Mebay DC8-D MK Series User manual

DC8xD MK3
GENSET CONTROLLER
USER MANUAL
DC80D MK3
DC82D MK3

DC8xD MK3 GENSET CONTROLLER USER MANUAL
1
Software Version
No.
Version
Date
Note
1
V1.0
2020-10-1
Original release.
2
V1.1
2021-02-01
Name of unified input and output port.
Chongqing MEBAY Technology Co.,Ltd
Add: No6-2,Building 4, Gangan Rd, Jiangbei District, Chongqing.
Tel：[phone]
Fax：[phone]
Web：http://www.mebay.cn
http://www.cqmb.cn
E_mail：[email protected]

DC8xD MK3 GENSET CONTROLLER USER MANUAL
2
Symbol Description
Symbol
Description
Note
Remind operators to operate correctly, otherwise it may cause
the equipment not to work correctly.
Be care
It is indicated that potential hazards can damage equipment
without proper precautions.
Warning
It is indicated if appropriate preventive measures are not taken,
potentially dangerous situations may result in death, serious
personal injury or significant property losses.

DC8xD MK3 GENSET CONTROLLER USER MANUAL
3
Warning
1.The installation of this equipment must be carried out by professionals.
2.When installing and operating the controller, please read the entire instruction
manual first.
3.Any maintenance and commissioning of the equipment must be familiar with all the
equipment.
4.t, safety standards and precautions in advance, otherwise it may cause personal
injury or damage to related equipment.
5.The engine must have an overspeed protection device independent of the
controller system to avoid casualties or other damage caused by engine out of
control.
6.After the installation of the controller is completed, please verify that all protection
functions are valid.
Be Care
1.Please keep the good connection of the power supply of the controller. Do not
share the connection lines of the positive and negative electrodes of the battery
with the floating charger.
2.During the operation of the engine, do not disconnect the battery, otherwise it may
cause damage to the controller.

DC8xD MK3 GENSET CONTROLLER USER MANUAL
4
Catalogue
1. Summary............................................................................................................................... 5
2. Main Features...................................................................................................................... 5
3. Parameters Display............................................................................................................. 6
4. Parameters........................................................................................................................... 7
5. Overall Dimension and Wiring Diagram........................................................................... 8
6. Installation instruction....................................................................................................... 15
7. Panel and display.............................................................................................................. 16
8. Control and operation instruction.................................................................................... 18
9. Warnings and Shutdown Alarms.....................................................................................21
10. Parameter setting............................................................................................................ 26
11. Fault finding......................................................................................................................35
Notes:
1. All rights reserved. No part of this duplication may be reproduced in any material
form (including photocopying or storing in any medium by electronic means or others)
without the written permission of the copyright holder.
2. MEBAY Technology reserves the rights to change the contents of this document
without prior notice.

DC8xD MK3 GENSET CONTROLLER USER MANUAL
5
1.Summary
This series controller is specialized for Diesel / Gasoline / Gas Genset Start,
Stop, Parameters monitoring, faults-checking as well as data setting.
4.3inch colorful LCD screen display with brand new UI design is adapted in this
controller that the relative failures can be displayed directly. All the parameters can
be displayed by simulated indicators and words. Besides, LCD screen can display
various faults in the same time that the genset will be stopped once it can’t work
smoothly.
There are Simplified Chinese, Traditional Chinese, English, Spanish, Russian
interface options, more language can be set according to user’s request. All the
parameters can be configured through the front face buttons or use programmable
interface by RS485 or USB to adjust via PC. It can be widely applied for all kinds of
auto control system of gensets.
2.Main Features
There are four Models under DC8xD MK3 series.
DC80D MK3: used for single machine automation. Start/Stop through remote
start signal.
DC82D MK3: Based on DC80D MK3, it adds Mains monitoring and AMF
(Mains/Generator automatic switching control), especially suitable for the automation
system composed by mains and genset.
DC80DR MK3: Based on DC80D MK3, it adds RS485 port.
DC82DR MK3: Based on DC82D MK3, it adds RS485 port.
Dual core 32bit high performance single chip microcomputer.
4.3inch TFT colorful big screen LCD, Available in 5 languages, user’s language set
if necessary.
Indicator and number display through UI surface.
Acrylic material is adapted to protect the screen.
Silicone panels;
USB Port: parameters can be set even without power through USD port to monitor
in real time.
With RS485 communication port, can achieve “Three Remote” functions via
MODBUS protocol.
Various kinds of parameters display.
Input/output function, status can be shown directly.
More categories of surface setting.
Real time clock inside.
Maintenance countdown function, can set maintenance timing or date.
The black box function can save the relevant parameters of the unit when the fault
alarm occurs in real time, and it is convenient to find the cause of the fault.
Totally 7 relay’s output, among which 5 relay output can be self-configurable, each
relay can be set as max 50 functions, besides, there are 2 groups as non-contact
terminals.
5 relays can be set as switch value input, and function configurable.
3 sensor simulation input connectors, various kinds of units can be set.
Sensor can be self-defined by front face button or PC software.

