Sony RM-AX4000 - Integrated Remote Commander Administrator guide

Remote Commander
settings
About the factory setting
The Remote Commander (RM-AX4000) is preset at
the factory to operate most Sony brand AV
components (see the table below).
If you operate a non-Sony AV component, you need
to set the component’s preset code on the Remote
Commander first.
Default components list
Displays on Component
Remote
Commander
TV TV
A-CBL Analog Cable box
D-SAT *1Digital Satellite
DVD DVD player
VCR Video Cassette Recorder
DVR Digital Video Recorder
CD CD player
RCVR Receiver/Amplifier
DVDVR DVR/DVD Combo
DVD-R DVD Recorder
D-CBL *1Digital Cable box
DAV DVD/Receiver Combo
PJ Projector
TAPE *2Cassette deck*
MD MD deck
LIGHT Light
*1If your component has the built-in DVR function,
preset the “code No.” of DVR.
*2Analog audio compact cassette deck
Setting the preset codes by
On-Remote Setup
You should register components to the Remote
Commander by setting their preset codes.
Setting of the preset code is required in the
following cases:
–To use a Sony component that is not registered to
the Remote Commander by the default setting
–To use other brands of components
Example: To set up a Philips TV
1See the tables at right, and find the
four-digit preset code for the desired
component.
If more than one preset code is listed for
the component, use the first number on
the list.
For example, to set up a Philips TV, you
would use the preset code “8011.”
2While pressing the COMMANDER
OFF button, press the MUTING
button.
MUTING
OFF
COMMANDER
“SET” appears as the Display title.
SET /1
SU
LEARN
NG
PRESET LEARN MACRO TIMER
3Press “PRESET” on the Label keys.
PRESET
“PRESET” appears as the Display title.
The component name flashes on the Label
keys.
If a page number such as “/1” appears to
the right side of Display title, multiple
pages are available. Press the number to
go to the next page.
PRESET /1
SU
LEARN
NG
TV A-CBL D-SAT DVD
4Select the component name you want
the Remote Commander to preset by
pressing the Label key (in this case,
TV).
TV
The “TV” and current preset code (in this
case, “8001”) appear as the Label keys.
“0” - “9,” “CLEAR” and “POWER” flash.
PRESET
213
546
8
0
79
POWER
CLEAR
LEARN
NG
TV 8001
Note
If another remote control signal has already been
learned, the delete confirmation message appears.
Register the components after deleting the learned
signal following the procedure of the LCD display.
PRESET
SU
LEARN
NG
DELET LEARN? YES NO
5Press the “8,” “0,” “1,” and “1”
number keys.
Tip
Each time the CHANNEL +/– button is pressed,
the preset code increases/decreases by 1.
If you make a mistake in inputting
Press the CLEAR key. The preset code returns to
the previous number.
6Press the OK button.
OK
A beep sounds and the input preset code
appears on the Label key momentarily.
PRESET
SU
LEARN
NG
TV TV 8011 OK
“PRESET” appears as the Display title.
PRESET /1
SU
LEARN
NG
TV A-CBL D-SAT DVD
7Press and hold the COMMANDER
OFF button for more than 2 seconds.
OFF
COMMANDER
The Remote Commander turns off.
If you want to quit before finishing
Press and hold the COMMANDER OFF button for
more than 2 seconds. The previous status returns,
and the Remote Commander turns off.
If you want to return to the previous
display
Press the BACK button or the COMMANDER OFF
button, the previous LCD display returns.
Notes
•If you enter a preset code that is not on the table
at right, the Remote Commander beeps five times.
The digits you input and “NG” appear on the
Label key after you press the OK button. The
previous setting returns. If this happens, check the
preset code, and try setting again.
• If you do not enter any data to the Remote
Commander for over 2 minutes between each
step, the setup procedure will be canceled. To set
the preset code again, press the MUTING button
while pressing the COMMANDER OFF button.
•Except the DVD/Receiver combo (DAV), the
components with the built-in amplifier should be
registered as RCVR (Receiver). All the keys that
are inoperative should be registered by the
learning function.
2005 Sony Corporation Printed in Malaysia
2-635-474-11 (1)
RM-AX4000
Preset code lists
Analogue Cable box (A-CBL)
Brand
Hamlin/Regal
Jerrold/G.I.
