Medion P16021 User manual

30634 Aldi PT+ES+DE+EN Final Cover.FH11 Wed Oct 20 09:33:53 2010 Seite 3

Schwarz

C M Y CM MY CY CMY K

Ia/12/10

94 cm / 37" Design LCD-TV

with integrated HD DVB-T t ner

MEDION

LIFE

® P16021 (MD 30634)

Instruction manua

Medion Service Center

Visonic S.A.

c/ Miguel Faraday, 6

Parque Em resarial "La Car etania", N-IV Km. 13

E-28906 Getafe, Madrid

Es anha

Hotline: 808 202 789

Fax: (+34) 91 460 4772

service- or[email protected]

www.medion.com/ ortugal

Medion Service Center

Visonic S.A.

c/ Miguel Faraday, 6

Parque Em resarial "La Car etania", N-IV Km. 13

E-28906 Getafe, Madrid

Es aña

Hotline: 902196437

Fax: 914604772

service-s [email protected]

www.medion.es

English - 1 -

Contents

Features ................................................................. 2

Introduction............................................................. 2

Preparation............................................................. 2

Safety Precautions ................................................. 3

Connection to a Television Distribution System

(Cable TV etc.) from Tuner................................. 4

Licence Notiﬁcation (optional)............................. 4

TRADEMARK ACKNOWLEDGMENT................ 4

Package Contents.................................................. 4

Environmental Information ..................................... 5

Repair Information .......................................... 5

Remote Control Buttons......................................... 6

LCD TV and Operating Buttons.............................. 7

Viewing the Back side Connections ....................... 7

Viewing the Connections - Side Connectors.......... 8

Power Connection.................................................. 8

Aerial Connection ............................................... 8

Using Digital Multimedia Connectors...................... 9

USB Memory Connection................................... 9

Side HDMI Connection........................................... 9

Connecting the LCD TV to a PC............................. 9

Connecting to a DVD Player................................. 10

Using Side AV Connectors ................................... 10

Using Other Connectors....................................... 10

Remote Control Handset...................................... 10

Inserting Batteries............................................. 10

Switching On/Off....................................................11

To Switch the TV On..........................................11

To Switch the TV Off..........................................11

Digital Teletext (** for UK only) ..........................11

Analogue Teletext..............................................11

Input Selection.......................................................11

Operation with the Buttons on the TV................11

Volume Setting...............................................11

Programme Selection....................................11

Viewing Main Menu........................................11

AV Mode ........................................................11

Operation with the Remote Control...................11

Volume Setting.............................................. 12

Programme Selection (Previous or Next

Programme).................................................. 12

Programme Selection (Direct Access).......... 12

First Time Installation............................................ 13

Auto Tuning .......................................................... 14

Auto Channel Scan Menu Operation................14

Manual Tuning ..................................................... 14

Digital Manual Search.......................................14

Analogue Manual Search.................................14

Analog Fine Tune.............................................. 14

Clear Service List (*)......................................... 14

Managing Stations: Channel List.......................... 15

Operating the Channel List...............................15

Moving a Channel............................................. 15

Deleting a Channel........................................... 15

Renaming a Channel........................................15

Locking a Channel............................................15

Managing Stations: Favourites............................. 16

Button Functions............................................... 16

Managing Stations: Sorting Channel List ............. 16

On-Screen Information......................................... 16

Media Playback Using Media Browser................. 16

Viewing Videos via USB .................................. 17

Viewing Photos via USB...................................17

Slideshow Options............................................ 17

Playing Music via USB .....................................17

Media Browser Settings.................................... 18

Changing Image Size: Picture Formats................ 18

Conﬁguring Picture Settings................................. 19

Operating Picture Settings Menu Items............19

Picture Settings Menu Items............................. 19

PC Picture Settings...........................................20

Conﬁguring Sound Settings.................................. 20

Operating Sound Settings Menu Items............. 20

Sound Settings Menu Items..............................20

Conﬁguring Your TV’s Settings............................. 21

Operating Settings Menu Items........................ 21

Settings Menu Items.........................................21

Using a Conditional Access Module..................... 21

Viewing ConditionalAccess Menu (*)............... 21

Conﬁguring Language Preferences...................... 22

Language Settings............................................ 22

Parental Control.................................................... 22

Parental Settings Menu Operation (*)............... 23

Timers................................................................... 23

Setting Sleep Timer .......................................... 23

Setting Programme Timers............................... 23

Conﬁguring Date/Time Settings............................ 24

Conﬁguring Source Settings................................. 24

Conﬁguring Other Settings................................... 24

Operation.......................................................... 24

Other Features ..................................................... 25

Teletext................................................................. 26

Tips....................................................................... 26

Appendix A: PC Input Typical Display Modes....... 27

Appendix B: AV and HDMI Signal Compatibility

(Input Signal Types).............................................. 27

Appendix C: Supported DVI Resolutions..............28

Appendix D: Supported File Formats for USB

Mode..................................................................... 28

Appendix E: Software Upgrade............................ 29

Speciﬁcations ....................................................... 30

Digital Reception (DVB-T).................................... 30

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 1B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 1 27.10.2010 14:22:1227.10.2010 14:22:12

English - 2 -

Features

Remote controlled colour LCD TV.• Fully integrated Terrestrial digital TV (DVB-T -• MPEG2) (DVB-T- MPEG4).

HDMI connectors for digital video and audio. This• connectionisalsodesigned to accepthighdeﬁnition

signals.

USB input.• 1000 programmes (analogue+digital).• OSD menu system.• Integrated tuner DVB-T HD, MPEG 2 / MPEG 4• compatible.

Scart socket for external devices (such as video,• video games, audio set, etc.).

