MAZDA 323/PROTEGE 1990-94
Labor Times Shown are for Replacement with New OEM Undamaged Parts on New Undamaged Vehicles.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629.
44 madpl1_g01_
Page 44—April 22, 2004—13:29:11—Version Manufacturer
REAR BUMPER Cont’d
WAGON Cont’d
1 Center BJ19-50-221
2 Outer R BJ19-50-231
L BJ19-50-241
3
Moulding, Cover
Bright BJ20-50-225
Argent BJ19-50-225
4
Brkt, Slide Outer R/L B092-50-230
5
Brkt, Slide Inner R BJ19-50-232
L BJ19-50-242
6
Plate, Stud Outer R BJ19-50-234
L BJ19-50-244
7
Plate, Stud Inner R BJ19-50-2A1
L BJ19-50-2B1
8
Absorber, Impact R BJ19-50-223
L BJ19-50-224
9
Retainer, Cover BJ19-50-229
10
Bar Assy, Reinforcement BJ19-50-260
Retainer to Reinforcement
11 Upper¶ BJ19-50-1Z0
12 Lower BJ19-50-0D0
¶Included w/Reinforcement Bar Assy
13
Arm, Bumper Mounting R BJ19-50-270
LBJ19-50-280
MAZDA 323/PROTEGE 1990-94
PAINT CODE LOCATION
Paint code located on left lock pillar or engine compartment.
CLEAR COAT IDENTIFICATION
All metallic colors are clear coat.
INFORMATION LABELS
1 Label, Logo B6S7-13-309
2
Label, Radiator Caution 8791-15-201
Label, A/C Caution UE38-61-439
3
Label, Caution
USA
1.6L Eng E301-15-031
1.8L Eng
Man Trans E301-15-031
Auto Trans B660-15-031
Canada N.A.
4
Caution Plate
1.6L Eng E563-15-201
1.8L Eng
Man Trans E563-15-201
Auto Trans 0488-15-201
5
Model Plate 8595-69-011B
6
Label, Battery FA03-69-C72A
7
Label, Caution FA01-69-064B
8
Label, Oil
SOHC Eng BR93-69-D21D
DOHC Eng BR86-69-D21E
Label, Emission¶ BB7A-69-036
¶Order by Application
Label, Vehicle Information B001-69-D51
Label, Vacuum Diaphragm
1.6L Eng
1990-92 BR78-69-044
1993
w/Calif Emission BR97-69-044
w/o Calif Emission BR78-69-044
1994 BR97-69-044
1.8L Eng
SOHC Eng BB7L-69-044
DOHC Eng BB7E-69-044
9
Caution Plate GA02-69-068
10
Tire Plate
FWD
1.6L Eng BR86-69-014A
1.8L Eng
SOHC Eng BR87-69-014A
DOHC Eng BW1N-69-014A
AWD BA1C-69-014A
11
Label, Child Proof-English R/L BA06-72-301
Label, Fuel Warning KA10-69-D61A
12
Label, Unleaded Fuel UB40-69-C61
Label, Fuel Economy UB40-69-C61
13
Label, Temporary Tire
FWD
USA BF68-69-073B
Canada
English N.A.
French N.A.
AWD BK14-69-073
14
Label, Tire Caution BR70-61-438
Safety Panel
Canada N.A.
Label, Indicator-See Steering Wheel/Column Section
FRONT BUMPER
1 Cover, Front
Black BR70-50-031
Painted (P) BR71-50-031A
(P) Paint to Match
2
Tape, Stripe R BA1C-50-0D5
L BA1C-50-0D6
3
Bracket, Lower R/L BR70-50-G21-2
4
Fastener (10) BF67-50-235
5
Absorber, Impact R/L BR70-50-111-2
6
Bar, Reinforcement BR70-50-070
Retainer, Cover
7 Side R BR70-50-1Z2
L BR70-50-1Z3
8 Center BR70-50-1Z1
Rivet (7) BR70-50-0Z1
Frame, License Plate
9 Upper GJ21-50-183
10 Lower
FWD GJ21-50-180
AWD BA1E-50-180
11
Bracket, License Plate H005-50-060
Spoiler, Air BA1E-51-9L0
SECTION INDEX
A/C /HEATER/VENTILATION .............................................................. 46
A/C REFRIGERANT CAPACITIES ...................................................... 46
AIR CLEANER..................................................................................... 50
BACK WINDOW .................................................................................. 55
CENTER CONSOLE ........................................................................... 51
CLEAR COAT IDENTIFICATION ......................................................... 44
COOLING ............................................................................................ 46
COWL & DASH.................................................................................... 51
CRUISE CONTROL SYSTEM............................................................. 47
ELECTRICAL....................................................................................... 50
EMISSION SYSTEM ........................................................................... 50
ENGINE............................................................................................... 49
ENGINE MOUNTS .............................................................................. 50
EXHAUST ............................................................................................ 50
FRONT BUMPER ................................................................................ 44
FRONT DOOR..................................................................................... 53
FRONT DRIVE AXLE .......................................................................... 48
FRONT FENDER................................................................................. 46
FRONT INNER STRUCTURE ............................................................. 47
FRONT LAMPS ................................................................................... 45
FRONT STEERING LINKAGE/GEAR ................................................. 49
FRONT SUSPENSION........................................................................ 48
FUEL TANK ......................................................................................... 59
GRILLE................................................................................................ 45
HOOD.................................................................................................. 45
INFORMATION LABELS ..................................................................... 44
INSTRUMENT PANEL......................................................................... 51
LIFTGATE............................................................................................ 57
LUGGAGE LID .................................................................................... 57
PAINT CODE LOCATION .................................................................... 44
QUARTER GLASS .............................................................................. 57
QUARTER PANEL ............................................................................... 56
REAR BODY........................................................................................ 59
REAR BUMPER .................................................................................. 61
REAR DOOR....................................................................................... 54
REAR DRIVE AXLE............................................................................. 59
REAR LAMPS...................................................................................... 59
REAR SEAT......................................................................................... 52
REAR SUSPENSION .......................................................................... 58
ROCKER/PILLARS/FLOOR ................................................................ 51
ROOF .................................................................................................. 55
SEAT.................................................................................................... 52
SEAT BELTS........................................................................................ 52
STEERING PUMP............................................................................... 49
STEERING WHEEL/COLUMN............................................................ 49
SUNROOF........................................................................................... 55
UNDERHOOD DIMENSIONS ............................................................. 47
WHEEL................................................................................................ 47
WINDSHIELD ...................................................................................... 50

MAZDA 323/PROTEGE 1990-94
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629. 45
madpl1_g01_
Page 45—April 22, 2004—13:29:12—Version Manufacturer
GRILLE
HATCHBACK
1990-92
1 Grille Assy (P) BRY3-50-710
(P) Paint to Match
2
Nameplate (a)
"Mazda" B300-51-771
3
Clip, Grille Side (a)
(2/Side) R/L B092-50-715
4
Clip, Grille Center (a) 9991-00-410
(a) Included w/Grille Assy
5
Moulding, Below Lamp¶ R B455-50-7J1-5D
L B455-50-7K1-5D
¶Harbor Blue listed, Order by Application
DV Bay Blue; DX Honey Blue; FZ Herbie Green;
GU Shade Green; PZ Brilliant Black;
SQ Blaze Red; SS Coral Red; UF Clear White;
IH Steel Gray MC; IS Niagara Silver MC;
Z1 Bluish Green M; 3L Silver Stone MC;
4C, 4Z Silent Silver; 5D Harbor Blue MC;
5S Neat Green MC; 6C Mighty Gray;
6L Graceful Red MC; 6M Elegant Beige;
6N Current Blue MC; 6V Raspberry Metallic;
6W Laguna Blue M; 6Y Sea Mist M
E9 Deep Purple; J4 Passion Rose
Clip, Moulding R/L B092-50-782
HATCHBACK
1993-95
1 Grille Assy (P) BBYB-50-710B
(P) Paint to Match
2
Emblem (a) GA8B-51-731
3
Clip, Emblem (a) (2) BB0S-50-717
4
Clip, Grille Side (a)
(2/Side) R/L B092-50-715
5
Clip, Grille Center (a) 9991-00-410
(a) Included w/Grille Assy
6
Moulding, Below Lamp¶ R B455-50-7J1-5D
L B455-50-7K1-5D
¶Harbor Blue listed, Order by Application
DV Bay Blue; DX Honey Blue; FZ Herbie Green;
GU Shade Green; PZ Brilliant Black;
SQ Blaze Red; SS Coral Red; UF Clear White;
IH Steel Gray MC; IS Niagara Silver MC;
Z1 Bluish Green M; 3L Silver Stone MC;
4C, 4Z Silent Silver; 5D Harbor Blue MC;
5S Neat Green MC; 6C Mighty Gray;
6L Graceful Red MC; 6M Elegant Beige;
6N Current Blue MC; 6V Raspberry Metallic;
6W Laguna Blue M; 6Y Sea Mist M;
E9 Deep Purple; J4 Passion Rose
Clip, Moulding R/L B092-50-782
SEDAN
1990-92
1 Grille Assy (P) BAYC-50-710
(P) Paint to Match
2
Nameplate (a)
"Mazda" B300-51-771
3
Clip, Grille (a) B092-50-715
4
Grommet, Screw (a) B455-50-712
(a) Included w/Grille Assy
5
Moulding, Below Lamp¶ R B455-50-7J1-5D
L B455-50-7K1-5D
¶Harbor Blue listed, Order by Application
DV Bay Blue; DX Honey Blue; FZ Herbie Green;
GU Shade Green; PZ Brilliant Black
SQ Blaze Red; SS Coral Red; UF Clear White;
IH Steel Gray MC; IS Niagara Silver MC;
Z1 Bluish Green M; 3L Silver Stone MC;
4C, 4Z Silent Silver; 5D Harbor Blue MC;
5S Neat Green MC; 6C Mighty Gray
6L Graceful Red MC; 6M Elegant Beige
6N Current Blue MC; 6V Raspberry Metallic;
6W Laguna Blue M; 6Y Sea Mist M
E9 Deep Purple; J4 Passion Rose
Clip, Moulding R/L B092-50-782
SEDAN
1993
1 Grille Assy (P) BBYD-50-710A
(P) Paint to Match
2
Emblem (a) GA8B-51-731
3
Clip, Emblem (a) (2) BB0S-50-717
4
Clip, Grille (a) B092-50-715
5
Grommet, Screw (a) B455-50-712
(a) Included w/Grille Assy
6
Moulding, Below Lamp¶ R B455-50-7J1-5D
L B455-50-7K1-5D
¶Harbor Blue listed, Order by Application
DV Bay Blue; DX Honey Blue; FZ Herbie Green;
GU Shade Green; PZ Brilliant Black;
SQ Blaze Red; SS Coral Red; UF Clear White;
IH Steel Gray MC; IS Niagara Silver MC;
Z1 Bluish Green M; 3L Silver Stone MC;
4C, 4Z Silent Silver; 5D Harbor Blue MC;
5S Neat Green MC; 6C Mighty Gray;
6L Graceful Red MC; 6M Elegant Beige;
6N Current Blue MC; 6V Raspberry Metallic;
6W Laguna Blue M; 6Y Sea Mist M;
E9 Deep Purple; J4 Passion Rose
Clip, Moulding R/L B092-50-782
SEDAN 1994-95
1 Grille Assy (P) BBYB-50-710B
(P) Paint to Match
2
Emblem (a) GA8B-51-731
3
Clip, Emblem (a) (2) BB0S-50-717
4
Clip, Grille Side (a)
(2/Side) R/L B092-50-715
5
Clip, Grille Center (a) 9991-00-410
(a) Included w/Grille Assy
6
Moulding, Below Lamp¶ R B455-50-7J1-5D
L B455-50-7K1-5D
¶Harbor Blue listed, Order by Application
DV Bay Blue; DX Honey Blue; FZ Herbie Green;
GU Shade Green; PZ Brilliant Black;
SQ Blaze Red; SS Coral Red; UF Clear White;
IH Steel Gray MC; IS Niagara Silver MC;
Z1 Bluish Green M; 3L Silver Stone MC;
4C, 4Z Silent Silver; 5D Harbor Blue MC;
5S Neat Green MC; 6C Mighty Gray;
6L Graceful Red MC; 6M Elegant Beige;
6N Current Blue MC; 6V Raspberry Metallic;
6W Laguna Blue M; 6Y Sea Mist M;
E9 Deep Purple; J4 Passion Rose
Clip, Moulding R/L B092-50-782
FRONT LAMPS
HEADLAMP
Illustration Located in Next Column
1
Headlamp Assy
Hatchback R 8DBR-51-030B
L 8DBR-51-040B
Sedan
SOHC Eng
To 7-1-93 R 8DBP-51-030B
L 8DBP-51-040B
From 7-1-93 R 8DBR-51-030B
L 8DBR-51-040B
DOHC Eng
To 7-1-93 R 8DBP-51-030B
L 8DBP-51-040B
From 7-1-93 R 8DBR-51-030B
L 8DBR-51-040B
2
Lens & Body¶
Hatchback R BR93-51-0K0B
L BR93-51-0L0B
From 5-1-93 R BR93-51-0K0B
L BR93-51-0L0B
Sedan
SOHC Eng
To 5-1-93 R BR70-51-0K0B
L BR70-51-0L0B
From 5-1-93 to 7-1-93
Right BR93-51-0K0B
Left BR70-51-0L0B
From 7-1-93 R BR93-51-0K0B
L BR93-51-0L0B
DOHC Eng
To 9-1-92 R BR70-51-0K0B
L BR70-51-0L0B
From 9-1-92 to 5-1-93
Right BR70-51-0K0B
Left BR70-51-0L0B
From 5-1-93 to 7-1-93
Right BR93-51-0K0B
Left BR70-51-0L0B
From 7-1-93 R BR93-51-0K0B
L BR93-51-0L0B
3
Housing¶ R BR70-51-03X
L BR70-51-04X
4
Holder, Bulb¶ R/L BM89-51-0A3A
5
Bulb¶ R/L 0000-11-9004-90
¶Included w/Lamp Assy
SIDE MARKER LAMP
1 Lamp Assy R 8BBJ-51-060
L 8BBJ-51-070
2
Lens & Housing Assy¶ R BR70-51-06X
L BR70-51-07X
3
Protector¶ (a) R B455-51-065
L B455-51-075
(a) Included w/Lens & Housing Assy
4
Socket & Wire¶ R/L BR70-51-064
5
Bulb¶ R/L 0000-11-1157
¶Included w/Lamp Assy
HOOD
Illustration Located in Next Column
1
Panel, Hood
Hatchback BR93-52-310C
Sedan
SOHC Eng
To 7-1-93 BR70-52-310F
From 7-1-93 BB0S-52-310B
DOHC Eng
To 9-1-92 BR70-52-310F
From 9-1-92 to 7-1-93 BR70-52-310F
From 7-1-93 BB0S-52-310B

