Megasat SAT IP Server 2 User manual
Stand: 1.0 November 2014 // Technical changes, misprints and errors reserved.
user manual
SAT>IP Server 2
Content
02 03
Safety Instructions
ENGLISH ENGLISH
Safety Instructions...................................................................................................... 03
1. Introduction ......................................................................................................... 04
2. Connection & How to access................................................................... 05
3. Login / Logout..................................................................................................... 08
4. System Settings................................................................................................. 09
4.1 Network Settings............................................................................... 10
4.1.1 Wired .................................................................................................. 11
4.1.2 Wireless............................................................................................. 12
4.2 LNB Settings........................................................................................... 15
4.2.1 LNB Einstellung............................................................................ 16
4.2.2 Quad................................................................................................... 17
4.2.3 Quattro.............................................................................................. 18
4.2.4 Unicable ........................................................................................... 19
4.2.5 Jess....................................................................................................... 20
4.2.6 DiSEqC............................................................................................... 21
4.2.7 USALS................................................................................................. 27
4.3 Import Settings ................................................................................... 28
4.4 Export Settings.................................................................................... 29
5. System Status
5.1 Tuner Status................................................................................................. 30
6. Tuner
6.1 Tuner settings............................................................................................. 32
6.2 Tuner test...................................................................................................... 34
7. Software Update
7.1 USB.................................................................................................................... 35
7.2 OND.................................................................................................................. 42
7.3 WebUI.............................................................................................................. 48
8. Admin
8.1 SW Version.................................................................................................... 51
8.2 Language...................................................................................................... 51
8.3 Change Password.................................................................................... 51
8.4 Restart............................................................................................................. 51
9. Specicatons........................................................................................................ 52
Please read the manual thoroughly before operating the equipment. In case of incorrect
or improper handling, the warranty becomes void.
Power supply: Before start please check the correct operation voltage of the
power point. The operating voltage of this device is AC 100 ~
240V, 50/60 Hz.
Overload: Do not overload a wall outlet, extension cord or adapter, neither
use damaged power cord or touch it with wet hand as this may
result in electric shock.
Liquid: The device shall not be exposed to dripping or splashing water,
and that no objects filled with liquids, such as base, shall be
placed on the apparatus.
Ventilation: Keep the slots on top of the device uncover to allow sufficient
airflow to the unit. Do not put the receiver on soft furnishings or
carpets. Do not expose the receiver to direct light or do not
place it near a heater or in humid conditions. Do not stack other
electronic equipments on top of the receiver.
Risk of ssuocation: Do not let children play with films or other packaging
components, there is a risk of suffocation.
Cleaning: Plug out the device from the wall outlet before cleaning. Clean
the device by a soft cloth or mild solution of washing-up liquid
(no solvents).
Connection: Disconnect the device from the mains when you connect it to
satellite LNB or disconnect it from LNB. Failure would possibly
cause damage to the LNB.
Location: Put the device indoor in order to avoid lightening, raining or
sunlight.
Uncover: Do not remove the cover, to reduce the risk of electric shock.
Contact qualified and licensed service personnel to repair the
receiver, or contact your dealer.
1. Introduction
04 05ENGLISH ENGLISH
2. Connection & How to access
SAT>IP Server 2 allows free satellite live TV/Radio programs to be received & distributed
to SAT>IP Client compliant devices like smart phones, tablet pc‘s and notebook pc‘s &
other client devices over Wired/Wireless home network in both unicast/multicast mode
of transmission. SAT>IP Server 2 is equipped with four satellite tuners, so users can watch
4 x different frequency simultaneously & with same frequency 8 x different users can
watch simultaneously.
SAT>IP Server 2 device must be connected to same home network in which the Client
devices which are connected to.
SAT-IP Server Features:
• Fully compliant with SAT>IP Specification version 1.2
• Streaming Live SD/HDTV & Radio programs to 4 compatible Clients over LAN/WLAN
• Support MPEG2/MPEG4 TS & PS over IP in both Unicast and Multicast
• Support Unicable, JESS, DiSEqC1.0, DiSEqC 1.2 and USALS
• Firmware update over USB stick or online over the network
• Web UI based device configuration and management (password protected)
Supported Client devices:
• SAT-IP supporting devices (IP 100, .....)
• iOS devices (iPad, iPod, iPhone), Android tablets and smart phones using Elgato
applications
• DLNA/UPnP compatible PC software applications e.g.VLC Player, DVB Viewer
USB LAN Power
supply
Power
switch
VL
(RF4)
VH
(RF3)
HL
(RF2)
HH
(RF1)
Connection with a Universal LNB (z.B. Single, Twin or Quad LNB)
Single LNB = RF1
Twin LNB = RF1 + RF2
Quad LNB = RF1 + RF2 + RF3 + RF4 (The order is not important)
Connection with a Quattro LNB
The device must be connected to the appropriate connector on the Quattro LNB, please
make sure the correct ports on the LNB:
Tuner RF1 = Horizontal High (HH)
Tuner RF2 = Horizontal Low (HL)
Tuner RF3 = Vertical High (VH)
Tuner RF4 = Vertical Low (VL)
Connection with a Unicable LNB
Unicable LNB = RF1
Note that a change must be made in the web configurator. The respective settings, see
page 19.
