USER MANUAL
WBV412M05 AC voltage sensor
www.wbsensor.com
[email protected]
Tel: [phone]
Fax: [phone]
ISO9001 ISO14000 ISO18000
Certified

- 1 -
Mianyang Weibo Electronic Co., Ltd
No.98, Youxian East Road, Youxian District, Mianyang City, P.R. China
Tel: [phone] Fax: [phone]
www.wbsensor.com wbw[email protected]
WBV412M05 AC Voltage Sensor
Safety claim
The information in the safety claim of the equipment documentation is
intended to ensure that equipment is properly installed in order to
maintain it in a condition.
It is assumed that everyone who will be associated with the equipment
will be familiar with the contents of that safety section, or this safety
guide.
When electrical equipment is in operation, dangerous voltages will be
present in certain parts of the equipment (e.g. the input terminal). Failure
to obverse warning notices, incorrect use, or improper use may endanger
personnel and equipment and course personal injury or physical damage.
Before working in the terminal strip area, the equipment must be isolated.
Proper and safe operation of the equipment depends on appropriate
shipping and handling, proper storage, installation and commissioning,
and on careful operation, maintenance and servicing.
The operating manual for the equipment gives instructions for its
installation, commissioning, and operation. However, the manual cannot
cover all conceivable circumstances or include detailed information on all
topics. In the event of questions or specific problem, do not take any
action without proper authorization. Contact the appropriate WB
technical or sales office and request the necessary information.
Standard application
1. Accuracy
Accurate degree is conformed to IEC688:1992
2. Safety
2.1 Overload capability
Overload capability is conformed to IEC688:1992
2.2 Isolation voltage
Can be endured testing voltage is conformed to
Q/72085584-0.1-2004
2.3 Insulation impedance
The insulation impedance is no less than 20M Ohm, is conformed to

- 2 -
Mianyang Weibo Electronic Co., Ltd
No.98, Youxian East Road, Youxian District, Mianyang City, P.R. China
Tel: [phone] Fax: [phone]
www.wbsensor.com [e-mail]
Q/72085584-0.1-2004
3. Electromagnetic Capability
3.1. Electromagnetic field immunity test according to IEC
61000-4-3:1995
3.2 Power frequency magnetic field immunity test according to IEC
61000-4-8:1993
Product Description and Application
WBV412M05 uses a special isolation module to measure the AC voltage
in the grid and circuit in real time and convert it into DC voltage (Uz)
output. It has advantages of high precision, high isolation, low power
consumption, low drift, wide temperature range and anti-interference,
strong ability, wide working power range and so on. This product adopts
card-mounted structure, terminal wiring, easy installation, three isolation
among input, output and power supply. It is suitable for power equipment,
power network monitoring automation system, industrial control
monitoring system, railway signal system, etc.
Product Dimensional Drawing (unit: mm)

- 3 -
Mianyang Weibo Electronic Co., Ltd
No.98, Youxian East Road, Youxian District, Mianyang City, P.R. China
Tel: [phone] Fax: [phone]
www.wbsensor.com [e-mail]
Product Terminal Identification Drawing
Key Technical Data:
1. Input: 0-10V….0-500V AC;
2. Output: 0-5V, 0-10V DC ;
3. Frequency Range: 25Hz～5kHz ;
4. Accuracy: 0.2% ;
Input Impedance (R): Measurement Ux≥10V, Ri＝Ux×1kΩ/V ;
Measurement Ux＜10V, Ri＝Ux×10kΩ/V ;
5. Linear Range:0~120% of nominal input ;
6. Responding Time: 300ms ;
7. Over Load Capacity: 2 times of nominal input, continuous;
8. Maximum Load(output current): 5mA ;
9. Auxiliary Power: +9V-+36V DC
10. Isolation Voltage(Input/Output) 2500Vdc, for 1 min
(Input/power supply) 2500Vdc, for 1 min
(Output/power supply) 2500Vdc, for 1min
11. Output Ripple: ＜10mv
12. Drifting by Temperature: 150×10-6/℃
13. Ambient Temperature: -25℃～70℃
14. Mounting: DIN Rail 35mm Mount.
*The undefined terminals in the diagram can’t be used.
DC voltage output positive
electrode
(
OUT+
)
Working power grounding (GND)
AC voltage input negative
electrode
(
IN-
)
Positive electrode of
working power (+E)
1
2
3
4 8
7
6
5
12
11
10
9
AC voltage input positive
electrode
(
IN+
)
DC voltage output negative
electrode (OUT-)