MAZDA 323/PROTEGE 1990-94
Labor Times Shown are for Replacement with New OEM Undamaged Parts on New Undamaged Vehicles.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629.
46 madpl1_g01_
Page 46—April 22, 2004—13:29:13—Version Manufacturer
HOOD Cont’d
Insulator, Hood B528-68-601
2
Rubber, Cushion R/L UB39-56-740
3
Rubber, Stopper R/L LA01-56-786A
4
Hinge, Hood
Hatchback R B467-52-410D
L B467-52-420D
Sedan R B455-52-410E
L B455-52-420E
5
Latch
Hatchback BR93-56-620E
Sedan
SOHC Eng BR70-56-620G
DOHC Eng 90-92 BR70-56-620G
93-95 BR70-56-620G
6
Cable, Release B455-56-720B
7
Clip, Release Cable (2) D001-56-731
8
Fastener, Release LA01-56-631
9
Rod, Support B455-56-651
10
Holder, Rod Front B455-56-693
11
Holder, Rod Rear B092-52-518
12
Deflector Assy, Hood
Hatchback R B467-56-730C
L B467-56-740C
Sedan 90-92 R B455-56-730B
L B455-56-740B
93-95 R B595-56-730
L B595-56-740
Clip, Deflector¶ (3/Side) R/L B455-56-741
¶Included w/Hood Deflector Assy
13
Weatherstrip Assy, Front B455-56-750B
Clip, W/Strip (a) (7) B455-56-741
(a) Included w/Front Weatherstrip Assy
14
W/Strip, Rear B455-56-760A
Fastener Assy, Weatherstrip (b) (2)
G031-58-762
(b) Included w/Rear Weatherstrip Assy
COOLING
1 Radiator Assy¶
FWD
Man Trans B61S-15-200E
Auto Trans
1.6L Eng B61N-15-200D
1.8L Eng BP02-15-200H
AWD
Man Trans BP45-15-200B
Auto Trans BP46-15-200A
¶Order by Application
2
Cap, Radiator (a)
Calsonic Brand D316-15-205
Denso Brand F8B7-15-205
3
Mount, Rubber (a)
Man Trans
Calsonic Brand R/L B366-15-202B
Denso Brand R/L B541-15-202A
Auto Trans R/L B61N-15-202A
(a) Included w/Radiator Assy
4
Brkt, Rad Upper R/L B6S7-15-240B
5
Brkt, Rad Lower R/L B366-15-230
6
Shroud, Fan
FWD
1.6L Eng B61W-15-210
1.8L Eng
Man Trans B61W-15-210
Auto Trans BP05-15-210
AWD BP26-15-210A
7
Blade, Fan
FWD
1.6L Eng
Man Trans FEH5-15-140
Auto Trans B6S8-15-140A
1.8L Eng
Man Trans B6S8-15-140A
Auto Trans B61F-15-140
AWD BP26-15-140A
8
Motor, Fan
FWD
1.6L Eng
Man Trans B366-15-150B
Auto Trans B6S8-15-150C
1.8L Eng
Man Trans B6S8-15-150C
Auto Trans B61F-15-150A
AWD BP26-15-150C
9
Hose, Rad Upper
1.6L Eng B366-15-186A
1.8L Eng
SOHC B366-15-186A
DOHC Eng B6S7-15-186A
10
Hose, Rad Lower B366-15-185A
11
Tank Assy, Coolant B366-15-350D
12
Cap, Tank¶ B6S7-15-355A
13
Bracket, Tank¶ B366-15-371A
14
Lever, Tank¶ B6S7-15-355A
¶Included w/Coolant Tank Assy
Pump, Water
1.6L Eng 8AB7-15-010
1.8L Eng
SOHC Eng 8AB7-15-010
DOHC Eng 8AB8-15-010
Pulley, Water Pump B366-15-131A
A/C REFRIGERANT CAPACITIES
A/C R-12 Refrigerant Capacity
1990-92: 26.5-28 Ozs (1.65-1.75 Lbs)
1993-95: 28 Ozs (1.75 Lbs)
A/C /HEATER/VENTILATION
1 Condenser BB7C-61-480
2
Receiver/Drier BR70-61-500
3
Compressor Assy
SOHC Eng BR70-61-450A
DOHC Eng BR74-61-450A
Compressor¶ BR70-61-K00
4
Clutch Assy¶
SOHC Eng B455-61-L1O
DOHC Eng B461-61-L1O
¶Included w/Compressor Assy
5
Hose, Suction
1.6L Eng BR71-61-461B
1.8L Eng BR70-61-461B
6
Hose, Return
1.6L Eng BR71-61-462A
1.8L Eng BB7A-61-462
7
Pipe, Condenser BR70-61-464A
Tube, A/C
8 Upper
Man Trans BR70-61-465B
Auto Trans BR72-61-465B
9 Lower BR70-61-467A
10
Fan, Condenser BR70-61-710A
11
Bracket, Fan BR70-61-71X
Illustration Located in Next Column
12
Evaporator Assy BR70-61-520B
13
Case, Evap Upper¶ BR70-61-J01
14
Case, Evap Lower¶ BR70-61-J02
15
Core, Evaporator¶ BR70-61-J10A
16
Insulator¶ HA14-76-707
17
Valve, Expansion¶ BR70-61-J14
¶Included w/Evaporator Assy
18
Heater Assy BR70-61-130
19
Core, Heater¶ BR70-61-A10
Case, Heater¶
20 Right BR70-61-A01
21 Left BR70-61-A02
22
Lining, Heater¶ (2) BR70-61-A11A
23
Link Set, Temp¶ BR70-61-A20
24
Link Set, Mode¶ BR70-61-A30
¶Included w/Heater Assy
25
Blower Assy, Heater EA77-61-140
26
Case, Blower Upper¶ BR70-61-B01
27
Case, Blower Lower¶ BR70-61-B02
28
Fan¶ BR70-61-B10
29
Resistor, Blower¶ BR70-61-B15
30
Link¶ BR70-61-B20
¶Included w/Heater Blower Assy
FRONT FENDER

MAZDA 323/PROTEGE 1990-94
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629. 47
madpl1_g01_
Page 47—April 22, 2004—13:29:15—Version Manufacturer
1 Fender Assy
Hatchback R BR93-52-110B
L BR93-52-210C
Sedan R B456-52-110B
L B456-52-210C
2
Bracket, Lamp¶ R B455-52-180
L B455-52-280A
¶Included w/Fender Assy
Moulding, Side
Adhesive
Hatchback R B4Y7-50-681
L B4Y7-50-691
Sedan
w/Red Line R BAYG-50-681
L BAYG-50-691
w/o Red Line R B4Y5-50-681
L B4Y5-50-691
Nameplate
"DX"
Light Gold R/L BR70-51-761-71
Light Gray R/L BR70-51-761-85
Dark Gray R/L BR70-51-761-86
"LX"
Light Gold R/L BR71-51-761-71
Light Gray R/L BR71-51-761-85
Dark Gray R/L BR71-51-761-86
"SE"
Light Gold R/L BR72-51-761-71
Light Gray R/L BR72-51-761-85
Dark Gray R/L BR72-51-761-86
"GT"
Canada
Light Gold R/L N.A.
Light Gray R/L N.A.
Dark Gray R/L N.A.
"DOHC 16-VALVE"
Light Gold B516-51-771A-71
Light Gray B516-51-771A-85
Dark Gray B516-51-771A-86
3
Shield, Splash R B455-56-131B
L B455-56-141B
4
Mudguard R B455-51-840C
L B455-51-850C
UNDERHOOD DIMENSIONS
FRONT INNER STRUCTURE
FRONT
1 Support Assy, Radiator BR70-53-100J
2
Bar, Upper Tie¶ B455-53-150D
3
Panel, Side¶ R BR70-53-120E
L BR70-54-120F
4
Bar, Lower Tie¶ B455-53-16XE
¶Included w/Radiator Support Assy
5
Support, Hood Latch B455-53-35YA
6
Plate, Side Panel R B455-53-325B
L B455-54-325B
7
Cover, Under R BR70-56-111A
L BR70-56-121A
SIDE
1 Apron Assy
FWD R BR70-53-200A
L BR70-54-200A
AWD R BA1C-53-200
L BA1C-54-200
2
Panel, Apron¶ R BS06-53-210D
L BS06-54-210C
3
Frame Assy, Apron¶
FWD R BR70-53-300H
L BR70-54-300M
AWD R BA1C-53-300L
L BA1C-54-300P
Bolt, Member¶ (a) 90-93 R/L B455-53-319
94-95 R/L B456-53-319
¶Included w/Apron Assy
(a) Included w/Apron Frame Assy
4
Reinf, Apron R B455-53-281A
L B455-54-281A
5
Guard, Splash Front
FWD R B455-56-311B
L B455-56-321B
AWD R B528-56-31X
L B528-56-321B
6
Guard, Splash Rear
FWD R BC1D-56-114
L B455-56-115
AWD R B528-56-312A
L B528-56-322A
7
Bracket, Bumper R B455-53-335A
L B455-54-335A
8
Hook, Tie-Down R BR70-53-36YF
L BR70-54-36YF
9
Tray, Battery
1990-91
FWD B465-56-040C
AWD B542-56-040A
1992-94 B467-56-040B
10
Box, Battery
50 Amp Battery PN40-18-591
55 Amp Battery PN41-18-591A
11
Duct, Battery
FWD B6S8-18-596A
AWD BP47-18-596
12
Clamp, Battery B465-56-03XA
13
Bolt, Battery
Front B180-56-034A
Rear B455-56-034
14
Battery N.A.
Positive N.A.
Negative N.A.
CRUISE CONTROL SYSTEM
1 Actuator Assy BR70-66-310B
2
Brkt, Actuator Front¶ BR70-66-3A1B
3
Brkt, Actuator Rear¶ BR70-66-3A2
4
Holder, Wire¶ BR70-66-3A8A
¶Included w/Actuator Assy
5
Bracket, Lower BR70-66-3AXA
6
Wire, Cruise Control BR70-66-311E
7
Tube, Cruise Control BR70-66-361A
8
Control, Cruise BR70-66-320A
WHEEL
STEEL WHEEL
1 Wheel, Spare 9965-15-404
Wheel, Steel
2 13x5"
Base Model 9965-70-5030
DX, SE Model 9965-73-503
3 14x5-1/2" 9965-A9-554
4
Cap, Wheel
13" Wheels
DX, SE Model B458-37-170A
LX Model BB7E-37-170
14" Wheels B459-37-170A
5
Cap, Hub B457-37-170A
6
Cap Assy, Center
13" Wheels B455-37-190
14" Wheels B461-37-190A
7
Emblem, Center¶ B001-37-192
¶Included w/Center Cap Assy
Stem, Valve 9963-60-4130
Nut, Lug
Standard B002-37-160A
Chrome 0603-26-161A
ALLOY WHEEL
Wheel Assy
1 13x5" 8BB8-37-600
2 14x5-1/2" 90-91 8BB7-37-600
92-95 B599-37-192C
Cap, Center¶
3 13" Wheels B460-37-190B
4 14" Wheels B461-37-190A
5
Stem, Valve¶ 9963-60-4130

