Operating Manual
Hyperion 907
High Voltage Power Supply
v1.15B

Products shown in this document may be covered by one or more patents, patents applied for
and/or registered designs and/or trade marks. For further information please refer to our Head
O󰀩ce or visit www.meech.com.
© Meech Static Eliminators Ltd. 26.10.2017
Contents
Introduction 3
Input Voltage and Connection 4
Installation 5
Ionising Equipment Connection 6
Fault / Diagnostic Check 11
Repairs And Warranty 15
Maintenance 16
CE Approval 16

3
Introduction
The Meech Model 907 high voltage power supply has been designed to be powered
by 24V DC, it produces an adjustable output of 4 - 7kV AC.
The 907 provides AC power for any Meech AC Ioniser, the additional features include
a pin cleaning alert and adjustable balance.
The 24V DC input voltage suits modern machinery and means that they operate
independently of local mains voltage and frequency. Settings in the 907 can be
adjusted with BarMaster controller. The output voltage can be adjusted from 4kV to
7kV. Additionally, on the 907 the BarMaster allows adjustment and monitoring of the
clean pin alert and balance.

Unpacking And Inspection
Your Hyperion 907 Power Supply was carefully packed at the factory in a container
designed to protect it from accidental damage. Nevertheless, we recommend careful
examination of the carton and contents for any damage.
If damage is evident, do not destroy the carton or packing material and immediately
notify the carrier of a possible damage claim. Shipping claims must be made by the
consignee to the delivering carrier.
Contents:
Standard
Hyperion 907 Power Unit
Options
Power Cables and Power
Extension Cables - 4 Pin
M8 (straight or 90º elbow)
available in 1, 3 or 8m
lengths.
24V DC Supply & IEC
cable
BarMaster remote
programmer.
Allows optimisation of the
output of the
Hyperion 907
4

5
Input Voltage and Connection
Installation and connection of the Hyperion 907 Power supply must be completed
by a qualied electrical engineer.
For safety reasons this equipment must be grounded / earthed via the 24V supply or by
direct connection to the earth stud on the case.
Installation
The Hyperion power supply should be mounted in ventilated enclosures or in free
air space. The holes in the ange should be used for mounting, it is important that
the power unit is mounted in such a way so oil or moisture from other sources
cannot contaminate the power unit.
Failure to the unit through contamination will invalidate the warranty
Ionising Equipment Connection
BEFORE MAKING ANY CONNECTIONS ENSURE THE UNIT IS DISCONNECTED
FROM THE 24V SUPPLY
The 907 Hyperion power supply has 4 ionising appliance connection ports (2 on each
side). Remove the lid of the Hyperion power supply by unscrewing the two retaining
screws. Select the required number of ports, one per appliance, and remove the
necessary amount of grommets from the ports.

6
Connect the item of ionising equipment by removing the lock washer and nut from the
swivel connector of the appliance.
Push the connector through a port in the Hyperion power supply. Re t the lock
washer and nut to secure the appliance cable. Make sure the nut is fully tightened.
Remove the Black plastic thumb screw and place the appliance cable eyelet over the
stud.

7
If you are adding more than one appliance repeat the stages 2-4 before screwing the
thumb screw back on top of the stud securing the Eyelets in place and making the
electrical connection.
Before Re-attaching the lid using the two screws removed in stage 1 make sure all of
the nuts are fully tightened before the lid is attached.
24V 4 pole extension cables are available from Meech in 1, 3 and 8 meter lengths.
Ensure the 24V supply is o󰀨 before connecting the power cable. Once the cable is
connected turn the supply back on, the LED’s located on either side of the Hyperion
power supply should be green. If they are not please refer to the fault nding and
diagnostic check located on the next page.

