MCZ Veld Technical manual

8901142800
USE AND INSTALLATION
MANUAL
EN
NuTech Renewables Ltd
Unit 11, Warrenpoint
Enterprise Centre
Newry Road, Warrenpoint
Co.Down, BT34 3LA
Tel: + 44 28 417 53031
Email: [email protected]
www.NuTechrenewables.com

Contents
USE AND MAINTENANCE MANUAL
page 2
Contents Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
INTRODUCTION....................................................................................................................................3
Document revisions ...............................................................................................................................3
Manual care ..........................................................................................................................................3
How to consult the manual.....................................................................................................................3
1. WARNINGS AND GUARANTEE TERMS...............................................................................................4
1.1. GENERAL SAFETY WARNINGS..........................................................................................................4
1.2. OPERATIONAL WARNINGS ..............................................................................................................4
1.3. GUARANTEE TERMS........................................................................................................................5
1.3.1. Guarantee limits.......................................................................................................................5
1.3.2. Exclusions................................................................................................................................5
1.4. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC
DIRECTIVE 2002/96/EC .............................................................................................................................5
2. INSTALLATION RECOMMENDATIONS IN COMPLIANCE WITH UNI 10683 ......................................6
2.1. THE OPERATING ENVIRONMENT .....................................................................................................6
2.2. THE OPERATING ENVIRONMENT .....................................................................................................7
2.2.1. Safe distances..........................................................................................................................7
2.3. CONNECTING THE COMBUSTION AIR INLET PIPE.............................................................................8
2.4. EXTERNAL AIR INLET......................................................................................................................8
2.5. FLUE PIPE CONNECTION...............................................................................................................10
2.6. FLUE PIPE....................................................................................................................................10
2.6.1. Flue pipe examples.................................................................................................................11
2.7. CHIMNEY .....................................................................................................................................12
3. DIMENSIONS AND TECHNICAL SPECIFICATIONS..........................................................................13
3.1. VELD STOVE ................................................................................................................................13
3.1.1. Technical specifications...........................................................................................................14
4. INSTALLATION AND ASSEMBLY .....................................................................................................15
4.1. PREPARATION AND UNPACKING....................................................................................................15
4.2. FOOT ASSEMBLY AND ADJUSTMENT..............................................................................................16
4.3. CERAMIC CLADDING ASSEMBLY ....................................................................................................16
5. OPERATION.....................................................................................................................................18
5.1. WARNINGS PRIOR TO START-UP...................................................................................................18
5.2. FUEL............................................................................................................................................18
5.3. USING THE STOVE .......................................................................................................................19
5.3.1. FUEL LOADING ......................................................................................................................19
5.3.2. COMBUSTION CONTROL.........................................................................................................19
5.3.2.1. VELD stove air control......................................................................................................20
5.3.3. FIRST START-UP....................................................................................................................21
5.4. AIR DIFFUSION SYSTEMS .............................................................................................................22
5.4.1. Natural..................................................................................................................................22
5.4.2. Air (optional kit) .....................................................................................................................22
6. MAINTENANCE AND CLEANING......................................................................................................23
6.1. CLEANING UNDER THE USER'S RESPONSIBILITY ............................................................................23
6.1.1. Cleaning the glazing ...............................................................................................................23
6.1.2. Cleaning the upper Calorite deflectors ......................................................................................23
6.1.3. Ash removal...........................................................................................................................23
6.1.4. Cleaning stainless and matt steel surfaces ................................................................................23
6.1.5. Cleaning painted parts ............................................................................................................24
6.1.6. Cleaning the flue pipe.............................................................................................................24
6.2. CLEANING UNDER THE RESPONSIBILITY OF SPECIALISED STAFF ....................................................24
6.3. QUICK RESPONSE.........................................................................................................................24

