Maytag Commercial MHN33PD User manual

1
Table of Contents ..................................................................................................................................2
INSTALLATION INSTRUCTIONS
CommerCial Front-load Washer
W11294918A www.maytagcommerciallaundry.com
Model
MHN33PD
MHN33PN
MHN33PR

2
TABLE OF CONTENTS
WASHER SAFETY .................................................................................... 2
WASHER DISPOSAL................................................................................4
INSTALLATION REQUIREMENTS...........................................................5
Tools and Parts......................................................................................5
Options..................................................................................................5
Specications........................................................................................5
Location Requirements .........................................................................6
Drain System .........................................................................................6
Electrical Requirements.........................................................................7
INSTALLATION INSTRUCTIONS............................................................. 8
Remove Transport System.................................................................... 8
Connect the Inlet Hoses........................................................................8
Connect the Drain Hose........................................................................ 9
Secure the Drain Hose ........................................................................10
Level the Washer................................................................................. 10
Payment System Setup.......................................................................10
Complete Installation...........................................................................10
USER & SETUP INSTRUCTIONS ..........................................................11
General User Information ....................................................................11
Control Setup Procedures...................................................................11
Setup Codes ....................................................................................... 12
Washer Diagnostic Modes .................................................................. 15
WASHER CARE......................................................................................16
Cleaning Your Washer .........................................................................16
Water Inlet Hoses ................................................................................16
ASSISTANCE OR SERVICE...................................................................17
Accessories .........................................................................................17
WARRANTY............................................................................................ 18
WASHER SAFETY
Model Nomenclature
MHN - Maytag
33 - Model Type Number
PN - Electronic Control - Non-Pay
PD - Electronic Control - Coin Drop enabled
PR - Electronic Control - Card Ready
The washer shall be disconnected from its power source during service and when replacing parts. If the removal of plug is
foreseen, it shall be clearly indicated that the removal of the plug has to be such that an operator can check from any of the
points to which they have access that the plug remains removed.
If this is not possible, due to the construction of the washer or its installation, a disconnection with a locking system in the
isolated position shall be provided.

3
Under certain conditions, hydrogen gas may
be produced in a hot water system that has
not been used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot water system
has not been used for such a period, before using the
washer, turn on all hot water faucets and let the water
ow from each for several minutes. This will release
any accumulated hydrogen gas. As the gas is
ammable. do not smoke or use an open name during
this time.
Read all instructions before using the the washer.
Before the washer is removed from service or discarded,
remove the door or lid.
Do not install or store the washer where it will be exposed
to the weather.
Do not repair or replace any part of the washer or attempt
any servicing unless specically recommended in this
manual or in published user-repair instructions that you
understand and have the skills to carry out.
Do not wash or dry articles that have been previously cleaned
in, washed in, soaked in, or spotted with petrol, dry-cleaning
solvents. other ammable, or explosive substances as they
give off vapors that could ignite or explode.
Do not add gasoline, dry-cleaning solvents or other ammable,
or explosive solvents. other ammable, or explosive
substances as they give off vapors that could ignite or explode.
Do not allow children to play on or in the washer.
Close supervision of children is necessary when the washer is
used near children. Cleaning and user maintenance shall not
not be made by children without supervision. Children of less
than 3 years should be kept away unless continuously
supervised.
This appliance is intended, but not limited, to
be used in public areas.
This washer/dryer is not intended for use by persons
(including children) with reduced physical, sensory, or
mental capabilities, or lack of experience or knowledge,
unless they have been given supervision or instruction
concerning use of the dryer by a person responsibfe for
their safety.
Do not reach into the washer if the tub, agitator, or drum
is moving.
The appliance must be disconnected from its power source
during service and when replacing parts.
Do not tamper with controls.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent, or similarty qualied persons
in order to avoid a hazard.
Fabric softeners, or similar products, should be used as
specied by the fabric softener instructions.
WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by a utility.
Ventilation openings in the base shall not be obstructed by
a carpet or similar object.
The new hose-sets supplied with the appliance are to be
used. Old hose-sets should not be reused.
Only authorised spare parts shall be used in the event of
failure.
See “Electrical Requirements” section for earthing
instructions.

4
WASHER DISPOSAL
This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment
(WEEE).
By ensuring this product is disposed of correctly, you will help avoid potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or on the documents accompanying the product, indicates that this appliance may not be
treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical
and electronic equipment.
Disposal must be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please contact your local city ofce,
your household waste disposal service or the shop where you purchased the product.

5
Alternate Parts
Your installation may require additional parts. If you are
interested in purchasing one of the items listed here, contact
your authorized Maytag distributor.
If you have You will need to buy
Laundry tub or standpipe
taller than 2.4 m (96")
Sump pump system (if not already
available)
Overhead sewer Standard 76 L (20 gal.), 762 mm
(30") tall drain tub or utility sink and
sump pump (available from local
plumbing suppliers)
If you have You will need to buy
Floor drain Siphon break, Part Number
285834; additional drain hose,
Part Number 8318155; and
connector kit, Part Number 285835
Drain hose too short 1.2 m (4 ft) drain hose extension
kit, Part Number 285863
Options
Pedestal
You have the option of purchasing pedestals separately for this
washer. The pedestal will add to the total height of the washer.
Optional pedestal
Pedestal
Height
Approximate
height with washer
Color Part Number
73 mm (27⁄8") 1207 mm (47.5") White WHP0400VW
Tools and Parts
Gather the required tools and parts before starting installation.
The parts supplied are in the washer drum.
Tools needed for connecting the water inlet hoses
■Pliers (that open to
39.5 mm [19⁄16"])
■Flashlight (optional)
Tools needed for installation
■Open end wrenches 13 mm
(1/2") and 14 mm (9/16")
■TORX T20 Security
screwdriver
■6.3 mm (1/4") nut driver
Parts supplied
■Level
■Wood block
■Ruler or measuring tape
INSTALLATION REQUIREMENTS
A. U-shaped hose form
B. Water inlet hoses (2)
C. Inlet hose washers (4)
D. Transit bolt hole plug (4)
E. Removable tie strap
F. Drain hose
G. Hose clamp
TORX and T20 are trademarks of Acument Intellectual Properties, LLC.
AB
F
G
C
DE
Specications
These units are sold in multiple regions with different
requirements for measuring capacity. Below are a few
of the valid forms of measure posted on this product:
Dry Linen Capacity: A weight measure that reects a minimum
threshold for dry volume capacity that is needed for import tariff
purposes.
IEC Capacity: The capacity measure that represents the
maximum capacity of dry linens and textiles which the
manufacturer declares can be treated in a specic cycle.
Dry Linen Capacity
10.5 kg (23 lb)
IEC Capacity
8.5 kg (19 lb)
Sound Level
Lpa: 58 dB(A) (Kpa+/-10 dB(A))
Parts supplied for PD Models:
Service door lock cam
Parts supplied for PR Models:
Card reader bezel Screws (2)

