Introduction
The MFJ-401D Econo Keyer II is a microprocessor controlled keyer that provides iambic key opera-
tion and dot-and-dash memory to make sending perfect code easier. It has tuneable code speed,
code weight, and sidetone frequency; it supports both direct and grid-block keying outputs. You
also get to choose between Iambic Type "A" and Type "B" keying.
Control Functions
1. The Power button turns the unit ON and OFF. The power is ON when the button is locked in
the "in" position and OFF in the "out" position.
2. The Semi-Auto/Auto button allows semi-automatic "bug" and manual operations. The keyer
generates dots automatically when a squeeze or single lever key is used. Dashes are manually
made. The keyer is completely manual when a straight key is used. Semi-Auto is active when
the switch is in the "in" position and Auto when in the "out" position.
3. The Speed control varies the code speed. The speed range is configured with an internal
jumper (JMP9) for 5 to 65 WPM or 10 to 40 WPM. Turn the control clockwise to increase speed
and counter-clockwise to decrease speed. The unit is factory set to 5 to 65 WPM. To make the
speed adjustment less sensitive, change the speed range to the narrower range of 10 to 40
WPM. To change the speed range the power must be off, then remove the cover by removing
the two screws (one on each side) that secure it. Locate jumper JMP9 and set it to the "H" po-
sition.
Note: Power must be off when changing the jumper settings.
4. The Weight control varies the code weight from approximately 25 % to 75 %, with the stan-
dard dot defined as 50% weight. The standard dot-dash-space ratio is 1:3:1 (trimpot at mid-
range). Turn the control clockwise to increase dot and dash lengths and counter-clockwise to
decrease dot and dash lengths. This control is located internally. When looking at the unit's
front panel, it is accessible through the small hole on the left side, closest to the rear and may
be adjusted by inserting a small, flat-headed screwdriver.
5. The Tone control sets the desired sidetone pitch from approximately 300 to 1200 Hz. Turn the
control clockwise to raise the pitch and counter-clockwise to lower the pitch. This control is lo-
cated internally. When looking at the unit's front panel, it is accessible through the small hole
on the left side, closest to the front and may be adjusted by inserting a small, flat-headed
screwdriver.
6. The Volume control adjusts the sidetone level of the internal speaker. Turn the control clock-
wise to increase the volume and counter-clockwise to decrease the volume.
7. The Direct/Grid-Block Output keying circuit allows keying of grid-block and solid state transmit-
ters. The MFJ-401D can only key one type of transmitter at a time. This is an internal jumper
selected option. The unit is factory set to direct keying. To change to grid-block keying the
power must be off, then remove the cover by removing the two screws (one on each side) that
secure it. Locate JMP1 and JMP2. JMP2 is directly behind the RCA jack and JMP1 is approxi-
mately one inch in front of JMP2. Set both jumpers JMP1 and JMP2 to the "G" position. To key
a solid state transmitter, set both jumpers to the "D" position.
Note: Power must be off when changing the jumper settings.

8. The Iambic Type A/B mode is also set inside the unit with a jumper. The unit is factory set for
Type "A" Iambic. If you prefer Type "B" Iambic, remove the cover by removing the two screws
(one on each side) that secure it. Locate jumper JMP3 and set it to the "B" position. For Type
"A" Iambic, set the jumper to the "A" position.
Note: Power must be off when changing the jumper settings.
When a squeeze is released during an element (dot or dash), type "B" adds the opposite ele-
ment. Type "A" just finishes the element in progress and does not produce a following alter-
nate element. For example, in Type "A" Iambic, a squeeze release during the "dah" in the letter
A will produce "didah" (A). In Type "B" Iambic, a squeeze release during the "dah" in the letter
A will produce "di-dah-dit" (R).
Installation
1. A 9-volt battery (not included) may be installed. Remove the cover by removing the two screws
(one on each side) that secure it.. A battery holder, located inside the enclosure, is provided for
installing a 9-volt battery.
2. A 12 VDC power supply may also be used to power the MFJ-401D. A 2.1 mm coaxial plug with
a positive center and a negative sleeve should be used to power this unit. The MFJ-1312B, an
optional 12 volts adapter, is available from MFJ Enterprises, Inc. The battery is automatically
disconnected when external power is used.
3. A squeeze or single lever key can be used. Squeeze key allows Iambic operation. A ¼-inch
stereo phono plug and a two-conductor shielded cable should be used. If separate shielded ca-
bles are used, the two shields should be tied together and connected to ground. The dot wire
should be connected to the tip of the plug and the dash wire to the ring. The MFJ401D be-
comes a manual keyer when a straight key is used. The unit will safely key your transmitter
and eliminate the shock hazard of high voltage being present on the straight key.
Note: To use a straight key, first switch the keyer to the Semi-Auto mode (button in). Again a
¼-inch stereo phono plug should be used because a mono plug will not work on a straight key
in Semi-Auto mode. Connect one wire to the ring of the plug and another wire to ground. The
tip of the plug should not used.
4. Output keying circuit allows keying of grid-block and solid state transmitters. Remember this is
internally jumper selected (refer to page 2). The keying output connection is made with a RCA
phono plug.
Note: Consult the transmitter's instruction manual to determine which output to use. When in
doubt, try both jumper positions. The transmitter will key continuously when the jumpers are
connected to the wrong positions.