NET
Oak
Panasonic
Pioneer
Scientific Atlanta
Tocom
Zenith
Code No.
9022, 9023, 9024, 9025, 9026
9044, 9001, 9002, 9003, 9004, 9005,
9006, 9007, 9008, 9018, 9043, 9022
9042
9027, 9028, 9029
9019, 9020, 9021
9014, 9015
9009, 9010, 9011
9016, 9017, 9043
9012, 9013
Digital Cable box (D-CBL)
Brand
Sony
Jerrold/G.I.
Motorola
Philips
Scientific Atlanta
Code No.
3101
3103
3103
3104
3102
Brand
Sony
Admiral
Akai
AOC
Audinac
Bell & Howell
Broksonic
CCE
Cineral
Craig
Croslex
Crown
Curtis Mathis
Daewoo
Daytron
Emerson
Fisher
General Electric
Goldstar/LG
Gradiente
Hitachi
JC Penny
JVC
KTV
LXI (Sears)
Magnavox
Marantz
Mitsubishi/MGA
NEC
Noblex
Panasonic
Philco
Philips
Pioneer
Portland
Proton
Quasar
Radio Shack
RCA/PROSCAN
Samsung
Sanyo
Scott
SEMP Toshiba
Serie Dorada
Sharp
Signature 2000
Sylvania
Symphonic
Toshiba
Videch
Wards
Zenith
Code No.
8001
8002, 8014, 8009
8003
8012
8034
8014, 8009, 8038
8003, 8012, 8075
8063, 8072, 8011, 8041, 8073
8035, 8034
8022, 8023, 8020, 8021
8011
8023
8003, 8019, 8023
8035, 8036, 8003, 8041, 8073
8013
8022, 8013, 8020, 8021, 8023, 8003,
8015, 8042
8025
8002, 8018, 8003, 8007, 8045, 8049
8003, 8013, 8012, 8030, 8046, 8050,
8051, 8049
8064, 8065, 8028, 8006
8031, 8013, 8003, 8032
8003, 8002, 8030, 8007
8028, 8029
8033, 8013, 8003, 8023, 8034
8002, 8003, 8011, 8025, 8019, 8012,
8052
8011, 8012, 8013, 8003, 8043, 8047
8024
8024, 8003, 8012, 8066
8003, 8012
8057, 8061, 8062
8018, 8016, 8017, 8007, 8049, 8067,
8077, 8079
8011, 8013, 8003, 8068, 8035, 8031
8011, 8056, 8043
8037, 8018, 8019
8003, 8008
8071
8018, 8007, 8048
8002, 8012, 8024, 8023, 8015
8002, 8003, 8004, 8005, 8006, 8007,
8008, 8044, 8045, 8046, 8053
8026, 8012, 8013, 8003, 8055, 8027
8025, 8054, 8069, 8023
8023, 8012
8019
8058
8014, 8013, 8015, 8070
8014, 8009
8011, 8012, 8003, 8076
8023, 8039, 8040, 8074
8019, 8014, 8059, 8060, 8078, 8052
8031, 8003, 8012
8013, 8003, 8015, 8012
8009, 8010
TV
Brand
Sony
Admiral
Aiwa
Akai
B&O (Bang&Olufsen)
Crown
Daewoo
Denon
Finearts
Garrard
Goldstar/LG
Harman/Kardon
Jensen
JVC
Kenwood
Magnavox
Marantz
McIntosh
NAD
Nakamichi
Onkyo
Panasonic
Parasund
Philips
Pioneer
RCA
Rebox
Rotel
SABA
Samsung
Sansui
Sanyo
Sharp
Sherwood
Schneider
Sounde-sign
T+A
Teac
Technics
Toshiba
Yamaha
Code No.
4001, 4002, 4003, 4107
4095
4022, 4023, 4040, 4079
4074
4068
4062
4005
4010, 4024, 4027, 4028, 4036, 4037
4044
4058
4009
4035
4061
4019, 4020, 4047, 4070, 4078, 4098
4015, 4016, 4025, 4071, 4082, 4083
4021
4029, 4094, 4044, 4017
4097
4103, 4033
4104, 4087, 4086
4034, 4039, 4043, 4084
4008, 4077, 4099
4066
4017
4006, 4018, 4032, 4072, 4081, 4085,
4090
4105, 4091, 4092, 4093
4050
4067
4041
4042
4086, 4087, 4089, 4038
4011
4028, 4037, 4080, 4100, 4016
4012, 4013, 4031
4004, 4069
4096
4063
4088, 4055
4007, 4026, 4045, 4073, 4008
4101
4102, 4014, 4030, 4046
Receiver/Amplifier (RCVR)
Code No.
