Mec Speed Level Series Guide

Service & Parts Manual
Part # 91885 R1
January 2019
Speed Level Series
RT - Internal Combustion
ES - Electric 2684ES Serial Number Range 12700000 - Up 2684RT Serial Number Range 12800000 - Up
3084ES Serial Number Range 11700000 - Up
3084RT Serial Number Range 11800000 - Up

Page i Speed Level Series - Service & Parts Manual
January 2019
Revision History
Date Reason for Update
January 2019 Speed Level Mk. 2 Update
1401 S. Madera Avenue, Kerman, CA 93630 USA
Toll Free: 1 - 877 - 632 - 5438
Phone: 1 - 559 - 842 - 1500
Fax: 1 - 559 - 842 - 1520
[email protected]
www.MECawp.com
MEC Aerial Work Platforms

Page ii Speed Level Series - Service & Parts Manual
January 2019
Table of Contents
Chapter 1 - Service . . . . . . . . . . . . . 1
Service Introduction ................1
Section 1 - MEC Operator Policy ............2
MEC Operator Policy . . . . . . . . . . . . . . . . . . . 2
Section 2 - Safety Symbols & General Safety Tips. . . . . . . . 3
Safety Symbols & General Safety Tips . . . . . . . . . . . . . . 3
Section 3 - Specifications . . . . . . . . . . . . . . 4
RT Models Specifications . . . . . . . . . . . . . . . . . . 4
ES Models Specifications . . . . . . . . . . . . . . . . . . 5
Section 4 - General Information . . . . . . . . . . . . . 6
KeySafetyTips....................6
Hydraulic System . . . . . . . . . . . . . . . . . . . . 7
Primary Machine Components . . . . . . . . . . . . . . . . 8
Bolt Torque Specification - American Standard . . . . . . . . . . . . 10
Bolt Torque Specification - Metric Standard . . . . . . . . . . . . . 11
Hydraulic Components Torque Table . . . . . . . . . . . . . . . 12
Emergency Systems And Procedures. . . . . . . . . . . . . . . 13
Parking Brake And Towing Circuit . . . . . . . . . . . . . . . . 14
Lift And Support The Machine. . . . . . . . . . . . . . . . . 15
Transporting The Machine. . . . . . . . . . . . . . . . . . 16
Section 5 - Hydraulic System . . . . . . . . . . . . . 17
Hydraulic System – General . . . . . . . . . . . . . . . . . 17
Hydraulic Roadmap . . . . . . . . . . . . . . . . . . . 18
HydraulicFluid.....................19
Hydraulic Fluid Reservoir . . . . . . . . . . . . . . . . . . 20
Hydraulic Pump - 3084RT . . . . . . . . . . . . . . . . . . 21
Hydraulic Pump Seals - 3084RT . . . . . . . . . . . . . . . . 22
Hydraulic Pump - 3084ES . . . . . . . . . . . . . . . . . . 24
Hydraulic Manifold. . . . . . . . . . . . . . . . . . . . 25
Drive And Brake System Wheel Drive. . . . . . . . . . . . . . . 29
Floating Axle Lock Cylinders . . . . . . . . . . . . . . . . . 35
Steering Circuit . . . . . . . . . . . . . . . . . . . . 36
Platform Leveling System . . . . . . . . . . . . . . . . . . 37
Platform Lift Circuit . . . . . . . . . . . . . . . . . . . 38
LiftCylinder.....................39
General Cylinder Repair . . . . . . . . . . . . . . . . . . 40
Generator Option - 3084RT . . . . . . . . . . . . . . . . . 42
Section 6 - Electrical System . . . . . . . . . . . . . 43
Electrical System – General . . . . . . . . . . . . . . . . . 43
Batteries......................45
Battery Replacement . . . . . . . . . . . . . . . . . . . 47

