mazzivo SMOOTH User manual

SMOOTH
www.mazzivo.pl
assembly instructions

SMOOTH
www.mazzivo.pl
assembly instructions
1
2
3
4
5
6 7
To assemble the bed, you will need the following:
a battery-powered screwdriver, a cross-head screwdriver, an 8mm Allen wrench, a hammer
- two adults.
Bed frame:
Headboard (1) - 1 pc
Footrest (2) - 1 pc
Side panels (3,4) - 2 pcs
Bed support:
Central board (5) - 1 pc
Bars (6, 7) - 2 pcs
Fixing elements:
Note:
Some elements of the structure may already be mounted in the bed frame, therefore their number may
change. If there are any components missing, please contact our customer service department.
General safety notes: Keep all small parts and parts of the frame away from children! Heavy items should
not be lifted up by one person!
Eccentric (A) - 4 pcs
Mandrel (C) - 4 pcs
Peg (G) - 8 pcs
SPAX screw - 8 pcs
Hex socket screw - 16 pcs

SMOOTH
www.mazzivo.pl
assembly instructions
2. Assembly of eccentrics (A) to boxes of ele-
ments of the bed frame, the arrows indicate
the outer edge
3. Assembly of pegs (G) and mandrels in the
side panels of the bed (3,4)
4. Connecting side panels (3,4) to the he-
adboard (1), tightening the eccentric with a
screwdriver.
We suggest doing this with the headboard in
horizontal position
1. Assembly of legs to the bars (6,7) with
hex socket screws (J)

SMOOTH
www.mazzivo.pl
assembly instructions
6. Connecting the footboard (2) to the side
panels (3,4) and the board (5)
7. Tightening of all connecting elements
5. Assembly of the central board (5)
8. Assembly of bars (6,7)

SMOOTH
www.mazzivo.pl
assembly instructions
9. Screwing the board (5) with the bars (6,7)
10. Screwing the spax screws in the ttings
that x the bars (6,7)
When this is done, the bed frame can be put
on the legs.

SMOOTH
www.mazzivo.pl
assembly instructions
1. Putting caps of the frame on the pegs.
2. Inserting the boards of the frame into the
caps, as in the example shown in the pictu-
res.
assembly instructions
A silent sleep system
