AUTOMATIC DRYER INSTALLATION INSTRUCTIONS
MISE EN SERVICE SI_CHEUSE AUTOMATIQUE
INSTRUCCIONES DE INSTALACION DE LA SECADORA AUTOMATICA
The installation, including a proper exhaust system,
is the responsibility of the owner.
La responsabilit_ de la mise en service, y compris le syst_me
d'_vacuation qui convient, revient au propri_taire.
Es responsabilidad del propietario la instalaci6n correcta,
incluso la del sistema de escape.
LEAVE THESE INSTRUCTIONS WITH THE OWNER
REMETTRE CES INSTRUCTIONS AU PROPRIF: TAIRE
DEJE ESTAS INSTRUCCIONES CON EL PROPIETARIO
Printed in U.S.A., Printed in U.S.A.. Impreso en los Estados Unidos. Stampato negli Stati Uniti 6 3901250

Read this before you start...
Tools needed for installation
• Teflon tape or pipe
joint compound (gas only)
• Cutting knife
• Pipe wrench (gas only)
• Nut drivers
• Level
• Screw driver (standard)
• Duct tape
° Crescent wrench
ITEMS PROVIDED
@@
@
Electric Dryer
Only
@@
@
Gas Dryer
Only
Proper installation is the responsibility of the owner.
HOWEVER, SERVICE CALLS PERFORMED AS A RESULT OF POOR SET-UP, ADJUSTMENT AND CON-
NECTION ARE THE RESPONSIBILITY OF THE INSTALLER.
Make sure you have everything necessary for proper installation.
1. GROUNDED ELECTRICAL OUTLET is required. See Electric Requirements.
2. POWER CORD for electric dryers (except Canada).
3. GAS LINES (if a gas dryer) must meet National and Local Codes.
4. EXHAUST SYSTEM - must be rigid metal or flexible stiff walled metal exhaust ducting. See Exhaust Requirements.
36 1/4"
(9,2,1cm)
minimum
1
1 1/2"
(3.81 cm)
3/4"
(1.9 cm)
IMPORTANT TO INSTALLER
PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY BEFORE STARTING TO INSTALL THE
DRYER. THESE INSTRUCTIONS SHOULD BE RETAINED FOR FUTURE REFERENCE.
REMOVE THE DOOR FROM ALL DISCARDED APPLIANCES SUCH AS DRYERS TO AVOID THE
DANGER OF A CHILD SUFFOCATING.
Page 1

LOCATION CONSIDERATIONS
The dryer should be located to permit adequate room in front for loading the dryer, and sufficient room behind
the dryer for the exhaust system.
This dryer is factory-ready for rear exhaust. To exhaust out the bottom or left side, use the accessory exhaust
kit (see Accessories). Instructions are included with the kit.
It is important to make sure the room has adequate make-up air. The area where the dryer is located must not
obstruct the flow of combustion or ventilating air.
On gas dryers, adequate clearance as noted on the data plate must be maintained to insure adequate air for
combustion and proper operation of the dryer.
THE DRYER MUST NOT BE INSTALLED OR STORED IN AN AREA WHERE IT WILL BE EXPOSED TO
WATER AND/OR WEATHER. THE DRYER AREA IS TO BE KEPT CLEAR AND FREE FROM
COMBUSTIBLE MATERIALS, GASOLINE AND OTHER FLAMMABLE VAPORS AND LIQUIDS. A DRYER
PRODUCES COMBUSTIBLE LINT. THE AREAAROUND THE DRYER SHOULD BE KEPT FREE OF LINT.
ALCOVE OR CLOSET INSTALLATION
An appliance installed in a closet shall
have no other fuel-burning appliance
installed in the same closet.
Each opening area in the door must
have a minimum of 36 square inches.
These openings must not be obstruct-
ed. (Louvered door with equivalent air
opening is acceptable.)
FRONT VIEW
CLOSET DOOR
i(7.6cm) (91.4cm)
36 '+
_ 2" (5.1 crn) _ ................................. (91.4 cm)
3" (7.6 cm)
SIDE VIEW
_I,WARNING WARNING-
The dryer must
be exhausted to
the outside to
reduce the risk
of fire when
installed in an alcove or closet.
Minimum installation clearances. If possible, more clearance is recommended.
