McIntosh C1100 User manual

C1100
C1100
CONTROLLER
SERVICE MANUAL
SERIAL NO. AEE1001 And Above
Performance Specifications..........................................2
Notes...........................................................................2
Rear Panel ...................................................................3
Section Location.....................................................5 - 6
Block Diagram .......................................................7 - 8
Interconnection Diagram......................................9 - 10
Control Data Schematic and PCB .......................11 - 16
Power Supply Schematic and PCB......................17 - 20
Display/Pushbutton Schematic and PCB .............21 - 26
Parts List .............................................................29 - 33
Repacking Instruction ................................................35
CONTENTS
TRIM
ADJUST
INPUT
VOLUME
C1100 CONTROLLER
SETUP MUTE
RESET
MENU
INPUT: MC PHONO
VOLUME: 70%
STANDBY ON

2
1. Unless otherwise noted, all voltages indicated on the
schematics are measured under the following conditions:
a. AC input at rated voltage marked on rear panel.
b. All voltages are +/-10% with respect to ground. A
high impedance (10 megaohm) voltmeter must be used.
2. Unlessotherwisespecied:
a. Resistor values are in ohms.
b. Capacitor values are microfarads (uF).
c. Inductor values are in microhenries (uH)
3. On PC board drawings, Square pad indicates:
a. Polarized Capacitors - Positive
b. Diodes - Cathode
c. Others - Pin 1
4. WARNING
Parts marked with the symbol have critical
characteristics. Use only replacement parts recom-
mended by the manufacturer.
5. Use McIntosh Remote Control Model HR085.
NOTES
PERFORMANCE SPECIFICATIONS
Frequency Response
+0, -0.5dB from 20Hz to 20,000Hz
+0, -3dB from 10Hz to 100,000Hz
Total Harmonic Distortion
0.005% maximun from 20Hz to 20,000Hz
(High Level Inputs)
0.05% maximun from 20Hz to 20,000Hz
(Phono Inputs)
Rated Output
5V Balanced, 2.5V Unbalanced (Main Outputs)
Maximum Voltage Output
20V RMS Balanced, 10V RMS Unbalanced
Sensitivity (for rated output)
High Level, 450mV Unbalanced, 900mV Balanced
Phono MM, 4.5mV
Phono MC, 0.45mV
Signal To Noise Ratio (A-Weighted)
High Level - 107dB (Below rated output)
MM Phono - 77dB (Below 5mV input)
MC Phono - 79dB (Below 0.5mV input)
Input Impedance
High Level - 44K ohms Balanced
22K ohms Unbalanced
Phono MC - 25, 50, 100, 200, 400 or 1,000 ohms;
220pF
Phono MM - 50 to 800pF, in 50pF steps;
47K ohms
Maximum Input Signal
High Level, 20V Balanced, 10V Unbalanced
Phono MC, 10mV
Phono MM, 100mV
Voltage Gain
High Level to Main, Output1 and 2: 15dB
High Level to Rec/Fixed Output: 0dB
Phono MC to Rec/Fixed Output: 60dB
Phono MM to Rec/Fixed Output: 40dB
Output Impedance
200 ohms Balanced
100 ohms Unbalanced
Headphone Load Impedance (Selectable)
16 - 40 ohms, 40 - 150 ohms, 150 - 600 ohms
Headphone Voltage Gain (From Main Output)
16 - 40 ohms, 0dB
40 - 150 ohms, 6dB
150 - 600 ohms, 12dB
Headphone Output
150mW minimum from 16 ohms to 600 ohms load
Power Control and Trigger Output
12VDC, 25mA
Tube Complement
12 Tubes, Six - 12AX7A and Six - 12AT7
High level - one 12AX7A and two 12AT7 (per channel
viewed from Front Panel Window)
Phono MC - one 12AX7A and one-half 12AT7
(per channel viewed from the Top
Cover Window)
Phono MM - one 12AX7A and one-half 12AT7
(per channel viewed from the Top
Cover Window)
Power Requirements
Field AC Voltage conversion of the C1100 is not possible. The
C1100isfactoryconguredforoneofthefollowingACVoltages:
100 Volts, 50/60Hz at 75 watts
110 Volts, 50/60Hz at 75 watts
120 Volts, 50/60Hz at 75 watts
220 Volts, 50/60Hz at 75 watts
230 Volts, 50/60Hz at 75 watts
240 Volts, 50/60Hz at 75 watts
Standby Power, less than 0.5 watts
Note: Refer to the rear panel of the C1100C Controller for the
correct voltage.
Overall Dimensions
Width is 17-1/2 inches (44.45cm)
Height is 6 inches (15.2cm) including feet
Depth is 19 inches (48.3cm) including the Front Panel, Knobs and
Cables
Weight
C1100C Controller - 27 pounds (12.3 kg) net,
42 pounds (19.5 kg) in shipping
carton
C1100TPreamplier-25pounds(11.3kg)net,
39 pounds (17.7 kg) in shipping
carton
Shipping Carton Dimensions
Width is 27 inches (68.6cm)
Height is 12 inches (30.5cm)
Depth is 25 inches (63.5cm)

C1100
REAR PANEL
3
McINTOSH LABORATORY, INC. BINGHAMTON, NY 13903
HANDCRAFTED IN USA WITH US AND IMPORTED PARTS
C1100 C ONTROLLER
LEFT OUTPUT
TO C1100 TUBE PREAMPLIFIER
LEFT INPUT
RIGHT OUTPUT
TO C1100 TUBE PREAMPLIFIER
RIGHT INPUT
120V 50/60Hz
75 WATTS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
POWER CONTROL
MAIN
OUT 1
TRIG 3TRIG 1
PASSTHRU
OUT 2
TRIG 4TRIG 2 RS232
DATA PORTSEXTERNAL CONTROL
5
3
17IR IN
6
4
28
TO DIGITAL
PREAMPLIFIER UPDATE
USB
SERIAL
NUMBER
ATTENTION: RISQUEDE CHOC ELECTRIQUE-NE PA S OUVRIR

4
SECTION LOCATIONS
Top View
Bottom View
CONTROL
PCB
2
PUSHBUTTON
PCB
5
DISPLAY
PCB
4
POWER SUPPLY
PCB
3
T1
T2

C1100
5 6
BLOCK DIAGRAM
LEFT POWER SUPPLY
DISPLAY ROTARY
CONTROLS
DISPLAY
DRIVER
REMOTE
SENSOR
VOLUME
CONTROL
INPUT/OUTPUT MULTIPLEXER
DIGITAL
PREAMPLIFIER
CONTROL
SYSTEM
MICROCONTROLLER
KEY
CONTROLS
POWER
TRANSFORMER
FUSE
-18V 18V
5V
AC
POWER
TO TUBE PREAMPLFIER
LEFT INPUT
190V
TUBE
SYSTEM CONTROL
DATA
PORTS
IR
IN RS232
PASS
THRU
POWER
CONTROL
RIGHT POWER SUPPLY
POWER
TRANSFORMER FUSE
-18V 18V
-18.6V
TUBE
5V
18.6V
TUBE
AC
POWER
TO TUBE PREAMPLFIER
RIGHT INPUT
190V
TUBE
-18.6V
TUBE
18.6V
TUBE
SPECIFICATIONS
RATED OUTPUT (MAIN)
2.5V Unbalanced, 5V Balanced
SENSITIVITY (FOR RATED OUTPUT)
High Level, 450mV unbalanced, 900mV balanced
Phono MM, 4.5mV
Phono MC, 0.45mV
SIGNAL TO NOISE RATIO (A-WEIGHTED)
High Level, 107dB below rated output
Phono MM, 77dB below 5mV input
Phono MC, 79dB below 0.5mV input
INPUT IMPEDANCE
High Level, 25K ohms unbalanced, 50k ohms balanced
Phono MM, 47K ohms; 50 to 800pF, in 50pF steps
Phono MC, 25, 50, 100, 200, 400 or 1,000 ohms; 100pF
FREQUENCY RESPONSE
+0, -0.5dB from 20Hz to 20,000Hz
+0, -3dB from 10Hz to 100,000Hz
TOTAL HARMONIC DISTORTION
High Level, 0.005% from 20Hz to 20,000Hz
Phono, 0.05% from 20Hz to 20,000Hz
MAXIMUM OUTPUT
10V RMS Unbalanced, 20V RMS Balanced

7 8
INTERCONNECT
1
2
CONTROL
DATA
3
POWER
SUPPLY
3
POWER
SUPPLY
4
DISPLAY
T1 T2
5
PUSHBUTTON
100V 50/60Hz
110-127V 50/60Hz
220-240V 50/60Hz
T2AL 250V
T1.6AL 250V
T800mAL 250V
F1
PRIMARY LINE VOLTAGE
J6
J1
J9 J10
J3 J3
J4
J7
J4 J3
J2 J2
J1
F1
FN1
AC
PRIMARY
IN
CA1 CA3
CA4
CA5
CA2