6
Location Requirements
NOTE: This washer is intended to be used in public areas.
Selecting the proper location for your washer improves
performance and minimizes noise and possible washer “walk.”
Your washer can be installed under a custom counter, or in a
basement, laundry room, or recessed area. See “Drain System.”
Companion appliance location requirements should also be
considered. Proper installation is your responsibility.
You will need:
■A water heater set to deliver 49°C (120°F) water to the
washer.
■An earthed electrical outlet located within 1.8 m (6 ft.) of
where the power cord is attached to the back of the washer.
See “Electrical Requirements.”
■Hot and cold water taps located within 1.2 m (4 ft.) of
the hot and cold water ll valves and water pressure of
137.9–689.6 kPa (20–100 psi).
■A level oor with a maximum slope of 25 mm (1") under entire
washer. Installing the washer on soft oor surfaces, such as
carpets or surfaces with foam backing, is not recommended.
■A sturdy and solid oor to support the washer with a total
weight (water and load) of 180 kg (400 lbs).
Do not operate your washer in temperatures below 0°C (32°F).
Some water can remain in the washer and can cause damage
in low temperatures.
Installation clearances
■The location must be large enough to allow the washer
door to be fully opened.
■Additional spacing should be considered for ease of
installation and servicing. The door opens more than 90°
and is not reversible.
■Additional clearances might be required for wall, door, and
oor moldings.
■Additional spacing of 25 mm (1") on all sides of the washer
is recommended to reduce noise transfer.
■Companion appliance spacing should also be considered.
Washer Dimensions
1282 mm
961 mm
(501/2")
686 mm
(27")
(3713/16")
1134 mm
28
2813
13
/
⁄16
16
)
(445/8")
732 mm
732 mm
(
(")
A oor drain should be provided under the bulkhead.
Prefabricated bulkheads with electrical outlets, water inlet
lines, and drain facilities should be used only where local
codes permit.
Drain System
The washer can be installed using the standpipe drain system
(oor or wall), the laundry tub drain system, or the oor drain
system. Select the drain hose installation method you need.
See “Tools and Parts.”
Standpipe drain system – wall or oor (views A & B)
The standpipe drain requires a minimum diameter standpipe of
50 mm (2"). The minimum carry-away capacity can be no less
than 45.5 L (12 gal.) per minute per washer.
The top of the standpipe must be at least 762 mm (30") high and
no higher than 2.4 m (96") from the bottom of the washer.
Laundry tub drain system (View C)
The laundry tub needs a minimum 76 L (20 gal.) capacity. The top
of the laundry tub must be at least 762 mm (30") above the oor.
Floor drain system (View D)
The oor drain system requires a siphon break that may be
purchased separately. See “Tools and Parts.”
The siphon break must be a minimum of 710 mm (28") from
the bottom of the washer. Additional hoses might be needed.
Door is not reversible 762 mm
(30" min.)
710 mm
(28" min.)
CD
732 mm
(2813⁄16")
A
762 mm
(30" min.)
B

7
Electrical Requirements
■A 220–240 V, 60 Hz., fused electrical supply is required.
A time-delay 10–16 A fuse or circuit breaker is
recommended.
■This washer is equipped with a power supply cord having
a 3 prong earthed plug.
■To minimize possible shock hazard, the cord must be
plugged into a mating, 3 prong, earthing-type outlet, earthed
in accordance with local codes and ordinances. If a mating
outlet is not available, it is the personal responsibility and
obligation of the customer to have the properly earthed
outlet installed by a qualied electrician.
■If codes permit and a separate ground wire is used, it is
recommended that a qualied electrician determine that
the earth path is adequate.
■If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent, or a qualied person
to avoid a hazard.
■Do not earth to a gas pipe.
■Check with a qualied electrician if you are not sure
the washer is properly earthed.
■Do not have a fuse in the neutral or earth circuit.
■Philippines: Outlet must comply with Philippine National
Standard PNS 1572:1997 Annex A, 250V, 10/15A, 2-pole,
3-wire, grounding receptacle.
EARTHING INSTRUCTIONS
This washer must be earthed. In the event of a malfunction
or breakdown, earthing will reduce the risk of electric
shock by providing a path of least resistance for electric
current. This washer is equipped with a cord having an
equipment-earthing conductor and an earthing plug. The
plug must be plugged into an appropriate outlet that is
properly installed and earthed in accordance with all local
codes and ordinances.
WARNING: Improper connection of the equipment-
earthing conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in
doubt as to whether the appliance is properly earthed.
Do not modify the plug provided with the appliance – if it will
not fit the outlet, have a proper outlet installed by a qualified
electrician.
NOTE: Electrical safety standards: The manufacturer has
chosen compliance with IEC/EN.60335 standards as the most
appropriate for this product.
■Sound Pressure Level, Lpa: 58 dbA (uncertainty,
Kpa: +/-3.6 dbA)
Dangerous Voltage

