Medisoft 870 a User manual

Treadmillmod.870A,870S, 870C

USER’S MANUAL

This Manual should be carefully read in all of its parts, before starting to

operate the treadmill

REV. 1/01.07.2019

This manual has been carefully written and checked.

Nevertheless no responsibility is assumed for

possible inaccuracies.

document may be reproduced or transmitted in any

form or by any means without the written permission

of Medisoft RAM Italia S.r.l.

The Medisoft RAM Italia S.r.l. company is committed

to a policy of constant improvement in compliance to

Norm ISO EN 9001:2001 requirements, and as a

function of feedback from customers and the market

in compliance to norm ISO EN 13485:2004. As a

consequence, the company reserves the right to

make changes to this document and to the products

described herein without notice.

Validity date : 11.04.2018

© Medisoft RAM Italia S.r.l.. All rights reserved.

TABLE OF CONTENTS

Treadmill Mod. 870 A, 870 S and 870 C



1Introduction to the Equipment..........................................................................................................4
1.1 ABOUT THIS MANUAL ...........................................................................................................4
1.2 INTENDED USE......................................................................................................................4
1.3 PRECAUTIONS........................................................................................................................5
1.4 MANUFACTURER LIABILITY RESTRICTIONS. ....................................................................5
1.5 SAFETY REGULATIONS........................................................................................................6
1.6 ELECTROMAGNETIC COMPATIBILITY ................................................................................8
1.7 IDENTIFICATION PLATES ..................................................................................................11
1.8 SAFETY PLATE.....................................................................................................................12
1.9 MAIN PARTS IDENTIFICATION ...........................................................................................13
2Packing, transport, storage and delivery........................................................................................16
2.1 PACKING...............................................................................................................................16
2.2 TRANSPORT.........................................................................................................................16
2.3 STORAGE .............................................................................................................................16
2.4 DELIVERY AND CLAIMS......................................................................................................17
3Installation......................................................................................................................................18
3.1 INSPECTION ........................................................................................................................18
3.2 CONFIGURATION.................................................................................................................18
3.3 MOUNTING ...........................................................................................................................19
3.4 MOVING.................................................................................................................................22
3.5 PRECAUTIONS.....................................................................................................................22
3.6 VERIFICATION OF SPEED PARAMETERS..........................................................................24
4Patient secutiry...............................................................................................................................24
4.1 EMERGENCY STOP BUTTONS ..........................................................................................24
5Maintenance...................................................................................................................................26
5.1 PRECAUTIONS.....................................................................................................................26
5.2 ROUTINE MAINTENANCE....................................................................................................26
5.3 NON-ROUTINE MAINTENANCE ..........................................................................................29
6Disposal..........................................................................................................................................30
7Treadmill model 870 A technical specifications .............................................................................31
8Treadmill model 870 S technical specifications .............................................................................32
9Treadmill model 870 C technical specifications.............................................................................33

ANNEX A - Symbology..........................................................................................................................34
ANNEX B - RS232 Serial Port...............................................................................................................35
ANNEX C - Tap-Tst program ................................................................................................................36
ANNEX D –Troubleshooting.................................................................................................................37














TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

WARNING

NO ACCIDENTALLY REBOOT SECURITY SISTEM

If the tension of the treadmill is taken off by one of this methods:

•Pushing the red emergency button

•Switch off the mains

•Pulling off the safety lanyard

Wait at least 30 seconds

Before give tension to the treadmill by this operations:

•Rotate to pull up the red emergency button

•Switch on the mains

•Put on the rubber cup of the safety lanyard

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

1 Introduction to the Equipment

Congratulations on your purchase of a new Treadmill 800 Series. This state-of-

the-art equipment represents the best current technology in Fitness, Sports

Applications, and Cardiorespiratory Diagnostic Exercise Systems.

1.1 ABOUT THIS MANUAL

This manual covers all aspects of the installation, operation and maintenance of

the 870 A, 870 S and 870 C Treadmills. It provides the necessary instructions to

guarantee correct and safe operations.

