Medion E12471 User manual

Dok./Rev.-Nr. IMA 21571 Cover V2.0
3
Made in China
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
WWW.ALDI.COM.AU
1
AU
YEARS
WARRANTY
AFTER SALES SUPPORT
www.medion.com.au
1 300 884 987
MODEL:
MD 21571
700797
02/2020
AU
24“ Full HD LED LCD TV
E12471
User Manual Contents
Overview .................................................................................................................. 4
Device parts.............................................................................................................. 6
About these operating instructions........................................................................ 9
Safety instructions ...................................................................................................11
Declaration of conformity.......................................................................................15
Overview of the device...........................................................................................16
Operation.................................................................................................................18
Installation ..............................................................................................................18
Operation.................................................................................................................24
Navigating within the menu ..................................................................................26
Media Player........................................................................................................... 36
DVD mode ............................................................................................................... 43
Troubleshooting..................................................................................................... 48
Storage when not in use........................................................................................ 50
Disposal .................................................................................................................. 50
Technical data.......................................................................................................... 51
Service information ................................................................................................53
Legal Notice .............................................................................................................53
Warranty Details ..................................................................................................... 54
Repair and Refurbished Goods or Parts Notice.................................................... 55
IMA 21571 Cover V2.0.indd 1-5IMA 21571 Cover V2.0.indd 1-5 27.11.2019 10:53:2727.11.2019 10:53:27

Dok./Rev.-Nr. IMA 21571 Cover V2.0
3
Made in China
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
WWW.ALDI.COM.AU
1
AU
YEARS
WARRANTY
AFTER SALES SUPPORT
www.medion.com.au
1 300 884 987
MODEL:
MD 21571
700797
02/2020
AU
24“ Full HD LED LCD TV
E12471
User Manual Contents
Overview .................................................................................................................. 4
Device parts.............................................................................................................. 6
About these operating instructions........................................................................ 9
Safety instructions ...................................................................................................11
Declaration of conformity.......................................................................................15
Overview of the device...........................................................................................16
Operation.................................................................................................................18
Installation ..............................................................................................................18
Operation.................................................................................................................24
Navigating within the menu ..................................................................................26
Media Player........................................................................................................... 36
DVD mode ............................................................................................................... 43
Troubleshooting..................................................................................................... 48
Storage when not in use........................................................................................ 50
Disposal .................................................................................................................. 50
Technical data.......................................................................................................... 51
Service information ................................................................................................53
Legal Notice .............................................................................................................53
Warranty Details ..................................................................................................... 54
Repair and Refurbished Goods or Parts Notice.................................................... 55
IMA 21571 Cover V2.0.indd 1-5IMA 21571 Cover V2.0.indd 1-5 27.11.2019 10:53:2727.11.2019 10:53:27

64 5
Device partsOverview Overview
A
B
C
⻪䂽
MENU SOURCE
INFOEXIT
ENTER
VOLCH
SOUND ASPECT
REC
A-B
SEARCH
AUDIO REPEATSETUP
T-SHIFT
EPG
USB
ANGLE
SUBTLTLE LIST
SLOW ZOOM PROGRAM
20
21
22
23
24
25
26
28
30
27
31
32
33
35
34
36
37
38
39
40
41
42
43
29
6
7
3
4
5
1
2
PC AUDIO
IN
PC
HDMI
ARC/CEC
USB (2.0)
DC 5V
Max. 500mA
RF
Earphone Out
SPDIF
COAX OUT
VIDEO L R
(AV IN)
8
9
10
11
12
13
14
15
1617
19
YPb Pr
Power
DC 12V
3A
18
Device parts
1VOL +/VOL -
2CH + /CH -
3MENU
SOURCE
4PLAY
EJECT
5POWER
6Operating light / Infrared sensor
7LCD screen
8VIDEO L-R (AV IN)
9USB 5V max. 500mA
10 HDMI ARC/CEC
11 RF
12 SPDIF COAX OUT
13 YPbPr
14 PC
15 PC AUDIO IN
16 EARPHONE OUT
17 POWER DC 12V 3A
18 DVD player
19 Fixing holes for a wall bracket
20 (MUTE)
21 ASPECT / PROGRAMM (DVD mode)
22 Number buttons
23 (SWAP)
24 SOURCE
25 Direction buttons
26 INFO
27 EPG / A-B (DVD mode)
28 VOL+/-
29 USB
30 Colour / media buttons
31 LIST / SEARCH (DVD mode)
32 T-SHIFT /REPEAT (DVD mode)
33 REC / SETUP (DVD mode)
34 AUDIO / : (stereo/mono sound
format)
35 (FAV) / ANGLE (DVD mode)
36 SUBTITLE
37 CH+/-
38 EXIT
39 ENTER
40 MENU
41 PICTURE / SLOW (DVD mode)
42 SOUND / ZOOM (DVD mode)
43 (STANDBY)
IMA 21571 Cover V2.0.indd 6-10IMA 21571 Cover V2.0.indd 6-10 27.11.2019 10:53:3827.11.2019 10:53:38