8
INSTALLATION INSTRUCTIONS
Remove Transport System
WARNING
Excessive Weight Hazard
Use two or more people to move and install washer.
Failure to do so can result in back or other injury.
Max. packed weight:
PD model: 115 kg (253.53 lb)
PN/PR model: 111 kg (244.71 lb)
Max. unpacked weight:
PD model: 111 kg (244.71 lb)
PN/PR model: 107 kg (235.89 lb)
IMPORTANT: Position the washer so that the rear of the washer
is within approximately 900 mm (3 ft.) of its nal location.
There are 4 shipping bolts in the rear panel of the washer that
support the suspension system during transportation. These bolts
also retain the power cord inside the washer until the bolts are
removed.
1. Keep the washer in the upright position while removing the
shipping bolts.
Shipping bolt
2. Using a 13 mm (1/2") wrench, loosen each of the bolts.
3. Once the bolt is loose, move it to the center of the hole
and completely pull out the bolt, including the plastic spacer
covering the bolt.
4. Once all 4 bolts are removed, discard the bolts and spacers.
Then push the plug back into the back of the washer and pull
the power cord through the left opening of the rear panel and
close the hole with the attached cap.
5. Close the bolt holes with the 4 transport bolt hole plugs.
NOTE: If the washer is to be transported at a later date, call your
product distributor or installer. To avoid suspension and structural
damage, your washer must be properly set up for relocation by a
trained professional.
Connect the Inlet Hoses
Insert new at washers (supplied) into each end of the inlet
hoses. Firmly seat the washers in the couplings.
NOTE: Use new hoses supplied with the washer. Do not reuse
old hoses.
A B
A. Coupling
B. Washer
Connect the inlet hoses to water faucets
Make sure the washer drum is empty.
1. Attach a hose to the hot water faucet. Screw on coupling
by hand until it is seated on the washer.
2. Attach a hose to the cold water faucet. Screw on coupling
by hand until it is seated on the washer.
3. Using pliers, tighten the couplings with an additional
two-thirds turn.
NOTE: Do not overtighten, use tape, or sealants on the valve.
Damage to the valves can result.
Shipping bolt with plastic spacer

9
Clear water lines
■Run water through both faucets and inlet hoses, into a
laundry tub, drainpipe, or bucket, to get rid of particles
in the water lines that might clog the inlet valve screens.
■Check the temperature of the water to make sure that the
hot water hose is connected to the hot water faucet and
that the cold water hose is connected to the cold water
faucet.
Connect the inlet hoses to the washer
C. Cold water inlet
H. Hot water inlet
1. Attach the hot water hose to the check valve on washer’s
hot (H) water inlet valve. Screw on coupling by hand until
it is seated on the check valve.
2. Attach the cold water hose to the check valve on washer’s
cold (C) water inlet valve. Screw on coupling by hand until
it is seated on the check valve.
3. Using pliers, tighten the couplings with an additional
two-thirds turn.
NOTE: Do not overtighten. Damage to the coupling can result.
4. Turn on the water taps completely and check for leaks.
NOTE: Replace inlet hoses after 5 years of use to reduce the risk
of hose failure. Record hose installation or replacement dates on
the hoses for future reference.
Periodically inspect and replace hoses if bulges, kinks, cuts,
wear, or leaks are found.
Connect the Drain Hose
Remove drain hose from washer drum
1. Use locking pliers, squeeze hose clamp tabs together and
insert over the end of drain hose.
2. Slide drain hose onto washer connection.
3. Once drain hose is in place, release pliers.
Washer drain system can be installed using a oor drain, wall
standpipe, oor standpipe, or laundry tub.
Laundry tub drain or standpipe drain
Connect the drain hose form to the corrugated drain hose.

10
To keep drain water from going back into the washer:
■Use the drain hose form, and do not force excess drain hose
into standpipe. Hose should be secure, but loose enough to
provide a gap for air.
■Do not lay excess hose on the bottom of the laundry tub.
Floor drain
You may need additional parts. See Floor drain under “Tools
and Parts.”
Secure the Drain Hose
Drain hose must be secured to stop the hose from moving when
water is pumped out. If the drain hose moves, water may end up
on the oor.
1. Drape the power cord over the washer top.
2. Move the washer to its nal location.
3. Place the drain hose in the laundry tub or standpipe as shown.
See illustrations A and B.
NOTES:
■Do not force excess drain hose back into the rear of the
washer.
■To avoid siphoning, do not seal or put more than
114 mm (4½") of the drain hose into drainpipe or standpipe.
■It is the responsibility of the installer to install and secure the
drain hose into the provided plumbing/drain in a manner that
will avoid the drain hose coming out of, or leaking from, the
plumbing/drain.
Level the Washer
Properly leveling your washer avoids excessive noise and
vibration.
1. Check the levelness of the washer by placing a level on the
top edge of the washer, rst side to side, then front to back.
If the washer is against a wall, move the washer out slightly
before tipping back. If the washer is not level, rst prop the
front with a wood block and adjust the feet as necessary.
To adjust feet, use a 14 mm or 9/16" open-end or adjustable
wrench to turn jam nuts clockwise (as viewed from above) on
feet until they are about 13 mm (1/2") from the washer cabinet.
Then turn the leveling foot counterclockwise to lower the
washer or clockwise to raise the washer. Recheck levelness of
washer and that all four feet are rmly in contact with the oor.
Repeat as needed.
2. Make sure all four feet are stable and resting on the oor.
Then check that the washer is perfectly level (use a level).
3. When washer is level and all four feet are rmly in contact
with the oor, use a 14 mm or 9/16" open-end or adjustable
wrench to turn jam nuts counterclockwise (as viewed from
above) on leveling feet tightly against washer cabinet.
IMPORTANT: All four feet must be tightened. If the nuts are
not tight against the washer cabinet, the washer may vibrate.
4. The washer should not move front to back, side to side,
or diagonally when pushed on its top edges.
5. Slide the washer to its nal location.
6. Conrm the levelness of the washer.
Payment System Setup
PD Model Washer is coin payment ready and allows the use of
two different sizes of coins if a dual drop is installed. To set up
the washer for coin payment, acquire a coin drop mechanism
with the appropriate coin sensors. Connect coin sensors to
coin slots 1 and 2, respectively.
Complete Installation
1. Check the electrical requirements. Be sure that you have
the correct electrical supply and the recommended earthing
method. See “Electrical Requirements.”
2. Check that all parts are now installed. If there is an extra part,
go back through the steps to see which step was skipped.
3. Check that you have all of your tools.
4. Dispose of/recycle all packaging materials.
5. Check that the water taps are on.
6. Check for leaks around taps and inlet hoses.
7. Plug into an earthed socket outlet.
8. To test and to clean your washer, measure 1/2 the detergent
manufacturer’s recommended amount for a medium-size load.
Pour the detergent into the detergent dispenser. Select any
cycle and allow the washer to complete one whole cycle.
41/2"
(114 mm)
41/2"
(114 mm)
114 mm
(41/2")
114 mm
(41/2")
B
A
Jam nut

