meitav-tec ETNC24-SUPER-MDB-01 User manual

ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
OFF
F
o
Aux
On/Off Mode Fan
Hi
Me
LoFan

Operating instructions…………………………………………….. Pg. 3-4
Turning the thermostat ON and OFF
Adjusting the Set point temperature
System Modes
Economy mode
Fan speeds (for 2 and 3 speeds configuration)
Auto fan (Fan on demand)
Locking the thermostat buttons
Installation…………………………………………………………….Pg. 5
Wiring…………………………………………………………………. Pg. 6
Wiring diagram
Connecting the fan to the fan terminals
Communication network
End of line jumper
Contact input
DIP switch S1 settings…………………………………………….. Pg. 7
Internal or External sensor
Heat pump or Non Heat pump system
Heat pump active in Cool or in Heat
Heater type – Electric or Oil
Window contact operation – Economy or OFF
DIP switch S2 settings…………………………………………….. Pg. 8
Enable or Disable room temperature display
One, Two or Three fan speeds configuration
Enable or Disable Auto change over mode
Temperature scale
Enable or Disable compressor delay
Technician Settings………………………………………………… Pg. 9
Temperature limit for Cool
Temperature limit for heat
Offset for calibration of measured temperature
Dead zone
Set point temp. for cooling in economy mode
Set point temp. for heating in economy mode
Communication MAC Address…………………………………… Pg. 10
Tel: [phone]
Fax: [phone]
[e-mail]
ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
Pg. 2
Index

Operating instructions
Turning the thermostat ON and OFF
Press the [On/Off] button to turn the thermostat ON.
Press again to turn the thermostat OFF.
* The words “ON” or “OFF” will appear on display.
Adjusting the Set point temperature
Press the [+] or [-] buttons once - the word “SET” and the set point
temperature will flash.
Press again to adjust the set point temperature.
* Room temperature display can be disabled by technician.
Tel: [phone]
Fax: [phone]
[e-mail]
ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
Pg. 3
System Modes
Press the [Mode] button to switch between modes:
- “Cool”…………………..…… Cooling
- “Heat”….…………….…....… Heating
- “Cool” & “Heat”………..….… *Auto mode
- “Fan”….………………..……. Fan only
* In Auto mode, the system mode depends on the difference between room
temperature and set point:
Set point temperature higher than Room temperature Heating mode.
Set point temperature lower that Room temperature Cooling mode.
* Auto mode can be disabled by technician.
* Active mode flashes during demand for cooling or heating.
Economy mode can be used to keep the room temperature at economy
levels during absence.
Economy set points for cool and heat are set by technician.
Press and hold the [On/Off] button for 20 seconds to turn economy
mode ON – “EC” will appear on display.
Press the [On/Off] button again to return to normal mode.
ON
OFF
Thermostat
ON
Thermostat
OFF
Set point
temperature
F
o
Room
temperature
F
o
SET
Cool
Cooling
Heat
Heating
Heat
Cool
Auto
Fan
Fan only
Economy mode
Economy
mode

Operating instructions (Cont’)
Fan speeds (for 2 and 3 speeds configuration)
Tel: [phone]
Fax: [phone]
[e-mail]
ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
Pg. 4
Press the [Fan] button to switch between fan speeds:
- “Lo”...………………......….… Low speed
- “Me”…..……………....……… Medium speed
- “Hi”…………………....….…...High speed
- “Lo”,”Me",”Hi”………...…..… Auto speed
* In Auto speed, the fan speed depends on the difference between
room temperature and set point.
* In 2 speeds configuration, medium speed is not active and the letters
“Me” will not appear on display.
* In 1 speed configuration, the fan speeds display will remain empty.
* The active speed will flash.
For thermostat with 1 speed configuration:
Press the [Fan] button to turn Auto fan ON and OFF.
For thermostat with 2 or 3 speeds configuration:
Press and hold the [Fan] button for 3 seconds to turn Auto fan ON and OFF.
* While ON, “Auto Fan” will appear on display and the fan will cycle only with
demand for cooling or heating.
* While OFF, the fan will cycle continuously regardless of demand for cooling or
heating.
* Auto fan is not available in Fan only mode.
* While using Oil heater with Auto fan, the fan will be disabled.
Auto fan (Fan on demand)
Locking the thermostat buttons
Make sure the set point temperature is different than 10-11°C / 50-51°F.
Press and hold the [Mode] button for 15 seconds until “LC” appears on
display.
Press and hold the [Mode] button again for 15 seconds to unlock the
buttons.
* Separate locking features for selected buttons can be reached through
communication control.
Lo
MediumLow
Me
Hi
AutoHigh
Lo
Me
Hi
Auto Fan
Auto fan
ON
Buttons
locked