MAZDA 323/PROTEGE 1990-94
Labor Times Shown are for Replacement with New OEM Undamaged Parts on New Undamaged Vehicles.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629.
48 madpl1_g01_
Page 48—April 22, 2004—13:29:16—Version Manufacturer
WHEEL Cont’d
ALLOY WHEEL Cont’d
¶Included w/Wheel Assy
6
Cap, Wheel
13" Wheels
DX, SE Model B458-37-170A
LX Model BB7E-37-170
14" Wheels B459-37-170A
7
Cap, Hub B457-37-170A
Stem, Valve 9963-60-4130
Nut, Lug
Standard B002-37-160A
Bright 0603-26-161A
FRONT SUSPENSION
1 Rotor, Brake
FWD
SOHC Eng R/L B26Y-33-25XA
DOHC Eng R/L BB7E-33-25XD
AWD R/L B530-33-25XE
Nut, Lock R/L GJ21-33-042B
2
Hub, Drive R/L B01A-33-060A
3
Caliper, Brake
FWD
SOHC Eng R B4Y2-33-98ZR
L B4Y2-33-99ZR
DOHC Eng R BRY4-33-98ZR
L BRY4-33-99ZR
AWD R BRY4-33-98ZR
L BRY4-33-99ZR
Hose, Brake
FWD R/L B455-43-980B
AWD R/L B461-43-980C
4
Knuckle Assy, Steering
FWD
SOHC Eng
To 1-1-92 R B455-33-020A
L B455-33-030A
From 1-1-92 to 3-9-93
Right B455-33-020A
Left B455-33-030A
From 3-9-93 R B01L-33-020B
L B01L-33-030B
DOHC Eng
To 1-1-92 R BR74-33-020C
L BR74-33-030C
From 1-1-92 to 3-9-92
Right BR74-33-020C
Left BR74-33-030C
From 3-9-92 R B01A-33-020B
L B01A-33-030B
AWD R BR74-33-020C
L BR74-33-030C
5
Shield, Splash¶
To 6-1-93 R B01A-33-261B
L B01A-33-271B
From 6-1-93 R B01A-33-261B
L B01A-33-271B
¶Included w/Steering Knuckle Assy
6
Bearing, Wheel R/L B455-33-047D-MV
7
Seal, Bearing R/L G304-33-065
8
Ring, Retaining R/L B21M-33-048
Illustration Located in Next Column
9
Strut
FWD
1.6L Eng R BR70-34-700F
L BR70-34-900F
1.8L Eng R BR70-34-700F
L BR70-34-900F
AWD R BA1E-34-700A
L BA1E-34-900A
10
Spring, Coil¶
Hatchback
Man Trans R/L B458-34-011A
Auto Trans R/L B463-34-011A
Sedan
FWD
Man Trans R/L B463-34-011A
Auto Trans R/L BR72-34-011A
AWD
Man Trans R/L BR72-34-011A
Auto Trans R/L BR75-34-011A
¶Order by Application
11
Bumper, Stop R/L B455-34-111B
12
Seat, Rubber R/L B455-34-012
13
Seat, Spring R/L B455-34-340A
14
Bushing, Mtg R/L B455-34-38XB
15
Mount, Strut R/L B455-34-380D
16
Cap, Damper R/L 1011-34-019
17
Arm Assy, Lower Control
1990-91
FWD R B455-34-300E
L B455-34-350E
AWD R B530-34-300A
L B530-34-350A
1992-95
Std Duty
To 3-9-93 R BR70-34-300B
L BR70-34-350B
From 3-9-93 R B455-34-300E
L B455-34-350E
Hvy Duty
To 3-9-93 R BS06-34-300
L BS06-34-350
From 3-9-93 R B620-34-300C
L B620-34-350C
18
Joint, Ball¶
To 3-9-93 R/L B455-34-550
From 3-9-93 R/L BTDA-34-550
Bolt, Ball Joint¶ R/L B455-34-349A
¶Included w/Lower Control Arm Assy
19
Bolt, Lower Arm R/L B455-34-113
20
Bar, Stabilizer
FWD
Std Duty B459-34-151
Hvy Duty B461-34-151B
AWD BA1C-34-151A
21
Bushing, Stabilizer
FWD
Std Duty R/L B459-34-156A
Hvy Duty R/L EA03-34-156
AWD R/L B461-28-156A
22
Bracket, Stabilizer
To 6-1-94 R/L B461-34-155A
From 6-1-94 R/L BC1D-34-155B
23
Crossmember, Susp
FWD EA01-34-800G
AWD B528-34-800G
FRONT DRIVE AXLE
Illustration Located in Next Column
1
Shaft Assy, Axle
FWD
1.6L Eng R FZ24-25-400R-0A
L F024-25-600R-0H
1.8L Eng
SOHC Eng R FS17-25-400R-0F
L FS17-25-600R-0F
DOHC 1990-91
Man Trans R F037-25-500R-0B
L F037-25-600R-0D
Auto Trans R F037-25-500R-0B
L F017-25-600R-0E
DOHC 1992-95
Right
To 3-1-92 F037-25-400R-0A
From 3-1-92 F037-25-500R-0B
Left
To 7-1-92 F037-25-600R-0D
From 7-1-92 F037-25-600R-0D
AWD
Man Trans R F051-25-500
L F051-25-600D
Auto Trans R F059-25-500B
L F052-25-600B
2
Joint Set, Outer¶ (b)
FWD
1.6L Eng R F024-22-510A
L F024-22-610A
1.8L Eng
SOHC Eng
To 7-12-93 R FS17-22-510
L FS17-22-610
From 7-12-93 R FS17-22-510C
L FS17-22-610C
DOHC Eng
Man Trans R F037-22-510B
L F037-22-610A
Auto Trans R F037-22-510B
L F017-22-610A
AWD
Man Trans R F051-22-510A
L F051-22-610A
Auto Trans R F059-22-510B
L F052-22-610A
3
Boot, Outer¶ (a) (b)
FWD
1.6L Eng R/L BS10-V9-050-9U
1.8L Eng
SOHC Eng R/L BS05-V9-050
DOHC Eng R/L BS40-V9-050-9U
AWD R/L BS20-V9-050-9U
(a) Included w/Outer Joint Set
4
Joint Set, Inner¶ (b)
FWD
1.6L Eng 90-92 R/L FZ02-22-520A
93-95 R/L FZ02-22-520A
1.8L Eng
SOHC Eng 90-92 R FS17-22-520C
L FS17-22-620
93-95 R FS17-22-520C
L FS17-22-620B
DOHC Eng
1990-92 R F037-22-520
L F017-22-620C
1993-95
Man Trans R F037-22-520
L F037-22-620C
Auto Trans R F037-22-520
L F017-22-620C
AWD R F051-22-520
L F051-22-620C
5
Boot, Inner¶ (a) (b)
FWD
1.6L Eng R/L F061-22-540-9U
1.8L Eng R/L FS17-22-540
AWD R/L G071-22-540
(a) Included w/Inner Joint Set
6
Damper, Dynamic¶ (b)
1.6L Eng F002-25-411B
1.8L Eng F018-25-411
¶Included w/Axle Shaft Assy
7
Shaft Assy, Joint (b)
Man Trans (DOHC Eng) F037-25-700
Auto Trans (DOHC Eng) F047-25-700
8
Seal, Dust Inner¶ (b) F002-25-744
9
Bearing, Ball¶ (b) 9960-68-2063
10
Brkt, Shaft¶ (b)-Serviced w/Joint Shaft Assy
11 Seal, Dust Outer¶ (b) F002-25-742
¶Included w/Joint Shaft Assy

MAZDA 323/PROTEGE 1990-94
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629. 49
madpl1_g01_
Page 49—April 22, 2004—13:29:17—Version Manufacturer
(b) Order by Application
FRONT STEERING LINKAGE/GEAR
MANUAL
1 Gear Assy BR70-32-110A
2
Rod, Inner Tie¶ R/L B455-32-24X
3
Boot, Dust¶ R/L B455-32-125
4
Rack, Gear¶ BR70-32-119
5
Bushing, Shaft¶ BF67-32-114
6
Housing, Gear¶ BR70-32-120
7
Pinion, Gear¶ BR70-32-122
8
Cover, Lever¶ B455-32-112
Rubber, Mounting¶
9 Right B455-32-124
10 Left B455-32-123
Bracket, Mounting¶
11 Right B455-32-134
12 Left B455-32-133
¶Included w/Gear Assy
13
End, Tie Rod R/L 8AB2-32-280
Seal, Dust R/L B455-32-279
POWER
1 Gear Assy
FWD BR71-32-110L
AWD BA1C-32-110C
2
Rod, Inner Tie¶
FWD R B456-32-24X
L B456-32-25X
AWD R B528-32-24X
L B528-32-25X
3
Boot, Dust¶ R/L B456-32-125
4
Rack, Gear¶
FWD BR71-32-119
AWD BA1C-32-119
5
Valve, Gear¶
FWD
To 4-1-93 BR71-32-380
From 4-1-93 BR72-32-380
AWD BA1C-32-380
6
Cover, Lever¶ B456-32-112
Insulator, Gear¶
7Right
FWD B456-32-124
AWD B528-32-124
8Left
FWD B595-32-123
AWD B528-32-123
Bracket, Mounting¶
9 Right
FWD B456-32-134
AWD B528-32-134
10 Left
FWD B456-32-133
AWD B528-32-133
11
Bracket, Hose¶
FWD BR71-32-18X
AWD BA1C-32-18X
12
Pipe, Fluid¶
Right Turn
FWD BR71-32-6G0A
AWD BA1C-32-6G0
13
Pipe, Pressure¶
FWD BR71-32-451
AWD BA1C-32-451
14
Pipe, Fluid¶
Left Turn
FWD BR71-32-481
AWD BA1C-32-481
¶Included w/Gear Assy
15
End, Tie Rod R/L 8AB2-32-280
STEERING PUMP
1 Pump Assy
FWD
1.6L Eng B456-32-600G
1.8L Eng BR71-32-600R-0D
AWD B530-32-600A
2
Pulley, Pump¶-Serviced w/Pump Assy
3 Bracket, Pump¶ B456-32-614
4
Pipe, Suction¶
1.6L Eng B456-32-5M0
1.8L Eng BR71-32-5M0
5
Nipple, Hose¶ B456-32-613A
6
Sensor, Pressure¶ B456-32-230
¶Included w/Pump Assy
7
Bracket, Pump Side B456-32-60YB
8
Bracket, Pump Rear B25D-32-680
9
Reservoir Assy BR71-32-690D
10
Cap, Reservoir¶
To 12-1-91 B01C-32-691
From 12-1-91 G211-32-618A
¶Included w/Reservoir Assy
11
Strainer, Reservoir BR71-32-503A
12
Pipe Assy, Cooling BR71-32-470B
13
Hose, Return Front¶ B456-32-684A
14
Hose, Return Rear¶ B456-32-683A
¶Included w/Cooling Pipe Assy
15
Hose, Suction BR71-32-688
16
Hose Assy B456-32-410F
17
Mount, Hose Assy¶ H267-32-425
¶Included w/Hose Assy
18
Hose, Pressure BR71-32-49YC
19
Hose, Return B456-32-6F0A
STEERING WHEEL/COLUMN
1 Wheel Assy, Steering
w/Cruise Control BR71-32-980B
w/o Cruise Control
Base, GT Model BR70-32-980B
Sport Model B456-32-980A
2
Cover, Steering Wheel¶
w/Cruise Control BR71-32-040
w/o Cruise Control
Base, GT Model B461-32-040
Sport Model B456-32-040
¶Included w/Steering Wheel Assy
3
Cap Assy, Horn
w/Cruise Control BR71-32-800C
w/o Cruise Control
Base Model BR70-32-800
GT Model B461-32-800A
Sport Model B456-32-800
4
Switch, Cruise Control¶ BR70-66-3D1C
¶Included w/Horn Cap Assy
5
Cover Assy, Column Upper
w/Cruise Control BR72-60-220A
w/o Cruise Control BR70-60-220
6
Cover Assy, Column Lower
w/Key Lamp BR70-60-230
w/o Key Lamp BR93-60-231
7
Label, Indicator¶
w/Cruise Control BR70-60-222
w/o Cruise Control BA70-60-222
¶Included w/Column Upper Cover Assy
8
Case, Lamp (a) B456-60-245
9
Lens, Column (a) B456-60-246
(a) Included w/Column Lower Cover Assy
10
Bulb & Socket B456-60-223
11
Ring, Key Cylinder LA01-60-261
12
Switch, Combination
w/Intermittent Wiper
w/Rear Wiper
w/Cruise Control BB7B-66-120
w/o Cruise Control
Standard, DX, SE Model BB7A-66-120
LX Model BB7B-66-120
w/o Rear Wiper
w/Cruise Control BR75-66-120D
w/o Cruise Control BR72-66-120G
w/o Intermittent Wiper BR70-66-120G
Switch, Ignition B455-66-151A
13
Column Assy
w/Tilt Column BR71-32-100G
w/o Tilt Column BR70-32-100E
14
Bracket, Shaft Upper¶ BS07-32-175A
15
Bracket, Shaft Lower¶ BR71-32-140
16
Lever, Adjust¶ B456-32-171
¶Included w/Tilt Steering Column Assy
17
Shaft, Intermediate
FWD BR71-32-090E
AWD BA1C-32-090
18
Cover, Steering Shaft
FWD BR70-32-210E
AWD BA1C-32-210
19
Plate, Strg Upper BR70-32-216
20
Plate, Strg Lower BR70-32-212
21
Cover, Lever BR70-32-215C
ENGINE
1.6L ENG
Pulley, Crankshaft¶ 90-91 B6S7-11-401A
92-95 B6S8-11-401
¶Order by Application
Cover, Timing Belt
Upper B630-10-510B
Lower B630-10-500D
Pan, Eng Oil B366-10-400A
Gasket, Eng Oil Pan R/L B541-10-427-8
Sealant, Eng Oil Pan 8527-77-739
1.8L ENG
Pulley, Crankshaft
1990-91