Stereo sound system. (SRS TruSurround HD)• Teletext, fastext, TOP text.• Headphone connection.• Automatic programming system.• Forward or backward manual tuning.• Sleep timer / Child lock.• Automatic sound mute when no transmission.• NTSC playback.• AVL (Automatic Volume Limiting).• Auto power down.• PLL (Frequency Search).• PC input.• Plug&Play for Windows 98, ME, 2000, XP, Vista,• Windows 7.

Game Mode•

Introduction

Please read the corresponding instructions of this

handbook prior to the ﬁrst usage of the device, even

when the usage of electronic devices is familiar

to you. Notice especially the chapter SAFETY

PRECAUTIONS. Carefully keep the handbook as

future reference. When selling the device or giving it

away, absolutely give these direction for use.

Thank you for choosing this product. This manual will

guide youfortheproperoperation of yourTV.

Before operating the TV, please read this

manual thoroughly. Please do keep this

manual in a safe place for future references.

This device is intended to receive and display TV

programs. The different connection options make

an additional expansion of the reception and display

sources possible (receiver, DVD player, DVD

recorder,

VCR, PC etc.). This device is only suitable for the

operation in dry interiors. This appliance is intended

solely for private domestic use and may not be used

for industrial and commercial purposes. We exclude

liability in principle, if the device is not used as

intended, or unauthorized modiﬁcations have been

made. To operate your LCD TV in extreme ambient

conditions may cause the damage of the device.

Preparation

For ventilation, leave a free space of at least 10 cm

all around the set. To prevent any fault and unsafe

situations, please do not place any objects on top of

the set. Use this device in moderate climates.

10 cm

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 2B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 2 27.10.2010 14:22:1227.10.2010 14:22:12

English - 3 -

Safety Precautions

Read the following recommended safety

precautions carefully for your safety.

Power Source

The TV set should be operated only from a 220-240

VAC, 50 Hz outlet. Ensure that you select the correct

voltage setting for your convenience.

Power Cord

Do not place the set, a piece of furniture, etc. on the

power cord (mains lead) or pinch the cord. Handle the

power cord by the plug. Do not unplug the appliance by

pulling from the power cord and never touch the power

cordwith wethands asthis couldcause ashort circuitor

electricshock.Nevermakeaknotinthecordortieitwith

othercords.Thepowercordsshouldbeplacedinsuch a

waythat theyarenotlikelytobesteppedon.Adamaged

powercordcancause ﬁre orgive you anelectricshock.

When itis damaged andneeds to bereplaced, it should

be done by qualiﬁed personnel.

Moisture and Water

Do not use this device in a humid and

damp place (avoid the bathroom, the

sinkinthe kitchen,andnearthewashing

machine). Do not expose this device to

rain or water, as this may be dangerous

and do not place objects filled with

liquids, such as ﬂower vases, on top.

Avoid from dripping or splashing.

Ifanysolid objectorliquidfalls intothecabinet, unplug

the TV and have it checked by qualiﬁed personnel

before operating it any further.

Cleaning

Before cleaning, unplug the TV set

from the wall outlet. Do not use liquid

or aerosol cleaners. Use soft and dry

cloth.

Ventilation

Theslotsandopenings on theTVset are intendedfor

ventilationandto ensurereliableoperation.Toprevent

overheating, these openings must not be blocked or

covered in anyway.

Heat and Flames

The set should not be placed near to

open ﬂames and sources of intense heat

such as an electric heater. Ensure that

no open ﬂame sources, such as lighted

candles,areplacedontop of theTV. Batteries should

not be exposed to excessive heat such as sunshine,

ﬁre or the like.

Lightning

In case of storm and lightning or when

going on holiday, disconnect the power

cord from the wall outlet.

Replacement Parts

Whenreplacementpartsare required,makesurethat

the service technician has used replacement parts,

which are speciﬁed by the manufacturer or have the

samespeciﬁcationsas the originalone.Unauthorized

substitutions may result in ﬁre, electrical shock or

other hazards.

Servicing

Please refer all servicing to qualiﬁed

personnel. Do not remove the cover

yourselfasthismayresult in an electric

shock.

Waste Disposal

Instructions for waste disposal:•

Packaging and packaging aids are recyclable and

should principally be recycled. Packaging materials,

such as foil bag, must be kept away from children.

Batteries,includingthose which areheavymetal-free,

should not be disposed of with household waste.

Please dispose of used battery in an environment

friendly manner. Find out about the legal regulations

which apply in your area.

• Don’t try to recharge batteries. Danger of explosion.

Replace batteries only with the same or equivalent

type.

Thissymbolon the productoronits packagingmeans

that your electrical and electronic device should be

disposed at the end of its service life

separately from your household wastes.

There are separate collection systems for

recyclinginEU. Formoreinformation,please

contactthelocal authorityorthe dealerwhere

you purchased the product.

Disconnecting the Device

The mains plug is used to disconnect TV set from

the mains and therefore it must remain readily

operable.

Headphone Volume

Excessivesoundpressurefromearphones

and headphones can cause hearing loss.

Installation

To prevent injury, this device must be securely

attachedtothewall inaccordancewiththe installation

instructions when mounted to the wall (if the option

is available).

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 3B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 3 27.10.2010 14:22:1227.10.2010 14:22:12

English - 4 -

Package Contents

REPEAT

ZOOM TITLE

ROOT

TEXT SWAP

123

456

789

SCREEN

LANG SUBTITLE

SOURCE

RETURN

INFO

FAV SLEEP EPG

DISPLAY

MODE

P+

PRESETS

P-

V+

V-

Remote

Control

LCD TV

Batteries: 2 X AAA

Instruction Book

Note: You should check the accessories after

purchasing. Make sure that each accessory is

included.

LCD Screen

TheLCDpanelisa very high technologyproductwith

about a million thin ﬁlm transistors, giving you ﬁne

picture details. Occasionally, a few non-active pixels

may appear on the screen as a ﬁxed blue, green or

red point. Please note that this does not affect the

performance of your product.