MOBILE HOME INSTALLATION
The installation of the dryer in mobile homes must conform to the Manufactured Home Construction and Safety
Standard Title 24 CFR, Part 32-80 {formerly the Federal standard for Mobile Home Construction and Safety, Title
24, HUD (Part 280), 1975} for the United States,) or CSA Standards Z240 (for Canada).
When installing a dryer in a mobile home, prowsions for anchoring the dryer to the floor must be made. An
anchor bracket kit is available with instructions (see Accessories). Locate in an area that has adequate make
up air. A minimum of 25 square inches (63.5 cm) of unobstructed opening is required.
All mobile home installations must be exhausted to the outside with the exhaust duct termination securely
fastened to the mobile home structure, using materials that will not support combustion. The exhaust duct
may not terminate beneath the mobile home. See the section on exhausting for more information.
EXHAUSTING
Exhausting the dryer to the outside will prevent large amounts of lint and moisture from being blown into the room.
In the United States:
• all gas dryers must be exhausted to the outside.
°electric dryers located in a confined area such as a bedroom, bathroom, or closet must be exhaust-
ed to the outside.
°electric dryers not located in a confined area may be exhausted to the inside (see nonexhausted
installations).
In Canada:
°all gas and electric dryers must be exhausted to the outside.
Outside the U.S. and Canada:
•refer to local codes.
Page 2

-&WARNING WARNING - plastic or nonmetal flexible duct presents a potential fire hazard.
NEVER USE PLASTIC OR NONMETAL FLEXIBLE DUCT.
If your existing ductwork is plastic, nonmetal or combustible, replace it with metal. Use only metal
exhaust duct that will not support combustion to insure the containment of exhaust air, heat and lint.
Plastic flexible duct can kink, sag, be punctured, reduce air
flow, extend drying times and affect dryer operation.
USE A MINIMUM OF 4-INCH (10.2 cm) DIAMETER
RIGID ALUMINUM OR RIGID GALVANIZED STEEL
DUCT. Do not use smaller duct. Ducts larger than
4 inches (10.2 cm) in diameter can result in increased
lint accumulation. Lint accumulation should be cleaned
regularly. If flexible metal duct must be used, use the
type with a stiff sheet metal wall. Do not use flexible
duct with a thin foil wall. Serious blockage can result if
flexible metal duct is bent too sharp. Never install any
type of flexible duct in walls, ceilings or other concealed
spaces.
Keep exhaust duct as straight and short as possible.
Exhaust systems longer than recommended can extend
drying times, affect machine operation and may collect
lint. Secure joints with duct tape. Do not use screws.
DO NOT EXHAUST DRYER INTO ANY WALL,
CEILING, CRAWL SPACE OR A CONCEALED
SPACE OF A BUILDING, GAS VENT, ANY OTHER
COMMON DUCT OR CHIMNEY. THIS COULD CRE-
ATE A FIRE HAZARD FROM LINT EXPELLED BY
THE DRYER.
Number
of
90 ° Turns
Exhaust Hood Type
I
4" (10.2 cm)
Maximum length of 4-inch
rigid metal duct
0 65 ft.(165.1 cm)
1 54 ft. (137.2 cm)
2 44 ft. (111.8 cm)
3 36 ft. (91.4 cm)
4 28 ft. (71.1 cm)
Maximum length of 4-inch
flexible stiff walled
1
2-1/2" ('6.4 cm_
(10.2 cm) diameter
59 ft. (149.9 cm)
48 ft. (121.9 cm)
38 ft. (96.5 cm)
30 ft. (76.2 cm)
22 ft. (55.9 cm)
(10.2 cm) diameter
metal duct
0
1
2
3
4
36 ft.
32 ft.
28 ft.
25 ft.
23 ft.
(91.4 cm) 28 ft.
(81.3 cm) 24 ft.
(71.1 cm) 20 ft.
(63.5 cm) 17 ft.
(58.4 cm) 15 ft.
(71.1 cm)
(60.9 cm)
(50.8 cm)
(43.2 cm)
(38.1 cm)
The exhaust duct should end with an exhaust hood with a swing out damper to prevent backdrafts and entry
of wildlife. Never use an exhaust hood with a magnetic damper. The hood should have at least 12 inches
(30.5 cm) of clearance between the bottom of the hood and the ground or other obstruction. The hood
opening should point down. Never install a screen over the exhaust outlet.
When possible, do not exhaust the dryer directly into a window well in order to avoid lint build-up. Do not
exhaust under a house or porch.
If exhaust ductwork must run through an unheated area, the duct should be insulated and slope slightly down
towards the exhaust hood to reduce condensation and lint build-up.
