MHC Medical Products SureLife Classic SL-BW101 User manual

Wrist Blood Pressure Monitor
Classic Model

SAFETY PRECAUTIONS
2
• Infants, young children or individuals who cannot express
their consent are not suitable to take blood pressure
measurement.
• Individuals with serious arteriosclerosis are not suitable to
take blood pressure measurement.
• Blood pressure readings may change in case of pregnancy.
Pregnant women should consult their doctor before
taking measurement.
•Self-measurement is not medical treatment. If there are
unusual values, consult your doctor.
• Handling batteries properly:
°As soon as old batteries run out, replace with
new batteries.
°Do not use old and new batteries together.
°Align the polarities of batteries correctly.
°When the unit will not be used for more than 3 months,
remove the batteries. Otherwise, batteries may leak and
cause damage to the unit.
Classic Model

3
QUICK START GUIDE
• Infants, young children or individuals who cannot express
their consent are not suitable to take blood pressure
measurement.
• Individuals with serious arteriosclerosis are not suitable to
take blood pressure measurement.
• Blood pressure readings may change in case of pregnancy.
Pregnant women should consult their doctor before
taking measurement.
•Self-measurement is not medical treatment. If there are
unusual values, consult your doctor.
• Handling batteries properly:
°As soon as old batteries run out, replace with
new batteries.
°Do not use old and new batteries together.
°Align the polarities of batteries correctly.
°When the unit will not be used for more than 3 months,
remove the batteries. Otherwise, batteries may leak and
cause damage to the unit.
Avoid smoking, eating, drinking caeinated drinks or
exercising for 30 minutes before taking measurement
1. Sit upright in a chair with both feet
on the oor.
2. Roll up the sleeve to bare your wrist
if necessary. Take caution not to
constrict the blood ow.
3. Pull on the end of the cu until it
wraps securely around your wrist.
Place your elbow on a table so that
the monitor will be at the same
level as your heart.
4. Press the“ ” button. The cu will
automatically inate and the
measurement will start.
5. When the measurement is complete,
the cu will automatically deate
and your systolic and diastolic
pressure values and pulse rate
will display.

4
Monitor
OVERVIEW
On/O Button
Memory Recall
Button
Display
Features
• One Touch Operation
• 99 Total Memory
• Auto-o Power Saving Feature
• Operated by 2 AAA batteries

Display
Package Contents
Memory
Display Sticker
Low Battery
Indicator
Pulse symbol
Systolic
Diastolic
Pulse
Memory No.
(1~99 readings)
5
Alkaline Battery
2xAAA
Main Unit Instruction
Manual
Note: Peel o and remove the display sticker before use

2.1 Battery Installation
1. Remove the batteries cover
according to the direction
of the arrow.
2. Insert 2 AAA batteries with the
polarities in the correct direction.
3. Slide the battery cover to close
until the lock securely clicks
into place.
Note: Replace batteries when
the battery indicator “ ”
shows low voltage.
6
PREPARATION
*Enlarged to show correct battery direction
Note: Peel o and remove the display sticker before use

3.3 Taking Measurement
1. Press the“ ” button. The cu will automatically inate
and the measurement will start.
2. When the measurement is complete, the cu will
automatically deate and your systolic and diastolic
pressure values and pulse rate will display.
3. Remove the wrist cu and take note of your
measurement results.
Note: You can press the “ ” button to stop inating the
wrist cu at any time.
3.4 Heartbeat Readings
Besides Systolic and
Diastolic values, Pulse
will also be displayed
after a measurement.
7
Note:
• Avoid smoking, eating, drinking caeinated drinks or
exercising for 30 minutes before taking measurement.
• Do not move or talk during measurement.
3.1 Sitting Correctly
1. Relax
2. Sit upright in a chair with both feet on the oor.
3. Roll up the sleeve to bare your wrist if necessary.
Take caution not to constrict the blood ow.
4. Place your arm on a table so that the cu will be at the
same level as your heart.
3.2 Applying the Wrist Cu
1. Place your elbow on a table and palm
facing upward, and wrap the arm cu
around the left wrist.
2. Pull on the end of the cu until it wraps securely around
your upper wrist. Do not over tighten the cu. Allow
1–2 cm or 1/2 inch between the bottom of the cu and
your wrist joint.
3. Make sure the cu is at the same level as your heart.
TAKING MEASUREMENT

3.3 Taking Measurement
1. Press the“ ” button. The cu will automatically inate
and the measurement will start.
2. When the measurement is complete, the cu will
automatically deate and your systolic and diastolic
pressure values and pulse rate will display.
3. Remove the wrist cu and take note of your
measurement results.
Note: You can press the “ ” button to stop inating the
wrist cu at any time.
3.4 Heartbeat Readings
Besides Systolic and
Diastolic values, Pulse
will also be displayed
after a measurement.
Note:
• Avoid smoking, eating, drinking caeinated drinks or
exercising for 30 minutes before taking measurement.
• Do not move or talk during measurement.
3.1 Sitting Correctly
1. Relax
2. Sit upright in a chair with both feet on the oor.
3. Roll up the sleeve to bare your wrist if necessary.
Take caution not to constrict the blood ow.
4. Place your arm on a table so that the cu will be at the
same level as your heart.
3.2 Applying the Wrist Cu
1. Place your elbow on a table and palm
facing upward, and wrap the arm cu
around the left wrist.
2. Pull on the end of the cu until it wraps securely around
your upper wrist. Do not over tighten the cu. Allow
1–2 cm or 1/2 inch between the bottom of the cu and
your wrist joint.
3. Make sure the cu is at the same level as your heart.
8
Pulse