64 5
Device partsOverview Overview
A
B
C
⻪䂽
MENU SOURCE
INFOEXIT
ENTER
VOLCH
SOUND ASPECT
REC
A-B
SEARCH
AUDIO REPEATSETUP
T-SHIFT
EPG
USB
ANGLE
SUBTLTLE LIST
SLOW ZOOM PROGRAM
20
21
22
23
24
25
26
28
30
27
31
32
33
35
34
36
37
38
39
40
41
42
43
29
6
7
3
4
5
1
2
PC AUDIO
IN
PC
HDMI
ARC/CEC
USB (2.0)
DC 5V
Max. 500mA
RF
Earphone Out
SPDIF
COAX OUT
VIDEO L R
(AV IN)
8
9
10
11
12
13
14
15
1617
19
YPb Pr
Power
DC 12V
3A
18
Device parts
1VOL +/VOL -
2CH + /CH -
3MENU
SOURCE
4PLAY
EJECT
5POWER
6Operating light / Infrared sensor
7LCD screen
8VIDEO L-R (AV IN)
9USB 5V max. 500mA
10 HDMI ARC/CEC
11 RF
12 SPDIF COAX OUT
13 YPbPr
14 PC
15 PC AUDIO IN
16 EARPHONE OUT
17 POWER DC 12V 3A
18 DVD player
19 Fixing holes for a wall bracket
20 (MUTE)
21 ASPECT / PROGRAMM (DVD mode)
22 Number buttons
23 (SWAP)
24 SOURCE
25 Direction buttons
26 INFO
27 EPG / A-B (DVD mode)
28 VOL+/-
29 USB
30 Colour / media buttons
31 LIST / SEARCH (DVD mode)
32 T-SHIFT /REPEAT (DVD mode)
33 REC / SETUP (DVD mode)
34 AUDIO / : (stereo/mono sound
format)
35 (FAV) / ANGLE (DVD mode)
36 SUBTITLE
37 CH+/-
38 EXIT
39 ENTER
40 MENU
41 PICTURE / SLOW (DVD mode)
42 SOUND / ZOOM (DVD mode)
43 (STANDBY)
IMA 21571 Cover V2.0.indd 6-10IMA 21571 Cover V2.0.indd 6-10 27.11.2019 10:53:3827.11.2019 10:53:38

64 5
Device partsOverview Overview
A
B
C
⻪䂽
MENU SOURCE
INFOEXIT
ENTER
VOLCH
SOUND ASPECT
REC
A-B
SEARCH
AUDIO REPEATSETUP
T-SHIFT
EPG
USB
ANGLE
SUBTLTLE LIST
SLOW ZOOM PROGRAM
20
21
22
23
24
25
26
28
30
27
31
32
33
35
34
36
37
38
39
40
41
42
43
29
6
7
3
4
5
1
2
PC AUDIO
IN
PC
HDMI
ARC/CEC
USB (2.0)
DC 5V
Max. 500mA
RF
Earphone Out
SPDIF
COAX OUT
VIDEO L R
(AV IN)
8
9
10
11
12
13
14
15
1617
19
YPb Pr
Power
DC 12V
3A
18
Device parts
1VOL +/VOL -
2CH + /CH -
3MENU
SOURCE
4PLAY
EJECT
5POWER
6Operating light / Infrared sensor
7LCD screen
8VIDEO L-R (AV IN)
9USB 5V max. 500mA
10 HDMI ARC/CEC
11 RF
12 SPDIF COAX OUT
13 YPbPr
14 PC
15 PC AUDIO IN
16 EARPHONE OUT
17 POWER DC 12V 3A
18 DVD player
19 Fixing holes for a wall bracket
20 (MUTE)
21 ASPECT / PROGRAMM (DVD mode)
22 Number buttons
23 (SWAP)
24 SOURCE
25 Direction buttons
26 INFO
27 EPG / A-B (DVD mode)
28 VOL+/-
29 USB
30 Colour / media buttons
31 LIST / SEARCH (DVD mode)
32 T-SHIFT /REPEAT (DVD mode)
33 REC / SETUP (DVD mode)
34 AUDIO / : (stereo/mono sound
format)
35 (FAV) / ANGLE (DVD mode)
36 SUBTITLE
37 CH+/-
38 EXIT
39 ENTER
40 MENU
41 PICTURE / SLOW (DVD mode)
42 SOUND / ZOOM (DVD mode)
43 (STANDBY)
IMA 21571 Cover V2.0.indd 6-10IMA 21571 Cover V2.0.indd 6-10 27.11.2019 10:53:3827.11.2019 10:53:38