11
1. Door must be closed before cycle selection is made.
2. Press fabric setting keypad for the wash cycle desired. After
the cycle is started, the time will display and count down.
General User Information
Scrolling ‘out of order’ showing in display, followed
by a failure code
This condition indicates the washer is inoperative.
‘0 Minutes’ showing in display
This condition indicates the washer cannot be operated. Coins
dropped or debit inputs during this condition will be stored in
escrow but cannot be used until normal operation is restored
by opening and closing the door. If a door switch fails, it must
be replaced before normal operation can be restored.
Cold Start (Initial rst use)
Washer is programmed at the factory as follows:
11-minute wash period
3 rinses (extra rinse not enabled)
7 x coin 1 wash price (PD models)
Warm Start (after power failure)
A few seconds after power is restored, if a cycle was in progress
at the time of the power failure, ‘RESELECT CYCLE’ will ash
in the display, indicating the need for a key pad press to restart
washer.
Door Lock
The door will be locked when the cycle starts. The door
will remain locked until the end of a cycle or approximately
2 minutes after a power interruption.
Pricing
After the door is opened following the completion of a cycle, the
display indicates the cycle price (unless set for free operation).
As coins are dropped or debit inputs arrive, the display will
change to lead the user through the initiation of a cycle.
Free Cycles
This is established by setting the cycle price to zero. When this
happens, ‘SELECT CYCLE’ will appear rather than a cycle price.
Display
After the washer has been installed and plugged in, the display
will show “0 MINUTES.” Once the washer has been plugged in
and the washer door opened and closed, the display will show
the price. In washers set for free cycles, the display will ash
“SELECT CYCLE.”
Control Set-Up Procedures
IMPORTANT: Read all instructions before operating.
■PD Models: Insert access door key, turn, and lift to remove
access door.
Set-up procedures can be entered by using the Service Access
Code (see Service Access Code section) for PN/PR washers set
up without a key switch installed.
The washer is now in the set-up mode. The lower fabric setting
key pads and the digital display are used to set up the controls.
The display can contain 4 numbers and/or letters and a decimal
point. These are used to indicate the set-up codes and related
code values available for use in programming the washer.
Once the washer has been programmed with a hand-held device
using Accu Trac, or a Gen. 2 card reader has been installed, the
washer will be put into dAS mode permanently, and dAS will be
displayed every time set-up mode is accessed.
How to use the key pads to program controls
1. The Brights key pad is used to adjust the values
associated with set-up codes. Pressing this key pad will
change the value by increments. Rapid adjustment is
possible by holding the key pad down.
2. The Delicates and Knits key pad advances you through
the set-up codes. Pressing this key pad will advance you
to the next available set-up code. Holding the key pad down
will automatically advance through the set-up codes at a rate
of 1 per second.
NOTE: Not displayed on washer as shown. Message scrolls
followed by the failure code.
USER & SETUP INSTRUCTIONS

12
3. The Quick Cycle key pad is used to select or deselect
options.
Start Operating Setup
NOTE: Prior to operation, a payment system or an OPL kit must
be installed on PD models as part of the setup.
Before proceeding, it is worth noting that, despite all of the
options available, an owner can simply choose to uncrate a new
commercial washer, hook it up, plug it in, and have a washer
that operates. Washers are preset at the factory for an 11-minute
wash period and 3 rinses (no extra rinse).
Setup Codes
■The Delicates and Knits key pad will advance you from code
to code.
■The Brights key pad will change the code value.
■The Quick Cycle key pad will select or deselect options.
FOR PN/PR MODELS: The set-up codes are the same as for the
“PD” model except where noted.
The set-up code is indicated by the 1 or 2 left-hand characters.
The set-up code value is indicated by the 2 or 3 right-hand
characters. The rst code shown in each section is the Factory
Default setting.
CODE EXPLANATION
6 07 REGULAR CYCLE PRICE (Factory Default)
6
6
07
00
g
Represents the number of coins (Coin 1) needed
to start the washer; may adjust from 0–39. (See
VALUE OF COIN 1.) Advance from 0–39 by
pressing BRIGHTS key pad. Factory default
of 7 x coin 1.
With coin slide activation, this code represents
the number of push-in actuations of a coin slide
to start the washer.
6 01 setting would represent one coin slide
actuation.
NOTE: For coin slide activation, replacement
of the meter case is necessary.
PN/PR MODELS ONLY: Factory default of 0 coins.
Press the DELICATES AND KNITS key pad once
to advance to next code.
7 11 WASH LENGTH
7 11
g
This is the number of minutes for Wash. Washer
comes from the factory preset with 11 minutes.
Choose from 9–17 minutes by pressing the
BRIGHTS key pad.
Press the DELICATES AND KNITS key pad once
to advance to next code.
NOTE: This option does not apply to Quick Cycle.
8 00 ADDITIONAL RINSE OPTION
This option is either SELECTED ‘ON’ or NOT
SELECTED ‘OFF’.
8
8
00
Ar
g
Not Selected ‘OFF’.
Selected ‘ON’. Cannot be combined with the
Super Cycle rinse option.
Press the QUICK CYCLE key pad once for this
selection.
Press the DELICATES AND KNITS key pad once
to advance to next code.
CODE EXPLANATION
9 00 CYCLE COUNTER OPTION
This option is either SELECTED ‘ON’ or NOT
SELECTED ‘OFF’.
9
9
00
0C
g
Not Selected ‘OFF’.
Selected ‘ON’ and not able to be deselected.
Press the QUICK CYCLE key pad 3 consecutive
times to select ‘ON’. Once selected ‘ON’ it cannot
be deselected.
Press the DELICATES AND KNITS key pad once
to advance to next code.
1. 00 MONEY COUNTER OPTION
This option is either SELECTED ‘ON’ or NOT
SELECTED ‘OFF’.
1.
1.
1.
00
0C
g
C0
Not Selected ‘OFF’.
Selected ‘ON’.
Press the QUICK CYCLE key pad 3 consecutive
times to select ‘ON’ and 3 consecutive times to
remove (Not Selected ‘OFF’.) Counter resets by
going from ‘OFF’ to ‘ON’.
Press the DELICATES AND KNITS key pad once
to advance to next code.
Selected ‘ON’ and not able to be deselected.
To select ‘ON’ and not able to be deselected,
rst select ‘ON’, then within 2 seconds, press
the QUICK CYCLE key pad twice, BRIGHTS once,
and exit the set-up mode.
2. 00 SPECIAL PRICING OPTIONS
This option is either SELECTED ‘ON’ or NOT
SELECTED ‘OFF’.
2.
2.
00
SP
Not Selected ‘OFF’, and next available code will
be A.00.
Selected ‘ON’. Press the QUICK CYCLE key pad
once for this selection.
If SPECIAL PRICING OPTION is selected, there is access
to codes ‘3.XX’ through ‘9.XX’.
g Press the DELICATES AND KNITS key pad once to
advance to next code.
Options to use if SPECIAL PRICING is selected:
3. 07 SPECIAL CYCLE PRICE
3.
3.
07
00
g
Represents the number of coins (coin 1) needed
to start the washer; may adjust from 0–39. (See
VALUE OF COIN 1.) Advance from 0–39 by
pressing the BRIGHTS key pad. Factory default
of 7 x coin 1.
PN/PR MODELS ONLY: Factory default of 0 coins.
Press the DELICATES AND KNITS key pad once
to advance to next code.
5. 00 TIME-OF-DAY CLOCK, MINUTES
5. 00
g
This is the Time-of-Day Clock, minute setting;
select 0–59 minutes by pressing the BRIGHTS
key pad.
Press the DELICATES AND KNITS key pad once
to advance to next code.
6. 00 TIME-OF-DAY CLOCK, HOURS
NOTE: Uses the 24-hr. clock
6. 00
g
This is the Time-of-Day ClockK, hour setting;
select 0–23 hours by pressing the BRIGHTS
key pad.
Press the DELICATES AND KNITS key pad once
to advance to next code.

