Maytag MEW7527AB Assembly instructions

27" (68.6 cm) models
A. 51
³⁄₁₆
" (130.0 cm) max. overall
height
B. 25
⁷⁄₁₆
" (64.6 cm) max.
recessed width
C. 48
¹³⁄₁₆
" (124.0 cm) recessed
height
D. 23
¹⁄₄
" (59.1 cm) max.
recessed depth
E. 27" (68.6 cm) overall width
30" (76.2 cm) models
A. 51
³⁄₁₆
" (130.0 cm) max. overall
height
B. 28½" (72.4 cm) max. recessed
width
C. 48
¹³⁄₁₆
" (124.0 cm) recessed
height
D. 23
¹⁄₄
" (59.1 cm) max. recessed
depth
E. 30" (76.2 cm) overall width
C
B
A
ED
¹⁄₂
27" (68.6 cm) models
A. 28¾" (72.8 cm) max. overall
height
B. 25
⁷⁄₁₆
" (64.6 cm) max. recessed
width
C. 26
³⁄₄
" (67.9 cm) recessed
height
D. 23
¹⁄₄
" (59.1 cm) max. recessed
depth
E. 27" (68.6 cm) overall width
30" (76.2 cm) models
A. 28¾" (72.8 cm) max. overall
height
B. 28½" (72.4 cm) max. recessed
width
C. 26
³⁄₄
" (67.9 cm) recessed
height
D. 23
¹⁄₄
" (59.1 cm) max. recessed
depth
E. 30" (76.2 cm) overall width
B
C
D
E
A
³⁄₄ ³⁄₄
¹⁄₂
PRODUCT MODEL SERIES PRODUCT DIMENSIONS
MEW7527A
MEW7627A
MEW9527A
MEW9627A
MEW7530A
MEW7630A
MEW9530A
MEW9630A
Electrical:
To properly install your oven, you must determine the type of
electrical connection you will be using and follow the instructions
provided for it here.
● Oven must be connected to the proper electrical voltage and
frequency as specified on the model/serial number rating plate.
The model/serial number rating plate is located under the
control panel on single ovens and under the control panel on
the upper oven cavity on double ovens. See the following
illustrations.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specifications subject to change without notice. Ref. W10351242
2/15/12
27" (68.6 CM) AND 30" (76.2 CM)
ELECTRIC SINGLE AND DOUBLE BUILT-IN OVEN
Page 1 of 2
Single Oven
A. Model/serial number plate
Double Oven
A. Model/serial number plate
AA
● Models rated from 7.3 to 9 kW at 240 volts (5.4 to 7.4 kW at
208 volts) require a separate 40-amp circuit. Models rated at
4.8 kW and below at 240 volts (3.6 kW and below at 208 volts)
require a separate 20-amp circuit.
● A circuit breaker is recommended.
● Connect directly to the circuit breaker box (or fused disconnect)
through flexible, armored or nonmetallic sheathed, copper cable
(with grounding wire). See “Make Electrical Connection”
section.
● Flexible conduit from the oven should be connected directly to
the junction box.
● Fuse both sides of the line.
● Do not cut the conduit. The length of conduit provided is for
serviceability of the oven.
● A UL listed or CSA approved conduit connector must be
provided.
● If the house has aluminum wiring, follow the procedure below:
1. Connect a section of solid copper wire to the ends of the
flexible conduit leads.
2. Connect the aluminum wiring to the added section of
copper wire using special connectors and/or tools
designed and UL listed for joining copper to aluminum.
Follow the electrical connector manufacturer's recommended
procedure. Aluminum/copper connection must conform with
local codes and industry accepted wiring practices.
For power requirements for models MEW7527A, MEW7530A,
MEW7627A, MEW7630A, MEW9537A, MEW9627A, MEW9530A
and MEW9630A, refer to the following table.
Voltage Single Single Double Double
Thermal Convect Thermal Convect
240 VAC 3690 W 3720 W 7370 W 7400 W
208 VAC 2790 W 2820 W 5580 W 5610 W
240 VAC 15.4 A 15.5 A 30.7 A 30.8 A
208 VAC 13.4 A 13.6 A 26.8 A 27.0 A

Double Ovens Installed in Cabinet
NOTE: The cutout height can be between 48⁷⁄₈" (124.1 cm) and
52³⁄₁₆" (132.6 cm) for double ovens.
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 14³⁄₄" (37.5 cm) bottom of
cutout to floor is
recommended.
4"-14³⁄₄" (10.2-37.5 cm)
bottom of cutout to floor is
acceptable.
D. 25¹⁄₂" (64.8 cm) cutout width
E. 1¹⁄₂" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 5 0
¹⁄₄ " (127.6 cm)*
recommended cutout height
G. 24" (60.7 cm) cutout depth
30" (76.2 cm) models
A. 30" (76.2 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 14³⁄₄" (37.5 cm) bottom of
cutout to floor is
recommended.
4"-14³⁄₄" (10.2-37.5 cm) bottom
of cutout to floor is acceptable.
D. 28¹⁄₂" (72.4 cm) cutout width
E. 1¹⁄₂" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 5 0
¹⁄₄ " (127.6 cm)*
recommended cutout height
G. 24" (60.7 cm) cutout depth
F
E
A
D
G
B
C
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specifications subject to change without notice. Ref. W10351242
2/15/12
CABINET OPENING DIMENSIONS
27" (68.6 cm) and 30" (76.2 cm) Single Oven Undercounter
(without cooktop installed above)
A. 27" (68.6 cm) min. cabinet width on 27" (68.6 cm) models
30" (76.2 cm) min. cabinet width on 30" (76.2 cm) models
B. 1¹⁄₂" (3.8 cm) min. top of cutout to underside of countertop
AB
C
D
E
C. 5¹⁄₄ " (13.3 cm) bottom of cutout to floor
D. 25¹⁄₂" (64.8 cm) cutout width
E. 28" (71.2 cm) min. cutout height
D. 28¹⁄₂" (72.4 cm) cutout width
Page 2 of 2
Single Ovens Installed in Cabinet
NOTE: The cutout height can be between 26¹⁵⁄₁₆" (68.4 cm) and
29⁷⁄₁₆" (74.8 cm) for sin
g
le ovens.
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 32" (81.3 cm) bottom of cutout
to floor
D. 25¹⁄₂" (64.8 cm) cutout width
E. 1¹⁄₂" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 28" (71.2 cm)* recommended
cutout height
G. 24" (60.7 cm) cutout depth
30" (76.2 cm) models
A. 30" (76.2 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 32" (81.3 cm) bottom of
cutout to floor
D. 28¹⁄₂" (72.4 cm) cutout width
E. 1¹⁄₂" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 28" (71.2 cm)* recommended
cutout height
G. 24" (60.7 cm) cutout depth
F
E
B
C
A
D
G