7
Contents
Contents
Overview...................................................................................................................................................... 4
Device parts.................................................................................................................................................. 6
About these operating instructions............................................................................................................ 9
Intended use ..........................................................................................................................................................10
Full HD......................................................................................................................................................................10
Package contents...................................................................................................................................................10
Safety instructions .......................................................................................................................................11
Operating safety......................................................................................................................................................11
Set-up location ...................................................................................................................................................... 12
Repairs..................................................................................................................................................................... 13
Environmental temperature ................................................................................................................................ 13
Safety when connecting....................................................................................................................................... 13
Handling batteries................................................................................................................................................. 14
Declaration of conformity........................................................................................................................... 15
DVD player............................................................................................................................................................... 15
Overview of the device............................................................................................................................... 16
Front.........................................................................................................................................................................16
Rear..........................................................................................................................................................................16
Remote control....................................................................................................................................................... 17
Operation ....................................................................................................................................................18
Unpacking ..............................................................................................................................................................18
Installation ..................................................................................................................................................18
Inserting the batteries in the remote control ....................................................................................................19
Connecting the antenna.......................................................................................................................................19
Connecting the mains adapter ............................................................................................................................19
Switching the Full HD LED LCD TV on and off ......................................................................................................19
Use of the multimedia connections.................................................................................................................... 20
Channel search after switching on for the first time.........................................................................................22
Operation ....................................................................................................................................................24
Selecting channels.................................................................................................................................................24
Setting the volume ................................................................................................................................................24
Picture settings.......................................................................................................................................................24
Displaying channel information ..........................................................................................................................25
Opening a favourites list.......................................................................................................................................25
Selecting the source ..............................................................................................................................................25
Navigating within the menu ......................................................................................................................26
Picture menu ..........................................................................................................................................................27
Sound menu .......................................................................................................................................................... 28
Channel menu....................................................................................................................................................... 29
Lock System menu................................................................................................................................................. 31
Setup menu ............................................................................................................................................................32
PVR recording........................................................................................................................................................ 35
Timeshift recording function............................................................................................................................... 35
Media Player ...............................................................................................................................................36
Accessing the media player ................................................................................................................................ 36
IMA 21571 Content V2.0.indd 7IMA 21571 Content V2.0.indd 7 29.11.2019 08:52:4129.11.2019 08:52:41

8
Contents
Main menu for the media player ........................................................................................................................ 36
Displaying photos ..................................................................................................................................................37
Playing back music ............................................................................................................................................... 38
Playing back films ................................................................................................................................................. 39
Displaying text files............................................................................................................................................... 40
EPG - programme guide ....................................................................................................................................... 41
DVD mode....................................................................................................................................................43
Switching between TV and DVD modes............................................................................................................. 43
Inserting a DVD...................................................................................................................................................... 43
Button functions.................................................................................................................................................... 43
Navigating MP3 and JPEG data media................................................................................................................ 45
SETUP menu in DVD mode ................................................................................................................................... 46
Troubleshooting ........................................................................................................................................ 48
Do you need more help?...................................................................................................................................... 49
Full HD LED LCD TV pixel faults ............................................................................................................................. 49
Cleaning ................................................................................................................................................................. 50
Storage when not in use............................................................................................................................ 50
Disposal ..................................................................................................................................................... 50
Technical data ............................................................................................................................................. 51
Service information ....................................................................................................................................53
Legal Notice.................................................................................................................................................53
Warranty Details......................................................................................................................................... 54
Repair and Refurbished Goods or Parts Notice..........................................................................................55
IMA 21571 Content V2.0.indd 8IMA 21571 Content V2.0.indd 8 29.11.2019 08:53:0429.11.2019 08:53:04

