McCue Crash Barrier User manual

Crash Barrier | Page 1 of 6
mccue.com
McCue Corporation
Peabody, Massachusetts, USA
[phone]
[email protected]
McCue UK & Europe
Milton Keynes, United Kingdom
[phone]
[email protected]
McCue Asia
迈客(厦门)有限公司
Xiamen, Fujian, China
[phone]
Crash Barrier
?
Questions
INSTALLATION INSTRUCTIONS
10
Crash Rail
End
Crash Rail
Mid
Crash Rail
Corner Barrier
Tools Required
16mm (5/8in)
Components (varies by installation)
Components:
High Traffic Extrusion Crash Barrier End
3/4" (20mm) Shock-
absorbing Anchor Kit
(2 Per Part)
HT Crash Barrier Installation Instructions
Epoxy/Resin
Crash Barrier Mid Crash Barrier Corner
Epoxy/Resin
Rack End Right Leg
Rack End Left Leg
3/4" (20mm) Shock-absorbing
Anchor Kit (3 per part)
High Traffic Extrusion
HT Rack End Installation Instructions
Components:
20mm (3/4in)
Shock-Absorbing
Anchor Kit
(2 per each steel part)
Components:
High Traffic Extrusion Crash Barrier End
3/4" (20mm) Shock-
absorbing Anchor Kit
(2 Per Part)
HT Crash Barrier Installation Instructions
Epoxy/Resin
Crash Barrier Mid Crash Barrier Corner
24mm (15/16in)

Crash Barrier | Page 2 of 6
TOP VIEW
TOP VIEW
3048mm
(120in)
Max.
1
2
92mm (3 5/8in)
Min.
92mm (3 5/8in)
Min.
92mm (3 5/8in)
Min.
92mm (3 5/8in)
Min.
3048mm (120in)
Max.

Crash Barrier | Page 3 of 6
5
6
Hole Depth
152mm (6in)
8X
3
4
Hole Diameter
16mm (5/8in)

Crash Barrier | Page 4 of 6
5
6
7 8
9

Crash Barrier | Page 5 of 6
7 8
9

Crash Barrier | Page 6 of 6
10
Installation instructions are provided for guidance only. The seller assumes no liability regarding improper
installation or misapplication of its products. It is the installer’s responsibility to check for proper installation
and, if in doubt, contact McCue Customer Care for assistance. ©2014 McCue Corporation. NOV2014