Page iii Speed Level Series - Service & Parts Manual
January 2019
Lower Controls - 3084RT Dual Fuel/Diesel . . . . . . . . . . . . . 48
Lower Controls - 3084ES Electric . . . . . . . . . . . . . . . . 49
Upper Controls - 3084RT Dual Fuel/Diesel . . . . . . . . . . . . . 50
Upper Controls - 3084ES Electric . . . . . . . . . . . . . . . . 51
Alarms And Switches . . . . . . . . . . . . . . . . . . . 52
Deutsch Connectors . . . . . . . . . . . . . . . . . . . 54
Continuity Checks . . . . . . . . . . . . . . . . . . . . 55
GP400 Control Module Setup .................57
General Description . . . . . . . . . . . . . . . . . . . 58
GP400 Calibration . . . . . . . . . . . . . . . . . . . . 59
Calibration Problems . . . . . . . . . . . . . . . . . . . 64
Information Messages . . . . . . . . . . . . . . . . . . . 69
Section 7 - Mechanical System . . . . . . . . . . . . . 72
Mechanical Components . . . . . . . . . . . . . . . . . . 72
Floating Axle Lock Cylinders . . . . . . . . . . . . . . . . . 76
Boom - Elevating Assembly . . . . . . . . . . . . . . . . . 80
Lubrication......................81
Engine Maintenance . . . . . . . . . . . . . . . . . . . 82
Gasoline & Dual Fuel Engine Models . . . . . . . . . . . . . . . 85
Section 8 - Troubleshooting - 3084RT Models . . . . . . . . . 87
General Troubleshooting Tips . . . . . . . . . . . . . . . . . 87
Electrical System Troubleshooting - 3084RT . . . . . . . . . . . . . 88
GP400Module.....................89
Matrix Module & Terminal Block Module (TBM) . . . . . . . . . . . . 90
EZ-Cal Scan Tool . . . . . . . . . . . . . . . . . . . . 91
Using The EZ-Cal With The Flow Charts . . . . . . . . . . . . . . 92
EZ-Cal Adjustment. . . . . . . . . . . . . . . . . . . . 97
EZ-Cal Diagnostics . . . . . . . . . . . . . . . . . . 100
EZ-Cal Retrieve Mode And Help Messages . . . . . . . . . . . . 103
EZ-Cal Help Messages . . . . . . . . . . . . . . . . . 107
Function Active Messages. . . . . . . . . . . . . . . . . 108
Shutdown Help Messages. . . . . . . . . . . . . . . . . 109
Supply Messages . . . . . . . . . . . . . . . . . . . .111
Sensor Messages CE Models . . . . . . . . . . . . . . . . .112
Other Messages . . . . . . . . . . . . . . . . . . . .113
Troubleshooting Chart . . . . . . . . . . . . . . . . . . .114
Hydraulic Pressure Adjustment - 3084RT . . . . . . . . . . . . . .118
Adjustments - 3084RT. . . . . . . . . . . . . . . . . . .119
Component Illustrations . . . . . . . . . . . . . . . . . 121
Section 9 - Troubleshooting - 3084ES Models . . . . . . . . . 122
General Troubleshooting Tips . . . . . . . . . . . . . . . . 122
Electrical System Troubleshooting - 3084ES . . . . . . . . . . . . 123
GP400 Module.................... 124
Matrix Module & Terminal Block Module . . . . . . . . . . . . . 125
P600 Motor Control Module . . . . . . . . . . . . . . . . 126
EZ-Cal Scan Tool . . . . . . . . . . . . . . . . . . . 127
Using The EZ-Cal With The Flow Charts . . . . . . . . . . . . . 128

Page iv Speed Level Series - Service & Parts Manual
January 2019
EZ-Cal Adjustment. . . . . . . . . . . . . . . . . . . 133
EZ-Cal Setup .................... 135
EZ-Cal Diagnostics . . . . . . . . . . . . . . . . . . 136
EZ-Cal Retrieve Mode And Help Messages . . . . . . . . . . . . 138
EZ-Cal Help Messages . . . . . . . . . . . . . . . . . 142
Function Active Messages. . . . . . . . . . . . . . . . . 143
Shutdown Help Messages................. 144
P600 Temperature Messages ................ 146
Sensor Messages CE Models . . . . . . . . . . . . . . . . 147
Other Messages . . . . . . . . . . . . . . . . . . . 148
Troubleshooting Chart . . . . . . . . . . . . . . . . . . 149
Troubleshooting Battery Charger: Electric Models . . . . . . . . . . 154
Battery Charger, HB1500-48 ................ 155
Hydraulic Pressure Adjustment - 3084ES . . . . . . . . . . . . . 157
Component Illustrations . . . . . . . . . . . . . . . . . 159
Section 10 - Schematics . . . . . . . . . . . . . . . 162
3084RT - Diesel/Dual Fuel Models . . . . . . . . . . . . . . 162
3084RT - Hydraulic Schematic . . . . . . . . . . . . . . . 163
3084RT - Hydraulic Manifold Main M1 . . . . . . . . . . . . . 164
3084 All Models - Hydraulic Manifold Tilt M2 . . . . . . . . . . . . 165
3084RT - Upper Controls Electric Schematic . . . . . . . . . . . . 166
3084RT - Upper Controls Components . . . . . . . . . . . . . 167
3084RT Dual Fuel - Lower Control Box Electric Schematic . . . . . . . . 168
3084RT Dual Fuel - Base Electric Schematic . . . . . . . . . . . . 169
3084RT Diesel - Lower Control Box Electric Schematic . . . . . . . . . 170
3084RT Diesel - Base Electric Schematic. . . . . . . . . . . . . 171
3084RT - Lower Controls Components . . . . . . . . . . . . . 172
3084ES - Electric Model . . . . . . . . . . . . . . . . . 173
3084ES - Hydraulic Schematic . . . . . . . . . . . . . . . 174
3084ES - Hydraulic Manifold Main M1 . . . . . . . . . . . . . 175
3084 All Models - Hydraulic Manifold Tilt M2 . . . . . . . . . . . . 176
3084ES - Upper Controls Electric Schematic . . . . . . . . . . . . 177
3084ES - Upper Controls Components . . . . . . . . . . . . . 178
3084ES - Lower Control Box Electric Schematic . . . . . . . . . . . 179
3084ES - Base Electric Schematic . . . . . . . . . . . . . . 180
3084ES - Lower Controls Components . . . . . . . . . . . . . 181
XX84RT Model, Hydraulic Schematic with Hydrastatic Drive . . . . . . . . 182
XX84 RT Diesel Models - Electrical Schematic, Part 1 . . . . . . . . . 183
XX84 RT Diesel Models - Electrical Schematic, Part 2 . . . . . . . . . 184
Chapter 2 - Parts . . . . . . . . . . . . . . 186
Parts Introduction ................186
Section 11 - Controls................187
Upper Controls, ANSI Models, Early Style . . . . . . . . . . . . 187
Upper Controls, CE Models . . . . . . . . . . . . . . . . 189
Upper Control Box Cover Assembly, Early Style ........... 191
Upper Control Joystick, Early Style . . . . . . . . . . . . . . 193

