Measurement Computing PCI-DAS1002 User manual

PCI-DAS1002
Multifunction Analog & Digital I/O
User's Guide
Document Revision 4, July, 2007
© Copyright 2007, Measurement Computing Corporation

Your new Measurement Computing product comes with a fantastic extra —
Management committed to your satisfaction!
Refer to www.mccdaq.com/execteam.html for the names, titles, and contact information of each key executive at Measurement
Computing.
Thank you for choosing a Measurement Computing product—and congratulations! You own the finest, and you can now enjoy
the protection of the most comprehensive warranties and unmatched phone tech support. It’s the embodiment of our mission:
To provide PC-based data acquisition hardware and software that will save time and save money.
Simple installations minimize the time between setting up your system and actually making measurements. We offer quick and
simple access to outstanding live FREE technical support to help integrate MCC products into a DAQ system.
Lifetime warranty: Every hardware product manufactured by Measurement Computing Corporation is warranted against
defects in materials or workmanship for the life of the product. Products found defective are repaired or replaced promptly.
Lifetime Harsh Environment Warranty®: We will replace any product manufactured by Measurement Computing
Corporation that is damaged (even due to misuse) for only 50% of the current list price. I/O boards face some tough operating
conditions, some more severe than the boards are designed to withstand. When a board becomes damaged, just return the unit
with an order for its replacement at only 50% of the current list price. We don’t need to profit from your misfortune. By the way,
we honor this warranty for any manufacturer’s board that we have a replacement for.
30 Day Money Back Guarantee: You may return any Measurement Computing Corporation product within 30 days of
purchase for a full refund of the price paid for the product being returned. If you are not satisfied, or chose the wrong product by
mistake, you do not have to keep it. Please call for an RMA number first. No credits or returns accepted without a copy of the
original invoice. Some software products are subject to a repackaging fee.
These warranties are in lieu of all other warranties, expressed or implied, including any implied warranty of merchantability or
fitness for a particular application. The remedies provided herein are the buyer’s sole and exclusive remedies. Neither
Measurement Computing Corporation, nor its employees shall be liable for any direct or indirect, special, incidental or
consequential damage arising from the use of its products, even if Measurement Computing Corporation has been notified in
advance of the possibility of such damages.
3
HM PCI-DAS1002.doc

Trademark and Copyright Information
TracerDAQ, Universal Library, Harsh Environment Warranty, Measurement Computing Corporation, and the Measurement
Computing logo are either trademarks or registered trademarks of Measurement Computing Corporation.
Windows, Microsoft, and Visual Studio are either trademarks or registered trademarks of Microsoft Corporation
LabVIEW is a trademark of National Instruments.
CompactFlash is a registered trademark of SanDisk Corporation.
XBee and XBee-PRO are trademarks of MaxStream, Inc.
All other trademarks are the property of their respective owners.
Information furnished by Measurement Computing Corporation is believed to be accurate and reliable. However, no
responsibility is assumed by Measurement Computing Corporation neither for its use; nor for any infringements of patents or
other rights of third parties, which may result from its use. No license is granted by implication or otherwise under any patent or
copyrights of Measurement Computing Corporation.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form by any
means, electronic, mechanical, by photocopying, recording, or otherwise without the prior written permission of Measurement
Computing Corporation.
Notice
Measurement Computing Corporation does not authorize any Measurement Computing Corporation product for use
in life support systems and/or devices without prior written consent from Measurement Computing Corporation.
Life support devices/systems are devices or systems which, a) are intended for surgical implantation into the body,
or b) support or sustain life and whose failure to perform can be reasonably expected to result in injury.
Measurement Computing Corporation products are not designed with the components required, and are not subject
to the testing required to ensure a level of reliability suitable for the treatment and diagnosis of people.
4