Connection with a Jess LNB
Unicable LNB = RF1
Note that a change must be made in the web configurator. The respective settings, see
page 20.
Connection with a DiSEqC controlled device
Depending on the connection used, please refer to the corresponding DiSEqC settings.
The respective settings, refer to page 21.
Connection with a Motor (USALS)
Motor (USALS)= RF1
Note that a change must be made in the web configurator. The respective settings, see
page 25.
2. Connection & How to access
06 07DEUTSCH DEUTSCH
2. Connection & How to access
Identify the IP address
Turn on the server. The server connects to the network and receives
own IP address automatically. You can also assign the server in your network a static IP
address with DHCP.
To access the web configurator, it is necessary the IP address
to identify the device. This can be found in the following manner:
The Megasat SAT> IP Server 2 supports UPnP technology that experienced it
Users allows the IP address to identify a free UPnP tool (eg Intel Developer Tools for UPnP
Technologies).
• Download the appropriate software on the PC and install it.
• Open the„Device Spy“ from the Start menu.
Open a web browser (Recommended: Google Chrome or Opera) and enter the server‘s
IP address. You can find the assigned IP address in the configuration menu of the Internet
router.
192.168.3.128
Conguration
The server can be configured with a PC that is located in the same network. The configu-
ration is done through a web browser with which you have to log in to access the user
interface of the server.
• Select in the list of„UPnP Devices“ to„Megasat SAT> IP Server 2“, and read the corre-
sponding„Base URL“ from (for example 192.168.2.100)
4. System Settings
08 09ENGLISH ENGLISH
3. Login / Logout
Login
Once the browser was successful-
ly connected to Server, then the
„Login“ page will be displayed.
The default user name for server is
„admin“ and password is„admin“.
Enter the Password and click the
„Login“ button. The server page
will be displayed on the screen.
We have restricted the password
length to be minimum of 8 charac-
ters and maximum 16 characters.
Logout
To log out, click on „Logout“ icon
place at right top corner.
Select „Yes“ from the confirmation
to log out from the Server page.
Click„System Settings->Network Settings“ from the server page.
Server box supports the below network mode of interfaces.
• Wired Network
• Wireless Network
4. System Settings
10 11ENGLISH ENGLISH
4. System Settings
4.1.1 Wired
By default the Server box is in
DHCP mode.
Server acquires IP address from
DHCP server & listed the informa-
tion on the screen.
Server box failed to find DHCP ser-
ver then it will automatically move
to Auto-IP mode & allocate IP ad-
dress in 169.x.x.x range.
User can configure the IP settings
by„Manual“ mode also. In manual
mode user can enter/edit the IP
settings. IP configuration can be
edited from this dialog.
After complete the IP configurati-
on, click„Apply“ for save.
Wired Network
Server box supports the below IP mode of configurations in Wired network,
• DHCP (Managed Network)
• AUTO IP (Unmanaged network)
• Manual (User IP configuration)
Wireless Network
Server box supports the below IP mode of configurations in Wireless network.
• Auto
• Manual
4.1 Network Settings
Note:
1. By default the Server box is in DHCP mode.
2. Server box failed to find DHCP server then it will automatically move to Auto-IP
mode & allocate IP address in 169.x.x.x range.
Click„System Setting“ from the Server page.
Topics covered under Admin are listed below:
• Network Settings
• LNB Settings
• Import Settings
• Export Settings
4. System Settings
12 13ENGLISH ENGLISH
4. System Settings
4.1.2 Wireless
Wireless option can be configure
by Auto (or) Manual.
Password request screen will be
displayed if user select WPA se-
cure system available WiFi router.
Using keypad user should enter
the valid WPA key.
A warning pop-up is displayed
if the password is invalid or the
Receiver is unable to connect to
the network.
In the event that the warning
pop-up is displayed, pressing any
key causes the network list to be
re-displayed with the same net-
work in focus.
Enter valid password and select
„Connect“ button; the wireless
network will be connected suc-
cessfully.
If user selects „Auto“, WiFi routers
which is available nearby can be
discovered automatically & listed.
# Network name (SSID): Name of
the network. Network name will
be truncated with ellipsis (…) if
the network name exceeds more
than 15 characters.
# Signal Quality: Signal icon dis-
played with different colors based
on the reception quality.