This manual should be kept with the treadmill at all times.

If you have a question regarding the operation or maintenance of the treadmill,

consult the manual first. If your question remains unanswered, please call the

Manufacturer, directly.

1.2 INTENDED USE

These treadmills have been specifically designed to be used in connection to a

variety of medical applications such as motor function, rehabilitation programs,

breathing and stress tests, and cardiorespiratory diagnostic exercise systems.

Used as indicated, the treadmills can be considered as supplementary

components for diagnostic purposes, and must be handled and maintained

under supervision by adequately qualified personnel. Typical environments for

these treadmills are outpatient cardiologic clinics, hospital wards and outpatient

departments for motor function rehabilitation.

The extraordinary versatility of these treadmills allows them to be used by a

wide range of people that wish to enjoy daily use of a treadmill for general

fitness purposes, progressive muscle exercises, and weight control.

The treadmill allows you to exercise in a safe environment, with adequate

space, and with simple fingertip control of all important parameters, including

speed.

Use of a treadmill eliminates many of the risks associated with outdoor

exercise. Most importantly, there is no risk of muscular trauma caused by the

asperity of the ground, because of the shock-absorbing deck. It also avoids

problems and inconveniences associated with climatic conditions and air

pollution.

These instruments were specifically designed to be compatible with other

Manufacturer’s Cardiorespiratory Diagnostic Exercise Systems, and for use in

Motor Rehabilitation Centres. In such configuration the treadmill becomes a

passive device of a diagnostic system and can be used by adequately qualified

personnel only.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

1.3 PRECAUTIONS

During medical procedures such as cardiac stress tests, pulmonary function tests,

or motor rehabilitation therapies, the use of models 870 A, 870 S and 870 Cmust

be supervised and carried out by adequately qualified medical personnel.

•Stress test exercises must be performed under medical supervision and

with the assistance of qualified nursing staff. Furthermore the working area

must be equipped with all first aid instruments to be able to face potential

emergencies.

•During rehabilitation therapies, patients must be followed and kept under

supervision by adequately qualified personnel

During sport activities, the use of treadmill models 870 A, 870 S and 870 C is

strictly forbidden to the following category of people:

•Children under 14 years of age.

•People suffering from a heart condition.

•People suffering from kidney problems.

•Women with gynaecological problems.

•Pregnant women, later than six months.

•People with evident condition of overweight

•Diabetics.

•People without adequate medical certification of their qualification for sports

activities.

1.4 MANUFACTURER LIABILITY RESTRICTIONS.

The treadmills mod. no. 870 A, 870 S and 870 Care in compliance to all norms

applicable. The Manufacturer will not accept liability for any personal injury or

damage to belongings, if equipment is not used as intended, and according to

regulations in this User’s Manual.

Norms compliance can be violated by:

•use not in compliance with intended use as established by Manufacturer

•Failure to observe operating instructions

•Tampering or alterations improperly made by end user or by non-authorized

personnel

•Use of non-original spare parts, or parts not authorised by the

Manufacturer.

•Electrical system (where equipment will be used) in non-compliance with

safety norms and relative statutes

•Failure to observe routine maintenance norms.

•Using the equipment outdoors, or in inadequately protected or unhealthful

conditions or environments.

•Medical or therapeutically use of the equipment by personnel who is not

adequately qualified.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

Non-compliance with any of the above warnings and cautions exempts the

Manufacturer from any responsibility for any accident or damage derived from

non-compliance.

1.5 SAFETY REGULATIONS

WARNING !

Incorrect use of this equipment may cause injury. Please ensure that the

safety regulations listed below are strictly observed:

1. Read this User Manual and the plates attached to the underside of the

treadmill hood carefully. Before operating the treadmill ensure you are

completely familiar with the control panel and its key functions.