8
PLC Wiring
10kΩ
Pull up
24VDC
Output
0V, 24V
0V
Output Signal Voltage
Normally Open Output Matrix Normally Closed Output Matrix
24V Supply
Power ON
24V Supply
Power OFF
24V Supply
Power ON
24V Supply
Power OFF
OK (Green LED) 24V 0V OK (Green LED) 0V 0V
Dirty/Faulty
(Red LED) 0V 0V Dirty/Faulty
(Red LED) 24V 0V
External Relay Wiring
10kΩ
Pull up
24VDC
0V
Imax 20mA
NO
COM
NC
Relay Power
Normally Open Output Matrix Normally Closed Output Matrix
24V Supply
Power ON
24V Supply
Power OFF
24V Supply
Power ON
24V Supply
Power OFF
OK (Green LED) OFF OFF OK (Green LED) ON OFF
Dirty/Faulty
(Red LED) ON OFF Dirty/Faulty (Red LED) OFF OFF

9
Fault nding and diagnostic check
To ensure that the state of the power unit can be seen at any angle, the 907 has twin
LED indicators. Their colour and state show whether the system is operating correctly
or whether it needs attention. The meaning of the colours and states is as follows:
Colour State 907
Green Continuous OK
Green Flashing slow (1Hz) BarMaster connected
Red Continuous HT failure
Red Flashing slow (1Hz) Pin cleaning alert
Red Flashing fast (10Hz) Sparking detected (HT shut down)

Technical Characteristics
Material of Construction Painted Steel
Size 92mm x 118mm x 110mm WxDxH
Weight 2.2kg
Input Voltage 24V DC - N.B. Supply must be grounded.
Input Current 200mA-2A Load Dependant
Output Voltage 4000-7000V AC
Output Frequency 67Hz
Connection Murr 4pin M8, Earth terminal
Settings Control BarMaster
Output Signal 24V Output resistance 10kΩ
Local Indication Twin Green/Red LEDs
10

Advantages of Barmaster Programmer
Connection
The BarMaster is connected in line with the ionising bar’s 24V power supply cable.
The power cable is connected to the BarMaster and, in turn, its cable is connected to
the Hyperion 907 Power Unit.
Warning: It is recommended to turn-o󰀨 the 24V power supply to the power unit and
wait a few seconds before disconnecting the power cable from the bar. Failure to do
so will not damage the equipment, but may result in a small shock caused by the
stored energy in the bar.
Attach the cable on the BarMaster to the M8 connector on the power unit, then
connect the M8 connector from the power supply to the BarMaster.
Switch on the power supply. After a few seconds, the BarMaster will establish a
connection to the bar and display the bars settings and status.
The display on the BarMaster will show data including
Model No and Software version E.g. 907 V1.01
Serial No XXXXXX
Frequency 60-99Hz
Balance 20%-80% Positive
Voltage 4000V-7000V
Alarm 0%-99%
Ion Level 0%-99%
Reset Ion Ref Calibration command. 11

Controls
The ashing cursor can be moved to the parameter to be adjusted.
To scroll through the menu use the up down function.
To adjust Frequency, Balance, feedback, Alarm levels or to reset the ion reference
current use left and right function
Please note the OK button in the centre of the toggle is redundant and has no
function on the BarMaster.
12

Adjustments
Frequency
Your Hyperion 907 Power Unit is set to a default frequency that provides good
performance across its operating range. Lower frequencies can assist long-range use.
Higher frequencies give better results at short-range.
Balance
To get faster decay times, it is possible to adjust the output balance. Negative static
charges will be neutralised faster if the bar is biased to a positive balance (>50 Pos).
Hi accuracy neutralisation can be required in applications involving electronic circuitry,
E.g. RFID tag production. In the case the balance can be adjusted to give the most
accurate neutralisation for the target distance.
Output Voltage: 4kV - 7kV
Using a BarMaster programmer it is possible to set the output voltage of the 907 to
suit any Meech Ioniser. This makes the unit truly universal and removes the need to
stock di󰀨erent models for di󰀨erent ionisers.
13

Alarm (only on Hyperion 907 Power Unit)
This is the level of performance (Ion Level) at which the Clean Pin Alert will be
triggered. Typically set at 60% it can be set higher for more critical applications.
Ion Level (only on Hyperion 907 Power Unit)
This is an instantaneous measure of the performance of the bar, compared to its
performance when new and clean. A low percentage could indicate that the bar needs
cleaning.
Reset Ion Ref.
This function is used to set reference performance level when the bar is clean. It is set
by Meech during initial calibration. It should be reset after making changes to either
the balance or the frequency of the output.
Make sure that the bar is clean before resetting the Ion Ref Current.
Disconnecting Bar Master
Warning: It is recommended to turn-o󰀨 the 24V power supply to the BarMaster and
wait a few seconds before disconnecting the power cable from the power unit. Failure
to do so will not damage the equipment, but may result in a small shock caused by the
stored energy in the power unit.
Reconnect the 24V supply cable to the power unit and turn the power supply on. The
power unit will operate at the new settings.
14