C1100
9 10
CONTROL DATA 751784 SCH 1 of 3
2
KEY REF
EXT TXD
EXT RXD
NRST
PASS PC
TCK
TDI
TDO
TMS
VOL A VOL B
USB1 -
USB1 +
IR CTRL
C RXD
C TXD
WP
7
SCL
6
VCC
8
SDA
5
A1 2
A2 3
A0 1
GND 4
U20
CONV IR
INP A
FR IR
INP B
REAR IR
.1µF
C49
.1µF
C46
AC DET
I2C CL
I2C DA
PASS LT
42
1
3 5
Vcc
GND
U11
42
1
3 5
Vcc
GND
U12
42
1
3 5
Vcc
GND
U10
+3.3V BU
+3.3V BU
+1.2V M
+1.2V M
+1.2V M
+3.3V M
+3.3V M
+3.3V M
+3.3V M
+3.3V M
+3.3V M +3.3V M
+3.3V M
RS T
+5V
+5V
LEFT POWER
R KEY
I2C CL
I2C DA
S2
J10:1
J10:3
J10:12
J10:9
EXT TXD
EXT RXD NRST
TCK
TDI
TDO
TMS
USB1 - USB1 +
+3.3V BU
J9:8
J9:7
L8
.1µF
C48
.1µF
C45
.1µF
C47
.1µF
C44
.1µF
C37
10
R24
4.7µF
C35
KEY REF
VOL B
VOL A
SDAA 3
GND 4
SDAB
6
EN
5
VCC(A) 1 VCC(B)
8
SCLA 2 SCLB
7
U9
INP A
INP B
J6:15
R KEY
FR IR
+3.3V BU+3.3V BU
+3.3V BU
I2C CL
I2C DA
.1µF
C50
Q3
7
VSS
8
Q1
5
A1
2
A2
3
Q4 9
Q5 10
Q7 12
SDA 15
SCL 14
Q2
6
A0
1
Q0
4
Q6 11
VDD 16
N C 13
U15
22.1k
R44
22.1k
R41
22.1k
R43
22.1
R50
22.1
R38
22.1k
R39
+3.3V BU
+3.3V BU
+3.3V BU
I2C CL
I2C DA
.1µF
C36
4.7µF
C38
.1µF
C41
22.1
R26
22.1
R27
22.1
R25
12pF
C43
12pF
C42
1k
R33
12.00 MH z
Y1
22.1
R28
22.1
R29
J10:6
J10:7
J10:4
J10:5
J10:18
J10:2
PS ON
+3.3V BU
RIGHT POWER
J9:17
J9:18
+3.3V BU
+3.3V BU +3.3V BU +3. 3VBU
A = 0 1 0 (2)
6
4
2
3
5
1
7 8
9 10
11 12
13 14
15 16
USB - USB +
TCK
TMS
TDO
TDI
RXD
TXD
TST
GND
GND
NRST
+3.3V
GND
GND
GND
J7
ERASE
FP RST
PWR
PWR RLY
4
2
1
3
Vcc
GND
5
U23
3
1
2
Q4
2.21k
R45
.1µF
C54
+3.3V BU
+3.3V BU
PA20/PGMD8/AD3
16
PA19/PGMD7/AD2
13
PA22/PGMD10/AD9
14
PA21/PGMD9/AD8
11
VDDOUT
8
PA17/PGMD5/AD0
9
PB3/AD7
6
PB0/AD4
3
PB1/AD5
4
ADVREF
1
VDDPLL 64
XOUT/PB8 61
XIN/PGMCK/PB9 62
PB13/DAC0 59
DDM/PB10 56
DDP/PB11 57
VDDCOR E 54
TMS/SWDIO/P B6 51
PA31 52
TDO/TRACESW O/PB5 49
TDI/PB433
PA4/PGMNC MD 36
PA5/PGMRD Y 35
PA28 38
PA29 41
TST40
PA343
GND 46
VDDIO 45
PA0/PGMEN0 48
PA23/PGMD11
15
VDDIN
7
PB2/AD6
5
VDDC ORE
12
PA18/PGMD6/AD1
10
GND
2
GND
17
PA15/PGMD3
20 PA16/PGMD4
19
PA13/PGMD1
22
PA25/PGMD13
25 VDDCORE
24
PA12/PGMD0
27
PA9/PGMM1
30 PA10/PGMM2
29
PA7/XIN32/PGMNVALID
32
PA6/PGMNOE 34
PA27/PGMD15 37
NRST 39
PA30 42
PA2/PGMEN2 44
PA1/PGMEN1 47
PB14/DAC1 63
VDDIO 58
TCK/SW CLK/PB7 53
GND 60
ERASE/PB12 55
JTAGS EL 50
VDDIO
18
PA24/PGMD12
23
PA11/PGMM3
28
PA14/PGMD2
21
PA26/PGMD14
26
PA8/XOUT32/PGMM0
31
U1 3
VFD DA
VFD CL
VFD CS
I2C CL 1
I2C DA 1
J10:13
J10:14
J10:15
J10:16
J10:10
RS232 SD
+1.2V M
.1µF
C39
+1.2V M
.1µF
C40
J6:2
J6:14
J6:1
J6:7
J6:8
J6:9
J6:13
J6:12
J6:3
J6:6
J6:5
J6:4
J6:16
.1µF
C53
.1µF
C34
J9:14
J9:15
J9:9
J9:10
J9:2
J9:1
J9:11
J6:10
J6:11
J6:17
J6:18
J6:19
J6:20
J6:21
J6:22
J6:23
+3.3V BU
+3.3V BU
22.1k
R42
22.1
R51
VFD ON
+3.3V BU
J9:12
J9:3
J9:4
J9:5
J9:6
J9:16
J9:13
+3.3V BU
4
2
1
3
Vcc
GND
5
U22
10k
R300
+3.3V BU +3. 3VBU
10k
R301
1k
R109
D I S P L A Y
S1
ERASE
+3.3V M
TRIM B
TRIM A
ADJUST A
ADJUST B
TRIM B
TRIM A
ADJUST A
ADJUST B
T R XD
T TXD
J10:11
J10:8
J10:17
AC ON
PS ON
TCBL DET
VFD ON
READY
5VFD
+5V
5VFD
D RXD
.1µF
C18
.1µF
C17
L6
.1µF
C19
L21
.1µF
C20
DGND
.1µF
C16
T2out 8
R2in 9
C2- 6
T2in
11
V+ 3
R1in
14
EN 1
GND
16 C1+ 2
C1- 4
C2+ 5
V- 7
R2out
10
T1in
12 R1out
13
T1out
15
Vcc
17 SD
18
U3
L7
L20
C TXD
C RXD
+3.3VBU
T RXD
T TXD
D1100 TXD
D1100 RXD
D TXD
+V PC1
+V PC2
OPEN
R110
READY
1k
R111
100k
R112
3 1
2
10k
10k
Q40
+3.3V BU
D1100CBL DET
D1100
+3.3V BU
42
1
3 5
Vcc
GND
U4
475
R114
100k
R113
+3.3V BU
ACC PC
.1µF
C22
10k
R115
10k
R116
+3.3V BU
+3.3V BU
C TXD = T RXD
D RXD
D TXD
TCBL DET
D1100CBL DET
C R XD = T TXD
NC
RS232 SD
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4NC
NC
NC
NC
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3