2. Before connecting any equipment or device to a network, insure that this is

compatible with input voltage for device operations (230 Vac, 50 –60 Hz). A

lower input voltage, below values indicated on plate, would result in uneven

performance of treadmill, particularly at lower speeds.

3. Medical procedures such as cardiac stress tests, pulmonary function tests, or

motor rehabilitation processes are only to be carried out by adequately

qualified medical personnel.

4. Before beginning any exercise program check with your doctor to determine

your present physical condition and ability to undertake aerobic exercise. This

is especially essential for people suffering from abnormal blood pressure,

smokers, people addicted to stimulants, or taking other medication, people

suffering from cardiovascular disease, or those at risk of hereditary

cardiovascular disease.

5. During exercise, it is important to wear adequate shoes and clothing. Avoid

shoes with leather soles, heels, anti-slip strips, and spikes. The most

appropriate shoes are gym shoes with a soft rubber sole.

6. Do not step onto the running belt without shoes.

7. Do not put drinks or other liquids on or near the treadmill.

8. Do not leave clothing or towels on or near the treadmill. Such items may

seriously interfere with the moving parts of the equipment.

9. Do not scratch the plastic control panel of the treadmill with sharp objects such

as pens or screwdrivers.

10.Before moving the treadmill, make sure that the power switch is OFF, and it is

unplugged from the mains power outlet.

11. If, for any reasons it becomes necessary to move the equipment, you must

insure that the equipment power switch is turned off and that the equipment is

unplugged and rendered inoperable, before moving the equipment. If the

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

equipment is moved to a different environment double-check that this is

compatible with input voltage for device operations (230 Vac, 50 –60 Hz)

before connecting it to the network.

12.Ensure the treadmill is positioned well away from sources of water such as

drinking fountains. Do not pour any kind of liquid on the equipment.

WARNING !

If any kind of liquid should filter through the equipment, perform the

following:

•stop using it immediately

•disconnect the device from the mains power

•let skilled technicians check the device before using it again

13.Ensure the treadmill is positioned well away from heat sources such as

radiators.

14.Do not use the treadmill outside, or in areas exposed to external conditions

such as direct sunlight or rain.

15.Do not use the treadmill near an inflammable gas source.

16.Do not pull the power cord or the equipment itself in an attempt to remove the

plug from the outlet.

17.Do not try to move equipment by pulling the power cord.

18.Do not allow children, mentally or physically disabled people to use the

treadmill, unless under the direct supervision of adequately qualified personnel.

19.Always step onto the running belt facing forward (toward the Control Panel).

Assume a normal walking posture and hold the lateral handrails.

20.Do not put your hands, feet or any other object under the treadmill while the

equipment is in motion.

21.Ensure the treadmill has been thoroughly checked prior to use. Do not operate

the equipment if the power cable or plug is damaged. If you suspect the power

cable or plug is malfunctioning, set the power switch to OFF, remove the plug

from the mains outlet and call the authorised dealer.

22.Ensure the area surrounding the treadmill is clean, dry, and dust-free at all

times.

23.Do not remove the treadmill hood. This should only be carried out by

authorised service personnel.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

WARNING !

Medisoft RAM Italia S.r.l. takes no responsibility for any accidents or

any damages caused to people or things due to a connection of the

treadmill to an electric outlet in non-compliance with current laws and

safety norms.

1.6 ELECTROMAGNETIC COMPATIBILITY

This device was designed and built to meet all the requirements and standards

of Norm EN 60601-1-2 and was found in compliance with all such norms and

standards.

EN 60601-1-2: Medical electrical equipment - Part 1: General requirements for

safety –Collateral standard: Electromagnetic compatibility –Requirements and

tests.

Nevertheless, in particular conditions, some interferences may arise. In order to

insure that the equipment operates correctly and performs as expected, the

Manufacturer invites the end user to focus attention on all special features of

the equipment discussed so far, and all that will follow, including all warnings

and recommendations that are often indicated by visually understandable

“warning” and “caution” tags.