Introduction
USE AND MAINTENANCE MANUAL
page 3
Introduction Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
INTRODUCTION
Dear customer,
Thank you for purchasing this MCZ appliance. We are
convinced that, as you operate it, you will appreciate
the high quality of this appliance, which is the result
of painstaking design and thorough testing. Our aim is
to combine technology with simple use and, first and
foremost, safety.
Products built with OYSTER technology, where
appropriately installed, due to their fully watertight
structure, do not draw on the oxygen inside the room.
Instead, they draw air from the outside environment
and can therefore be fitted in all well-insulated homes
and in passive houses. This technology eliminates all
risk of smoke being released into the room and
ventilation grilles are no longer required.
Consequently, there will be no more flows of cold air
into the room, making it less comfortable and
compromising the overall efficiency of the system.
In the case of forced ventilation or rooms that may be
in a negative vacuum compared to the outside, a
sealed stove can be installed.
To allow optimal operation of the stove and to
benefit fully from the heat and sense of well-
being distributed throughout your home, we
advise you to read this manual carefully before
starting it up for the first time; in the event of
faults or if in doubt, please contact your
retailer, who will provide all the necessary
assistance.
Document revisions
In order to improve the product and to update this
document, the Manufacturer reserves the right to
make any changes without notice.
All reproduction, including partial, of this manual is
strictly prohibited without the Manufacturer's
authorisation.
Manual care
Take care of this manual and keep it in an easily
and rapidly accessible place.
Should you misplace or destroy the manual or
should it be damaged irreparably, ask your
retailer or the Manufacturer for another copy,
specifying the product identification data.
How to consult the manual
Any vital topics or those requiring special
attention are printed in “bold text”.

“Italic text” is used to invite the user to observe
the explanatory figures beside it or to check other
sections in the manual which may provide an
additional explanation.
NOTE: the “NOTE” provides the reader with
additional information about the topic.
These symbols indicate specific messages
found in this manual
CAUTION!
This warning symbol indicates you should
read carefully and understand the
message it refers to since failure to
observe the instructions given could
damage the stove seriously and also
endanger the person using it.
INFORMATION:
This symbol is used to highlight the
information that is deemed important for
the correct functioning of the stove.
Failure to observe the instructions
provided will jeopardise the use of the
appliance, the functioning of which may
prove unsatisfactory

Chapter 1
USE AND MAINTENANCE MANUAL
page 4
Warnings and guarantee terms Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
1. WARNINGS AND GUARANTEE
TERMS
1.1. GENERAL SAFETY WARNINGS
Installation, electrical connection,
functional check and maintenance of this
device must only be performed by qualified
or authorised personnel.
Install the stove in accordance with all the
local and national laws, and the applicable
European Standards in force in the place,
region or country of installation.
This appliance must not be used by anyone
(including children) with limited physical,
sensory or mental skills or with little
experience and knowledge, unless they are
supervised or have been instructed to use
the device by the person in charge of its
safety.
Only use the fuel recommended by MCZ.
The appliance must not be used as an
incinerator. The use of liquid fuel is strictly
forbidden.
The instructions provided in this manual must
always be observed to ensure the correct use of
this stove and of any appliances connected to it
as well as to avoid any accidents.
The user - or whoever is operating the stove -
must read and fully understand the contents of
this instruction manual before beginning any
operation.
The stove must only be used for its intended use.
Any other use is to be considered incorrect and
therefore dangerous.
Do not use the stove as a ladder or supporting
structure.
Do not place laundry in the stove to dry; any
clothes airers or similar items should be kept at a
safe distance from the stove. Fire hazard.
Assess the static conditions of the surface on
which the weight of the stove will bear and
provide suitable insulation if it is made of
flammable material (e.g. wood, fitted carpet,
plastic).
Avoid installing the appliance in rooms containing
type B gas appliances, or hoods with or without
an extractor fan, heat pumps, or collective
ventilation ducts (If Oyster technology is not
implemented).
Avoid having several operational flue ducts in the
room, or the proximity of a stair well and make
sure that there are no appliances in adjacent
communicating rooms, the concurrent use of
which causes a vacuum in one of the two rooms.
All liability for the incorrect use of the product lies
fully with the user and relieves MCZ of any civil
and criminal liability.
All unauthorised tampering or replacement with
non-original stove spare parts could endanger the
operator and relieves MCZ of any civil and
criminal liability.
Parts of the surface of the stove can get very hot
(door, handle, glass, smoke outlet pipe, etc.).
Please therefore avoid coming into contact with
these parts without wearing suitable protective
clothing or using appropriate measures, such as
heat protective gloves.
Incorrect installation or poor maintenance (not
conforming to the instructions provided herein)
could cause personal injury or harm animals or
cause property damage. In this case, MCZ is
relieved of any civil and criminal liability.
1.2. OPERATIONAL WARNINGS
Use the appliance in accordance with all the
local and national laws, and the applicable
European Standards in force in the place,
region or country of use.
Turn off the stove in the event of a failure or
malfunctioning.
Install the stove in premises which are suitably
protected against fire hazards and equipped with
all the utilities such as supplies (air and
electricity) and smoke exhaust.
Do not use volatile and/or flammable substances
(petrol-alcohol-etc.) to ignite the fire.
INFORMATION:
Please contact your retailer or MCZ's qualified
authorised personnel for any issues, and in the
event of repairs, demand original spare parts.
Check and clean the smoke outlet pipe regularly
in accordance with the provisions of the
applicable regulations in the country of installation
Keep this instruction manual in a safe place, as it
should accompany the stove along its entire life
cycle. If the stove is sold or transferred to another
user, always ensure that the manual accompanies
the appliance.

