Maytag MDB9601AWS - Jetclean III Dishwasher Manual

Repair
Parts
List
MODEL NUMBER
MDB9601AWS
When requesting service or ordering parts, always
provide the following information:
- Product Type - Part Number
- Model Number - Part Description
DISHWASHER
©2005 Maytag Services

Section: CONTROL PANEL
DW11-85
Model: MDB9601AWS
1

CONTROL PANEL
No. Part No. Description
Section:
Series Qty
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, PANEL 10 4
1 99003385 PANEL, CONTROL (BLK) 10 1
2 99003222 VENT SEAL, CONTROL PANEL 10 1
3 99002577 HANDLE, LATCH (BLK) 10 1
4 99002751 SWITCH, DOOR 10 2
5 99003347 LATCH ASSEMBLY 10 1
6 99002576 HOUSING, BOARD (BASE) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 10 2
7 99003432 BOARD, CONTROL 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 10 1
8 99002575 HOUSING, BOARD (TOP) 10 1
- 99003537 HARNESS, WIRE 10 1
2
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: DOOR
DW12-91
Model: MDB9601AWS
3

DOOR
No. Part No. Description
Section:
Series Qty
1 99003534 PANEL, DECO W/SOUND (SNLS) 10 1
2 99002673 VENT HOUSING ASSEMBLY 10 1
4 99002929 BRACKET, HINGE (LT) 16 1
- 99001075 SCREW Note: SCREW, BRACKET 10 4
4 99002930 BRACKET, HINGE (RT) 16 1
5 Y99002587 INSULATION, DOOR 10 1
6 903233 FOAM STRIP, INSULATION 10 1
7 99003540 DOOR LINER, SECONDARY 10 1
- 99003541 BRACKET, SECONDARY DOOR LINER 10 2
- 99003482 FOAM STRIP (SHORT) 10 1
- 99003481 FOAM STRIP (LONG) 10 1
- Y912620 SCREW Note: SCREW, DOOR 10 11
8 99002970 DOOR, INNER (W/DAMPER) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, BRACKET 10 6
9 99003316 BRACKET, DISPENSER MOUNTING 10 1
10 99002270 SEAL, BASE 10 1
11 99003317 RINSE AID/DETERGENT DISPENSER 10 1
12 99002614 KNOB, RINSE AID (W/O-RING) 10 1
13 99002186 SEAL, DOOR VENT 10 1
14 99002590 BEZEL, DOOR VENT 10 1
4
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TRACK & RACK ASSEMBLY (UPR)
DW15-151
Model: MDB9601AWS
5

TRACK & RACK ASSEMBLY (UPR)
No. Part No. Description
Section:
Series Qty
1 99003019 RACK ASSEMBLY (UPR) 10 1
- 99002905 CAP, RACK (DARK GRAY) 10 1
2 99002712 VARILOCK (REAR) 10 1
3 99002714 CUP, VARILOCK 10 1
4 99002715 SPRING, VARILOCK 10 1
5 99002713 SUPPORT, VARILOCK 10 1
6 99002711 VARILOCK (FRT) 10 1
- 99002623 STOP, RACK (GRAY) 10 4
7 99002621 TRACK, RACK 10 2
8 99002620 BASKET, AUXILLARY (BLUE) 10 1
- 99002343 SHAFT, TUB WHEEL 10 8
9 99002622 WHEEL, TUB 10 8
- Y912798 WASHER, TUB WHEEL 10 8
10 99002624 ARM, WASH (UPR) 10 1
- 99002740 SCREW, TRUSS HEAD (10-18X.75) Note: SCREW, WASH ARM 10 1
11 99002669 CLIP, UPR WASH MANIFOLD (FRT) 10 1
12 99002945 CLIP, UPR WASH MANIFOLD (BACK) 10 1
13 99002679 WASH MANIFOLD ASSY (UPR) 10 1
14 99002709 PIVOT, FOLD AWAY TINE 10 2
15 99003485 TINE, FOLDING (DK GREY) 10 2
16 99003484 CLIP, FOLDING TINE (BLUE) 10 1
17 99002671 SHELF, CUP (UPR) 10 2
18 99003011 COVER, RACK ADJUSTER (GRAY) 10 2
19 99003020 STABILIZER, RACK ADJUSTER 10 1
20 99003178 LEVER, ADJUSTER (BLUE) 10 2
21 99003585 RACK ADJUSTER ASSY (RT) 10 1
- 99003010 SCREW (T15) 8-18 X .500 Note: SCREW, RACK ADJUSTER 10 11
- 99003584 RACK ADJUSTER ASSY (LT) 10 1
22 99002696 CLIP, CUP (BLUE) 10 3
6
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TRACK & RACK ASSEMBLY (MIDDLE/LWR)
DW15-152
Model: MDB9601AWS
7