Table of Contents
Preface
About this User's Guide .......................................................................................................................7
What you will learn from this user's guide .........................................................................................................7
Conventions in this user's guide .........................................................................................................................7
Where to find more information .........................................................................................................................7
Chapter 1
Introducing the PCI-DAS1002 ..............................................................................................................8
Overview: PCI-DAS1002 features .....................................................................................................................8
Software features ................................................................................................................................................8
PCI-DAS1002 block diagram.............................................................................................................................9
Chapter 2
Installing the PCI-DAS1002 ................................................................................................................10
What is included with your PCI-DAS1002 ......................................................................................................10
Hardware .........................................................................................................................................................................10
Additional documentation................................................................................................................................................10
Optional components .......................................................................................................................................................10
Unpacking the PCI-DAS1002 ..........................................................................................................................11
Installing the software ......................................................................................................................................11
Installing the hardware .....................................................................................................................................11
Configuring the hardware.................................................................................................................................12
Differential input mode....................................................................................................................................................12
Single-ended input mode .................................................................................................................................................12
Connecting the board for I/O operations ..........................................................................................................12
Connectors, cables – main I/O connector.........................................................................................................................12
Pinout – main I/O connector ............................................................................................................................................13
Cables ..............................................................................................................................................................................15
Field wiring and signal termination .................................................................................................................................15
Chapter 3
Programming and Developing Applications ....................................................................................16
Programming languages ...................................................................................................................................16
Packaged applications programs.......................................................................................................................16
Register-level programming .............................................................................................................................16
Chapter 4
Calibrating the Board..........................................................................................................................17
Introduction ......................................................................................................................................................17
Calibration theory.............................................................................................................................................17
Chapter 5
Specifications......................................................................................................................................18
Analog input .....................................................................................................................................................18
Accuracy..........................................................................................................................................................................19
Crosstalk ..........................................................................................................................................................................19
Noise performance...........................................................................................................................................................19
Analog output ...................................................................................................................................................20
Absolute accuracy............................................................................................................................................................20
Calibrated accuracy components......................................................................................................................................20
Counters............................................................................................................................................................21
Digital input/output...........................................................................................................................................22
Interrupts...........................................................................................................................................................22
5

PCI-DAS1002 User's Manual
Miscellaneous ...................................................................................................................................................22
Power consumption ..........................................................................................................................................22
Environmental ..................................................................................................................................................22
Mechanical .......................................................................................................................................................22
Connector and pin out.......................................................................................................................................23
8-channel differential mode pin out .................................................................................................................................23
16-channel single-ended mode pin out.............................................................................................................................24
Declaration of Conformity ..................................................................................................................25
6

Preface
About this User's Guide
What you will learn from this user's guide
This user's guide explains how to install, configure, and use the PCI-DAS1002 so that you get the most out of
its analog, digital, and timing I/O features.
This user's guide also refers you to related documents available on our web site, and to technical support
resources.
Conventions in this user's guide
For more information on …
Text presented in a box signifies additional information and helpful hints related to the subject matter you are
reading.
Caution! Shaded caution statements present information to help you avoid injuring yourself and others,
damaging your hardware, or losing your data.
<#:#> Angle brackets that enclose numbers separated by a colon signify a range of numbers, such as those assigned
to registers, bit settings, etc.
bold text Bold text is used for the names of objects on the screen, such as buttons, text boxes, and check boxes. For
example:
1. Insert the disk or CD and click the OK button.
italic text Italic text is used for the names of manuals and help topic titles, and to emphasize a word or phrase. For
example:
The InstaCal® installation procedure is explained in the Quick Start Guide.
Never touch the exposed pins or circuit connections on the board.
Where to find more information
The following electronic documents provide relevant information to the operation of your PCI-DAS1002.
MCC's Specifications: PCI-DAS1002 (the PDF version of the Electrical Specification Chapter in this guide)
is available on our web site at www.mccdaq.com/pdfs/PCI-DAS1002.pdf.
MCC's Quick Start Guide is available on our web site at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.
MCC's Guide to Signal Connections is available on our web site at
www.mccdaq.com/signals/signals.pdf.
MCC's Universal Library User's Guide is available on our web site at
www.mccdaq.com/PDFmanuals/sm-ul-user-guide.pdf.
MCC's Universal Library Function Reference is available on our web site at
www.mccdaq.com/PDFmanuals/sm-ul-functions.pdf.
MCC's Universal Library for LabVIEW™User’s Guide is available on our web site at
www.mccdaq.com/PDFmanuals/SM-UL-LabVIEW.pdf.
PCI-DAS1002 User's Manual (this document) is also available on our web site at
www.mccdaq.com/PDFmanuals/PCI-DAS1002.pdf.
7

