Meteotime WM5300 User manual

7
KSPO:
NIL DV229NL & TS21 MANUAL (ENG)
SIZE: W105 X H148 (mm)
BY Lai HZ 21/12/12
Remote Thermo-Hygrometer
Main Unit
Meteotime Weather Station
with
Wireless Thermo-Hygrometer
DAY/NIGHT
MEM
CHANNEL
SET
TEST
2
In/Outdoor Temperature/
Humidity.
Information Window.
Today Weather Information
including Wind Speed, Wind
Direction, and the probability
of Rain/Snow/Hail, Day &
Night Temperature, Day &
Night Weather Status.
Tomorrow, One-Day-After,
and Two-Day-After Weather
Information including Day &
Night Temperature, Day &
Night Weather Status.
WM5300
three days for 470 cities
•3 channel outdoor 433Mhz wireless Thermo-hygrometer (channel 1 sensor is included,
additional sensors are required for channels 2 and 3)
• Indoor Thermo-hygrometer
• Maximum and minimum memories of temperature and humidity readings
• Temperature and humidity trends (UP/ FLAT/ DOWN),
• Temperature unit in degree C only.
• Regional Day-time temperature and Night-time Temperature information
• 7-languages abbreviation (English/ Espanol/ Francais/ Italiano/Dutch /Swedish/ Deutsch)
• Critical Weather Alert
• Maximum of 5 cities’ weather information can be selected and displayed
• Personalized a place name / city.
• Radio-controlled Clock and Calendar (24 hours format only)
• Time-zone setting
• Dual alarm (weekday alarm/single alarm, Alarm sound for 2 minutes)
• Pre- alarm (Programmable) for outdoor sensor – Channel 1 only.
• Battery Low Indicator for Main Unit and Wireless Sensor
• Powered by 2 x AAbatteries for main unit, and 2 x AAAbatteries for the outdoor sensor
Alarm Time
DATE Weekday alarm “OFFW-ALM”
Single alarm “OFF S-ALM” Pre-alarm “OFF P-ALM”
Exit to city display mode
•Read critical weather information one by one.
•Turn ON the alarm
• Press and hold for 3 seconds to enforce a radio controlled clock DCF signal search
• Switch to next day’s weather information
•Turn OFF the alarm
• Press and hold for 3 seconds to enforce a wireless RF signal search from remote sensor
•Switch to read outdoor temperature and humidity readings of channels 1, 2 and 3
• Press and hold for 3 seconds to enter into the auto-circulation display mode
•SCAN A: the signal strength will be represented from 0 (very bad) to 9 (very good).
•You are able to press [SET] to switch from the display of the City to date, weekday alarm,
single alarm and pre-alarm.
DATE ALARM
temperature and humidity readings in record

[DAY/NIGHT]
[DAY/NIGHT]
[DAY/NIGHT]
DAY/NIGHT
UP [▲]
UP [▲]
UP [▲]
UP [▲]
WEATHER
WEATHER
WEATHER
DATE WEEKDAYALARM
SINGLE ALARM PRE-ALARM.
WEATHER STATUS
There are total 15 weather status for Day and 15 weather status for Night.
REMOTE SENSORS STATUS
The wave icon above the current channel icon shows the connection status of the corresponding
remote sensor:
Icon Status
Searching for the signals from the remote sensor
Corresponding remote sensor signal received successfully
No signals received for over 1 hour
SEARCH FOR REMOTE SENSORS
- The main unit can be manually activated to search for the signals from remote sensors by
pressing and holding DOWN (▼)button.
VIEWING REMOTE (CHANNEL) TEMPERATURE AND HUMIDITY
Static Display:
- Press [ CHANNEL ] keys to select measurements from different remote sensors, each is
mode to a unique channel 1,2, or 3
Channel Auto-Scan Display:
- Press To enable an automatic scan of all channels, press and hold [CHANNEL], until the
icon is displayed. The measurements from each remote channel will be alternately displayed
with a 5 seconds viewing.
NOTE: the channel auto-scan feature can be actived only if there are more than one remote
sensors operating and are set to different channels.
MAXIMUM AND MINIMUM TEMPERATURES
- The maximum and minimum recorded indoor and outdoor temperatures and humidity will be
automatically stored in the memory of the main unit. To display them, press [MEM] button
and the respective indicators, [MAX] or [MIN] will be displayed.
- To clear the memory, hold [MEM] button for 3 seconds. The maximum and minimum
temperature records will be erased.
flashing
flashing
SWITCH TO NEXT DAY’S WEATHER INFORMATION
For each press of the UP [▲] button, the user can switch and view the weather information
from today to tomorrow, one-day-after and two-day-after.
Today’s weather
information:
Tomorrow’s weather
information:
One-day-after’s
weather information:
Two-day-after’s
weather information:
61

WM5300
AA batteries x 2 pcs.
AAA batteries x 2 pcs.
Electromagnetic compatibility and Radio spectrum Matters
ETSI EN 300 220-2 V2.3.1 (2010-02)
ETSI EN 300 330-2 V1.5.1 (2010-02)
Electromagnetic compatibility
ETSI EN 301 489-1 V1.9.2 (2011-09)
ETSI EN 301 489-3 V1.4.1 (2002-08)
Low voltage directive
EN 60950-1:2006+A11:2009+A1:2010+A12:2011
2006/95/EC
ALARM FEATURE
Weekday Alarm:
- This is a repeat alarm that will activate daily from Monday to Friday at a set time.
Single Alarm:
- This is a single alarm that will activate once at a set time
HOW TO SET ALARM
- Press [SET] to toggle between weekday, single alarm time or pre-alarm.
If the alarm is disarmed, the time will be displayed as “OFF W-ALM”
- Hold [SET] for 3 seconds, the hour digits will blink.
- Enter the hour by using UP [▲] or DOWN [▼] button.
- Press [SET] to confirm, the minute digits will blink.
- Enter the hour by using UP [▲] or DOWN [▼] button.
- Press [SET] to exit and the respective alarm icons [ ] , [ ] and [ ]will be
activated.
HOW TO STOPALARM
- When alarm is on, the respective alarm icons [ ] and [ ] will be flashing. Press UP [▲]
or DOWN [▼] button to stop the alarm immediately.
- To turn off the alarm, press UP [▲] or DOWN [▼] button to change the alarm time display
as “OFF W-ALM”
- If no button is pressed, the alarm will be sounded for 2 minutes and then deactivated
automatically.
SETTING THE ICE WARNING ALARM (PRE-ALM)
- If Weekday (W) or Single day (S) alarm is set, the Ice Warning Alarm (Pre-ALM) can be
programmed.
- Press and hold [SET] button for 3 seconds once to enter into the Ice Warning Alarm setting
mode on “PRE-ALM” display mode.
- The number 15 will flash, meaning that if selected, the alarm will sound 15 minutes earlier
than the Weekday or Single alarm.
- Select the desired Ice Warning Alarm interval in 15 minutes increments between 15 and 90
minutes, using UP (▲) or DOWN (▼)buttons
- Press [SET] button to confirm and exit from the alarm setting mode.
62 63