It is the client/customer/end user’s responsibility to handle the equipment in

such a way as to be in full compliance with all indications provided by the

Manufacturer, in order to insure that the equipment will perform as expected

and guarantee safety as it operates in compliance with intended use.

The client/customer/end user must keep in mind that the utilisation of wireless

portable devices (such as cellular phones, cordless phones, walkie-talkies) can

interfere with operating functions of the equipment itself. To avoid

electromagnetic interferences it is important to keep a safe minimum distance

between the portable and RF communication devices and the treadmills model

no. 870 A, 870 S and 870 C, as recommended in the following Table 1 -

Immunity to RF.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

Table 1 - RF immunity –Distance calculation for non-life-support equipment

Other equipment or devices can be a source of interference, or can be susceptible

to interference from a nearby noise source, such as TV broadcasts, speakers,

microwave ovens and other radio communication devices.

WARNING !

To avoid interferences between equipment and devices, we recommend

that the equipment be used at an adequate distance from such devices.

CAUTION

If it becomes necessary to use the equipment near other devices one must closely

observe its performance to check if the setup in which it is used, allows it to

perform at normal operational level.

CAUTION

•When connections are made to the RS 232 port, one should be very careful

as to avoid touching the pins of the connectors themselves.

•Before making any connections, we suggest using all ESD elementary

cautionary procedures: discharge the accumulated static electricity by

touching a conducting metal part connected to the ground protection of the

electrical system. As an alternative, touch a metallic part of a very wide

surface.

•When making any connections double-check that both devices or equipment

to connect are turned off.

Recommended separation distances between portable and mobile RF communications equipment and

the 870 A / 870 S /870 C treadmills

The treadmill model no. 860 A / 870 A is intended for use in an electromagnetic environment in which radiated

RF disturbances are controlled. The customer or the end user of the equipment can help prevent

electromagnetic interference by maintaining a minimum distance between portable and mobile RF

communications equipment and the treadmill model no. 870 A / 870 S / 870 C as recommended below,

according to the maximum output power of the radio communications equipment.

Rated maximum

output power of

transmitter (W)

Separation distance according to frequency of transmitter m

150 KHz to 80 MHz

Pd = 35.0

80 MHz to 800 MHz

Pd = 35.0

800 MHz to 2.5 GHz

Pd = 7.0

0.01

0.035

0.07

0.1

0.11

0.22

.35

0.7

1.1

2.2

100

3.5

For transmitters rated at a maximum output power not listed above, the recommended separation distance d in

meters (m) can be determined using the equation applicable to the frequency of the transmitter, where P is the

maximum output power rating of the transmitter in watts (W) according to the transmitter Manufacturer.

NOTES:

• At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.

• These guidelines may not apply in all situations. Electromagnetic propagation is affected by

absorption and reflection from structures, objects, and people.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

•Always and only use the cables provided by Manufacturer. The use of any

cables, different from the original, can result in a raise in emissions or a

decrease in immunity.

•The cables sold by the Manufacturer as spare parts are exempt from the

above cautionary statement.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

1.7 IDENTIFICATION PLATES

The identification plate is located on the underside of the treadmill hood.

Legend

The structure of the serial number is as follows:

where:

pr pr pr: progressive production number referring to the year

S indicates the model of the treadmill

a a a a: indicates the year when the item was manufactured

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

1.8 SAFETY PLATE

The safety plate is located below the power switch. It reminds users to set the

power switch to OFF and remove the plug from the mains outlet before

removing the treadmill hood.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

1.9 MAIN PARTS IDENTIFICATION

1 Front handrail

2 Angular covers

3 Lateral handrail

4 Red stop switch

5 Treadmill hood

6 Anti-skid tape

7 Running belt

8 Back roller

1.9.1 MODEL 870 A / 870 S / 870 C

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

1.9.2 HANDRAILS SPECIFICATIONS

RED STOP SWITCH:

Red stop switch

Safety lanyard

In case of emergency, by pressing this

button completely take the mains in the

treadmill.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

SAFETY LANYARD

WARNING !