Chapter 1
Introducing the PCI-DAS1002
Overview: PCI-DAS1002 features
This manual explains how to install and use the PCI-DAS1002. This board is a multifunction analog and digital
I/O board designed for the PCI bus.
The PCI-DAS1002 provides either 16 single-ended or eight differential analog inputs. Input ranges are
software-selectable as either bipolar or unipolar.
Analog input ranges for the PCI-DAS1002 are software programmable for the following ranges:
Bipolar: ±10 V, ±5 V, ±2.5 V, and ±1.25 V
Unipolar: 0 to 10 V, 0 to 5 V, 0 to 2.5 V and 0 to 1.25 V
The PCI-DAS1002 provides a 200 kHz sample rate.
The PCI-DAS1002 also provides two channels of 12-bit analog output. Analog output ranges are ±10 V and ±5
V (bipolar) and 0-10 V, 0-5 V (unipolar).
The PCI-DAS1002 offers 24-bits of parallel, digital I/O (two 8-bit ports and two 4-bit ports). You can configure
each port independently as input or output.
This board has an 82C54 counter chip which has three user-accessible 16-bit counters. Clock, gate, and output
signals from two of three counters are available on a 100-pin connector. The third counter is used internally.
The PCI-DAS1002 is fully plug-and-play. All addresses and interrupt channels are set with software.
Software features
For information on the features of InstaCal and the other software included with your PCI-DAS1002, refer to
the Quick Start Guide that shipped with your device. The Quick Start Guide is also available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.
Check www.mccdaq.com/download.htm for the latest software version.
8

PCI-DAS1002 User's Manual Introducing the PCI-DAS1002
PCI-DAS1002 block diagram
PCI-DAS1002 functions are illustrated in the block diagram shown here.
Figure 1. PCI-DAS1002 functional block diagram
9

Chapter 2
Installing the PCI-DAS1002
What is included with your PCI-DAS1002
As you unpack your board, make sure each of the items shown below is included:
Hardware
PCI-DAS1002
Additional documentation
In addition to this hardware user's guide, you should also receive the Quick Start Guide (available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf). This booklet supplies a brief description of
the software you received with your PCI-DAS1002 and information regarding installation of that software.
Please read this booklet completely before installing any software or hardware.
Optional components
If you ordered any of the following products with your board, they should be included with your shipment.
C100FF-x cable
10

PCI-DAS1002 User's Manual Installing the PCI-DAS1002
Signal termination and conditioning accessories
MCC provides signal termination and conditioning products for use with the PCI-DAS1002. Refer to the
"Field wiring and signal termination" section for a complete list of compatible accessory products.
Unpacking the PCI-DAS1002
As with any electronic device, you should take care while handling to avoid damage from static
electricity. Before removing the PCI-DAS1002 from its packaging, ground yourself using a wrist strap or by
simply touching the computer chassis or other grounded object to eliminate any stored static charge.
If any components are missing or damaged, notify Measurement Computing Corporation immediately by
phone, fax, or e-mail:
Phone: [phone] and follow the instructions for reaching Tech Support.
Fax: [phone] to the attention of Tech Support
Email: [email protected]
Installing the software
Refer to the Quick Start Guide for instructions on installing the software on the Measurement Computing Data
Acquisition Software CD. This booklet is available in PDF at
Quick-Start.pdf.
www.mccdaq.com/PDFmanuals/DAQ-Software-
Installing the hardware
The PCI-DAS1002 board is completely plug-and-play. There are no switches or jumpers to set on the board.
Configuration is controlled by your system's BIOS. To install your board, follow the steps below.
Install the MCC DAQ software before you install your board
The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to install the
MCC DAQ software before you install your board. Refer to the Quick Start Guide for instructions on installing
the software.
1.
2.
3. To test your installation and configure your board, run the InstaCal utility installed in the previous section.
Refer to the Quick Start Guide that came with your board for information on how to initially set up and
load InstaCal.
If you are using an operating system with support for plug-and-play (such as Windows 2000 or
Windows XP), a dialog box opens as the system loads, indicating that new hardware has been detected. The
information file for this board should have already been loaded onto your PC when you installed the
Measurement Computing Data Acquisition Software CD supplied with your board, and should be detected
automatically by Windows. If you have not installed this software, cancel the dialog and install it now.
Close your computer and turn it on.
Turn your computer off, open it up, and insert your board into an available PCI slot.
Allow your computer to warm up for at least 15 minutes before acquiring data with this board. The high speed
components used on the board generates heat, and it takes this amount of time for a board to reach steady state
if it has been powered off for a significant amount of time.
11