Page v Speed Level Series - Service & Parts Manual
January 2019
Upper Control Box Assembly, Early Style . . . . . . . . . . . . . 195
Lower Controls, 3084ES Electric Models . . . . . . . . . . . . . 197
Lower Controls, 3084RT Dual Fuel Models ............ 199
Lower Controls, 3084RT Diesel Models . . . . . . . . . . . . . 201
Section 12 - Platform and Rails . . . . . . . . . . . . . 203
Platform Installation - To Serial #11800046 . . . . . . . . . . . . 203
Platform & Rails, 3084 - To Serial # 11800046 . . . . . . . . . . . 205
Platform & Rails, 3084 - From Serial # 11800047 . . . . . . . . . . . 207
Platform & Rails, 2684 - Part 1 . . . . . . . . . . . . . . . 209
Platform & Rails, 2684 - Part 2 . . . . . . . . . . . . . . . .211
Section 13 - Boom . . . . . . . . . . . . . . . . 213
Boom Mount and Pivot . . . . . . . . . . . . . . . . . 213
Chassis Planetary Drive Assembly . . . . . . . . . . . . . . 215
Side Port Assembly . . . . . . . . . . . . . . . . . . 217
Lower Boom Assembly . . . . . . . . . . . . . . . . . 219
Upper Boom Assembly . . . . . . . . . . . . . . . . . 221
Section 14 - Axles . . . . . . . . . . . . . . . . 223
Front Axle Assembly . . . . . . . . . . . . . . . . . . 223
Axle Installation, Front. . . . . . . . . . . . . . . . . . 225
Axle Installation, Rear . . . . . . . . . . . . . . . . . . 227
Wheel Motor, Rear. . . . . . . . . . . . . . . . . . . 229
Wheel Motor, Front . . . . . . . . . . . . . . . . . . 231
Section 15 - Hydraulics . . . . . . . . . . . . . . . 233
Main Manifold Assembly, Electric Models - Part 1. . . . . . . . . . . 233
Main Manifold Assembly, Electric Models - Part 2. . . . . . . . . . . 235
Main Manifold Assembly, RT Models - Part 1 . . . . . . . . . . . . 237
Main Manifold Assembly, RT Models - Part 2 . . . . . . . . . . . . 239
Leveling Manifold Assembly . . . . . . . . . . . . . . . . 241
RT Manifold Assembly. . . . . . . . . . . . . . . . . . 243
Hydraulic Hose Routing, RT Models: Steer, Brake, Case Drain Early Style . . . . 245
Hydraulic Hose Routing, RT Models: Lift, Pump . . . . . . . . . . . 247
Hydraulic Hose Routing, RT Models: Platform Level, Axle Float . . . . . . . 249
Hydraulic Hose Routing, RT Models: Drive Motors . . . . . . . . . . 251
Hydraulic Hose Routing, ES Models: Steer, Brake, Case Drain . . . . . . . 253
Hydraulic Hose Routing, ES Models: Lift, Pump . . . . . . . . . . . 255
Hydraulic Hose Routing, ES Models: Platform Level, Axle Float . . . . . . . 257
Hydraulic Hose Routing, ES Models: Drive Motors . . . . . . . . . . 259
LiftCylinder.................... 261
Steering Cylinder . . . . . . . . . . . . . . . . . . . 263
Level Cylinder . . . . . . . . . . . . . . . . . . . . 265
Axle Lock Cylinder. . . . . . . . . . . . . . . . . . . 267
Section 16 - Base. . . . . . . . . . . . . . . . . 269
Module Installation. . . . . . . . . . . . . . . . . . . 269
Control Module – ES, Drawing 1 of 2 . . . . . . . . . . . . . . 271
Control Module – ES, Drawing 2 of 2 . . . . . . . . . . . . . . 273

