1 Introduction and general information
Dear Customer,
We are delighted about the confidence you have shown in our products.
It is very important to us that you should obtain significant use from MEIKO products and
that they should make your work easier.
If you follow the instructions in this document carefully, your dishwashing machine will al-
ways give you total satisfaction and will have a long service life.
The cleaning and disinfection machine has been assembled by us at the factory and has
undergone a thorough inspection. This provides us with the certainty and you with the
guarantee that you will receive a fully developed product.
We would therefore ask you to read these operating instructions carefully before
using the installation. Any further associated operating instructions for accesso-
ries and integrated third-party products must be strictly observed!
These operating instructions inform users of this installation about the installation, its op-
erating methods, Its use, the safety instructions and the maintenance.
This information will help you to get to know the installation fully and to use it properly. It
will also enable you to avoid repairs and the concomitant loss of productive work.
In the event of any damage caused by non-observance of these operating instructions,
any guarantee claims are invalid. We accept no liability for any additional damage caused
as a result.
MEIKO is constantly working on the further development of all its models.
We would therefore ask you to understand that because of this, we must reserve the right
to make modifications at any time to any items covered by the contract in terms of their
shape, fittings and technical characteristics.
No claims may therefore be based on the details, the images or the descriptions con-
tained in these operating instructions.
Should you require any further information, or in case any particular problems not dealt
with in great detail in the operating instructions should arise, you may contact the relevant
MEIKO branch to obtain the information you require.
We should also like to inform you that the contents of these instructions do not form part
of or amend any earlier or existing agreement, statement, or legal position.
All MEIKO’s obligations arise from the relevant purchase contract which also contains the
entire and only valid guarantee provisions.
The operating instructions must exist in the local language for each EU country. If this is
not the case, the dish-washing machine must not be commissioned.
The original operating instructions in Germany, and all operating instructions in all lan-
guages for EU countries can be downloaded from the following address:
https://partnernet.meiko.de
The complete technical documentation is issued to you free of charge.
Additional copies will be charged at cost.
These contractual guarantee rules shall be neither extended nor restricted as a result of
any explanations given in the instructions.
The MEIKO Company very much hopes that you will enjoy our product and use it suc-
cessfully.

Operating instructions FV 28 GiO
Datei:1D3A4F9D.doc 9671086
5/38
We reserve the right to change execution and construction!
MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: [phone], Fax: [phone]
1.1 Storage
Always store the operating instructions close to the installation!
The operating instructions must always be kept within easy reach!
1.2 Name and address of the manufacturer
Please address any queries, technical problems etc. directly to:
MEIKO Maschinenbau GmbH & Co. KG
Englerstr. 3
D - 77652 OFFENBURG
Phone + 49 781 / 203-0
http://www.meiko.de
[e-mail]
or:
Name and address of the MEIKO branch, manufacturer’s agent or dealer.
((nsert company stamp or address)
1.3 Authorization for service technicians of our service partners
MEIKO exclusively authorises authorised service partners for commissioning, inductions,
repairs, maintenance, assembly and installation of the corresponding product groups with-
in MEIKO devices.
1.4 Description of the machine
Please provide the following information on any query and/or when ordering spare parts:
Type:
SN:
This information can be found on the plate.

Operating instructions FV 28 GiO
Datei:1D3A4F9D.doc 9671086
6/38
We reserve the right to change execution and construction!
MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: [phone], Fax: [phone]
2 Explanation of the safety symbols used
The following safety symbols will appear throughout these operating instructions. The
purpose of these symbols is to draw the reader’s attention to the text of the adjacent safe-
ty information.
CAUTION!
This symbol warns that there is danger to human life and health.
DANGER!
This symbol warns that there is danger to the installation, to mate-
rial or to the environment.
This symbol denotes information that helps you to understand the
installation’s operation.
Warning of dangerous electrical current!
Warning hand injury!
No splashing water: prohibits the use of a high pressure hose.
Danger of explosion: indicates a potential explosion hazard.
Non-potable water: The water is not for drinking. Health can be
endangered by drinking.
Danger of burning: indicates possible hazard due to hot surfac-
es or media.
3 Use in accordance with regulations
DANGER!
This glasswashing machine is intended for washing dishes, cutlery and glasses.
The glasswashing machine must be used only in accordance with regulations.
Other uses are prohibited.
The items to be cleaned must be suitable for washing in washing machines.
This machine is intended solely for use in a commercial environment.

Operating instructions FV 28 GiO
Datei:1D3A4F9D.doc 9671086
7/38
We reserve the right to change execution and construction!
MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: [phone], Fax: [phone]
4 EC Declaration of Conformity