Warning! DonotleaveyourTVin standby oroperating

mode when you leave your house.

Connection to a Television Distribution

System (Cable TV etc.) from Tuner

Device connected to the protective earthing of the

building installation through the mains connection or

throughother apparatuswithaconnectiontoprotective

earthing-and to a television distribution system using

coaxial cable, may in some circumstances create a

ﬁre hazard.

Connection to a cable distribution system has

therefore to be provided through a device providing

electrical isolation below a certain frequency range

(galvanic isolator, see EN 60728-11).

The Standby / On button doesn´t separate this

device completely from mains. Moreover the device

consumespowerinthe standby operation. Inorderto

separatethedevice completelyfrommains,the mains

plughastobe pulled from themainssocket.Because

of that the device should be set up in a way, that an

unobstructed access to mains socket is guaranteed,

so that in case of emergency the mains plug can be

pulled immediately. To exclude the danger of ﬁre, the

power cord should principally be separated from the

mains socket prior to a longer period of non-usage,

i.e. during vacations.

Electrical device not in the hands of children

Neverletchildrenuse electrical deviceunsupervised.

Children can´t always recognize properly the

possible dangers. Batteries / accumulators can be

life threatening when swallowed. Store batteries

unreachable for small children. In case of swallowing

a battery medical aid has to be sought immediately.

Also keep the packaging foils away from children.

There is danger of suffocation.

Licence Notiﬁcation (optional)

is a trademark of SRS Labs, Inc.

TruSurround technology isincorporatedunder license

from SRS Labs, Inc.

Licence Notiﬁcation (optional)

Manufactured under license from Dolby

Laboratories.

TRADEMARK ACKNOWLEDGMENT

“Dolby” and the double-D symbol are trademarks of

Dolby Laboratories.

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 4B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 4 27.10.2010 14:22:1327.10.2010 14:22:13

English - 5 -

Environmental Information

• This television is designed to consume less energy to save environment.

Younot onlyhelpto savetheenvironmentbut alsoyoucansave moneybyreducing electricitybillsthanksto the

energy efﬁciency feauture of this TV. To reduce energy consumption, you should take the following steps:

• You can use Power Save Mode setting, located in the Feature menu. If you set Power Save Mode as On,

the TV will switch to energy-saving mode and luminance level of TV set will be decreased to optimum level.

Note that some picture settings will be unavailable to be changed when the TV is in Power Save Mode.

• When the TV is not in use, please switch off or disconnect the TV from the mains plug. This will also reduce

energy consumption.

• Disconnect power when going away for longer time.

• Note that annually, using the TV set in Power Save Mode has more power efﬁciency than disconnecting

the TV from the mains plug instead of keeping stand-by mode. Therefore disconnect the TV from the mains

plug to save energy when you do not use. However it is highly recommended to activate Power Save Mode

setting to reduce your annual power consumption.

• Please helps us to save environment by following these steps.

Repair Information

Please refer all servicing to qualiﬁed personnel. Only qualiﬁed personnel must repair the TV. Please contact

your local dealer, where you have purchased this TV for further information.

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 5B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 5 27.10.2010 14:22:1427.10.2010 14:22:14

English - 6 -

Remote Control Buttons

No function1. Play (in Media Browser mode)2. No function3. Rapid reverse (in Media Browser mode)4. No function5. Mono/Stereo - Dual I-II / Current Language6. Expand (in TXT mode) / Image size /7. Green button8. Red button / Zooms videos (in Media Browser9. video mode)

Numeric buttons10. Teletext / Mix11. Info / Reveal (in TXT mode)12. Programme Down - Page up / Programme Up -13. Page down

Mute14. Favourite mode selection15. Exit (in DTV mode) / Return / Index page (in16. TXT mode)

No function17. No function18. Exit USB menu19. Picture mode selection / Changes picture mode20. (in Media Browser video mode)

Electronic Programme Guide21. Sleep timer22. Menu on/off23. OK / Select / Hold (in TXT mode) / Channel List24. Volume up / down25. Navigation buttons26. AV / Source27. Previous programme28. Blue buton29. Yellow button:Active channel list30. No function31. Subtitle on-off / TXT subtitle (analogue TV32. mode) / Subtitle (in Media Browser mode).

No function33. Rapid advance (in Media Browser mode)34. Stop (in Media Browser mode)35. Pause (in Media Browser mode)36. Standby37. Operation LED light38.

REPEAT

ZOOM TITLE

ROOT

TEXT SWAP

123

456

789

SCREEN

LANG SUBTITLE

SOURCE

RETURN

INFO

FAV SLEEP EPG

SEARCH DISPLAY

MODE

P+

PRESETS

P-

V+

V-

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 6B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 6 27.10.2010 14:22:1427.10.2010 14:22:14

English - 7 -

LCD TV and Operating Buttons

FRONT and REAR VIEW Control buttons VIEW Control Buttons

1. Standby/On button

2. TV/AV button

3. Programme Up/Down buttons

4. Volume Up/Down buttons

Note:Press “ ”and

buttons at the same time to view

main menu.

Viewing the Back side Connections

HDMI 3

SCART 21. inputs or outputs for external devices.

SCART 12. input or output for external devices. Connect the SCART cable between SCART socket on

TV and SCART socket on your external device (such as a decoder, a VCR or a DVD player).

Note: If an external device is connected via the SCART socket, the TV will automatically switch to AV

mode.

Note: To connect external device,please use to supplied scart connection cable .

Component Video Inputs (YPbPr)3. are used for connecting component video.

You can connect the component video and audio sockets with a device that has component output.

Connect the component video cables between the COMPONENT VIDEO INPUTS on on the TV and

the component video outputs of your device. While connecting, be sure that the letters on your TV, “Y”,

“Pb”, “Pr” correspond with your device’s connectors.