DC8xD MK3 GENSET CONTROLLER USER MANUAL
6
Adapt to 3P4W,1P2W,2P3W(120V/240V,50/60HZ)
Various of crank conditions (RPM, Frequency, Oil Pressure) can be chosen.
Control Protection: Auto Start/Stop of genset, load transfer (ATS control) and
perfect failure display and protection.
Standard water-proof rubber gasket. The waterproof can reach IP54
Module design: All the connections are adapted with European connectors so that
installation, connection, repair and replacement can be more easily.
3.Parameters Display
Engine RPM
Engine oil pressure
Engine temperature
Engine fuel level
Engine battery voltage
Charging voltage
Mains Frequency (only for DC82D MK3)
Mains phase voltage L-N (only for DC82D MK3)
Mains phase voltage L-L (only for DC82D MK3)
Generator 3 Phase voltage L-N
Generator 3 Phase voltage L-L
Generator phase
Generator 3 phase current A
Generator Frequency Hz
Generator Power Factor COS φ
Generator active power KW
Generator apparent power KVA
Generator reactive power K Var
Real-time load rate %
Current load rate%
Average loading rate %
Current consumption KWH
Total consumption KWH
Total Crank times
Current running time
Total running time
Maintenance notice
5 switches input status display
Output status display of 7 relays
Protection
Over speed
Under speed
Low oil pressure
High temperature
Low fuel level
Low oil level
External emergency alarm

DC8xD MK3 GENSET CONTROLLER USER MANUAL
7
RPM Lost
Sensor Open
Over Frequency
Under Frequency
Over voltage
Under voltage
Over current
Over power
Maintenance expire
Low water level alarm
Emergency Stop
Crank failure
Stop Failure
4.Parameters
Options
Parameters
Working voltage
DC8V----36V Continuous
Power consumption
Standby：24V：MAX 1W
Working：24V：MAX 7W
AC Voltage Input
1P2W 30VAC-276VAC (ph-N)
2P3W 30VAC-276VAC (ph-N)
3P4W 30VAC-276VAC (ph-N)
Rotate speed sensor
Frequency
200-10000Hz
MAX Accumulating Time
99999.9Hours（Min Store time:6min）
Fuel Relay Output
Max 16Amp DC+VE Supply voltage
Start Relay Output
Max 16Amp DC+VE Supply voltage
AUX. OUPUT1
Max 5Amp DC+VE Supply voltage
AUX. OUPUT2
Max 5Amp DC+VE Supply voltage
AUX. OUPUT3
Max 5Amp DC+VE Supply voltage
AUX. OUPUT4
5AMP Non-contact normal close output
AUX. OUPUT5
5AMP Non-contact normal open output
Excitation output
Max 0.9AMP DC+VE supply voltage
Switch value input
Available if connecting with Battery -
Working condition
-25-65℃
Storage condition
-40-85℃
Protection Level
IP54：when waterproof rubber gasket is added between
controller and its panel
Insulation strength
Apply AC1.5kV voltage between high voltage terminal
and low voltage terminal; The leakage current is not
more than 3mA within 1min.
Overall dimension
241mm*177mm*45mm
Panel cutout
220mm*160mm
Weight
0.9Kg