PCI-DAS1002 User's Manual Installing the PCI-DAS1002
Configuring the hardware
All hardware configuration options on the PCI-DAS1002 are software controlled. You can select some of the
configuration options using InstaCal, such as the analog input configuration (16 single-ended or eight
differential channels), and the source for the two independent counters. Once selected, any program that uses
the Universal Library will initialize the hardware according to these selections.
For general information regarding analog signal connection and configuration, refer to the Guide to Signal
Connections (available on our web site at www.mccdaq.com/signals/signals.pdf).
Differential input mode
When all channels are configured for differential input mode, eight analog input channels are available. In this
mode, the input signal is measured with respect to the low input. The input signal is delivered through three
wires:
The wire carrying the signal to be measured connects to CH# IN HI.
The wire carrying the reference signal connects to CH# IN LO.
The third wire, typically a system ground, connects to LLGND.
Single-ended input mode
When all channels are configured for single-ended input mode, 16 analog input channels are available. In this
mode, the input signal is referenced to the board's signal ground (LLGND). The input signal is delivered
through two wires:
The wire carrying the signal to be measured connects to CH# IN HI.
The second wire connects to LLGND.
Connecting the board for I/O operations
Connectors, cables – main I/O connector
The table below lists the board connectors, applicable cables, and compatible accessory boards for the PCI-
DAS1002.
Board Connectors, cables, accessory equipment
Connector type 100 pin high density Robinson Nugent connector
Compatible cables C100FF-x, unshielded ribbon cable. x = length in feet (Figure 2 on on page 15)
Compatible accessory products
(with the C100FF-x cable)
ISO-RACK16/P
ISO-DA02/P
CIO-ERB08 (DADP-5037 adaptor required *)
CIO-ERB24 (DADP-5037 adaptor required *)
SSR-RACK08 (DADP-5037 adaptor required *)
SSR-RACK24 (DADP-5037 adaptor required *)
BNC-16SE
BNC-16DI
CIO-MINI50 (2 required)
CIO-TERM100 (1 required)
SCB-50 (1 required)
* Details on the DADP-5037 adaptor board are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=103&pf_id=1381.
12