CLAMP THIS CLIPS TIGHT ON VEST

WARNING !

DISENGAGE ALL STOP SWITCHES AFTER 30 SEC.

By a clip is attached to the patient, in case

of patient fall, it is completely switched off

the mains in the treadmill.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

2 Packing, transport, storage and delivery

2.1 PACKING

When transporting the treadmill for significant distances, always use the original

packaging of the Manufacturer. Fix the treadmill firmly to the provided wooden

pallet, using the wood shafts nailed to the pallet. Fix the supplied carton over

the treadmill to the pallet with appropriate plastic strips.

2.2 TRANSPORT

A forklift must be used to lift the pallet with the treadmill. Always lift the pallet

from the bottom; arrows on the carton indicate the correct position of the pallet

on the forklift.

WARNING !

Do not put heavy packages on top of the carton. This may cause

damage to mechanical and electronic parts of the treadmill.

Transport the treadmill with care and do not subject it to any kind of mechanical

shock.

2.3 STORAGE

When not in use, we recommend you store the treadmill in its original carton, on

its original wooden pallet. The environmental conditions should be in the range

-10 °C to 60 °C, with a maximum humidity of 90%. Keep the treadmill free from

dust, and away from direct heat and sunlight, in environments that are

•dust-free and/or charged with ionising agents and/or with high humidity rate

•free of frequent or sudden changes in temperature, moisture and

atmospheric pressure.

•not subject to continuous vibrations.

Storage conditions

1. Allowed temperature range: from -10oC to + 50oC.

2. Maximum relative humidity allowed: below 90%, without moisture.

WARNING!

Do not leave the equipment exposed to sunlight, rain or other

atmospheric agents.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

Precautions when equipment is not in use

When the equipment is left unused for long periods of time, the following steps

should be followed:

•Turn off the equipment, cut off the electricity by pulling the plug from the mains,

wind the cable, and lay it on the treadmill belt.

•disconnect any other device (e.g. a PC connected via a serial port).

•clean the equipment following the instructions specified in paragraph 5.2.1.2.

Dry or let the equipment dry before covering it.

•Carefully cover the equipment with adequate means, so as to avoid dust,

moisture or the infiltration of other atmospheric agents that might be present in

the environment where equipment will be stored. The environment should meet

specifications as indicated in paragraph 2.3.

•protect the cables from dust, moisture, sunlight and from heat sources by

storing them in adequate containers or in a cabinet.

WARNING!

Before covering the equipment make sure that the equipment is dry.

Before reusing the treadmill

•Verify that the equipment and all accessories are in perfect conditions, state of

preservation and cleanliness. If all is verified to be in excellent state, act

accordingly.

•Start the equipment by switching the power on, and let it work for about an

hour. This procedure allows the equipment to reach operating temperature,

favouring the elimination of any moisture that might have formed inside the

equipment.

•During this period, it is possible to verify that the equipment functions properly.

2.4 DELIVERY AND CLAIMS

Do not unpack the equipment immediately.

Verify that the number of cartons received equals the number listed on the

delivery note. Verify that the packaging is original, and the treadmill is on its

original wooden pallet. Inspect the packaging for external damage.

It is important to itemise any discrepancies on the waybill and have it signed by

the carrier's agent. Failure to adequately describe external evidence of loss or

damage may result in the carrier refusing to honour your claim.

If damage is discovered after the waybill is signed, contact the carrier’s agent

immediately by telephone, and in writing. Request an inspection, and a copy of

the inspection report.

If damage is discovered do not discard the packaging materials until all checks

have been made by the Medisoft RAM Italia representative. Upon being

notified that you have received the equipment, a qualified Medisoft RAM Italia

representative will visit your premises. They will unpack your equipment, check

for internal damage or missing items, and then assemble it according to the

directions of our Technical Service department.

