The CAPTEST Digital Torque Tester
CAPTEST is used to measure and record the torque required
for the opening and closing of screw-caps. CAPTEST stores
up to 240 readings. The stored data can be sent to the display
or to a data printer (e.g. EPSON P40) connected to the serial
RS232 port. Statistical evaluation is accomplished by means
of a Mitutoyo statistics processor (e.g. Mitutoyo DP-1 VR),
which interfaces directly with CAPTEST.
The splash-proof, stainless steel housing and the robust
construction of the clamping fixture guarantee continuous
and reliable operation in laboratory and tough production
environments.
The built-in rechargeable battery, in combination with the
latest power-saving technology, enables extended operation,
independent of a mains supply. In continuous operation, a
minimum 72 hours operating time can be achieved.
Automatic shut-off occurs if the device is not used for a
period of about 2 minutes, enabling the device to operate for
days without charging. When the battery charge is low, the
display will show ‘BAT’. The battery is prevented from being
low-level discharged by a security function that switches the
device off automatically.
When performing a measurement, the peak value of the
applied torque is displayed.

2 Mecmesin CAPTEST Operator Manual

CAPTEST Operator Manual Mecmesin 3
General Operating Instructions
Before using
On delivery, please check your CAPTEST for damage and
completeness. Should there be any defects, inform your
CAPTEST distributor immediately.
Screw the vertical grips into the clamping fixture, ensuring
a centred and symmetrical arrangement.
Charge the internal battery with the mains adapter
provided: connect the charger to the CAPTEST before
plugging it in.
The device can be operated with the mains adapter connected.
Battery management
CAPTEST is equipped with a modern power-saving
technique to achieve a relatively long operating time. If you
don’t use the device for a period of 2 minutes, it will switch
off automatically. To take new measurements, press the ON
key; CAPTEST is immediately ready to use. The readings
remain stored if the device is switched off manually or
automatically. When the maximum operating time is
reached, the symbol ‘BAT’is displayed. Please charge your
CAPTEST as soon as possible as described above. If you
continue using the device without loading, it will switch off
automatically shortly afterwards in order to prevent the
battery from low-level discharge.
Interfaces
The interface plug is placed at the rear of the device. An
RS232C or a DIGIMATIC cable can be connected. Be sure

4 Mecmesin CAPTEST Operator Manual
that both the device to be connected and your CAPTEST are
switched off before connecting.
RS-232 protocol: 9600 baud, 8 bit, 1 stop-bit, no parity, no handshake
Overload
CAPTEST is overload-protected by a mechanical end stop.
This protection prevents the internal sensor from being
damaged. The scale range, however, does not extend to this
load range. If the scale range is exceeded, ‘oL’(overload) is
displayed.
Maintenance, cleaning, repair
CAPTEST is largely maintenance-free. The spindle drive of
the clamping fixture has to be greased occasionally. Please
clean the parts with a soft, moistened cloth and don’t use any
strong cleansing agents or solvents. Repairs will only be
done by the manufacturer. If a repair is required, please
return your CAPTEST to your distributor and describe any
damage or faults you have identified.
Calibration
CAPTEST is calibrated carefully, so the precision of the
measurement will be guaranteed for one year. After that time
it is recommended to have the device checked annually by
the manufacturer.
You can also have the device recalibrated and certified. If
you do your own calibration, it is done in the following way:
switch the device off
press and hold the ZERO key
press the ON key while holding the ZERO key

CAPTEST Operator Manual Mecmesin 5
The device is now in the ‘continuous’mode and the actual
applied torque is displayed in the scientific unit N.m,
together with the tilde ‘~’. Now you can apply a well-known
torque and check the reading.
Safety issues
CAPTEST works with low-level voltages. In normal use
there is no risk of electric shock. The splashproof housing
normally prevents fluids from penetrating, but it should not
be exposed to jets of water or immersed, or the electronics
may be damaged. If you suspect any penetration of fluid,
send the device to your CAPTEST distributor.
Important
Be careful if the device is connected to the mains supply. The mains
adapter/charger is not splashproof. In case of a penetration of fluid
into the adapter there is a danger of electric shock with risk to your
personal safety.
Waste disposal
CAPTEST works with NiMh-battery. This battery must not
be put into normal waste, but should be taken to battery
recycling.