DC8xD MK3 GENSET CONTROLLER USER MANUAL
8
5.Overall Dimension and Wiring Diagram
Overall Dimension:
241
177
45
241
177
45

DC8xD MK3 GENSET CONTROLLER USER MANUAL
9
Descriptions of terminal connection
No.
Function
Description
Cable
cross
sectional
area
1
Battery Negative Input B-
Controller power supply input B-.
2.5mm2
2
Battery Negative Input B+
Controller power supply input B+.
2.5mm2
3
Emergency Stop Input
B+ voltage input is active, and connected
to emergency stop normal closed button.
2.5mm2
4
Fuel Output
Active output, Max 16Amp
1.5mm2
5
Crank Output
Active output, Max 16Amp.
1.5mm2
6
Aux. Ouput1
Active output, Max 5Amp.
1.5mm2
7
Aux. Ouput2
Passive Output, Max 5Amp.
1.5mm2
8
Aux. Ouput3
Passive Output, Max 5Amp.
1.5mm2
9
Charging excitation output
Active output, Max 0.9Amp.
1.0mm2
10
Aux. Input1
The grounding is valid according to the
function selection switch input.
1.0mm2
11
Aux. Input2
1.0mm2
12
Aux. Input3
1.0mm2
13
Aux. Input4
1.0mm2
14
Aux. Input5
1.0mm2
15
Reserved
Reserved.

DC8xD MK3 GENSET CONTROLLER USER MANUAL
10
16
Speed sensor SCR
Connecting speed sensor shielded wire
ground.
1.0mm2
17
Speed sensor +
Use a shielded wire to connect the speed
sensor.
1.0mm2
18
Speed sensor -
1.0mm2
19
Common GND
Connect the battery negative or outer
casing.
1.5mm2
23
RS485 B
A 120 Ω shielded wire and good grounding
are recommended.
1.0mm2
24
RS485 A
1.0mm2
25
RS485 SCR
1.0mm2
27
Aux.Output4
Passive normally closed output, Max
5Amp.
1.5mm2
28
Aux.Output4
1.5mm2
29
Aux.Output5
Passive normally open output, Max 5Amp.
1.5mm2
30
Aux.Output5
1.5mm2
31
Mains Voltage R
Connected to the mains U phase.
1.0mm2
32
Mains Voltage S
Connected to the mains V phase.
1.0mm2
33
Mains Voltage T
Connected to the mains W phase.
1.0mm2
34
Mains Voltage N1
Connected to the mains N phase.
1.0mm2
35
Generator Voltage U
Connected to the power generation output
R phase.
1.0mm2
36
Generator Voltage V
Connected to the power generation output
S phase.
1.0mm2
37
Generator Voltage W
Connected to the power generation output
T phase.
1.0mm2
38
Generator Voltage N2
Connected to the power generation output
N phase.
1.0mm2
39
Load CT Secondary L1
Current Transformer Secondary Rated 5A.
1.5mm2
40
Load CT Secondary L2
1.5mm2
41
Load CT Secondary L3
1.5mm2
42
Load CT Secondary ICOM
Connect to the common GND instead of
the neutral line N.
1.5mm2
43
Load CT Secondary ICOM
1.5mm2
44
Temperature Sensor
Connect sensor input.
1.0mm2
45
Oil pressure sensor
1.0mm2
46
Fuel level sensor
1.0mm2
47
Sensor common GND
Connect the battery negative or outer.
1.5mm2
48
+5V Output
Connect the power supply of the oil
pressure sensor with the output voltage
signal, with a maximum of 50mA.
1.0mm2
49
GND
Connect the battery negative.
1.0mm2