13
CODE EXPLANATION
7. 00 SPECIAL PRICE START HOUR
NOTE: Uses the 24-hr. clock
7. 00
g
This is the start hour; 0–23 hours. Select Start
Hour by pressing the BRIGHTS key pad.
Press the DELICATES AND KNITS key pad once
to advance to next code.
8. 00 SPECIAL PRICE STOP HOUR
NOTE: Uses the 24-hr. clock
8. 00
g
This is the stop hour; 0–23 hours. Select Stop
Hour by pressing the BRIGHTS key pad.
Press the DELICATES AND KNITS key pad once
to advance to next code.
9. 10 SPECIAL PRICE DAY
9. 10
g
This represents the day of the week and whether
special pricing is selected for that day. A number
followed by ‘0’ indicates no selection that
particular day (9.10). A number followed by an ‘S’
indicates selected for that day (9.1S). To change
the value of ‘0’ and ‘S’, use the QUICK CYCLE
key pad.
Days of the week (1–7) are selected by pressing
the BRIGHTS key pad.
When exiting setup code ‘9’, the display must
show current day of week:
DISPLAY DAY OF WEEK CODE (selected)
10 Day 1 = Sunday 1S
20 Day 2 = Monday 2S
30 Day 3 = Tuesday 3S
40 Day 4 = Wednesday 4S
50 Day 5 = Thursday 5S
60 Day 6 = Friday 6S
70 Day 7 = Saturday 7S
Press the DELICATES AND KNITS key pad once
to advance to next code.
A. 00 VAULT VIEWING OPTION
This option is either SELECTED ‘ON’ or NOT
SELECTED ‘OFF’.
A.
A.
00
SC
g
Not Selected ‘OFF’.
Selected ‘ON’. Press the QUICK CYCLE key pad
once for this selection. When selected, the money
and/or cycle counts will be viewable (if counting is
selected) when the coin box is removed.
Press the DELICATES AND KNITS key pad once
to advance to next code.
b. 05 VALUE OF COIN 1
b. 05
g
This represents the value of coin 1 in the quantity
of 5% increments of the larger coin value. 5 x
5%=25%.
By pressing the BRIGHTS key pad, there is
the option of 1–199 for the quantity of 5%
increments.
With coin slide activation, this represents the total
vend price.
NOTE: For coin slide activation, replacement
of the meter case is necessary.
Press the DELICATES AND KNITS key pad once
to advance to next code.
CODE EXPLANATION
C. 20 VALUE OF COIN 2
C.
C.
20
05
g
This represents the value of coin 2 in the quantity
of 5% increments of the larger coin value. 20 x
5%=100%.
By pressing the BRIGHTS key pad, there is
the option of 1–199 for the quantity of 5%
increments.
PN/PR MODELS: This represents the value of
coin 2 in the quantity of 5% increments of the
larger coin value. Factory default = 5 x 5% of the
larger coin value.
Press the DELICATES AND KNITS key pad once
to advance to next code.
d. 00 COIN SLIDE OPTION
This option is either SELECTED ‘ON’ or NOT
SELECTED ‘OFF’.
d.
d.
00
CS
g
Not Selected ‘OFF’. Used with coin drop or card
readers.
Selected ‘ON’. Press the QUICK CYCLE key pad
3 consecutive times for this selection.
NOTE: This option needs to be set to “00” unless
the meter case has been changed to accept a
coin slide device.
When coin slide mode is selected ‘On’, set b.
equal to value of vend price. Set setup code
6 (regular cycle price) and setup code 3 (special
cycle price) to number of slide pushes. If washer
is set up as “CS” and a coin drop is installed, it
will not register coins.
NOTE: For coin slide activation, replacement
of the meter case is necessary.
Press the DELICATES AND KNITS key pad once
to advance to next code.
E. 00 ADD COINS OPTION
This option is either SELECTED ‘ON’ or NOT
SELECTED ‘OFF’. This option causes the
customer display to show the number of coins
(coin 1) to enter, rather than the amount.
E.
E.
00
AC
g
Not Selected ‘OFF’.
Selected ‘ON’. Press the QUICK CYCLE key pad
3 consecutive times for this selection.
Press the DELICATES AND KNITS key pad once
to advance to next code.
F. 00 ENHANCED PRICING OPTION
F.
F.
F.
00
CP
Su
g
Not Selected ‘OFF’.
Cycle-Based pricing enabled. This option allows
conguration of different prices for cold, warm,
and hot water cycles.
Super Cycle pricing enabled. This option allows
customers to upgrade cycles by depositing
extra money. Setup codes “H.” and “h.” will
be displayed only when this option is enabled.
Press the QUICK CYCLE key pad once for this
selection.
Press the DELICATES AND KNITS key pad once
to advance to next code.
H. 01 SUPER CYCLE UPGRADE PRICE
(Skipped unless super cycle pricing is enabled.)
H. 01
g
This represents the number of coin 1 required to
upgrade a base cycle to a super cycle. Advance
from 0–39 by pressing the BRIGHTS key pad.
Press the DELICATES AND KNITS key pad once
to advance to next code.