Page vi Speed Level Series - Service & Parts Manual
January 2019
Power Module – ES . . . . . . . . . . . . . . . . . . 275
Control Module RT, Drawing 1 of 2 . . . . . . . . . . . . . . 277
Control Module, RT Drawing 2 of 2 . . . . . . . . . . . . . . 279
ES Control Module Assembly . . . . . . . . . . . . . . . . 281
RT Control Module Assembly . . . . . . . . . . . . . . . . 283
Power Module – RT . . . . . . . . . . . . . . . . . . 285
ES Power Module Assembly ................ 287
Diesel Power Module Assembly . . . . . . . . . . . . . . . 289
Dual Fuel Power Module Assembly . . . . . . . . . . . . . . 291
Engine Mount – Dual Fuel. . . . . . . . . . . . . . . . . 293
Engine Mount – Diesel. . . . . . . . . . . . . . . . . . 295
Engine – Diesel . . . . . . . . . . . . . . . . . . . 297
Engine – Dual Fuel . . . . . . . . . . . . . . . . . . 299
LP Tank – Dual Fuel . . . . . . . . . . . . . . . . . . 301
Generator Option, RT - Old Style . . . . . . . . . . . . . . . 303
Wire Harness – Electric Models . . . . . . . . . . . . . . . 305
Wire Harness – RT Models . . . . . . . . . . . . . . . . 307
Section 17 - Decals, ANSI Models . . . . . . . . . . . . 309
Decals, ES Models, ANSI Specification - Part 1 . . . . . . . . . . . 309
Decals, ES Models, ANSI Specification - Part 2 . . . . . . . . . . . .311
Decals, ES Models, ANSI Specification - Part 3 . . . . . . . . . . . 313
Decals, ES Models, ANSI Specification - Part 4 . . . . . . . . . . . 314
Decals, RT Models, ANSI Specification - Part 1 . . . . . . . . . . . 315
Decals, RT Models, ANSI Specification - Part 2 . . . . . . . . . . . 317
Decals, RT Models, ANSI Specification - Part 3 . . . . . . . . . . . 319
Decals, RT Models, ANSI Specification - Part 4 . . . . . . . . . . . 320
Section 18 - Decals, CE Models . . . . . . . . . . . . . 321
Decals, ES Models, CE Specification - Part 1. . . . . . . . . . . . 321
Decals, ES Models, CE Specification - Part 2. . . . . . . . . . . . 323
Decals, ES Models, CE Specification - Part 3. . . . . . . . . . . . 325
Decals, ES Models, CE Specification - Part 4. . . . . . . . . . . . 326
Decals, RT Models, CE Specification - Part 1. . . . . . . . . . . . 327
Decals, RT Models, CE Specification - Part 2. . . . . . . . . . . . 329
Decals, RT Models, CE Specification - Part 3. . . . . . . . . . . . 331
Decals, RT Models, CE Specification - Part 4. . . . . . . . . . . . 332

Page 1 Speed Level Series - Service & Parts Manual
January 2019
Service Introduction
This Service section is designed to provide you, the customer, with the instructions needed to
properly maintain the MEC self-propelled aerial work platform. When used in conjunction with the
illustrated Parts section in this manual and the Operator’s Manual (provided separately), this manual
will assist you in making necessary adjustments and repairs, and identifying and ordering the correct
replacement parts.
All parts represented here are manufactured and supplied in accordance with MEC quality
standards. We recommend that you use genuine MEC parts to ensure proper operation and reliable
performance.
To obtain maximum benefits from your MEC Aerial Work Platforms, always follow the proper
operating and maintenance procedures. Only trained authorized personnel should be allowed to
operate or service this machine. Service personnel should read and study the Operator’s, and the
Service and Parts Manuals in order to gain a thorough understanding of the unit prior to making any
repairs.
Chapter 1 - Service