DC8xD MK3 GENSET CONTROLLER USER MANUAL
11
DC80D MK3 3-phase 4-wire Typical Wiring Diagram
Note: Please don’t move battery during running status or it may cause the
controller broken!
WARNING: When generator is on-load, C. T. secondary must not be open
circuit, Otherwise, the high voltage generated will pose a danger to personal safety.
GND
AUX. S2_COOLANT TEMP
AUX. S3_FUEL LEVEL
CTs MUST BE 5 AMP SECONDARY
FROM GENERATOR
TO LOAD SWITCHING
DEVICE
AUX. INPUT 5_LOW COOLANT LEVEL ALARM AUX. INPUT 2_HIGH COOLANT TEMP ALARM AUX. INPUT 4_LOW FUEL LEVEL WARNING AUX. INPUT 3_LOW OIL PRESSURE ALARM AUX. INPUT 1_REMOTE START
AUX. S1_OIL PRESSURE
11
109 45 44
5
43
21 46
37
T
3635
SR
41
CT2
38
N1
MODEL: DC80D MK3
BATTERY FUSE 10A
FUSE 20A EMERGENCY
INPUTS
FUEL
CRANK
BATTERY NEGATIVE MUST BE GROUNDED
SWITCH
4039
CT1 CT3 COM
17 18
D+
42
12
613 14 47
ALT
P1 P2
S1S2
P1 P2
S1S2
P1 P2
S1S2
R
S
T
N1
7 8 16
WL
AUX. OUTPUT 1
MAX 5A
MAX 16A
30 33
W
3231
V
U
34
N2
27
29 28
(MAX 5A)
G
(MAX 5A)
DC8-36V
+
-
+-
1519 24 2523
B A SCR
RS485 MPU
43
48 49
+5V OUTPUT
(AC30-276V)(AC 0-5A)
GEN CURRENT GEN VOLTS AUX. OUTPUT 5 AUX. OUTPUT 4 (AC30-276V)
MAIN VOLTS
GND
AUX. OUTPUT 2 AUX. OUTPUT 3
STOP
1.No. 47 common sensor lines must be securely
attached to the vicinity of the sensor body.
2.To ensure reliable operation of the module and the
measuring accuracy, power lines as much as
possible and do not share power cable crude and
other devices.
REMARK:
FUSE 2A
GND
INPUTS

DC8xD MK3 GENSET CONTROLLER USER MANUAL
12
DC82D MK3 3-phase 4-wire Typical Wiring Diagram
Note: Please don’t move during running status or it may cause the
controller broken!
WARNING: When generator is on-load, C. T. secondary must not be open
circuit, Otherwise, the high voltage generated will pose a danger to personal safety.
FROM MAINS
MECHANICAL INTERLOCK
TO LOAD SWITCHING
DEVICE
11
10
945 44
5
43
21 46
37
T
3635
SR
41
CT2
38
N1
INPUTS
4039
CT1 CT3 COM
17 18
42
12
613 14 47
P1 P2
S1 S2
P1 P2
S1S2
P1 P2
S1S2
R
S
T
N1
7 8 16
MAX 5A
MAX 16A
30 33
W
32
31
V
U
34
N2
27
29 28
G
DC8-36V
1519 24 2523
RS485 MPU
43
48 49
M
L1 L2 L3 N
U
V
W
N2
CTs MUST BE 5 AMP SECONDARY
FROM GENERATOR
FUSE 2A FUSE 2A
(MAX 5A) (MAX 5A)(AC30-276V)
(AC 0-5A)
GEN CURRENT GEN VOLTS AUX. OUTPUT 5 AUX. OUTPUT 4
(AC30-276V)
MAIN VOLTS
MODEL: DC82D MK3
GND
AUX. S2_COOLANT TEMP
AUX. S3_FUEL LEVEL
AUX. INPUT 5_LOW COOLANT LEVEL ALARM AUX. INPUT 2_HIGH COOLANT TEMP ALARM AUX. INPUT 4_LOW FUEL LEVEL WARNING AUX. INPUT 3_LOW OIL PRESSURE ALARM AUX. INPUT 1_REMOTE START
AUX. S1_OIL PRESSURE
BATTERY FUSE 10A
FUSE 20A EMERGENCY
FUEL
CRANK
BATTERY NEGATIVE MUST BE GROUNDED
SWITCH
D+
ALT WL
AUX. OUTPUT 1
+
-
+-
B A SCR
+5V OUTPUT
GND
AUX. OUTPUT 2 AUX. OUTPUT 3
STOP
1.No. 47 common sensor lines must be securely
attached to the vicinity of the sensor body.
2.To ensure reliable operation of the module and the
measuring accuracy, power lines as much as
possible and do not share power cable crude and
other devices.
REMARK:
GND
INPUTS