9
About these operating instructions
About these operating instructions
Thank you for choosing our product. We hope you enjoy using it.
Read the safety instructions carefully before using the device for the first time. Note the warnings on
the device and in the operating instructions.
Always keep the operating instructions close to hand. If you sell the device or give it away, please ensure that you
also pass on these operating instructions. They are an essential component of the product.
Explanation of symbols
If a block of text is marked with one of the warning symbols listed below, the hazard described in that text must be
avoided to prevent the potential consequences described there from occurring.
DANGER!
This signal word indicates a hazard with a high level of risk which, if not avoided, will result in death or serious
injury.
WARNING!
This signal word indicates a hazard with a medium level of risk which, if not avoided, could result in death or seri-
ous injury.
CAUTION!
This signal word indicates a hazard with a low level of risk which, if not avoided, could result in minor or moderate
injury.
NOTICE!
This signal word warns of possible damage to property.
Please follow the guidelines in the operating instructions.
This symbol gives you useful additional information on assembly or operation.
The RCM is the compliance mark for all applicable Australian Communications and Media Authority
(ACMA) regulatory arrangements, including all technical and record-keeping requirements.
Protection class III
Electrical appliances in protection class III are electrical appliances built for operation with safety ex-
tra-low voltage that have neither internal nor external electricity circuits which work with a different
voltage other than safety extra-low voltage. The maximum rated voltage for the safety extra-low
voltage between the conductors and between the conductors and the earth is 42 V. In the case
of three-phase alternating current, the maximum rated voltage between the conductors and the
neutral conductor is 24 V. The maximum off-load voltage must not exceed 50 V. The safety extra-low
voltage may only be supplied via a safety transformer or a transformer with separate windings.
IMA 21571 Content V2.0.indd 9IMA 21571 Content V2.0.indd 9 29.11.2019 08:53:0429.11.2019 08:53:04

10
About these operating instructions
Intended use
This device is used to receive and play back television channels. The range of different connections
makes it possible to expand the input and output sources (receiver, DVD player, DVD recorder, video
recorder, PC, etc.). Your device offers a number of options for usage:
The device is intended for private use only and not for industrial/commercial use.
Please note that we shall not be liable in cases of improper use:
−Do not modify the device without our consent and do not use any auxiliary equipment
that we have not approved or supplied.
−Use only spare parts and accessories that we have supplied or approved.
−Heed all the information in these operating instructions, especially the safety information.
Any other use is deemed improper and can cause personal injury or damage to the device.
−Do not use the device in extreme environmental conditions.
−This product is intended for use in dry, indoor areas only.
−This device is not designed to be used as a data monitor for office workplaces.
Full HD
Your Full HD LED LCD TV is equipped with the feature “Full HD”. This means that it is capable of displaying high reso-
lution television programmes (HDTV). The prerequisite for this is a HDTV signal.
Package contents
Please check your purchase to ensure that all the items are included and contact us within 14 days of purchase if
any parts are missing.
DANGER!
DANGER!
Risk of suffocation!
Packaging film can be swallowed or used improperly. Therefore, there is a risk of suffocation!
− Keep packaging material such as plastic film or plastic bags away from children.
The following items are supplied with your product:
• 24”Full HD LED LCD TV
• Remote Control incl. 2 x batteries 1.5V AAA
• External power adapter
• Car adapter
• Instruction Manual
• Warranty Certificate
• Stands incl. screws for mounting
IMA 21571 Content V2.0.indd 10IMA 21571 Content V2.0.indd 10 29.11.2019 08:53:0529.11.2019 08:53:05

11
Safety instructions
Safety instructions
CAUTION!
Risk of injury!
There is a risk of injury when using a wrong power supply!
− Use only the power supply listed in the user instructions.
Operating safety
−This device may be used by children over the age of 8 and by persons with reduced phys-
ical, sensory or mental abilities or by those without experience and knowledge, if they are
supervised or have been instructed in the safe use of the device and have understood the
dangers that result from it.
−Children must not be allowed to play with the device. Cleaning and user maintenance
must not be carried out by children unless they are supervised.
DANGER!
Risk of suffocation!
Packaging film can be swallowed or used improperly. Therefore, there is a risk of suffocation!
− Keep packaging material such as plastic film or plastic bags away from children.
DANGER!
Risk of electric shock!
Risk of electric shock, short circuit and fire!
− Never open the housing of the Full HD LED LCD TV and never insert any objects through the
slots and openings into the Full HD LED LCD TV.
WARNING!
Overheating! Risk of fire!
Overheating can damage the Full HD LED LCD TV and lead to a risk of fire!
− The slots and openings on the TV are for ventilation purposes. Do not cover these openings
e.g. with newspapers, table cloths, curtains, etc.
−Do not put any pressure on the display. There is a risk that the screen may break.
−The remote control has a class 1 infrared diode. Never use optical devices to look at the LED.
CAUTION!
Risk of injury!
There is a risk of injury if the display is broken!
− Pick up the shattered pieces wearing protective gloves.
− Then wash your hands with soap because chemicals may have leaked out.
− Send the broken parts to your Service Centre for professional disposal.
− To avoid damaging the display, do not touch it with fingers or sharp objects.
IMA 21571 Content V2.0.indd 11IMA 21571 Content V2.0.indd 11 29.11.2019 08:53:0529.11.2019 08:53:05