14
CODE EXPLANATION
A1. 00 PREWASH LENGTH
A1. 00
g
This is the number of minutes of Prewash.Choose
0 to disable the prewash or select between 2 and
7 minutes by pressing the BRIGHTS key pad.
Press the DELICATES AND KNITS key pad once
to advance to next code.
A2. 03 FINAL SPIN LENGTH
A2. 03
g
This is the number of minutes of nal high-speed
spin. Choose from 3–8 minutes by pressing the
BRIGHTS key pad.
Press the DELICATES AND KNITS key pad once
to advance to next code.
If cycle counter (9 0C) is selected, the following is true:
1 00 Number of cycles in HUNDREDS. 1 02 = 200
2 00 Number of cycles in ONES. 2 25 = 25
TOTAL CYCLES = 225
This is ‘VIEW ONLY’ and cannot be cleared.
g Press the DELICATES AND KNITS key pad once
to advance to next code.
If money counter (1.0C or 1.C0) is selected, the following
is true:
3 00 Currency amount in HUNDREDS. 3 01 = 100.00
4 00 Currency amount in ONES. 4 68 = 68.00
5 00 Currency amount in HUNDREDTHS. 5 75 = 00.75
TOTAL = 168.75
END OF SETUP PROCEDURES
EXIT FROM SETUP MODE
■PD Models: Reinstall access door.
■PN/PR Models:
– Unplug washer or disconnect power.
– Open console, reinsert plug into AA1, close console.
– Plug in washer or reconnect power.
■PN/PR MODELS WITH PROGRAMMING SWITCH:
Turn key clockwise and remove.
■PN/PR MODELS SET UP WITHOUT PROGRAMMING
SWITCH: Setup mode can be exited by using procedures
from Service Access Code (Below).
SERVICE ACCESS CODE
This code can be entered to access service mode without
removing the console. It only functions on washers set up for 0
vend price without any Special Pricing setup, and the Coin/Debit
Option must be set to “J._d”. If the washer is not in failure mode,
the door must be opened to proceed.
To enter the Service Access Code, press these key pads
in the following order: 1–upper left, 2–lower right, 3–upper right,
4–lower left.
NOTE: If the Service Access Code procedure is not completed
properly, as noted above, there is a 15-second delay before it
can be attempted again.
There are 3 options to exit from the Service Mode:
1. Power down the washer; then reapply power.
2. Wait 2 minutes without touching any keypads (without
diagnostic modes running).
3. From Set-Up Code 8, press key pad #1 for 4 seconds.
CODE EXPLANATION
h. 01 SUPER CYCLE TYPE
(Skipped unless Super Cycle pricing is enabled.)
h. 01
g
This represents the Super Cycle upgrade option.
Press the BRIGHTS key pad to step through
upgrade options 1–3 as follows:
01 – enhanced wash, extra 3 minutes of wash
tumble in addition to the programmed wash time.
02 – extra rinse for all cycles.
03 – both 01 and 02.
Press the DELICATES AND KNITS key pad once
to advance to next code.
J. Cd COIN/DEBIT OPTION
J.
J.
J.
J.
Cd
C_
_d
Ed
g
Both coin & debit selected. Press the QUICK
CYCLE key pad 3 consecutive times to change
this selection.
Coins selected, debit disabled. Press the QUICK
CYCLE key pad 3 consecutive times to change
this selection.
Debit card selected, coins disabled. This is the
factory default for PN/PR models. Press the
QUICK CYCLE key pad 3 consecutive times to
change this selection.
Enhanced Debit is self-selected when a
Generation 2 card reader is installed in the
washer. The Ed option cannot be manually
selected or deselected.
Press the DELICATES AND KNITS key pad once
to advance to next code.
L. 00 PRICE SUPPRESSION OPTION
This option causes the customer display to show
‘ADD’ or ‘AVAILABLE’ rather than the amount of
money to add. (Used mainly in debit installations.)
L.
L.
00
PS
g
Not Selected ‘OFF.’
Selected ‘ON.’ Press the QUICK CYCLE key pad
once for this selection.
Press the DELICATES AND KNITS key pad once
to advance to next code.
n. CE CLEAR ESCROW OPTION
When selected, money held in escrow for
30 minutes without further escrow or cycle
activity will be cleared.
00
CE
g
Not Selected ‘OFF’.
Selected ‘ON’. Press the QUICK CYCLE key pad
once for this selection.
Press the DELICATES AND KNITS key pad once
to advance to next code.
r. 800 TOP SPIN SPEED RPM
r. 800
g
This can be selected from the following spin
speeds: 600 rpm, 750 rpm, 800 rpm, 1000
(displays as 999) rpm. Step between speeds by
pressing the BRIGHTS key pad. Factory pre-set
for 800 rpm.
Press the DELICATES AND KNITS key pad once
to advance to next code.
U. 00 PENNY INCREMENT OFFSET
U. 00
g
This option is not supported for European Models
and the value must be set to 00.
Press the DELICATES AND KNITS key pad once
to advance to next code.

