Sunjoy L-DN2235SST-B-C User manual

Country of Origin: China Production Number: xxxxxxxx
ASSEMBLY INSTRUCTION
ITEM#：L-DN2235SST-B-C
Contact US FIRST
* *
We have you in mind
，
let us help you
！
24 / 7
？Support
www.sunjoyonline.com
24 / 7
[e-mail]
Free
Toll
24 / 7
1-(866)-578-6569
Live Chat

Country of Origin: China Call 1-(866)-578-6569 for assistance.
Or visit us at www.sunjoyonline.com
2/ 10
Safety Information
One people are required for this assembly.
Some parts may contain sharp edges. Wear
protective gloves.
When assembling and using this product,
basic safety precautions should always be
followed to reduce the risk of personal
injury and damage to equipment. Please read
all instructions before assembly and usage.
The limited warranty is extended to the original purchaser and applies to material and manufacturer’s defect provided
the item is maintained with care and used only for personal, residential purposes.
Warranty: 1 Year
WHAT IS COVER?
KEEP THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
CAUTION: Chair is for setting
purpose only. Standing on or misuse of
chair may result in damage or injury.
Not intended for commercial use.
WEIGHT LIMIT 250LBS(113.5KG)
NOTICE:
For outdoor use only.
WARING:
Keep all children and pets away from assembly area.
Children and pets should be supervised when they are
in the area of the Chair construction.
Keep assembly area at least 6 feet from any obstruction
such as a fence, garage, house, overhanging branches,
laundry line or electrical wires.
Check all bolts for tightness before use. IMPORTANT -
check and tighten bolts often to keep them secure!
IMPORTANT
How many people needed for the installation work

Country of Origin: China Call 1-(866)-578-6569 for assistance.
Or visit us at www.sunjoyonline.com
3/ 10
EXPLODED DRAWING

Country of Origin: China Call 1-(866)-578-6569 for assistance.
Or visit us at www.sunjoyonline.com
4/ 10
Parts List
Label
Part Number
Description
Qty
Part Image
A
P30125A01180
Back
4
B
P30227A01180
Seat
4
C1
P30046A01180
Handrail（Right）
4
C2
P30047A01180
Handrail（Left）
4
D
P31214A01180
Chair Base
4
E
P00415H14122
Cushion
4
F
P00501H12122
Back Cushion
4
G
P91008C07001
Foot pad
Pre-assembled
8
H
P91009C07001
Foot pad
Pre-assembled
8
J
P12504E07001
Plastic plug
Pre-assembled
8

Country of Origin: China Call 1-(866)-578-6569 for assistance.
Or visit us at www.sunjoyonline.com
5/ 10
Hardware Pack
Label
Part Number
Description
Qty
Add
Part Image
AA
H06020C11
Bolt M6*20
40
1
BB
H01040C11
Bolt M8*40
16
1
CC
P31601A01100
Big washer
16
1
DD
H22001D11
Nut M8
16
1
EE
H13001D11
Spring
Washer M8
16
1
FF
H12001D11
Flat washer
M8
16
1
GG
H00002C12
Allen Key
Size 4
1
0
HH
H00001D12
Wrench M8
2
0

Country of Origin: China Call 1-(866)-578-6569 for assistance.
Or visit us at www.sunjoyonline.com
6/ 10
1
1x
1x
4x

Country of Origin: China Call 1-(866)-578-6569 for assistance.
Or visit us at www.sunjoyonline.com
7/ 10
2
1x
6x
1x

Country of Origin: China Call 1-(866)-578-6569 for assistance.
Or visit us at www.sunjoyonline.com
8/ 10
3
4x
4x
1x
4x
4x
4x

Country of Origin: China Call 1-(866)-578-6569 for assistance.
Or visit us at www.sunjoyonline.com
9/ 10
4
1x
1x