11 12
CONTROL DATA 751784 SCH 2 of 3
2
L30
10
R106
4
6
5
Top
J17:2
D34
P A S S - THRU
10
R107
1
3
2
Bottom
J19:1
D35
L22
10
R103
D30
L24
10
R104
D31
L28
10
R105
D33
3
1
2
Q15
4.75k
R96
MAIN PC
Q3
7
VSS
8
Q1
5
A1
2
A2
3
Q4 9
Q5 10
Q7 12
SDA 15
SCL 14
Q2
6
A0
1
Q0
4
Q6 11
VDD 16
NC 13
U30
2.21k
R78
.1µF
C64
150
R102
3
1
2
Q11
4.75k
R9
150
R98
3
1
2
Q12
4.75k
R93
150
R99
3
1
2
Q14
4.75k
R95 150
R101
D28
D29
D24
D25
D27
L10
10
R52
D13
L11
10
R53
D14
L14
10
R56
D17
L15
10
R57
D18
3
1
2
Q9
22.1k
R69
100
R62
3
1
2
Q10
22.1k
R70
100
R63
3
1
2
Q6
22.1k
R66
100
R59
100
R58
47.5k
R73
1.5k
R64
475k
R76
100pF
C62
4
6
5
Top
J18:2
D20
IR IN
1
3
2
Bottom
J18:1
D19
.1µF
C59
.1µF
C58
L19
.1µF
C61
L18
.1µF
C55
.1µF
C60
T2out 8
R2in 9
C2- 6
T2in
11
V+ 3
R1in
14
EN 1
GND
16 C1+ 2
C1- 4
C2+ 5
V- 7
R2out
10
T1in
12 R1out
13
T1out
15
Vcc
17 SD
18
U26
RS232 SD
L16
L17 EXT TXD
EXT RXD
L9
D21
TO EXT D B9 - 2 (R XD ) TIP
RIN G
GN D
FR OM EXT D B9 - 3 (T XD )
EXT DB9 - 5 (GN D)
RS 232
Q3
7
VSS
8
Q1
5
A1
2
A2
3
Q4 9
Q5 10
Q7 12
SDA 15
SCL 14
Q2
6
A0
1
Q0
4
Q6 11
VDD 16
NC 13
U29
I2C CL
I2C DA
.1µF
C63
TRIG 1
4
6
5
Top
J16:2
10
R108
D32
TRG1 PC
3
1
2
Q13
4.75k
R94 150
R100
L26
D26
TRIG 2
1
3
2
Bottom
J16:1
4
6
5
Top
J15:2
1
3
2
Bottom
J15:1
OUT 1
+3.3VBU
+3.3VBU
+3.3VBU
+3.3VBU
L12
10
R54
D15
L13
10
R55
D16
3
1
2
Q8
22.1k
R68
100
R61
100
R60
3
1
2
Q7
22.1k
R67
DATA 1
CONV IR FR IR
REAR IR
42
1
3
Vcc
GND
5
U31
42
1
3
Vcc
GND
5
U25
. 1µF
C57
42
1
3 5
Vcc
GND
U28
IR CTRL
+3.3VBU
+3.3VBU+3.3VBU+3.3VBU
DAT A OU T
I2C CL
I2C DA
+3.3VBU
+3.3VBU
A = 0 0 0 (0)
A = 0 0 1 (1)
.1µF
C68
D22 34
6
5
1
2
U24
CLR
3
GND
4C ex t 6
Q5
A
1VC C 8
B
2R /Cex t 7
U27
4
2
1
3
Vcc
GND
5
U32
+3.3VBU
+3.3VBU+3.3VBU+3.3VBU +3.3VBU+3.3VBU
3
1
2
Q5
22.1k
R65
DATA 2
DATA 3
DATA 4
DATA 5
DATA 6
DATA 1
DATA 2
DATA 3
DATA 4
DATA 7
DATA 8
PASS PC
22.1k
R85
D23
+3 .3V BU
22.1k
R84
.01µF
C69
+3 .3V BU
42
1
3
Vcc
GND
5
U34
PASS LT
+3 .3V BU
22.1k
R91 22.1k
R97
+3 .3V BU
TRIG 3
TRIG 4
.1µF
C56
+3.3VBU
42
1
3
Vcc
GND
5
U40
1
3
2
Bottom
J11:1
4
6
5
Top
J11:2
L2
10
R32
D9
L3
10
R47
D10
3
1
2
Q29
22.1k
R34
100
R31
3
1
2
Q31
22.1k
R49
100
R46
DATA 7
DATA 8
DATA 5
DATA 6
4
6
5
Top
J12:2
4
6
5
Top
J13:2
4
6
5
Top
J14:2
1
3
2
Bottom
J12:1
1
3
2
Bottom
J13:1
1
3
2
Bottom
J14:1
1
2
3
4
5
6
7
8
TRG2 PC
TRG1 PC
TRG4 PC
TRG3 PC
OUT2 PC
OUT1 PC
3
1
2
Q16
3
1
2
Q17 22.1
R6
2.21k
R4
22.1k
R3
3.32k
R5
.1µ F
C7
+V PC1
TRG2 PC
TRG3 PC
TRG4 PC
OUT1 PC
L4
10
R80
1
3
2
Bottom
J17:1
D12
3
1
2
Q35
4.75k
R81 150
R77
D11
OUT 2
OUT2 PC
L5
10
R89
4
6
5
Top
J19:2
D37
3
1
2
Q39
4.75k
R90
150
R88
D36
MAIN
MAIN PC
3
1
2
Q3
+V PC1
4.75k
R92
+V PC1
3
1
2
Q19
3
1
2
Q20 22.1
R13
2.21k
R11
22.1k
R8
3.32k
R12
.1µF
C8
3
1
2
Q18
4.75k
R10
+V PC1
3
1
2
Q22
3
1
2
Q23 22.1
R18
2.21k
R16
22.1k
R14
3.32k
R17
.1µF
C9
3
1
2
Q21
4.75k
R15
+V PC1
3
1
2
Q25
3
1
2
Q26 22.1
R23
2.21k
R21
22.1k
R19
3.32k
R22
.1µF
C10
3
1
2
Q24
4.75k
R20
+V PC1
3
1
2
Q28
3
1
2
Q30 22.1
R40
2.21k
R36
22.1k
R30
3.32k
R37
.1µF
C11
3
1
2
Q27
4.75k
R35
+V PC2
3
1
2
Q33
3
1
2
Q34 22.1
R75
2.21k
R72
22.1k
R48
3.32k
R74
.1µF
C12
3
1
2
Q32
4.75k
R71
+V PC2
3
1
2
Q37
3
1
2
Q38 22.1
R87
2.21k
R83
22.1k
R79
3.32k
R86
.1µF
C15
3
1
2
Q36
4.75k
R82
+V PC2
+V PC1+V PC1
+V PC1+V PC1
+V PC1+V PC1
+V PC2+V PC2
+V PC2+V PC2
+V PC2+V PC2
6
4
2
3
5
1
PWR
D-
D+
GN D
CASE
CASE
J8
USB1 -
USB1 +
D7
D8
3
6
1 2
5
4
J21
D1100
D1100 TXD D1100 RXD
D41 D40
D38 D39
ACC PC
CGND
CGND
DATA PORTS
TO DIGITAL
PREAMPLIFIER
POWER CONTROL

C1100
13 14
CONTROL DATA 751784 SCH 3 of 3
2
.1µF
C14
VOUT 3
GND
2
VIN
1
TAB
4
U2
L1
220µF
C27
42
1
3
Vcc
GND
5
U1
3
1
2
Q1
.1µF
C6
150k
R7
AC DETECTOR
.1µF
C5
3
1
2
Q2
AC DET
DGNDDGND
DGND
+3.3VBU
+3.3VBU
.1µF
C1
1
GRY
BLU
BLK
350mA
t
R1
D3
1
1
1
WHT
ORN
VIO
1
1
D2
2 6
8
4
1
3
5
7
PRIMARY
T1
+VBU
J5:1 J5:2
J4:4
J4:3
J4:5
J4:2
J4:1
J4:6
3300µF
C13
2 3
1
45
6
K1
!
!
!
J2:3
J2:2
J2:1
J2:4
J2:5
J2:6
J1:1
J1:2
PWR RLY
F 1
1
1
AC N
AC L
WHT
BLK
D4
D5
D6
350mA
t
R2
1
1
1
1
1
1
CONVERSION PLUG
TEST ONLY
APPLY 12VDC
TO ENERGIZE RELAY
!
!
D1
+3.3VBU
+3.3VBU
.1µF
C2
.1µF
C3
6-32
GP5
AC ON
1
GRY
BLU
BLK
1
1
1
WHT
ORN
VIO
1
1
J3:4
J3:3
J3:5
J3:2
J3:1
J3:6
6-32
GP1
6-32
GP2 OPEN
C21
6-32
GP3
220µF
C4
220µF
C23
FN1
T1
T2
100V 50/60Hz
110-127V 50/60Hz
220-240V 50/60Hz
T2AL 250V
T1.6AL 250V
T800mAL 250V
F1
PRIMARY LINE VOLTAGE
! ! ! !
VOLTAGE SELECTION JUMPERS
240V
220V
120V
100V
100V
120V
230V
110V
110V