PCI-DAS1002 User's Manual Installing the PCI-DAS1002
Pinout – main I/O connector
8-channel differential mode
Signal Name Pin Pin Signal Name
GND 100
•
•
50 GND
N/C 99
•
•
49 N/C
N/C 98
•
•
48 PC +5V
N/C 97
•
•
47 N/C
N/C 96
•
•
46 N/C
A/D Int. Pacer Output 95
•
•
45 A/D External Trigger
N/C 94
•
•
44 N/C
N/C 93
•
•
43 N/C
PC -12V 92
•
•
42 A/D External Pace
r
PC GND 91
•
•
41 CTR4 OUT
PC +12V 90
•
•
40 CTR4 GATE
PC GND 89
•
•
39 CTR4 CLK
N/C 88
•
•
38 D/A OUT 1
CTR5 OUT 87
•
•
37 D/A GND 1
CTR5 GATE 86
•
•
36 D/A OUT 0
CTR5 CLK 85
•
•
35 D/A GND 0
N/C 84
•
•
34 N/C
N/C 83
•
•
33 N/C
CTR6 OUT 82
•
•
32 N/C
CTR6 GATE 81
•
•
31 N/C
CTR6 CLK 80
•
•
30 N/C
N/C 79
•
•
29 N/C
N/C 78
•
•
28 N/C
N/C 77
•
•
27 N/C
N/C 76
•
•
26 N/C
N/C 75
•
•
25 N/C
FIRSTPORTC Bit 7 74
•
•
24 N/C
FIRSTPORTC Bit 6 73
•
•
23 N/C
FIRSTPORTC Bit 5 72
•
•
22 N/C
FIRSTPORTC Bit 4 71
•
•
21 N/C
FIRSTPORTC Bit 3 70
•
•
20 N/C
FIRSTPORTC Bit 2 69
•
•
19 N/C
FIRSTPORTC Bit 1 68
•
•
18 LLGND
FIRSTPORTC Bit 0 67
•
•
17 CH7 IN LO
FIRSTPORTB Bit 7 66
•
•
16 CH7 IN HI
FIRSTPORTB Bit 6 65
•
•
15 CH6 IN LO
FIRSTPORTB Bit 5 64
•
•
14 CH6 IN HI
FIRSTPORTB Bit 4 63
•
•
13 CH5 IN LO
FIRSTPORTB Bit 3 62
•
•
12 CH5 IN HI
FIRSTPORTB Bit 2 61
•
•
11 CH4 IN LO
FIRSTPORTB Bit 1 60
•
•
10 CH4 IN HI
FIRSTPORTB Bit 0 59
•
•
9 CH3 IN LO
FIRSTPORTA Bit 7 58
•
•
8 CH3 IN HI
FIRSTPORTA Bit 6 57
•
•
7 CH2 IN LO
FIRSTPORTA Bit 5 56
•
•
6 CH2 IN HI
FIRSTPORTA Bit 4 55
•
•
5 CH1 IN LO
FIRSTPORTA Bit 3 54
•
•
4 CH1 IN HI
FIRSTPORTA Bit 2 53
•
•
3 CH0 IN LO
FIRSTPORTA Bit 1 52
•
•
2 CH0 IN HI
FIRSTPORTA Bit 0 51
•
•
1 LLGND
PCI slot ↓
13

PCI-DAS1002 User's Manual Installing the PCI-DAS1002
16-channel single-ended mode
Signal Name Pin Pin Signal Name
GND 100
•
•
50 GND
N/C 99
•
•
49 N/C
N/C 98
•
•
48 PC +5V
N/C 97
•
•
47 N/C
N/C 96
•
•
46 N/C
A/D Int. Pacer Output 95
•
•
45 A/D External Trigger In
N/C 94
•
•
44 N/C
N/C 93
•
•
43 N/C
PC -12V 92
•
•
42 A/D External Pace
r
PC GND 91
•
•
41 CTR4 OUT
PC +12V 90
•
•
40 CTR4 GATE
PC GND 89
•
•
39 CTR4 CLK
N/C 88
•
•
38 D/A OUT 1
CTR5 OUT 87
•
•
37 D/A GND 1
CTR5 GATE 86
•
•
36 D/A OUT 0
CTR5 CLK 85
•
•
35 D/A GND 0
N/C 84
•
•
34 N/C
N/C 83
•
•
33 N/C
CTR6 OUT 82
•
•
32 N/C
CTR6 GATE 81
•
•
31 N/C
CTR6 CLK 80
•
•
30 N/C
N/C 79
•
•
29 N/C
N/C 78
•
•
28 N/C
N/C 77
•
•
27 N/C
N/C 76
•
•
26 N/C
N/C 75
•
•
25 N/C
FIRSTPORTC Bit 7 74
•
•
24 N/C
FIRSTPORTC Bit 6 73
•
•
23 N/C
FIRSTPORTC Bit 5 72
•
•
22 N/C
FIRSTPORTC Bit 4 71
•
•
21 N/C
FIRSTPORTC Bit 3 70
•
•
20 N/C
FIRSTPORTC Bit 2 69
•
•
19 N/C
FIRSTPORTC Bit 1 68
•
•
18 LLGND
FIRSTPORTC Bit 0 67
•
•
17 CH15 IN
FIRSTPORTB Bit 7 66
•
•
16 CH7 IN
FIRSTPORTB Bit 6 65
•
•
15 CH14 IN
FIRSTPORTB Bit 5 64
•
•
14 CH6 IN
FIRSTPORTB Bit 4 63
•
•
13 CH13 IN
FIRSTPORTB Bit 3 62
•
•
12 CH5 IN
FIRSTPORTB Bit 2 61
•
•
11 CH12 IN
FIRSTPORTB Bit 1 60
•
•
10 CH4 IN
FIRSTPORTB Bit 0 59
•
•
9CH11 IN
FIRSTPORTA Bit 7 58
•
•
8CH3 IN
FIRSTPORTA Bit 6 57
•
•
7CH10 IN
FIRSTPORTA Bit 5 56
•
•
6CH2 IN
FIRSTPORTA Bit 4 55
•
•
5CH9 IN
FIRSTPORTA Bit 3 54
•
•
4CH1 IN
FIRSTPORTA Bit 2 53
•
•
3CH8 IN
FIRSTPORTA Bit 1 52
•
•
2CH0 IN
FIRSTPORTA Bit 0 51
•
•
1 LLGND
PCI slot ↓
14