Chapter 1
USE AND MAINTENANCE MANUAL
page 5
Warnings and guarantee terms Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
1.3. GUARANTEE TERMS
MCZ guarantees the product, with the exception of
parts subject to normal wear specified below, for
two years from the date of purchase, provided that
proof of purchase is supplied in a document specifying
the name of the retailer and the date the sale was
made and that the completed guarantee certificate
was sent within 8 days of said purchase. The product
must also be installed and tested by a specialised
fitter and in accordance with the detailed instructions
provided in the instruction manual that accompanies
the product.
The guarantee covers the replacement or free repair
of parts recognised as being faulty at source
due to manufacturing defects.
1.3.1. Guarantee limits
The guarantee does not cover parts subject to normal
wear, such as: seals, glazing, and all the
removable parts of the combustion chamber.
The parts replaced will be guaranteed for the
remaining guarantee cover period starting from the
original date of purchase of the product.
The glazing in particular is
guaranteed until an authorised MCZ
fitter certifies that it is perfectly
intact at the time of completion of
installation.
1.3.2. Exclusions
The guarantee does not cover all parts found to
be faulty due to negligence or inappropriate
use, incorrect maintenance, or installation not
performed in compliance with MCZ's
instructions (see relevant chapters in this use
manual).
MCZ will not be held liable for any damage which may
- either directly or indirectly - be caused to property,
or personal injury or harm to animals ensuing from
failure to observe all the instructions provided herein
and specifically concerning the warnings regarding
installation, use and maintenance of the device.
Please contact your retailer and/or local importer in
the event of product failure.
Damage caused by transport and/or handling are not
covered by the guarantee.
Reference must be made solely to the manual
provided for product installation and use.
The guarantee is not valid for damage caused by
tampering with the device, atmospheric agents,
natural disasters, electrical discharges, fires, faults in
the electrical and plumbing system and caused by
failure to perform maintenance or by incorrect
maintenance in compliance with the Manufacturer's
instructions.
Service call
Service calls must be made to the
retailer, who will forward the call to
the MCZ technical support
department.
MCZ cannot be held liable if the
product and any of its accessories are
used incorrectly or modified without
authorisation.
Only original MCZ spare parts must
be used for replacements.
1.4. IMPORTANT INFORMATION FOR
CORRECT DISPOSAL OF THE PRODUCT
IN ACCORDANCE WITH EC DIRECTIVE
2002/96/EC
.
At the end of its working life, the product must not be
disposed of as urban waste.
It must be taken to a special local authority
differentiated waste collection centre or to a dealer
providing this service.
Disposing of a appliance separately avoids possible
negative consequences for the environment and
health deriving from inappropriate disposal and
enables the constituent materials to be recovered to
obtain significant savings in energy and resources.
As a reminder of the need to dispose of appliances
separately, the product is marked with a crossed-out
wheeled dustbin.