15 16
CONTROL DATA 751784 PCB
2

C1100
17 18
POWER SUPPLY 751785 SCH
3
15
14
T1
T1
OR G
OR G
213V
18V
193V
175V
POWER
TRANSFO RMER
232V
193V
190V
24.5V
-18V
.1 µF
C13
22 1 k
R39
10 0 µF
C1
22 1 k
R38
3
1
2
Q 2
SEC 3
1M
R41
3300pF
C36
33 . 2 k
R43
15 0 k
R36
22 0 µF
C14
!
T1
T1
1
1
T1 1
T1 1
1
BL K
RED
RED
.0 4 7 µF
C9
D2
D3
T1
BL U
.1 µF
C27
D6
D4
D1
D5
3A
T°
R24
SEC 1
10
9
8
7
12
SEC 2
1
3A
T°
R29
8V_UNR EG
YEL
10000µF
C25
11
YEL
1
AC ON
221k
R37
.2 2 µF
C37
15m A
NC
47 5R31. 5 k
R2
47 5
R14
1. 5 k
R16
18V
-18V
18V
1k
R42
18.7V
10 µF
C33
.0 4 7 µF
C32
33 0 0 µF
C4
33 0 0 µF
C5
33 0 0 µF
C3
4. 7 5 k
R1
4. 7 5 k
R15
18.6V
24.5V
.1 µF
C6
10 0 µF
C7
681
R6
33 . 2 k
R5 18.6VM
8.25k
R8
18.8V
.1 µF
C11 100µF
C10
681
R10
33.2k
R9
18.6VP
8. 2 5 k
R13
OPEN
R7
OPEN
R12
-18.6V
.1 µF
C19 220µF
C20
681
R19
33.2k
R18 -18.6VM
8.25k
R21
-18.6V
.1 µF
C22
22 0 µF
C23
68 1R2333 . 2 k
R22 -18.6VP
8.25k
R26
10 0 µF
C21
10 0 µF
C24
OPEN
R20
OPEN
R25
-24.5V
33 0 0 µF
C 1 6
33 0 0 µF
C 1 7
33 0 0 µF
C 1 5
10 0 µF
C12
10 0 µF
C8
33
R34
15 0 k
R40
J1 :1
J1 :3
J1 :1 6
J1 :4
J1 :1 7
J1 :5
J1 :1 2
O U P UT T O T U BE P R E A M P L IF IE R
J1 :1 8
J1 :9
J1 :2 2
J1 :2 4
J1 :1 3
J1 :1 5
J1 :7
J1 :2 0
J1 :8
J1 :2 1
J1 :6
J1 :1 9
J1 :2 5
J1 :2 3
J1 :1 1
T TXD
T RXD
J1 :1 0
190V
190V
18V
-18V
18.8VM
18.8VP
-18.8VP
-18.8VM
5V
.1 µF
C30
IN
ON/OFF
OUT
GND ADJ
___TAB
1
6
2
3
4 5
U7
15 0 k
R28
47 . 5 k
R30
L1
22 0 µF
C28
1000pF
C29
PS ON
READY
L CBL
Female
DB25 Connector
J3 :1
J3 :2
J3 :3
J3 :4
J3 :5
J3 :6
J3 :7
J3 :8
J3 :9
J3 :1 0
J3 :1 1
J3 :1 2
J3 :1 3
J3 :1 4
J3 :1 5
J3 :1 6
J3 :1 7
J3 :1 8
5V
5V
T RXD
T TXD
AC ON
PS ON
READY
TO CONTROL DATA PCB
24V UN REG
24V UN REG 13V
24.5V
10 µF
C31
475
R27
2. 2 1 k
R31
10 µF
C2
10 µF
C18
.0 4 7 µF
C 3 5
10000µF
C26
47.5k
R32
R CBL
2. 2 1 k
R33
R CBL
NC M RS T
V F D LE F T
P S RIGHT
6-3 2
G P1
IN(TAB) OUT
ADJ
1
2 3
U4
IN(TAB) OUT
ADJ
1
2 3
U5
IN(TAB) OUT
ADJ
1
2 3
U6
IN OUT(TAB)
ADJ
1
23
U1
IN OUT(TAB)
ADJ
1
23
U2
IN OUT(TAB)
ADJ
1
23
U3
IN OUT(TAB)
ADJ
1
23
U8
3
2
1
Q 3
T125m AL250V
F1
FH 1
J2 :1
J2 :2
J2 :3
J2 :4
J2 :5
J2 :6
J2 :7
J2 :8
J2 :9
1. 8 5 A
t
R4
1. 8 5 A
t
R11
3
21
D
S
GQ 1
J1 :2 7
J1 :2 6
1. 8 2 k
R35
2 20 µF
C 3 8
D7
D8
D10
D11
2 2µF
C 3 4
2 2µF
C 3 9
D12
D13
D14
D15
D16
D17
24V UN REG
D 2 1
D 1 9
D 2 0 D 1 8
1
3
D9
1
8V
3.7V
5V8V
-24.5V
-17.3V
-24.5V
-16.7V
-24.5V
17.3V
24.5V
18.6V
17.3V
16.7V
13V VPC 2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
T1/T2
-17.3V

19 20
POWER SUPPLY 751785 PCB
3

C1100
21 22
4
VFD CS
VFD DA
VFD CL
DS5DS4
2.74k
R28
10k
R41
10k
R27 .1µF
C13
D I2C DA
D I2C CL
.1µF
C12
10µH
L1
470µF
C11 J9:1
J9:2
J9:3
J9:5
J9:4
A = 0 1 1 (3)
+5 V D+5 V D
+3 .3V BU+3 .3V BU
INPUT
LOGO
3
1
2
Q1
+5 V D
DISPLAY
4
Q3
7
VSS
8
Q1
5
A1
2
A2
3
Q4 9
Q5 10
Q7 12
SDA 15
SCL 14
Q2
6
A0
1
Q0
4
Q6 11
VDD 16
NC 13
U5
2.74k
R24
SETUP
2.74k
R26
MUTE
10k
R43
DS6
+5 V D
DS13 DS14
2.74k
R29
DS16
2.74k
R22
DS11
2.74k
R19
TRIM
1.21k
R20
ADJUST
DS8 DS9
2.74k
R21
DS10
STANDBY/ON
MUTE STA NDB Y /ON
+3 .3V BU
1.21k
R17
DS7
2.74k
R23
DS12DS15
2.74k
R31
DS18
2.74k
R34
DS21
2.74k
R37
DS24
2.74k
R39
DS26
2.74k
R30
DS17
2.74k
R33
DS20
2.74k
R36
DS23
6.81k
R4
DS2
FP RST
VOLUME
D GN D
+5 V D
4.75k
R70
.2 5 0
MP1
.2 5 0
MP2
.2 5 0
MP3
.2 5 0
MP4
HXD
HXD
S E T UP
2.74k
R5
DS3
TO VFD
22.1k
R6
10k
R15
10k
R14
+3 .3V BU
750913 = 058195 + 14 pin conn (117647)2X20 VFD ASSY
DS1
DISPLAY/PUSHBUTTON 751786 SCH 1 of 2
5

23 24
150
R2
10µF
C1
Vs
2
OUT
1
GND
3
IR1
.1µF
C2
22.1
R1
KEY REF
2.21k
R11
MU TE
HXD
SET UP
.1µF
C5
A B
C
GNDGND
1
2 3
4
5
S2
+3 .3V BU
S6
S5
S7
INPUT
STANDBY/ ON
42
1
3
Vcc
GND
5
U4
+3 .3V BU 2.21k
R10
+3 .3V BU
3. 3V
1. 028V
NO PU SH
MU TE
1. 65V H XD
TO CONTROL DATA
.1µF
C8
+3 .3V BU
J4:1
J7:1
J4:7
J4:4
J4:6
J4:8
J4:3
J4:5
J7:3
J7:4
J7:5
J7:6
J7:8
J7:2
J2:4
J2:3
J2:2
J2:1
+5 V D
+3 .3V BU
+5 V D
KEY REF
J1:1
IN P A
IN P B
VFD CS
VFD DA
VFD CL
D I2C DA
D I2C CL
VOL A
VOL B
PW R
FR IR
R KEY
VOLUME
J1:2
J1:3
J1:4
J1:5
J1:6
J1:7
J1:8
J1:9
J1:10
J1:11
J1:12
J1:13
J1:14
J1:15
J1:16
J1:17
J1:18
J1:19
J1:20
J1:21
J1:22
J1:23
ST BY
6-32
GP1
FP RST
S4
MU TE
HXD
SET UP
SET UP2. 25V
475
R9
10µF
C3
475k
R8
D1
42
1
3
Vcc
GND
5
U2
+3 .3V BU
A B
C
1 2
3
4
5
S8
A B
C
1
2 3
4
5
S3
TRIM ADJUS T
TR IM B
TR IM A
ADJU ST B
ADJU ST A
10k
R3
4.75k
R12
2.21k
R13
1k
R7
SET UP+M UTE
SET UP+H XD
MU TE+H XD
.898V
1. 34V
.784V
6-32
GP3
6-32
GP4
6-32
GP2
.47µF
C4
( SWITCH ON BRACKET)
GNDGND
GNDGND
FRONT PANEL
IR SENSOR
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
5
5
5
5
5
4
4
4
4
4
5
PUSHBUTTON
4DISPLAY/PUSHBUTTON 751786 SCH 2 of 2
5