PCI-DAS1002 User's Manual Installing the PCI-DAS1002
Cables
1
50
2
49
51
100
52
99
10050
511
Key
Key
The red stripe
identifies pin # 1
The red stripe
identifies pin # 51
Cable is labeled
“Pins 51-100”.
Cable is labeled
“Pins 1-50”.
Figure 2. C100FF-x cable
Field wiring and signal termination
The following MCC screw terminal and signal conditioning boards are compatible with the PCI-DAS1002:
SCB-50 – 50-conductor, shielded signal connection box. Details on this product are available on our web
site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=196&pf_id=1168.
CIO-MINI50 – 50-pin universal screw terminal accessory. Details on this product are available on our web
site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=258.
ISO-RACK16/P – 16-channel isolation module mounting rack. Details on this product are available on our
web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=127&pf_id=1111.
ISO-DA02/P – Two-channel 5B module rack. Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=128&pf_id=710.
BNC-16SE – 16-channel single-ended BNC connector box. Details on this product are available on our
web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=101&pf_id=713.
BNC-16DI – Eight-channel differential BNC connector box. Details on this product are available on our
web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=101&pf_id=714.
SSR-RACK24* – 24-position solid state relay rack. Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=122&pf_id=1193.
SSR-RACK08* – Eight-channel solid state relay rack. Details on this product are available on our web site
at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=122&pf_id=620.
CIO-ERB24* – 24-channel electromechanical relay accessory for digital I/O boards. Details on this
product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=123&pf_id=241.
CIO-ERB08* – Eight-channel electromechanical relay accessory for digital I/O boards. Details on this
product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=123&pf_id=241.
* The SSR-RACK24, SSR-RACK08, CIO-ERB24, and CIO-ERB08 boards require the DADP-5037 PCI-DAS-
to-37-pin SSR and ERB adapter. Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=103&pf_id=1381.
15