Chapter 2
USE AND MAINTENANCE MANUAL
page 6
Installation recommendations in compliance with UNI 10683 Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
2. INSTALLATION RECOMMENDATIONS IN COMPLIANCE WITH UNI
10683
2.1. THE OPERATING ENVIRONMENT
For the correct functioning and an even distribution of heat, the stove
should be positioned where the air required for combustion is
accessible (at least 60 m3/h must be available) in accordance with the
installation instructions and the applicable standards in force in the
country of installation.
The volume of the room should be no less than 60 m3.
The air should enter through permanent apertures made in the walls
(near the stove) onto the outside with a minimum cross-section of 150
cm2 (in the case of non-Oyster installation).
These apertures (air inlets) must be made in such a way as not to
obstruct them in any way.
Air may also be taken from adjoining rooms to the one to be ventilated,
provided they are equipped with an external air inlet and that they are
not used as a bedroom or bathroom or where there is no fire hazard,
such as: garages, timber storerooms, warehouses of flammable
materials, observing under all circumstances the provisions of all the
applicable standards in force.
If the floor is wood, lay the floor guard down, in
compliance with the applicable standards in
force in the country of installation.
If the walls are not flammable, position the
stove with a minimum rear clearance of at least
10 cm.
Extreme proximity between the stove and the
wall could cause overheating and damage the
plaster (yellowing, cracking, etc..)
Stove installation and assembly must be
performed by qualified staff.
The stove must be connected to a flue pipe or a
vertical duct that can discharge the smoke at the
highest point of the home.
The stove must be connected to a flue pipe or
internal or external vertical duct, in accordance
with the applicable standards in force.
The smoke does however result from combustion
of wood essences, and may therefore soil walls if
released in contact with or close to the latter.
Before positioning the stove, drill the hole for
the external air inlet (not in the case of
installation with Oyster technology).

Chapter 2
USE AND MAINTENANCE MANUAL
page 7
Installation recommendations in compliance with UNI 10683 Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
2.2. THE OPERATING ENVIRONMENT
In the case of concurrent installation with other heating appliances,
provide the appropriate air inlets for each one (according to the
instructions for each appliance).
Installing the stove in a bedroom or bathroom is not
permitted, nor in any room where another heating
appliance is installed without an independent air
inflow.
It is forbidden to position the stove in rooms with an
explosive atmosphere.
The floor of the room where the stove is installed
must be suitably sized to withstand its weight.
2.2.1. Safe distances
If particularly delicate objects are present, such as furniture, curtains or
sofas, increase the stove clearances substantially.
If the stove is positioned on a flammable floor, we
recommend you ensure it is suitably insulated.
Heat-sensitive or flammable objects and parts
cannot be stored near the stove; keep such objects
or parts at a minimum front clearance of 100 cm
from the outermost point of the appliance.
VELD Non-flammable
walls *
Flammable walls
*
A=15cm
B=20cm
A=20cm
B=30cm
20cmmin.
30 cm.
* Leave an appropriate distance from the walls in any case in order to allow easier appliance maintenance.
A
B

Chapter 2
USE AND MAINTENANCE MANUAL
page 8
Installation recommendations in compliance with UNI 10683 Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
2.3. CONNECTING THE COMBUSTION AIR INLET
PIPE
The combustion air outlet does not necessarily have to be connected to
the outside; only if you wish to use Oyster technology do you need to
connect the combustion air inlet to the outside of the home.
Always use pipes and unions with appropriate seals
that guarantee air- and watertightness.
Products built with Oyster technology, due to their fully watertight
structure, do not draw on the oxygen inside the room. Instead, they
draw air from the outside environment and can therefore be fitted in all
well-insulated homes and in passive houses.
In order to satisfy these requirements, the 80 mm diameter connection
pipe for the combustion air inlet must be connected to the outside of
the building.
The air inlet should also:
be designed with a grille, insect-proof metal mesh or suitable
protection, provided it does not reduce the minimum cross-
section.
be positioned in such a way as to not be obstructed
the maximum length permitted for ducting is 6 m, with two 90°
elbows
The stove must be connected to the external air inlet
using pipes and unions which guarantee
watertightness to comply with the requirements of
the sealed stove (OYSTER technology).
2.4. EXTERNAL AIR INLET
It is necessary for the room in which the stove is installed to provide at
least as much air as is required for regular combustion (not in the case
of installation with Oyster technology). This can be achieved through
permanent apertures made in the walls of the room to be ventilated
onto the outside or rooms aired in accordance with UNI 10683 REV.
To this end, drill a through hole in the external wall near the stove with
a minimum free cross-section of 150 cm². (15 cm diameter or 10x15
cm rectangular hole), protected by a grille on the inside and on the
outside.
The air inlet should also:
communicate directly with the installation setting
be designed with a grille, insect-proof metal mesh or suitable
protection, provided it does not reduce the minimum cross-
section.
be positioned in such a way as to not be obstructed
Rear view of the Veld stove:
1) Combustion air inlet