6 Mecmesin CAPTEST Operator Manual
Using your CAPTEST
Instructions can also be found on the underside of the instrument.
Switch on
Test: opening a closure
Test: closing a closure
Clear the current reading
Store the current reading
The reading is added to any data already stored.
Device is ready for testing
Peak value of applied
anticlockwise torque
Peak value of applied
clockwise torque
Device is ready for further
measurement
Pressing ON stores the
reading and clears the
display

CAPTEST Operator Manual Mecmesin 7
Print the current reading
When printing the reading, the data is also stored. If no printer is
connected, the reading is still added to any data already stored.
Print the stored data
All stored data is sent to the printer. Press the ON button to pause, or
the ZERO key to stop printing.
Clear the memory
Switch off
If the tester is not operated for a period of 2 minutes, the tester
automatically switches off.
Return to test mode
Press ON to cancel switching off.
Memory cleared
Blank display,
device is off
Operation is resumed

8 Mecmesin CAPTEST Operator Manual
Using a Mitutoyo Mini-Processor
The example used here is the Mitutoyo DP-1 VR, but other
Mitutoyo mini-processors may be used.
The DP-1 VR mini-processor is an easy-to-use instrument for
data analysis and statistical evaluation of CAPTEST data.
The integral printer documents both the CAPTEST data and
the results of analysis.
Before using the equipment, please read the DP-1 VR
operating instructions. Some aspects of operation with
CAPTEST will differ.
The DP-1 VR [DATA] key is disabled. CAPTEST sends the
data to the DP-1 VR: ON > ZERO.
Time-controlled data acquisition by DP-1 VR is not
possible.
Connection and use
Ensure that both the CAPTEST and DP-1 VR are switched off.
Connect the CAPTEST to the DP-1 VR with the enclosed
special Mitutoyo printer cable.
First switch on the DP-1 VR [Power] and then the
CAPTEST (ON key).
To clear any stored DP-1 VR data, press the [CL] key.
After you have taken a measurement, you can send
CAPTEST data to DP-1 VR by pressing the ON key; data
will be stored simultaneously in the CAPTEST and the
DP-1 VR, so it is not necessary to transmit complete
CAPTEST data to DP-1 VR at the end of a batch for the
purpose of later analysis.

CAPTEST Operator Manual Mecmesin 9
Note: If you do not want to print CAPTEST data each time it
is sent, but only to have statistical analysis data at the end of
a test batch, disable printing using the [Printer] key.
CAPTEST data will still be stored.
Switching off
Always switch the CAPTEST off first, and then the DP-1 VR.
This is important, because CAPTEST is equipped with an
automatic interface detection.
Detach the interface connection only if both the CAPTEST
and DP-1VR are switched off.
Setting tolerance limits
Clear stored data: press the DP-1 VR [CL] key and clear
the CAPTEST memory: ON > ON > ZERO.
Press [TOL. LIMIT] on the DP-1 VR to begin setting values.
Apply torque to the CAPTEST; to the upper or lower limit
required (sequence does not matter). Transmit the value to
the DP-1 VR: ON > ZERO.
Repeat the last step to the second limit torque.
Press the [TOL. LIMIT] key of the DP-1 VR. This will
complete the setting and print the tolerance limits:
LSL=lower limit; USL=upper limit, TOL=tolerance range.
For each measurement transmitted to the DP-1 VR, red
and green indicator lights will show if the result is below
the lower limit, above the upper limit, or within limits.
When you have completed a batch of measurements, make
sure the printer is on and press the DP-1 VR [STAT] key to
print the data values and histogram.

10 Mecmesin CAPTEST Operator Manual
Technical Data
Range 5 N.m (44.2 lbf.in) clockwise and anticlockwise
Min peak 0.2 N.m (1.8 lbf.in)
Accuracy better than 1%, at 20(±5)°C
Sampling rate 250 Hz in continuous mode
8 or 60 Hz in peak mode
Data storage 240 readings, non-volatile memory
Clamping fixture adjustable 15 mm to 130 mm, 3-bearing spindle
Interface RS232C, Mitutoyo DIGIMATIC
Batteries built-in NiMh battery, 4.8 V, 600 mAh
Mains adapter Input 230 VAC, 50 Hz, 1.5 VA
Output 8.2 VDC, 150 mA. Isolation: T40 E; IP20
DC-Input 5 mA (charge: max. 60 mA)
Charging time 8 h will provide 75% charge, delivering up to
72 hrs continuous operation
Housing IP54-rated, stainless steel
Protection category III (SELV) IEC 536/DIN VDE 0106
Environment designed for indoor use
max. altitude 2000 m
temperature 5 to 40°C
max. rel. humidity: 80% up to 31°C, by linear
decrease to 50% at 40°C
Dimensions width 180 mm, height 150 mm, depth 170 mm
Weight 2.3 kg