DC8xD MK3 GENSET CONTROLLER USER MANUAL
13
DC80D MK3 1-phase 2-wire Typical Wiring Diagram
DC80D MK3 2-phase 3-wire Typical Wiring Diagram
CTs MUST BE 5 AMP SECONDARY
FROM GENERATOR
TO LOAD SWITCHING
DEVICE
37
T
3635
SR
41
CT2
38
N1
MODEL: DC80D MK3
4039
CT1 CT3 COM
42
P1 P2
S1S2
R
N1
30 33
W
32
31
V
U
34
N2
29
G
43
(AC 0-5A)
GEN CURRENT GEN VOLTS MAIN VOLTS
FUSE 2A
1 PHASE 2 WIRE
(AC30-276V) (AC30-276V)
27 28
(MAX 5A) (MAX 5A)
AUX. OUTPUT 5 AUX. OUTPUT 4
CTs MUST BE 5 AMP SECONDARY
FROM GENERATOR
TO LOAD SWITCHING
DEVICE
37
T
3635
SR
41
CT2
38
N1
MODEL: DC80D MK3
4039
CT1 CT3 COM
42
P1 P2
S1S2
P1 P2
S1S2
R
S
N1
30 33
W
32
31
V
U
34
N2
29
G
43
(AC 0-5A)
GEN CURRENT GEN VOLTS MAIN VOLTS
FUSE 2A
2 PHASE 3 WIRE
(AC30-276V) (AC30-276V)
27 28
(MAX 5A) (MAX 5A)
AUX. OUTPUT 5 AUX. OUTPUT 4

DC8xD MK3 GENSET CONTROLLER USER MANUAL
14
DC82D MK3 1-phase 2-wire Typical Wiring Diagram
DC82D MK3 2-phase 3-wire Typical Wiring Diagram
FROM MAINS
MECHANICAL INTERLOCK
TO LOAD SWITCHING
DEVICE
3736
35
41 38
4039 42
P1 P2
S1 S2
R
N1
30 3332
31 34
27
29 28
G
43
M
L1 N
U
N2
CTs MUST BE 5 AMP SECONDARY
FROM GENERATOR
FUSE 2A FUSE 2A
MODEL: DC82D MK3 1 PHASE 2 WIRE
TSR
CT2 N1 CT1 CT3 COM WV
UN2
(MAX 5A) (MAX 5A)(AC30-276V)(AC 0-5A)
GEN CURRENT GEN VOLTS AUX. OUTPUT 5 AUX. OUTPUT 4
(AC30-276V)
MAIN VOLTS
FROM MAINS
MECHANICAL INTERLOCK
TO LOAD SWITCHING
DEVICE
373635
41 38
4039 42
P1 P2
S1S2
P1 P2
S1S2
R
S
N1
30 333231 34
27
29 28
G
43
M
L1 L2 N
U
V
N2
CTs MUST BE 5 AMP SECONDARY
FROM GENERATOR
FUSE 2A FUSE 2A
MODEL: DC82D MK3 2 PHASE 3 WIRE
TSR
CT2 N1 CT1 CT3 COM WV
UN2
(MAX 5A) (MAX 5A)(AC30-276V)
(AC 0-5A)
GEN CURRENT GEN VOLTS AUX. OUTPUT 5 AUX. OUTPUT 4
(AC30-276V)
MAIN VOLTS