PC/YPbPr Audio Inputs4. are used for connecting audio signals of a PC or a device that connects to the

TV via YPbPr. Connect the PC audio cable between the AUDIO INPUTS on the TV and audio output

of your PC to enable PC audio. Connect the audio cable between AUDIO INPUTS on the TV and audio

outputs of your device to enable component audio.

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 7B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 7 27.10.2010 14:22:1527.10.2010 14:22:15

English - 8 -

SPDIF Coaxial Out5. outputs digital audio signals of the currently watched source.

Use an SPDIF coaxial cable to trasfer audio signals to a device that has SPDIF input.

RF Input6. connects to an aerial antenna system.

Note that if you use a decoder or a media recorder, you should connect the aerial cable through the device

to the television with an appropriate antenna cable, as shown in the illustration in the following pages.

PC Input7. is for connecting a personal computer to the TV set.

Connect the PC cable between the PC INPUT on the TV and the PC output on your PC.

HDMI 1: HDMI Input8. HDMI Inputs are for connecting a device that has an HDMI socket. Your LCD TV is capable of

displaying High Deﬁnition pictures from devices such as a High Deﬁnition Satellite Receiver or DVD

Player. These devices must be connected via the HDMI sockets or Component Socket. These sockets

can accept either 720p or 1080p signals. No sound connection is needed for an HDMI to HDMI

connection.

HDMI 2: HDMI Input9. HDMI 3: HDMI Input10.

Viewing the Connections - Side Connectors

CI Slot is used for inserting a CI card. A CI card allows you to view all the1. channels that you subscribe to. For more information, see “Conditional

Access” section.

Side USBs2. Side HDMI Input is for connecting a device that has an HDMI socket.3. Headphone jack is used for connecting an external headphone to the system.4. Connect to the HEADPHONE jack to listen to the TV from headphones

(optional).

VideoInputisusedforconnectingvideosignalsofexternaldevices.Connectthevideo5. cablebetweentheVIDEOINsocketontheTVandtheVIDEOOUTjackonyourdevice.

AudioInputsareusedforconnectingaudiosignalsofexternaldevices.Connecttheaudio6. cablebetweentheAUDIOINPUTSontheTVandtheAUDIOOUTPUTjacksonyourdevice.

Note:Ifyou connectadevice totheTV viatheVIDEOINPUT,you shouldalsoconnect

your device with an audio cable to the AUDIO INPUTS of the TV to enable audio.

Standby switch is used for turning the TV on or off7. .

Power Connection

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.

After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the• mains. Plug the power cable to the mains socket outlet.

Aerial Connection

Connect the aerial or cable TV plug to theAERIAL INPUT socket located at the rear of the TV.•

HDMI 3

5Vdc-Max500mA

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 8B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 8 27.10.2010 14:22:1627.10.2010 14:22:16

English - 9 -

Using Digital Multimedia

Connectors

You can connect USB devices to your TV by using• the USB inputs of the TV. This feature allows you

to display/play JPG, MP3 and video ﬁles stored in

a USB stick.

It is possible that certain types of USB devices (e.g.• MP3 Players) may not be compatible with this TV.

You may back up your ﬁles before making any• connections to the TV set in order to avoid any

possible data loss. Note that manufacturer will not

be responsible for any ﬁle damage or data loss.

Do not pull out USB module while playing a ﬁle.•

CAUTION: Quickly plugging and unplugging USB

devices, is avery hazardous operation. Especially,

do not repeatedly quickly plug and unplug the

drive. This maycause physical damage to theUSB

player and especially the USB device itself.

SIDE VIEW USB MEMORY

USB Memory Connection

IMPORTANT: The TV should be switched off while

plugging or unplugging a USB device. Plug your

USB device to the USB inputs of the TV. You can

connect two usb device to your TV by using the USB

inputs of the TV at the same time.

Note: It is possible certain types of hard disk drives

are not supported.

Side HDMI Connection

Youcan use side HDMI input toconnectadevicethat

hasanHDMIconnectorto yourTV.Useanappropriate

HDMIcabletomake suchaconnection.Note that you

should switch to the HDMI source to view the content

fromtheconnecteddevice. Power offboth theTVand

thedevicebefore makinganyconnections. SideHDMI

Input supports connections between HDMI devices

such as DVD players. You can use side HDMI input

of the TV to connect to an external HDMI device. Use

an HDMI cable to connect.

HDMI DEVICE SIDE VIEW

Connecting the LCD TV to a PC

Fordisplayingyourcomputer’sscreenimageon your

LCDTV,youcan connectyourcomputer to theTV set.

Power off both computer and display before making

any connections. Use 15-pin D-sub display cable to

connect a PC to the LCD TV. When the connection

is made, switch to PC source. See “Input selection”

section. Set the resolution that suits your viewing

requirements. Resolution information can be found

in the appendix parts.

PC audio cable

(not supplied)

to AUDIO INPUTS

on the TV

PC RGB cable

(not supplied)

to PC input

Audio

Inputs

PC Input

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 9B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 9 27.10.2010 14:22:1927.10.2010 14:22:19

English - 10 -

Using Side AV Connectors

You can connect a range of optional equipment to

your LCD TV.

For connecting a camcorder, connect to the VIDEO• INsocket andtheAUDIOSOCKETS.Do notconnect

the camcoder to VIDEO IN socket at the same time

since it can cause noise in the picture. For selecting

the related source, see the section “Input selection”

in the following parts.

To listen the TV sound from headphones, connect• to the HEADPHONE jack of theTV.

Using Other Connectors

You can connect a range of optional equipment

to your LCD TV. Possible connections are shown

below. Note that cables shown in the illustration are

not supplied.

Forconnectinga toadevice thathasSPDIF support,• use an appropriate SPDIF cable to enable sound

connection.

