VABCHES D8L245BS01 User manual

1/31
As this item contains many parts, please read the installation
instruction carefully before installation and complete the
installation with the cooperation of your partner. Please use
tools properly and carefully. If you have any questions about
the product and installation, please contact us.
Our professional after-sales team will serve you online all
[e-mail]
day.
D8L245BS01
WhatsApp community↑

Before You Start
P
P
P
P
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware of to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P
Helpful Hints
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-03.bmp
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-04.bmp
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-05.bmp
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-010.bmp
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-011.bmp
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-012.bmp
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with an R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
PEOPLE NEEDED FOR ASSEMBLY: 1-2
2/31

Board Identification
Not actual size
3/31
A
TOP
Qty:1
B
LEFT SIDE PANEL
Qty:1
C
Qty:1
RIGHT SIDE PANEL
D
UPPER BACK PANEL
Qty:1
E
Qty:1
F
Qty:1
FRONT SLAT PANEL
G
PARTITION
Qty:1
H
HOTCH SIDE PANEL
Qty:2
I
Qty:2
LOWER BACK PANEL
HOTCH SIDE PANEL

Board Identification
Not actual size
4/31
J
HOTCH FIXED SHELF
Qty:1
K
DRESSING MIRROR
Qty:1
L
Qty:2
N
Qty:2
O
Qty:2
P
Qty:2
M
Qty:2
R
Qty:2
STOOL SIDE PANEL
Q
Qty:1
STOOL BACK APRON
DRAWER FRONT
DRAWER LEFT SIDE
DRAWER RIGHT SIDE
DRAWER BOTTOM
DRAWER BACK PANEL

V
Qty:1
BACK PANEL
Board Identification
Not actual size
5/31
S
Qty:1
STOOL FRONT APRON
T
Qty:1
STOOL BOTTOM BOARD
U
Qty:1
SPONGE CUSHION

Not actual size
Board Identification
6/31
A
B
C
D
E
F
G
H
I
H
I
J
K
L
N
O
P
RS
T
U
R
M
N
O
P
Q
V
L
M

Part List
7/31
∅15X9.5mm
1X25
CAM LOCK
spare：2
∅6X35mm
2X25
CAM BOLT
spare：2
∅8X30mm
3X19
WOOD DOWEL
spare：1
4X27
SCREW
∅3.5X14mm
5X19
SCREW
spare：2
∅4X35mm
6X34
SCREW
spare：2
X2
X2 X2 12 X9
LIGHT BULB
13 X2
HINGE
∅6.3X50mm
spare：2
7X14
SCREW
spare：1
8X4
SCREW
10 X2 X2
11CL
∅3X14mm
M4*18mm
HANDLE
11CR
11DL 11DR
350mm
LEFT CABINET MEMBER RIGHT CABINET MEMBER
LEFT DRAWER RUNNER RIGHT DRAWER RUNNER
106*8*16mm
∅25mm
350mm
350mm 350mm
9X12
spare：1
∅8X40mm
WOOD DOWEL

14
Part List
8/31
15 X1 X2 16
Cam Lock
Fastening
System
12
34
X40
The opening must point toward the
edge of the board
Insert the cam bolt into the
hole first, then insert the cam
lock and lock it.
17 X1
HAIR DRYER RACK
∅21mm
PERFECT STICKER
18 X1
HEX KEY
X1 set
TIPPING RESTRAINT
HARDWARE KIT
POWER STRIP
∅4X14mm
SCREW
109*99*38.5mm
20
4*65mm

STEP1
B
C
11CL
6
6
6
LEFT CABINET MEMBER
11CR
RIGHT CABINET MEMBER
6
6
6
UP
UP
∅3.5X14mm
6X6 X1
11CL
350mm
X1
11CR
350mm
9/31

STEP2
FLIP OVER
11CR
11CL
LEFT CABINET MEMBER
RIGHT CABINET MEMBER
∅3.5X14mm
6X6 X1
11CL
350mm
X1
11CR
350mm
6
6
6
6
6
6
UP
UP
G
G
10/31

STEP3
F
G
∅8X30mm
3X8 X2
3
D
E
11/31
5
∅4X35mm
5

STEP4
12/31
∅8X30mm
3X1 X1
5
∅4X35mm
G
D
5
3

STEP5
13/31
4X6
∅6.3X50mm
18 X1
4*65mm
14 X6
∅21mm
THIS STEP REQUIRES 2 PEOPLE
D
B
F
B
E
4
14

STEP6
4X6
∅6.3X50mm
18 X1
4*65mm
14 X6
∅21mm
14/31
THIS STEP REQUIRES 2 PEOPLE
C
4
14
E
D

STEP7
B
C
∅8X30mm
3X8
3
15/31

16/31
STEP8
∅15X9.5mm
1X8
∅6X35mm
2X8
J
2
Proper orientation of CAM LOCK
UNLOCK
LOCK
14 X8
∅21mm
I
H
H
I
EDGE BANDING
J
14
1

STEP9
A
A
5X8
∅4X35mm ∅6X35mm
2X9
2
5
17/31
I
EDGE BANDING

STEP10
∅15X9.5mm
1X6
Proper orientation of CAM LOCK
UNLOCK
LOCK
18/31
A
B
C1
THIS STEP REQUIRES 2 PEOPLE

STEP11
∅15X9.5mm
1X3
Proper orientation of CAM LOCK
UNLOCK
LOCK
19/31
∅8X30mm
3X2
D
C
J
1
3

STEP12
20/31
K
20
4X3
∅6.3X50mm
18 X1
4*65mm
X1 set
20
Place one item underneath the
product to make the product
stable and easy to install
K
4
90°
THIS STEP REQUIRES 2 PEOPLE