Chapter 2
USE AND MAINTENANCE MANUAL
page 9
Installation recommendations in compliance with UNI 10683 Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
in the case of ducting, up to 3.5 linear metres, increase the
cross-section by about 5% whereas for longer ducter, increase it
by 15%.
Remember that the ventilation grilles always feature an
indication of the useful cross-section in cm2on one side.
When choosing the grille and hole size, check that the useful
cross-section of the grille is larger or the same as the cross-
section required by MCZ for the appliance operation.
IMPORTANT!
The flow of air may also be taken from an adjoining
room to the one in which the stove is installed,
provided the air can flow freely through permanent
apertures communicating with the outside; avoid air
inlets connected to thermal power plants, garages,
kitchens or bathrooms.

Chapter 2
USE AND MAINTENANCE MANUAL
page 10
Installation recommendations in compliance with UNI 10683 Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
2.5. FLUE PIPE CONNECTION
The flue pipe connection is extremely important, and it should be
performed carefully and attentively. Stoves have a top or rear smoke
outlet.
The smoke outlet pipe must be fitted in such a way as to guarantee its
seal during the appliance's vacuum operation and avoid the formation
and conveying towards the stove of any condensation.
Any manual draught control devices inserted in the pipe should not
hermetically seal the internal section of the duct. These shutters should
be equipped with a suitable mechanism to avoid the complete rotation
of the valve in the closed position. The minimum safety opening surface
must be 3% of the through cross-section, and not less than 10 cm². If
the smoke duct has a horizontal section, the same should rise with a
minimum slope gradient of 3-5% (3-5 cm for every metre).
The tilted horizontal part should not be longer than 2 linear
metres.
The use of flexible pipes and fibre cement pipes is
forbidden. The smoke pipe must not cross rooms in
which it is forbidden to install combustion
appliances. The use of counter-sloping pipes is
forbidden.
2.6. FLUE PIPE
The flue pipe is vital for the disposal of smoke and should therefore
comply with the following requisites:
Be waterproof and thermally insulated.
Be made of suitable heat-proof materials, resistant to the
effects of the combustion products and any possible
condensation.
Have a prevalently vertical arrangement with deviations from
the axis of no more than 45° and without kinks.
must be suitable for the specific operating conditions of the
product and marked EC (EN1856-1, EN1443).
must be suitably sized to accommodate the draught/smoke
disposal requirements necessary for the correct functioning of
the product (EN13384-1).
Have an internal section which is preferably circular.
If it is existing and has operated beforehand, it should be
cleaned.
The flue pipe is vital for the correct functioning and
safety of your stove. Typical diagram of a correctly laid flue pipe
with, at the foot of the external rising
section, the positioning of a chamber with a
sealed hatch to collect and remove the solid
materials produced during combustion.
Flue pipe connection example
Chimney
Flue pipe
External air
inlet
Smoke union
MAX 2 mt.
3 - 5 %

Chapter 2
USE AND MAINTENANCE MANUAL
page 11
Installation recommendations in compliance with UNI 10683 Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
2.6.1. Flue pipe examples
AISI 316 steel flue pipe with
double chamber insulated with
fibreglass or similar, resistant to
400 °C.
EXCELLENT
Refractory flue pipe with double
insulated chamber and external
concrete jacket lightened with
honeycomb material such as
clay.
GOOD
Traditional square-section clay
flue pipe with empty insulating
inserts.
MEDIOCRE
Avoid flue pipes with
rectangular cross-sections
where the larger side is twice
the smaller one, such as 20x40
or 15x30.
POOR
For square- or rectangular-section flue pipes, the internal corners
should be rounded with a radius of no less than 20 mm. For the
rectangular cross-section, the ratio between the internal dimensions
should be ≤1.5.
The sections/lengths of the flue pipe shown in the technical data table
are guidelines for correct installation. Any alternative configurations
must be suitably sized in accordance with EN13384-1.
You are advised to fit a chamber to the smoke duct to collect solid
materials located beneath the mouth of the smoke duct. This chamber
should be easy to open and inspect from the airtight flap.
IMPORTANT!
If you have doubts about the performance of your
flue pipe or if the dimensions of the latter differ from
the recommended values, it is highly advisable to
have an authorised MCZ fitter perform a prior survey
and instrumental measurement of the performance
of the flue pipe (measurement with micro pressure
gauge)
MCZ s.p.a. will not be held liable for any stove
malfunctioning if the same is ascribable to the use of
a poorly sized flue pipe installed in a way that does
not comply with the requisites listed herein.