Page 2 Speed Level Series - Service & Parts Manual
January 2019
MEC Operator Policy
Note:The best method to protect yourself and others from injury or death is to use common sense. If
you are unsure of any operation, don’t start until you are satisfied that it is safe to proceed and
have discussed the situation with your supervisor.
Service personnel and machine operators must understand and comply with all warnings and
instructional decals on the body of the machine, at the ground controls, and platform control console.
MODIFICATIONS OF THIS MACHINE FROM THE ORIGINAL DESIGN AND
SPECIFICATIONS WITHOUT WRITTEN PERMISSION FROM MEC ARE
STRICTLY FORBIDDEN. A MODIFICATION MAY COMPROMISE THE
SAFETY OF THE MACHINE, SUBJECTING OPERATOR(S) TO SERIOUS
INJURY OR DEATH.
MEC’s policies and procedures demonstrate our commitment to Quality and our relentless ongoing
efforts towards Continuous Improvement, due to which product specifications are subject to change
without notice.
Any procedures not found within this manual must be evaluated by the individual to assure oneself
that they are “proper and safe.”
Your MEC Aerial Work Platform has been designed, built, and tested to provide many years of safe,
dependable service. Only trained, authorized personnel should be allowed to operate or service the
machine.
MEC, as manufacturer, has no direct control over machine application and operation. Proper safety
practices are the responsibility of the user and all operating personnel.
If there is a question on application and/or operation, contact MEC Aerial Work Platforms:
1401 S. Madera Avenue, Kerman, CA93630 USA
Toll Free: 1 - 877 - 632 - 5438
Phone: 1 - 559 - 842 - 1500
Fax: 1 - 559 - 842 - 1520
[email protected]
www.MECawp.com
MEC Aerial Work Platforms
MEC Operator Policy
Section 1 - MEC Operator Policy

Page 3 Speed Level Series - Service & Parts Manual
January 2019
Safety Symbols & General Safety Tips
MEC manuals and decals use symbols, colors and signal words to help you recognize important
safety, operation and maintenance information.
RED and the word DANGER – Indicates an imminently hazardous
situation which, if not avoided, will result in death or serious injury.
ORANGE and the word WARNING – Indicates a potentially hazardous
situation which, if not avoided, could result in death or serious injury.
YELLOW with alert symbol and the word CAUTION – Indicates a
potentially hazardous situation which, if not avoided, may result in minor
or moderate injury.
YELLOW without alert symbol and the word CAUTION – Indicates a
potentially hazardous situation which, if not avoided, may result in
property damage.
GREEN and the word NOTICE – Indicates operation or maintenance
information.
Regular inspection and constant maintenance is the key to efficient economical operation of your
aerial work platform. It will help to assure that your equipment will perform satisfactorily with a
minimum of service and repair.
The actual operating environment of the machine governs the inspection schedule. Correct lubrication
is an essential part of the preventative maintenance to minimize wear on working parts and ensure
against premature failure. By maintaining correct lubrication, the possibility of mechanical failure and
resulting downtime is reduced to a minimum.
Never leave hydraulic components or hoses open. They must be protected from contamination
(including rain) at all times.
Never open a hydraulic system when there are contaminants in the air.
Always clean the surrounding area before opening hydraulic systems.
Use only recommended lubricants. Improper lubricants or incompatible lubricants may be as
harmful as no lubrication.
Watch for makeshift “fixes” which can jeopardize safety as well as lead to more costly repair.
•
•
•
•
•
Safety Symbols & General Safety Tips
Section 2 - Safety Symbols & General Safety Tips

Page 4 Speed Level Series - Service & Parts Manual
January 2019
RT Models Specifications
2684RT 3084RT
Working Height* 32 ft* 10.0 m* 36 ft* 11.0 m*
Platform Height 26 ft 7.9 m 30 ft 9.0 m
Stowed Height Rails Up 107 in 2.72 m 105 in 2.67 m
Rails Folded Down 72 in 1.83 m 70 in 1.78 m
Maximum Occupants 0 m/s wind 5 5
45 km/h (12.5 m/s) wind 5 5
On Slide-Out Extension 2 N/A
Lift Capacity 1700 lbs 770 kg 1500 lbs 680 kg
Slide-Out Deck Capacity 700 lbs 320 kg N/A
Platform Dimensions Length (Inside Rails) 12 ft 2 in 3.71 m 14 ft 4.27 m
Length (Platform Extended) 16 ft 2 in 4.93 m N/A
Platform Width (Inside Rails) 72 in 1.83 m 72 in 1.83 m
Guardrail Height 43.5 in 1.1 m 43.5 in 1.1 m
Toeboard Height 6 in 15 cm 6 in 15 cm
Overall Length 13 ft 2 in 4.0 m 14 ft 6 in 4.4 m
Overall Width 84 in 2.13 m
Wheel Base 100 in 2.54 m
Wheel Track 72 in 1.83 m
Turning Radius Inside 8 ft 2.44 m
Outside 16 ft 8 in 5.08 m
Ground Clearance 10 in 25 cm
Machine Weight** (Unloaded) (Approximate) 7800 lb** 3535 kg** 8100 lb** 3674 kg**
Drive System (Proportional)
Drive Speed - Platform Elevated 0-.4 mph 0-.6 km/h
Drive Speed - Platform Lowered 0-3.2 mph 0-5 km/h
Lift/Lower Speeds (Approximate) 35 sec/40 sec
Gradeability 40% 22°
Ground Pressure/Wheel (Maximum) 90 psi 6.3 kg/cm294 psi 6.6 kg/cm2
Wheel Load 2855 lb 1295 kg 2965 lb 1345 kg
Wind Speed (Maximum) 28 mph 45 km/h (12.5 m/s)
Tire Size - Standard 26 x 12D / 380NHS
Tire Pressure 45 psi 3.1 bar
Foam-filled tires are standard in Europe and Australia, optional in NorthAmerica
Wheel Lug Nut Torque 75-85 ft/lb 102-115 Nm
Hydraulic Pressure Main System 2800 psi 193 bar
Lift System 2800 psi 193 bar
Steering System 2000 psi 138 bar
Hydraulic Fluid Capacity 23 gallon 87 liters
Engine Diesel -- Kubota D1105E, 25HP (18.6 kW), Liquid Cooled Dual Fuel (North America only)
-- Kubota DF752, 20HP (14.9 kW), Liquid Cooled
Noise Level 86 dB maximum
Maximum Vibration Does not exceed 2.5 m/sec at operator’s position
Ambient Operating Range -30° C minimum; 50° C maximum
Operating Inclination Manual and self-leveling, side/side to 14°, fore/aft to 10°
Brakes Dual Rear Wheel Multi-disc
*Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options or country standards.
RT Models Specifications
Section 3 - Specifications