If an existing exhaust system is to be used with your new dryer, you must be sure:
• The exhaust system meets all local, state and national codes.
• That plastic flexible duct is not used.
• To completely inspect and clean all lint accumulation from the interior of the duct.
• The duct is not kinked or crushed.
• The exhaust hood damper opens and closes freely.
The static pressure in any exhaust system must not exceed 0.92 inches of water column, or be less than 0.
This can be measured with the dryer running with a manometer at the point where the exhaust duct connects
to the dryer. A no heat setting should be used. The dryer tumbler should be empty and the lint filter clean.
Page 3

Inspect and clean the interior or the exhaust system at least once a year. Disconnect electrical service prior
to cleaning. Check the gas line on gas dryers anytime the dryer is moved.
Frequently check to be sure the exhaust hood damper opens and closes freely.
NONEXHAUSTED INSTALLATIONS
If the electric dryer is not exhausted to the outside, the exhaust must not terminate directly behind the dryer.
Use a rectangular vent kit along with a dacron mesh lint bag (see Accessories). Maintain a 6" (15.2 cm)
clearance between the back of the control panel and the wall. Although the lint screen and lint bag will retain
most of the lint, a certain amount will be expelled into the laundry area.
WARNING: IF THE DRYER IS NOT EXHAUSTED TO THE OUTSIDE, SOME FINE LINT WILL BE
EXPELLED INTO THE LAUNDRY AREA. AN ACCUMULATION OF DUST OR LINT IN ANY AREA OF THE
HOME CREATES A FIRE HAZARD. ANY LINT ACCUMULATIONS MUST BE CLEANED FREQUENTLY.
GAS REQUIREMENTS
Use only Natural or LP (liquid propane) gases.
THE INSTALLATION MUST CONFORM WITH LOCAL CODES, OR IN THE ABSENCE OF LOCAL CODES,
WITH THE NATIONAL FUEL GAS CODE ANSI/Z223.1, LATEST REVISION (FOR THE UNITED STATES),
OR WITH THE CAN/CGA-B149 INSTALLATION CODES (FOR CANADA).
Gas dryers are equipped with a burner orifice for operation on NATURAL gas. If the dryer is to be operated
on LP (liquid propane) gas, it must be converted for safe and proper performance and must be
converted by a qualified service technician. Conversion kits from NATURAL to LP, or LP to NATURAL are
available through your local Maytag dealer (see Accessories). If other conversions are required, check with
the local gas utility for specific information concerning conversion requirements.
A 1/2" (1.27 cm) gas supply line is recommended and must be reduced to connect to the 3/8" (1.0 cm) gas line
on the dryer.
The National Fuel Gas Code requires that an accessible, approved manual gas shut off valve be installed
within 6 feet of the dryer.
Gas Dryers installed in residential garages must be elevated 18 inches (46 cm) above the floor.
Additionally, a 1/8" (.3 cm) N.P.T. (National Pipe Thread) plugged tapping, accessible for test gauge
connection, must be installed immediately upstream of the gas supply connection to the dryer.
The dryer must be disconnected from the gas supply piping system during any pressure testing of the system.
DO NOT re-use old flexible metal gas line. Flexible gas line must be design certified by American Gas
Association (CGA in Canada). NOTE: Any pipe joint compound used must be resistant to the action of any
liquefied petroleum gas.
NOTE: As a courtesy, most local gas utilities will inspect a gas appliance installation.
GAS IGNITION -
This dryer uses an automatic ignition system to ignite the burner. There is no constant burning pilot.
COMMONWEALTH OF MASSACHUSETTS
INSTALLATION INSTRUCTIONS
This gas dryer must be installed by a licensed
plumber or gas fitter
A "T" handle manual gas valve must be installed in
the gas supply line to this gas dryer.
If a flexible gas connector is used to install this gas
dryer, the connector must have a maximum length
of 3 feet. (36 inches)
Gas leaks may occur in your system and result in
a dangerous situation. Gas leaks may not be
detected by smell alone. Gas suppliers recom-
mend you purchase and install a UL approved
gas detector. Install and use in accordance with
the manufacturer's instructions.
Page 4

ELECTRICAL REQUIREMENTS
NOTE: Wiring diagram is located inside the control console.
Export models (not U.S. or Canada): See Additional Instructions for Export Models on the other side of this sheet.
