OVEN PARTS
1
For Models: CWE4100ACB10, CWE4100ACE10
(Black) (White)
10−11 Litho in U.S.A. (JMJ)(bay) Part No. W10250556 Rev. B
24" BUILT−IN
ELECTRIC OVEN

OVEN PARTS
2
For Models: CWE4100ACB10, CWE4100ACE10
(Black) (White)
W10250556
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10203506 Installation
Instructions
W10224167 Owners Manual
W10211157 Diagram, Wiring
9762761 Brochure, Tips
(Safe Cooking)
2
4002F121−51 Back, Main
3
3601F005−61 Baffle, Base
4
7002P236−60 Insulation,
Top & Rear
5
W10214296 Cover, Box
6
7101P356−60 Screw
7 Extrusion, Bottom
7754P004−60 White
7754P003−60 Black
8 Extrusion, Side
7750P122−60 White Left
7750P121−60 White Right
7750P118−60 Black Left
7750P117−60 Black Right
9
7002P006−60 Insul., Bottom
10 Nut, Snap
7103P039−60 White
7103P041−60 Black
11
7101P287−60 Screw
12 Panel, Side
2618F150−51 Left
2618F149−51 Right
13
3804F096−51 Retainer, Rear
14
3804F118−51 Retainer, Top
15
3604F101−80 Shield, Air
16
3804F104−51 Retainer, Bottom
17
2205F003−19 Bottom, Oven
18
7408P035−60 Receptacle, Lamp
19
7112P004−60 Clip, Thermostat
20
7112P020−60 Clip, Oven Front
21
7407P103−60 Bulb, Oven
22
3807F137−80 Support
23
4003F049−80 Base, Chassis
24
7506P403−60 Tube, Oven
25
8026P070−60 Tube, Vent
26 Extrusion ,Vent
7756P123−60 White
7756P071−60 Black
27 Extrusion, Top Frt
7756P117−60 White
7756P104−60 Black
28
7101P633−60 Screw
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
7002P160−60 Insulation, Back

OVEN DOOR PARTS
3
For Models: CWE4100ACB10, CWE4100ACE10
(Black) (White)
W10250556
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3601F102−51 Baffle, Door
3 Handle, Door
7701P137−60 White
7701P136−60 Black
4 Spacer,
Door Handle
8010P128−60 White
8010P127−60 Black
5 Panel, Oven Door
2401F199−71 White
2401F199−70 Black
6 Glass, Oven Door
7902P590−60 White
7902P357−60 Black
7
7902P715−60 Glass, Inner
8
2402W205−19 Lining, Door
9 Retainer, Glass
7112P094−60 White
7112P093−60 Black
10
7101P356−60 Screw
11
7101P326−60 Screw
12
7101P633−60 Screw
13
7002P015−60 Insulation, Door
14
7212P003−60 Seal, Oven Door
(Vertical)
15
7212P006−60 Seal, Oven Door
(Horizontal)

INTERNAL OVEN PARTS
4
For Models: CWE4100ACB10, CWE4100ACE10
(Black) (White)
W10250556
Illus. Part
No. No. DESCRIPTION
1 7406P182−60 Element, Broil
2
7801P153−60 Rack, Oven
3
7406P424−60 Element, Bake
4
7101P287−60 Screw
5
W10273818 Rack, Offset
6
3807F749−45 Support,
Broil Support

CONTROL PANEL PARTS
5
For Models: CWE4100ACB10, CWE4100ACE10
(Black) (White)
W10250556
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Clock
7602P165−60 White
7602P164−60 Black
2
5700P367−60 Conduit, Flexible
3
7417P017−60 Connector, Cable
4
W10214294 Cover, Wire
5
4005F262−51 Cover, Fan
6
7427P006−60 Assembly, Fan
7 Panel, Control
W10198731 White
W10198729 Black
8
7407P102−60 Light, Indicator
9 Knob, Thermostat
7735P048−60 White
7735P049−60 Black
10
3605F194−80 Plate, Backing
11
7403P172−60 Switch, Selector
12
7404P049−60 Thermostat, Oven
13
7101P077−60 Screw
14
3605F164−51 Plate, Conduit
15
7101P376−60 Screw
16
7101P287−60 Screw
17
8008P004−60 Grommet
18 Switch, Rocker
7403P842−60 White
7403P841−60 Black

OPTIONAL PARTS
6
For Models: CWE4100ACB10, CWE4100ACE10
(Black) (White)
W10250556
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
PAINT, SPRAY
350930 White
830864 Black
WIRING HARNESS PARTS
W10212891 Harness, Main
Miscellaneous
W10123240 Pan,
Porcelain Broiler
4396096RB Griddle, Gourmet
4378577 Stone,
Brick Baking
31605 Kit,
Cooktop Care
31552 Degreaser,
Heavy Duty
31682 Cleaner,
Appliance
