Maytronics Dolphin DYNAMIC 2002 Setup guide

Repair instructions for - TOP1

Table of Contents
I. Tools needed for repair Page 3
II. Dismantling the Dolphin Page 4
III. Testing and replacing main components Page 11
–Analyze power s pply Page 11
–Analyze cable Page 12
–Repair/replace cable Page 14
–Replace motor nit Page 21
IV. Replacing br shes Page 22
V. Replacing filter bags Page 25
2
*NOTE: Some images may differ slightly in shape color etc.

I. Tools needed for repair
•Dolphin tester
•Dolphin key
•Screwdriver or screw g n
•Needle nose pliers
•Wire c tters
•Wire strippers
•Cable crimper
•1.5 x 50mm hex screwdriver
Please note: when repairing any Dolphin cleaner
only hand-tighten screws. Do not over tighten! For
automatic screw guns use low torque setting only.
3

II. Dismantling the Dolphin
Remove screws
attaching handle to
body.
Remove handle. Use
gentle press re from a
screwdriver to help pry
it away from the body
if necessary.
4

II. Dismantling the Dolphin
Flip the nit over and
remove the bottom
plate.
5
Remove the two
screws attaching the
plastic screen to the
body.

II. Dismantling the Dolphin
Remove the plastic
screen.
6
Use the silver key to
remove cable from
motor nit.

II. Dismantling the Dolphin
Unpl g cable by gently
p lling pward.
7
Remove the 12 screws
(6 per side) that hold
the side panels to the
chassis.

II. Dismantling the Dolphin
Location of screws.
6 per side.
8
Remove the side
panels.

II. Dismantling the Dolphin
Note that the cable
passes thro gh the
panel on one side of
the nit.
9
The br shes and tracks
are now free to be
removed.

II. Dismantling the Dolphin
Note: the center g ide
wheel contains a
removable slot for the
drive shaft. This m st
be removed to replace
the motor.
10
Also, it’s easiest to
wind the tracks aro nd
the center g ide wheel
first and then attach to
nit.

III. Testing the Dolphin
Step 1. Analyze power s pply
Insert ro nd end of
Dolphin tester into
power s pply where
cable connects. Pl g in
power s pply and p sh
power b tton.
If yo get a green light,
power s pply is good!
If there is no light, the
power s pply sho ld
be replaced.
11

III. Testing the Dolphin
Step 2. Analyze cable
Pl g cable into
triang lar end of
Dolphin tester.
Pl g other end of cable
into power s pply and
t rn the power s pply
on.
12

III. Testing the Dolphin
Step 2. Analyze cable
A green light indicates
the cable is good. If
yo do not get a green
light, and yo are s re
all connections are
sec re, replace cable.
13

III. Testing the Dolphin
Step 3. Repairing/replacing cable
C t off the triangle end
and p ll the cable o t
thro gh the side plate.
14
Strip off the o ter
cable casing to expose
the internal wires.

III. Testing the Dolphin
Step 3. Repairing/replacing cable
Strip each wire approx.
¼ inch. Note that some
cables may have three
wires: white, black and
red.
15
Using wire c tters,
separate the metal
elements, trimming
away any excess.

III. Testing the Dolphin
Step 3. Repairing/replacing cable
Crimp one element
onto the end of each
wire. This can be done
with pliers if necessary.
16
Insert the cable
thro gh the pieces of
the cable kit in the
order shown.

III. Testing the Dolphin
Step 3. Repairing/replacing cable
P sh the wires into the
triangle end as
pict red. The white
wire will always be to
the right of the
channel in the
connector, the black
wire to the left, and
the red wire (if
present) in the back.
To replace Amphenol
pl g, first c t off
molded end.
17
present) in the back.

III. Testing the Dolphin
Step 3. Repairing/replacing cable
Insert the cable
thro gh the pieces of
the cable kit in the
order shown.
18
Strip each wire approx.
¼ inch. Note that some
cables may have three
wires: white, black and
red.

III. Testing the Dolphin
Step 2. Analyze cable
Using the 1.5 x 55mm
hex screwdriver, loosen
the necessary
terminals.
•AC = white 1, black 2
•DC = white 2, black 3
•Red = gro nd
19
Insert the wires into
their appropriate
terminals and tighten.

III. Testing the Dolphin
Step 3. Repairing/replacing cable
Re-assemble the
Amphenol pl g first by
screwing “C” into the
end, then screwing “A”
into “C” with “B”
inside.
20
Note: screwing “A”
into “C” first will twist
the cable inside the
connector and may
damage the wires!
