MD SPORTS 1538410 User manual

MODEL: 1538410
VM Innovations
ASSEMBLY INSTRUCTIONS
TM
Register Now on themdsports.com and Earn a One-Year Warranty for Free!
Please contact us before returning the product to the store.

FREE FULL YEAR
EXTENDED WARRANTY!
Give Us Your Opinion and Receive A
Write a review for a recently purchased
item on TheMDSports.com and receive an
extended full year limited warranty,
valued at $150.00.
See TheMDSports.com
for additional details.
TM

This product is covered by a limited warranty that is effective for 90 days from the date of purchase. If,
during the limited warranty period, a part is found to be defective or broken, we will offer replacement parts
at no cost to you, the customer. The only exceptions to the warranty include main frames, table tops,
playing surfaces, batteries or tools.
The above warranty will not apply in cases of damages due to improper usage, alteration, misuse, abuse,
accidental damage or neglect.
This Limited Warranty gives you specific legal rights and you may also have other rights which vary from
one State (province) to another.
A PURCHASE RECEIPT (or other proof of purchase) will be required before any warranty service is
initiated. For all requests for warranty service, please feel free to contact our Consumer Service Department
at :
Please be aware of your product’s Limited Warranty for the return/refund policy from the store, We, at Medal
Sports, can not handle the product which is out of product’s limited warranty since we only provide available
parts. Thank you!
PLEASE CONTACT US BEFORE RETURNING
THE PRODUCT TO THE STORE.
WEBSITE: www.themdsports.com
NOTICE!
STAPLE YOUR RECEIPT HERE
1 - Please leave your name, address, phone number, model number, parts needed on the answering
machine if there is no attendance. Failure to do so will result in a delay in shipping parts to you.
2 - Please review the replacement parts list and make sure that you have all of your parts before
beginning assembly. For questions that may arise or for missing/damaged parts, please contact us.
3 - Since you build all tables upside down, please inspect tabletops or playing surfaces right away before
putting together, all damaged table tops/playing surfaces need to be returned to the store. Please
contact with retailer for their return policy.
LIMITED 90 DAYS WARRANTY
www.themdsports.com
1538410 1
(Continued on the next page.)

X 4
Strong Adults Needed No Children in
Assembly Area
Keep away from pets Do not use or keep product
outdoors. For indoor use only.
No wet/humid conditions.
Power Tools
- Set Low Torque
High Torque
over tightened
TOOLS REQUIRED:
Phillips Screwdriver - Not Included
Standard (Flat Head Screwdriver) - Not Included
Allen Key - Included
CAUTION!
Electric Screwdrivers may be helpful during assembly;
however, please set a low torque and use extreme
caution.
WARNING:
CHOKING HAZARD -- This item contains small parts or / and small balls.
Not suitable for children under 3 years.
!
WARNING: Adult Assembly Required.
!
ASSEMBLY TIPS:
1 - Please read the instructions carefully, and follow all assembly, operation and safety instructions properly
in order to avoid damage or injury. For the assembly, at least fwo adults are required.
2 - Some figures or drawings may not look exactly like your product. Please read and understand the text before
beginning each assembly step.
1 - This product is intended for INDOOR use only.
2 - Please do not sit, climb or lean on the product.
3 - Please do not drag the product when moving it in order to avoid damaging the legs.
4 - Please only use spray furniture polish to clean the exterior surfaces of the product.
5 - This is not a child's toy, adult supervision is required for children playing this game.
IMPORTANT NOTICE!
www.themdsports.com
1538410 2
(Continued on the next page.)

www.themdsports.com
1538410 3
(Continued on the next page.)
Allen Key 19mm Washer 3.5x18mm Screw
Leg Leveler Cue Chalk Triangle
8 x 35mm Leg Bolt
910 11 12
13 14 15 16
Table Tennis Top - A Table Tennis Top - BBilliard Ball Set Brush
Left Leg Right Leg End Leg Panel
2 3 4
Mainframe
1
x1 x2 x2 x2
6 7 85
x1 x12 x12
x4 x2 x2 x1
x1 x1 x2 x1
x12
Table Tennis Support
18 19 20
Table Tennis PaddleTable Tennis Post Table Tennis Ball
x2 x2 x2
21
Table Tennis Net
x1
EVA Pad
22
x12
17
x2
Apron Corner Rail Corner Side Pocket Cap
P1 P2
x4 x4 x2
P3
Corner Pocket Cap
P4
x4
Square Nut with Screws
P5 P6
x4
T - Nut
x12
1538410 PRE-INSTALLED PARTS
1538410 PARTS LIST
P7
Fabric Pocket
x6

www.themdsports.com
1538410 4
(Continued on the next page.)
1. Find a clean, level place to begin the assembly of your Billiard Table. The table will be assembled upside down
and then turned over on its legs once the assembly is completed. This game table is heavy, and turning it over
will require at least four strong adults.
2. Remove all of the parts from the box and verify that you have all of the listed parts as shown on the parts list
page. Carefully cut or tear the four corners of the box so that the bottom of the box can be used as your
work surface.
ASSEMBLY INSTRUCTIONS:
FIG.1
3. Attach the Right Legs (#3) and Left Legs (#2) to the Mainframe (#1) using three Bolts (#6) and three Washers
(#7) per Leg. See FIG. 1.
4. Screw the Leg Levelers (#9) into the bottom of each Leg. See FIG. 1A.
1
2
3
6
7
X 1
X 2
X 2
X 12
X 12
P1
P5
P6
X 4
X 4
X 12
P7
X 6
FIG. 1
9
X 4
FIG. 1A
2
3
3
9
P1
P5
P7
P6
6
7
1
2
FIG. 2
4
8
X 2
X 12
4
8
FIG.2
5. Attach the End Leg Panels (#4) to the Legs using six Screws (#8) per End Leg Panel. See FIG. 2.

www.themdsports.com
1538410 5
(Continued on the next page.)
FIG. 3
FIG.3
6. Lift the table assembly from the floor with four strong adults, turn it over and set the table on its legs in the
location where you will play.
Go back and make sure that all connections are tight.
P3 P2
P4
CAUTION: Four strong adults are recommended to turn
the table over as shown.
1. Lift the table off the ground.
2. Turn the table over.
3. Place it on all four feet at the same time on the ground.
DO NOT LEAN THE
TABLE ON ITS LEGS
HOLD TABLE
HOLD TABLE
DO NOT HOLD THE LEGS
NOTE: DO NOT lift the table by the pockets.
If you move the table, do not lift it by placing
your hands beneath the pockets and do not
lean or put pressure on them. Do not lean
or sit on the end or side rails as this may
damage the table.
P2
P3
P4
X 4
X 2
X 4

www.themdsports.com
1538410 6
(The last page)
FIG. 4
15
16
22
FIG.4
7. Tear off the backside papers of the EVA Pads (#22) and stick them onto the bottom of the Table Tennis
Tops (#15 and #16). See FIG. 4.
FIG.5
8. Place the Table Tennis Supports (#17) onto the playfield and place the Table Tennis Tops (#15 & #16) onto the billiards
surface. Then insert the Net Posts (#18) and Net (#21) onto the Table Tennis Top. See FIG. 5.
X 2
X 1
X 12 16
15
22
15
FIG. 5
17
18
21
X 2
X 2
X 1
YOU ARE NOW READY TO PLAY!
21
18
17
15
15
16