Page 5 Speed Level Series - Service & Parts Manual
January 2019Section 3 - Specifications ES Models Specifications
2684ES 3084ES
Working Height* 32 ft* 10.0 m* 36 ft* 11.0 m*
Platform Height 26 ft 7.9 m 30 ft 9.0 m
Stowed Height Rails Up 107 in 2.72 m 105 in 2.67 m
Rails Folded Down 72 in 1.83 m 70 in 1.78 m
Maximum Occupants 0 m/s wind 5 5
45 km/h (12.5 m/s) wind 5 5
On Slide-Out Extension 2 N/A
Lift Capacity 1700 lbs 770 kg 1500 lbs 680 kg
Slide-Out Deck Capacity 700 lbs 320 kg N/A
Platform Dimensions Length (Inside Rails) 12 ft 2 in 3.71 m 14 ft 4.27 m
Length (Platform Extended) 16 ft 2 in 4.93 m N/A
Platform Width (Inside Rails) 72 in 1.83 m 72 in 1.83 m
Guardrail Height 43.5 in 1.1 m 43.5 in 1.1 m
Toeboard Height 6 in 15 cm 6 in 15 cm
Overall Length 13 ft 2 in 4.0 m 14 ft 6 in 4.4 m
Overall Width 84 in 2.13 m
Wheel Base 100 in 2.54 m
Wheel Track 72 in 1.83 m
Turning Radius Inside 8 ft 2.44 m
Outside 16 ft 8 in 5.08 m
Ground Clearance 10 in 25 cm
Machine Weight** (Unloaded) (Approximate) 8400 lb** 3810 kg** 8700 lb** 3946 kg**
Drive System (Proportional)
Drive Speed - Platform Elevated 0-.4 mph 0-.6 km/h
Drive Speed - Platform Lowered 0-3.2 mph 0-5 km/h
Lift/Lower Speeds (Approximate) 35 sec/40 sec
Gradeability 40% 22°
Ground Pressure/Wheel (Maximum) 98 psi 6.9 kg/cm2101 psi 7.1 kg/cm2
Wheel Load 3065 lb 1390 kg 3175 lb 1440 kg
Wind Speed (Maximum) 28 mph 45 km/h (12.5 m/s)
Tire Size - Standard 26 x 12D / 380NHS
Tire Pressure 45 psi 3.1 bar
Foam-filled tires are standard in Europe and Australia, optional in NorthAmerica
Wheel Lug Nut Torque 75-85 ft/lb 102-115 Nm
Hydraulic Pressure Main System 2800 psi 193 bar
Lift System 2800 psi 193 bar
Steering System 2000 psi 138 bar
Hydraulic Fluid Capacity 23 gallon 87 liters
Electric Motor 8 hp (6kW): 3600 rpm
Power Source -- Voltage 48 volts DC
Batteries Eight 6-volt DC 370 amp-hour industrial deep cycle batteries
Battery Charger Input 120 Volt AC, 50.60 Hz, 18Amp - 240 Volt AC, 50.60 Hz, 9 Amp
Output 48 Volt DC, 32 Amp, 1500 W, Timed Shutoff
Maximum Vibration Does not exceed 2.5 m/sec at operator’s position
Ambient Operating Range -30° C minimum; 50° C maximum
Operating Inclination Manual and self-leveling, side/side to 14°, fore/aft to 10°
Brakes Dual Rear Wheel Multi-disc
*Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options or country standards.

