Medion Notebook Computer User manual

Notes on This Manual
Keep these instructions with your computer at all times. The proper set up, use
and care can help extend the life of your computer. In the event that you
transfer ownership of this computer, please provide these instructions to the
new owner.
This manual is divided into sections to help you find the information you
require. Along with the Table of Contents, an Index has been provided to help
you locate information.
In addition, many application programs include extensive help functions. As a
general rule, you can access help functions by pressing F1 on the keyboard.
These help functions are available to you when you use the Microsoft Windows®
operating system or the various application programs.
This interactive manual is designed to provide additional information about
your Notebook as well as useful links accessible via the World Wide Web.
We have listed further useful sources of information starting on page 60.
Document Your Notebook
It is important to document the details of your Notebook purchase in the event
you need warranty service. The serial number can be found on the back of the
Notebook:
Serial Number ......................................
Date of Purchase ......................................
Place of Purchase ......................................
Audience
These instructions are intended for both the novice and advanced user.
Regardless of the possible professional utilization, this Notebook is designed for
day-to-day household use. The functions and applications for use with this
Notebook have been designed with the entire family in mind.

ii
Quality
We have selected the components in this computer for their high level of
functionality, ease of use, safety and reliability.
Through balanced hardware and software design we are able to provide you
with an innovative personal computer useful for applications relating to both
work and leisure.
We are pleased to welcome you as our newest customer.
Copying this manual
This document contains legally protected information. All rights reserved.
Copying in mechanical, electronic and any other form without the written
approval of the manufacturer is prohibited.
Copyright©2008 MEDION®. / 16/11/2009
All rights reserved. Microsoft®, MS-DOS®, and Windows are registered trademarks of
Microsoft Corporation in the U.S. and other countries.
Pentium® is a registered trademark of Intel Corporation.
The names of actual companies and products mentioned herein may be the trademarks of
their respective owners.
Information in this document is subject to change without notice.

iii