Chapter 3
Programming and Developing Applications
After following the installation instructions in Chapter 2, your board should now be installed and ready for use.
Although the board is part of the larger DAS family, in general there may be no correspondence among
registers for different boards. Software written at the register level for other DAS models will not function
correctly with your board.
Programming languages
Measurement Computing’s Universal Library®provides access to board functions from a variety of Windows
programming languages. If you are planning to write programs, or would like to run the example programs,
refer to the Universal Library User's Guide (available on our web site at www.mccdaq.com/PDFmanuals/sm-
ul-user-guide.pdf).
Packaged applications programs
Many packaged application programs now have drivers for your board. If the package you own does not have
drivers for the board, please fax or e-mail the package name and the revision number from the install disks. We
will research the package for you and advise how to obtain drivers.
Some application drivers are included with the Universal Library package, but not with the application package.
If you have purchased an application package directly from the software vendor, you may need to purchase our
Universal Library and drivers. Please contact us by phone, fax, or e-mail:
Phone: [phone] and follow the instructions for reaching Tech Support.
Fax: [phone] to the attention of Tech Support
Email: [email protected]
Register-level programming
You should use the Universal Library or one of the packaged application programs mentioned above to control
your board. Only experienced programmers should perform register-level programming.
If you need to program at the register level in your application, refer to the Register Map for the PCI-DAS1000
Series (available at www.mccdaq.com/registermaps/RegMapSTC1000.pdf).
16

Chapter 4
Calibrating the Board
Introduction
Calibrate the board using the InstaCal utility after the board has fully warmed up. The recommended warm-up
time is 15 minutes. For best results, calibrate the board immediately before making critical measurements. The
high resolution analog components on the board are sensitive to temperature. Pre-measurement calibration
ensures that your board is operating at optimum calibration values.
Calibration theory
The PCI-DAS1002 is shipped fully calibrated from the factory with calibration coefficients stored in nvRAM.
When using Universal Library at run time, these calibration factors are loaded into system memory and are
automatically retrieved each time a different DAC/ADC range is specified.
The analog input circuits are calibrated for both offset and gain ( ).Figure 3
Figure 3. Analog input circuit calibration
Offset calibration for the analog input is performed directly on the input amplifier (PGIA) with coarse and
fine trim DACs acting on the amplifier.
For input gain calibration, a precision calibration reference is used with coarse and fine trim DACs acting
on the ADC.
PGIA
Analog In A/D
Trim DAC
Coarse
Trim DAC
Fine
Pre-Gain
Offset
Variable
Gain
The analog output circuits are calibrated for both offset and gain ( ). This circuit is duplicated for both
DAC0 and DAC1.
Figure 4
Figure 4. Analog output circuit calibration
Offset adjustments are made in the output buffer section. The tuning range of this adjustment allows for
max DAC and output buffer offsets.
Gain calibration is performed via DAC reference adjustments.
Trim DAC
Ref
D/A
Gain
Adjust
Analog Out
Offset
Adjust
Trim DAC
Coarse
Trim DAC
Fine
17

Chapter 5
Specifications
Typical for 25 °C unless otherwise specified.
Specifications in italic text are guaranteed by design.
Analog input
Table 1. Analog input specifications
Parameter Specification
A/D converter type ADS7800 or equivalent
Resolution 12 bits
Number of channels 16 single-ended / 8 differential, software selectable
Input ranges ±10 V, ±5 V, ±2.5 V, ±1.25 V, 0 to 10 V, 0 to 5V, 0 to 2.5 V, 0 to 1.25 V software
programmable
Internal counter - 82C54.
External source (A/D External Pacer)
software programmable for rising or falling edge
A/D pacing
(software programmable)
Software polled
A/D trigger sources External edge trigger (A/D EXTERNAL TRIGGER)
A/D triggering modes Rising edge trigger
A/D pre-trigger mode Unlimited pre- and post-trigger samples. Total number of samples must be greater than
512.
Burst mode Software selectable option, burst rate = 150 kHz
From 1024 sample FIFO via REPINSWData transfer
Programmed I/O
A/D conversion time 3 µs max
Analog front end settling time 6 µs for a full scale step to 1 LSB
Calibrated throughput 200 kHz
Calibration Auto-calibration, calibration factors for each range stored on board in nonvolatile RAM
A/D full-scale gain drift ±0.25 LSB/°C max
A/D zero drift ±0.25 LSB/°C max
Common mode range ±10 V min
CMRR @ 60 Hz -70 dB min
Input leakage current ±20 nA max
Input impedance 10 MOhms min
Absolute maximum input
voltage
±35 volts
Warm-up time 15 minutes
18