MAZDA 323/PROTEGE 1990-94
Labor Times Shown are for Replacement with New OEM Undamaged Parts on New Undamaged Vehicles.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629.
50 madpl1_g01_
Page 50—April 22, 2004—13:29:19—Version Manufacturer
ENGINE Cont’d
1.8L ENG Cont’d
SOHC Eng B6S7-11-401A
DOHC Eng BP05-11-401
1992-95
SOHC Eng B6S8-11-401
DOHC Eng B577-11-401
Cover, Timing Belt
SOHC Eng
Upper B630-10-510B
Lower B630-10-500D
DOHC Eng
Upper BJ01-10-510C
Lower B660-10-501E
Center B660-10-521B
Pan, Eng Oil
Man Trans BP01-10-400K
Auto Trans BP02-10-400H
Gasket, Eng Oil Pan R/L B541-10-427-8
Sealant, Eng Oil Pan 8527-77-739
ENGINE MOUNTS
1.6L ENG
1 Mount, Eng Right BR70-39-060B
2
Mount, Eng Left
Man Trans B456-39-040C
Auto Trans B456-39-040C
3
Mount, Eng Front B455-39-050B
Mount, Rear
4 Man Trans B596-39-100B
5 Auto Trans B599-39-100A
6
Brkt, Mount Right B461-39-030C
7
Brkt, Mount Left
Man Trans B455-39-010B
Auto Trans B458-39-010F
Brkt, Mount Front
8 Man Trans B455-39-020A
9 Auto Trans B456-39-020A
10
Brkt, Eng Mount R B455-53-37XC
11
Clip BF67-67-996
12
Crossmember, Susp B455-39-800D
1.8L ENG
1 Mount, Eng Right
FWD B455-39-060E
AWD B528-39-060B
2
Mount, Eng Left
FWD
Man Trans B456-39-040C
Auto Trans B456-39-040C
AWD
Man Trans B528-39-040A
Auto Trans B529-39-040A
3
Mount, Eng Front
FWD B455-39-050B
AWD B455-39-050B
Mount, Rear
FWD
4 Man Trans B455-39-100E
5 Auto Trans B599-39-100A
AWD
Man Trans B528-39-100B
Auto Trans B529-39-100C
6
Brkt, Mount Right BR70-39-030D
7
Brkt, Mount Left
FWD
Man Trans
SOHC Eng B455-39-010B
DOHC Eng BR74-39-010C
Auto Trans B458-39-010F
AWD B528-39-010A
Brkt, Mount Front
Man Trans
8 SOHC Eng B455-39-020A
9 DOHC Eng B456-39-020A
10
Bracket, Support Eng Mtg
Man Trans
To 3-1-94 BR74-39-090
From 3-1-94 BC1F-39-090
11
Brkt, Eng Mount R B455-53-37XC
12
Clip BF67-67-996
13
Crossmember, Susp
FWD B455-39-800D
AWD B528-39-800D
AIR CLEANER
1 Cleaner Assy, Air B6S7-13-320A
2
Cover, Air Cleaner¶ B6S7-13-Z01
3
Element, Cleaner¶ B6S7-13-Z40-9U
¶Included w/Air Cleaner Assy
4
Meter, Air Flow
SOHC B6S7-13-210R-0A
DOHC Eng BP05-13-210R-00
5
Gasket, Meter B6S7-13-211A
6
Joint, Rubber B6S7-13-245A
7
Chamber, Resonance
SOHC Eng BP01-13-195A
DOHC Eng B6S7-13-195B
8
Hose, Air
SOHC Eng BP01-13-221A
DOHC Eng B6S7-13-221B
9
Hose, Resonator Duct B6S7-13-228
10
Duct, Resonance B6S7-13-18XD
11
Duct, Fresh Air
SOHC Eng
1.6L Eng B6S7-13-200C
1.8L Eng BP01-13-200D
DOHC Eng BP01-13-200D
EXHAUST
Manifold, Exhaust
1.6L Eng
w/Calif Emission
1990-92 B61K-13-450C
1993-94 B67K-13-450A
w/o Calif Emission B61K-13-450C
1.8L Eng
SOHC Eng BP01-13-450D
DOHC Eng 90-93 BP05-13-450E
94-95 BPE1-13-450
Pipe, Exhaust Front
1990-91
1.6L Eng B6E5-40-100A
1.8L Eng
SOHC Eng BP02-40-100G
DOHC Eng B684-40-100J
1992-95
1.6L Eng BP04-40-500B
1.8L Eng
SOHC Eng BP04-40-500B
DOHC Eng 92-93 BP04-40-500B
94-95 BP51-40-500
Converter, Catalytic¶
1990-91
1.6L Eng B6Y5-20-600
1.8L Eng
FWD BPY1-20-600A
AWD BP45-20-600B
1992-95
1.6L Eng B6Y5-20-600
1.8L Eng BPY1-20-600A
¶Order by Application
Pipe, Intermediate
1.6L Eng B685-40-300B
1.8L Eng
SOHC Eng
Hatchback BP05-40-300
Sedan BP01-40-300
DOHC Eng B683-40-300C
Muffler w/Pipe
1.6L Eng 90-91 B6E5-40-100A
92-95 B6E5-40-100A
1.8L Eng
SOHC Eng BP02-40-100G
DOHC Eng B684-40-100J
EMISSION SYSTEM
Canister, Vapor BP01-13-970
Bracket, Canister B6S7-13-961
Valve, Solenoid BP01-18-740A
Bracket, Solenoid Valve BP51-18-835A
Rubber, Mounting (2) F285-13-363
Valve, 3 Way¶ BP51-18-741A
¶Order by Application
Valve, Air Control
1.6L Eng B6S7-13-190B
1.8L Eng
Man Trans BP01-13-190A
Auto Trans BP02-13-190A
ELECTRICAL
ALTERNATOR
Alternator Assy
New B366-18-300R-00
Remanufactured¶ B366-18-300R-00
¶Remanufactured Part. Contact Dealer for Core Charge & Exchange
Information
Pulley, Alternator (a) B366-18-W10
(a) Included w/Alternator Assy
Strap, Alternator BP01-18-361
Belt, Drive
1.6L Eng B6S7-18-381B-9U
1.8L Eng B61H-18-381A-9U
BATTERY
Battery¶ 0000-80-026R-WB
¶Order by Application
Cable, Battery
Positive N.A.
Negative N.A.
HORN
Horn
1990-91 FB03-66-790A
1992-95
To 8-1-92 B596-66-790A
From 8-1-92 B596-66-790A
IGNITION
Module, Main Computer¶ (a)
Man Trans BP10-18-881R
Auto Trans BPB2-18-881R
¶Remanufactured Part. Contact Dealer for Core Charge & Exchange
Information
(a) Order by Application
Coil, Ignition B6S7-18-10XA
WINDSHIELD
1 Glass, Windshield
Mazda

MAZDA 323/PROTEGE 1990-94
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629. 51
madpl1_g01_
Page 51—April 22, 2004—13:29:20—Version Manufacturer
Hatchback
Clear B467-63-901A
Blue Tint
To 2-4-93 BR93-63-901A
From 2-4-93 B469-63-901A
Sedan
Clear B457-63-901A
Blue Tint B457-63-901A
2
Dam, Windshield 90-91 GT8T-50-894
92-95 B481-50-894
3
Stopper, Glass BR70-50-G30
Spacer, Glass
Black R/L B455-50-891A
White R/L EA01-50-891A
Moulding, Reveal
4 Hatchback B4Y7-50-601A
5 Sedan BW5B-50-601A
6
Retainer, Moulding
Hatchback BTE4-50-6B1
Sedan BTE4-50-6B1
Moulding, Inside Garnish
Hatchback
Gray R BR93-68-160E-06
L BR93-68-170E-06
Gray/Taupe R BR93-68-160E-35
L BR93-68-170E-35
Sedan
Gray R BR70-68-160D-06
L BR70-68-170D-06
Gray/Taupe R BR70-68-160D-35
L BR70-68-170D-35
Mirror, Rear View
Hatchback B460-69-220A
Sedan B461-69-220
Visor, Sun
w/Mirror
To 2-1-94
Gray R BR76-69-270B-06
L BR77-69-320B-06
Gray/Taupe R BR76-69-270A-39
L BR76-69-320A-39
From 2-1-94
Gray R BR76-69-270B-06
L BR77-69-320B-06
Gray/Taupe R BR76-69-270A-39
L BR77-69-320B-36
w/o Mirror
To 2-1-94
Gray R BR74-69-270B-06
L BR76-69-320B-06
Gray/Taupe R BR74-69-270A-39
L BR76-69-320A-39
From 2-1-94
Gray R BR74-69-270B-06
L BR76-69-320B-06
Gray/Taupe R BR74-69-270B-36
L BR76-69-320B-36
WIPER SYSTEM
1 Blade Assy, Wiper R NC11-67-330-9U
L BR70-67-330C
Insert, Wiper¶ R B460-67-333
L D040-67-333-9U
¶Included w/Wiper Blade Assy
2
Arm, Wiper R BR71-67-321
L BR70-67-321
3
Cover, Wiper Arm R/L LA01-67-395C
4
Link Assy, Wiper BR71-67-360
5
Arm, Wiper Link¶ R BR70-67-362
L BS34-67-361
6
Shaft, Drive¶ R/L BR71-67-363-4
¶Included w/Wiper Link Assy
7
Motor, Wiper
Std Duty BR70-67-340
Hvy Duty BR71-67-340
8
Reservoir & Pump Assy
FWD
w/Level Switch BR72-67-480C
w/o Level Switch B455-67-480A
AWD BR70-67-480B
9
Tank, Washer¶
FWD
w/Level Switch BR72-67-481
w/o Level Switch B455-67-481A
AWD BR70-67-481A
10
Cap, Tank¶ B455-67-483
11
Switch, Level¶ BR72-67-488
12
Pump, Washer¶ S084-76-672
¶Included w/Reservoir & Pump Assy
Nozzle, Spray R/L N.A.
COWL & DASH
1 Grille Assy, Cowl BR70-50-790E
2
Protector, Grille¶ B455-50-794A
3
Cap¶ (5) B455-50-796A
¶Included w/Cowl Grille Assy
4
Plate, Baffle R BR70-56-191D
L BR70-56-192B
5
Panel, Cowl Front B455-70-62YD
6
Panel, Dash Upper BR70-53-510J
7
Panel, Dash Lower
FWD BR70-53-400G
AWD BA1C-53-400B
INSTRUMENT PANEL
1 Panel, Instrument¶ BR70-60-350D-48
2
Garnish, Upper¶ BR70-60-720B-48
3
Pad Assy, Lower¶
To 11-1-92 R BR70-64-260-48
L BR70-64-280-48
From 11-1-92 R BR70-64-260-48
L BR70-64-280-48
4
Louver, Lower Pad¶ (a) FB01-64-850
¶Blue listed, Order by Application
19 Red; 32 Gray/Taupe; 48 Blue; 65 Off Black
(a) Included w/Right Lower Pad Assy
5
Crossmember, Inst Panel BR70-60-420C
6
Reinf, Inst Panel BR70-60-430
7
Protector, Knee
FWD BR70-60-K80A
AWD
To 5-8-90 BR70-60-K80A
From 5-8-90 BR70-60-K80A
8
Cover, Under BR70-64-520A
9
Brkt, Inst Panel R BR70-60-56X
L BR70-60-58X
10
Frame, Upper BR70-60-610
11
Frame, Lower BR70-60-620
12
Panel Assy, Center Lower¶ BR70-64-270-48
¶Blue listed, Order by Application
19 Red; 32 Gray/Taupe; 48 Blue; 65 Off Black
13
Lens, Ashtray (a) BR70-55-215
(a) Included w/Lower Center Panel Assy
14
Glove Box Assy¶ BR70-64-030A-48
15
Glove Box, Lid¶ (a) BR70-64-041-48
¶Blue listed, Order by Application
19 Red; 32 Gray-Taupe; 48 Blue; 65 Off Black
16
Glove Box (a) BR70-64-161A
Hinge, Glove Box (a) R/L B455-64-071-2
(a) Included w/Glove Box Assy
17
Cover, Glove Box BR70-64-110
Radio Assy¶ 0000-81-601B
¶Order by Application
Speaker, Radio-See Front Door Section
CENTER CONSOLE
Console Assy, Front
Man Trans¶
1 w/Cup Holder B457-64-320D-48
2 w/o Cup Holder B455-64-320-48
Auto Trans¶
3 w/Cup Holder B458-64-320D-48
4 w/o Cup Holder B455-64-321-48
5
Box, Console¶ (a) B457-64-360C-48
¶Blue listed, Order by Application
19 Red; 32 Gray/Taupe; 48 Blue; 65 Off Black
6
Boot, Change (a) B455-64-330
7
Bracket, Front Console (a)
w/Cup Holder B457-64-31X
w/o Cup Holder
Man Trans BW3F-64-316
Auto Trans R B457-64-31Y
L B456-64-316
(a) Included w/Front Console Assy
8
Console, Rear¶ BR70-64-420B-48
9
Ashtray¶ BR70-64-660A-48
¶Blue listed, Order by Application
19 Red; 32 Gray/Taupe; 48 Blue; 65 Off Black
ROCKER/PILLARS/FLOOR
ROCKER/PILLARS
HATCHBACK
1 Pillar Assy, Hinge
Outer R BR93-70-210
L BR93-71-210
2
Panel Assy, Cowl Side¶ R BR70-70-020
L B455-71-020
3
Bracket, Fender¶ (a) R/L B092-70-070A
¶Included w/Outer Hinge Pillar Assy
(a) Included w/Cowl Side Panel Assy
4
Moulding Set, Pillar R B467-50-8B0A
L B467-50-8C0A
5
Moulding, Upper End¶ R B467-50-8B4
L B467-50-8C4
6
Protector, Mldg Outer¶ R B467-50-8B3A
L B467-50-8C3A
7
Protector, Mldg Inner¶ R/L B467-50-8B2B
¶Included w/Pillar Moulding Set
8
Panel, Cowl Trim (a) R BR70-68-370A-32
L BR70-68-390B-32
(a) Gray/Taupe listed, Order by Application

