Introduction and Intended Use
This instruction manual provides important information about the automatic digital blood
pressure monitor MDS1001 Series. This device is intended to measure the systolic and
diastolic blood pressures and pulse rate of an adult individual by using a non-invasive
technique, in which an inflatable cuff is wrapped around the upper arm.
Please read all of these instructions carefully, before using the monitor.
IMPORTANT NOTES
• Only a physician is qualified to interpret changes in your blood pressure.
This device is not intended to replace regular medical examinations.
• It is recommended to have your physician review your procedure for using this monitor.
Never make adjustments to your medication unless recommended by your physician.
• This Blood Pressure Monitor is intended for use by adults.
Children should not use this monitor unless it is under the supervision of an adult.
• Only use the cuff(s) included with this device or offered as approved accessories.
Unapproved cuffs can affect measurement accuracy.

4
Symbol Identification
The following symbols may appear in this manual, onthe blood pressure monitor, or on its accessories.
Important Safety Information
Warning
• Consult with your physician before using this device on an arm where intravascular access,
therapy, or an arteriovenous shunt is present because of temporary interference to blood
flow which could result in injury.
• Consult your physician before using this device if you have had a mastectomy.
• Too frequent measurements can cause injury due to blood flow interference.
• Do not apply the cuff over a wound, as it can cause further injury.
Warning
Type B: Identifies applied part complying with IEC 60601-1.
Class II
Refer to instruction manual
Disposal: Do not dispose this product with household waste.

5
• Do not kink the cuff hose, as this may cause the cuff pressure to continuously increase,
which can interfere with blood flow and result in injury.
• Do not inflate the cuff on the same limb to which other monitoring medical electrical
(ME) equipment is applied. This can cause temporary loss of function of the monitoring
ME equipment.
• Make sure that operation of this device does not result in prolonged impairment of
blood circulation.
Measurement Accuracy
The quality of the device has been verified and conforms to the provisions of the EC-Council
directive 93/42/EEC as well as the EMC directive 89/336/EEC:
EN 1060-1
Non-invasive blood pressure measuring equipment. General requirements
EN 1060-3
Non-invasive blood pressure measuring equipment. Supplementary requirements for
electro-mechanical blood pressure measuring system
EN 60601-1
Safety requirements for medical electrical equipment
EN 60601-1-2
Electromagnetic compatibility and safety for medical electrical equipment
EN 14971
Risk analysis for medical devices in accord with requirement in section 21 of CMDR’S

6
Helpful Information about Blood Pressure
What is Blood Pressure?
Blood pressure is the force that blood exerts on the arteries. This force is constantly changing
as the heart beats. When the heart contracts, blood pressure reaches its highest value. This
is called systolic blood pressure. When the heart relaxes between beats, the value of blood
pressure is lower. This is called the diastolic blood pressure. The unit of measure for blood
pressure is millimeters of mercury, abbreviated mmHg. For example, an individual’s blood
pressure may be measured as 120 mmHg (systolic) and 80 mmHg (diastolic). This would be
spoken as “120 over 80” and written as “120/80”.
What Affects Blood Pressure?
Blood pressure can be affected by the following factors: eating, drinking alcohol or
caffeine, smoking, stress, exercise, physiologic condition, measurement site, body position,
temperature, humidity, altitude, and many other factors.
Remember that blood pressure can also vary throughout the day. It is important to take
measurements at the same time each day, and under the same conditions.

7
Typical Daily Blood Pressure Fluctuations
What is High Blood Pressure?
Hypertension, or high blood pressure, is a condition where an individual’s blood pressure
remains high over a long period of time. Consult with your physician with any questions or
concerns you may have about hypertension.
Example: 35-year-old male

8
Blood Pressure Classification
The World Health Organization (WHO) and the International Society of Hypertension (ISH)
Monitor Pressure Gauge and Indicator
The pressure gauge allows quick detection of your blood
pressure classification. The indicator displays a segment,
based on your measurement, corresponding to the WHO and
ISH classification.
Note: The pressure gauge indicator is approximate. Please
consult your physician to interpret your blood pressure
measurements.
+-+-
+
-+
-
SYS
mmHg
DIA
mmHg
Pressure
Gauge
Indicator
Pressure
Gauge
Blood Pressure Classification Systolic (mmHg) Diastolic (mmHg)
Optimal Less than 120 Less than 80
Normal 120-129 80-84
High - Normal 130-139 85-89
Hypertension - Stage 1 140-159 90-99
Hypertension - Stage 2 160-179 100-109
Hypertension - Stage 3 180 or Higher 110 or Higher

9
Why is it Importantto Measure Your Blood Pressure at Home?
Having your blood pressure taken at the doctor’s office may cause you to become nervous,
thus artificially raising your reading. Having the ability to take your blood pressure at
home makes it easy to record a log of your daily readings. This will help you gain a greater
understanding of your blood pressure reading and the factors that affect it. Be sure that you
share your information with your physician.
Hints forAccurate Measurement
1. Relax and try to remain still for 5 to 10 minutes before a measurement.
2. Remove any clothing on the upper arm so that the cuff can be placed directly on the skin.
Constricting garments may cause an inaccurate reading.
3. Perform measurements on the same arm (preferably the LEFT arm).
4. Refrain from eating, smoking and drinking (especially alcoholic beverages) before a
measurement. These activities can affect your blood pressure.
5. Remember that blood pressure varies continuously throughout the day.
Try to take your blood pressure at the same time each day.
6. Do not be concerned with the results of one measurement. Many measurements, recorded
over an extended period of time, will provide a better indication of your blood pressure.
7. Relax for 5 to 10 minutes before taking another measurement.
8. Because many factors can affect your blood pressure,daily fluctuations of 25 to 50 mmHg
are common.

10
Please Note:
Some individuals with hypertension, diabetes, kidney disorders, arteriosclerosis or poor
circulation may see a significant difference in blood pressure readings taken from the wrist
as compared to readings from the upper arm. It is recommended that you consult with your
physician concerning the use of this monitor.
Correct Method of Measurement
To obtain the most accurate blood pressure measurement, please follow these important
directions:
1. Sit comfortably in a chair with your back supported. Place both feet flat on the floor and
keep your legs uncrossed.
2. Rest your left arm on a table and position your palm upwards.
IMPORTANT: The arm cuff must be at the same level as your heart, or accurate
measurement will not be possible. (Your heart is located slightly below your left armpit.)
3. Remain still, avoid moving or talking during the measurement.
Feet Flat on Floor Position Arm at Heart Level Avoid Moving or Talking
+-+-
+
-+
-
SYS
mmHg
DIA
mmHg
+-+-
+
-+
-
SYS
mmHg
DIA
mmHg
+-+-
+
-+
-
SYS
mmHg
DIA
mmHg