# Lock: Lock icon will be displayed
if the connection mode is secu-
re. Supported security modes are
WPA, WPA2, WEP-64 bit, WEP-128
bit.
4. System Settings
14 15ENGLISH ENGLISH
4. System Settings
The Green color tick icon is dis-
played if WiFi Router is connec-
ted without any problem. All WiFi
network settings are stored in the
system memory.
Select the type of LNB that is connected to Satellite input of your box based on your
satellite installation. Topics covered under are listed below:
Quad
Select„Quad“ when a Quad LNB, Octo LNB or Universal multiswitch is connected to your
Server box.
Quattro (Quattro LNB)
Select„Quattro“ when a Quattro LNB is connected to your Server box directly.
Unicable (Unicable LNB or Unicable multiswitch)
Select„Unicable“ when a Unicable switch is connected to your Server box
JESS
Select„Jess“ when a Jess switch is connected to your Server box.
DiSEqC1.2
Select„DiSEqC“ when a DiSEqC1.2 motor is connected to your Server box.
USALS
Select„USALS“ when a USALS motor is connected to your Server box.
How to Access?
Click„LNB Setting“ from the Server page.
Wireless can be configured by Ma-
nually. To connect the Box to WiFi
router user need to provide the
Device information.
If users pressing OK key the base
station will be opened. Further
procedure will be same as exp-
lained for Auto mode.
4.2 LNB Settings
4.2.1 LNB Settings 4.2.2 Quad
4. System Settings
16 17ENGLISH ENGLISH
4. System Settings
To configure the below settings from the LNB settings menu.
• LNB Mode - Quad / Quarto / Unicable / Jess
• LNB Type - Universal / C band / Ku band / Extended C band / User
• LNB Low Frequency
• LNB High Frequency
• Positioner - None / DiSEqC / USALS
Configure the settings and click on„Apply“ button for save.
Satellite reception system consists of a Quad LNB. Connect the 4 outputs of the LNB to
the inputs 1... 4 of the Server box via suitable SAT antenna cables.
Similar to all Tuners.
• Horizontally polarised, high band 11.70-12.75 GHz („horizontal high“)
• Horizontally polarised, low band 10.70-11.70 GHz („horizontal low“)
• Vertical polarised, high band 11.70-12.75 GHz („vertical high“)
• Vertical polarised, low band 10.70-11.70 GHz („vertical low“)
4.2.3 Quattro 4.2.4 Unicable
4. System Settings
18 19ENGLISH ENGLISH
4. System Settings
Satellite reception system consists of a Quattro LNB. Connect the 4 outputs of the
Quattro LNB to the inputs 1... 4 of the Server via suitable SAT antenna cables & and ensu-
re the correct port assignment should be as follows:
• RF#4 - LNB output„horizontal high“ into input 1(11.70-12.75 GHz)
• RF#3 - LNB output„horizontal low“ into input 3(10.70-11.70 GHz)
• RF#2 - LNB output„vertical high“(11.70-12.75 GHz)
• RF#1 - LNB output„vertical low“ (10.70-11.70 GHz)
Unicable distribution is a satellite TV technology that enables delivery of broadcast pro-
gramming to multiple users over a single coaxial cable.
• Unicable IF Channel have eight options: None, 1, 2, 3, 4, 5, 6, 7 & 8
• User has provided the edit option Centre frequency.
• User has provided the option to select the available Ports A or B.
4.2.5 Jess 4.2.6 DiSEqC
4. System Settings
20 21ENGLISH ENGLISH
4. System Settings
DiSEqC 1.2 is used to move the motor manually. Using this option user can move the
motor with the following moving controls.
• User - Step by step movement, based on user input
• Installer - Continuous movement
• Goto X - Move to the dish to user specified position
• Advanced - Dish settings(For e.g. Dish moving limits, Reset dish position, etc.,)
32 users can able to view the 8 different satellites via user band frequency.
4. System Settings
22 23ENGLISH ENGLISH
4. System Settings
Set the Dish moving type as INSTALLER. Press Left/Right key in Drive East/West option
to move the motor. Now motor will be move continuously[coarse movement]. Motor
movement will be stop when the user press again LEFT/RIGHT key.
Set the Dish moving type as USER. Press Left/Right key in Drive East/West option to
move the motor. Now motor will be move slowly [step by step movement].
4. System Settings
24 25ENGLISH ENGLISH
4. System Settings
GoTo X option is used to move the motor in specified position. To perform this action,
select Dish moving type as GoTo X and enter the Dish position by pressing numeric keys.
Then press OK key, now dish will be move to specified dish position.
The above picture which shows the Advanced setup, through this setup user can per-
form the below listed Motor related settings,
• Enable / Disable limit - Enable or Disable the motor rotation to the restricted direc-
tion angle.
• Drive East / West - User can rotate the dish either East/West direction by pressing
LEFT/RIGHT key.