Irregular Heartbeat
This unit has a unique feature that alerts the user of irregular
heartbeat detection during measurement.
Note: An irregular heartbeat is dened as a heartbeat
rhythm that has a variation of more than 25% from
the average rhythm detected during measurement.
If such irregular rhythm occurs twice or more during the same
measurement, the display screen will ash between the pulse
value and “IH” symbol. Example: (90 / IH)
Note: You may want to consult your doctor if irregular
heartbeat occurs often.
9

After measurement, the last set of measured values will be
saved automatically after measurement when the unit is
turned o by pressing“ ” button or by automatic power-o
after 3 minutes.
4.1 View Past Readings
1. Press the “M”button to enter memory function.
2. Press the “M”button to display the next set of values.
Past readings are displayed from the most recent to
the oldest.
3. This device can store up to 99 past readings.
4.2 Delete Past Readings
When the monitor’s power is o, press and hold the memory
button “M” for 5 seconds until the memory icon “ ”appears
in the display. Without releasing the memory button, press
the power button “ ” and “ALL EE” will appear. Release the
power button“ ” and the memory button “M”to erase all
stored readings from the monitor.
10
MEMORY FUNCTIONS

Note: If your problem cannot be solved by the solutions
above, contact Customer Service at [phone]
(Mon–Fri, 9am–5pm, EST). Do not disassemble
the unit.
11
“Err P” displayed Fail to inate Return for servicing.
“Err 1” displayed Deate too rapidly Return for servicing.
“Err 2” displayed Movement during
measurement
Do not move during
measurement.
Signal
interference
Remove interfering source
e.g. mobile phones,
magnets.
“Err 3” displayed Incorrect results Measure again.
Problem Cause Solution
No display when
you press the Power
/Start button
Have the batteries
run out?
Are the battery
polarities wrong?
Replace new batteries.
Re-align batteries in correct
polarities.
TROUBLESHOOTING

12
STORAGE & MAINTENANCE
• Keep the unit away from direct sunlight, extreme
temperatures, humidity or moisture.
• Use a dry, soft cloth to clean the unit, or if desired, use a
cloth lightly dampened with water.
• Do not use alcohol, benzene, thinner or other volatile
liquids to clean the unit.
• Do not wash or expose the wrist cu to liquid.
• Remove batteries from the unit when it will not be used
for more than 3 months.

Note: Subject to modication without prior notice.
13
Model No. Classic (SL-BW101)
Measurement Method Oscillometric
Measurement Range Pressure: 20 – 280 mmHg
Pulse Rate: 40 – 195 beats/min
Accuracy Pressure: +/- 3 mmHg
Pulse Rate: +/- 5%
Ination Pump driven
Pressure Detection Semi-conductor
Power Supply 2x AAA batteries
Auto Power O 3 minutes after last operation
Storage Environment -4°F to 140°F, 10% to 95% RH
Operation Environment 50°F to 104°F, 30% to 85% RH
External Dimensions
80 x 60 x 75 mm
Net Weight 4.59oz/130g (batteries excluded)
Cu Dimensions 5.3-8.7in/135~220mm
Package Content Instruction Manual, Battery Set,
Main Unit
SPECIFICATIONS
3.15” (L) x 2.35”(W) x 2.96”(H) or

The SureLife® Wrist Blood Pressure Monitor is warranted to
be free from defects in materials and workmanship within
5 years from the date of purchase. The monitor must be used
in accordance with the instructions provided.
The above warranty is extended to only the original
retail purchaser. Proof of Purchase required.
We will, at our discretion, repair or replace without charge the
wrist monitor covered by the above warranty.
To obtain warranty service, please contact MHC Medical
Products at [phone].
ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE
DURATION OF THE APPLICABLE WRITTEN WARRANTY ABOVE.
14
WARRANTY
FOR CUSTOMER
SERVICE CALL OUR
TOLL FREE NUMBER:
[phone]
AD-091621.4

The SureLife® Wrist Blood Pressure Monitor is warranted to
be free from defects in materials and workmanship within
5 years from the date of purchase. The monitor must be used
in accordance with the instructions provided.
The above warranty is extended to only the original
retail purchaser. Proof of Purchase required.
We will, at our discretion, repair or replace without charge the
wrist monitor covered by the above warranty.
To obtain warranty service, please contact MHC Medical
Products at [phone].
ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE
DURATION OF THE APPLICABLE WRITTEN WARRANTY ABOVE.
Manufactured in accordance with
FDA and International Standards
MHC Medical Products
8695 Seward Road
Faireld, Ohio 45011
www.MHCmed.com
Made in China. Distributed by MHC Medical Products, LLC.
Package design © 2010
SureLife® is a registered trademark of MHC Medical Products.
FOR CUSTOMER
SERVICE CALL OUR
TOLL FREE NUMBER:
[phone]
AD-091621.4