Chapter 2
USE AND MAINTENANCE MANUAL
page 12
Installation recommendations in compliance with UNI 10683 Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
2.7. CHIMNEY
Often, if it is underestimated, it prevents the correct functioning of the
"chimney system".
The draught of the flue pipe also depends on its chimney.
It is therefore vital that, if it has been hand-crafted, the development of
the four relief sections correspond to more than twice the internal
cross-section of the flue pipe.
Since it should always be higher than the ridge of the roof, the
chimney will be exposed to all weather, and so an industrial-
type chimney is recommended.
Industrial chimney
with prefabricated
stacked elements.
Allows excellent
smoke disposal.
Traditional hand-
crafted chimney.
The correct outlet
cross-section should
be at least twice the
internal cross-
section of the flue
pipe, ideally 2.5
times its size.
Steel flue pipe
chimney with
internal smoke-
deflector cone.
Allows excellent
smoke disposal.
The chimney must:
Have an inner section equal to that of the flue.
Have a working outlet section of at least double that of the
inner section of the flue pipe.
Be built in such a ways as to prevent rain, snow and any
foreign bodies from penetrating the flue pipe.
Be positioned so as to ensure adequate dispersion of smoke
and, in all cases, outside the reflux area in which back-
pressures are likely to form.
In the case of paired flue pipes, the solid
combustibility or upper storey chimney shall be at
least 50 cm higher than the others in order to avoid
the transfer of pressure from one paired pipe to the
other.
The chimney must not have any obstacles within a
range of 10 metres, including walls, pitches and trees.
If this is the case, then raise it at least 1 metre above
the obstacle and in the event of other chimneys
nearby, space them at least 2 metres apart and in all
cases the chimney must protrude from the ridge of the
roof by at least 1 metre.
UPPER STOREY OR SOLID
COMBUSTIBILITY
LOWER STOREY
1 mt
YE
S
NO
0.5 mt

Chapter 3
USE AND MAINTENANCE MANUAL
page 13
Dimensions and technical specifications Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
3. DIMENSIONS AND TECHNICAL SPECIFICATIONS
3.1. VELD STOVE
218
267.5
Ø80
1124
445
535
535
1097,5
267,5
192,5
452,5

Chapter 3
USE AND MAINTENANCE MANUAL
page 14
Dimensions and technical specifications Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
3.1.1. Technical specifications
Technical specifications Veld natural/air
Fuel type Wood - logs
Hourly consumption 2.05 Kg/h – 1.4 kg/h
Global heat output Max KW 7/Kcal 6020
Global heat output Min: KW 3.5/Kcal 3010
Efficiency 84,7 %
Heatable volume m3151/40 – 172/35 – 201/30
Recommended draught 12 Pa / 0,12 mbar
Smoke temperature 240 °C
Particulate 30 mg/Nm3 (13% O2)
17 mg/MJ
Smoke outlet Ø 15 cm
Combustion chamber dimensions 33 x 25 - h 43
Net weight Kg 175
External combustion air inlet cm² 200
CO emission in the smoke (13 %O2) 0,09 %
Smoke flow rate 6.9 g/s
Flue pipe
Flue pipe cross-section 18x18 cm Ø18
Minimum flue pipe height 4 m
Notes
The stove is an intermittent combustion appliance
* These data may vary according to the type of fuel
used