MAZDA 323/PROTEGE 1990-94
Labor Times Shown are for Replacement with New OEM Undamaged Parts on New Undamaged Vehicles.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629.
52 madpl1_g01_
Page 52—April 22, 2004—13:29:22—Version Manufacturer
ROCKER/PILLARS/FLOOR Cont’d
ROCKER/PILLARS
HATCHBACK Cont’d
Mldg, Inside Garnish
9 USA-See Windshield Section
10 Canada-See Quarter Panel Section
19 Red; 32, 35 Gray/Taupe; 48 Blue; 65 Off Black
11
Pillar, Hinge Inner R B467-70-24X
L B467-71-24X
12
Panel, Rocker Outer R B467-70-270C
L B467-71-270C
ROCKER/PILLARS
SEDAN
Pillar Assy, Hinge
1 Outer R BR70-70-210
L BR70-71-210
2
Panel Assy, Cowl Side¶ R BR70-70-020
L B455-71-020
3
Bracket, Fender¶ (a) R/L B092-70-070A
¶Included w/Outer Hinge Pillar Assy
(a) Included w/Cowl Side Panel Assy
4
Panel, Cowl Trim (b) R BR70-68-370A-48
L BR70-68-390B-48
(b) Blue listed, Order by Application
19 Red; 32 Gray/Taupe; 48 Blue; 65 Off Black
5
Pillar, Hinge Inner R B455-70-24X
L B455-71-24X
Pillar, Center Outer-See Quarter Panel Section
6 Pillar, Center Inner R B455-70-080C
L B455-71-080C
Mldg, Inside Garnish
Upper
7 USA-See Windshield Section
8 Canada R/L N.A.
9 Lower¶ R BR70-68-220A-32
L BR70-68-230A-32
¶Gray/Taupe listed, Order by Application
19 Red; 32, 35 Gray/Taupe; 48 Blue; 65 Off Black
10
Panel, Rocker Outer R B455-70-270B
L B455-71-270B
FLOOR
1 Panel, Rocker Inner R BR70-53-950D
L BR71-54-950
Plate, Scuff¶
Hatchback R B499-68-710B-48
L B499-68-720B-48
Sedan
Front R B455-68-710B-48
L B455-68-720B-48
Rear R B455-68-730C-48
L B455-68-740C-48
¶Blue listed, Order by Application
19 Red; 32 Gray/Taupe; 48 Blue; 65 Off Black
2
Pan, Front Floor
FWD BR70-53-600D
AWD BA1C-53-600B
3
Member, Front Side Rear
FWD R BR70-53-660C
L BR70-54-660B
AWD R/L BA1C-53-660C
SEAT
1 Seat Assy, Front¶
Hatchback
Base Model R BB7A-57-100B-65
L BB7A-57-150B-65
DX Model R BB7H-57-100B-65
L BB7H-57-150B-65
SE Model
w/25th Anniversary Pkg
Right BC0D-57-100A-64
Left BC0C-57-150A-64
w/o 25th Anniversary Pkg
Right BB7H-57-100B-65
Left BB7H-57-150B-65
LX R BC0D-57-100A-64
L BC0C-57-150A-64
Sedan
DX, SE Model R BB7C-57-100-65
L BB7C-57-150E-65
GT Model R BB7R-57-100D-64
L BB7R-57-150D-64
LX Model R BB7D-57-100E-64
L BB7D-57-150-64
¶Off Black listed, Order by Application
32 Gray/Taupe; 48 Blue; 64, 65 Off Black
2
Adjuster, Seat (a)
Passenger Side R BR72-88-102A
L BR95-88-103B
Driver Side R BR72-88-152B
L BR72-88-153A
3
Wire¶ (a) R/L B455-88-026
4
Cushion, Front Seat¶ (a)
Hatchback
Base Model R BB7A-88-110-65
L BB7A-88-160-65
DX Model R BB7H-88-110-65
L BB7H-88-160-65
SE Model
w/25th Anniversary Pkg
Right BC0C-88-110-64
Left BB7E-88-160-64
w/o 25th Anniversary Pkg
Right BB7H-88-110-65
Left BB7H-88-160-65
LX Model R/L N.A.
Sedan
DX, SE Model R BB7C-88-110-65
L BB7C-88-160-65
GT Model R BB7R-88-110-64
L BB7R-88-160-64
LX Model R BB7D-88-110-64
L BB7D-88-160-64
5
Back Assy, Front Seat¶ (a)
Hatchback
Base Model R BB7A-88-130A-65
L BB7A-88-180A-65
DX Model R BB7H-88-130A-65
L BB7H-88-180A-65
SE Model
w/25th Anniversary Pkg
Right BC0D-88-130A-64
Left BC0C-88-180A-64
w/o 25th Anniversary Pkg
Right BB7H-88-130A-65
Left BB7H-88-180A-65
LX Model R/L N.A.
Sedan
DX, SE Model R BB7C-88-130A-65
L BB7C-88-180A-65
GT Model R BB7R-88-130B-64
L BB7R-88-180B-64
LX Model R BB7D-88-130C-64
L BB7D-88-180-64
¶Off Black listed, Order by Application
32 Gray/Taupe; 48 Blue; 64, 65 Off Black
6
Adjuster, Recline (a) (b)
Hatchback R BR93-88-101
L BR70-88-151
Sedan R BR70-88-101
L BR70-88-151
(b) Included w/Front Seat Back Assy
7
Cover, Adjuster¶ (a) R BR70-88-127B-64
L BR70-88-177B-64
8
Knob, Adjuster¶ (a) R B001-88-081-65
L B001-88-091-65
9
Headrest¶ (a)
Hatchback
Base, DX Model R/L BB7A-88-140-65
LX, SE Model R/L BB7H-88-140-65
Sedan
DX, SE Model R/L B618-88-140-65
GT Model R/L BR73-88-140B-64
LX Model R/L BB7E-88-140-64
¶Off Black listed, Order by Application
32 Gray/Taupe; 48 Blue; 64, 65 Off Black
(a) Included w/Front Seat Assy
10
Cover, Adjuster
Passenger Side R B455-57-051B
L B455-57-052C
Driver Side R B455-57-053C
L B455-57-054B
11
Bracket, Front Seat R B455-57-580A
L B455-57-590A
REAR SEAT
SEAT BELTS
FRONT
USA
1 Belt, Outer Seat¶
Hatchback R BR93-57-930G
L BR70-57-990H
Sedan R BR70-57-930H
L BR70-57-990H
2
Retractor, Center¶
Hatchback
Blue BR70-57-620A-48
Gray/Taupe BR70-57-620A-32
Off Black BR70-57-620A-65
Sedan
Blue BR70-57-920F-48
Gray/Taupe BR70-57-920F-32
Off Black BR70-57-920F-65
3
Belt, Lap¶
Hatchback
Blue R BR70-57-940D-48
L BR70-57-980D-48
Gray/Taupe R BR70-57-940D-32
L BR70-57-980D-32
Off Black R BR70-57-940D-65
L BR70-57-980D-65
Sedan
Blue R BR70-57-940C-48
L BR70-57-980D-48
Gray/Taupe R BR70-57-940D-32
L BR70-57-980D-32
Off Black R BR70-57-940D-65
L BR70-57-980D-65
4
Buckle, Belt¶
Blue R BR70-57-620A-48
L BR70-57-680A-48
Gray Taupe R BR70-57-620A-32
L BR70-57-680A-32
Off Black R BR70-57-620A-65
L BR70-57-680A-65
¶Order by Application
5
Bracket, Seat Belt R/L BR70-57-925A
6
Handle, Emergency FC01-57-999A
7
Control Unit, Passive BR70-67-780D
FRONT
CANADA
Illustration Located in Next Column
Belt, Seat

MAZDA 323/PROTEGE 1990-94
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629. 53
madpl1_g01_
Page 53—April 22, 2004—13:29:23—Version Manufacturer
1 Retractor Side
Blue R/L N.A.
Gray/Taupe R/L N.A.
Off Black R/L N.A.
2 Buckle Side
Blue R/L N.A.
Gray/Taupe R/L N.A.
Off Black R/L N.A.
3
Plate, Seat Belt R/L N.A.
REAR
HATCHBACK
1 Belt, Seat Outer
Blue R BR93-57-710B-48
L BR93-57-770B-48
Gray/Taupe R BR93-57-710B-32
L BR93-57-770B-32
Off Black R BR93-57-710B-65
L BR93-57-770B-65
2
Belt, Seat Center
Blue BR70-57-740A-48
Gray/Taupe BR70-57-740A-32
Off Black BR70-57-740A-65
REAR
SEDAN
1 Belt, Seat Outer
Blue R BR70-57-710B-48
L BR70-57-770B-48
Gray/Taupe R BR70-57-710B-32
L BR70-57-770B-32
Off Black R BR70-57-710B-65
L BR70-57-770B-65
2
Belt, Seat Center
Blue BR70-57-740A-48
Gray/Taupe BR70-57-740A-32
Off Black BR70-57-740A-65
3
Cover, Anchor
Blue R/L BR70-57-631-48
Gray/Taupe R/L BR70-57-631-32
Off Black R/L BR70-57-631-65
FRONT DOOR
SHEET METAL
Shell Assy, Door
Hatchback R BR93-58-020T
L BR93-59-020T
Sedan R BS06-58-020K
L BS06-59-020K
Panel, Door Repair¶
Hatchback R B468-58-030C
L B468-59-030C
Sedan R B455-58-031B
L B455-59-031B
¶Included w/Door Shell Assy
EXTERIOR TRIM
1 Moulding, Belt
Hatchback R B468-50-640A
L B468-50-650A
Sedan R B456-50-640
L B456-50-650
2
Moulding, Side
Adhesive
Hatchback R B4Y7-50-682
L B4Y7-50-692
Sedan
USA R B4Y5-50-682
L B4Y5-50-692
Canada R/L N.A.
Mirror, Rear View
3 Manual
Hatchback R BR94-69-110B
L BR94-69-170B
Sedan R BR72-69-110B
L BR72-69-170B
4Power¶
Hatchback
To 4-1-93 R BR96-69-120C-UF
L BR96-69-180C-UF
From 4-1-93 R BR96-69-120C-UF
L BR96-69-180C-UF
Sedan R BR74-69-120C-UF
L BR74-69-180C-UF
¶Clear White listed, Order by Application
DV Bay Blue; DX Honey Blue;
E9 Deep Purple; FZ Herbie Green;
J4 Passion Rose; PZ Brilliant Black;
SQ Blaze Red; SS Coral Red
UF Clear White; Z1 Bluish Green M;
IH Steel Gray MC; IS Niagara Silver MC;
3L Silver Stone Met; 4R Passion Yellow Mica
4Z Silent Silver; 5D Harbor Blue M; 5S Neat Green MC;
6C Mighty Gray; 6L Graceful Red MC;
6M Elegant Beige; 6N Current Blue MC;
6S Excess Green; 6V Raspberry Metallic
6W Laguna Blue M; 6Y Sea Mist M
5
Garnish, Mirror
Manual¶ R B472-69-111B
L B472-69-171B
Power R B471-69-111B
L B471-69-171B
Knob, Mirror Door¶
6 Outer R/L D062-69-1B6
7 Inner R/L D062-69-1B5
¶Order by Application
8
Wire, Remote Control R/L B463-69-108
INTERIOR TRIM
Illustration Located in Next Column
1
Panel Assy, Trim¶
Hatchback
Base Model
Gray Taupe R BR93-68-420E-32
L BR93-68-450E-32
Off Black R BR93-68-420E-65
L BR93-68-450E-65
SE Model
w/25th Anniversary Pkg
Gray/Taupe R BC3H-68-420-32
L BC3H-68-450D-32
Off Black R BC3H-68-420-65
L BC3H-68-450-65
w/o 25th Anniversary Pkg
Gray/Taupe R BR94-68-420F-32
L BR94-68-450F-32
Off Black R BR94-68-420F-65
L BR94-68-450F-65
Sedan
GT Model
Off Black R BB7F-68-420J-65
L BB7F-68-450H-65
SE Model
Gray/Taupe R BR71-68-420E-32
L BR71-68-450E-32
Off Black R BR71-68-420E-65
L BR71-68-450E-65
LX Model
Blue R BB1C-68-420H-48
L BB1C-68-450K-48
Gray/Taupe R BC3M-68-420C-32
L BC3M-68-450C-32
Off Black R BR75-68-420C-65
L BR75-68-450C-65
¶Order by Application
32 Gray Taupe; 48 Blue; 65 Off Black
2
Weatherstrip, Inner (b)
Hatchback R B467-58-821
L B467-59-821
Sedan R B455-58-821
L B455-59-821
3
Cover, Door Lock¶ (b) R/L B101-68-421-48
4
Pocket, Door¶ (b)
Hatchback
Canada R B471-68-4C1-48
L B471-68-4N1-48
USA R B455-68-4C1A-48
L B455-68-4N1A-48
Sedan
SE Model R B455-68-4C1A-48
L B455-68-4N1A-48
GT, LX Model R B461-68-4C1-48
L B461-68-4N1-48
5
Grip, Assist¶ (b)
Base, SE Model R B455-69-460B
L B455-69-470B
GT, LX Model R B461-69-461A
L B461-69-471A
6
Grille, Speaker¶ (b)
Blue R/L BR70-68-4H0A-48
Gray/Taupe R/L BR70-68-4H0A-32
Off Black R/L BR70-68-4H0A-65
¶Blue listed, Order by Application
19 Red; 32 Gray/Taupe; 48 Blue; 65 Off Black
(b) Included w/Trim Panel Assy
Speaker, Radio R/L BR73-66-96X
7
Armrest¶ R UB40-69-370-48
L UB40-69-390-48
¶Blue listed, Order by Application
19 Red; 32 Gray Taupe; 48 Blue; 65 Off Black
HARDWARE
1 Latch
Hatchback
Manual R BR93-58-310A
L BR93-59-310A
Power R BR93-58-310B
L BR93-59-310C
Sedan