Installation
The ETNC24-SUPER-MDB-01 is designed for wall
mounting in the room to be controlled. It should be
located where the occupant can easily read the LCD
display and use the controls. If the built in temperature
sensor is being used to measure room temperature, the
module should be placed where the temperature is
representative of the general room conditions. Cold or
warm air draughts; radiant heat and direct sunlight should
be avoided.
General points to follow:
- Disconnect power to the main board before installing the unit.
- The standard height to install this unit is 1.6 meter (5 feet) from the floor.
Installation procedure:
A. Separate the front panel from back panel by pressing the tongue located in the top of the unit and
pull the back panel out.
B. Line the back panel up against the wall or flat surface. Install three screws as required.
C. Make electrical connections as shown on enclosed electrical wiring diagram.
D. Install the cove to the back panel; first the two tabs on the bottom and then the top tongue. Push
until tight against the wall.
Tel: [phone]
Fax: [phone]
[e-mail]
ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
Pg. 5
OFF
F
o
Aux
On/Off Mode Fan
Hi
Me
LoFan

Wiring
Tel: [phone]
Fax: [phone]
[e-mail]
ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
Pg. 6
Heat pump system with 1 fan speed
Compressor 2
Communication RS485 - MODBUS
Ext. sensor (option) Contact input (option)
Heat Pump Heat element Fan Compressor 1
Supply 24VAC
Non Heat pump system with 1 fan speed
Compressor 2
Communication RS485 - MODBUS
Ext. sensor (option) Contact input (option)
Heat element 1 Heat element 2 Fan Compressor 1
Supply 24VAC
Heat pump with 2 fan speed
Low fan speed
Communication RS485 - MODBUS
Ext. sensor (option) Contact input (option)
Heat Pump Heat element High fan speed Compressor
Supply 24VAC
Non Heat pump with 2 fan speed
Communication RS485 - MODBUS Ext. sensor (option) Contact input (option)
Heat element 1 Heat element 2 Compressor
Supply 24VAC
Low fan speed High fan speed
RCY1
Y2 INToBA T
G1 G3G2B/0
GW2W1
Heat pump with 3 fan speed
Low fan speed
Communication RS485 - MODBUS
Ext. sensor (option) Contact input (option)
Heat Pump Medium fan speed High fan speed Compressor
Supply 24VAC
RCY1
Y2 INToBA T
G1 G3G2B/0
GW2W1
Non Heat pump with 3 fan speed
Communication RS485 - MODBUS Ext. sensor (option) Contact input (option)
Heat element Medium fan speed Compressor
Supply 24VAC
Low fan speed High fan speed
RCY1
Y2 INToBA T
G1 G3G2B/0
GW2W1 RCY1 Y2 INToBA T
G1 G3G2B/0
GW2W1
RCY1
Y2 INToBA T
G1 G3G2B/0
GW2W1 RCY1 Y2 INToBA T
G1 G3G2B/0
GW2W1
* Ext. sensor = External sensor
* In some configurations, the thermostat offers connection to 2 and/or 3 stages of cooling or heating.
Where the system uses less stages than offered, leave the unnecessary terminals unwired.
(2nd stg. Heat)
(3rd stg. Heat)

Wiring (Cont’)
Tel: [phone]
Fax: [phone]
[e-mail]
ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
Pg. 7
JMP1
S5AB
First and last devices in the communication line
should be terminated with a 120Ωresistor to
prevent signal reflection.
JMP1 – End of line jumper
Short – End of line
Open – Not end of line (default)
Jumper
Short
Jumper
Open
End of line jumper
Do not run communication cables in the same conduit of high voltage (24VAC) electrical cables and if
you cross an electrical cable, cross at a 90° angle. Mixing high and low voltage lines may cause
serious communication problems.
In order to prevent any potential contact between high and low voltage
wires, group the high voltage wires together using a non conductive cable clamp, as close as possible
to the thermostat, and repeat the procedure on the low voltage wires (A, B, 0, To, IN).
Communication Network
RS485
MODBUS
Twisted shielded pair cable
(SFTP 120Ω@1MHz), 22AWG
Connect the shield to ground at one end of
communication line
Tested
ground
Communication
network
Shield
ETN
A B
ETN
A B
ETN
A B
The IN,0 Dry contact , normally open terminals can be used to connect any contact input (i.e window
contact or door switch).
When the contact is closed, the thermostat will either turn OFF or switch to Economy set points
(please refer to technician settings).
Contact Input