TRACK & RACK ASSEMBLY (MIDDLE/LWR)
No. Part No. Description
Section:
Series Qty
- 99002905 CAP, RACK (DARK GRAY) 10 1
1 99003627 RACK ASSEMBLY,MIDDLE (DK GRY) Note: FOLDING TINES NOT INCLUDED 10 1
2 99003640 FOLDING TINE ASY,MID REAR DK G 10 2
3 99003639 FOLDING TINE ASY,MID FRT DK G 10 2
- 99003584 RACK ADJUSTER ASSY (LT) 10 1
4 99003585 RACK ADJUSTER ASSY (RT) 23 1
- 99003010 SCREW (T15) 8-18 X .500 Note: SCREW, RACK ADJUSTER 23 11
5 99003011 COVER, RACK ADJUSTER (GRAY) 23 2
6 99003020 STABILIZER, RACK ADJUSTER 23 1
7 99002621 TRACK, RACK 10 2
- 99002623 STOP, RACK (GRAY) 10 4
8 99002622 WHEEL, TUB 10 8
- 99002343 SHAFT, TUB WHEEL 10 8
- Y912798 WASHER, TUB WHEEL 10 8
- 99002740 SCREW, TRUSS HEAD (10-18X.75) Note: SCREW, WASH ARM 10 1
9 99002739 ARM, WASH (MIDDLE) 10 1
10 99002732 CLIP, MIDDLE MANIFOLD (FRT) 10 1
11 99002758 CLIP, MIDDLE MANIFOLD (BACK) 10 1
12 99002793 WASH MANIFOLD ASSY (MIDDLE) 10 1
13 99003178 LEVER, ADJUSTER (BLUE) 23 2
14 99002748 BASKET, UTILITY 10 1
- 99002731 COVER, SPLIT/FIT BASKET 10 2
- 99002730 BASKET, SPLIT/FIT Note: BASKET, SPLIT/FIT HALF 10 2
15 99002729 SPLIT/FIT BASKET ASSEMBLY 10 1
- 99002905 CAP, RACK (DARK GRAY) 10 1
16 99002962 PAN RACK ASSEMBLY 17 1
17 99002780 WHEEL ASSEMBLY (LWR) 10 8
8
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TUB
DW13-117
Model: MDB9601AWS
9

TUB
No. Part No. Description
Section:
Series Qty
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
1 99002629 BRACKET, WATER VALVE 10 1
2 99002975 VALVE, WATER 10 1
- 99002553 SCREW-#8X7/16 HEX WASHER HEAD Note: SCREW, VALVE 10 2
3 911856 CLAMP, SPRING 10 1
4 99002852 HOSE, INJECTOR 10 1
- N 99002954 FELT, AIR/WATER INLET Note: (APPLY TO PLASTIC TUB BELOW AIR WATER INLET) 10 1
- N 99002955 FOAM BLOCK, AIR/WATER INLET Note: (APPLY TO PLASTIC TUB BELOW AIR WATER INLET) 10 1
5 99002645 INLET, AIR/WATER 10 1
- 99002867 FOAM INSERT, AIR/WATER INLET 10 2
- 99002646 SEAL, AIR/WATER INLET 10 1
- 99002948 COVER, AIR/WATER INLET 10 1
6 99002588 SEAL, DOOR 10 1
7 99002648 BRACKET, CABINET MOUNTING 10 2
- 912366 SCREW --++*** Note: SCREW, PANEL (BLK) 10 2
- 99002694 SOUND SEAL, TOE PANEL (BLK) 10 1
8 99002765 PANEL, TOE (W/DAMPER-BLK) 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 4
9 99002610 BRACKET, SPRING ADJUSTMENT 10 2
10 99002598 SPRING, DOOR 10 2
11 99003446 DOOR CABLE ASSEMBLY 10 2
12 99002859 SUPPORT, FRONT (W/SEALS)(BLK) 10 1
- 912366 SCREW --++*** Note: SCREW, SUPPORT (BLK) 10 2
- 99002701 GAP SEAL, TOE KICK (BLK) 10 1
- 99002928 SUPPORT, HINGE (LT) 10 1
13 99002927 SUPPORT, HINGE (RT) 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, SUPPORT 10 4
14 99003127 INSULATION, TUB 10 1
- 99002640 FASTENER, INSULATION 10 2
15 99002608 ROLLER, CABLE BRACKET 10 2
16 99002609 SHOULDER BOLT, CABLE BRACKET 10 2
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 4
17 99002607 BRACKET, CABLE 10 2
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
18 99002637 BRACKET, JUNCTION BOX SUPPORT 10 1
19 99002635 LEG, LEVELING 10 4
20 99002638 COVER, JUNCTION BOX 10 1
- 912365 SCREW Note: SCREW, COVER 10 1
21 99002630 FLOAT 10 1
22 99002631 SWITCH, FLOAT 10 1
23 99002632 PLATE, SWITCH MOUNTING 10 1
- 99002749 SCREW, STEEL HEX HD PLASITE Note: SCREW, PLATE 10 1
25 99002634 CLIP, THERMOSTAT 10 1
26 99002633 THERMOSTAT, LIMITING 10 1
27 99002636 BRACKET, SUPPORT (LT) 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
- 99002973 GASKET, HEATER 18 2
28 99002625 HEATER 10 1
28 99002971 HEATER (W/GASKET) 18 1
29 99002626 BRACKET, HEATER SUPPORT 10 2
- Y913079 O-RING, HEATER 10 2
30 99002972 NUT, HEATER 10 2
31 99002723 STRIP, TRIM/MOUNTING (TOP) 10 1
32 99003451 TRIM STRIP (RIGHT) 10 1
32 99003450 TRIM STRIP (LEFT) 10 1
- 99002692 SCREW, TRIM MOUNTING 10 4
10
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WATER DISTRIBUTION ASSEMBLY
DW14-72
Model: MDB9601AWS
11