Repairs And Warranty
The Hyperion power supply is warranted by Meech Static Eliminators Ltd to the
original purchaser against defects in the material and workmanship for two years after
shipment. Should any malfunction occur, please return the power supply directly to
Meech Static Eliminators or your local distributor. All products returned to the factory
MUST be accompanied by a return authorisation number and must be shipped
prepaid. For prompt service, ship the unit to the factory with the return authorisation
number shown clearly on the label. Be sure it is well packed in a sturdy carton with
shock absorbing material.
Include a note stating the nature of the problem as specically as possible, and also
include instructions for returning the power supply to you. We will pay one-way return
surface shipping costs on any repairs covered under the warranty.
Field repairs should not be undertaken under the warranty period. Repair attempts by
unqualied personnel will invalidate the warranty.
CE Approval
A CE Declaration of Conformity for this product exists in respect of the Low Voltage
Directive:72/23/EEC (“LVD”) & Electromagnetic Compatibility Directive: 89/336/EEC
(“EMCD”)
Health and Safety
Emission of Ozone: Considerably below international standard of 0.1ppm

15
1 1
2 2
3 3
4 4
5 5
6 6
A A B B
C C D D
David.Hyde
17/08/2015
Drawn by:Date:
1 / 5

Sheet
Meech Internatio nal 2 Network Point Range Road, Witne y OX29 0YN, UK Tel: [phone] Fax: [phone] email: sales@meec h.com web: www.meec h.com
COPYRIGHT © MEECH ST ATIC ELIMINAT ORS THIS DOCUMENT AND THE INFORMATION THERE IN IS THE PROPE RTY OF THE ME ECH GROUP AND SHOULD NOT BE COPIED IN WHOLE OR PART OR USED FOR MANUFACTURE OR OTHERWISE DISCLOSED WITHOUT THE PRIOR WRITTEN CONSENT OF MEECH INTERNATIONAL
MATERIAL: FINISH: TOLERANCE UNLESS OTHERWISE SPECIFIED Machined Work Metric ±0.1mm Unmachined Fabrications ±1mm Angular ±0°30'
PROJECTION
DIMENSIO NS IN MM DO NOT SCALE
TITLE: DRAWING No: REVISION: SHEET:

Various
1:2
STATUS: Production
CRITICAL TO FUNCTION (CTF) DIMENSION S AS MARKED
103
52
118
92
110
88 91
24V Power Supply input
Earth Stud
Mounting Holes

6,2
LED Indicators,
(one on each side)
4 Power Outlets (2 on each side)
Lid Securing Screws
Lid
900 Series Bar Connection
907 Power Supply
A907
Various
-

©Meech Static Eliminators Ltd 2017 www.meech.com
Meech International
2 Network Point
Range Road, Witney
OX29 0YN, UK
Tel: [phone]
Fax: [phone]
email: [email protected]
Meech Static Eliminators
(Shanghai) Co. Ltd
7G, 7F, LP Tower
#25 Xiangfeng Road
201103 Shanghai
China
Tel: [phone]
Fax: [phone]
email: [email protected]
Meech Static Eliminators USA Inc
2915 Newpark Drive
Norton, OH 44203
USA
Tel: [phone]
Fax: [phone]
email: [email protected]
Meech Shavotech
29/2, Kharadi
Off Pune-Nagar Road
On Old Kharadi Mundhwa Road
Pune : 411014 , Maharashtra
India
Tel: [phone]
Fax: [phone]
email: [email protected]
Meech Elektrostatik SA
Kaiserbaracke 166
B-4780 St.Vith
Belgium
Tel.: [phone]
[phone]
Fax: [phone]
email: [email protected]
Meech International
(Singapore) Pte. Ltd.
7 Temasek Boulevard
12 - 07 Suntec Tower One
Singapore
Singapore
038987
Tel: [phone]
email: [email protected]
Meech CE
Gábor László utca 2
Budapest 1041
Hungary
Tel: [phone]
[phone]
email: [email protected]
