MGG S200 User manual

1
MGG Solar Powered Electric Fence Energisers
Models S200 and S500
www.mggproducts.co.nz
[email protected]

2
Foreword
Thank you for buying an MGG electric fence energizer. MGG Products is committed to
supplying electric fence energizers, testers and accessories of the highest quality. This
Energizer has built-in lightning protection devices to reduce the incidence of lightning
damage and built-in RFI (Radio Frequency Interference) Suppressed Circuitry. If for any
reason you are not happy with your purchase, please return the energizer to MGG Products
within 14 days of purchase and we will give you a full refund - guaranteed. If you have any
questions regarding this product please email us: [email protected], or contact the
store where you purchased this from.
Please read this manual carefully before using this product and conserve it well. If you have
problems in the process of use you can read it again. Do not let children operate or play
with an electric fence energizer.
This manual describes MGG electric fence energizers:
0.2 J model S200
0.5 J model S500
Important safety introduction
WARNING: Please read all instructions
Do not touch a live fence
Do not drench with water.
This product is for use in controlling livestock. Any other use is prohibited.
Keep fence clear of weeds, branches etc to avoid electrical shorts resulting in battery
drainage.
Do not climb over, through or under a multi -wire electric fence. Use a gate or a
specially designed crossing point.
Do NOT become entangled in the fence. Avoid electric fence constructions that are
likely to lead to the entanglement of animals or persons.
Electric animal fences shall be installed and operated so that they cause no electrical
hazard to persons, animals or their surroundings.
It is recommended that in all areas where there is a likely presence of unsupervised

3
children who will be unaware of the dangers of electric fencing, that a suitably rated
current limiting device having a resistance of not less than 500 ohms be connected
between the energizer and the electric fence in this area.
The appliance is not intended for use by young children or infirm persons without
supervision.
Do not place combustible materials near the fence or energizer connections. In times of
extreme fire risk, disconnect energizer.
Don't dismantle. Don't make any changes to this energizer. Don't touch high voltage
parts which can cause electric shock. This energizer is not user-servicable.
Young children should be supervised to ensure that they do not play with the appliance.
An electric animal fence shall not be supplied from two separate energizers or from
independent fence circuits of the same energizer. That is very dangerous.
For any two separate electric fences, each supplied from a separate energizer
independently timed, the distance between the wires of the two electric animal fences
shall be at least 2.5m.
Barbed wire or razor wire must not be electrified by an energizer.
A non-electrified fence incorporating barbed wire or razor wire may be used to support
one or more off-set electrified wires of an electric animal fence. The supporting devices
for the electrified wires shall be constructed so as to ensure that these wires are
positioned at a minimum distance of 150 mm from the vertical plane of the non-
electrified wires. The barbed wire and razor wire shall be earthed at regular intervals.
Where an electric animal fence crosses a public pathway, a non-electrified gate shall be
incorporated in the electric fence at that point or a crossing by means of stiles. At any
such crossing the adjacent electrified wires must carry warning signs.
In areas of public access, use an electric fence warning sign every 10m (33ft) to identify
the electrified wire(s).
Crossing with overhead power lines should be avoided wherever possible. If such a
crossing cannot be avoided, it should be made underneath the power line and as nearly
as possible at right angles to the power line.
If connecting leads and electric fence wires are installed near an over head power line,
the clearances should be not less than those shown below:
Power Line Voltage
V
Clearance
M
≤1000
＞1000 ≤33000
＞33000
3
4
8
If connecting leads and electric fence wires are installed near an over head power line
their height above the ground should not exceed 3m.

4
This height applies either side of the projection of the outermost conductors of the
power line on the ground surface, for a distance of:
• 2 m for power lines operating at a nominal voltage not exceeding 1000V;
• 15 m for power lines operating at a nominal voltage exceeding 1000V.
Electric animal fences intended for deterring birds, household pet containment need
only be supplied from low output energizers to obtain satisfactory and safe
performance.
Fence wiring should be installed well away from any telephone or telegraph line or
radio aerial.
The size of the warning sign shall be at least 100mm x 200mm.
The background colour of both sides of the warning sign shall be yellow. The inscription
on the sign shall be black and shall be either:
-the substance of “CAUTION: Electric Animal Fence” or,
-the symbol shown:
The inscription shall be indelible, inscribed on both sides of the warning sign and have a
height of at least 25mm.
Ensure that all mains operated ancillary equipment connected to the electric animal
fence circuit provides a degree of isolation between the fence circuit and the supply
mains equivalent to that provided by the energizer.
Protection from the weather shall be provided for the ancillary equipment unless this
equipment is certified by the manufacturer as being suitable for use outdoors, and is of
a type with a minimum degree of protection IPX4.
This energizer complies with international safety regulations and is manufactured to
international standards. MGG reserves the right to make changes without notice to any
product specification to improve reliability, function or design.

5
Specifications.
Parts of the Energiser
1. Switch
2. Charger input
3. Fence Terminal
4. Post Mounting Slot
5. Earth Terminal
6. Solar Panel
7. Battery
8. Battery Compartment
Power source S200 S500 (12V 7.5 Ah SLA battery for both models)
Maximum output
Voltage up to 10.5 KV up to 11 KV
Energy 0.17 J 0.54 J
Stored energy 0.2 J 0.65 J