WATER DISTRIBUTION ASSEMBLY
No. Part No. Description
Section:
Series Qty
1 99002738 MANIFOLD, MAIN MULTI-LEVEL 10 1
2 99002643 BRACKET, MANIFOLD MOUNTING 10 2
3 99002674 STATION, DOCKING (W/FLAPPER) 10 2
4 99002676 WASH ARM, TOP (W/RETAINER) 10 1
5 99002753 RETAINER, TOP WASH ARM 10 1
12
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: PUMP & MOTOR
DW14-81
Model: MDB9601AWS
13

PUMP & MOTOR
No. Part No. Description
Section:
Series Qty
1 99002654 CAP, WASH ARM 10 1
2 99002678 WASH ARM, LOWER (W/SHIELDS) 10 1
3 99002653 SHIELD, RADIANT 10 2
- 99002666 SCREW Note: SCREW, GUARD 10 3
4 99002979 GUARD, FILTER (GRAY) 10 1
5 99002677 DISCHARGE HOUSING ASSY (UPR) 10 1
- 99002664 SCREW, DISCHARGE HOUSING 10 6
6 99002741 WASH IMPELLER ASSEMBLY 10 1
- 99002660 SCREW, IMPELLER 10 1
7 99003291 ASSY., FILTER/FLOWPLATE 10 1
- 99002668 SCREW, STAINLESS PAN HEAD Note: SCREW, FILTER/FLOWPLATE 10 3
8 99003427 CHOPPER 10 1
9 99003341 SEAL KIT, METAL CHOPPER SLEEVE 10 1
10 99003430 WASH MOTOR ASSY SEAL NOT INCL Note: SEAL KIT NOT INCLUDED. ORDER SEAL KIT
SEPARATELY. 10 1
11 99002650 SENSOR, TURBIDITY 10 1
- 33002917 SCREW, #10-16 Note: SCREW, SENSOR 10 2
- 99002651 O-RING, TURBIDITY SENSOR 10 1
12 99002663 GASKET, PUMP 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, CAPACITOR 10 1
- 99003440 SHIELD, CAPACITOR 10 1
13 99002665 CAPACITOR, MOTOR 10 1
14 99002750 DRAIN PUMP ASSEMBLY 10 1
- 99002815 FLAPPER, DRAIN PUMP VALVE 10 1
15 99003309 FLAPPER, DRAIN PUMP INLET 10 1
16 99002857 O-RING, DRAIN PUMP 10 1
17 99002752 BRKT, DRAIN PUMP (W/GROMMET) 10 1
- 99002657 SCREW, DRAIN PUMP MOUNTING 10 1
- 99002656 CLAMP, DRAIN HOSE (1-3/8") 10 1
18 99002652 HOSE, DRAIN 10 1
14
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

SUPPLEMENTAL INFORMATION
No. Part No. Description
Section:
Series Qty
- Y6920183 MANUAL, USE & CARE 10 1
- 16021814 TALL TUB SERVICE MANUAL 10 1
- 16026946 TECH SHT, DISHWASHER 10 1
- 99003349 GUIDE, ENERGY (REV C) 10 1
- 99002854 MISC. PARTS PACKAGE 10 1
- DAX3200AXE TRIM STRIP KIT (WHT) 10 1
- DAX3090AXB WOOD PANEL KIT (BLK) 10 1
- DAX3090AXW WOOD PANEL KIT (WHT) 10 1
15
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WIRING INFORMATION
99003526
Model: MDB9601AWS
16