I_I,WARNING] WARNING - To prevent unnecessary risk of fire, electrical shock or personal injury, all
wiring and grounding must be done in accordance with local codes, or in the
_ bsence of local codes, with the National Electrical Code, ANSI/NFPA (for the United
States) or the Canadian Electrical Code CSA C22.1 (for Canada).
GROUNDING
This dryer must be grounded. In the event of malfunction or breakdown, the ground will reduce the risk of
electrical shock by providing a path of least resistance for electrical current.
GAS MODELS
This appliance is equipped with a cord having an
equipment-grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet
that is properly installed and grounded in accordance
with all local codes and ordinances.
Do not modify the plug provided with the appliance - if
it will not fit the outlet, have a proper outlet installed by
a qualified electrician.
_'WARNING WARNING - Improper connection of
the equipment grounding conductor can
result in a risk of electric shock. Check
with a qualified electrician or serviceman
if you are in doubt as to whether the
appliance is properly grounded.
if a separate ground is required by local codes, a grounding kit (Part No. 12001875) is available. It contains
ground wire, clamp, ground screw and washer. Connect ground wire to back of unit with the cabinet ground
screw and washer. Secure other end of ground wire to a suitable external ground connection. The wire may
be secured with the clamp to a grounded COLD metal water pipe.
terminal block post to the frame of the dryer. If local codes prohibit the use of the
ground strap, the dryer must be grounded in accordance with local codes.
If a power cord is not used and the electric dryer is to be permanently wired,
the dryer must be connected to a grounded metal, permanent wiring system;
or an equipment grounding conductor must be run with the circuit conductors
and connected to the equipment grounding terminal.
NEVER CONNECT GROUND WIRE TO PLASTIC PLUMBING LINES, GAS LINES OR HOT WATER PIPES.
ELECTRIC MODELS 1_
U.S. electric models are shipped with a ground strap connected from the neutral
ELECTRICAL CONNECTIONS Ground
Screw
BEFORE OPERATING OR TESTING, follow all grounding instructions in Grounding Section.
An individual branch (or separate) circuit serving only this appliance is recommended. DO NOT USE AN
EXTENSION CORD.
GAS MODELS - U.S. and Canada
A 120 volt, 60 Hz AC, approved electrical service, with a 15 ampere fuse or circuit breaker is required.
ELECTRIC MODELS - U.S. Only
Most U.S. dryers, as manufactured, require a 120/240 volt, 60 Hz AC approved electrical service. Some require
120/208 volt, 60 Hz approved electrical service. The electric service requirements can be found on the data
label located on the front behind the door. A 30 ampere fuse or circuit breaker on both sides of the line is
required. Page 5

A 120/240 volt U.S. electric dryer must be converted if it is to operate on a 120/208 volt electrical system.
A heating element conversion kit is available (see Accessories).
If a power cord is used, the cord should be plugged into a 30 ampere receptacle.
The power cord is NOT provided with U.S. electric model dryers.
IMPORTANT: When permitted by local codes, the dryer electrical supply may be connected by means of a
new power supply cord kit, marked for use with clothes dryer, that is U.L. listed, rated at 120/240 volts
minimum, 30 amperes with three No. 10 copper wire conductors terminated with closed loop terminals, open-
end spade lugs with turned up ends or with tinned leads.
Do not reuse a power supply cord from an old dryer. The power cord electric supply wiring must be retained
at the dryer cabinet with a suitable UL listed strain relief.
If the dryer is to be installed in a mobile home or an area where local codes do not permit grounding through
neutral, only a 4 conductor power cord, rated and terminated as above, may be used.
ELECTRIC MODELS - Canada Only
A 120/240 volt, 60 Hz AC approved electrical service fused through a 30 ampere fuse or circuit breaker on
both sides of the line is required.
All Canadian models are shipped with the power cord attached. The power cord should be plugged into a
30 ampere receptacle.
NOTE: It is not permissible to convert a dryer in Canada to 208 volts.
REPLACEMENT PARTS AND ACCESSORIES
If your dryer requires replacement parts or accessories, contact the dealer from whom you purchased your
dryer or Maytag Customer Service, Box 2370, Cleveland, Tennessee 37320-2370, phone [phone],
for information on the nearest authorized Maytag Parts Distributor.
INSTALLATION
Parts and fiterature are packaged inside of dryer drum.
To Install...
I. Move dryer to an appropriate location for installation. Consider installing the dryer
before the washer in side-by-side installations, to allow access to gas, electrical
and exhaust connections.
