OPERATIONS MANUAL
ADDENDUM
Portable Traffic Analyzer
NC350
1.0 INTRODUCTION
M. H. Corbin Portable Traffic Analyzer NC350™
adds Bluetooth capability to the NC300 product
family. The NC350 uses the same chargers, hard
covers, and data communications cables as the
NC300 and NC200 products, and also supports data
communications without a cable via the use of a
class 2 Bluetooth SPP connection to your computer.
Bluetooth communications requires that your
computer has a compatible Bluetooth radio installed,
either internally or via a USB Bluetooth dongle.
NOTE: To use the Bluetooth protocol with HDM
software, you must install HDM v3.0 or higher.
2.0 NC350 LED Indicators
The NC350 includes 3 LED indicators that are
exposed through the clear window on the end of the
unit. The LEDs indicate the status of the unit during
programming and after the completion of a traffic
study:
The Bluetooth protocol requires that each computer
which is to be used to communicate with the NC350
first go through a pairing process before that
computer can be used to program or download a
study. This is a security mechanism that prevents
unauthorized access to your NC350. The pairing
feature is only available when your NC350 is
plugged into the battery charger. When charging,
you should see the NC350 blue LED blink –this
indicates you can now pair your computer to the
NC350. The HDM software automatically will pair
your computer to the NC350 when you program a
study, read a study, or check the battery voltage of
your unit.
NOTE: Computers which do not pair with the
NC350 while the charger cable is connected will
not be able to program or read study data.
When your computer communicates to the NC350
using the Bluetooth protocol, the NC350 blue LED
will light continuously while it is connected.
A blinking GREEN LED indicates that a study has
completed and the study data is ready for download
to your computer. Once the study has been
downloaded, the GREEN LED will no longer blink.

Visit our website at : www.MHCorbin.com
A blinking RED LED indicates that a study has been
programmed and that the NC350 is ready to be
placed on the road surface. While the RED LED
blinks, the NC350 continually tests the magnetic
environment in its location to ensure that it can
operate properly. If strong magnetic interference is
detected, the NC350 will blink YELLOW to indicatge
that the location it is in is not suitable for recording
vehicle traffic. If you note a YELLOW indicator, you
should relocate the NC350 to a new location, and
repeat this until the NC350 blinks RED again. The
NC350 will bink RED until approximately 5 minutes
before the study starts. From this period until the
study is complete, blinking stops and no LEDs will be
lit.
When the NC350 is not connected to a charger and
it has no LED indicators lit or blinking, one of the
following conditions have been met:
1) No study has been programmed and the
previous study has already been
downloaded (ie, unit is sleeping)
2) A study is in progress
3) The battery is completely discharged and
needs to be recharged.
3.0 BLUETOOTH COMMUNICATIONS RANGE
The NC350 utilizes a class 2 bluetooth module,
which has a range of up to 10 meters. This range is
highly affected by nearby radio interference sources,
and is also limited by line-of-site obstacles that may
lie between your computer and the NC350 device. In
addition, the Bluetooth capabilities of your computer
may limit the range of your communication to the
NC350 units. Different computers and/or Bluetooth
dongles may have a longer range than others. In
addition, data throughput across a Bluetooth
connection decreases with longer distancances
and/or increased interference, so keeping units as
close to your computer as possible during data
downloads will improve performance.
For more information and frequently asked questions
please visit our website:
http://www.mhcorbin.com/faq