6001, 6002, 6005
6042, 6045, 6025
6028, 6029, 6009, 6010
6011
6008
6033
6022, 6023, 6024
6036, 6037, 6015, 6016
6047
6031, 6032
6079
6038, 6039, 6040, 6041, 6043, 6044
6067
6047
6034, 6035, 6020, 6021, 6006
6084, 6085
6079, 6077, 6078
6011
6028
6077, 6078, 6080, 6081
6046, 6007, 6067
6030, 6014
Cassette deck (TAPE)
Brand
Sony
Aiwa
Denon
Fisher
GoldStar/LG
Harman/Kardon
JVC
Kenwood
Marantz
NAD
Nakamichi
Onkyo
Panasonic
Philips
Pioneer
RCA
Sansui
Sanyo
Sharp
Teac
Technics
Yamaha
MD deck (MD)
Brand
Sony
Aiwa
Akai
Denon
JVC
Kenwood
Marantz
Onkyo
Panasonic
Pioneer
Sansui
Sharp
Teac
Yamaha
Code No.
7001, 7002
7012
7018
7003
7008
7004, 7011, 7014
7007
7015
7006, 7010
7016
7009
7013
7005
7017
DVD/Amplifier Combo (DAV)
Brand
Sony
Code No.
0501, 0502, 0503, 0504, 0505
DVR/DVD Combo (DVDVR)
Brand
Sony
Panasonic
Pioneer
Toshiba
Code No.
0401, 0402, 0403
0405, 0406, 0407
0404, 0409, 0410
0408, 0411
DVD player (DVD)
Brand
Sony
Aiwa
Daewoo
Denon
Funai
Harman/Kardon
Hitachi
JVC
KLH
Onkyo
Panasonic
Philips
Pioneer
RCA
Samsung
Sharp
Shinco
Sylvania
Thomson
Toshiba
Yamaha
Zenith
LG
Marantz
Teac
Mitsubishi
Code No.
0001, 0024, 0023, 0025, 0030
0015
0029
0006, 0017, 0002
0020
0018
0008
0007, 0208
0010
0016
0002, 0006, 0027, 0028
0012
0004, 0019, 0021
0005
0014
0011
0022
0020
0013
0003
0006
0009
0009
0012
0022
0026
Digital Satellite receiver (D-SAT)
Brand
Sony
Hitachi
Hughes
Panasonic
RCA/Proscan
Toshiba
Code No.
3001, 3011, 3012
3005
3004
3003
3002, 3007
3006
DirecTV
Brand
Lutron
X10
Code No.
2001
2004
2002
2001
2003
2006
2005
Product
Grafik Eye
HomeWorks interactive
RadioRA
Spacer
Spacer System
Sivoia Shades
Light (LIGHT)
Projecter (PJ)
Brand
Sony
Code No.
8501
DVD Recorder (DVD-R)
Brand
Sony
Broksonic
Funai
JVC
LG
Panasonic
Philips
Pioneer
Samsung
Sharp
Sylvania
Toshiba
Zenith
Code No.
0203, 0201, 0202, 0211
0214
0220
0208
0218
0205, 0206, 0207, 0213, 0216
0221
0204, 0222, 0223
0212
0219
0215, 0220
0209, 0210, 0217, 0224
0218
Laser Disc (LD)
Brand
Sony
Hitachi
Kenwood
Magnavox
Panasonic
Philips
Pioneer
Sanyo
Sharp
Code No.
0101, 0102, 0103, 0104
0108
0113, 0114
0110
0105, 0106, 0107
0115
0109
0112
0111, 0116
Digital Video Recoder (DVR)
Brand
Sony
Panasonic
Philips
Replay
Scientific Atlanta
Code No.
3201, 3205, 3206, 3207, 3208, 3209,
3210
3203
3202
3204
3211
Code No.