Lay two of the carton corner posts on the floo. Tip the dryer forward on its front
so it will lay across both corner posts.
2. Remove the crate wires holding the crate base to the base frame. This '_,
can be done with a screwdriver.
3. Loosen the leveling locking nuts and install the vinyl feet.
4. Set the dryer back in an upright position.
5. Review the Exhausting Section before installing the exhaust system. Install the
ductwork from the dryer to the exhaust hood. The crimped end of the duct sections
must point away from the dryer. DO NOT use sheet metal screws when assem-
bling ducting. These joints should be taped. Never use plastic flexible exhaust
material.
Tip for tight installations: install a section of exhaust system
to the dryer before moving the dryer in place. Use duct tape
to secure this section to the dryer but do not cover louvers in
dryer cabinet. , /
Page 6

&WARNING ° Improper connection of the equipment-grounding conductor can result in a risk of electrical
shock. Check with a qualified electrician or serviceman if you are in doubt as to whether
the appliance is properly grounded. Do not modify the plug provided with the appliance -
if it will not fit the outlet, have a proper outlet installed by a qualified electrician.
• To prevent unnecessary risk of fire, electrical shock or personal injury, all wiring and
grounding must be done in accordance with the National Electrical Code ANSI/NFPA, No.
70-Latest Revision (for U.S.) or the Canadian Electrical code CSA C22.1 - Latest Revision and local
codes and ordinances. It is the personal responsibility and obligation of the appliance owner to provide
adequate electrical services for this appliance.
• All gas installations must be done in accordance with the National Fuel Gas Code ANSI/Z2231 - Latest
Revision (for the United States) or the CAN/CGA- B149 Installation Codes - Latest Revision (for
Canada) and local codes and ordinances.
1m
1m
Review Gas Requirements Section.
Remove the pipe thread protective cap.
Apply pipe joint compound or about 1 1/2 wraps of Teflon tape over all threaded
connections. NOTE: Pipe joint compound must be resistant to the action of any liquefied
petroleum gas.
Connect the gas supply to the dryer. An additional fitting is required to connect the 3/4"
(1.9 cm) female thread end of a flexible connector to the 3/8" (1 cm) male threaded end
on the dryer. Securely tighten the gas line fitting over threads.
Turn on the gas supply. Check all gas connections for leaks using a soap solution. If
bubbles occur, tighten the connections and recheck. DO NOT use an open flame to
check for gas leaks.
Review Electrical Requirements Section.
BEFORE OPERATING OR TESTING, follow the grounding instructions in the Grounding Section.
U.S. MODELS:
IMPORTANT -All U.S. models are produced for a 3-WIRE SYSTEM
CONNECTION. The dryer frame is grounded to the neutral conductor at the
terminal block. A 4-WIRE SYSTEM CONNECTION is required for new or
remodeled construction, mobile homes, or if local codes do not permit grounding
through neutral. If the 4-wire system is used, the dryer frame cannot be
grounded to the neutral conductor at the terminal block. Refer to the following
instructions for 3- and 4-WIRE SYSTEM CONNECTIONS.
IBIock Covel
I 'ate/
"O
Remove the terminal block cover plate.
Insert the power cord with a U.L. listed strain relief through the hole provided in the cabinet near the
terminal block. NOTE: a strain relief must be used.
t
Do not loosen the nuts already installed on the terminal block. Be sure they are tight. Use a 3/8" (1 cm)
deep well socket.
Page 7

3-WIRE SYSTEM CONNECTIONS
If the power cord has terminals, place the terminals over the existing nuts
on the posts. The neutral (white or center wire on power cord) conductor _3-WireSystem
must always be connected to the center (silver colored) post of the \ _
terminal block. °
Secure in place using the nuts provided in the partspackage. If the
power cord does not have terminals, use the cupped washers ahead of
the nuts.
Be sure the terminal block nuts are tight. Secure the power cord in position.
Tighten the strain relief screw(s) in order to clamp the strain relief to the
cord.
Replace the terminal block cover.
WARNING: If converting from a 4-wire electrical system to a 3-wire the ground strap must be
reconnected to the term nab OCKsupport to ground the aryer frame to the neutra conauctor.
4-WIRE SYSTEM CONNECTIONS
Strain
Remove the ground strap screw from the terminal block sup-
port. Fold the ground strap over so both ends of the ground
strap will be attached to the center terminal block post.
