UNU 2019 User manual
Title: Repair Plan - 2.0
Author: T. Beckmann
Copyright: unu GmbH
Version: 1.0
Language: EN
Created: September 2019
Foreword
This repair manual describes work on the unu Scooter (Model 2019).
The vehicle identification numbers (VIN) of the unu Scooter (Model 2019) begin with
“WUNU2S”.
The VIN can be found on the frame nameplate which is riveted to the frame on the right side
of the frame at the point where it connects to the rear swingarm.
At the time of release of this user manual, the included instructions are valid for every unit of
the unu Scooter (Model 2019).
The unu Scooter (Model 2019) will hereafter be called “the scooter”.
This manual is written for the use by trained mechanics. If you are not sure about your ability
to safely perform the work-steps described in this repair guide, both in terms of safety during
the repair as well as a safely reconstructed vehicle at the end of the repair, let a trained
mechanic perform the work.
Whether you are a trained mechanic or not, carefully read the safety notes provided in
chapter 0 of this repair guide before performing any work on the scooter.
Documentation of changes to this repair guide
This represents the first version (1.0) of the document titled “Repair Plan - 2.0”. Should any
relevant changes to the scooter itself, a specific repair instruction for one or more of its
components, or the structure of this document be made, then these changes will be
mentioned in this section.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
Content (resumed on following page)
0. Safety notes 5
0.1 Explanation of warning labels 5
0.2 General safety warnings for repair personnel 6
1. Part replacement 7
1.1 Fixtures 7
1.1.1 Rear handhold 7
1.1.2 Rear mudguard bracket (with mudguard attached) 7
1.1.3 License plate holder 9
1.1.4 License plate light 9
1.1.5 Mirror mounting bracket left 11
1.1.6 Mirror mounting bracket right 12
1.1.7 Left grip 13
1.1.8 Throttle 14
1.1.9 Luggage hook 15
1.2 Seat and substructure 16
1.2.1 Seat lock bar 16
1.2.2 Seat cushion 17
1.2.3 Seat assembly 18
1.3 Painted body panels 19
1.3.1 Front outer panel 19
1.3.2 Front mudguard 20
1.3.3 Seat hinge panel 21
1.3.4 Rear light panel 22
1.3.5 Rear panel assembly 23
1.3.6 Rear side panel left 24
1.3.7 Rear side panel right 25
1.4 Unpainted body panels 26
1.4.1 Footrest panel 26
1.4.2 Front inner panel 27
1.4.3 Bottom rear panel 28
1.4.4 Swingarm cover panel 29
1.5 Frame & Chassis 30
1.5.1 Front wheel 30
1.5.2 Front brake disc 31
1.5.3 Motor (removal from swingarm) 32
1.5.4 Rear brake disc 33
1.5.5 Rear swingarm 34
1.6 Lights & Electronics 35
1.6.1 Front light 35
1.6.2 Front indicator left 36
1.6.3 Front indicator right 37
1.6.4 Rear light 38
1.6.5 Electronics under footrest 39
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
0. Safety notes
Before performing any work-steps on the unu Scooter (Model 2019), familiarize yourself with
the following explanations and warnings.
0.1 Explanation of warning labels
The following labels will be used throughout the repair manual to warn you about potential
risks caused either by mechanical or electrical sources or negligence in the proper execution
of a crucial repair step. Please consider that even in the absence of any of the labels listed
below, the proper execution of any repair is relevant to providing a safe environment for the
execution of repairs and the driving experience after any repair.
Danger
A dangerous situation which, if not avoided, will undoubtedly result in
serious injury or death.
Warning
A hazardous situation which, if not avoided, could result in death or
serious injury.
Attention
A dangerous situation which, if not avoided, could result in minor to
moderate injury.
Information
Label distinguishes information that does not concern personal injury,
e.g. information on damage to property.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
0.2 General safety warnings for repair personnel
Before working on the scooter and even when preparing any repair, make
sure you understand the basic workshop rules for providing a safe
environment for the execution of repairs. Such workshop rules may include
wearing proper clothing to prevent the risks posed by sharp objects or heavy
equipment or parts necessary for the execution of a repair.
The scooter operates at voltages below 60V and therefore does not fall under the
classification of high voltage. However, some precautions need to be made when working on
the scooter in order to prevent electrical shock or other types of injury.
● When working on any element usually covered by the body of the scooter, turn off the
scooter, detach the battery from the scooter and then turn the scooter back on for at
least two seconds to discharge any electricity stored in the electrical components.
● Wear safety gloves when performing any type of work on the scooter to prevent cuts
as well as provide additional protection against electrical shock.
● Protect your eyes with proper safety goggles or glasses when performing steps such
as drilling, hammering, and polishing.