• Set EAST / WEST limit - This option is only enable, when we set the „Enable limits“.
Using this option, user can set the desired east / west angle. Afterward, they can‘t
able to move the dish after that angle. If user want to move the dish after that angle,
then they need to set the limit option as „Disable limits“. Recalculate Position - By
pressing the RED key, user can achieve the„RECALCULATE“ function.
• This Recalculate position option will replace the logical positions set by the user. If
user does this operation, confirmation will be displayed. If user selects YES option,
„Dish Moving“ message will be displayed.
• Reset Position - The motor position can be reset to its reference position [0 degree]
by using the Reset Position option. Confirmation message will be displayed after
pressing GREEN color key. If user select YES option,„Dish is Moving“ message will be
displayed.
4. System Settings
26 27ENGLISH ENGLISH
4. System Settings
The above picture shows the Motor moving in-progress.
USALS means Universal Satellite Automatic Location System. This type is used to move
the dish towards the satellite position automatically.
USALS is used to position the dish automatically without user stress. By giving the input
of satellite angle, user latitude & longitude angle, motor will be positioned automatically
to the selected satellite.
4.2.7 USALS
4. System Settings
28 29ENGLISH ENGLISH
4. System Settings
4.4 Export Settings4.3 Import Settings
Import Settings: User can import the configuration information which was available
from the receiver (can be extracted using export settings).
Using export settings user can retrieve the user configured details of the Server & stored
it as separate XML file.
6. Tuner
30 31ENGLISH ENGLISH
5. System Status
5.1 Tuner Status
System status menu gives the informations about:
• Tuner details
• Tuner parameters
• Streaming details
Select the type of Tuner of your box based on your satellite installation.
Topics covered under are listed below:
Tuner Settings
• Select„Dynamic“ for Server box tuned the client requested carrier.
• Select „Static“ for Server box tuned the fixed carrier where the client can only tune
that carrier.
Tuner Test
• Select„Tuner Test“ to to check the tuner lock sattus.
Tuner status screen gives details about;
• Tuner details
• Tuner parameters
• Streaming details
6. Tuner
32 33ENGLISH ENGLISH
6. Tuner
6.1 Tuner Settings
• By default the Server box is in Dynamic mode.
• Server box tuned the client requested carrier in Dynamic mode.
• Once the Client is requested to lock the particular frequency.Then Server box tuned
that carrier in Dynamic mode.
• LNA used to attenuate the signal strength and quality.
Select „Static“ for configure the tuner to the particular frequency where the client can
only tune that carrier.
• Source - To select DiSEqC 1.0 switch (A, B, C or D). The default value set to be 1.
• Frequency - To enter the fixed frequency.
• Symbol rate - To enter the fixed symbol rate(1000 to 65000 kps).
• Polarization - To select Horizontal / Vertical.
• Streaming Address - To enter the IP address and port number for multicast. Each
field values shall be 0 to 255. Port no range should be 1024 -65535.
• LNA - To attenuate the signal from 0 to 16db.
• PID’s - To enter (PAT, PMT, Audio, Video, Subtitle, Audio Descriptor, Teletext...) PID‘s.
Maximum of 32 pids and no more duplication allowed.
7. Software Update
34 35ENGLISH ENGLISH
6. Tuner
6.2 Tuner Test
7.1 USB
Enter the below valid parameters to check the tuner lock sattus.
• Source - To select the Tuner source
• Frequency - To enter the fixed frequency.
• Symbol rate - To enter the fixed symbol rate(1000 to 65000kSps).
• Polarization - To select Horizontal / Vertical.
• LNA - To attenuate the signal from 0 to 16db.
In order to support S/W upgrading, we have supported the below upgrading modes,
• S/W download via USB
• S/W download via OND
• S/W download via WEB UI
The S/W Upgrade via USB option used to download the latest software by USB memory
device
Procedure for S/W Upgrade via USB:
• Format (FAT32 file format) the USB stick and create the folder name„Update“
• Copy the .usb images directly in to the folder name „Update“ and insert the USB
memory device in the STB USB port.
• Select the S/W Upgrade via USB option from the menu.
Note:
If USB media is not inserted and when user select„Software Upgrade via USB“ then
above message will be displayed.
7. Software Update
36 37ENGLISH ENGLISH
7. Software Update
If USB media is inserted with S/W image and when user select „Software Upgrade via
USB“ then above message will be displayed.
System switch to Upgrader mode when select Yes from the confirmation.
7. Software Update
38 39ENGLISH ENGLISH
7. Software Update
System boot the upgrader mode and if the„Update“ folder in USB contains more than
one file the above screen will be displayed. User need to select the correct image. Other-
wise it directly start the S/W fusing.
Select the correct image and press the ok key, downloading will start.
Table of contents
Other Megasat Server manuals
