MecArmy SGN5 User manual

MECARMY
SGN5 User Manual
USB Rechargeable Personal Attack Alarm Flashlight
Primary Features
•Patented product
•CREE XP-G2 S3 LED, Max 560 lumens
•Very loud (up to 115dB) siren
•Instant access to Alarm, Strobe or Turbo
•Independent side Alarm switch design for quick access
•Uses rechargeable 300mAh lithium polymer battery
•Standard Micro USB charging port, charges in just 1 hour on any USB port
•Charging and fully charged indicators
•Multiple colors available
•Designed for everyday carry- lanyard supplied
Specification
LED: CREE XP-G2 S3 LED
Output & Runtime:
Mode/ Specification Turbo Low Med High Strobe
Output (Lumens) 560 3 28 118 /
Runtime 44mins 42h 350mins 65mins /
Peak beam intensity 1610cd
Max beam distance 80m
Impact resistance 1.5m
Waterproof IPX4
•Material: Polycarbonate
•Dimensions：L66.7mm/2.63in×W26mm/1.02in×H13mm/0.51in
•Weight：25g/0.882oz
•Working voltage: 3.0V-5.0V
•Battery：Rechargeable 300mAh lithium polymer battery
•Charging time: 1 hours (charging current 5V/0.5A)
•Accessories: User manual, USB cable, Lanyard
NOTICE: The above-mentioned parameters are approximate and may vary between flashlights and
environments.
Operation
Light Switch (front button):
•From OFF: 1 click for ON (Low mode)
•From OFF: 2 click for Turbo
•From OFF: 3 click for STROBE
•From STROBE: Long press (> 1 second) for SOS
•From OFF: Press and hold for Momentary ON (Turbo), release to turn off

•From ON: 1 click for OFF
•From ON: Press and hold to cycle through modes (Low/Med/High/Turbo)
Alarm Switch (side button):
• From any mode: Push the button up to activate Alarm (simultaneously Strobe)
• From ON: Pull the button down to turn OFF
Notice:
When the battery voltage is lower than 3.1V, the light will stop working; the Alarm function will continue to
work for 2 minutes.
Turbo mode: the SGN5 is a high-performance light and generates significant heat in Turbo mode. To protect
the light and user, output in Turbo will step down from maximum brightness after 3 seconds.
Charging
Carefully remove the cap from the USB charge port, and connect a mini USB charging cable, as shown in
the diagram below:
The flashlight will not operate during charging.
Charging Indicator
When charging, the light will flash red and green, when charging is complete, the light turns green
No light indicates that there is no load
Low battery indicator
When voltage falls to 3.3V, the light will flash red, and continue to flash during operation. Please recharge
the battery
WARNING:
•Do not point the light at human or animal eyes
•Do not look directly into light
•Do not permit children to use the flashlight unsupervised
Warranty Service
•Guaranteed exchange up to 15 days after purchase: any defective product can be exchanged for a
replacement through a local distributor/dealer within 15 days
•After 15 days: all defective products can be repaired free of charge for a period of 2 years from the date

of purchase
•Lifetime workmanship guarantee: after the free maintenance period has expired, the maintenance
service will charge for material expenses only, free of labor expenses.
ALTUNLIMITED
TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
Web: www.MecArmy.com
Address: Yikang Mansion, Huarong Road, Dalang Street, Longhua District, Shenzhen, China