12
Safety instructions
Contact customer services if:
−The power cable is burnt or damaged
−Liquid has penetrated the device
−The device is not operating correctly
−The device has fallen, or the housing is damaged
−Smoke is rising from the device
Set-up location
−In the first few hours of use, new devices can give off a typical, unavoidable but totally
harmless smell which wears off with time. We recommend that you ventilate the room at
regular intervals to counteract the smell. We have taken appropriate measures during the
development of this device to ensure that levels
are significantly below legal limits.
−Keep your Full HD LED LCD TV and all connected appliances away from moisture and avoid
dust, heat and direct sunlight. Non-compliance with these instructions can lead to faults
or damage to the Full HD LED LCD TV.
−Do not use the device outdoors as it could be damaged by rain, snow, etc.
−The device must not be exposed to dripping or sprayed water. Do not place vessels filled
with liquid (vases or similar) on or in the vicinity of the device. The container may tip over
and the liquid may impair the electrical safety of the product.
WARNING!
Risk of injury!
There is a risk of injury with candles and other open flames.
− Keep candles and other open flames away from this device at all times in order to prevent the
spread of fire.
−Make sure that there is enough clearance from the sides of the furniture unit. Ensure a
minimum clearance of 10 cm around the device for sufficient ventilation.
−Avoid dazzle, reflections and strong bright-dark contrast in order to protect your eyes.
−The optimal viewing distance is 3 times the screen diagonal.
DANGER!
Risk of injury! Mortal danger!
TVs that are not set up in a stable position could tip over and cause serious injuries or death. Lots of
injuries, especially to children, can be avoided by observing the following safety precautions.
− Operate all components on a stable, level and vibration-free base, to prevent the Full HD LED
LCD TV from falling over.
−Only use the stand supplied with the TV.
−Only use furniture that guarantees the safe use of the TV.
−Ensure that the TV does not hang over the edges of the furniture.
−Do not place the TV on higher or high furniture such as wall cabinets or shelves without
ensuring that both the furniture and the TV are safely and securely held in place.
−In order to guarantee the stability of the TV, do not place any sheets or similar under it.
IMA 21571 Content V2.0.indd 12IMA 21571 Content V2.0.indd 12 29.11.2019 08:53:0529.11.2019 08:53:05

13
Safety instructions
−Advise children of the dangers of climbing up furniture in order to reach the TV or its oper-
ating elements.
If you are storing or moving the TV, also observe the aforementioned safety instructions.
Repairs
−Repairs to your Full HD LED LCD TV should only be carried out by qualified specialists.
−If a repair must be carried out, please only contact our authorised service partner.
−Make sure that only replacement parts provided by the manufacturer are used. The device
may sustain damage if unsuitable replacement parts are used.
Environmental temperature
−The device can be operated at an ambient temperature of +5°C to +35°C with a relative
humidity of 20% - 85% (non-condensing).
−When switched off, the Full HD LED LCD TV can be stored at temperatures from -20°C to
+60°C.
−Keep the product at least one metre away from sources of high-frequency and magnet-
ic interference (television set, loudspeakers, mobile telephones, etc.) in order to avoid
malfunctions.
−During thunderstorms or if the device is not going to be used for long periods, remove the
plug from the socket and the aerial cable from the aerial socket.
NOTICE!
Risk of damage!
Large changes in temperature or fluctuations in humidity can cause moisture to build up due to
condensation within the Full HD LED LCD TV, which can cause an electrical short circuit.
− After transporting the Full HD LED LCD TV wait until it has reached ambient temperature before
switching it on.
Safety when connecting
Power supply
−Even when deactivated, some components of the device are live. To disconnect the Full HD
LED LCD TV from the power supply or to completely isolate the device from voltage sourc-
es, unplug the device completely from the mains.
DANGER!
Risk of electric shock!
There is a risk of death due to an electric shock when the housing is open!
− Do not open the housing of the device. It does not contain any parts requiring maintenance.
−Only plug the AC adapter of the Full HD LED LCD TV into an earthed socket with 220 - 240 V ~
50 Hz. Contact your electricity provider if you are not sure if the socket is earthed or not.
−The power socket must be close to the Full HD LED LCD TV and easy to access.
IMA 21571 Content V2.0.indd 13IMA 21571 Content V2.0.indd 13 29.11.2019 08:53:0529.11.2019 08:53:05