Country of Origin: China Call 1-(866)-578-6569 for assistance.
Or visit us at www.sunjoyonline.com
10 / 10
Before using, clean the Chair completely with a soft dry towel. When not in use, wipe free of any dirt or loose objects,
wash with a mild solution of soap and water; rinse thoroughly and dry completely. Do not use strong detergent or
abrasive cleaners. Over time nuts and bolts can loosen. Occasionally, check nuts and bolts, re-tighten if necessary.
SUNJOY Group warrants to the original purchaser that this item is free from defects in workmanship and materials for
a period of 1 year from the date of purchase, provided the item was factory-sealed at the time of purchase and is
maintained with care and used only for personal, residential purposes. Should any manufacturing defect arise within
this warranty period, SUNJOY Group will replace (at our option) any defective merchandise or parts upon proof of
purchase; however, transportation and delivery costs, as well as payments to a third party for assembly or disassembly
of the item, remain the responsibility of the purchaser. A purchaser of an "open box," previously-returned, or
"clearance" item, as well as original purchasers outside of the warranty period, may obtain replacement parts from
SUNJOY Group for products in current production, at nominal cost.
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of nature,
vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not covered. Proof of
purchase (dated register receipt) is required for warranty claims. Warranty is to the original purchaser and is
non-transferable. Any replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow exclusions or limitations on an
implied warranty, the above exclusions and limitations may not apply. This warranty gives you specific rights, and you
may also have other rights, which vary from state to state.
Care and Maintenance
Limited Manufacturer’s Warranty
Exclusions:

1 of 19
HD PROVENCE 5PC GAS FIRE PIT TABLE
Assembly Instruction
Item# L-DN2235SST-B-T
This appliance complies with “ANSI Z21.97-2017/CSA 2.41-2017, Outdoor Decorative Gas Appliances.
Propane cylinder required (not included)
1 AA 1.5V battery required (not included)
WARNING: For Outdoor Use Only.
Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, leave the area immediately
4. After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in
fire or explosion, which could cause property
damage, personal injury, or death.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
WARNING
Do not store or use gasoline, or other flammable vapors and liquids, in the vicinity of this or
any other appliance.
An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
DANGER CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper, tent,
car or home.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
For Outdoor Use only. Not for Commercial Use.

2 of 19
TABLE OF CONTENTS
General information …………….…….………………….………………..………….…… 2
Specification……….……………………………………….……………….……….……… 3
Important safety information and precaution……………….….….….….…….…… 3-4
Expanded view……………………………………………………….……….……..……… 5
Parts list……………………….………………………….………………………………6-7
Installation………………………….………………………..………………….………8-15
Location……………………………………………………………………….…….…….. 16
Set up……………………………………………………………….…………….……...… 16
Gas connection ………………………………….……………….…………………… 16
Operation……………………………………………………………….……….…….. 17
Leak check………………………………………………………….……………...…… 17
Ignite lighting………………………………………………………….………………. 17
Storage and Maintenance………………………………………….……...............…..…18
Trouble shooting ………………………………………………...….………………..… 19
Limited warranty……………………………………………………………….….…… 19
WARNING : Failure to position the parts in accordance with these diagrams or use only parts specifically approved
with this appliance may result in property damage or personal injury.
WARNING: This product can expose you to Carbon Monoxide, which is known to the State of
California to cause birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov
GENERAL INFORMATION
IMPORTANT
Please take time to read these instructions thoroughly and follow each step carefully for
safe and easy operation. Keep this manual to consumer for installer and consumer future
reference/use.
We would like to hear from you with any comments or suggestions. In the continental U.S.,
you can call Sunjoy Toll Free number: 1-866-578-6569 at any time.
You can also send us an email to custom[email protected]

3 of 19
SPECIFICATION
IMPROTANT SAFETY INFORMATION AND PRECAUTION
The installation must conform with local codes, or in the absences of local codes with the National
Fuel Gas Code, ANSI Z223.1/NFPA54; International Fuel Gas Code, Natural Gas and Propane
Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2, as applicable.
The LP gas supply cylinder to be used must be:
1- Constructed and marked in accordance with the U.S. Department of Transportation (D.O.T.)
Specifications for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for
transportation of Dangerous Goods and Commission, CAN/CSA-B339 as applicable;
2- Provided with a listed overfilling prevention device;
3- Provided with a cylinder connection device compatible with the connection for the appliance.
Always place the appliance on a firm and level surface.
Solid fuels shall not be burned in this gas appliance. When using decorative Lava Rocks, use only
Lava Rocks (INCLUDED).
The appliance shall be used only outdoors in a well-ventilated space and shall not be used in a
building, garage or any other enclosed area.
When in use, keep the appliance area clear and at least 40 in / 101.6 cm side, back and top
clearance from combustible materials, gasoline and other flammable liquid and vapors. Do not use
the appliance under overhead combustible surfaces. Certain items or materials, when stored under
the appliance or nearby, will be subjected to radiant heat and could be damaged.
Open the door and inspect the hose assembly and burner prior to each use. If there is evidence of
excessive abrasion or wear or if the hose or burner is damaged, it must be replaced by appropriate
part from the manufacturer.
Inspect the gas connections of the appliance prior to each use. Do not to operate the unit if there is a
gas leak. Have the appliance inspected annually by a qualified service person.
Product name
HD PROVENCE 5PC GAS FIRE PIT TABLE
Model NO.
L-DN2235SST-B-T
Rated Heat Output
26,000BTU/HR
Fuel
Propane-LP
Gas Supply
20 lb. LP-Gas cylinder
Manifold Pressure
11 Inches W.C.
Orifice Size (diameter)
1.57mm
Gas Supply Pressure
Max.250 PSI Min.25 PSI

