Mercia Garden Products 01SBS0202-V1 Instruction manual

P 1
01SBS0202-V1
Single Wheelie Bin Store
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All building’s should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
**Protim Aquatan T5 (621)**
Your building has been treated with Aquatan.
Aquatan is a water-based concentrate which is diluted with water, the building as been treated by the correct
application of Aquatan solution and then allowed to dry.
Aquatan is a decorative nish to colour the wood, which is applied industrially to timber fence panels and
garden buildings.
Aquatan undiluted contains: boric acid, sodium hydroxide 32% solution, aqueos mixture of sodium dioctyl
sulphosuccinat and alcohols: 2, 4, 6-trichlorophenol.
Please retain product label and instructions for future reference
General Instructions
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied)
including a Phillips screwdriver, Stanley knife, wood saw, step ladder and drill with 2mm
bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather conditions.
For the duration of heavy or extended periods of rain, swelling of the wood panels may
occur. Warping of the wood may also occur during excessive dry spells due to an interior
moisture loss. Unfortunately, these processes cannot be avoided but can be helped. It is
suggested that the outdoor building is sprayed with water during extended periods of
warm sunshine and sheltered as much as possible during rain or snow.
Our buildings are pre treated with a water based treatment**; this only helps to protect
the product during transit and for upto 3 months against mould. To validate your
guarantee and ensure longevity of the product, it is ESSENTIAL the building is treated
with a wood preserver within the rst three months of assembly and thereafter in
accordance with the manufactures recommendations. Care must be taken to ensure
the product is placed on a suitable base.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to
diagrams for the base dimensions, The base should be slightly smaller than the external
measurement of the building, i.e. The cladding should overlap the base, creating a run
o for water. It is also recommended that the oor be at least 25mm above the
surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in
the case of childrens products independently tested to EN71 level, we cannot accept
responsibility for your safety whilst erecting or using this product.
Refer to the instructions pages for you specic product code

50mm Screws x8
30mm Screws x32
1
2
Step 1
Rest the back panel and 1x side panel against
each other (ensuring they level & the back
panel overlaps the side panel) and secure
together using 2x50mm screws.
2x50mm Screws
Pre drill
hole
50mm
screw
a
a
Step 2
Following the same method outlined in
step 1....
Rest the second side panel against
the back panel (ensuring it is level
& the back panel overlaps the
side panel) and secure to the
assembly using 2x50mm screws.
2x50mm Screws
a
Pre drill
hole
50mm
screw
1
20mm Screws x6
30mm Black Screws x1
P 2
01SBS0202-V1
Overall Dimensions:
Length = 840mm
Width = 750mm
Height = 1115mm
Base Dimensions:
Length = 840mm
Width = 750mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
1
Side Panel QTY 2 Back Panel Lid Door
2 3 4
5
Panel Frame - 28x28x750mm
6
“U” Bracket - 670mm
7
Butt Hinge QTY 4
8
Turn Button
Nail Bag

a
b
5
6
Step 3
Place the “U”bracket at the between the
two side panels at the bottom, and x into
place with 4x20mm screws.
Attach the panel frame at the front of the
assembly (ensuring the panel frame is level
with the top of the assembly) and secure
using 2x50mm screws.
4x20mm Screws
2x50mm Screws
Pre drill
hole
20mm
screw
50mm
screw
a
b
7
Step 4
Place the lid on top of the assembly
(ensuring it sits level and ush around
all sides) and x into place using 2x
butt hinges, securing with 6x30mm
screws per hinge.
12x30mm Screws
Pre drill
hole
30mm
screw
3
7
Step 5
Locate the door inbetween the two
side panels and secure into place
using 2x butt hinges and 12x30mm
screws.
*Ensure to align the boards with the
side panel as shown in the illustration.
12x30mm Screws
Pre drill
hole
30mm
screw
Step 6
Once the assembly is square & level around
all sides, screw through the boards on the
back panel into the side panel framing with
6x30mm screws.
*This helps to keep your bin store rigid.
6x30mm Screws
Pre drill
hole
30mm
screw
P 3
Please retain product label and instructions for future reference

Step 7
Attach the turn button to the side panel
framing using 1x30mm black screw.
*Do NOT screw the turn button too tight.
6x30mm Black Screws
Pre drill
hole
30mm
screw
It is ESSENTIAL that you apply wood treat-
ment immediately after the building has
been assembled.
P 4
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