14
Safety instructions
−To disconnect the power supply from your monitor, pull the mains plug from the power
outlet.
−For extra safety, we recommend using an over-voltage protection device to prevent your
Full HD LED LCD TV sustaining damage as a result of power surges or lightning strikes.
−Position the cables so that they cannot be stepped on or tripped over.
−Do not place any objects on the cables as they may be damaged.
All multimedia devices, which are connected to the corresponding ports of the TV, must
comply with the requirements of the Low Voltage Directive.
Handling batteries
WARNING!
Risk of explosion!
Batteries may contain combustible materials and leak, heat up excessively, ignite or even explode.
− Avoid improper handling of the batteries to prevent damage to your device and your health.
Please follow the safety advice below closely:
−Keep batteries away from children.
If batteries are swallowed, consult a doctor immediately.
−Never charge batteries (unless they are designed to be recharged).
−Never empty the batteries by means of high power output.
−Never short-circuit the batteries.
−Never expose the batteries to excessive heat, such as sunlight, fire or similar sources of
heat!
−Do not dismantle or deform the batteries.
You could injure your hands or fingers, or battery fluid could come into contact with your
eyes or skin. If this happens, rinse the affected areas with plenty of clean water and con-
sult a doctor immediately.
−Avoid heavy impacts and vibrations.
−Always observe the correct polarity.
−Make sure that the plus (+) and minus (−) poles are correctly inserted to avoid short
circuits.
−Do not mix up new and old batteries or different types of batteries.
This could cause your device to malfunction. In addition, the weaker batteries would discharge
too much.
−Remove spent batteries from the device immediately.
−Remove the batteries from the device if you do not intend to use it for a long period of
time.
−Replace all of the old batteries in a device with new batteries of the same type.
−Cover the contacts of the batteries with sticky tape if you want to store or dispose of them.
−If necessary, clean the battery and device contacts before insertion.
IMA 21571 Content V2.0.indd 14IMA 21571 Content V2.0.indd 14 29.11.2019 08:53:0529.11.2019 08:53:05

15
Declaration of conformity
Declaration of conformity
MEDION AG herby declares that the product MD 21571 conform to all relevant Australian requirements.
DVD player
The DVD player is a Class 1 laser product. The device has a safety system that prevents dangerous
laser rays from escaping during normal use. To avoid eye injuries, never tamper with or damage
the safety system of the device.
IMA 21571 Content V2.0.indd 15IMA 21571 Content V2.0.indd 15 29.11.2019 08:53:0529.11.2019 08:53:05

16
Overview of the device
Overview of the device
Front
1VOL +/VOL -: Set the volume or navigate in the menu
2CH + /CH -: Select a channel or navigate in the menu
3MENU: Call up the on-screen menu to change settings on your device
SOURCE: Select source
4PLAY: For playing back DVDs
EJECT: Eject button (DVD)
5POWER: Standby button: Switches the device on or into standby mode
6Operating light: Lights up red when the device is in standby mode.
Lights up blue when the device is switched on.
Infrared sensor: Reception field for the infrared signals from the remote control.
7LCD screen
Rear
8VIDEO L-R (AV IN): Audio/video input (RCA)
9USB 5V max. 500mA:
USB connection for connecting an external storage medium for playing back me-
dia / PVR recording
10 HDMI ARC/CEC: HDMI connection for devices with HDMI output
11 RF: Aerial connection (DVB-T/analogue)
12 SPDIF COAX OUT: Digital audio output (coaxial)
13 YPbPr: YPbPr components input (RCA)
14 PC: Connection for connecting a PC
15 PC AUDIO IN: Audio connection for PC sound playback
16 EARPHONE OUT: For connecting headphones with a 3.5 mm jack plug
17 POWER DC 12V 3A: Connector for mains adapter or for car adaptor
18 DVD player
19 Fixing holes for a wall bracket
IMA 21571 Content V2.0.indd 16IMA 21571 Content V2.0.indd 16 29.11.2019 08:53:0629.11.2019 08:53:06

