Metra Electronics ABTI-CH2 User manual

ABTI-CH2
©Copyright 2007 Metra Electronics Corporation
1-800-221-0932 www.metraonline.com
ABTI-CH2
©Copyright 2007 Metra Electronics Corporation
1-800-221-0932 www.metraonline.com
4
ABTI-CH2 ABTI-CH2
A
AP PP PL LI IC CA AT TI IO ON NS S: :
* READ IMPORTANT WARNING ON PAGE 1
BEFORE ATTEMPTING ANY INSTALLATION
Chrysler Pacifica 2004-2007
CHRYSLER
BLUETOOTH
INTERFACE
INSTALLATION
MANUAL
10) Secure all components, and reinstall the radio.
11) Reconnect the vehicle battery.
6) Connect the white 8-pin plug on the IHF-1000 cable to the
vehicle interface cable.
UNPLUG EXISTING
EXISTING
RE-PLUG
FROM CAR
FROM CAR
20 WAY
ABTI-CH2
10 pin din
10 pin cap
10 pin plug
Chryslercable harness
8 pin
IHF-1000 keypad
plug
White
To
AMP
7) Run the two wires with exposed terminals to the amplifier,
which is typically mounted on the rear passenger side. Install the
terminals in the connector as show in the diagram.
UNPLUG EXISTING
EXISTING
RE-PLUG
FROM CAR
FROM CAR
20WAY
ABTI-CH2
10 pin din
10 pin cap
10 pin plug
Chrysler cable harness
8 pin
IHF-1000 keypad
plug
White
To
AMP
8) Install the IHF-1000 keypad on the dashboard of the vehicle,
and route the wire to the IHF-1000 harness. Attach the keypad
connector to the harness.
9) Install the IHF-1000 microphone in an appropriate location (see
IHF-1000 instructions), route the wire to the IHF-1000 harness, and
attach the microphone connector to the harness.
Rear Amplifier
Connector Location
AUDIO WIRES FROM INTERFACE CABLE
AMPLIFIER AUDIO CONNECTOR-
ADD TWO WIRES IN THE POSITION SHOWN BELOW
OPERA
TION
Refer to the IHF-1000 manual for operation. All audio signals from
the IHF-1000 will be played through the car stereo. Adjust the vol-
ume using the radio’s volume knob to a comfortable level. Audio
from FM, CD, Satellite etc. will be automatically paused or muted
while calls are in process. The vehicle’s radio does not need to be on
for IHF-1000 operations, but the vehicle’s ignition must be on or in
accessory mode.
REV. 08/08/07 INSTABTI-CH2
The ABTI-CH2 Chrysler Bluetooth interface is designed
to allow full integration of Motorola’s IHF-1000
Bluetooth Hands free kit with Chrysler Pacifica vehicles.
The kit will allow users to listen to phone calls through
their car stereo. The currently playing radio source will
be automatically muted, and the phone volume may be
controlled by the radio.

* IMPORTANT WARNING
THIS PRODUCT INCLUDES INSTRUCTIONS FOR INSTALLATION WHICH
MUST BE CAREFULLY FOLLOWED. THE INSTRUCTIONS ARE WORDED
IN SUCH A MANNER TO ASSUME THAT THE INSTALLER IS CAPABLE
OF COMPLETING THESE TYPE OF ELECTRONIC INSTALLATIONS.
IF YOU ARE UNCLEAR AS TO WHAT YOU ARE INSTRUCTED TO DO OR
BELIEVE THAT YOU DO NOT UNDERSTAND THE INSTRUCTIONS SO AS
TO PROPERLY AND SAFELY COMPLETE THE INSTALLATION YOU SHOULD
CONSULT A TECHNICIAN WHO DOES HAVE THIS KNOWLEDGE AND
UNDERSTANDING. FAILURE TO FOLLOW THESE INSTRUCTIONS
CAREFULLY AND TO INSTALL THE INTERFACE AS DESCRIBED COULD
CAUSE HARM TO THE VEHICLE OR TO SAFETY SYSTEMS ON THE
VEHICLE. INTERFERENCE WITH CERTAIN SAFETY SYSTEMS COULD
CAUSE HARM TO PERSONS AS WELL. IF YOU HAVE ANY QUESTIONS
IN THIS REGARD PLEASE CALL THE HELP LINE OR THE METRA AT
1-800-221-0932 FOR ASSISTANCE.
21
ABTI-CH2 ABTI-CH2ABTI-CH2
INSTALLATION PROCEDURES
1) Disconnect the vehicle battery.
2) Remove the radio from the dashboard, and disconnect the 10-
pin connector from the rear of the radio (if present).
3) Insert the 10-pin Plug on the vehicle interface cable into the
rear of the radio.
4) Connect the 10-pin cap on the vehicle interface cable to the
10-pin plug previously removed from the rear of the radio (if present).
3
UNPLUG EXISTING
FROM CAR
UNPLUG EXISTING
EXISTING
RE-PLUG
FROM CAR
FROM CAR
20 WAY
ABTI-CH2
10 pin din
10 pin cap
10 pin plug
Chryslercable harness
8 pin
IHF-1000 keypad
plug
White
To
AMP
UNPLUG EXISTING
EXISTING
RE-PLUG
FROM CAR
FROM CAR
20 WAY
ABTI-CH2
10 pin din
10 pin cap
10 pin plug
Chryslercable harness
8 pin
IHF-1000 keypad
plug
White
To
AMP
5) Connect the white 20-pin plug on the vehicle interface cable to
the ABTI-CH2.
UNPLUG EXISTING
EXISTING
RE-PLUG
FROM CAR
FROM CAR
20 WAY
ABTI-CH2
10 pin din
10 pin cap
10 pin plug
Chrysler cable harness
8 pin
IHF-1000 keypad
plug
White
To
AMP