CAPTEST Operator Manual Mecmesin 11
Configuring CAPTEST Settings
Settings for the CAPTEST are available from the
configuration menu, and are not intended for the regular
user to access. Please note the following:
The settings you make are not visible from the display
(e.g. there is no indication of units)
There is no confirmation of the settings you choose: be
methodical.
There is no ‘exit’from the configuration settings other than
by pressing ENTER and accepting a setting.
Settings are selected and made only one at a time.
Settings are retained when the unit is switched off.
The settings menu
Settings are found and saved one at a time. To enter the
settings, hold ZERO while pressing ON.
Press the ON key until the display shows SEt.
Press ENTER: the display will show U1 (the first settings
item)
oto set U1 (use lbf.in as the units of measurement), press
ENTER
oor to find another setting in the list, press ON until it
displays, and then press ENTER to set it.
Pressing ON returns you from the settings menu back to
continuous mode measurement.

12 Mecmesin CAPTEST Operator Manual
Settings
Units of measurement
U1
lbf.in
U2
N.m
Data transmission frequency (continuous mode)
(data acquisition frequency in peak value mode remains unaffected. at 250 Hz)
F1
8 Hz
F2
60 Hz
Delay period for peak value recognition
t1
~ 2 sec
t2
< 1 sec
Measurement threshold for peak value recognition
L1
0.14 N.m
(1.2 lbf.in)
L2
0.07 N.m
(0.6 lbf.in)
Auto-off function
Au0
off
Au1
on
Minus sign in the data output
S–
shows
S
hidden

CAPTEST Operator Manual Mecmesin 13
CE Declaration of Conformity
CE Declaration of Conformity
The manufacturer
KREIENSEN MESSTECHNIK
Erwinstr.79
D-79102 Freiburg
Germany
declares the conformity of the product
torque test equipment
C A P T E S T
to the following standards:
EN 61000-6-1-2-3-4:2007
in accordance to the directive 2006/95/EC (electromagnetic compatibility)
EN 61010-6-1
Safety requirements for electrical equipment for measurement
in accordance to the directive 73/23/EEC (low voltage directive)
Freiburg, 17.10.2007
.......................................................................................................

Mecmesin : a world leader in affordable force and torque testing solutions
Since 1977, Mecmesin has assisted thousands of companies achieve enhanced quality control in design
and production. The Mecmesin brand represents excellence in accuracy, build, service, and value.
In production centres and research labs worldwide, designers, engineers, operators, and quality
managers endorse Mecmesin force and torque testing systems for their high performance
across countless applications.
www.mecmesin.com
Algeria
Argentina
Australia
Austria
Bangladesh
Belgium
Brazil
Bulgaria
Cambodia
Canada
Chile
China
Colombia
Costa Rica
Croatia
Czech Republic
Denmark
Ecuador
Egypt
Estonia
Finland
France
Germany
Greece
Hungary
India
Indonesia
Iran
Ireland
Israel
Italy
Japan
Korea
Laos
Latvia
Lebanon
Lithuania
Malaysia
Mexico
Morocco
Myanmar
Netherlands
New Zealand
Norway
Peru
Philippines
Poland
Portugal
Romania
Russia
Saudi Arabia
Serbia
Singapore
Slovakia
Slovenia
South Africa
Spain
Sri Lanka
Sweden
Switzerland
Taiwan
Thailand
Tunisia
Turkey
UK
USA
Vietnam
The Mecmesin global distribution network guarantees your testing solution is rapidly delivered and
efficiently serviced, wherever you are.
Head Office
Mecmesin Limited
w: www.mecmesin.com
e: [email protected]
France
Mecmesin France
w : www.mecmesin.fr
e: [email protected]
Germany
Mecmesin GmbH
w: www.mecmesin.de
e: [email protected]
North America
Mecmesin Corporation
w: www.mecmesincorp.com
e: [email protected]
Asia
Mecmesin Asia Co. Ltd
w: www.mecmesinasia.com
e: [email protected]
China
Mecmesin (Shanghai) Pte Ltd
w: www.mecmesin.cn
e: [email protected]