External Speakers

A device that

supports

SPDIF signal.

Remote Control Handset

Inserting Batteries

Remove the battery cover located on the back of• the handset by gently pulling backwards from the

indicated part.

Insert two• AAA/R3 or equivalent type batteries

inside.Observe the correct polarity (+/-) when

inserting batteries and replace the battery cover.

Connecting to a DVD Player

If you want to connect a DVD player to your LCD

TV, you can use connectors of the TV set. DVD

players may have different connectors. Please refer

to your DVD player’s instruction book for additional

information. Power off both the TV and the device

before making any connections.

Note: Cables shown in the illustration are not

supplied.

If your DVD player has an HDMI socket, you can• connect viaHDMI.Whenyou connecttoDVD player

as illustrated below, switch to HDMI source. See,

“Input Selection” section.

Most DVD players are connected through• COMPONENT SOCKETS. Use a component video

cable to connect video input. For enabling audio,

use a component audio cable as illustrated below.

When the connection is made, switch to YPbPr

source. See, “Input selection” section.

You may also connect through the SCART 1 or• SCART 2. Use a SCART cable as shown below.

Note:Thesethree methods ofconnectionperform the

same function but in different levels of quality. It is not

necessary to connect by all three methods.

HDMI

inputs

Scart sockets

Component

video

inputs

Component

audio

inputs

DVD Player

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 10B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 10 27.10.2010 14:22:1927.10.2010 14:22:19

English - 11 -

Note: Remove the battery from remote control

handset when it is not to be used for a long period.

Otherwise it can be damaged due to any leakage of

batteries. Remote range is approximately 7m/23ft.

Switching On/Off

To Switch the TV On

Connect the power cord to the 220-240VAC 50 Hz.•

Switch the “• ” button to position “|” so the TV

will switch to standby mode. Then the standby LED

lights up.

To switch on the TV from standby mode either:•

Press the “• ” button, P+ / P- or a numeric button on

the remote control.

Pressthe• -P/CHor P/CH+touchbuttonontheTV.The

TV will then switch on.

Note: If you switch on your TV via PROGRAMME UP/

DOWN buttons on the remote control or on the TV

set, the programme that you were watching last will be

reselected.

By either method the TV will switch on.

To Switch the TV Off

Switch the “• ” button to position 2 as illustrated,(

) so the TV will switch off. .

To power down the TV completely, unplug the• power cord from the mains socket.

Note: When the TV is switched to standby mode,

standby LED can blink to indicate that features such as

Standby Search, OverAir Download or Timer is active.

The LEDcan also blinkwhen you switchon theTV from

standby mode.

Digital Teletext (** for UK only)

Press the “• ” button.

The digital teletext information appears.• Operate it with the coloured buttons, cursor buttons• and OK button.

The operation method may differ depending on the

contents of the digital teletext.

Follow the instructions displayed on digital teletext

screen.

When the “• ” button is pressed, the TV returns to

television broadcasting.

With digital terrestrial broadcasting (DVB-T), in• additiontodigitalteletext broadcastingtogetherwith

the normal broadcasting, there are also channels

with just digital teletext broadcasting.

The aspect ratio (picture shape) when watching• a channel with just digital teletext broadcasting is

the same as the aspect ratio of the picture viewed

previously.

When you press the “• ” button again, the digital

teletext screen will be displayed.

Analogue Teletext

Use of teletext and its functions are identical to

the analogue text system. Please do refer to the

“TELETEXT” explanations.

Input Selection

Once you have connected external systems to

your TV, you can switch to different input sources.

Press “SOURCE” button on your remote control

consecutively for directly changing sources.

You can operate your TV using both the remote control

and onset buttons.

Operation with the Buttons on the TV

Volume Setting

Press“• ”buttontodecreasevolumeor“

” buttontoincreasevolume, soavolumelevel scale

(slider) will be displayed on the screen.

Programme Selection

Press“• P/CH+”buttontoselectthenextprogrammeor

“P/CH -” button to select the previous programme.

Viewing Main Menu

Press the “• V+”/”V-” button at the same time to view

mainmenu.IntheMain menuselectsub-menu using

“AV” button and set the sub-menu using “ ” or

“” buttons. To learn the usage of the menus,

refer to the menu system sections.

AV Mode

Press the “• AV” button in the control panel on the TV

to switch between AV modes.

Operation with the Remote Control

Theremotecontrolof yourTVisdesignedto control• all the functions of the model you selected. The

functions will be described in accordance with the

menu system of your TV.

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 11B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 11 27.10.2010 14:22:2027.10.2010 14:22:20

English - 12 -

Volume Setting

Press“• V+”button toincreasethe volume.Press“V-”

buttontodecreasethe volume.Avolumelevelscale

(slider) will be displayed on the screen.

Programme Selection (Previous or Next

Programme)

Press “• P -” button to select the previous

programme.

Press “• P +” button to select the next programme.

Programme Selection (Direct Access)

Pressnumericbuttonsontheremotecontroltoselect• programmes between 0 and 9. The TV will switch

to the selected programme. To select programmes

between, press the numeric buttons consecutively.

When the pressing time is due for the second

numeric button, only the ﬁrst digit programme will

bedisplayed. Pressdirectly theprogrammenumber

to reselect single digit programmes.

Viewing Electronic Programme

Guide (EPG)

You can view the electronic programme guide (EPG)

to view information about available programmes.To

view the EPG menu please press EPG button on the

remote control.

Press “• ”/“ ” buttons to navigate through

channels.

Press “• ”/“ ” buttons to navigate through the

programme list.

EPG menu displays available information on all• channels.

Please note that event information is updated• automatically. If there are no event information

data available for channels, EPG will be displayed

with blanks.

OK (Options): Displaysprogrammeoptions including

“Select Channel” option.