MAZDA 323/PROTEGE 1990-94
Labor Times Shown are for Replacement with New OEM Undamaged Parts on New Undamaged Vehicles.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629.
54 madpl1_g01_
Page 54—April 22, 2004—13:29:25—Version Manufacturer
FRONT DOOR Cont’d
HARDWARE Cont’d
Manual R BR70-58-310A
L BR70-59-310A
Power R BR71-58-310B
L BR71-59-310B
2
Striker R/L B092-58-361A
3
Knob Assy, Door Lock¶
Hatchback R B467-58-390B-48
L B467-59-390A-48
Sedan R B455-58-390B-48
L B455-59-390B-48
4
Knob, Door Lock¶ (a) R/L B455-58-316B-48
¶Blue listed, Order by Application
19 Red; 32 Gray Taupe; 48 Blue; 65 Off Black
(a) Included w/Door Lock Knob Assy
5
Control, Lock
Hatchback 90-91 R/L BF67-58-350
92-95 R/L BR94-58-350
Sedan 90 R/L BF67-58-350
91-95 R/L BR71-58-350B
Cylinder w/Key R BR70-76-210B
L BR70-76-220B
6
Handle, Outside
Black R B455-58-410E
L B455-59-410E
Body Color¶ R B459-58-410D-SQ
L B459-59-410D-SQ
¶Blaze Red listed, Order by Application
DV Bay Blue; DX Honey Blue; E9 Deep Purple;
FZ Herbie Green; GU Shade Green;
PZ Brilliant Black; SQ Blaze Red;
SS Coral Red; UF Clear White;
Z1 Bluish Green M; 1H Steel Gray MC;
1S Niagara Silver MC; 3L Silver Stone M;
4R Passion Yellow Mica; 4Z Silent Silver;
5D Harbor Blue M; 5L Whisper Green;
5S Neat Green; 6C Mighty Gray;
6L Graceful Red; 6M Elegant Beige;
6N Current Blue MC; 6S Exceed Green M;
6V Raspberry Metallic; 6W Laguna Blue M
7
Handle, Inside R/L B455-58-330B-00
8
Hinge, Upper R B455-59-240A
L B455-58-240A
9
Hinge, Lower R B455-58-240A
L B455-59-240A
10
Shim, Hinge (2/Side) R/L B092-58-201A
11
Check, Door
Hatchback R/L B499-58-270B
Sedan
To 10-1-94 R/L B455-58-270B
From 10-1-94 R/L B607-58-270
Weatherstrip, Door
Hatchback R BS20-58-760E
L BS20-59-760E
Sedan R B455-58-760F
L B455-59-760F
Welt, Seaming¶
Hatchback R B467-68-911A-48
L B467-68-912A-48
Sedan R B455-68-911C-48
L B455-68-912C-48
¶Blue listed, Order by Application
19 Red; 23 Gray Taupe; 48 Blue; 65 Off Black
GLASS & PARTS
1 Glass, Front Door
Mazda
Hatchback
Clear R B467-58-511B
L B467-59-511B
Blue Tint R B469-58-511B
L B469-59-511B
Sedan
Clear R B455-58-511
L B455-59-511
Blue Tint R B457-58-511
L B457-59-511
2
Channel Assy, Glass
Hatchback R B467-58-60XA
L B467-59-60XA
Sedan R B455-58-605
L B455-59-605
3
Adjuster, Glass¶ R/L BS06-58-606
¶Included w/Glass Channel Assy
4
Regulator, Manual R B455-58-560A
L B455-59-560A
5
Handle, Regulator
To 8-1-93 R/L B092-58-580-00
From 8-1-93 R/L S084-58-580A-00
6
Escutcheon, Handle R/L B092-58-863A
7
Regulator Assy, Power R B456-58-560C
L B456-59-560C
8
Motor, Regulator¶ R B456-59-560C
L B500-59-58XA
¶Included w/Power Regulator Assy
REAR DOOR
SHEET METAL
Shell Assy, Door R BR70-72-020W
L BR70-73-020W
Panel, Door Repair¶ R B455-72-031B
L B455-73-031B
¶Included w/Door Shell Assy
EXTERIOR TRIM
1 Moulding, Belt R B456-50-660A
L B456-50-670A
2
Moulding, Side
Adhesive
USA R B4Y5-50-683
L B4Y5-50-693
Canada R/L N.A.
INTERIOR TRIM
1 Panel Assy, Trim¶
SE Model
Gray/Taupe R BR71-68-520B-32
L BR71-68-550B-32
Off Black R BR71-68-520B-65
L BR71-68-550B-65
GT Model
Off Black R BB7F-68-520B-65
L BB7F-68-550B-65
LX Model
Blue R B621-68-520D-48
L B621-68-550C-48
Gray/Taupe R B621-68-520C-32
L B621-68-550C-32
Off Black R B621-68-520D-65
L B621-68-550E-65
¶Order by Application
32 Gray Taupe; 48 Blue; 65 Off Black
2
W/Strip, Inner (a) R B455-72-821
L B455-73-821
3
Vessel, Inner Lock¶ (a) R/L B101-68-421-48
4
Handle, Pull¶ (a)
LX Model R/L B461-68-D71A-48
(a) Included w/Trim Panel Assy
5
Armrest¶
SE Model R UB40-69-370-48
L UB40-69-390-48
¶Blue listed, Order by Application
19 Red; 32 Gray Taupe; 48 Blue; 65 Off Black
6
Bracket, Pull Handle
LX Model R/L B110-68-525
HARDWARE
1 Latch Assy, Door
Manual R B455-72-310B
L B455-73-310B
Power R B456-72-310C
L B456-73-310B
2
Striker-See Quarter Panel Section
3 Knob Assy, Door Lock¶ R/L B455-72-390C-48
4
Knob, Door Lock¶ (a) R/L B455-58-316B-48
¶Blue listed, Order by Application
(a) Included w/Door Lock Knob Assy
19 Red; 32 Gray Taupe; 48 Blue; 65 Off Black
5
Control, Lock R BTAC-72-350
L B456-73-350B
6
Handle, Outside
Black R B455-72-410E
L B455-73-410E
Body Color¶ R B459-72-410D-SQ
L B459-73-410D-SQ
¶Blaze Red listed, Order by Application
DV Bay Blue; DX Honey Blue; E9 Deep Purple;
FZ Herbie Green; GU Shade Green;
PZ Brilliant Black; SQ Blaze Red;
SS Coral Red; UF Clear White;
Z1 Bluish Green M; 1H Steel Gray MC;
1S Niagara Silver MC; 3L Silver Stone M;
4R Passion Yellow Mica; 4Z Silent Silver;
5D Harbor Blue M; 5L Whisper Green;
5S Neat Green; 6C Mighty Gray;
6L Graceful Red; 6M Elegant Beige;
6N Current Blue MC; 6S Exceed Green M;
6V Raspberry Metallic; 6W Laguna Blue M
7
Handle, Inside R/L B455-58-330B-00
8
Hinge, Upper R B455-72-210A
L B455-73-210A
9
Hinge, Lower R B455-72-240A
L B455-73-240A
10
Shim, Hinge Upper R/L B455-72-231A
11
Shim, Hinge Lower R/L B092-72-231A
12
Check, Door
To 10-1-94 R/L B455-72-270B
From 10-1-94 R/L B607-72-270
13
Stopper, Bumper Upper R BR70-72-916C
L BR70-73-916C
14
Stopper, Bumper Lower R BR70-72-915C
L BR70-73-915C
W/Strip, Door R B455-72-760G
L B455-73-760G
Welt, Seaming¶ R B455-68-913A-48
L B455-68-914A-48
¶Blue listed, Order by Application
19 Red; 32 Gray Taupe; 48 Blue; 65 Off Black
GLASS & PARTS
Illustration Located in Next Column
1
Glass, Rear Door
Mazda
Clear R B455-72-511A
L B455-73-511A
Blue Tint R B457-72-511A
L B457-73-511A
2
Glass, Rear Vent
Mazda
Clear R B455-72-661
L B455-73-661
Blue Tint R B457-72-661
L B457-73-661
3
Run, Upper R B455-72-605
L B455-73-605
4
Bar, Division R B455-72-602C
L B455-73-602C
Protector, Bar

MAZDA 323/PROTEGE 1990-94
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629. 55
madpl1_g01_
Page 55—April 22, 2004—13:29:26—Version Manufacturer
5 Outer R B455-72-608
L B455-73-608
6 Inner R B456-72-608
L B456-73-608
7
W/Strip, Vent Glass R B455-72-651A
L B455-73-651A
8
Bracket, Lift R/L B268-72-520
9
Seal, Bracket (2/Side) R/L S001-58-502
10
Regulator, Manual R B455-72-560C
L B455-73-560C
11
Handle, Regulator
To 8-2-93 R/L B092-58-580-00
From 8-2-93 R/L S084-58-580A-00
12
Escutcheon, Handle R/L B092-58-863A
13
Regulator Assy, Power R B457-72-58X
L B456-73-58X
14
Motor, Regulator¶
To 8-1-91 R B457-72-58X
L B456-73-58X
From 8-1-91 R B457-72-58X
L B456-73-58X
15
Base, Regulator¶ R B456-72-59X
L B456-73-58X
¶Included w/Power Regulator Assy
ROOF
SHEET METAL
1 Panel, Roof
w/Sunroof B4X2-70-600
w/o Sunroof
Hatchback B4X7-70-600A
Sedan B4Y5-70-600
Antenna, Radio 0000-81-0730
Cover, Antenna Opng BR71-66-9A0
2
Moulding, Roof
Hatchback R B4Y7-50-9H0A
L B4Y7-50-9L0A
Sedan R BW5B-50-9H0A
L BW5B-50-9L0A
3
Panel, Front Header
Hatchback B467-70-640A
Sedan B455-70-640A
4
Panel, Rear Header
Hatchback B467-70-700B
Sedan B455-70-701
5
Bow, Reinforcement
w/o Sunroof
Hatchback B467-70-661A
Sedan B455-70-661B
6
Reinf, Sunroof U012-70-630
7
Bracket, Sunroof R B462-70-620A
L B462-71-620A
8
Rail, Roof Inner
Hatchback R B467-70-050
L B467-71-050
Sedan R B455-70-050B
L B455-71-050B
INTERIOR TRIM
HATCHBACK
1 Headliner Assy
To 8-2-93
Gray BR94-68-030C-05
Gray/Taupe BR94-68-030C-34
From 8-2-93
Gray BR94-68-030C-05
Gray/Taupe BR94-68-030C-05
2
Insulator, Roof¶ B481-68-022
¶Included w/Headliner Assy
3
Mldg, Inside Garnish
Gray B467-68-140-06
Gray/Taupe B467-68-140-35
INTERIOR TRIM
SEDAN
1 Headliner
w/Sunroof
Gray BR72-68-030C-05
Gray/Taupe BR72-68-030C-34
w/o Sunroof
To 8-2-93
Gray B456-68-030F-08
Gray/Taupe BR71-68-030F-34
From 8-2-93
Gray BR71-68-030F-08
Gray/Taupe BR71-68-030F-34
2
Bracket, Headliner R BR70-68-06XB
L BR70-68-06YB
3
Mldg, Inside Garnish
Gray B455-68-140B-06
Gray/Taupe B455-68-140B-35
OVERHEAD CONSOLE
1 Console Assy, Overhead
Gray B462-69-970-06
Gray/Taupe B462-69-970-35
2
Cover, Console¶
Gray B462-69-972-06
Gray/Taupe B462-69-972-35
¶Included w/Overhead Console Assy
SUNROOF
1 Panel, Steel Sliding BR71-69-810A
2
W/Strip, Steel Panel BR71-69-825A
3
Trim, Steel Sunroof¶ BR71-69-960-06
¶Gray listed, Order by Application
06 Gray; 39 Gray/Taupe
4
Panel, Glass Sliding B462-69-810
5
Shade, Glass Sunroof
Gray B462-69-891-06
Gray/Taupe B462-69-891-39
6
Welt, Seaming
Gray B096-69-915A-06
Gray/Taupe B096-69-915A-35
7
Rail, Drip B462-69-867
8
Panel, Lower B096-69-838B
Cover, Lower Panel
9 Side R B098-69-861
L B098-69-862-00
10 Center B098-69-863A
11
Guide, Rail Front R B096-69-839
L B096-69-841
12
Guide, Rail Side Front
Steel Sunroof R B096-69-832A
L B096-69-833A
Glass Sunroof R B098-69-832A
L B098-69-833A
13
Guide, Rail Side Rear
Steel Sunroof R/L BR71-69-864-5
Glass Sunroof R/L B462-69-864-5
14
Cover, Guide Rail
Steel Sunroof R B096-69-834A
L B096-69-835A
Glass Sunroof R B098-69-834B
L B098-69-835B
15
Plate Set R B462-69-855
L B462-69-856
16
Connector, Link R/L B096-69-867
17
Stopper, Sliding Panel R/L B096-69-852
18
Frame, Sliding Roof B462-69-840
19
Motor, Sliding Roof B462-69-848A
20
Bracket, Drive Unit B462-69-861
21
Deflector
Steel Sunroof BR71-69-881
Glass Sunroof B462-69-881
22
Link, Deflector R B096-69-846B
L B096-69-847B
BACK WINDOW
Illustration Located in Next Column
1
Glass, Back Window
Mazda
USA
Clear B455-63-931B
Blue Tint B457-63-930B
Canada N.A.
2
Spacer, Glass R/L GJ51-50-891
3
Dam, Back Window B456-50-899A
4
Mldg, Reveal Upper 8AB1-50-611
5
Moulding Assy, Reveal Side R 8AB1-50-612
L 8AB1-50-613