C1100
25 26
4DISPLAY/PUSHBUTTON 751786 PCB
5

C1100
PARTS LIST
2
29
Ref. No. Description Part No.
C1 CAP MONO .1uF 50V ±20% X7R SMD 061365
C2 CAP MONO .1uF 50V ±20% X7R SMD 061365
C3 CAP MONO .1uF 50V ±20% X7R SMD 061365
C4 CAP ELECT 220UF 25V SMD 066606
C5 CAP MONO .1uF 50V ±20% X7R SMD 061365
C6 CAP MONO .1uF 50V ±20% X7R SMD 061365
C7 CAP MONO .1uF 50V ±20% X7R SMD 061365
C8 CAP MONO .1uF 50V ±20% X7R SMD 061365
C9 CAP MONO .1uF 50V ±20% X7R SMD 061365
C10 CAP MONO .1uF 50V ±20% X7R SMD 061365
C11 CAP MONO .1uF 50V ±20% X7R SMD 061365
C12 CAP MONO .1uF 50V ±20% X7R SMD 061365
C13 CAP ELECT 3300UF 35V 066509
C14 CAP MONO .1uF 50V ±20% X7R SMD 061365
C15 CAP MONO .1uF 50V ±20% X7R SMD 061365
C16 CAP MONO .1uF 50V ±20% X7R SMD 061365
C17 CAP MONO .1uF 50V ±20% X7R SMD 061365
C18 CAP MONO .1uF 50V ±20% X7R SMD 061365
C19 CAP MONO .1uF 50V ±20% X7R SMD 061365
C20 CAP MONO .1uF 50V ±20% X7R SMD 061365
C22 CAP MONO .1uF 50V ±20% X7R SMD 061365
C23 CAP ELECT 220UF 25V SMD 066606
C27 CAP ELECT 220UF 25V SMD 066606
C34 CAP MONO .1uF 50V ±20% X7R SMD 061365
C35 CAP ELECT 4.7UF 50V SMD 066601
C36 CAP MONO .1uF 50V ±20% X7R SMD 061365
C37 CAP MONO .1uF 50V ±20% X7R SMD 061365
C38 CAP ELECT 4.7UF 50V SMD 066601
C39 CAP MONO .1uF 50V ±20% X7R SMD 061365
C40 CAP MONO .1uF 50V ±20% X7R SMD 061365
C41 CAP MONO .1uF 50V ±20% X7R SMD 061365
C42 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C43 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C44 CAP MONO .1uF 50V ±20% X7R SMD 061365
C45 CAP MONO .1uF 50V ±20% X7R SMD 061365
C46 CAP MONO .1uF 50V ±20% X7R SMD 061365
C47 CAP MONO .1uF 50V ±20% X7R SMD 061365
C48 CAP MONO .1uF 50V ±20% X7R SMD 061365
C49 CAP MONO .1uF 50V ±20% X7R SMD 061365
C50 CAP MONO .1uF 50V ±20% X7R SMD 061365
C53 CAP MONO .1uF 50V ±20% X7R SMD 061365
C54 CAP MONO .1uF 50V ±20% X7R SMD 061365
C55 CAP MONO .1uF 50V ±20% X7R SMD 061365
C56 CAP MONO .1uF 50V ±20% X7R SMD 061365
C57 CAP MONO .1uF 50V ±20% X7R SMD 061365
C58 CAP MONO .1uF 50V ±20% X7R SMD 061365
C59 CAP MONO .1uF 50V ±20% X7R SMD 061365
CONTROL DATA PCB 751784
1
CA1 CABLE FFC 18 CONDUCTOR 160MM 171549
CA2 CABLE ASSY POWER SW/BACKUP PS 171060
CA3 CABLE FFC 18 CONDUCTOR 160MM 171549
CA4 CABLE FLAT FLEXIBLE 23COND 250 171552
CA5 CABLE FLAT FLEX 8 PIN 1MM 173026
FN1 AC RECEPTACLE W/LINE FILTER 3A 118033
T1 CONTACT MCINTOSH SERVICE DEPARTMENT
T2 CONTACT MCINTOSH SERVICE DEPARTMENT
INTERCONNECT
Ref. No. Description Part No.
C60 CAP MONO .1uF 50V ±20% X7R SMD 061365
C61 CAP MONO .1uF 50V ±20% X7R SMD 061365
C62 CAP 100pF 200V 5% SMD0805 061390
C63 CAP MONO .1uF 50V ±20% X7R SMD 061365
C64 CAP MONO .1uF 50V ±20% X7R SMD 061365
C68 CAP MONO .1uF 50V ±20% X7R SMD 061365
C69 CAP .01uF 50V 20% X7R SMD0805 061372
D1 DIODE SCHOTTKY 40V 2A SMD 070210
D2 DIODE SMALL SIGNAL 4148 SMD 070199
D3 DIODE SCHOTTKY 40V 2A SMD 070210
D4 DIODE SCHOTTKY 40V 2A SMD 070210
D5 DIODE SCHOTTKY 40V 2A SMD 070210
D6 DIODE SCHOTTKY 40V 2A SMD 070210
D7 DIODE ESD SUPPRESSOR SMD 070198
D8 DIODE ESD SUPPRESSOR SMD 070198
D9 DIODE ESD SUPPRESSOR SMD 070198
D10 DIODE ESD SUPPRESSOR SMD 070198
D11 DIODE ESD SUPPRESSOR SMD 070198
D12 DIODE ESD SUPPRESSOR SMD 070198
D13 DIODE ESD SUPPRESSOR SMD 070198
D14 DIODE ESD SUPPRESSOR SMD 070198
D15 DIODE ESD SUPPRESSOR SMD 070198
D16 DIODE ESD SUPPRESSOR SMD 070198
D17 DIODE ESD SUPPRESSOR SMD 070198
D18 DIODE ESD SUPPRESSOR SMD 070198
D19 DIODE ESD SUPPRESSOR SMD 070198
D20 DIODE ESD SUPPRESSOR SMD 070198
D21 DIODE ESD SUPPRESSOR SMD 070198
D22 DIODE SMALL SIGNAL 4148 SMD 070199
D23 DIODE SMALL SIGNAL 4148 SMD 070199
D24 DIODE ESD SUPPRESSOR SMD 070198
D25 DIODE ESD SUPPRESSOR SMD 070198
D26 DIODE ESD SUPPRESSOR SMD 070198
D27 DIODE ESD SUPPRESSOR SMD 070198
D28 DIODE ESD SUPPRESSOR SMD 070198
D29 DIODE ESD SUPPRESSOR SMD 070198
D30 DIODE ESD SUPPRESSOR SMD 070198
D31 DIODE ESD SUPPRESSOR SMD 070198
D32 DIODE ESD SUPPRESSOR SMD 070198
D33 DIODE ESD SUPPRESSOR SMD 070198
D34 DIODE ESD SUPPRESSOR SMD 070198
D35 DIODE ESD SUPPRESSOR SMD 070198
D36 DIODE ESD SUPPRESSOR SMD 070198
D37 DIODE ESD SUPPRESSOR SMD 070198
D38 DIODE ESD SUPPRESSOR SMD 070198
D39 DIODE ESD SUPPRESSOR SMD 070198
D40 DIODE ESD SUPPRESSOR SMD 070198
D41 DIODE ESD SUPPRESSOR SMD 070198
F1 HOLDER FUSE 5X20MM PCB MOUNT 178159
GP1 TERMINAL PC MOUNT 6-32 117975
GP2 TERMINAL PC MOUNT 6-32 117975
J1 CONNECTOR 2PIN HEADER 11.88MM 118026
J2 CONN PCB MOUNT POWER RED 117719
J3 CONN PCB MOUNT POWER RED 117719
J4 CONN PCB MOUNT POWER RED 117719
J5 CONN 2 PIN MALE 117213
J6 CONN 23 PIN FFC SMD 118004
J7 CONN SHROUDED HEADER 2 X 8 117977