INFO (Event Details): Displays the programmes in

detail.

Green button: Programme schedule will be listed

Yellow button: Display EPG data in accordane with

timeline schedule

Blue button (Filter): Views ﬁltering options.

Red button (Prev Time Slice): Displays the

programmes of previous time slice.

Green button (Next Time Slice): Displays the

programmes of the next time slice.

Yellow button (Prev Day): Displays theprogrammes

of previous day.

Blue button (Next day): Displays the programmes

of the next day.

Numeric buttons (Jump): Jumps to the preferred

channel directly via numeric buttons.

OK (Options): Displaysprogrammeoptions including

“Select Channel” option.

Text button (Filter): Views ﬁltering options.

INFO (Details): Displays the programmes in detail.

Red button (Prev Day): Displays the programmes

of previous day.

Green button (Next day): Displays the programmes

of the next day.

Yellow button (Zoom): Expands programme

information.

Blue button (Filter): Views ﬁltering options.

INFO (Details): Displays the programmes in detail.

Numeric buttons (Jump): Jumps to the preferred

channel directly via numeric buttons.

OK (Options): Displaysprogrammeoptions including

“Select Channel” option.

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 12B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 12 27.10.2010 14:22:2027.10.2010 14:22:20

English - 13 -

Text (Search): Displays “Guide Search” menu.

SUBTTL: Press SUBTITLE button to view Select

Genre menu. Using this feature, you can search the

programme guide database in accordance with the

genre. Info available in the programme guide will

be searched and results matching your criteria will

be listed.

(Now) : Shows the current programme.

First Time Installation

IMPORTANT: Ensure that the aerial is connected

before switching on the TV for the first time

installation.

WhentheTVisoperated fortheﬁrst time,installation• wizard will guide you through the process. First,

language selection screen will be displayed:

Use “• ” or “ ” buttons to select your language

and press OK button to set selected language and

continue.

Afterselectingthe language,“• Welcome!”screen will

be displayed, requiring you to set Country,Teletext

Language and Scan Encrypted options.

By pressing “• ” or “ ” button, select the country

you want to set and press “ ” button to highlight

Teletext Language option. Use “ ” or “ ” button

to select desired Teletext Language.

Press “• ” button after setting Teletext Language

option. Scan Encrypted will be then highlighted.

You can set Scan Encrypted as Yes if you want to

scan coded stations.Afterwards select the desired

Teletext Language.

Press• OK button on the remote control to continue

and the following message will be displayed on the

screen:

To selectthe“Yes” or“No”option, highlight theitemby

using “ ” or “ ” buttons and press OK button.

Afterwards,thefollowing OSD willbedisplayed onthe

screen and the digital television will search for digital

terrestrial TV broadcasts

Note: You can press “M” button to cancel.

After all the available stations are stored, Channel• List will be displayed on the screen. If you like the

sort channels, according to the LCN,please select

“Yes” and than press “OK”.

Press• OK button to quit channel list and watch TV.

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 13B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 13 27.10.2010 14:22:2027.10.2010 14:22:20

English - 14 -

Auto Tuning

HINT:Autotuning featurewillhelp youtoretune theTV

set in order to store new services or stations.

Press “MENU” button on the remote control and

select Installation by using “ ” or “ ” button. Press

OK button and the following menu screen will be

displayed.

Select Automatic Channel Scan by using “”/“ ”

buttonandpress OK button.Automatic ChannelScan

optionswillbe displayed.Youcanselect DigitalAerial,

Analog or Digital Aerial-Analogue tuning using “”/“

”and OK buttons.

Auto Channel Scan Menu Operation

Digital: Searches and stores aerial DVB stations.

Analogue: Searches and stores analog stations.

Full: Searches and stores both analog and aerial

DVB stations.

Whenever you select an automatic search type and• press OK button, a conﬁrmation screen will appear

on the screen. To start installation process, select

Yes, to cancel select No by using .“ ” or “ ” and

OK button.

After auto channel scan type is set and selected• and conﬁrmed, installation process will start and

progressbarwill move along.Press“MENU” button

to cancel process. In such a case, located channels

are not stored.

Manual Tuning

HINT: This feature can be used for direct broadcast

entry.

Select• Manual Channel Scan from the Installation

menu by using “ ”/“ ” and OK buttons. Manual

Scan options screen will be displayed.

Select the desired• Search Type using “ ” or “

” button. Manual search options will change

accordingly.Use“ ”/“ ”button to highlight anitem

and then press “ ” or “ ” button to set an option.

You can press “MENU” button to cancel.

Digital Manual Search

In manual channel scan, the number of the multiplex

or frequency are entered manually and only that

multiplexorfrequencyare searched for thechannels.

After selecting search type as Digital, you can enter

the multiplex or frequency number using the numeric

buttons and press OK button to search.

Analogue Manual Search

After selecting search type as analogue, you can use

“ ”/“ ” button to highlight an item and then press “

” or “ ” button to set an option.

Enter the channel number or frequency using the

numeric buttons. You can then press OK button

to search. When the channel is located, any new

channels that are not on the list will be stored.

Analog Fine Tune

Select• Analog Fine Tune fromtheInstallation menu

byusing“ ” or“ ”andOK buttons.Analogﬁnetune

screen will be displayed. Analog Fine Tune feature

willnotbeavailableif there are noanalogchannels,

digital channels and external sources stored.

Press• OK button to proceed. Use “ ” or “ ” button

to set Fine Tune. When ﬁnished, press OK button

again.

Clear Service List (*)

(*)Thissettingis visible only whentheCountryoption

is set to Denmark, Sweden, Norway or Finland.

Usethissettingto clearchannelsstored.Press “ ” or

“”buttontoselectClear Service List andthenpress

OK. The following OSD message will be displayed

on the screen:

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 14B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 14 27.10.2010 14:22:2127.10.2010 14:22:21

English - 15 -

PressOKtocancel. SelectYes by pressing“ ”or“ ”

button and press OK to delete all of the channels.