Page 6 Speed Level Series - Service & Parts Manual
January 2019
Key Safety Tips
NEVER PERFORM SERVICE ON THE MACHINE WITH THE PLATFORM
ELEVATED WITHOUT FIRST SUPPORTING THE PLATFORM/BOOM
ASSEMBLY.
Use a crane with chains and straps of
adequate lifting capacity to support the
platform.
Never leave hydraulic components or
hoses open. They must be protected from
contamination (including rain) at all times.
Never open a hydraulic system when there
are contaminants in the air.
Always clean the surrounding area before
opening hydraulic systems.
Use only recommended lubricants. Improper
lubricants or incompatible lubricants may be
as harmful as no lubrication.
Watch for makeshift “fixes” which can
jeopardize safety as well as lead to more
costly repair.
•
•
•
•
•
•
Art_3098
Key Safety Tips
Section 4 - General Information

Page 7 Speed Level Series - Service & Parts Manual
January 2019Section 4 - General Information Hydraulic System
HYDRAULIC FLUID UNDER PRESSURE CAN PENETRATE AND BURN
SKIN, DAMAGE EYES, AND MAY CAUSE SERIOUS INJURY, BLINDNESS,
AND EVEN DEATH.
CORRECT LEAKS IMMEDIATELY.
Hydraulic fluid leaks under pressure may not always be visible. Check for
pin hole leaks with a piece of cardboard, not your hand.
Electrical System
Prevent damage to battery and/or electrical system;
Always disconnect the negative battery cable first.
Always connect the positive battery cable first.
•
•
When the negative cable is installed, a spark will occur if contact is made between the positive side
of the battery and a metal surface on the machine. This can cause damage to the electrical system,
battery explosion, and personal injury.
Total System
Engine coolant level must be checked only after engine has cooled.
If radiator cap is removed while the coolant is at normal operating
temperature, pressure within the coolant system will force hot liquid out
through the filler opening and may cause severe scalding.
Failure to perform preventive maintenance at recommended intervals
may result in the unit being operated with a defect that could result in
injury or death of the operator.
Immediately report to your supervisor any defect or malfunction.
Any defect shall be repaired prior to continued use of the aerial work
platform.
Inspection and maintenance should be performed by qualified personnel
familiar with the equipment.

Page 8 Speed Level Series - Service & Parts Manual
January 2019Section 4 - General Information
Primary Machine Components
ART_3090
Lanyard Points
(Option)
91859
91843
Document Box
Ladder
Boom Support Wheel
Lift Cylinder
Upper Controls
Pivot Gear
Tilt Cylinder
Front to Rear
Upper Boom
Control Module
Lower Controls
Propane Tank
Dual Fuel Models
Platform and Rails
Lower Boom
Power Module
Tilt Cylinder
Side to Side
Steering Components
Front Drive Motors
Axle Float Cylinders
Rear Drive Motors
Entry Gate
Loading Gate

Page 9 Speed Level Series - Service & Parts Manual
January 2019Section 4 - General Information
ART_3089
Control Module
Power Module
Battery
Disconnect Switch
Alarm
Terminal Block
Module
GP400 Module
12 Volt DC Battery
Emergency
Lowering Switch
Lower Controls
Hydraulic
Reservoir
Overflow
Reservoir
Radiator
Fuel
Reservoir
Hydraulic Fluid
Filter Engine Air Intake
Engine Air Filter
Hydraulic Fluid
Sight Gauge
Hydraulic Fluid
Pump
Engine
Relays
Main
Hydraulic
Manifold
Leveling
Hydraulic
Manifold
Power to Platform
AC Connector

Page 10 Speed Level Series - Service & Parts Manual
January 2019Section 4 - General Information
Bolt Torque Specification - American Standard
Fasteners
Use the following values to apply torque unless a specific torque value is called out for the part being
used
American Standard Cap Screws
SAE Grade 5 8
Cap Screw
Size (inches) Torque Torque
Ft. Lbs Nm Ft. Lbs Nm
Min Max Min Max Min Max Min Max
1/4 - 20 6.25 7.25 8.5 10 8.25 9.5 11 13
1/4 - 28 8 9 11 12 10.5 12 14 16
5/16 - 18 14 15 19 20 18.5 20 25 27
5/16 - 24 17.5 19 12 26 23 25 31 34
3/8 - 16 26 28 35 38 35 37 47.5 50
3/8 - 24 31 34 42 46 41 45 55.5 61
7/16- 14 41 45 55.5 61 55 60 74.5 81
7/16 - 20 51 55 69 74.5 68 75 92 102
1/2 - 13 65 72 88 97.5 86 96 116 130
1/2 - 20 76 84 103 114 102 112 138 152
9/16 - 12 95 105 129 142 127 140 172 190
9/16 - 18 111 123 150 167 148 164 200 222
5/8 - 11 126 139 171 188 168 185 228 251
5/8 - 18 152 168 206 228 203 224 275 304
3/4 - 10 238 262 322 255 318 350 431 474
3/4 - 16 274 302 371 409 365 402 495 544
7/8 - 9 350 386 474 523 466 515 631 698
7/8 - 14 407 448 551 607 543 597 736 809
1- 8 537 592 728 802 716 790 970 1070
1 - 14 670 740 908 1003 894 987 1211 1137
Torque values apply to fasteners as received from the supplier, dry or when lubricated with
normal engine oil.
If special graphite grease, molydisulphide grease, or other extreme pressure lubricants are
used, these torque values do not apply.