30
Ref. No. Description Part No.
CONTROL DATA PCB 751784 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
2
J8 CONN USB JACK TYPE B RA 117905
J9 CONN 18 PIN FFC SMD 118003
J10 CONN 18 PIN FFC SMD 118003
J11 JACK HEADPHONE DUAL BLACK 1/8” 117825
J12 JACK HEADPHONE DUAL BLACK 1/8” 117825
J13 JACK HEADPHONE DUAL BLACK 1/8” 117825
J14 JACK HEADPHONE DUAL BLACK 1/8” 117825
J15 JACK HEADPHONE DUAL BLACK 1/8” 117825
J16 JACK HEADPHONE DUAL BLACK 1/8” 117825
J17 JACK HEADPHONE DUAL BLACK 1/8” 117825
J18 JACK HEADPHONE DUAL BLACK 1/8” 117825
J19 JACK HEADPHONE DUAL BLACK 1/8” 117825
J21 CONN 5 PIN M12 PCB FEMALE 118121
K1 RELAY 12VDC 5A 250VAC TV-4 087077
L1 FERRITE 60 OHM 5 AMP SMD 076025
L2 FERRITE 600 OHM 1 AMP SMD 076026
L3 FERRITE 600 OHM 1 AMP SMD 076026
L4 FERRITE 600 OHM 1 AMP SMD 076026
L5 FERRITE 600 OHM 1 AMP SMD 076026
L6 FERRITE 600 OHM 1 AMP SMD 076026
L7 FERRITE 600 OHM 1 AMP SMD 076026
L8 FERRITE 600 OHM 1 AMP SMD 076026
L9 FERRITE 600 OHM 1 AMP SMD 076026
L10 FERRITE 600 OHM 1 AMP SMD 076026
L11 FERRITE 600 OHM 1 AMP SMD 076026
L12 FERRITE 600 OHM 1 AMP SMD 076026
L13 FERRITE 600 OHM 1 AMP SMD 076026
L14 FERRITE 600 OHM 1 AMP SMD 076026
L15 FERRITE 600 OHM 1 AMP SMD 076026
L16 FERRITE 600 OHM 1 AMP SMD 076026
L17 FERRITE 600 OHM 1 AMP SMD 076026
L18 FERRITE 600 OHM 1 AMP SMD 076026
L19 FERRITE 600 OHM 1 AMP SMD 076026
L20 FERRITE 600 OHM 1 AMP SMD 076026
L21 FERRITE 600 OHM 1 AMP SMD 076026
L22 FERRITE 600 OHM 1 AMP SMD 076026
L24 FERRITE 600 OHM 1 AMP SMD 076026
L26 FERRITE 600 OHM 1 AMP SMD 076026
L28 FERRITE 600 OHM 1 AMP SMD 076026
L30 FERRITE 600 OHM 1 AMP SMD 076026
PCB1 PC BD CONTROL DATA 130289
Q1 TRANSISTOR NPN A05 SMD 132333
Q2 TRANSISTOR NPN A05 SMD 132333
Q3 TRANSISTOR NPN A05 SMD 132333
Q4 TRANSISTOR NPN A05 SMD 132333
Q5 TRANSISTOR NPN A05 SMD 132333
Q6 TRANSISTOR NPN A05 SMD 132333
Q7 TRANSISTOR NPN A05 SMD 132333
Q8 TRANSISTOR NPN A05 SMD 132333
Q9 TRANSISTOR NPN A05 SMD 132333
Q10 TRANSISTOR NPN A05 SMD 132333
Q11 TRANSISTOR NPN A05 SMD 132333
Q12 TRANSISTOR NPN A05 SMD 132333
Q13 TRANSISTOR NPN A05 SMD 132333
Q14 TRANSISTOR NPN A05 SMD 132333
Q15 TRANSISTOR NPN A05 SMD 132333
Q16 TRANSISTOR NPN A05 SMD 132333
Q17 TRANSISTOR NPN A05 SMD 132333
Q18 TRANSISTOR NPN A05 SMD 132333
Q19 TRANSISTOR NPN A05 SMD 132333
Q20 TRANSISTOR NPN A05 SMD 132333
Q21 TRANSISTOR NPN A05 SMD 132333
Q22 TRANSISTOR NPN A05 SMD 132333
Q23 TRANSISTOR NPN A05 SMD 132333
Q24 TRANSISTOR NPN A05 SMD 132333
Q25 TRANSISTOR NPN A05 SMD 132333
Q26 TRANSISTOR NPN A05 SMD 132333
Q27 TRANSISTOR NPN A05 SMD 132333
Q28 TRANSISTOR NPN A05 SMD 132333
Q29 TRANSISTOR NPN A05 SMD 132333
Q30 TRANSISTOR NPN A05 SMD 132333
Q31 TRANSISTOR NPN A05 SMD 132333
Q32 TRANSISTOR NPN A05 SMD 132333
Q33 TRANSISTOR NPN A05 SMD 132333
Q34 TRANSISTOR NPN A05 SMD 132333
Q35 TRANSISTOR NPN A05 SMD 132333
Q36 TRANSISTOR NPN A05 SMD 132333
Q37 TRANSISTOR NPN A05 SMD 132333
Q38 TRANSISTOR NPN A05 SMD 132333
Q39 TRANSISTOR NPN A05 SMD 132333
Q40 TRANSISTOR PNP W/R1R2 10K/10K SMD 132348
R1 FUSE 0.35A 16V RESET 1206 SMD 145054
R2 FUSE 0.35A 16V RESET 1206 SMD 145054
R3 RES SMD0805 22.1K 1/8W 1% 145012
R4 RES SMD0805 2.21K 1/8W 1% 145024
R5 RES SMD0805 3.32K 1/8W 1% 145026
R6 RES SMD0805 22.1 1/8W 1% 145003
R7 RES SMD0805 150K 1/8W 1% 145037
R8 RES SMD0805 22.1K 1/8W 1% 145012
R9 RES SMD0805 4.75K 1/8W 1% 145008
R10 RES SMD0805 4.75K 1/8W 1% 145008
R11 RES SMD0805 2.21K 1/8W 1% 145024
R12 RES SMD0805 3.32K 1/8W 1% 145026
R13 RES SMD0805 22.1 1/8W 1% 145003
R14 RES SMD0805 22.1K 1/8W 1% 145012
R15 RES SMD0805 4.75K 1/8W 1% 145008
R16 RES SMD0805 2.21K 1/8W 1% 145024
R17 RES SMD0805 3.32K 1/8W 1% 145026
R18 RES SMD0805 22.1 1/8W 1% 145003
R19 RES SMD0805 22.1K 1/8W 1% 145012
R20 RES SMD0805 4.75K 1/8W 1% 145008
R21 RES SMD0805 2.21K 1/8W 1% 145024
R22 RES SMD0805 3.32K 1/8W 1% 145026
R23 RES SMD0805 22.1 1/8W 1% 145003
R24 RES SMD0805 10 1/8W 1% 145017
R25 RES SMD0805 22.1 1/8W 1% 145003
R26 RES SMD0805 22.1 1/8W 1% 145003
R27 RES SMD0805 22.1 1/8W 1% 145003
R28 RES SMD0805 22.1 1/8W 1% 145003
R29 RES SMD0805 22.1 1/8W 1% 145003
R30 RES SMD0805 22.1K 1/8W 1% 145012
R31 RES SMD0805 100 1/8W 1% 145005
R32 RES SMD0805 10 1/8W 1% 145017
R33 RES SMD0805 1K 1/8W 1% 145007
R34 RES SMD0805 22.1K 1/8W 1% 145012
R35 RES SMD0805 4.75K 1/8W 1% 145008
R36 RES SMD0805 2.21K 1/8W 1% 145024
R37 RES SMD0805 3.32K 1/8W 1% 145026