● Wear a safety mask with an air filter when applying and type of spray, especially
when working in an enclosed environment. Generally all types of work involving
sprays should be performed in a well-ventilated environment.
● Wear a safety helmet also for short test drives as some unexpected behavior of the
scooter after a repair can lead to a loss of control and result in a fall or crash.
● Carefully follow all of the instructions laid out in this repair guide to ensure the proper
reassembly of all parts. Pay attention also to applying the proper torque to all screws
and bolts, which have been worked on during the repair. A list of all relevant torque
values can be found in the according chapter of this repair guide.
● Make sure to use only parts provided by unu to ensure proper quality and fit of the
parts. We advise strongly against the use of inferior parts, even if they appear to be
fitting with the scooter.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1. Part replacement
The following articles describe the work needed for the detachment of each part from the
scooter a group of its parts. For reassembly execute the steps in reverse order, unless
otherwise specified. The listed durations describe the time needed for dis- and reassembly
combined. The durations do not include the time needed for the preparatory steps.
1.1 Fixtures
1.1.1 Rear handhold
Duration: 4 minutes
Preparatory steps: None
Work steps
Remove the four screws on the underside of the handhold.
With the screws removed, stretch the ends of the handhold away from the bodykit and pull
the handhold towards the rear to remove it. If you can’t find the right angle for taking off the
handhold, look at the angle at which the middle part of the handhold enters the bodykit. It is
only slotted in and does not need to be unscrewed anywhere.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.1.2 Rear mudguard bracket (with mudguard attached)
Duration
5 mins
Preparatory steps
None
Work steps
Remove screws 4 & 5 shown in the image. Do not remove the bracket abruptly, because the
cable for the license plate light is still connected. Disconnect it to remove the rear mudguard
bracket.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.1.3 License plate holder
Duration
5 mins
Preparatory steps
1.1.2 Rear mudguard bracket (with mudguard attached)
Work steps
Remove the two cross-head screws to detach the license plate holder from the mudguard.
Note: Before replacing the license plate holder, the license plate light will also have to be
detached.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.1.4 License plate light
Duration
4 mins
Preparatory steps
1.1.2 Rear mudguard bracket (with mudguard attached)
1.1.3 License plate holder
Work steps
Unscrew the two screws to detach the license plate light from the license plate holder. If you
have not detached the connector on the wires of the license plate light, do so now.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.1.5 Mirror mounting bracket left
Duration
3 mins
Preparatory steps
Front outer panel
Left grip
Work steps
Remove the two hex-head screws on the mounting bracket to remove it.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.1.6 Mirror mounting bracket right
Duration
3 mins
Preparatory steps
None
Work steps
Because the mounting bracket cannot be removed with the throttle fully in place, first loosen
the allen-head screw holding the throttle in place. Move the throttle to the right by 4cm.
Remove the two hex-head screws on the mounting bracket to remove it.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.1.7 Left grip
Duration
3 mins
Preparatory steps
None
Work steps
Unscrew the allen-head screw to detach the left grip from the handlebar.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.1.8 Throttle
Duration
3 mins
Preparatory steps
Front Outer Panel
Work steps
Unscrew the allen-head screw on the underside of the throttle to detach it from the
handlebar. Unclip the connector from the harness in order to replace it.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.1.9 Luggage hook
Duration
2 mins
Preparatory steps
None
Work steps
Unscrew the allen-head screw which connects the hook to the front inner panel.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.2 Seat and substructure
1.2.1 Seat lock bar
Duration
3 mins
Preparatory steps
None
Work steps
Remove the two allen-head screws in order to detach the seat lock bar from the substructure
of the seat.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.2.2 Seat cushion
Duration
3 mins
Preparatory steps
None
Work steps
Detach the cushion from the understructure by removing the cross-head screws at the three
locations. There are six screws in total.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.2.3 Seat assembly
Duration
4 mins
Preparatory steps
Rear panel sub-assembly
Work steps
To remove the seat assembly from the seatbox, unscrew the hinge bolt and remove it. The
hinge cover panel does not need to be removed for this step.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.3 Painted body panels
1.3.1 Front outer panel
Duration
10 mins
Preparatory steps
None
Work steps
Remove the six cross-head screws which are accessible on the front inner panel.
Next, remove the two cross-head screws which are accessible through the wheel-house.
Be careful when taking off the front outer panel and detach all of the light connectors.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
1.3.2 Front mudguard
Duration
8 mins
Preparatory steps
None
Work steps
With the two glued reflectors removed, unscrew the four allen-head screws to free the
mudguard from the front suspension.
unu GmbH - “Repair Plan - 2.0” - Version 1.0 - Created: September 2019