1001 (VTR1: Beta)
1002 (VTR2: 8 mm)
1003 (VTR3: VHS)
1004, 1005, 1006 (VTR4, 5, 6: DV)
1030
1041, 1050, 1035
1052, 1053, 1054
1017, 1040
1033, 1046
1020, 1022, 1017, 1066
1012, 1011
1018, 1044, 1035, 1064
1044, 1064
1035
1018, 1035
1007, 1041, 1012
1044, 1015, 1012, 1064
1017, 1039, 1040
1007
1044, 1022, 1023, 1019, 1020, 1021,
1041, 1058
1033, 1037, 1038, 1036
1041
1032, 1007, 1012, 1062
1035
1051, 1042, 1043
1061, 1047, 1041
1011, 1007, 1008
1015
1012, 1011
1012, 1008, 1007, 1033, 1017, 1039,
1040
1017, 1047, 1048, 1049, 1039, 1040
1017, 1039, 1035, 1040
1041, 1035, 1008, 1036, 1037, 1033,
1038, 1052
1013, 1011, 1012, 1010, 1063
1017, 1039, 1040
1035
1012, 1038
1008, 1007
1026, 1027, 1028, 1029, 1056, 1057,
1065, 1059
1028, 1041, 1024
1017, 1039, 1040
1044, 1064
1012, 1011
1027
1055
1009, 1010, 1011, 1012, 1060, 1068
1008, 1007
1011, 1012, 1064, 1044, 1020
1035, 1013, 1011, 1012, 1063
1011
1011, 1012, 1009, 1010, 1006
1007, 1008, 1011, 1012, 1013, 1014,
1015, 1016, 1063
1012, 1033, 1031, 1038, 1027, 1041
1025, 1016, 1024
1017
1033, 1038, 1064, 1046, 1044, 1035
1015, 1016, 1024, 1038, 1026, 1027,
1028, 1029
1025
1030, 1031
1018
1041, 1030
1018
1013, 1011, 1012, 1041, 1063, 1067
1041
1035
1017, 1039, 1040
1017, 1039, 1041, 1040
1012, 1011
1015, 1014, 1052, 1069
1030, 1031, 1038, 1034, 1035
1033, 1017, 1039, 1040
1034
Brand
Sony
Admiral
Aiwa
Akai
Audio Dynamic
Bell & Howell
Broksonic
Canon
CCE
Cineral
Citizen
Craig
Curtis Mathis
Daewoo
DBX
Dimensia
Emerson
Fisher
Funai
General Electric
Goldstar/LG
GO VIDEO
Gradiente
Hitachi
HQ
Instant Replay
JC Penny
JVC
Kenwood
LXI (Sears)
Magnavox
Marantz
Marta
Memorex
Minolta
Mitsubishi/MGA
Multitech
NEC
Nokia
Olympic
Optimus
Orion
Panasonic
Pentax
Philco
Philips
Pioneer
Quasar
RCA/PROSCAN
Realistic
Samsung
Sansui
Sanyo
Scott
SEMP Toshiba
Sharp
Shintom
Signature 2000
Singer
Sylvania
Symphonic
Tashiro
Tatung
Teac
Technics
Toshiba
Wards
Yamaha
Zenith
Video Cassette Recorder (VCR)
Brand
Sony
Admial
Aiwa
Akai
B&O (Bang&Olufsen)
Crown
Daewoo
Denon
Emerson
Fisher
Goldstar/LG
Harman/Kardon
Hitachi
Jensen
JVC
Kenwood
Magnavox
Marantz
McIntosh
NAD
Nakamichi
Onkyo
Optimus
Panasonic
Philips
Pioneer
RCA
SABA
Samsung
Sansui
Sanyo
Schneider
Sharp
Sherwood
Sounde-sign
T+A
Technics
Toshiba
Yamaha
CD player (CD)
Code No.
5001, 5002, 5099, 5100, 5101
5085
5021, 5022, 5037, 5074
5068
5063
5059
5003
5008, 5009, 5023, 5026
5091
5040
5098, 5007
5031
5041
5084
5018, 5019, 5033, 5073
5014, 5015, 5024, 5034, 5065, 5077,
5078
5016, 5026
5071
5090
5029
5044, 5082
5030, 5035, 5038, 5079
5092
5006, 5072, 5094
5016
5004, 5017, 5028, 5066, 5076
5080, 5081, 5088, 5089
5042
5043
5082, 5083, 5086
5010
5064
5075, 5095
5011, 5012, 5039
5087
5060
5005, 5025, 5032, 5067
5096, 5097
5013, 5027, 5036

Operating components
individually
EPG MENU
SYSTEM CONTROL
OK
1 MORE43
COMPONENT
VOLUME
BACK
X PRESS
2
RECALL
LIGHTTIMER
MUTING
SYNC-UP
CHANNEL
EXIT TOOLS
ALL OFF
LEARN
NG
OFF
COMMANDER
When you press the COMPONENT button on the
Remote Commander, the component names appear
at the bottom of the display.