15
Washer Diagnostic Modes
To enter the “Washer Diagnostic Mode,” rst enter “Start
Operating Setup.” Then press and hold the QUICK CYCLE key
pad for 1 second while in set-up code 6, anytime a diagnostic
code is present, or while dAS displays if operating with Maytag
Data Acquisition setup.
On entry to diagnostic mode the entire display will ash,
a cycle in process is canceled, money in escrow is cleared,
and diagnostic codes are cleared. If a diagnostic code persists,
it must be corrected before the following cycle options are
permitted.
There are ve possible ways to initiate cycle activity from
diagnostic mode as follows:
1. Washer Cleanout cycle – With the entire display ashing,
this cycle is started by pressing the STOP/PAUSE key pad.
Use the Washer Cleanout cycle once a month to keep
the inside of your washer fresh and clean. This cycle uses
a higher water level. Use with liquid chlorine bleach to
thoroughly clean the inside of the washer. This cycle
should not be interrupted.
IMPORTANT: Do not place garments or other items in the
washer during the Washer Cleanout cycle. Use this cycle with
an empty wash drum.
2. Cycle Credit – With the entire display ashing, a cycle may
be credited by pressing the BRIGHTS key pad (CC will dis-
play). When the service mode is exited, “SELECT CYCLE”
will be displayed unless the end-of-cycle door opening is
required.
3. Manual Overview Test – With the entire display ashing, this
cycle is started by pressing the WHITES key pad. This cycle
provides more typical full length lls, tumbles, drains, and
dispenser actuator movement, allowing for a more thorough
analysis of the washer operation, including pressure switch
behavior.
4. Quick Spin Cycle – With the entire display ashing, this
cycle is started by pressing the COLORS key pad. This cycle
provides a method to quickly drain and spin (remove water
from the washer) if desired.
5. Quick Overview Test – With the entire display ashing,
this cycle is started by pressing the DELICATES AND KNITS
key pad. This cycle provides a quick verication that the
cold and hot water valves, dispensers, and pump motor
are working, as well as dispenser actuator movement.
It also includes door lock, drain, and spin operations.
Pressing the QUICK CYCLE key pad will exit diagnostic mode
and cancel a diagnostic cycle in process.
DIAGNOSTIC CODES
If one of the following has occurred, the appropriate diagnostic
code will be in the display.
d5 Blocked coin 1 or coin drop control circuit failure (coin
recognition and price display disabled while blockage
persists).
PN/PR Models Only: Setup mode J. should be set
to _d to eliminate coin related diagnostic codes.
d9 Low voltage detected for 8 seconds.
d13 Blocked coin 2 or coin drop control circuit failure (coin
recognition and price display disabled while blockage
persists).
F20 Slow Fill. The washer will not detect water input for 4 min.
Pressure switch failure or no water inlet. This code is
reported as d8 on d7.
F22 The door is not able to lock. Door lock error or someone
trying to start the washer, by pressing the door switch
with the nger. This code is reported as d17 on Accu Trac.
(For any other codes, check supplied Technical Sheet.)
SERVICE ACCESS CODE
This code can be entered to access service mode without
removing the console. It only functions on washers set up for 0
vend price without any Special Pricing setup, and the Coin/Debit
Option must be set to “J._d”. If the washer is not in failure mode,
the door must be opened to proceed.
To enter the Service Access Code, press these keypads
in the following order: 1 – upper left, 2 – lower right, 3 – upper
right, 4 – lower left.
NOTE: If the Service Access Code procedure is not completed
properly, as noted above, there is a 15-second delay before it can
be attempted again.
There are 3 options to exit from the Service Mode:
1. Power down the washer; then reapply power.
2. Wait 2 minutes without touching any key pads (without
diagnostic modes running).
3. From Set-Up Code 8, press key pad #1 for 4 seconds.
WASHER HELP MODE
This mode is entered by pressing the BRIGHTS key pad while
in special pricing option mode 2.XX (or while dAS displays
if operating with Maytag Data Acquisition setup).
In help mode, other display symbols and elements are mapped
to reect the state of various inputs and outputs as follows:
Display Symbol Description
Wash Water sensed at wash level.
* Low voltage present (below about
90 VAC).
° (Circle above digit) Door closed.
DOOR LOCKED Door sensed locked.
COLD Cold water relay on.
HOT Hot water relay on.
OR Door unlocked.
AVAILABLE Drain pump on.
NOTE: A Technical Sheet is taped to inside of lower front panel,
which includes fault codes and a washer schematic diagram.

16
Cleaning Your Washer
Cleaning the Door Seal/Bellow
1. Open the washer door and remove any clothing or items from
the washer.
2. Inspect the colored seal/bellow between the door opening
and the drum for stained areas. Pull back the seal/bellow
to inspect all areas under the seal/bellow and to check for
foreign objects.
A
A. Seal/Bellow
3. If stained areas are found, wipe down these areas of the seal/
bellow, using the procedure that follows.
a) Mix a dilute solution, using 177 mL (3/4 cup) of liquid
chlorine bleach, and 3.8 L (1 gal. ) of warm tap water.
b) Wipe the seal/bellow area with the dilute solution,
using a damp cloth.
c) Let stand 5 minutes.
d) Wipe down area thoroughly with a dry cloth and let
the washer interior air dry with door open.
IMPORTANT:
■Wear rubber gloves when cleaning for prolonged periods.
■Refer to the bleach manufacturer’s instructions for proper use.
Washer Maintenance Procedure
This washer has a special cycle that uses higher water volumes
in combination with liquid chlorine bleach to thoroughly clean
the inside of the washer.
NOTES:
■Read these instructions completely before beginning the
cleaning process.
■If necessary, the cleaning cycle may be interrupted
by pressing the QUICK CYCLE key pad twice. However,
this will not immediately stop the cycle. The washer will
continue with several rinse and drain steps to ensure that
all remaining bleach is rinsed from the washer.
Begin procedure
1. Open the washer door and remove any clothing or items from
the washer.
2. Use liquid chlorine bleach:
Open the dispenser drawer and immediately add
160 mL (2/3 cup) of liquid chlorine bleach to the bleach
compartment.
NOTE: Do not add any detergent to this cycle. Use of more
than 160 mL (2/3 cup) of bleach will cause product damage
over time.
3. Close the washer door and the dispenser drawer.
4. To start the Clean Washer cycle, rst enter “Start
Operating Setup.” Then press and hold QUICK CYCLE
for 1 second. With the entire display ashing, press
STOP/PAUSE.
NOTE: The door will lock and the drum will rotate; then the
door will unlock, lock again, and the cycle will continue.
■The washer will not ll, but the drum will rotate while
the washer runs a short sensing cycle. This will take
approximately 3 minutes.
5. The cycle will determine whether clothing or other items are
in the washer.
a) If no items are detected in the washer, it will proceed
to Step 7.
b) If any items are detected in the washer, “rL” or “F-34”
will be displayed. Then the door will unlock.
■Press QUICK CYCLE to cancel the failure code.
Then repeat steps 1, 3, and 4 to start the cycle again.
6. Once the cycle has begun, allow the cycle to complete.
7. After the cycle is complete, leave the door open slightly,
to allow for better ventilation and drying of washer interior.
Always do the following to maintain washer freshness:
■Use only “HE” High Efciency detergent.
■Leave the door slightly open after each cycle to allow
for better ventilation and drying of washer interior.
■Clean the washer monthly using the Washer Maintenance
Procedure, and 160 mL (2/3 cup) of liquid chlorine bleach.
■If the procedure does not sufciently improve the washer
freshness, please evaluate your installation and usage
conditions for other causes.
Cleaning the Exterior
Use a soft, damp cloth or sponge to wipe up any spills.
Occasionally wipe the outside of your washer to keep it looking
new. Use mild soap and water. Do not use abrasive products.
Cleaning the Dispenser Drawer
The dispenser drawer is removable for easy cleaning.
1. Unlock the dispenser drawer by pressing the Release Lever.
Remove the drawer.
2. Remove the inserts (the siphon from the softener and bleach
compartments).
3. Wash the parts under running water.
NOTE: Do not wash components in the dishwasher.
4. Replace the inserts and return the dispenser to the drawer.
Water Inlet Hoses
Replace water inlet hoses after 5 years of use to reduce the risk
of hose failure. Periodically inspect and replace water inlet hoses
if bulges, kinks, cuts, wear, or leaks are found.
When replacing your water inlet hoses, mark the date
of replacement on the label with a permanent marker.
WASHER CARE

