Merry Products MPG-GDB Installation guide

Classic Glider Bench - MPG-GDB
Please check contents before assembly. If any items are missing or damaged, do not take the unit back to
the store. Please call [phone] for customer service and we will save you time by correcting any problems.
NOTE: Read all instructions before starting.
COMPONENTS
HARDWARE
page 1 v.2.0
Do not completely tighten any bolts until
the unit is fully assembled and sitting on a
level surface.
PRODUCT
R R YE
S
M
CARE INSTRUCTIONS
The Glider Bench has been conditioned for outdoor use with an oil-based color stain. To maintain the
beauty and life expectancy of the chair, it is highly recommended that you treat the chair with weather
proof coating (teak oil stain or weatherproof coating) once a year.
• Cover the Bench during harsh weather to keep it from weathering.
• Rinse any panels with water to clean.
• When assembling MERRY PRODUCTS’™ furniture, please handle all panels and/or hardware
with care to avoid any possibilities of damages and/or injuries.
Screw x 10 Pcs
(M7x60)mm
Bolt x 8 Pcs
(M6x20)mm
Washers x 8 Pcs
Seat
Right Arm Rest
Left Arm Rest
Back Rest Front Cross Beam
Right Glider Leg
Left Glider Leg
Glider Back Cross Beams
Glider Brackets
Glider Front Cross Beam
6
Locking Bolts x 8 Pcs
Screws x 2 Pcs
(M4 x 30)mm
Allen Key x 2 Pcs

Classic Glider Bench - MPG-GDB
page 2 v.2.0
PRODUCT
R R YE
S
M
Step 1: Insert dowelled ends of Back Rest and Front Cross Beam into Left and Right Arm Rests.
Secure with Screws (1) using appropriate Allen Key (6).
Step 2: Insert Seat into place. Secure with 2 Screws (5) underneath the seat using a
Phillips Screwdriver.
5
5

Classic Glider Bench - MPG-GDB
page 3 v.2.0
PRODUCT
R R YE
S
M
Step 3: Assemble Glider Back Cross Beams to Right and Left Glider Legs. Secure with 4 Screws (1)
using appropriate Allen Key (5).
1
1
1
1
Step 4: Assemble Glider Brackets and Glider Front Cross Beam to Glider Legs. Secure with Bolt (2),
Washer (3) and Locking Bolt (4) using appropriate Allen Key (6).
Please reference highlighted area for the correct location of the Bolts,Washers and Locking
Bolts to complete this step.
2
2
2
2
3
3
4
4
2
3
4
2
3
4

Classic Glider Bench - MPG-GDB
page 4 v.2.0
PRODUCT
R R YE
S
M
Step 4: Place the completed Bench portion over the Glider portion. Secure the Glider Brackets
to the legs of the Bench using Bolt (2),Washer (3) and Locking Bolt (4) at each leg. Please
reference the highlighted area for correct placement of hardware at each leg.
Step 5: Tighten all Screws (1) and Bolts (2) using appropriate Allen Keys (6) to complete assembly.