COMPONENT /1
SU
AM
LEARN
NG
TV A-CBL D-SAT DVD
When you press a component name you want to
operate, the display to operate the component
appears. This display is called “Component
display.” Keys on the Component display are
divided into two types—“Touch-keys” with preset
labels and “Label keys” that can be customized.
TV /1
SU
AM
213
546
ENTER
8
0
79
POWER
WIDE
INPUT
SWAP
DISPLAY
MAIN/SUB
2PIC
LEARN
NG
TV_TUNER ANT/SW
Example: To change the input select of the TV
1Press the COMPONENT button.
COMPONENT
“COMPONENT” appears as the Display
title.
COMPONENT /1
SU
AM
LEARN
NG
TV A-CBL D-SAT DVD
If a page number such as “/1” appears to the
right side of Display title, multiple pages are
available. Press the number to go to the next
page.
2Press the component name you want
to operate (in this case, TV).
TV
The component name appears as the
Display title.
And the keys you use to control the TV
are displayed as Touch-keys.
TV /1
SU
AM
213
546
ENTER
8
0
79
POWER
WIDE
INPUT
SWAP
DISPLAY
MAIN/SUB
2PIC
LEARN
NG
TV_TUNER ANT/SW
If a page number such as “/1” appears to
the right side of Display title, multiple
pages are available. Press the number to
go to the next page.
VCR
Preset code
No.
Full display
You can use the
following tables as a
memorandum for any
component.
3Press the key(s) or button(s) you
want to operate.
Example:
1Press the POWER key.
POWER
2Press the INPUT key repeatedly until
the desired input is selected.
INPUT
When the signal is sent, appears. You
can also use other buttons, such as the
VOLUME +/–, CHANNEL +/–,
MUTING, cursor, and MENU buttons.
4When you are finished using the
Remote Commander, press the
COMMANDER OFF button.
OFF
COMMANDER
The Remote Commander turns off.
If you want to return to the previous
display
Press the BACK button, the previous LCD display
returns.
To control the volume
EPG MENU
SYSTEM CONTROL
OK
1 MORE43
COMPONENT
VOLUME
BACK
X PRESS
2
RECALL
LIGHTTIMER
MUTING
SYNC-UP
CHANNEL
EXIT TOOLS
ALL OFF
LEARN
NG
OFF
COMMANDER
Press the VOLUME +/– buttons to control the
volume, and the MUTING button to silence. When
you select a visual component, the TV’s volume will
be controlled; when you select an audio component,
the amplifier’s volume will be controlled.
0123456789ABCDEFGHIJKLMNOPQRSTUV
0123456789AB
SU
PM
AM
213
546
JKLGHI MNO
TUVPQRS WXYZ
ENTER
12
SYMBOL 2
+100
10 11
SYMBOL 1
ABC DEF
8
0
79
MO TU WE TH FR SA
ON OFF
POWER
LOCK
VIDEO 3
TAPE
SHIFTTV
DONE
WIDE
MD
DVD
REC
D.SKIP
CLEAR
INPUT
SWAP
VIDEO 2
AUX
BAND
FAVORITE
PHONO
DISPLAY
MAIN/SUB
SUB TITLE
5.1 INPUT
LIST
2PIC
VIDEO 1
A/B
INFO
TUNER
TOP MENU
S.INDEX
CD
LEARNLEARN
NGNG
0123456789ABCDEFGHIJKLMNOPQRSTUV
0123456789AB
SU
PM
AM
213
546
JKLGHI MNO
TUVPQRS WXYZ
ENTER
12
SYMBOL 2
+100
10 11
SYMBOL 1
ABC DEF
8
0
79
MO TU WE TH FR SA
ON OFF
POWER
LOCK
VIDEO 3
TAPE
SHIFTTV
DONE
WIDE
MD
DVD
REC
D.SKIP
CLEAR
INPUT
SWAP
VIDEO 2
AUX
BAND
FAVORITE
PHONO
DISPLAY
MAIN/SUB
SUB TITLE
5.1 INPUT
LIST
2PIC
VIDEO 1
A/B
INFO
TUNER
TOP MENU
S.INDEX
CD
LEARNLEARN
NGNG
TV
Preset code
No.