MAZDA 323/PROTEGE 1990-94
Labor Times Shown are for Replacement with New OEM Undamaged Parts on New Undamaged Vehicles.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629.
56 madpl1_g01_
Page 56—April 22, 2004—13:29:28—Version Manufacturer
BACK WINDOW Cont’d
6 Joint, Upper¶ R/L B455-50-615-6
7
Protector, Mldg¶ (a) R B455-50-6H6
L B455-50-6H7
8
Protector, Center¶ (a) B455-50-6H3
9
Joint, Lower¶ (a) B455-50-617
¶Included w/Side Reveal Moulding Assy
(a) Included w/Right Side Reveal Moulding Assy
QUARTER PANEL
SHEET METAL
HATCHBACK
1 Panel, Quarter Outer R B467-70-401B
L B4X7-71-400B
Door, Fuel
w/Door Opener B468-42-410B
w/o Door Opener B467-42-410B
Cylinder & Key BR70-76-240B
2
Panel Assy, Inner R BR93-70-100
L BR93-71-100
3
Panel, Inner¶ R BR93-70-10X
L BR93-71-10X
4
Panel, Wheelhouse¶ R B455-70-150H
L B607-71-150
5
Plate, Joint Front¶ R B455-70-152
L B455-71-152
6
Plate, Joint Rear¶ R/L B467-70-153
7
Pillar, Rear Inner¶ R B467-70-113
L B467-71-113
¶Included w/Inner Panel Assy
8
Reinf, Lock Pillar R B4X7-70-420C
L B4X7-71-420C
9
Plate, Lock Pillar R BW0G-70-470A
L BW0G-71-470A
Striker, Latch R/L B092-58-361A
SHEET METAL
SEDAN
Illustration Located in Next Column
1
Panel Assy, Quarter
USA-Serviced by Components
Canada R N.A.
LN.A.
2
Panel, Quarter¶ R B4Y5-70-41XD
L B4Y5-71-41XD
3
Panel, Rocker Outer¶ R B4Y5-70-27XF
L B4Y5-71-27XF
4
Pillar, Center Outer¶ R B4Y5-70-350E
L B4Y5-71-350E
¶Included w/Quarter Panel Assy
5
Door, Fuel
w/Door Opener B456-42-410C
w/o Door Opener B455-42-410C
6
Cylinder & Key BR70-76-240B
7
Panel Assy, Inner
FWD R BR70-70-110
L BR70-71-110
AWD R BA1C-70-110
L BA1C-71-110
8
Panel, Inner¶ R BR70-70-11XA
L BR70-71-11XA
9
Panel, Wheelhouse¶
FWD R B455-70-150H
L B607-71-150
AWD R B528-70-150H
L B528-71-150H
10
Bracket, Wheelhouse¶ R B455-70-152
L B455-71-152
11
Plate Assy, Joint¶ R B455-70-180E
L B455-71-180E
¶Included w/Inner Panel Assy
12
Panel, Package Tray B455-70-500E
13
Reinf, Center Pillar R B4Y5-70-420
L B4Y5-71-420
14
Plate, Center Pillar R BR70-70-470B
L BR70-71-470B
15
Pillar, Center Inner-See Rocker/Pillars/Floor Section
16 Striker, Latch R/L B092-58-361A
EXTERIOR TRIM
HATCHBACK
1 Guard, Stone R BR93-50-481
L BR93-50-491
Stripe Tape-See Stripe Tape Section
2 Moulding, Side
Adhesive R/L B4Y7-50-693
INTERIOR TRIM
HATCHBACK
Illustration Located in Next Column
Mldg, Inside Garnish
1 USA-See Windshield Section
2 Canada
Gray R/L N.A.
Gray/Taupe R/L N.A.
3
Trim, Pillar Rear
Gray R B467-68-250B-06
L B467-68-260B-06
Gray/Taupe R B467-68-250B-35
L B467-68-260B-35
4
Panel Assy, Trim¶
Base Model R BR93-68-520E-65
L BR93-68-550E-65
SE Model
w/25th Anniversary Pkg
Right BC3G-68-520-65
Left BC3G-68-550-65
w/o 25th Anniversary Pkg
Right BR94-68-520E-65
Left BR94-68-550E-65
¶Off Black listed, Order by Application
32 Gray/Taupe; 48 Blue; 65 Off Black
5
Grille Assy, Speaker¶ (a)
Blue R B467-68-5H0A-48
L B467-68-5T0A-48
Gray/Taupe R B467-68-5H0B-32
L B467-68-5T0B-32
Off Black R B467-68-5H0A-65
L B467-68-5T0A-65
¶Order by Application
6
Spring, Center Panel (a) (b) R/L B092-55-257
(b) Included w/Speaker Grille Assy
7
Cover, Hole Front¶ (a) R BR93-68-529-48
L BR93-68-559-48
8
Cover, Hole Rear¶ (a) R/L B499-68-893-48
¶Blue listed, Order by Application
32 Gray/Taupe; 48 Blue; 65 Off Black
(a) Included w/Trim Panel Assy
9
Speaker, Radio (c) R/L 0000-81-089A-01
(c) Order by Application
10
Trim, Trunk Side¶ R B467-68-850B-48
L B467-68-870B-48
¶Blue listed, Order by Application
19 Red; 32 Gray Taupe; 48 Blue; 65 Off Black
11
Bracket, Lid R B467-68-8HXA
L B467-68-8HYA
12
Vessel, Belt¶ R BR93-68-3B1-48
L BR93-68-3B2-48
13
Cover, Trunk Lid¶ R BR93-68-8J0-48
L BR93-68-8K0-48
¶Blue listed, Order by Application
19 Red; 32 Gray/Taupe; 48 Blue; 65 Off Black
INTERIOR TRIM
SEDAN
1 Trim, Pillar
Gray R B455-68-250D-06
L B455-68-260D-06
Gray/Taupe R B455-68-250D-35
L B455-68-260D-35
2
Trim, Wheelhouse R B455-68-760A
L B455-68-770A
3
Trim, Trunk Side R BR70-68-851-09
L BR70-68-871-09
Trim Assy, Rear Package¶
USA
w/High Mount Stop Lamp BR70-68-3A0E-48
w/o High Mount Stop Lamp BR72-68-3A0D-48
Canada N.A.
¶Blue listed, Order by Application
19 Red; 32 Gray Taupe; 48 Blue; 60 Dark Gray
Grille, Speaker (a)
Blue R/L BR72-68-3S0A-48
Gray/Taupe R/L BR72-68-3S0A-32
Off Black R/L BR72-68-3S0A-60
Grille, Extractor¶ (a) R B455-68-3A3-48
L B455-68-3A4-48
¶Blue listed, Order by Application
19 Red; 32 Gray Taupe; 48 Blue; 60 Dark Gray
(a) Included w/Rear Package Trim Assy

MAZDA 323/PROTEGE 1990-94
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629. 57
madpl1_g01_
Page 57—April 22, 2004—13:29:29—Version Manufacturer
Speaker, Radio (b) R/L 0000-81-090A-01
(b) Order by Application
QUARTER GLASS
1 Glass, Quarter
Mazda
Clear R B467-72-511
L B467-73-511
Blue Tint R B469-72-511
L B469-73-511
2
W/Strip, Glass R B467-72-761B
L B467-73-761B
3
Latch, Glass R/L D001-72-310A
4
Hinge, Glass Upper R/L B499-72-210B
5
Hinge, Glass Lower R/L B499-73-210B
6
Moulding, Pillar R B467-50-F10
L B467-50-F20
LUGGAGE LID
1 Lid, Luggage
w/Spoiler BR70-52-610J
w/o Spoiler BR70-52-610J
Panel, Finish-See License Lamp Section
2 Rubber, Cushion R/L H001-56-801
Nameplate
"Mazda" BR70-51-710
"Protege"
USA BR72-51-720A
Canada N.A.
"S" TA01-51-761
3
Latch BR70-56-820
4
Striker, Latch GJ21-56-840C
5
Protector, Latch B455-56-823A
6
Cylinder & Key
To 8-1-92 BR70-76-230D
From 8-1-92 BB4E-76-230B
Fastener, Key Cylinder GJ21-56-902A
7
Cable Assy, Release BR71-56-850B
8
Cable, Trunk Lid¶ B456-56-870B
9
Cable, Fuel Lid¶ BR71-56-880
¶Included w/Release Cable Assy
10
Hinge R B455-52-710A
L B455-52-720A
11
Cushion, Hinge R/L B455-56-802A
12
Bar, Torsion
w/Rear Spoiler R B456-52-791B
L B456-52-792A
w/o Rear Spoiler R B456-52-791B
L B456-52-792A
13
Protector, Torsion Bar B130-56-805A
14
Weatherstrip, Lid B455-56-951B
REAR SPOILER
CANADA
1990-91
Illustration Located in Next Column
1
Spoiler Assy, Rear¶ N.A.
¶Harbor Blue listed, Order by Application
DV Blue; DX Honey Blue; FZ Herbie Green;
PZ Brilliant Black; SQ Blaze Red; SS Coral Red;
UF Clear White; 1H Steel Gray MC;
IS Niagara Silver MC; 3L Silver Stone M;
5D Harbor Blue M; 6L Graceful Red MC;
6N Current Blue MC; 6S Excess Green MC
2
Bracket, Spoiler Side¶ R/L N.A.
3
Bracket, Spoiler Center¶ N.A.
4
Protector, Spoiler Side¶ R/L N.A.
5
Protector, Spoiler Center¶ N.A.
6
Fastener, Spoiler Side¶ R/L N.A.
¶Included w/Rear Spoiler Assy
REAR SPOILER
CANADA
1992-95
1 Spoiler Assy, Rear¶ N.A.
2
Support, Center¶ N.A.
¶Bluish Green listed, Order by Application
3
Bracket, Spoiler (a)
Center N.A.
DV Bay Blue; E9 Deep Purple; J4 Passion Rose;
PZ Brilliant Black; SQ Blaze Red; UF Clear White;
Z1 Bluish Green M; 4Z Silent Silver; 5S Neat Green
6C Mighty Gray; 6M Elegant Beige; 6V Raspberry
Metallic; 6W Laguna Blue M; 6Y Sea Mist M
4
Stay, Spoiler (a) R/L N.A.
5
Protector, Spoiler (a) R/L N.A.
6
Gasket, Spoiler (a) N.A.
7
Lamp, High Mount Stop (a) N.A.
(a) Included w/Rear Spoiler Assy
LIFTGATE
1 Shell, Gate
w/Spoiler BS22-62-020M
w/o Spoiler
w/Rear Wiper BR94-62-020K
w/o Rear Wiper BR93-62-020K
Nameplate
"Mazda"
Light Gold B455-51-711A-71
Light Gray B455-51-711A-85
Dark Gray B455-51-711A-86
"Mazda 323"
Light Gold BR93-51-721-71
Light Gray BR93-51-721-85
Dark Gray BR93-51-721-86
"S" G263-51-761
2
Panel Assy, Finish
Outer 90-91 BR93-50-850A
92-95 BB5A-50-850A
3
Lens¶ 90-91 BR93-50-852A
92-95 B596-50-852
4
Protector¶ 90-91 B467-50-853
92-95 B596-50-853
5
Gasket¶ B467-50-855
¶Included w/Outer Finish Panel Assy
6
Panel, Inside Trim (a) B467-68-960A-48
(a) Blue listed, Order by Application
19 Red; 32 Gray Taupe; 48 Blue; 65 Off Black
7
Bracket, Trim Panel B467-68-928A
8
Wedge, Liftgate R/L B467-62-681
9
Latch, Gate B468-62-310A
10
Striker, Latch B467-62-361
11
Cable Assy, Release BR94-56-850
12
Cable, Trunk Lid¶ BR94-56-870
13
Cable, Fuel Lid¶ BR94-56-880
¶Included w/Release Cable Assy
Cylinder & Key BR95-76-260A
14
Hinge Assy, Liftgate R/L D001-62-210C
15
Gasket, Hinge¶ R/L B001-62-212
¶Included w/Liftgate Hinge Assy
16
Stay, Liftgate R 8AB4-62-620
L 8AB4-63-620
17
Weatherstrip B467-62-761
18
Glass, Liftgate
Mazda
Clear
w/Rear Defroster B468-63-930
w/o Rear Defroster B467-63-931
Blue Tint B469-63-930
19
Spacer, Glass R/L B455-50-891A
20
Dam, Glass B456-50-899A
21
Mldg, Reveal Upper 8AB3-50-611
22
Mldg, Reveal Lower 8AB1-50-614
23
Moulding Assy, Side R/L 8AB2-50-612-3
24
Joint, Mldg Upper¶ R/L B467-50-615-6
25
Joint, Mldg Lower¶ R/L B467-50-617-8
¶Included w/Side Moulding Assy
26
Blade Assy, Wiper B467-67-330

MAZDA 323/PROTEGE 1990-94
Labor Times Shown are for Replacement with New OEM Undamaged Parts on New Undamaged Vehicles.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629.
58 madpl1_g01_
Page 58—April 22, 2004—13:29:31—Version Manufacturer
LIFTGATE Cont’d
Insert, Wiper¶
To 8-1-94 B499-67-331
From 8-1-94 B467-67-331
¶Included w/Wiper Blade Assy
27
Arm, Wiper B467-67-421
28
Cover, Arm B093-76-641
29
Motor Assy, Wiper B467-67-450A
30
Bushing, Inner¶ B467-67-402
¶Included w/Wiper Motor Assy
31
Bushing, Outer B467-67-407
32
Cap, Seal B093-67-366A
33
Clip, Hose H001-67-057
34
Clip, Pipe (2) B499-67-519
35
Joint, Hose DB05-67-502
36
Protector, Hose LA05-67-506
37
Nozzle, Washer B467-67-510
38
Tank Assy, Washer B467-67-480C
39
Tank, Washer¶ B467-67-481C
40
Cap, Tank¶ UB39-51-815
41
Pump, Washer¶ 8532-76-672
¶Included w/Washer Tank Assy
42
Valve, Washer Tank
To 2-1-94 B467-67-492C
From 2-1-94 B01A-56-054
REAR SPOILER
1992-95
1 Spoiler Assy, Rear¶
To 11-3-93 B603-51-9N0A-Z1
From 11-3-93 B603-51-9N0B-Z1
¶Bluish Green listed, Order by Application
2
Clip, Spoiler Outer (a) R/L B471-51-9N3
3
Clip, Spoiler Center (a) B467-51-9N2
4
Protector, Spoiler Otr (a)
Right B603-51-9N5A
Left B603-51-9N6A
5
Protector, Center (a) B603-51-9N4
6
Lamp, High Mount Stop (a)
To 8-1-94 B603-51-580C
From 8-1-94 B603-51-580D
7
Protector, Lamp (a) R/L B603-51-582
(a) Included w/Rear Spoiler Assy
REAR SUSPENSION
FWD
1 Rotor, Brake R/L BB4C-26-251C
2
Drum, Brake 90-91 R/L BR70-26-251
92-95 R/L D102-26-251
3
Hub Assy, Wheel R/L B455-26-15XA
4
Bolt, Hub¶ R/L B01Y-33-062
¶Included w/Wheel Hub Assy
5
Caliper, Brake 90-91 R BRY6-26-98ZR
L BRY6-26-99ZR
92-95 R BRY6-26-98ZR
L BRY6-26-99ZR
6
Plate, Backing
Drum Brakes 90-91 R BR71-26-280
L BR71-26-290
92-95 R B596-26-280B
L BC1D-26-290A
7
Shield, Splash
Disc Brakes 90-91 R/L BR74-26-261A
92-95 R/L B613-26-261A
Hose, Brake
Drum Brakes R/L B455-43-810C
Disc Brakes R/L B461-43-980C
8
Spindle, Hub
Drum Brakes R B455-26-111D
L B455-26-115D
Disc Brakes R B461-26-111B
L B461-26-115B
9
Strut Assy
1.6L Eng R B455-28-700
L B455-28-900
1.8L Eng
USA
Std Duty R BR70-28-700A-9U
L BR70-28-900A-9U
Hvy Duty R B625-28-700A
L B625-28-900A
Canada R/L N.A.
10
Bolt, Strut (2/Side) R/L 9YA0-21-231C
11
Spring, Coil¶ R/L BR70-28-011
¶Order by Application
12
Seat, Rubber R/L B455-28-0A3
13
Stopper, Bumper R/L B455-28-111A
14
Seat, Spring R/L B455-28-340A
15
Insulator, Mounting R/L B595-28-390A
16
Bushing R/L B455-28-343A
17
Cap, Mount R/L B455-28-019
18
Link, Lateral Front R BR70-28-620
L BR70-28-630
19
Link, Lateral Rear R/L BR70-28-600
Bolt, Lateral Link
20 Front R/L B528-28-112A
21 Rear R/L B455-28-113
22
Link, Trailing R/L BR70-28-200B
Bolt, Trailing Link
23 Front R/L B455-28-114A
24 Rear R/L B455-28-116
25
Bar Assy, Stabilizer
1990-91
1.6L Eng B457-28-10X
1.8L Eng
Rear Drum Brakes B457-28-10X
Rear Disc Brakes B461-28-10X
1992-95
Std Duty B455-28-10X
Hvy Duty B462-28-10X
Bolt, Stabilizer¶ R/L G030-28-157
Spacer, Stabilizer¶ 90-91 R/L G030-28-158
92-95 R/L B455-28-157
¶Included w/Stabilizer Bar Assy
26
Bushing, Bar
Rear Drum Brakes R/L BW0A-28-156A
Rear Disc Brakes R/L B461-28-156A
27
Bracket, Bar 90-91 R/L B461-34-155A
92-95 R/L E016-28-15YB
28
Crossmember Assy, Suspension 90-91 B455-28-400D
92-95 E016-28-400A
29
Stopper, Rubber¶ R/L B455-28-809
30
Protector, Crossmember¶ R/L B455-28-8A2A
¶Included w/Suspension Crossmember Assy
AWD
1 Rotor, Brake R/L BB4C-26-251C
2
Hub Assy, Wheel R/L B01A-33-060A
3
Bolt, Hub¶ R/L B01Y-33-062
¶Included w/Wheel Hub Assy
4
Shield, Splash R/L B530-26-261A
5
Caliper, Brake R BRY6-26-98ZR
L BRY6-26-99ZR
6
Knuckle R B531-26-110B
L B531-26-120C
7
Strut R B530-28-700
L B530-28-900
8
Bolt, Strut (2/Side) R/L 9YA0-21-231C
9
Spring, Coil¶ R/L BA1C-28-011
¶Order by Application
10
Seat, Rubber R/L B455-28-0A3
11
Stopper, Bumper R/L B455-28-111A
12
Seat, Spring R/L B455-28-340A
13
Insulator, Mounting R/L B595-28-390A
14
Bushing R/L B455-28-343A
15
Cap, Mount R/L B455-28-019
Link, Lateral
16 Front R B528-28-620
L B528-28-630
17 Rear R/L B528-28-600A
Bolt, Lateral Link
18 Front R/L B528-28-112A
19 Rear R/L B455-28-113
20
Link, Trailing R BR70-28-200B
L BR70-28-250
Bolt, Trailing Link
21 Front R/L B455-28-114A
22 Rear R/L B455-28-116
23
Bar Assy, Stabilizer B528-28-10X
Bolt, Stabilizer¶ R/L G030-28-157