4 of 19
The pressure regulator and hose assembly provided with the appliance must be used. The
replacement part must be the same as the part specified by manufacturer.
The assembly of LP-gas and leak checking please refer to the “Gas connection”on page 16 and
“leak Test”on page 17.
Children and adults should be alerted to the hazards of high surface temperatures and should
stay away to avoid burns or prevent clothing ignition.
Young children and pets should be carefully supervised when they are in the area of the
appliance.
Any guard or other protective device removed for servicing the appliance must be replaced
prior to operation.
Clothing or other flammable materials should not be hung from the appliance or placed on or
near the appliance.
Do not use the appliance if any part has been under water. Immediately call a qualified technician to
inspect the appliance and to replace any part of the control system and any gas control which has been
under water.
LP-gas supply cylinder to be used must be constructed and marked in accordance with the
specifications for LP-gas cylinders of the U.S. Department of Transportation (DOT).
The cylinder supplies system must be arranged for vapor withdrawal and the cylinder must include a
collar to protect the cylinder valve.
Use only 20 lb / 9 kg LP-Gas cylinders.
Do not burn wood or any other materials in this appliance.
The appliance must be isolated from the gas supply piping system by closing
its individual manual shutoff valve during any pressure testing of the gas supply
piping system at test pressure equal to or less than 1/2psi (3.5kPa).
That other cylinder may be acceptable for use with the appliance provided
they are compatible with the appliance retention means and accompanied by illustration(s) depicting
the cylinder mounted to the appliance utilizing the cylinder retention means and the point of contact
between the cylinder and the retention means.
Properly place the hose out of pathways where people may trip over it or in areas where there may
be subject to accidental damage.
The burner must be replaced prior to the appliance being put into operation if it is evident that the
burner is damaged. The replacement burner must be the same as the part specified by manufacturer.
The cleaning of the appliance including the burner, please refer to “Storage and Maintenance”on
page 18.

5 of 19
EXPANDED VIEW

6 of 19
Parts List
Label
Part Number
Description
Qty
Part Image
A
P20722A01180
Lid
1
B
P31341A01180
Table top
1
C
P22008A01178
Fire bowl
1
D
P22328A01180
Leg1
1
E
P22329A01180
Leg2
1
F
P21233A01180
Back panel
1
G
P21150A01180
Side panel1
1
H
P20813A01180
Tank holder
1
I
P99903D01002
Lava rock
3kg

7 of 19
J
P21151A01180
Side panel2
1
K
P20927A01180
Panel
1
L
P22330A01180
Leg1
1
M
P22331A01180
Leg2
1
N
P23401A01002
Chain
1
Hardware Pack
Label
Part Number
Description
Qty
Add
Part Image
AA
H02015C11
Bolt M6*15
12
2
BB
H02010C11
Bolt M6*10
4
1
CC
H09015C11
Bolt M6*15
4
1
DD
H02030C11
Bolt M6*30
4
1
EE
H19001C11
Flat washer
M6
24
3
FF
H00001C12
Wrench M6
1
0
If you want to replace the parts listed, please contact Customer Service Center: 1(866) 578-6569.

8 of 19
INSTALLATION
Z
1
1x
1x
4x
4x
1x

9 of 19
2
4x
4x
1x
1x

10 of 19
3
4x
4x
1x
1x