DIP switch S1 settings
Tel: [phone]
Fax: [phone]
[e-mail]
ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
Pg. 8
Important: Disconnect power to the unit before changing the
configuration of the DIP switches.
Using the internal temperature sensor or connect an
external sensor to T-To terminals
Internal sensor (default)…….... S1.1 On S1.2 Off S1.3 On
External sensor…………..…….S1.1 Off S1.2 On S1.3 Off
On
123456
Default position:
ON
123456 ON
123456
S2
S1
Heat pump (Active in Cool or in Heat)
or Non Heat pump (Electrical or Oil heaters)
Non Heat pump with El. heaters (default)... S1.4 Off S1.5 Off
Non Heat pump with Oil heaters ………….. S1.4 Off S1.5 On
Heat pump system active in Heat…....……. S1.4 On S1.5 Off
Heat pump system active in Cool…………..S1.4 On S1.5 On
Window contact operation (when closes)
Use Economy set points (default)….....……S1.6 On
Turn the unit Off ……………………..……… S1.6 Off
ON
123456
External sensor
ON
123456
Internal sensor
ON
123456
ON
123456
ON
123456
ON
123456
Non Heat pump
With El. heaters
Non Heat pump
With Oil heaters
Heat pump
Active in Heat
Heat pump
Active in Cool
ON
123456
ON
123456
Economy
set points
Turn unit
Off
S1

DIP switch S2 settings
Tel: [phone]
Fax: [phone]
[e-mail]
ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
Pg. 9
Selecting temperature display –
1- Normal display shows room temp. and [+] or [-] buttons shows the set point.
2- Normal display shows the set point. Room temp. cannot be displayed.
Display both room and set point temp. (default)….…... S2.1 On
Display set point temperature only…….…………….…. S2.1 Off
ON
123456
ON
123456
Set point & Room
Set point only
Fan speeds configuration
One Fan speed (default)………...…...…….. S2.2 Off S2.3 Off
Two Fan speeds…………….……..….…….. S2.2 On S2.3 Off
Three Fan speeds…………….……….……..S2.2 On S2.3 On
Enabling or disabling Auto change over mode
Enable the use of Auto mode (default)…………….……S2.4 On
Disable Auto mode……………………...…………...……S2.4 Off
Enabling or disabling the 3 minutes compressor delay
3 Minutes compressor delay (default)….………...….….S2.6 Off
No compressor delay….………………...…………..……S2.6 On
Temperature scale
Fahrenheit (default)…………………….……...…….……S2.5 On
Celsius………………….………………...…...……...…… S2.5 Off
ON
123456
ON
123456
ON
123456
One speed Two speeds
Three speeds
ON
123456
ON
123456
Enable Auto
mode
Disable Auto
mode
ON
123456
ON
123456
FahrenheitCelsius
ON
123456
ON
123456
3 Minutes delay No delay
Important: Disconnect power to the unit before changing the
configuration of the DIP switches.
On
123456
Default position: S2
ON
123456 ON
123456
S2
S1

Tel: [phone]
Fax: [phone]
[e-mail]
ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
Pg. 10
1. Enter technician settings mode:
Adjust the set-point temperature to 10°C or to 50°F.
Press and hold the [Mode] button for 15 seconds to enter technician settings mode.
Use the [Mode] button to move between parameters 2-7.
Use the [+] and [-] buttons to make adjustments.
When finished, press the [Mode] button and Readjust he set point.
Technician Settings
Communication MAC Address
Adjust the set point temperature to 11°C or to 51°F.
Press and hold the [Mode] button (15 sec.) to enter
MAC Address settings mode.
Use the [+] and [-] buttons to change the MAC
Address (range 1 to 99)
When finished, press the [Mode] button and
Readjust he set point.
* Do not use the same MAC Address for two units.
F
o
SET
Cool
2. Adjusting the temperature limit for Cool
(range 10...30°C/50...86°F, default 10°C/50°F).
3. Adjusting the temperature limit for heat
(range 10...30°C/50...86°F, default 30°C/86°F).
4. Adjusting the Offset for calibration of measured temperature
(range -5…+5°C/-9…+9°F, default 0°C/0°F).
5. Adjusting the Dead zone
(range 2…5°C/4…9°F, default 2°C/4°F).
6. Adjusting the set point temp. for cooling in economy mode
(range 18...30°C/64...86°F, default 26°C/79°F).
7. Adjusting the set point temp. for heating in economy mode
(range 10...22°C/50...72°F, default 12°C/54°F).
F
o
SET
F
o
Cool
Aux
F
o
SET
Heat
F
o
SET
Aux
F
o
Heat
Aux
F
o
SET
1. Enter
technician
settings
2. Limit Cool
3. Limit Heat
4. Offset
5. Dead zone
6. EC Cool
7. EC Heat
F
o
SET
Enter MAC
Addr. settings
Communication MAC
Address (1-99)

Tel: [phone]
Fax: [phone]
[e-mail]
ETNC24-SUPER-MDB-01
Owner’s manual & Technician Settings
Pg. 11
Technician Settings

Tel: [phone]
Fax: [phone]
[e-mail]