Chapter 4
USE AND MAINTENANCE MANUAL
page 15
Installation and assembly Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
4. INSTALLATION AND ASSEMBLY
IMPORTANT!
The stove must be installed and connected to the flue
pipe by a specialised technician or by competent
staff so that all local or national regulations are
complied with and in all cases in accordance with the
provisions of standard UNI 10683 REV.
When you unwrap the stove and related frame, make sure that
every part is in perfect working order or check for any damage
due to transport. If the stove is installed in a difficult to access place,
the weight can be lightened by removing the internal elements making
up the combustion chamber. We recommend you reposition each
element correctly.
4.1. PREPARATION AND UNPACKING
The Veld stove is delivered with three different packagings:
one contains the stove (figure 1)
one contains the ceramic parts (sides and fronts) figure 2 (the
box containing the ceramic parts will be placed on top of the
structure packaging)
Open the package, remove the packaging straps and the two brackets
(fig. 3) that secure the stove to the pallet.
Remove the two screws (A) from the bracket at the bottom right and
left of the stove.
Then remove the other three screws (B) securing the bracket to the
pallet and position the stove in the chosen location, making sure it
complies with the applicable provisions.
Only reposition the sides onto the stove after it has been
positioned in the right place.
A
A
B
B
B
BRACKE
Figure 1 - Veld stove packaging
Figure 2 - Veld stove ceramic
packaging
Figure 3 - Removing the packaging
screws (Veld stove)

Chapter 4
USE AND MAINTENANCE MANUAL
page 16
Installation and assembly Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
The stove must always be handled vertically and only with trolleys. Pay
special attention to the door and its glazing, to protect them from
mechanical knocks which would compromise their good working order.
In all cases, appliances must be handled with care. If possible, unwrap
the stove near the chosen place of installation.
The materials making up the packaging are neither toxic nor harmful,
and so require no particular disposal measures.
Storage, disposal or any recycling is under the responsibility of the end
user in compliance with the applicable laws in force.
4.2. FOOT ASSEMBLY AND ADJUSTMENT
Some models envisage the assembly of support feet, designed to level
the stove so that it is aligned and stable on the floor. The feet are
screwed into the base of the structure, and they can be installed as
illustrated in the figure and adjusted with a screwdriver, inserting it into
the tip of the feet.
4.3. CERAMIC CLADDING ASSEMBLY
The installation of the ceramic parts does not present any particular
difficulties:
Ceramic on ash tray:
1. Remove lever “A” as follows:
remove the black cap at the top of the lever, you will find a
screw inside it; loosen it and remove the lever “A”.
2. Remove the brackets “B”, insert the ceramic part “D” onto the
hook of air adjustment lever “A” and screw the brackets “B”
back on to secure the ceramic in place.
Ceramic on front panel “E”:
1. Loosen the two brackets “C” (left and right) and insert the
ceramic front panel “E” from the top down.
You can now fit the ceramic sides on:
1. Take the side “F” fitting the pins featured on the side into the
corresponding slots featured at the bottom of the stove
structure. At the top of the ceramic panel, secure the side to
the structure using two screws. Repeat the same steps with the
side Gand with sides H-I.
Ceramic top assembly:
1. Rest the cover “L” onto the purpose-provided rubber pads
featured on the stove casing.

Chapter 4
USE AND MAINTENANCE MANUAL
page 17
Installation and assembly Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
G
F
SPINE
H
I
D
L
E
C
C
B
A
B
PIN
S

Chapter 5
USE AND MAINTENANCE MANUAL
page 18
Operation Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
5. OPERATION
5.1. WARNINGS PRIOR TO START-UP
Make sure you have read and fully understood the contents of this
instruction manual.
Remove all components which could burn from the stove and door
(instructions and various adhesive labels).
Remove the stickers from the glass ceramic otherwise the high
temperature could melt them and cause irreparable damage to the
glass. If this is the case, MCZ will not guarantee the glass.
The stove can be positioned either in a corner or up against a wall.
Avoid touching the stove during the initial start-up, since the
paint completes its drying process during this time and
hardens.
It is good practice to guarantee the efficient ventilation in the
room during the initial start-up, since the stove will release
some smoke and paint smells.
If necessary, touch up the paint with the spray can of the
dedicated colour. (see "Stove accessories”)
Do not stand close to the stove and as mentioned, air the room. The
smoke and paint smell will disappear after about an hour of operation,
but remember that they are not in any case harmful.
The stove will undergo expansion and contraction
during the start-up and cooling phases, so it may
squeak slightly.
This is completely normal, since the structure is made
of laminated steel and should therefore not be
considered a defect.
It is extremely important to make sure you do not
immediately overheat the stove, but instead raise the
temperature gradually.
This will avoid any damage to the welding and to the
steel structure.
Do not try to achieve the maximum
heating efficiency immediately!
5.2. FUEL
FUEL: Wood
In order to get the best efficiency from your stove, it is of vital
importance that you use wood with appropriate characteristics.
Heating wood can be used, such as oak-beech-ash-robinia or non-
resinated pressed logs. The latter have a high calorific value and