- 4 -
Mianyang Weibo Electronic Co., Ltd
No.98, Youxian East Road, Youxian District, Mianyang City, P.R. China
Tel: [phone] Fax: [phone]
www.wbsensor.com [e-mail]
15. Surge (impact) immunity (see IEC61000-4-5): output / power supply
2KV 1.2 / 50μs, performance criteria A;
16. Electrostatic discharge immunity (see IEC61000-4-2): contact
discharge 6KV, air discharge 8KV, performance criterion A;
17. Radio frequency electromagnetic field radiation immunity (see
IEC61000-4-3): Test level 10V/m, performance criterion A;
18. Electrical fast transient burst immunity (see IEC61000-4-4): signal
line port: ± 2KV, auxiliary power port: ± 2KV, performance criterion
A;
19. Conducted immunity of RF electromagnetic field induction (see
IEC61000-4-6): Test level 10V/m, performance criterion A.
Instruction of Installation and Use
1. The product has adopted structure compliance with EN50022;
suitable for DIN rail mounting NS35/7.5, NS35/15. Installation
steps are as following (please reference to dimensional drawing):
Step 1: Immobilize one side of product‘s mounting trough to
the DIN mounting rail;
Step 2: Pull out the spring clasp;
Step 3: Place whole mounting trough to the DIN mounting rail
properly;
Step 4: Release spring clasp to make sure the installation.
2. The product has calibrated before out of factory. After correctly
wiring, it can be powered and used immediately. But for further
precise signal sampling, user need to warm-up the product for 3
minutes before use.
a) the auxiliary power requires isolation voltage≥2000VAC, DC
current output ripple＜10mV.
b) When sensor measuring voltage exceed 1000V, it needs
dividing input voltage by using resistor which is provided by
Weibo electronic. Different sensor uses special resistor.

- 5 -
Mianyang Weibo Electronic Co., Ltd
No.98, Youxian East Road, Youxian District, Mianyang City, P.R. China
Tel: [phone] Fax: [phone]
www.wbsensor.com [e-mail]
3. Basic testing method for accuracy
(1) According to the terminal definition table to connect the
testing circuit;
(2) The testing must to be done by under the following
conditions；
Auxiliary power: DC +9V～+36V, ripple≤5mV
Ambient temperature: 25℃±5℃
Relative humidity: RH(45～75)％
Accuracy for Signal Power Source instrument: 0.05
(3) warming up the sensor for 3 minutes
(4) using output monitoring meter V1 to measuring the output
of signal power source instrument, set a any input value
which is within the measuring range of the sensor Vr. (for
e.g. if input value is 100V, the output is 0-5V, the expected
output value Vz should be calculated as:
Vz=（5V-0V）× Vr/100V
(5) using output monitoring meter V2 to measuring the output
voltage V0 of the sensor, the basic introduced errorγof the
sensor should be calculated as:
γ= (Vo－Vz)/（5V-0V）×100
(6) Repeating (4) (5), if calculated absolute value is less than
the given accuracy value of the sensor, it shows the
sensor’s accurate grade is qualified.
3
Sensor
UX 4
Resistor
Sig
nal
Sou
rce
Sensor
Power
V1
·
·
V2
8
5
1
4
9
++
-
-
12
+ -

- 6 -
Mianyang Weibo Electronic Co., Ltd
No.98, Youxian East Road, Youxian District, Mianyang City, P.R. China
Tel: [phone] Fax: [phone]
www.wbsensor.com [e-mail]
Caution:
1. Pay attention to the auxiliary power information, especially the
auxiliary power grade, and polarity, otherwise will damage the
product.
2. Pay attention to the wire connection; wrong terminal connection
will cause malfunction of the product and even damage the
product;
3. Don’t dismantle the product, and carry with care to avoiding
bump and fall of the product;
4. If the product has been using under the environment with strong
magnetic field interference, please pay attention to the shield of
input wire, and the output signal wire should be as short as
possible. For product intensive installation, the space between
each product should not be smaller than 10mm.
5. Only use identified terminals.
6. There is no lightning strike prevention circuit design in this
product. For outdoor and hazardous environment using, please
add protective alternatives.
7. This product uses fire prevent ABS crust, its temperature
withstand is only limited as +85℃, higher than this limitation
will cause the product deformation. Please use and store
carefully.