Managing Stations: Channel List

The TV sorts all stored stations in the Channel List.

You can edit this channel list, set favourites or set

active stations to be listed by using the Channel List

options.

Press• “MENU” button to view main menu. Select

Channel List item by using “ ” or “ ” button. Press

OK to view menu contents.

Select Edit Channel List to manage all stored

channels. Use “ ” or “ ” and OK buttons to select

Edit Channel List.

Operating the Channel List

Press “• ” or “ ” button to select the channel that

will be processed. Press “ ” or “ ” button to select

a function on Channel List menu.

Use• P+/P- buttons to move page up or down.

Press• BLUE button to view ﬁltering options.

Press• “MENU” button to exit.

Moving a Channel

Firstselectthedesired channel. Select Moveoption• in the channel list and press OK button.

Edit Number screen will be displayed. Enter the• desired channel number by using the numeric

buttonsonthe remote control.Ifthere is apreviously

stored channel on that number, a warning screen

willbedisplayed.Select Yesif you want tomovethe

channel and press OK.

Press• OK button to process. Selected channel is

now moved.

Deleting a Channel

You can press GREEN button to tag/untag all

channels; YELLOW button to tag/untag channel.

Selectthechannel thatyouwant to deleteandselect• Delete option. Press OK button to continue.

Awarning screen will appear. Select• YES to delete,

select No to cancel. Press OK button to continue.

Renaming a Channel

Select the channel that you want to rename and• select Edit Name option. Press OK button to

continue.

Pressing “• ” or “ ” button moves to the previous/

next character. Pressing “ ” or “ ” button toggles

the current character, i.e., ‘b’ character becomes ‘a’

by “ ” and ‘c’by “ ”. Pressing the numeric buttons

‘0...9’ replaces the highlighted character with the

characters printed above the button one by one as

the button is pressed.

When ﬁnished, press• OK button to save. Press

“MENU” to cancel.

Locking a Channel

You can press GREEN button to tag/untag all

channels; YELLOW button to tag/untag a single

channel.

Select the channel that you want to lock and select• Lock option. Press OK button to continue.

You will be asked to enter parental control PIN.• Default PIN is set as 0000. Enter the PIN number.

Press• OK button when the desired channel is

highlightedtolock/unlockthechannel. Lock symbol

will be displayed next to the selected channel.

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 15B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 15 27.10.2010 14:22:2227.10.2010 14:22:22

English - 16 -

Managing Stations: Favourites

You can create a list of favourite programmes.

Press• “MENU” button to view main menu. Select

Channel List item by using “ ” or “ ” button. Press

OK to view menu contents.

Select• Favourites to manage favourite list. Use “

”/“ ” and OK buttons to select Favourites.

You can set various channels as favourites so that• only the favourite channels are navigated.

Select a channel by using “• ” or “ ” button. Press

OK buttontoaddselectedchannel to favourites list.

Press OK button again to remove.

Button Functions

OK• : Add/remove a station.

YELLOW• : Tag/untag a channel.

GREEN• : Tag/untag all channels.

BLUE• : Displays ﬁltering options.

Managing Stations: Sorting

Channel List

You can select broadcasts to be listed in the channel

list.To display speciﬁctypesofbroadcast, you should

use Active channel list setting.

Select Active channel list from the Channel list

menu by using “ ” or “ ” button. Press OK button

to continue.

You can select a broadcast type option from the list

by using “ ” /“ ” and OK buttons.

On-Screen Information

You can press “INFO” button to display on-screen

information. Details of the station and current

programme will be displayed on the information

banner.

The information banner gives information on the

channelselectedand theprogrammesonit.Thename

of the channel is displayed, along with its channel

list number.

Hint: Not all channels broadcast the programme

data. If the name and time of the programme are not

available, then information banner will be displayed

with blanks.

If the selected channel is locked, you must enter the

correct four-digit numeric code to view the channel

(default code is 0000). “Enter PIN” will be displayed

on the screen in such a case:

Media Playback Using Media

Browser

If the USB stick is not recognized after power off/on

or First Time Installation, ﬁrst, plug the USB device

out and power off/on the TV set. Plug the USB device

in again.

To display Media Browser window, press either

“MENU” buttonontheremote controlandthenselect

Media Browser by pressing “ ” or “ ” button. Press

OK button to continue. Media Browser menu options

will be displayed.

Also, when you plug USB devices, media browser

screen will be displayed automatically:

You can play music, picture and video ﬁles from the

connected USB memory stick. Use “ ” or “ ” button

to select Videos, Photos, Music or Settings.

You can connect two USB devices to yourTV. If both

USBdevicesinclude music,pictureor videoﬁles,USB

selection osd will be displayed on the screen. The

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 16B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 16 27.10.2010 14:22:2227.10.2010 14:22:22

English - 17 -

ﬁrst USB device connected to the TV will be named

as USB Drive1.

Select a device by using “ ” or “ ” button and press

OK.

Viewing Videos via USB

When you select Videos from the main options,

available video ﬁles will be ﬁltered and listed on this

screen.Youcan use“ ”or “ ”buttonto selectavideo

ﬁle and press OK button to play a video. If you select

a subtitle ﬁle and press OK button, you can select or

deselect that subtitle ﬁle. The following menu will be

displayed while playing a video ﬁle:

Play ( button): Starts the video playback.

Stop ( button): Stops the video playback.

Pause ( button): Pause the video playback.

Rewind ( button): Goes backward.

Forward ( button): Goes forward.

Subtitle/Audio (LANG. button): Sets subtitle/Audio.

Yellow: Opens subtitle time correction menu

Press RETURN (Exit) button to switch back to

previous menu.