PCI-DAS1002 User's Manual Specifications
Accuracy
Accuracies are listed for a 200 kHz sampling rate, 100 sample average, single channel operation, a 15 minute
warm-up, and operational temperatures within ±2 °C of internal calibration temperature. The calibrator test
source high side is tied to Channel 0 In and the low side is tied to AGND.
Table 2. Absolute accuracy specifications (analog input)
Range Absolute Accuracy
±10.00 V ±2.5 LSB max
±5.000 V ±2.5 LSB max
±2.500 V ±2.5 LSB max
±1.250 V ±2.5 LSB max
0 to 10.00 V ±2.5 LSB max
0 to 5.000 V ±2.5 LSB max
0 to 2.500 V ±2.5 LSB max
0 to 1.250 V ±2.5 LSB max
Each PCI-DAS1002 is tested at the factory to assure the board’s overall error does not exceed accuracy limits
described in Table 2 above.
Table 3. Calibrated accuracy components (in LSB)
Range Gain Error Offset Error DLE ILE
All ranges ±1.0 max ±1.0 max ±0.75 max ±0.5 max
As shown in Table 3, total board error is a combination of gain, offset, differential linearity and integral
linearity error. The theoretical worst-case error of the board may be calculated by summing these component
errors. Worst case errors are realized only in the unlikely event that each of the component errors are at their
maximum level, and causing error in the same direction.
Crosstalk
Crosstalk is defined here as the influence of one channel upon another when scanning two channels at the
maximum rate. A full scale 100 Hz triangle wave is input on channel 1; Channel 0 is tied to analog ground at
the 100-pin user connector. The table below summarizes the influence of channel 1 on channel 0 with the
effects of noise removed. The residue on channel zero is described in LSB’s.
Table 4. Crosstalk specifications
Condition Crosstalk Per channel Rate ADC Rate
All ranges 2 LSB pk-pk 100 kHz 200 kHz
Noise performance
Table 5 below summarizes the noise performance for the PCI-DAS1002. Noise distribution is determined by
gathering 50 K samples at 200 kHz with inputs tied to ground at the user connector.
Table 5. Board noise performance
Range % within ±2 LSB % within ±1 LSB LSBs LSBrms*
0 to 1.250 V 100% 99% 4 0.61
All other ranges 100% 100% 3 0.45
* RMS noise is defined as the peak-to-peak bin spread divided by 6.6.
19

PCI-DAS1002 User's Manual Specifications
Analog output
Table 6. Analog output specifications
D/A converter type AD7847AR or equivalent
Resolution 12 bits
Number of channels 2
Configuration Voltage output, single-ended
Output range ±10 V, ±5 V, 0 to 10 V, or 0 to 5 V. Software selectable. Each channel independently
programmable.
D/A pacing Software
Data transfer Programmed I/O
Monotonicity Guaranteed monotonic over temperature
Overall analog output drift ±0.03 LSB/°C max
Settling time 4 µs to 0.01% of 10 V step
Slew rate 7 V/µs min
Current drive ±5 mA min
Output short-circuit duration Indefinite @25 mA
Output coupling DC
Output impedance 0.1 Ohm, max
Double buffered output latchesMiscellaneous
Output voltage on power up and reset: ±200 mV
Absolute accuracy
Table 7. Absolute accuracy specifications (analog output)
All ranges ±3 LSB
Calibrated accuracy components
Table 8. Calibrated accuracy specifications (analog output)
Gain error ±1.0 LSB max
Offset error ±0.5LSB max
Integral linearity error ±1.0 LSB max
Differential linearity error ±1.0 LSB max
Each PCI-DAS1002 is tested at the factory to assure absolute accuracy.
Total analog output error is a combination of gain, offset, integral linearity and differential linearity error. The
theoretical worst-case error of the board may be calculated by summing these component errors. Worst case
error is realized only in the unlikely event that each of the component errors are at their maximum level, and
causing error in the same direction. Although an examination of the chart and a summation of the maximum
theoretical errors shows that the board could theoretically exhibit a ±3.5 LSB error, our testing assures this error
is never realized in a board that we ship.
20