DC8xD MK3 GENSET CONTROLLER USER MANUAL
15
6.Installation instruction
The controller is fixed by four special fixing members and screws, and the screws
of the metal fasteners cannot be too tight.
Panel Cutout: W220mm*H160mm.
220
160
Note: If the controller is installed directly in the genset shell or other fluctuated
equipment, the rubber pad must be installed.
Battery Voltage Input
DC8xD MK3 controller is suitable for 8-36V DC battery voltage. Battery negative
must be reliably connected to the enclosure of the engine. The controller power
supply B+ and B- must be connected to battery positive and negative, and the wire
size must not be less than 2.5mm2.
NOTE:
In case of floating charger connect charger output to battery positive and negative
directly, then, connect battery positive and negative poles to controller positive and
negative power supply.
Output and relay expansion
Note: All outputs of the controller are relay contacts. The maximum current
capacity is described in the "Parameters" in this manual. Please use it in the relay
current capacity. If an extended relay is needed, add a continuous current diode
(when the extended relay coil is DC) or a resistance-capacitance loop (when the
extended relay coil is AC) to both ends of the coil to prevent interference with the
controller or other equipment.
AC current input
Current transformer with rated secondary current 5A must be externally connected
to the controller current input.
WARNING: When generator is on-load, C. T. secondary must not be open
circuit, Otherwise, the high voltage generated will pose a danger to personal safety.
Withstanding voltage test

DC8xD MK3 GENSET CONTROLLER USER MANUAL
16
If withstanding voltage test is conducted after the controller has already been
installed onto the control panel, please unplug all controller terminal connections in
order to prevent high voltage from damaging it.
7.Panel and display
DC80D MK3
DC82D MK3
Right
OK/UI Change
Down
LED Test/MUTE
Alarm record
Stop
Manual Start
Manual
Auto
Running
Warning
Alarm
Close/On
Gens on load
Gens status
Mains Status
Right
OK/UI Change
Down
Manual
Auto
Stop
Manual Start
LCD
Left
Up
Gens status
Running
Warning
Alarm
On load
Load transfer
On MAN mode
LCD
Left
Up
Mains on load
Close/On
Test
LED Test/MUTE

DC8xD MK3 GENSET CONTROLLER USER MANUAL
17
Key Function Description
KEYS
NAME
Main Function
Stop
Reset
Revert
Can stop generator under manual/auto mode;
Can reset shutdown alarm
During stop procession, pressing this key again can stop
generator immediately.
Pressing this key can cancel the setting and back to
upper class under edition.
Under the setting mode with checking data, the data can
be saved and system will exit after pressing.
Start
Start the genset under manual mode.
Pressing this key can start the genset under manual
testing mode.
Manual
Pressing this key will set the module into manual mode.
Auto
Pressing this key will set the module into auto mode.
DC80D MK3
Records
Pressing this key to check the alarm records under stop
mode.
DC82D MK3
Test
Pressing this key to come into manual testing mode.
Under testing mode, pressing MANUAL can start the
genset and transfer to normal loading after running which
is to test if the auto start is in normal status.
LED Test/
Warning clear
Test if all LED lights are ok, pressing this key to test if all
lighted, all off when loosen it.
Under warning, pressing this key can clear warning and
controller will re-check warning.
Under alarm, pressing this key can clear the buzzer call.
Pressing this key in 3 seconds can clear the buzzer call,
pressing it again in 3 seconds can recover the buzzer call.
Gens/ Mains
Close/On
Under manual mode, pressing this key can transfer load
to genset/mains.
Left
Under display mode, pressing this key to turn left page.
Under edition mode, pressing this key to move the digit.
Right
Under display mode, pressing this key to turn right page.
Under edition mode, pressing this key to move the digit.
Up
Under display mode, parts of the page can move up.
Under edition mode, pressing this key to move the digit
or increase the numbers.
Under records mode, pressing this key to move the digit.
Down
Under display mode, parts of the page can move down.
Under edition mode, pressing this key to move the digit
or decrease the numbers.
Under records mode, pressing this key to move the digit.