Page 11 Speed Level Series - Service & Parts Manual
January 2019Section 4 - General Information
Bolt Torque Specification - Metric Standard
Fasteners
Use the following values to apply torque unless a specific torque value is called out for the part being
used
Metric Cap Screws
Metric Grade 8.8 10.9
Cap Screw Size
(Millimeters)
8.8
9.01
Torque Torque
Ft. Lbs Nm Ft. Lbs Nm
Min Max Min Max Min Max Min Max
M6 × 1.00 6 8 8 11 9 11 12 15
M8 × 1.25 16 20 21.5 27 23 27 31 36.5
M10 × 1.50 29 35 39 47 42 52 57 70
M12 × 1.75 52 62 70 84 75 91 102 123
M14 × 2.00 85 103 115 139 120 146 163 198
M16 × 2.50 130 158 176 214 176 216 238 293
M18 × 2.50 172 210 233 284 240 294 325 398
M20 × 2.50 247 301 335 408 343 426 465 577
M22 × 2.50 332 404 450 547 472 576 639 780
M24 × 3.00 423 517 573 700 599 732 812 992
M27 × 3.00 637 779 863 1055 898 1098 1217 1488
M30 × 3.00 872 1066 1181 1444 1224 1496 1658 2027
Torque values apply to fasteners as received from the supplier, dry or when lubricated with
normal engine oil.
If special graphite grease, molydisulphide grease, or other extreme pressure lubricants are
used, these torque values do not apply.

Page 12 Speed Level Series - Service & Parts Manual
January 2019Section 4 - General Information
Hydraulic Components Torque Table
Note:Always lubricate threads with clean hydraulic fluid prior to installation.
Use the following values to torque hydraulic components when a specific value is not available.
Always check for torque values in the following places before relying on the Hydraulic Components
Torque Table.
Parts drawings and service instructions in this manual.
Packaging and instruction sheets provided with new parts.
Instruction manuals provided by the manufacturer of the component being serviced.
Type: SAE Port Series Cartridge Poppet Fittings Hoses
Ft. lbs Nm Ft. lbs Nm Ft. lbs Nm
#4 N/A N/A N/A N/A 135 - 145 15 - 16
#6 N/A N/A 10 - 20 14 - 27 215 - 245 24 - 28
#8 25 - 30 31 - 41 25 - 30 34 - 41 430 - 470 49 - 53
#10 35 - 40 47 - 54 35 - 40 47 - 54 680 - 750 77 - 85
#12 85 - 90 115 - 122 85 - 90 115 - 122 950 - 1050 107 - 119
#16 130 - 140 176 - 190 130 - 140 176 - 190 1300 - 1368 147 - 155
•
•
•

Page 13 Speed Level Series - Service & Parts Manual
January 2019Section 4 - General Information
Emergency Systems And Procedures
IF THE CONTROL SYSTEM FAILS WHILE THE PLATFORM IS ELEVATED,
HAVE AN EXPERIENCED OPERATOR USE THE EMERGENCY LOWERING
PROCEDURE TO SAFELY LOWER THE PLATFORM.
DO NOT ATTEMPT TO CLIMB DOWN ELEVATING ASSEMBLY.
Emergency Stop
The machine is equipped with an EMERGENCY STOP switch on both control panels.
Press the EMERGENCY STOP switch at any time to stop all machine functions.
Turn switch clockwise to reset.
Selector Switch Set To Platform
Either switch will stop all machine functions.
Both switches must be reset or machine will not operate.
Selector Switch Is Set To Base
The upper controls are locked out.
The lower controls switch must be reset or the machine will not operate.
The machine will operate from the lower controls if the upper controls switch is tripped.
Emergency Lowering
The Emergency Lowering System is used to lower the platform in case of power failure.
The Emergency Lowering switch *will* continue to function if the EMERGENCY STOP switch is
tripped.
To lower the platform, perform the following steps:
Push and hold the toggle switch down to lower the platform.
Once the platform is fully lowered, release the toggle switch.
ART_3107
91843
Emergency Stop Switch
Upper Controls
Lower Controls
Emergency Lowering Switch
•
•
1.
2.
•
•
•
•
•
•