Chapter 5
USE AND MAINTENANCE MANUAL
page 19
Operation Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
must be used with caution to avoid harmful overheating of the
stove
Fuels such as poplar-pine-linden-chestnut have a low calorific value as
the wood is soft, i.e. tender, and does not last long. The humidity
content is fundamental for all types of wood.
A high percentage humidity causes condensation to form in
the smoke duct, causing an alteration to the draught and
generating smoke and considerable soot deposits in the
combustion chamber, on the door glazing and on the flue
pipe, with the subsequent possible fire hazard in the same; in
addition, it leads to a much lower global efficiency.
The use of humid or treated wood releases a larger than
normal quantity of smoke, which could soil the glass more
quickly. The poor performance of the flue pipe can also
compromise the cleanliness of the glass, considering that the
smoke remains in the combustion chamber longer than usual.
Do not use treated fuels (painted or lacquered wood)
or non-compliant fuels (plastic or derivatives) which
could release toxic substances or pollutants.
Do not burn waste.
The gases produced by combustion resulting from the
use of unsuitable fuel could damage the stove, the
flue pipe, pollute and compromise your health.
5.3. USING THE STOVE
5.3.1. FUEL LOADING
To load the fuel, simply open the door by lifting the handle and pulling
the door towards you.
During use, the metal parts and the glazing reach very high
temperatures, so it is necessary to use a heat protective glove (not
included).
During combustion, the door to the combustion chamber must
remain closed.
It is forbidden to load larger quantities of fuel than
those specified in the technical datasheets of each
individual product.
Excessive quantities of fuel introduced into the
combustion chamber could damage and warp the
combustion chamber and the structure of the stove.
MCZ will not be held liable for any damage caused by
fuel overloads or by the use of fuels which do not
comply with the specifications.
5.3.2. COMBUSTION CONTROL
The combustion and therefore the combustion air inlet is controlled via
a single control lever.
The inlet air is either:
PRIMARY AIR:
Primary air is introduced at the base of the flame to encourage mostly
the stove start-up operation
Wood drying
time (e.g. beech) % humidity
Calorific
value
Kcal/h
Freshly cut 50 /
3 Months 40 2410
6 Months 35 2700
9 Months 30 2900
12 Months 25 3150
15 Months 20 3400
18 Months 15 3710
21 Months 10 3980

Chapter 5
USE AND MAINTENANCE MANUAL
page 20
Operation Technical dept. - All rights reserved by MCZ GROUP S.p.A. - Reproduction
prohibited
SECONDARY AIR:
The introduction of secondary air is predetermined, and is used for the
partial cleaning of the glass and allows the completion of the
combustion process. Consequently, if it is well calibrated, the efficiency
and heating performance of the stove are higher.
5.3.2.1. VELD stove air control
Move the control lever towards the right if you want more combustion
air to enter the combustion chamber. Vice versa move the lever
towards the left if your want less air inlet.
The primary and secondary air inlet is predetermined; move the lever
to dose the quantity of primary and secondary inlet air.
1
2
3
PRIMARY AIR LEVER (TURNED TOWARDS THE RIGHT)
The lever turned towards the right (pos.1) is designed to bring a large
quantity of primary air beneath the combustion chamber fire plane, to
allow rapid and effective ignition of the fire (Fig.4).
SECONDARY AIR LEVER (TURNED DOWN)
Secondary air, as mentioned above, allows the completion of
combustion and increases the efficiency (lever in pos.2 - fig.5).
The position of the lever in fig.5 determines the nominal output,
minimizing primary air and the secondary air inlet.
LEVER TURNED TOWARDS THE LEFT
From this point, turn the lever clockwise to decrease the quantity of air
in the combustion chamber until position 3 is reached, where only a
minimum quantity of primary air is present (fig.6).
This position is used to prolong combustion (for instance, at night, or
when you are not at home) so that the stove is set to minimum for
auto-combustion, to save on fuel and keep the flame burning.
Fig.4 Primary air inlet
Start-u
p
Fig.5 Secondary air inlet Fig.6 Minimum primary air inlet