Viewing Photos via USB

When you select Photos from the main options,

available image ﬁles will be ﬁltered and listed on this

screen.

Jump (Numeric buttons):Jumptoselectedﬁle using

the numeric buttons.

OK: Views the selected picture in full screen.

Slideshow ( button): Starts the slideshow using

all images.

RED: Sorts ﬁles by date.

GREEN: Views images in thumbnails.

BLUE: Switch between music,photo,video and all

YELLOW: Change view style

Slideshow Options

Pause ( button) : Pauses the slideshow.

Continue ( button) : Continues the slideshow.

Previous/Next (Left/Right buttons): Jumps to

previous or next ﬁle on slideshow.

Rotate (Up/Down buttons):Rotatestheimage using

up/down buttons.

Loop/Shufﬂe(GREEN button):Pressoncetodisable

Loop. Press again to disable both Loop and Shufﬂe.

Press once more to enable only Shufﬂe. Press again

to enable all. You can follow the disabled functions

with the change of the icons.

RETURN (Exit): Back to ﬁle list.

INFO: Displays help screen.

Playing Music via USB

Whenyou selectMusic fromthe mainoptions,available

audio ﬁles will be ﬁltered and listed on this screen.

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 17B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 17 27.10.2010 14:22:2327.10.2010 14:22:23

English - 18 -

0..9 (Numeric buttons): Jumps to the selected ﬁle.

Play This (OK button) : Plays the selected ﬁle.

Play ( button) : Plays all media ﬁles starting with

the selected one.

Stop ( button) : Stops playback.

Pause ( button) : Pauses the selected playback.

Previous/Next (Left/Right buttons) : Jumps to

previous or next ﬁle to play.

RED: Sorts ﬁles by Title,Artist or Album.

BLUE: Switch between music, photo, video and all

YELLOW : Change view style

Loop/Shufﬂe(GREEN button):Pressoncetodisable

Loop. Press again to disable both Loop and Shufﬂe.

Press once more to enable only Shufﬂe. Press again

to enable all. You can follow the disabled functions

with the change of the icons.

Media Browser Settings

You can set your Media Browser preferences by

using the Settings dialog. Press “ ” or “ ” button to

highlight an item and use “ ” or “ ” button to set.

View Style: Sets default browsing mode.

Slide Show Interval: Sets slide show interval time.

Show Subtitle: Sets subtitle enabling preference.

Subtitle Position: Sets subtitle position as up or

down.

Subtitle Font Size: Sets subtitle font size (max.

54pt).

Changing Image Size: Picture

Formats

Programmes can be watched in different picture• formats, depending on the transmission received.

You can change the aspect ratio (image size) of• the TV for viewing the picture in different zoom

modes.

Press• “SCREEN” button repeatedly to change

the image size. Available zoom modes are listed

below.

Auto

WhenaWSS (WideScreenSignalling) signal,which

shows the aspect ratio of the picture, is included in

the broadcast signal or the signal from an external

device, the TV automatically changes the ZOOM

mode according to the WSS signal.

When the• AUTO mode does not function correctly

due to poor WSS signal quality or when you want to

changetheZOOM mode,change to another ZOOM

mode manually.

16:9

This uniformly stretches the left and right sides of a

normal picture (4:3 aspect ratio) to ﬁll the wide TV

screen.

For 16:9 aspect ratio pictures that have been• squeezed into a normal picture (4:3 aspect ratio),

use the 16:9 mode to restore the picture to its

original shape.

Subtitle

This zooms up the wide picture (16:9 aspect ratio)

with subtitles to the full screen.

Note: You can shift to screen up or down by pressing

“” / “ ” buttons while picture zoom is selected as

panaromic, 14:9 Zoom, Cinema or Subtitle.

14:9

This zooms up the wide picture (14:9 aspect ratio) to

the upper and lower limits of the screen.

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 18B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 18 27.10.2010 14:22:2327.10.2010 14:22:23

English - 19 -

14:9 Zoom

This option zooms to the 14:9 picture.

4:3

Use to view a normal picture (4:3 aspect ratio) as this

is its original size.

Panoramic

This stretches the left and right sides of a normal

picture (4:3 aspect ratio) to ﬁll the screen, without

making the picture appear unnatural.

The top and bottom of the picture are slightly cut off.

Cinema

This zooms up the wide picture (16:9 aspect ratio) to

the full screen.

Conﬁguring Picture Settings

You can use different picture settings in detail.

Press “MENU” button and select the Picture icon

by using “ ” or “ ” button. Press OK button to view

Picture Settings menu.

Operating Picture Settings Menu Items

Press “• ” or “ ” button to highlight a menu item.

Use “• ” or “ ” button to set an item.

Press• “MENU” button to exit.

Picture Settings Menu Items

Mode: For your viewing requirements, you can set

the related mode option. Picture mode can be set

to one of these options: Cinema,Game,Dynamic

and Natural.

Contrast: Sets the lightness and darkness values

of the screen.

Brightness: Sets the brightness value for the

screen.

Sharpness: Sets the sharpness value for the objects

displayed on the screen.

Colour: Sets the colour value, adjusting the colors.

Colour Shift: Adjust the desired colour tone.

Hue (NTSC only): Adjusts the colour value.

Colour Temp: Sets the desired colour tone.

Setting Cool option gives white colours a slight blue

stress.

For normal colours, select Normal option.

Setting Warm option gives white colours a slight red

stress.

Noise Reduction:Ifthebroadcast signal isweakand

the picture is noisy, use Noise Reduction setting to

reducethenoiseamount. Noise Reductioncanbe set

to one of these options: Low, Medium, High or Off.

B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 19B02_MB61_[GB]_5110UK_IDTV_GOLD12_37884W_10070326_50179516.indd 19 27.10.2010 14:22:2427.10.2010 14:22:24