C1100
Ref. No. Description Part No.
CONTROL DATA PCB 751784 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
31
2
R38 RES SMD0805 22.1 1/8W 1% 145003
R39 RES SMD0805 22.1K 1/8W 1% 145012
R40 RES SMD0805 22.1 1/8W 1% 145003
R41 RES SMD0805 22.1K 1/8W 1% 145012
R42 RES SMD0805 22.1K 1/8W 1% 145012
R43 RES SMD0805 22.1K 1/8W 1% 145012
R44 RES SMD0805 22.1K 1/8W 1% 145012
R45 RES SMD0805 2.21K 1/8W 1% 145024
R46 RES SMD0805 100 1/8W 1% 145005
R47 RES SMD0805 10 1/8W 1% 145017
R48 RES SMD0805 22.1K 1/8W 1% 145012
R49 RES SMD0805 22.1K 1/8W 1% 145012
R50 RES SMD0805 22.1 1/8W 1% 145003
R51 RES SMD0805 22.1 1/8W 1% 145003
R52 RES SMD0805 10 1/8W 1% 145017
R53 RES SMD0805 10 1/8W 1% 145017
R54 RES SMD0805 10 1/8W 1% 145017
R55 RES SMD0805 10 1/8W 1% 145017
R56 RES SMD0805 10 1/8W 1% 145017
R57 RES SMD0805 10 1/8W 1% 145017
R58 RES SMD0805 100 1/8W 1% 145005
R59 RES SMD0805 100 1/8W 1% 145005
R60 RES SMD0805 100 1/8W 1% 145005
R61 RES SMD0805 100 1/8W 1% 145005
R62 RES SMD0805 100 1/8W 1% 145005
R63 RES SMD0805 100 1/8W 1% 145005
R64 RES SMD0805 1.5K 1/8W 1% 145022
R65 RES SMD0805 22.1K 1/8W 1% 145012
R66 RES SMD0805 22.1K 1/8W 1% 145012
R67 RES SMD0805 22.1K 1/8W 1% 145012
R68 RES SMD0805 22.1K 1/8W 1% 145012
R69 RES SMD0805 22.1K 1/8W 1% 145012
R70 RES SMD0805 22.1K 1/8W 1% 145012
R71 RES SMD0805 4.75K 1/8W 1% 145008
R72 RES SMD0805 2.21K 1/8W 1% 145024
R73 RES SMD0805 47.5K 1/8W 1% 145013
R74 RES SMD0805 3.32K 1/8W 1% 145026
R75 RES SMD0805 22.1 1/8W 1% 145003
R76 RES SMD0805 475K 1/8W 1% 145040
R77 RES SMD0805 150 1/8W 1% 145019
R78 RES SMD0805 2.21K 1/8W 1% 145024
R79 RES SMD0805 22.1K 1/8W 1% 145012
R80 RES SMD0805 10 1/8W 1% 145017
R81 RES SMD0805 4.75K 1/8W 1% 145008
R82 RES SMD0805 4.75K 1/8W 1% 145008
R83 RES SMD0805 2.21K 1/8W 1% 145024
R84 RES SMD0805 22.1K 1/8W 1% 145012
R85 RES SMD0805 22.1K 1/8W 1% 145012
R86 RES SMD0805 3.32K 1/8W 1% 145026
R87 RES SMD0805 22.1 1/8W 1% 145003
R88 RES SMD0805 150 1/8W 1% 145019
R89 RES SMD0805 10 1/8W 1% 145017
R90 RES SMD0805 4.75K 1/8W 1% 145008
R91 RES SMD0805 22.1K 1/8W 1% 145012
R92 RES SMD0805 4.75K 1/8W 1% 145008
R93 RES SMD0805 4.75K 1/8W 1% 145008
R94 RES SMD0805 4.75K 1/8W 1% 145008
R95 RES SMD0805 4.75K 1/8W 1% 145008
R96 RES SMD0805 4.75K 1/8W 1% 145008
R97 RES SMD0805 22.1K 1/8W 1% 145012
R98 RES SMD0805 150 1/8W 1% 145019
R99 RES SMD0805 150 1/8W 1% 145019
R100 RES SMD0805 150 1/8W 1% 145019
R101 RES SMD0805 150 1/8W 1% 145019
R102 RES SMD0805 150 1/8W 1% 145019
R103 RES SMD0805 10 1/8W 1% 145017
R104 RES SMD0805 10 1/8W 1% 145017
R105 RES SMD0805 10 1/8W 1% 145017
R106 RES SMD0805 10 1/8W 1% 145017
R107 RES SMD0805 10 1/8W 1% 145017
R108 RES SMD0805 10 1/8W 1% 145017
R109 RES SMD0805 1K 1/8W 1% 145007
R111 RES SMD0805 1K 1/8W 1% 145007
R112 RES SMD0805 100K 1/8W 1% 145014
R113 RES SMD0805 100K 1/8W 1% 145014
R114 RES SMD0805 475 1/8W 1% 145020
R115 RES SMD0805 10K 1/8W 1% 145010
R116 RES SMD0805 10K 1/8W 1% 145010
R300 RES SMD0805 10K 1/8W 1% 145010
R301 RES SMD0805 10K 1/8W 1% 145010
S1 SWITCH TACT 260GF 5MM SMD 150072
S2 SWITCH TACT 260GF 5MM SMD 150072
T1 TRANSFORMER BACKUP 159376
U1 IC SINGLE NAND SCHMITT SMD 133724
U2 IC REGULATOR 3.3V 500mA SMD 133736
U3 IC DUAL RS232 3V W/SHUTDWN SMD 133707
U4 IC SINGLE 2-INPUT AND GATE SMD 133552
U9 IC I2C BUS REPEATER SMD 133769
U10 IC SINGLE 2-INPUT AND GATE SMD 133552
U11 IC SINGLE 2-INPUT AND GATE SMD 133552
U12 IC SINGLE 2-INPUT AND GATE SMD 133552
U13 IC MICRO 32-BIT SAM4S SMD 133875
U15 IC 8 BIT DRIVER SMD 133461
U20 IC EEPROM 256K BITS 3.3V SMD 133709
U22 IC SINGLE NAND SCHMITT SMD 133724
U23 IC SINGLE NAND SCHMITT SMD 133724
U24 IC OPTOCOUPLER SCHMITT SMD 133879
U25 IC SINGLE 2 INPUT OR GATE SMD 133700
U26 IC DUAL RS232 3V W/SHUTDWN SMD 133707
U27 IC MONO MULTIVIBRATOR SMD 133738
U28 IC SINGLE 2-INPUT AND GATE SMD 133502
U29 IC 8 BIT DRIVER SMD 133461
U30 IC 8 BIT DRIVER SMD 133461
U31 IC SNGLE 2-INPUT NAND GATE SMD 133501
U32 IC SNGLE 2-INPUT NAND GATE SMD 133501
U34 IC SINGLE NAND SCHMITT SMD 133724
U40 IC SINGLE NAND SCHMITT SMD 133724
Y1 CRYSTAL 12.00MHZ SMD 180103
R110 RES SMD0805 OPEN NONE
POWER SUPPLY PCB 751785
3
C1 CAP ELECT 100UF 25V SMD 066605
C2 CAP ELECT 10UF 50V SMD 066602
C3 CAP ELECT 3300UF 35V 066509
C4 CAP ELECT 3300UF 35V 066509
C5 CAP ELECT 3300UF 35V 066509
C6 CAP MONO .1uF 50V ±20% X7R SMD0805 061365

Ref. No. Description Part No.
POWER SUPPLY PCB 751785 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
32
3
C7 CAP ELECT 100UF 25V SMD 066605
C8 CAP ELECT 100UF 25V SMD 066605
C9 CAP POLYPROP 0.047UF 10% 275V 064466
C10 CAP ELECT 100UF 25V SMD 066605
C11 CAP MONO .1uF 50V ±20% X7R SMD0805 061365
C12 CAP ELECT 100UF 25V SMD 066605
C13 CAP MONO .1uF 50V ±20% X7R SMD0805 061365
C14 CAP ELECT 220UF 25V SMD 066606
C15 CAP ELECT 3300UF 35V 066509
C16 CAP ELECT 3300UF 35V 066509
C17 CAP ELECT 3300UF 35V 066509
C18 CAP ELECT 10UF 50V SMD 066602
C19 CAP MONO .1uF 50V ±20% X7R SMD0805 061365
C20 CAP ELECT 220UF 25V SMD 066606
C21 CAP ELECT 100UF 25V SMD 066605
C22 CAP MONO .1uF 50V ±20% X7R SMD0805 061365
C23 CAP ELECT 220UF 25V SMD 066606
C24 CAP ELECT 100UF 25V SMD 066605
C25 CAP ELECT 10000UF 10V 066595
C26 CAP ELECT 10000UF 10V 066595
C27 CAP MONO .1uF 50V ±20% X7R SMD0805 061365
C28 CAP ELECT 220UF 25V SMD 066606
C29 CAP NPO 1000pF 100V 5% SMD0805 061391
C30 CAP MONO .1uF 50V ±20% X7R SMD0805 061365
C31 CAP 10uF 20% 16V X5R SMD0805 061392
C32 CAP POLYPROP 0.047UF 10% 275V 064466
C33 CAP ELECT 10UF 250V 066558
C34 CAP ELECT 22UF 450V 066597
C35 CAP POLYPROP 0.047UF 10% 275V 064466
C36 CAP 3300PF 250V UL/CSA 061312
C37 CAP POLYPROP 0.22UF 400V 20% 064438
C38 CAP ELECT 220UF 25V SMD 066606
C39 CAP ELECT 22UF 450V 066597
D1 DIODE RECTIFIER 1000V 1A SMD 070225
D2 DIODE RECTIFIER 1000V 1A SMD 070225
D3 DIODE RECTIFIER 1000V 1A SMD 070225
D4 DIODE RECTIFIER 1000V 1A SMD 070225
D5 DIODE SCHOTTKY 40V 2A SMD 070210
D6 DIODE SCHOTTKY 40V 2A SMD 070210
D7 DIODE RECTIFIER 1000V 1A SMD 070225
D8 DIODE RECTIFIER 1000V 1A SMD 070225
D9 DIODE ZENER 10V 5% 0.35W SMD 070222
D10 DIODE RECTIFIER 1000V 1A SMD 070225
D11 DIODE RECTIFIER 1000V 1A SMD 070225
D12 DIODE RECTIFIER 1000V 1A SMD 070225
D13 DIODE RECTIFIER 1000V 1A SMD 070225
D14 DIODE RECTIFIER 1000V 1A SMD 070225
D15 DIODE RECTIFIER 1000V 1A SMD 070225
D16 DIODE RECTIFIER 1000V 1A SMD 070225
D17 DIODE RECTIFIER 1000V 1A SMD 070225
D18 DIODE ESD SUPPRESSOR SMD 070198
D19 DIODE ESD SUPPRESSOR SMD 070198
D20 DIODE ESD SUPPRESSOR SMD 070198
D21 DIODE ESD SUPPRESSOR SMD 070198
F1 FUSE 1/8A SLO-BLO 5X20 IEC 089128
FH1 HOLDER FUSE 5X20 PCB MOUNT 178159
GP1 TERMINAL PC MOUNT 6-32 117975
J1 CONN 25 PIN D RECEPTACLE 117901
J2 HEADER 9 CIRCUIT POST NATURAL 117724
J3 CONN 18 PIN FFC SMD 118003
L1 FERRITE 60 OHM 5 AMP SMD 076025
PCB1 PC BD POWER SUPPLY 130290
Q1 TRANSISTOR NCH MOSFET 800V SMD 132353
Q2 TRANSISTOR NPN A05 SMD 132333
Q3 TRANSISTOR NPN 300V BF420 132351
R1 RES SMD0805 4.75K 1/8W 1% 145008
R2 RES SMD0805 1.5K 1/8W 1% 145022
R3 RES SMD0805 475 1/8W 1% 145020
R4 POLYSWITCH 1.85A 72V 144716
R5 RES SMD0805 33.2K 1/8W 1% 145033
R6 RES SMD0805 681 1/8W 1% 145002
R7 RES SMD0805 OPEN NONE
R8 RES SMD0805 8.25K 1/8W 1% 145009
R9 RES SMD0805 33.2K 1/8W 1% 145033
R10 RES SMD0805 681 1/8W 1% 145002
R11 POLYSWITCH 1.85A 72V 144716
R12 RES SMD0805 OPEN NONE
R13 RES SMD0805 8.25K 1/8W 1% 145009
R14 RES SMD0805 475 1/8W 1% 145020
R15 RES SMD0805 4.75K 1/8W 1% 145008
R16 RES SMD0805 1.5K 1/8W 1% 145022
R18 RES SMD0805 33.2K 1/8W 1% 145033
R19 RES SMD0805 681 1/8W 1% 145002
R20 RES SMD0805 OPEN NONE
R21 RES SMD0805 8.25K 1/8W 1% 145009
R22 RES SMD0805 33.2K 1/8W 1% 145033
R23 RES SMD0805 681 1/8W 1% 145002
R24 POLYSWITCH 3.00A 72V 144722
R25 RES SMD0805 OPEN NONE
R26 RES SMD0805 8.25K 1/8W 1% 145009
R27 RES SMD0805 475 1/8W 1% 145020
R28 RES SMD0805 150K 1/8W 1% 145037
R29 POLYSWITCH 3.00A 72V 144722
R30 RES SMD0805 47.5K 1/8W 1% 145013
R31 RES SMD0805 2.21K 1/8W 1% 145024
R32 RES SMD0805 47.5K 1/8W 1% 145013
R33 RES SMD0805 2.21K 1/8W 1% 145024
R34 RES TF 33 1% 0.1W SMD0805 145080
R35 RES SMD0805 1.82K 1/8W 1% 145023
R36 RES SMD0805 150K 1/8W 1% 145037
R37 RES SMD0805 221K 1/8W 1% 145038
R38 RES SMD0805 221K 1/8W 1% 145038
R39 RES SMD0805 221K 1/8W 1% 145038
R40 RES SMD0805 150K 1/8W 1% 145037
R41 RES SMD0805 1M 1/8W 1% 145042
R42 RES SMD0805 1K 1/8W 1% 145007
R43 RES SMD0805 33.2K 1/8W 1% 145033
U1 IC REG POS ADJ 1.5A SMD 133822
U2 IC REG POS ADJ 1.5A SMD 133822
U3 IC REG POS ADJ 1.5A SMD 133822
U4 IC REG NEG ADJ 1.5A SMD 133821
U5 IC REG NEG ADJ 1.5A SMD 133821
U6 IC REG NEG ADJ 1.5A SMD 133821
U7 IC REG 1.2A LO-DROP ENABLE SMD 133717
U8 IC REG POS ADJ 1.5A SMD 133822