Keyer Operation
1. A 9-volt battery or an optional DC adapter may be used to supply power to the keyer.
2. The key paddle should be connected to the Key jack on the rear panel of the unit. A dual pad-
dle squeeze key or a single lever key can be used.
3. Next, the keyer should be turned on with the Power switch.
4. The Semi-Auto/Auto switch should be in the "out" position for automatic operation.
5. The user should now start sending with the paddle and adjust volume, tone, weight, and
speed to his or her preference.
6. The dot and dash memories make sending easier. The memories allow the user to key a dot
before the completion of a dash and vice versa. This feature can be checked by setting the
keyer to the lowest speed and tapping first the dash lever and then the dot lever before the
completion of the dash. The keyer will provide both the dash and the dot. The dash memory
can be checked in a similar manner. The dot insertion feature allows the user to insert a dot by
tapping the dot lever while holding the dash lever in. The dash insertion feature allows the
user to insert a dash while holding the dot lever in. The Iambic operation allows sending of al-
ternate dots and dashes when using squeeze key and with both paddles squeezed. The first
paddle contacted will determine whether a dot or dash occurs first.
7. The user may select either Iambic A or B according to his preference.
Jumper Settings
JMP1
JMP2
JMP3
JMP9
D
D
Keying Mode Direct *
D
G
Invalid
G
D
Invalid
G
G
Keying Mode Grid Block
A
Iambic Mode A *
B
Iambic Mode B
L
Speed Range 5 – 66 WPM *
H
Speed Range 10 – 40 WPM
* Factory default

Morse Code Character Set 1
A di-dah ·- N dah-dit -·
B dah-di-di-dit -··· O dah-dah-dah ---
C dah-di-dah-dit -·-· P di-dah-dah-dit ·--·
D dah-di-dit -·· Q dah-dah-di-dah --·-
E dit ·R di-dah-dit ·-·
F di-di-dah-dit ··-· S di-di-dit ···
G dah-dah-dit --· T dah -
H di-di-di-dit ···· U di-di-dah ··-
I di-dit ·· V di-di-di-dah ···-
J di-dah-dah-dah ·--- W di-dah-dah ·--
K dah-di-dah -·- X dah-di-di-dah -··-
L di-dah-di-dit ·-·· Y dah-di-dah-dah -·--
M dah-dah -- Z dah-dah-di-dit --··
1 di-dah-dah-dah-dah ·---- 6 dah-di-di-di-dit -····
2 di-di-dah-dah-dah ··--- 7 dah-dah-di-di-dit --···
3 di-di-di-dah-dah ···-- 8 dah-dah-dah-di-dit ---··
4 di-di-di-di-dah ····- 9 dah-dah-dah-dah-dit ----·
5 di-di-di-di-dit ····· 0 dah-dah-dah-dah-dah -----
Period [.] di-dah-di-dah-di-dah ·-·-·- AAA
Comma [,] dah-dah-di-di-dah-dah --··-- MIM
Question Mark or Request for Repetition [?] di-di-dah-dah-di-dit ··--·· IMI
Fraction Bar or Slash Bar [/] dah-di-di-dah-dit -··-· DN
End of Message, Plus Sign, or Cross [+] di-dah-di-dah-dit ·-·-· AR
End of Work di-di-di-dah-di-dah ···-·- SK
Double Dash, Equal Sign, Pause, or Break [=] dah-di-di-di-dah -···- BT
Semicolon [;] dah-di-dah-di-dah-dit -·-·-· KR
Colon [:] dah-dah-dah-di-di-dit ---··· OS
Apostrophe ['] di-dah-dah-dah-dah-dit ·----· WG
Quotation Mark ["] di-dah-di-di-dah-dit ·-··-· AF
Hyphen or Dash [-] dah-di-di-di-di-dah -····- DU
Underline [_] di-di-dah-dah-di-dah ··--·- IQ
Dollar Sign [$] di-di-di-dah-di-di-dah ···-··- SX
Left Parenthesis or Go Only [(] dah-di-dah-dah-dit -·--· KN
Right Parenthesis [)] dah-di-dah-dah-di-dah -·--·- KK
Wait or Stand By di-dah-di-di-dit ·-··· AS
Understood di-di-di-dah-dit ···-· SN
Starting Signal dah-di-dah-di-dah -·-·- KA
Error di-di-di-di-di-di-di-dit ········ HH
Paragraph [¶] di-dah-di-dah-di-dit ·-·-·· AL
Invitation to Transmit or Go Ahead [K] dah-di-dah -·- K
Signals used in other Radio Services
Interrogatory di-di-dah-di-dah ··-·- INT
Emergency Silence di-di-di-di-dah-dah ····-- HM
Executive Follows di-di-dah-di-di-dah ··-··- IX
Break-in Signal dah-dah-dah-dah-dah ----- TTTTT
Emergency Signal di-di-di-dah-dah-dah-di-di-dit ···---··· SOS
Relay of Distress dah-di-di-dah-di-di-dah-di-dit -··-··-·· DDD
1FCC test requirement consists the 26 letters, the 10 numerals, the period, the comma, the question mark,
AR, SK, BT and fraction bar DN.