Connect the neutral (white) conductor of the cord to the center
(silver) post of the terminal block. Connect the grounding
(green) wire of the cord to the terminal block support using the
ground strap screw.
Connect the red and black wires of the cord to the outer posts
of the terminal block.
Be sure the terminal block nuts are on tight. Secure the power
cord in position. Tighten the strain relief screw(s) in order to
clamp the strain relief to the cord. Replace the terminal block
cover.
4-Wire System with
Power Cord Attached
'\j Folded
Neutral Ground
VAC
120
VAC
Strain
relief
EXPORT MODELS
Refer to the Additional Instructions Section.
7. With a level, check the dryer, and make necessary adjustments to the level-
ing legs. Once level, tighten the leveling leg locking nuts with a wrench.
8, The dryer door direction can be reversed.
1. If the dryer is plugged in, unplug from electrical service.
2. Remove the hinge hole covers and screws. Move the door catch cover to the opposite side.
3. While supporting the door remove 2 screws in the hinges that secure the hinges to the cabinet.
4. Remove the door by lifting slightly at the hinges and pulling the hinge tabs out of the hinge slots.
5. Move the following parts to the opposite side of the door: 2 hinges and 4 hinge screws, 4 door
screws, door strike and screw, inner door cover plate and screw.
6. Attach the door to the opposite side of the cabinet using the 2 counter sunk hinge screws.
(See below.)
7. Driving the lower hinge screw first will help to align the door and hinges.
8. Replace the hinge hole covers and screws in the opposite side.
Door Catch
, ' [,,
,';"'t_..,,,
i i
i rlJ
i i i - _1
IrPi Ili _ i
i i i _ i
i i i i i_
i
Counter Sunk Screw _ i
Door
_"Screws
Door
Page 8

At this time, make sure all gas connections (on gas models), exhaust and electrical connections are
complete. Plug dryer in, and check operation by using the check list below.
(GAS MODELS ONLY)
The burner may not ignite initially due to air in the gas line. Allowing the dryer to operate on a heat
setting will purge the line. If the gas does not ignite within five minutes, turn the dryer off and wait
5 minutes. Be sure the gas supply to the dryer has been turned on. In order to confirm gas ignition,
check the exhaust for heat.
FINAL INSTALLATION CHECK LIST
Dryer is plugged into electrical outlet and is properly grounded. NOTE: The first time power is applied
a code "PF" may be displayed. This is normal and can be reset by pressing any key.
Exhaust duct work is hooked up and joints taped.
Plastic flexible duct is NOT used.
Use rigid or stiff walled flexible metal vent material.
Dryer is level with all legs firmly on the floor, with the lock nuts tightened.
Vinyl feet have been installed.
Gas Models - gas is turned on, there are no gas leaks.
Dryer runs, heats, shuts off.
Demonstrate use to consumer.
HOUSEHOLD INSTALLATION ACCESSORIES
• Vent hood - 4" (10.16 cm) opening - 059129
• Aluminum pipe - 4" x 24" (10.16 cm x 60.96 cm) - 059130
• Aluminum elbow - 4" (10.16 cm) - 059131
• Aluminum window plate - 15" x 20" (38.10 cm x 50.80 cm) - 4" (10.16 cm) hole - 059134
• Flexible aluminum vent duct - 4" (10.16 cm) diameter - 38" (81.28 cm) length stretches to 8' (2.44 cm) -
304353
• Clamp for flexible aluminum duct - 304630
• Exhaust duct kit for base or left side exhausting - 12001453
• Rectangular vent kit - 059144
• Dacron lint bag - 311353
• NATURAL to LP conversion kit - 306195
• LP to NATURAL conversion kit - 306204
• Anchor bracket kit - 303740
• Heating element conversion kit, 208V., not for Canada- 308590
• Grounding kit- 12001875
• Power cords - 240 v, 30 A
4' (121.9 cm - 3-wire
5' (152.4
6' (182.9
10' (304.8
4' (121.9
5' (152.4
6' (182.9
10' (304.8
- 33001780
cm - 3-wire - 33001822
cm - 3-wire - 33001823
cm - 3-wire - 33001838
cm - 4-wire - 33001781
cm - 4-wire - 33001824
cm - 4-wire - 33001825
cm - 4-wire - 33001838
For the visually impaired, Braille labels can be placed on the control panel of the appliance. Check with your
local Association for the Blind for information on Braille label makers.
Page 9