17
Overview of the device
Remote control
20 : Mute
21 ASPECT: Change image format
PROGRAM: DVD: program playlist of the DVD player
22 Number buttons: TV: select channel / Videotext: select page
23 : Set previous TV programme
24 SOURCE: Select input signal of connected devices
25 Direction buttons:
: Move up in menu / Videotext: select the next page.
: Move down in menu / Videotext: select the previous page.
: Move left in menu / Videotext: call up subpages.
: Move right in menu / Videotext: call up subpages.
26 INFO: For displaying information, such as current programme number and image format
27 EPG: Digital magazine for television programmes and radio programmes (depending on broadcaster)
A-B: Media browser: repeat A-B / DVD: set Repeat A-B
28 VOL+/-: Increase (+) or decrease (−) volume.
29 USB: Open media browser
30 Colour buttons / Buttons for operating the media browser/DVD player/PVR recording:
: Rewind; RED: Intended for use in certain menus
: Start/pause playback
: Fast forward; GREEN: Intended for use in certain menus
: Previous title; YELLOW: Intended for use in certain menus
: Stop playback
: Next title; BLUE: Intended for use in certain menus
: DVD: Eject button
31 LIST: Open channel list
SEARCH: DVD: for selecting a desired section on a DVD
32 REPEAT: Select the repeat play mode in USB mode
T-SHIFT: Start/stop timeshift recording. This function is only available in DTV mode and with connected USB
flash memory
33 SETUP: DVD: open the menu
REC: Start PVR recording
34 AUDIO: DVD: Set stereo/mono sound format
: DTV: Select the sound type
35 : Call up favourites list
ANGLE: DVD: select camera position (viewing angle) in the DVD playback
36 SUBTITLE: DTV/media browser: subtitle function / DVD: subtitle function for the DVD player
37 CH+/-: Programme selection buttons
38 EXIT: Exiting the menu
39 ENTER: Confirm selection in certain menus. Also used to open the channel list
40 MENU: Open and close menu
41 PICTURE: Select picture mode
SLOW: DVD: slow motion function for DVD player
42 SOUND: Select sound mode
ZOOM: DVD: zoom function for the DVD player
IMA 21571 Content V2.0.indd 17IMA 21571 Content V2.0.indd 17 29.11.2019 08:53:0629.11.2019 08:53:06

18
Operation
43 : POWER: i.e. switch Full HD LED LCD TV on/off (switch standby mode on/off).
Operation
Unpacking
− Select a suitable place for setting up the device.
− Open the box very carefully to avoid damaging the device. The device could be damaged if you use a knife
with a long blade to open the box.
− The box contains a number of small items (including batteries). Keep these out of the reach of children as they
represent a choking hazard.
Store the packaging material in a safe place; always use this box to transport the television.
DANGER!
DANGER!
Risk of suffocation!
Packaging film can be swallowed or used improperly. Therefore, there is a risk of suffocation!
− Keep packaging material such as plastic film or plastic bags away from children.
Installation
Attach the stand as shown in the illustration. Carry out this step before connecting up the Full HD LED LCD TV.
ST3 x 8 4PCS
− Place a soft cushioned material on top of a flat surface to prevent damaging the screen panel. Then place the
Full HD LED LCD TV flat on top, with the screen side facing down, as illustrated.
− Align the screw holes on the stands and the bottom of the Full HD LED LCD TV, as illustrated with arrows.
Tighten the screws (supplied) with a screwdriver to affix the stands to the panel.
IMA 21571 Content V2.0.indd 18IMA 21571 Content V2.0.indd 18 29.11.2019 08:53:0629.11.2019 08:53:06

19
Installation
NOTICE!
Risk of damage!
Do not apply excessive force as this may damage the screw holes.
Inserting the batteries in the remote control
− Remove the battery compartment cover on the back of the remote control.
− Insert two AAA 1.5 V batteries in the battery compartment of the remote control. Check the battery polarity
(inscribed on the bottom of the battery compartment).
− Close the battery compartment.
NOTICE!
Risk of damage!
Remove the batteries from the remote control if the device is not going to be used for a long peri-
od. The remote control could be damaged by leaking batteries.
Connecting the antenna
Your Full HD LED LCD TV supports different antenna signals. You can input the following image signals to the televi-
sion through the connection labelled RF 11 :
• via analogue cable / an analogue house antenna,
• via a DVB-T1antenna or
• via a DVB-C*connection
− Insert the antenna cable either from the house antenna /analogue cable connection, a DVB-T antenna or the
DVB-C connection into the antenna connection on the Full HD LED LCD TV.
Connecting the mains adapter
− Insert the jack plug on the supplied mains adapter into the POWER DC IN socket 17 on the device.
− Connect the mains plug on the device to an easily accessible 100 - 240 V ~ 50 Hz mains socket.
NOTICE!
Risk of damage!
Using a different mains adapter may damage the device.
− Only use the supplied mains adapter.
Switching the Full HD LED LCD TV on and off
− The device will be in standby mode as soon as you have connected the mains plug with the mains socket.
− In order to switch on the device, press
- on the remote control: the Standby/On button 43 ;
- on the device: the POWER button 5.
− You can switch the device back into standby mode using the Standby/On button on the remote control (or
the POWER button on the device). Although the device has been switched off, it will continue to consume
electricity.
If the device is not receiving an input signal, it will automatically switch to standby mode
after five minutes. A countdown timer will appear on the screen until this time. This func-
tion is not available for all sources.
1This service must be available in your region
IMA 21571 Content V2.0.indd 19IMA 21571 Content V2.0.indd 19 29.11.2019 08:53:0729.11.2019 08:53:07