C1100
Ref. No. Description Part No.
DISPLAY/PUSHBUTTON PCB 751786 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
33
C1 CAP 10uF 20% 16V X5R SMD0805 061392
C2 CAP MONO .1uF 50V ±20% X7R SMD 061365
C3 CAP 10uF 20% 16V X5R SMD0805 061392
C4 CAP X7R .47uF 20% 50V SMD0805 061373
C5 CAP MONO .1uF 50V ±20% X7R SMD 061365
C8 CAP MONO .1uF 50V ±20% X7R SMD 061365
C11 CAP ELECT 470UF 16V SMD 066607
C12 CAP MONO .1uF 50V ±20% X7R SMD 061365
C13 CAP MONO .1uF 50V ±20% X7R SMD 061365
D1 DIODE SMALL SIGNAL 4148 SMD 070199
DS1 ASSY INFO VFD 750913
DS2 LED RED HIGH EFFICIENCY 5MM 058207
DS3 LED GRN REV MOUNT SMD 058212
DS4 LED RED HIGH EFFICIENCY 5MM 058207
DS5 LED RED HIGH EFFICIENCY 5MM 058207
DS6 LED RED HIGH EFFICIENCY 5MM 058207
DS7 LED GRN REV MOUNT SMD 058212
DS8 LED GRN REV MOUNT SMD 058212
DS9 LED GRN REV MOUNT SMD 058212
DS10 LED GRN REV MOUNT SMD 058212
DS11 LED GRN REV MOUNT SMD 058212
DS12 LED GRN REV MOUNT SMD 058212
DS13 LED GRN REV MOUNT SMD 058212
DS14 LED GRN REV MOUNT SMD 058212
DS15 LED GRN REV MOUNT SMD 058212
DS16 LED GRN REV MOUNT SMD 058212
DS17 LED GRN REV MOUNT SMD 058212
DS18 LED GRN REV MOUNT SMD 058212
DS20 LED GRN REV MOUNT SMD 058212
DS21 LED GRN REV MOUNT SMD 058212
DS23 LED GRN REV MOUNT SMD 058212
DS24 LED GRN REV MOUNT SMD 058212
DS26 LED GRN REV MOUNT SMD 058212
IR1 SENSOR IR 38KHZ 3V-5V RA 121066
J1 CONN 23 PIN FFC SMD 118004
J2 CONNECTOR 4 PIN HEADER 2MM 118014
J4 CONN 8 PIN FFC SMD 118118
J7 CONNECTOR FFC 8 PIN 117915
J9 TERMINAL STRIP 14 PIN .025 SQ 117647
L1 INDUCTOR 10UH 30% SMD 122438
MP1 SPACER LED 3/16 IN 017642
MP2 SPACER LED 3/16 IN 017642
MP3 SPACER LED 3/16 IN 017642
MP4 SPACER LED 3/16 IN 017642
PCB1 PC BD DISPLAY 130291
Q1 TRANSISTOR PNP A55 SMD 132334
4
5
R1 RES SMD0805 22.1 1/8W 1% 145003
R2 RES SMD0805 150 1/8W 1% 145019
R3 RES SMD0805 10K 1/8W 1% 145010
R4 RES SMD0805 6.81K 1/8W 1% 145029
R5 RES SMD0805 2.74K 1/8W 1% 145025
R6 RES SMD0805 22.1K 1/8W 1% 145012
R7 RES SMD0805 1K 1/8W 1% 145007
R8 RES SMD0805 475K 1/8W 1% 145040
R9 RES SMD0805 475 1/8W 1% 145020
R10 RES SMD0805 2.21K 1/8W 1% 145024
R11 RES SMD0805 2.21K 1/8W 1% 145024
R12 RES SMD0805 4.75K 1/8W 1% 145008
R13 RES SMD0805 2.21K 1/8W 1% 145024
R14 RES SMD0805 10K 1/8W 1% 145010
R15 RES SMD0805 10K 1/8W 1% 145010
R17 RES SMD0805 1.21k 1/8W 1% 145021
R19 RES SMD0805 2.74K 1/8W 1% 145025
R20 RES SMD0805 1.21k 1/8W 1% 145021
R21 RES SMD0805 2.74K 1/8W 1% 145025
R22 RES SMD0805 2.74K 1/8W 1% 145025
R23 RES SMD0805 2.74K 1/8W 1% 145025
R24 RES SMD0805 2.74K 1/8W 1% 145025
R26 RES SMD0805 2.74K 1/8W 1% 145025
R27 RES SMD0805 10K 1/8W 1% 145010
R28 RES SMD0805 2.74K 1/8W 1% 145025
R29 RES SMD0805 2.74K 1/8W 1% 145025
R30 RES SMD0805 2.74K 1/8W 1% 145025
R31 RES SMD0805 2.74K 1/8W 1% 145025
R33 RES SMD0805 2.74K 1/8W 1% 145025
R34 RES SMD0805 2.74K 1/8W 1% 145025
R36 RES SMD0805 2.74K 1/8W 1% 145025
R37 RES SMD0805 2.74K 1/8W 1% 145025
R39 RES SMD0805 2.74K 1/8W 1% 145025
R41 RES SMD0805 10K 1/8W 1% 145010
R43 RES SMD0805 10K 1/8W 1% 145010
R70 RES SMD0805 4.75K 1/8W 1% 145008
S2 SWITCH ROT ENCODER 24 DETENT 146255
S3 SWITCH ROT ENCODER 24 DETENT 146255
S4 SWITCH TACT 260GF 5MM SMD 150072
S5 SWITCH TACT 260GF 5MM SMD 150072
S6 SWITCH TACT 260GF 5MM SMD 150072
S7 SWITCH TACT 260GF 5MM SMD 150072
S8 POT ROTARY SWITCH QUADRATURE 146255
U2 IC SINGLE NAND SCHMITT SMD 133724
U4 IC SINGLE NAND SCHMITT SMD 133724
U5 IC 8 BIT DRIVER SMD 133461