MAZDA 323/PROTEGE 1990-94
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629. 59
madpl1_g01_
Page 59—April 22, 2004—13:29:33—Version Manufacturer
Spacer, Stabilizer¶ R/L G030-28-158
¶Included w/Stabilizer Bar Assy
24
Bushing, Bar R/L B459-34-156A
25
Bracket, Bar R/L E016-28-15YB
26
Crossmember Assy, Suspension BA1C-28-400F
27
Stopper, Rubber¶ R/L B455-28-809
28
Protector, Crossmember¶ R/L B455-28-8A2A
¶Included w/Suspension Crossmember Assy
REAR DRIVE AXLE
1 Shaft Assy, Axle R F058-25-500
L F058-25-600
2
Joint Set, Outer¶ R F058-22-510
L F058-22-610A
3
Joint Set, Inner¶ R/L F057-22-520
4
Boot Kit, Outer¶ (a) R/L BS20-V9-050-9U
(a) Included w/Outer Joint Set
5
Boot Kit, Inner¶ (b) R/L G071-22-550
¶Included w/Axle Shaft Assy
(b) Included w/Inner Joint Set
FUEL TANK
1 Cap Assy, Filler
1990-91
FWD BF67-42-250
AWD UE54-42-250
1992-95 GN60-42-250
2
Gasket, Cap¶ BF67-42-252
¶Included w/Filler Cap Assy
3
Cover, Lever
To 7-1-94 B455-42-242A
From 7-1-94 B01W-42-240A
4
Gasket, Dust Cover B455-42-244
5
Pipe, Filler
FWD
Hatchback BR93-42-210E
Sedan BR70-42-210E
AWD BA1C-42-210A
6
Protector, Filler Pipe
FWD
Hatchback B467-42-291A
Sedan BR70-42-298C
AWD B528-42-291
7
Hose, Filler
FWD
Hatchback B467-42-241
Sedan B455-42-241
AWD B528-42-241
8
Tank, Fuel
FWD
Hatchback BR93-42-110B
Sedan BR70-42-110B
AWD B698-42-110B
9
Band, Fuel Tank
FWD
Hatchback R B467-42-710F
L BR93-42-720B
Sedan R B455-42-710E
L BR70-42-720B
AWD R B528-42-710B
L B528-42-720A
10
Insulator, Fuel Tank B455-42-751A
11
Valve, Check BR70-42-910A
12
Gauge, Fuel Tank
FWD
Hatchback
w/Warning Switch B475-60-960A
w/o Warning Switch BR93-60-960
Sedan
w/Warning Switch BS42-60-960
w/o Warning Switch B617-60-960
AWD R B530-60-960B
L B528-60-970A
13
Pump Assy, Fuel
Electric
FWD BP02-13-35ZD
AWD¶ BP47-13-35ZC
Pump, Fuel Sub¶ (a) B6DA-13-350
Filter, Fuel Pump¶ (a) KL22-13-ZE1
¶Order by Application
(a) Included w/Fuel Pump Assy
REAR BODY
SHEET METAL
HATCHBACK
1 Panel Assy, Rear Body B467-70-750A
2
Panel, Rear Body¶ B467-70-751A
3
Bracket, Lamp¶ R B467-70-75X
L B467-71-75X
¶Included w/Rear Body Panel Assy
4
Pillar, Rear Outer R B467-70-440
L B467-71-440
SHEET METAL
SEDAN
Panel, Rear End Upper
-See Rocker/Pillars/Floor Section
1
Panel, Rear End B455-70-750A
2
Extension, Rear End R B455-70-405
L B455-71-405
3
Bracket, Lamp R B455-70-490A
L B455-71-490A
4
Plate, Corner R B455-70-451
L B455-71-451
INTERIOR TRIM
HATCHBACK
1 Trim Assy, Rear End¶ BR93-68-89XC-48
2
Cover, Jack¶ (a) B467-68-8S0A-48
3
Cover, End Trim¶ (a) B467-68-893-48
¶Blue listed, Order by Application
19 Red; 32 Gray Taupe; 48 Blue; 65 Off Black
(a) Included w/Rear End Trim Assy
INTERIOR TRIM
SEDAN
Illustration Located in Next Column
1
Trim, Rear End B455-68-891B-09
FLOOR
1 Panel, Rear End Upper
Hatchback B467-53-940D
Sedan B4Y5-53-940C
2
Pan, Rear Floor
Hatchback BR93-53-730C
Sedan B455-53-730B
3
Panel, Floor Side
FWD
Hatchback R B467-53-740F
L B467-54-741C
Sedan R B455-53-740J
L B455-54-741A
AWD R B529-53-740E
L B529-54-741C
4
Crossmember, Center
Hatchback B467-53-930D
Sedan
FWD B455-53-930C
AWD B528-53-900A
5
Pan, Center Floor
FWD
Hatchback BR93-53-720D
Sedan BR70-53-720E
AWD BA1C-53-720
6
Reinf, Center Floor R B455-53-715A
L B455-54-715A
7
Crossmember, Front
FWD B455-53-900F
AWD B528-53-900A
8
Unirail, Rear
FWD
Hatchback R BR93-53-810H
L BR93-54-810H
Sedan R BR70-53-810K
L BR70-54-810J
AWD R BA1C-53-810D
L BA1C-54-810F
REAR LAMPS
COMBINATION LAMP
HATCHBACK
1990-91
1 Lamp Assy R 8FB2-51-150
L 8FB2-51-160
2
Lens & Housing Assy¶ R BR93-51-170
L BR93-51-180

MAZDA 323/PROTEGE 1990-94
Labor Times Shown are for Replacement with New OEM Undamaged Parts on New Undamaged Vehicles.
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax [phone] or 858-549-0629.
60 madpl1_g01_
Page 60—April 22, 2004—13:29:34—Version Manufacturer
REAR LAMPS Cont’d
COMBINATION LAMP
HATCHBACK
1990-91 Cont’d
3 Lens & Body¶ (a) R B467-51-151
L B467-51-161
4
Gasket¶ (a) R B467-51-158
L B467-51-168
(a) Included w/Lens & Housing Assy
5
Socket & Wire¶ R/L B467-51-155
6
Bulb¶
Signal/Stop/Tail R/L 0000-11-1156
Back-Up R/L 0000-11-0921
7
Bracket, Lamp¶ R/L B467-51-172
¶Included w/Lamp Assy
COMBINATION LAMP
HATCHBACK
1992-95
1 Lamp Assy R 8FBJ-51-150
L 8FBJ-51-160
2
Lens & Body Assy¶ R BB7A-51-170
L BB7A-51-180
3
Lens¶ (a) R B596-51-151
L B596-51-161
4
Gasket¶ (a) R B467-51-158
L B467-51-168
(a) Included w/Lens & Body Assy
5
Socket & Wire¶ R/L B467-51-155
6
Bulb¶
Signal/Stop/Tail R/L 0000-11-1157
Back-Up R/L 0000-11-0921
7
Bracket, Lamp¶ R/L B467-51-172
¶Included w/Lamp Assy
COMBINATION LAMP
SEDAN
1990-91
1 Lamp Assy R 8FB1-51-150
L 8FB1-51-160
2
Lens¶ R BR70-51-170A
L BR70-51-180A
3
Gasket¶ R/L B455-51-158
4
Socket¶ R B455-51-155
L B455-51-165
5
Bulb¶
Signal/Stop/Tail R/L 0000-11-1156
Back-Up R/L 0000-11-0921
6
Moulding, Lamp¶ R B455-51-159
L B455-51-169
¶Included w/Lamp Assy
COMBINATION LAMP
SEDAN
1992-95
Illustration Located in Next Column
1
Lamp Assy R 8FBK-51-150
L 8FBK-51-160
2
Lens & Body Assy¶ R BB7C-51-170A
L BB7C-51-180A
3
Lens¶ (a) R BB7C-51-170A
L BB7C-51-180A
4
Gasket¶ (a) R/L B617-51-158
(a) Included w/Lens & Body Assy
5
Socket¶ R B617-51-155
L B617-51-165
6
Bulb¶
Signal/Stop/Tail R/L 0000-11-0921
Back-Up R/L 0000-11-1157
¶Included w/Lamp Assy
LICENSE LAMP
HATCHBACK
1 Lamp Assy 8BB8-51-270
2
Lens¶ R/L G225-51-274B
3
Gasket¶ R/L G225-51-273
4
Housing¶ BR93-51-271
5
Bulb¶ R/L 0000-11-0168
6
Bracket, Lamp¶ R/L BR93-51-261
¶Included w/Lamp Assy
LICENSE LAMP
SEDAN
1 Panel Assy, Finish
Outer 90-91 BR70-50-850
92-95 BB4W-50-850A
2
Lens¶-Serviced w/Outer Finish Panel Assy
3 Cover, Lamp¶ 90-91 R BR70-51-283
L BR70-51-293
92-95 R B623-51-283
L B623-51-293
4
Gasket¶ R/L BR70-50-855
5
Gasket, Side¶ R/L BR70-50-865
6
Socket¶ R/L BR70-51-272
7
Bulb¶ R/L BR70-51-686
8
Protector¶ 90-91 B455-50-853A
92-95 B617-50-853
¶Included w/Outer Finish Panel Assy
SIDE MARKER LAMP
1 Lamp Assy R 8BB1-51-550
L 8BB1-51-560
2
Socket & Wire¶ R/L BR70-51-554
3
Bulb¶ R/L 0000-11-0194
¶Included w/Lamp Assy
REFLECTOR LAMP
1 Reflector R BR93-51-5B0A
L BR93-51-5C0A
HIGH MOUNT STOP LAMP
HATCHBACK
1 Lamp Assy (a) (b) BR93-51-580A-PZ
(a) Located on Liftgate
(b) Brilliant Black listed, Order by Application
DV Bay Blue; DX Honey Blue; E9 Deep Purple;
FZ Herbie Green; GU Shade Green;
PZ Brilliant Black; SQ Blaze Red;
SS Coral Red; UF Clear White;
Z1 Bluish Green M; 1H Steel Gray MC;
1S Niagara Silver MC; 3L Silver Stone M;
4R Passion Yellow Mica; 4Z Silent Silver;
5D Harbor Blue M; 5L Whisper Green;
5S Neat Green; 6C Mighty Gray;
6L Graceful Red; 6M Elegant Beige;
6N Current Blue MC; 6S Exceed Green M;
6V Raspberry Metallic; 6W Laguna Blue M
2
Gasket¶ BR93-51-582
3
Socket & Wire¶ BR93-51-584
4
Bulb¶ 0000-11-0921
5
Cap, Lamp¶ (a) R BR93-51-586A-PZ
L BR93-51-596A-PZ
¶Included w/Lamp Assy
(a) Brilliant Black listed, Order by Application
DV Bay Blue; DX Honey Blue; E9 Deep Purple;
FZ Herbie Green; GU Shade Green;
PZ Brilliant Black; SQ Blaze Red;
SS Coral Red; UF Clear White;
Z1 Bluish Green M; 1H Steel Gray MC;
1S Niagara Silver MC; 3L Silver Stone M;
4R Passion Yellow Mica; 4Z Silent Silver;
5D Harbor Blue M; 5L Whisper Green;
5S Neat Green; 6C Mighty Gray;
6L Graceful Red; 6M Elegant Beige;
6N Current Blue MC; 6S Exceed Green M;
6V Raspberry Metallic; 6W Laguna Blue M
HIGH MOUNT STOP LAMP
SEDAN W/SPOILER
1 Lamp Assy (a)
1990-91 BR74-51-580
1992-95-See Luggage Lid Section
(a) Located on Spoiler
2
Lens¶ GJ22-51-593
3
Socket & Wire¶ BR74-51-584
4
Bulb¶ 0000-11-0921
¶Included w/Lamp Assy
HIGH MOUNT STOP LAMP
SEDAN W/O SPOILER
Illustration Located in Next Column
1
Lamp Assy¶ (a) BR70-51-580-48
(a) Located on Package Tray
2
Lens & Body¶ (b) GE61-51-593-48
¶Blue listed, Order by Application
19 Red; 32 Gray Taupe; 48 Blue; 65 Off Black
3
Socket & Wire (b) 0000-11-0921
4
Bulb (b) 0000-11-0921