TV /1
SU
AM
213
546
ENTER
8
0
79
POWER
WIDE
INPUT
SWAP
DISPLAY
MAIN/SUB
2PIC
LEARN
NG
TV_TUNER ANT/SW
A-CBL
Preset code
No.
A-CBL /1
SU
AM
213
546
ENTER
8
0
79
POWER
LEARN
NG
D-SAT
Preset code
No.
D-SAT /1
SU
AM
213
546
ENTER
8
0
79
POWER
INPUT
FAVORITE DISPLAY
INFO
S.INDEX
LEARN
NG
CATEGORY
DVD
Preset code
No.
DVD /1
SU
AM
213
546
ENTER
8
0
79
POWER
DISPLAY
SUB TITLE
A/B
TOP MENU
LEARN
NG
TIME SET_UP SLOW
VCR /1
SU
AM
213
546
ENTER
8
0
79
POWER
REC
INPUT
DISPLAY
MAIN/SUB
LEARN
NG
PLAYx2 Q.TIMER SP/LP H.S.REW
DVR
Preset code
No.
DVR /1
SU
AM
213
546
ENTER
8
0
79
POWER
REC
INPUT
DISPLAY
LIST
LEARN
NG
REPLAY LIVE_TV
CD
Preset code
No.
RCVR
Preset code
No.
CD /1
SU
AM
213
546
ENTER+10
8
0
79
POWER
D.SKIP
CLEAR
DISPLAY
LEARN
NG
REPEAT SHUFFLE PROGRAM CONTINUE
POWER
VIDEO 3
TAPE
SHIFTTV
MD
DVD
VIDEO 2
AUX
BANDPHONO
5.1 INPUT
VIDEO 1TUNER
CD
RCVR /1
SU
AM
213
546
ENTER+10
8
0
79
LEARN
NG
S.FIELD GENRE MODE T.TONE
DVDVR
Preset code
No.
DVDVR /1
SU
AM
213
546
ENTER
8
0
79
POWER
REC
INPUT
DISPLAY
LIST
TOP MENU
LEARN
NG
HDD DVD TIMER
DVD-R
Preset code
No.
DVD-R /1
SU
AM
ENTER
POWER
REC
DISPLAY
SUB TITLE
A/B
TOP MENU
LEARN
NG
TIME
213
546
8
0
79
D-CBL
Preset code
No.
D-CBL /1
SU
AM
213
546
ENTER
8
0
79
POWER
INPUT
FAVORITE DISPLAY
LEARN
NG
HOME VIEWER
DAV
Preset code
No.
POWER
BAND
DISPLAY
TUNER
TOP MENU
DAV /1
SU
AM
213
546
ENTER+10
8
0
79
LEARN
NG
D.SKIP S.FIELD EJECT
INPUT
SUB TITLE
PJ
Preset code
No.
PJ /1
SU
AM
POWER
WIDEINPUT
DISPLAY
LEARN
NG
RESET
TAPE
Preset code
No.
POWER
REC
DISPLAY
TAPE /1
SU
AM
213
546
8
0
79
LEARN
NG
REC_REV REC_FWD FADER REC_MUTE
MD
Preset code
No.
POWER
REC
DISPLAY
MD /1
SU
AM
213
546
ENTER+10
8
0
79
LEARN
NG
REPEAT SHUFFLE PROGRAM CONTIUE
D.SKIP
CLEAR
LIGHT
Preset code
No.
LIGHT /1
SU
AM
213
546
1210 11
879
POWER
LEARN
NG
SCENE13 SCENE14 SCENE15 SCENE16
COMPONENT
button
Touch-keys
Label keys
Component
names
Component display
VOLUME +/–
button
MUTING
button
Information
The Remote Commander is displayed at the factory setting to operate most Sony brand components as
follows. If you change the preset code, the display for operating component also is changed.