20
Installation
Use of the multimedia connections
NOTICE!
Risk of damage!
Incorrect operation can lead to damage to the equipment used.
− Before wiring and use, also read the operating instructions of the devices you are connecting.
NOTICE!
Risk of damage!
If plugs and sockets are connected incorrectly it can cause damage to the contacts.
− Ensure that the plugs and corresponding sockets fit together precisely in order to avoid any
damage to the contacts. Due to the arrangement of the contacts, the plug will only fit into the
socket in one position.
AV
AV transmission (composite) works via three RCA jacks in which one carries the video signal (yellow) and two carry
the stereo audio signal (red/white). Use a commercially available AV cable.
− Connect the AV inputs and outputs of the equipment with an AV cable.
− If any of the connected devices have AV connections to mini jack, please use an appropriate AV adapter (3x
RCA > mini jack) (optional).
YPbPr
YPbPr transmission (component) works via five RCA connections in which three jacks carry the video signal (red/
blue/green) and the remaining two jacks carry the stereo audio signal (red/white). Use a commercially available
YPbPr cable.
− Connect the YPbPr inputs and outputs of the equipment with a YPbPr cable.
− If any of the connected devices have YPbPr connections to mini jack, please use an appropriate YPbPr adapter
(5x RCA > mini jack) (optional).
HDMI
HDMI (high definition multimedia interface) is an interface for digital video and audio transmission. It has the
highest quality of transmission and can also play Ultra HD resolution (from version 2.0). Use a commercially availa-
ble HDMI cable.
− Connect the corresponding HDMI ports of the devices used with an HDMI cable.
USB
A USB port can be used to connect and read storage media such as USB sticks or external hard drives. Use a suita-
ble USB cable. If a suitable USB cable is included in delivery, you should use this (e.g. for hard drives).
− Connect the corresponding USB ports of the devices used with a USB cable. Whenever possible, do not use a
USB extension cord as this can cause problems (depending on the voltage).
SPDIF
SPDIF (Sony®/Phillips digital interface) is an interface for transferring digital stereo or multi-channel audio signals
between various devices. Usually, the digital audio signal is output via a coaxial (RCA) or an optical connection. Use
a suitable, commercially available cable.
− Connect the SPDIF ports of the devices used with a corresponding SPDIF cable.
IMA 21571 Content V2.0.indd 20IMA 21571 Content V2.0.indd 20 29.11.2019 08:53:0729.11.2019 08:53:07

21
Installation
VGA (PC)
Using the VGA port, you can connect a PC with a monitor/TV set to transmit the video signal. Use a commercially
available VGA cable.
− Connect the VGA ports of the devices used with a VGA cable.
VGA audio (PC AUDIO IN)
If you have connected a PC to a monitor/TV via the VGA port, the VGA audio connection also allows audio transmis-
sion. Use a commercially available stereo mini jack cable.
− Connect the VGA audio ports of the devices used with a stereo mini jack cable.
Headphone out
The headphone socket is used for connecting a pair of headphones with a stereo mini jack connection.
− Connect the headphones to the stereo mini jack of the device. On some devices, this will mute the speakers.
− Otherwise, you should perform all necessary settings in the sound menu to coordinate the speaker and head-
phone signals.
CAUTION!
Risk of hearing damage!
To prevent possible damage to your hearing, avoid listening at high volume over long periods of time.
− Before pressing play, set the volume to the lowest setting.
− Start playback and increase the volume to a comfortable level.
IMA 21571 Content V2.0.indd 21IMA 21571 Content V2.0.indd 21 29.11.2019 08:53:0829.11.2019 08:53:08