17
ASSISTANCE OR SERVICE
Direct all requests for service to the Maytag Commercial Laundry
Distributor that sold the appliance.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us to better respond to your request.
Accessories
Enhance your washer with these premium accessories.
For more high-quality items or to order, contact your authorized
Maytag distributor.
Part Number Accessory
8212526 Washer drip tray, ts under all
31682 All-purpose appliance cleaner
1903WH Laundry supply storage cart
285320 Anti Siphon
Whirlpool Corporation, Benton Harbor, Michigan 49022, USA.
Manufacturer site: Whirlpool Corporation, 119 Birdseye St., Clyde, OH 43410.

18
MAYTAG COMMERCIAL LAUNDRY LIMITED WARRANTY
MHN33PD, MHN33PN, MHN33PR
The cost of repair or replacement under these excluded circumstances
shall be borne by the customer.
1. All other costs including labor, transportation, shipping, or custom duties
for covered parts.
2. Factory specified replacement parts if this commercial appliance is
used for other than normal, commercial use or when it is used in a manner
that is inconsistent to published user or operator instructions and/or
installation instructions.
3. Service calls to correct the installation of your commercial appliance,
to instruct you on how to use your commercial appliance, to replace
or repair house fuses, or to correct external wiring or plumbing.
4. Service calls to repair or replace appliance light bulbs, air filters, or water
filters. Consumable parts are excluded from warranty coverage.
5. Damage resulting from improper handling of product during delivery,
theft, accident, alteration, misuse, abuse, fire, flood, acts of God,
improper installation, installation not in accordance with local electrical
or plumbing codes, or use of products not approved by Maytag.
6. Pick up and delivery. This commercial appliance is designed to be
repaired on location.
7. Repairs to parts or systems resulting from unauthorized modifications
made to the commercial appliance.
8. The removal and reinstallation of your commercial appliance if it is
installed in an inaccessible location or is not installed in accordance
with published installation instructions.
9. Damage resulting from exposure to chemicals.
10. Changes to the building, room, or location needed in order to make the
commercial appliance operate correctly.
11. Factory specified replacement parts on commercial appliances with
original model/serial numbers that have been removed, altered, or cannot
be easily determined.
12. Discoloration, rust, or oxidation of stainless steel surfaces.
13. Factory specified replacement parts as a result of incorrect diagnosis
or repair by an “unauthorized” service company.
14. Replacement parts during the sixth through seventh years from the date
of original purchase where the commercial appliance is installed, operated
and maintained in a setting other than a vended and/or multi-housing
environment.
15. Replacement parts during the sixth through seventh years from the
date of original purchase where the defective part is not preventing the
functioning of the product.
DISCLAIMER OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO FIVE YEARS OR THE SHORTEST PERIOD ALLOWED BY LAW. Some locations may not allow
limitations on the duration of implied warranties of merchantability or fitness, so this limitation may not apply to you. This warranty gives
you specific legal rights, and you also may have other rights that vary.
LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.
MAYTAG SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some locations do not allow the exclusion or limitation
of incidental or consequential damages, so these limitations and exclusions may not apply to you. This warranty gives you specific legal rights,
and you also may have other rights that vary by location.
03/17
DISCLAIMER OF REPRESENTATIONS OUTSIDE OF WARRANTY
Maytag makes no representations about the quality, durability, or need for service or repair of this major appliance other than the
representations contained in this Warranty. If you want a longer or more comprehensive warranty than the limited warranty that comes
with this major appliance, you should ask your retailer about buying an extended warranty. The benefits to you given by this warranty
are in addition to other rights and remedies available to you under a law in relation to the goods or service to which this warranty relates.
Please contact Maytag for further information on warranty terms.
SEVEN YEAR LIMITED WARRANTY
For written correspondence:
Maytag Commercial Laundry Service Department
2000 N M 63
Benton Harbor, Michigan 49022-2632 USA
WHAT IS COVERED
IF YOU NEED SERVICE:
Contact your authorized Maytag Commercial Laundry distributor. To locate your authorized Maytag Commercial Laundry distributor,
visit www.MaytagCommercialLaundry.com.
WHAT IS NOT COVERED
FIVE YEAR LIMITED WARRANTY
(PARTS ONLY — LABOR NOT INCLUDED)
For the first five years from the original date of purchase,
when this commercial appliance is installed, maintained,
and operated according to the instructions attached to
or furnished with the product, Maytag brand of Whirlpool
Corporation (hereafter “Maytag”) will pay for factory
specified replacement parts to correct defects in materials
or workmanship that existed when this commercial appliance
was purchased. This limited warranty does not include labor.
SIXTH THROUGH SEVENTH YEAR LIMITED WARRANTY
(CERTAIN COMPONENT PARTS ONLY –
LABOR NOT INCLUDED)
In the sixth through seventh years from the date of original
purchase, when this commercial appliance is installed,
operated, and maintained in a vended and/or multi-housing
environment ONLY according to instructions attached to
or furnished with the product, Maytag will pay for factory
specified replacement parts for the following components to
correct non-cosmetic defects in materials or workmanship
in the part that prevent functioning of the product and that
existed when this commercial appliance was purchased.
This is a limited 7-year warranty on the below named parts
only and does not include labor.
Drive Bearings, Tub Seal, Bearing Spacer, Hub, Cross Piece,
Drum, Rear Tub, Front Tub, Drum Shaft
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS
LIMITED WARRANTY SHALL BE PART REPLACEMENT AS
PROVIDED HEREIN. Maytag recommends that you use an
“authorized” service provider to diagnose and repair your
Commercial Laundry product. Maytag will not be responsible
under this warranty to provide additional replacement parts as
a result of incorrect diagnosis or repair by an “unauthorized”
service company. Except in the European Union, this limited
warranty is valid only when the commercial appliance is used
in the country in which it was purchased. This limited warranty
is effective from the date of the original consumer purchase.
Proof of original purchase date is required to obtain service
under this limited warranty.

19
NOTES

W11294918A 11/18
©2018 All rights reserved.