DC8xD MK3 GENSET CONTROLLER USER MANUAL
18
OK
UI Change
Confirm the change under edition mode.
Page exited under records checking mode.
Black UI and white UI can be switched when Pressing.
In standby state, press for 3 seconds to enter the
parameter setting mode.
+
Setting mode
Pressing OK and STOP simultaneously to come into
setting mode
+
DC82D MK3
Alarm Records
checking
Pressing STOP and RIGHT to check the records and
any buttons pressed to exit from the page.
Engine flywheel teeth automatic adjustment
1)Crank disconnect must be set to include both "speed" and "frequency" options.
2)When the generator frequency and engine speed are not zero, press
and for more than 0.5 seconds, the controller will automatically calculate
and save the number of flywheel teeth according to the generation frequency and
generator poles.
3)After calculating and saving the number of flywheel teeth successfully, the
controller shows: " Flywheel xxx teeth, saved successfully!"
Alarm records checking
DC8xD MK3 controller can save 40 group of alarm records which contains the alarm
record data includes detailed data such as alarm time, generator parameters, engine
parameters, etc.
How to check the alarm records:
1)Enter alarm record page:
a)DC80D MK3: under stop mode, press to come into alarm records page;
b)DC82D MK3: press and simultaneously to come into alarm records
page;
2)Press to turn upper digit and press to turn lower digit in order to
choose the record you need. Press to confirm the record and come into
history records checking page.
3)Press to turn lower records under records checking page. Press to
turn upper records and press to revert back to alarm history records page.
4)Exit from records page: In the history records page and checking page, press
to exit.
8.Control and operation instruction
Manual test mode: (only DC82D MK3 has this function)
press and make sure it is in the stop position before starting.
Press “ ” and the test file indicator is on. At this time, it is detected whether the
connection of each sensor is normal. If the sensor is open, the sensor opens an

DC8xD MK3 GENSET CONTROLLER USER MANUAL
19
alarm. If it is normal, the unit start process is executed in the following sequence after
pressing the " ". automatically switch to Generator provide the power when the
unit is running normally.
Press “ ” The controller performs the parking process at the following timing:
0RPM
Idle
Rated speed
Pre-
heat
delay
5S
Long-
est
pre-oil
supply
delay
0S
Start
Crank
delay
2S 8S
Safe
time
8S
Start
idle
time
5S
Longest
speed
increasing
time
120S
Idle
Rated speed
Pre-
heat
delay
Longest
temperature
increasing
time
10S
Longest
voltage
built/
increasing
time
120S 10S
rated
runn-
ing
Cooling
running time
30S
Stop
idle
time
5S
ETS
solen-
oid
hold
10S
Wait
Stop
30S
warming
up time
Crank
test
time
Manual Start Mode
press and make sure it is in the stop position before starting.
Press “ ” and the test file indicator is on. At this time, it is detected whether the
connection of each sensor is normal. If the sensor is open, the sensor opens an
alarm. If it is normal, the unit start process is executed in the following sequence after
pressing the " ". automatically switch to Generator provide the power when the
unit is running normally. Press “ ” The controller performs the parking process at
the following timing:
Manual start and stop process:
0RPM
Idle
Rated speed
Pre-
heat
delay
5S
Long-
est
pre-oil
supply
delay
0S
Start
Crank
delay
2S 8S
Safe
time
8S
Start
idle
time
5S
Longest
speed
increasing
time
120S
Idle
Rated speed
Pre-
heat
delay
Longest
temperature
increasing
time
10S
Longest
voltage
built/
increasing
time
120S 10S
rated
runn-
ing
Cooling
running time
30S
Stop
idle
time
5S
ETS
solen-
oid
hold
10S
Wait
Stop
30S
warming
up time
Crank
test
time
After the manual start is successful, pressing the "automatic key" can be converted
into an automatic file. The specific working time is as follows:
