.
2. Side tube & Bottom floor valve – please see drawing to the right:
Unscrew the valve cap(1). Screw the valve insert(2) onto its base(3) and (1) Valve cap
check that the valve cap stays accessible. Insert the pump hose end piece
and inflate it until you will reach the required pressure. After inflation tighten (2) Valve insert
the valve cap (clockwise). A slight air-leak before screwing the valve cap is
normal. Only the valve cap can ensure final AIR TIGHTNESS. (3) Valve base
To release air from bottom floor unscrew the valve insert(2) from the valve
base(3).
(3) Valve base
3. Max. air pressure : the correct pressure for this item is :
0,1 bar/ 1.45 PSI(= 100 mBar ). Do not exceed it.

4
WARNING
Any use of an air compressor may result in poor performance or damage to the kayak, and automatically
voids all warranties. If you leave your kayak exposed to the hot sun, check the pressure and deflate it
slightly. Otherwise the kayak may become over inflated and stretch the material. The ambient temperature
affects the tube’s internal pressure : a variation of 1°C/ 1.8°F causes a variation of the pressure in the tube of
+/- 4 mBar (.06 PSI)
REMOVABLE SKEG FOR CAYMAN II
It is recommended to use the removable skeg in deep water (lake, sea…) where it will allow you to move forward in a straight line.
Do not use it in shallow water or white water: the skeg would deteriorate the bottom of the kayak in shallow water and reduce the
maneuverability in white water. The kayak is equipped with moulded directional strakes to allow good performance without the
skeg.
ADJUSTABLE SEAT(S)
Your kayak is supplied with a (or several) adjustable seat(s), featuring a comfortable high backrest. The seat is held in place by the
Velcro strips on the underside and by webbing straps on the sides of the backrest. Place the seat(s) into the kayak, matching the
position of the Velcro strips on the floor. Attach the webbing straps from the sides of the backrest to the D-rings located inside the
kayak, on the side walls/chambers. Tighten the straps as needed for proper back support.
DRAIN PLUG
Your kayak has been designed with a drain system located on the underside of the kayak in the rear. It consists of a drain port with
a plug, for those of you who would like to use the kayak in calm waters and do not wish to get your bottom wet.
MAINTENANCE
1. To deflate the kayak, remove the valve cap from the valves in the kayak floor and kayak body.
2. Clean and check the kayak as well as all the accessories. Make sure the kayak is completely dry before putting it away.
3. Fold the 2 sides into the middle, then roll it up from the opposite end of the valves (so remaining air can escape from the
valves).
4. When storing your inflatable, keep it in a clean and dry place.
WARNING
Whenever you take your kayak out of the water and deflate it, allow time for it to air out and dry. Neither the
skin/hull or the inside chambers will suffer from water damage, but stagnant water could cause mildew and
foul odor.
HOW TO REPAIR SMALL PUNCTURES
Check that the tube is fully deflated and lies flat.
1. Prepare a round patch no less than 3 inches or 7 centimeters in diameter.
2. Clean the patch and the area surrounding the leak with Alcohol.
3. To contain excess glue, use masking tape to tape off the area around the patch.
4. Apply 3 thin, even coats of repair kit adhesive to both the surface of the kayak and the patch. Wait 5 minutes between each
coat.
5. After the 3rd coat, wait 10-15 minutes before applying the patch. Use a hand roller to apply the patch evenly. Pay special
attention to the edges.
6. Wait 24 hours before re-inflating.

5
WARNING
• Perform all of your repairs in a well-ventilated area.
• Avoid inhaling glue vapors.
• Avoid contact with the skin or the eyes.
• Keep all repair materials (glue, solvents, etc) away from the reach of children.
• The repairs on the welds must not be glued. Only the manufacturer of the kayak can perform repairs on
the welds themselves.
WARRANTY
EVERGOING PRODUCTS (MAXXON) warrants (legal warranty) to the original purchaser only, and from date of purchase, that the
product is free from defects. The warranty applies only when this product is used for normal recreational purposes. Check with your
local EVERGOING PRODUCTS (MAXXON) office for details on the length of this warranty, which varies for different countries. The
warranty does not cover any puncture, cut or abrasion sustained in normal use or damage from unreasonable uses or improper
storage. If any product is found to be defective, the owner may return it to the store where it was purchased along the original sales
receipt. After inspection of any product found defective, EVERGOING PRODUCTS (MAXXON) shall either repair or replace the
defective part or item as deemed necessary by EVERGOING PRODUCTS (MAXXON). EVERGOING PRODUCTS (MAXXON)
shall not be held liable for incidental and consequential damages. There are no warranties which extend beyond the description of
the face hereof. This warranty is in lieu of all other warranties. This warranty gives you specific legal rights and you may also have
other rights, which may vary, from country to country.
The main limitations to the application of this warranty are the following;
• The item must not be modified and/or fitted with a motor in excess of that allowed by the manufacturer or used in any activities
outside normal recreational use (such as races, rental, or commercial usage).
• Used in excess of the manufacturers recommended maximum load capacity.
• Pressure recommendations, assembly / disassembly and handling procedures must be strictly observed.
• The maintenance and the storage procedures must not be neglected.
• This warranty does not cover parts and accessories not supplied or recommended by the manufacturer or defects resulting from
the installation of such equipment on their products.
WARNING
ALL REPAIRS COVERED BY WARRANTY MUST BE PERFORMED BY EVERGOING PRODUCTS
(MAXXON)
This product is designed in accordance with standards for a specific use. Any modifications, transformations
or use of a motor horse power higher than that indicated by the manufacturer could result in serious risks
for the user and will void the warranty.

6
EVERGOING PRODUCTS GROUP
8803 S 218 ST
KENT, WA 98031
P/253-373-0166
F/253-373-0169
www.evergoing.net