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

3 Installation

3.1 INSPECTION .

The treadmill is delivered to the customer in its original carton, and is securely

fixed to a wooden pallet by means of plastic strips. The carton is fixed to the

wooden pallet with nails.

A forklift must be used to lift the pallet with the treadmill. Always lift the pallet

from the bottom; arrows on the carton indicate the correct position of the forklift.

If a forklift is not available, four people are required to lift the treadmill with its

wooden pallet.

WARNING !

When opening the carton, it is necessary to wear protective gloves to

avoid injury.

1. Remove all the nails from the wooden pallet using a proper pincer.

2. Ensure you remove them all to avoid injury.

3. Lift the carton from the wooden pallet. This will require more than one

person.

4. If it is likely that you will want to move the treadmill a significant distance at a

later date, ensure that the carton is carefully folded and stored for this

purpose. If not, dispose of it properly.

5. Cut the three plastic strips attaching the treadmill to the wooden pallet with

scissors.

WARNING !

Do not leave the packaging within reach of children. Dispose of it

according to current regulations governing waste disposal.

3.2 CONFIGURATION

The treadmill configuration is composed by a 800 series device (mod. 870 A,

870 S or 870 C), a RS 232 serial cable and a technical CD.

Verify the presence of the following material, inside the box of the standard

accessories :

1 RS232 cable (no. 1)

2 CD ROM containing Tap_Tst program, user and service manual

TREADMILLS MOD. 870A/870S/870C

Rev.1/01.07.2019

3.3 MOUNTING

Three people are required to lift the treadmill from its wooden pallet. It is

recommended that two people lift the treadmill from the hood end, the third near

the end roller.

WARNING!

Do not try to use the treadmill on the pallet. When lifting the treadmill, lift

it from the lateral frames of the body. Do NOT lift it from the plastic hood,

or from the back roller. Failure to comply with this recommendation may

result in damage to the equipment.

Once the treadmill is removed from the crate, it can be moved to the exercise

area by rolling it on its front wheels. If it is necessary to move the treadmill over

a rough surface (for example a pavement), use a trolley to avoid damage to the

wheels. Position the treadmill on a smooth, level, stable surface. Ensure the

weight capacity of the surface is adequate for both the treadmill, and the

additional weight of the user. Short pile, industrial carpet is acceptable. The

front wheels must be free and not restricted to ensure that the treadmill can

incline correctly. Do not place the treadmill on thick or long pile carpet. If

necessary, place a metal or hard plastic plate under the front wheels to ensure

stability.

Eventually, to put the treadmill in a horizontal position, you can adjust the height

of the back support feet of the treadmill.

This manual suits for next models

Table of contents

Other Medisoft Treadmill manuals

Medisoft

Medisoft 800 Series User manual

Medisoft

Medisoft 800 Series User manual

Popular Treadmill manuals by other brands

Precor

Precor 9.55 manual

NordicTrack

NordicTrack CMX500 user manual

Reebok

Reebok ZR8 Assembly guide

Woodway

Woodway ST PPS 43 Plus operating manual

NordicTrack

NordicTrack T12 Si Cwl Treadmill Manual Del Usuario

Precor

Precor 9.31 Service manual

Finnlo

Finnlo 3513 manual

BLADEZ

BLADEZ ST7i owner's manual

NordicTrack

NordicTrack S 30 user manual

Weslo

Weslo 225 Gtx Treadmill user manual

FitnessBaza

FitnessBaza A10TS operation instruction

Stamia

Stamia InMotion II owner's manual

Schwinn

Schwinn 830/Journey 8.0 Assembly manual / owner's manual

Keys Fitness

Keys Fitness HealthTrainer HT-740T owner's manual

Weslo

Weslo Cadence 4.9 Ery Treadmill manual

NordicTrack

NordicTrack Elite 4000 user manual

Master

Master F-03 user manual

Precor

Precor C954 owner's manual

Medisoft 870 A User manual

Popular Treadmill manuals by other brands
